Congratulations on your purchase and welcome to Philips! To fully benet
from the support that Philips offers, register your product at www.philips.
com/welcome.
Please read this user manual, as it contains information about the
wonderful features of this shaver as well as some tips to make shaving
easier and more enjoyable.
Read this user manual carefully before you use the shaver and the Jet
Clean System. Save the user manual for future reference.
- Make sure the adapter does not get wet (Fig. 1).
- Be careful with hot water. Always check if the water is not too hot, to
prevent your hands from getting burnt.
- The adapter contains a transformer. Do not cut off the adapter to
replace it with another plug, as this causes a hazardous situation.
- The shaver and the Jet Clean System are not intended for use by
persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliances by a person responsible for their safety.
- Children should be supervised to ensure that they do not play with
the shaver and the Jet Clean System.
- Do not use the shaver or the Jet Clean System if it is damaged.
- Never immerse the shaver in water (Fig. 2).
- Charge, use and store the shaver at a temperature between 10°C
and 35°C.
- Always put the protection cap on the shaver to protect the shaving
heads when you are travelling.
- The shaver, the Jet Clean System and the other accessories are not
dishwasher-proof.
- Never use water hotter than 80°C to rinse the shaver.
- Do not use the shaver in the bath or in the shower.
- Only use the adapter supplied.
- Never immerse the Jet Clean System in water nor rinse it under the
tap. (Fig. 3)
- If the adapter is damaged, always have it replaced with one of the
original type in order to avoid a hazard.
- Only use the Jet Clean System with the original HQ200 cleaning uid.
- Use and store the Jet Clean System at a temperature between 10°C
and 35°C.
- Always place the Jet Clean System on a stable, level and horizontal
surface to prevent leakage.
- Always place the Jet Clean System on a uid-resistant surface.
- The Jet Clean System thoroughly cleans but does not disinfect your
shaver, therefore do not share the shaver with others.
- The shaver complies with the internationally approved IEC safety
regulations and can be safely cleaned under the tap (Fig. 4).
- The shaver and the Jet Clean System comply with all standards
regarding electromagnetic elds (EMF). If handled properly and
according to the instructions in this user manual, the appliances are
safe to use based on scientic evidence available today.
- The adapter transforms 100-240 volts to a safe low voltage of less
than 24 volts.
- Noise level: Lc = 64 dB [A]
Protection cap
Shaving unit
Shaving unit release button
Shaver on/off button with power-on symbol
Display
Trimmer
Storage pouch
9
Jet Clean System
Locking lever
Cleaning symbol, drying symbol and ‘uid low’ symbol
Jet Clean System on/off button
Cleaning chamber release button
Shaver holder
Cleaning brush
Adapter
Small plug
HQ8290: Before you use the shaver for the rst time, remove the
protective foil from the display.
The three shaver types (HQ8290, HQ8270 and HQ8260) have different
displays, which are shown in the gures below.
- HQ8290 (Fig. 6)
- HQ8270 (Fig. 7)
- HQ8260 (Fig. 8)
Charging takes approx. 60 minutes.
A fully charged shaver has a cordless shaving time of up to 55 minutes,
which is enough for approx. 17 shaves.
- When the shaver is charging, the minutes indication and the plug
symbol ash (Fig. 9).
- The shaving minutes increase until the shaver is fully charged.
- When the shaver is charging, the battery level lights go on in a rising
pattern as the battery charges. (Fig. 10)
- When the battery is fully charged, the minutes indication is visible on
the display and the plug symbol disappears from the display. (Fig. 11)
10
Note: The actual shaving time is calculated by the shaver. If you have a heavy
beard, the shaving time may be less than 55 minutes. The shaving time may
also vary over time, depending on your shaving behaviour, cleaning habits and
beard type.
- After 4 hours of charging, the display automatically switches off and
the charging process stops.
- When the battery is fully charged, all battery level lights light
up continuously (Fig. 12).
- After 4 hours of charging, the battery level lights go out automatically
and the charging process stops.
Note: If the rechargeable battery runs low during shaving, you can connect
the shaver to the mains to nish the shave.
