Philips HQ9140 User manual

ENGLISH 4
BAHASA MELAYU 17
INDONESIA 30
TI”NG VI◊T 43
 56
67
79
91
HQ9140

Important
Read these instructions for use carefully before
using the appliance and save them for future
reference.
◗Only use the powerplug supplied.
◗The powerplug transforms 100-240 volts to a
safe low voltage of less than 24 volts.
◗The powerplug contains a transformer. Do
not cut off the powerplug to replace it with
another plug, as this will cause a hazardous
situation.
◗Do not use a damaged powerplug.
◗If the powerplug is damaged, always have it
replaced by one of the original type in order
to avoid a hazard.
◗Make sure the powerplug does not get wet.
◗Charge and store the appliance at a
temperature between 5cC and 35cC.
C◗Never immerse the charging stand in water
nor rinse it under the tap.
◗Do not recharge the shaver in a closed pouch.
◗Always unplug the shaver before cleaning it
under the tap.
C◗The appliance complies with the
internationally approved IEC safety regulations
and can be safely cleaned under the tap.
Be careful with hot water. Always check if the
water is not too hot, to prevent your hands from
getting burnt.
ENGLISH4

Charging
Make sure the appliance is switched off before
you start charging it.
Charging normally takes approx. 1 hour.
You can also shave without charging by
connecting the shaver to the mains.
Charge indications
Charging
C◗When the shaver is being charged, the plug
indicator burns continuously.
Battery fully charged
C◗When the battery has been fully charged, the
battery indicator starts to blink.
Cordless shaving time
A fully charged shaver has a cordless shaving time
of up to 