- When the battery is almost empty (when there are only 5 or fewer
shaving minutes left), the minutes indication and the plug symbol
start ashing (Fig. 9).
- When you switch off the shaver, the shaving minutes and the plug
symbol continue to ash for a few more seconds.
- When the battery is almost empty (when there are only 5 or fewer
shaving minutes left), the orange plug symbol lights up. (Fig. 13)
- When you switch off the shaver, the plug symbol ashes for a few
seconds.
The remaining battery capacity is shown when you switch the shaver on
or off:
- The remaining battery capacity is indicated by the number of shaving
minutes shown on the display. (Fig. 11)
11
- The remaining battery capacity is indicated by the number of battery
level lights that are on (Fig. 12).
You can lock the shaver when you are going to travel. The travel lock
prevents the shaver from being switched on by accident.
Note: The travel lock cannot be activated when the shaver is connected to
the mains.
1 Press the on/off button for 4 seconds to enter the travel lock
mode (your display may differ from the one shown in the
gure) (Fig. 14).
,The lock symbol and the power-on symbol in the on/off button
ash for a few seconds to indicate that the travel lock has been
activated.
Note: When you press the on/off button for less than 4 seconds while the
shaver is in the travel lock mode, the lock symbol and the power-on symbol
in the on/off button ash for a few seconds.
1 Press the on/off button for 4 seconds.
,The lock symbol disappears and the motor starts running to
indicate that the travel lock has been deactivated.
The shaver is now ready for use again.
Note: When you start charging, the travel lock is automatically deactivated.
It takes approx. 60 minutes to fully charge the battery.
When you charge the shaver for the rst time or after a long period of
disuse, let it charge for 4 hours.
Tip: To optimise the battery capacity, fully charge the shaver and then use
it normally until the battery is completely empty. Repeat this process three
12
times in a row. If you optimise the battery capacity in this way, you can also
charge the shaver in between shaves, even if the battery is not completely
empty yet.
A fully charged shaver has a cordless shaving time of up to 55 minutes,
which is enough for approx. 17 shaves.
The actual shaving time is calculated by the shaver. If you have a heavy
beard, the shaving time may be less than 55 minutes. The shaving time
may also vary over time, depending on your shaving behaviour, cleaning
habits and beard type.
HQ8290: As the shaver charges, the display shows the number of shaving
minutes available. Depending on the number of minutes you usually need
for one shave, you can determine when the shaver contains enough
energy for one shave.
HQ8270/HQ8260: When the orange plug symbol goes out, the shaver
contains enough energy for one shave.
1 Put the small plug in the Jet Clean System.
2 Put the adapter in the wall socket.
,The holder automatically moves to the highest position.
3 Place the shaver upside down in the holder (Fig. 15).
Note: The shaver cannot be placed in the Jet Clean System when the
protection cap is on the shaving unit.
4 Push the lever down completely to lock the shaver into
place (Fig. 16).
,The battery symbol on the Jet Clean System goes on to indicate
that the shaver is being charged.
Note: When the Jet Clean System is performing the cleaning program, the
battery symbol is out.
,When the battery is fully charged, the battery symbol on the Jet
Clean System goes out and the charging process stops.
13
5 To remove the shaver from the Jet Clean System: move the lever
upwards until it does not go any further (1) and remove the shaver
(2). (Fig. 17)
Do not charge the shaver in a closed pouch.
1 Put the small plug in the shaver.
2 Put the adapter in the wall socket.
,The display shows that the shaver is charging (see chapter ‘The
display’).
Note: You can also use the appliance without charging. Simply connect the
appliance to the mains.
1 Press the on/off button once to switch on the shaver.
,The power-on symbol in the on/off button lights up.
2 Move the shaving heads over your skin. Make both straight and
circular movements (Fig. 18).
- Shaving on a dry face gives the best results.
- Your skin may need 2 or 3 weeks to get accustomed to the Philips
shaving system.
3 Press the on/off button once to switch off the shaver.
4 Clean the shaver (see chapter ‘Cleaning and maintenance’).
You can use the trimmer to groom your sideburns and moustache.
1 Press the on/off button once to switch on the shaver.
,The power-on symbol in the on/off button lights up.
2 Push the trimmer slide downwards to open the trimmer (Fig. 19).
,You can now start trimming.
14
3 After trimming, close the trimmer (‘click’) and switch off the
shaver (Fig. 20).
Never use scouring pads, abrasive cleaning agents or aggressive liquids
such as petrol or acetone to clean the shaver and the Jet Clean System.
- Clean the shaver after every shave for optimal shaving performance.
- The best and most hygienic way to clean the shaver is in the Jet Clean
System. You can also rinse the shaver under the tap or clean it with
the brush supplied.
- Be careful with hot water. Always check if the water is not too hot, to
prevent your hands from getting burnt.
- You can clean the outside of the shaver with a damp cloth.
Note: Water may leak from the socket at the bottom of the appliance when
you rinse it. This is normal and not dangerous.
The Jet Clean System cleans the shaving unit.
- Fill the cleaning chamber before rst use and when the ‘uid low’
symbol ashes to indicate that the uid level is too low. When the
uid level drops below the minimum level, the cleaning symbol and
the ‘uid low’ symbol start to ash with intervals and the holder
returns to its starting position. (Fig. 21)
1 Simultaneously press the release buttons on both sides of the
cleaning chamber (1). Then lift the Jet Clean System off the cleaning
chamber (2). (Fig. 22)
,The cleaning chamber remains behind.
2 Unscrew the cap from the bottle with HQ200 cleaning uid and
remove the airtight seal.
3 Fill the cleaning chamber with HQ200 cleaning uid up to the MAX
indication (Fig. 23).
15
Note: Make sure the cleaning chamber is always lled above the MIN
indication.
4 Place the Jet Clean System back onto the cleaning
chamber (Fig. 24).
Make sure that the release buttons snap back into place.
When the cleaning chamber is lled with cleaning uid, do not move it
to prevent leakage of cleaning uid.
5 Put the small plug in the Jet Clean System and put the adapter in
the wall socket.
,The holder automatically moves to the highest position.
The Jet Clean System is now ready for use.
1 Place the shaver upside down in the holder and push the lever
down completely to lock the shaver into place (Fig. 16).
,The battery symbol on the Jet Clean System goes on to indicate
that the shaver is being charged.
Note: The shaver cannot be placed in the Jet Clean System when the
protection cap is on the shaving unit.
2 Press the on/off button on the Jet Clean System to start the
cleaning program. (Fig. 25)
The cleaning program has two phases, the cleaning and drying phase.
,The battery symbol on the Jet Clean System goes out.
,During the rst phase of the cleaning program, the cleaning symbol
starts to ash and the shaver is automatically lowered into the
cleaning uid (Fig. 26).
,The shaver automatically switches on and off several times
and moves up and down.
,The cleaning symbol ashes throughout the cleaning program,
which takes 8 minutes.
,During the second phase of the cleaning program, the shaver is
placed in the drying position, indicated by a ashing drying symbol.
This phase takes approx. 4 hours. The shaver stays in this position
until the end of the program. (Fig. 27)
16
,After the cleaning program, the battery symbol on the Jet Clean
System goes on to indicate that the shaver is being charged.
Note: If you press the on/off button of the Jet Clean System during the
cleaning program, the program aborts and resets. In this case, the cleaning or
drying symbol stops ashing and the holder returns to its starting position.
The shaver may still be wet and dirty, because the cleaning program has not
been nished.
Note: If you remove the adapter from the wall socket during the cleaning
program, the program aborts. The holder remains in its current position. When
you put the adapter back into the wall socket, the holder moves to the
highest position.
- When the uid level drops below the minimum level, the cleaning
symbol and the ‘uid low’ symbol start to ash with intervals and the
holder returns to its starting position (Fig. 21).
Empty the cleaning chamber and clean it thoroughly by rinsing it with hot
tap water every 15 days if you use the Jet Clean System daily. Otherwise
empty and clean the cleaning chamber at least once a month.
1 Clean the outside of the Jet Clean System with a moist cloth.
Never immerse the Jet Clean System in water nor rinse it under the
tap.
2 Simultaneously press the release buttons on both sides of the Jet
Clean System (1). Then lift the Jet Clean System off the cleaning
chamber (2). (Fig. 22)
,The cleaning chamber remains behind.
3 Pour any remaining cleaning uid out of the cleaning
chamber. (Fig. 28)
You can simply pour the cleaning uid down the sink, this is not harmful
to the environment.
4 Rinse the cleaning chamber under a hot tap (Fig. 29).
Be careful with hot water. Always check if the water is not too hot, to
prevent your hands from getting burnt.
17
The cleaning chamber is not dishwasher-proof.
5 Fill the cleaning chamber with HQ200 cleaning uid up to the MAX
indication (Fig. 23).
Note: Make sure the cleaning chamber is always lled above the MIN
indication.
6 Place the Jet Clean System back onto the cleaning
chamber. (Fig. 24)
Make sure that the release buttons snap back into place.
1 Switch off the shaver and disconnect it from the mains.
2 Press the release button to open the shaving unit (Fig. 30).
3 Rinse the shaving unit and hair chamber under a hot tap for some
time. (Fig. 31)
- Make sure that you clean the inside as well as the outside of the
shaving unit (Fig. 32).
Be careful with hot water. Always check if the water is not too hot, to
prevent your hands from getting burnt.
4 Close the shaving unit and shake off excess water.
Never dry the shaving unit and the hair chamber with a towel or tissue,
as this may damage the shaving heads and the coupling spindles.
5 Open the shaving unit again and leave it open to let the shaver dry
completely.
1 Switch off the shaver and disconnect it from the mains.
2 Press the release button to open the shaving unit (Fig. 30).
3 Turn the lock anticlockwise (1) and remove the retaining frame
(2) (Fig. 33).
18
4 Clean the shaving heads with the brush supplied. Each shaving head
consists of a cutter and a guard (Fig. 34).
Do not clean more than one cutter and guard at a time, since they are all
matching sets. If you accidentally mix up the cutters and guards, it may
take several weeks before optimal shaving performance is restored.
5 Put the shaving heads back into the shaving unit.
6 Put the retaining frame back into the shaving unit and turn the lock
clockwise.
7 Close the shaving unit.
Note: If the shaving unit does not close smoothly, check if you have positioned
the shaving heads properly and if the retaining frame is locked.
Clean the trimmer every time you have used it.
1 Switch off the shaver and disconnect it from the mains.
2 Push the trimmer slide downwards to open the trimmer (Fig. 19).
3 Clean the trimmer with the short-bristled side of the cleaning
brush. Brush up and down along the trimmer teeth. (Fig. 35)
4 Close the trimmer (‘click’).
Tip: For optimal trimming performance, lubricate the trimmer teeth with a
drop of sewing machine oil every six months (Fig. 36).
There are three ways to store the shaver or to take it with you when you
travel:
- put the shaver in the Jet Clean System. Make sure the protection cap
is not on the shaving unit.
Note: If you do not want the shaver to charge while it is stored it in the Jet
Clean System, just leave the lever in the upright position
- put the protection cap on the shaver to prevent damage (Fig. 37).
- store the appliance in the pouch supplied.
19
For maximum shaving performance, we advise you to replace the shaving
heads every two years. Replace damaged shaving heads right away.
Only replace the shaving heads with original HQ9 Philips Shaving Heads.
1 Switch off the shaver. Disconnect the shaver from the mains or
remove it from the Jet Clean System.
2 Press the release button to open the shaving unit (Fig. 30).
3 Turn the lock anticlockwise (1) and remove the retaining frame
(2) (Fig. 33).
4 Remove the shaving heads and place new ones in the shaving unit.
Make sure that the projections of the shaving heads t exactly into the
recesses.
5 Put the retaining frame back into the shaving unit and turn the lock
clockwise.
6 Close the shaving unit.
Note: If the shaving unit does not close smoothly, check if you have positioned
the shaving heads properly and if the retaining frame is locked.
The following accessories are available:
- HQ8500 adapter
- HQ9 Philips Shaving heads
- HQ110 Philips Shaving Head Cleaning Spray (not available in some
countries)
- HQ200 Philips Cleaning Fluid
- HQ8010 car cord.
- Do not throw away the shaver and the Jet Clean System with the
normal household waste at the end of their life, but hand them in at
20
an ofcial collection point for recycling. By doing this, you help to
preserve the environment (Fig. 38).
- The built-in rechargeable shaver battery contains substances that may
pollute the environment. Always remove the battery before you
discard or hand in the shaver at an ofcial collection point. Dispose of
the battery at an ofcial collection point for batteries. If you have
trouble removing the battery, you can also take the appliance to a
Philips service centre. The staff of this centre will remove the battery
for you and will dispose of it in an environmentally safe way.
Only remove the rechargeable battery when you discard the shaver.
Make sure the rechargeable battery is completely empty when you
remove it.
1 Disconnect the shaver from the mains or remove it from the Jet
Clean System.
2 Let the shaver run until it stops and undo the two screws in the
back of the shaver (Fig. 39).
3 Undo the two screws in the hair chamber (Fig. 40).
4 Remove the back panel (Fig. 41).
5 Remove the two side panels (Fig. 42).
6 Bend the 4 hooks aside and take out the power unit (Fig. 43).
Be careful, the hooks are sharp.
7 Undo the three screws in the power unit (Fig. 44).
8 Remove the power unit cover with a screwdriver (Fig. 45).
9 Remove the battery.
Be careful, the battery strips are sharp.
Do not put the shaver back into the plugged-in Jet Clean System after
you have removed the rechargeable battery.
21
Do not connect the shaver to the mains again after you have removed
the rechargeable battery.
If you need service or information or if you have a problem, please visit
the Philips website at www.philips.com or contact the Philips Consumer
Care Centre in your country (you nd its phone number in the
worldwide guarantee leaet). If there is no Consumer Care Centre in
your country, go to your local Philips dealer.
The shaving heads (cutters and guards) are not covered by the terms of
the international guarantee because they are subject to wear.
1 The shaver does not shave as well as it used to.
- The Jet Clean System may not have cleaned the shaver properly
because the cleaning uid in the cleaning chamber is soiled or the
cleaning uid level is too low. Clean the shaver thoroughly before you
continue shaving. If necessary, clean and rell the cleaning chamber
(see chapter ‘Cleaning and maintenance’).
- The shaving heads may be damaged or worn. Replace the shaving
heads (see chapter ‘Replacement’).
- Long hairs may be obstructing the shaving heads. Clean the cutters
and guards with the brush supplied (see chapter ‘Cleaning and
maintenance’).
2 The shaver does not work when I press the on/off button.
- The battery may be empty. Recharge the battery (see chapter
‘Charging’) or connect the shaver to the mains.
- The travel lock may be activated. Press the on/off button for 4
seconds to deactivate the travel lock.
- The temperature of the shaver may be too high. In this case, the
shaver does not work. As soon as the temperature of the shaver has
dropped sufciently, you can switch on the shaver again.
22
Other manuals for HQ8290CC
1
This manual suits for next models
5
Table of contents
Languages:
Other Philips Electric Shaver manuals
Philips
Philips SmartTouch-XL HQ9199 User manual
Philips
Philips OneBlade Pro 360 User manual
Philips
Philips 9000 series User manual
Philips
Philips 7325XL User manual
Philips
Philips QG3352 User manual
Philips
Philips HQ 7830 User manual
Philips
Philips Multitrim QG3040 User manual
Philips
Philips BT5515 User manual
Philips
Philips HQ6996 User manual
Philips
Philips HQ4441, HQ4421, HQ4411, HQ4407, HQ4406,... User manual
Philips
Philips HP6328/03 User manual
Philips
Philips AT887 User manual
Philips
Philips S5290 User manual
Philips
Philips BT3237 User manual
Philips
Philips QC5380 User manual
Philips
Philips RQ1076/21 User manual
Philips
Philips HP6350 User manual
Philips
Philips qs6161 User manual
Philips
Philips HQ 4401 User manual
Philips
Philips QG3322 User manual
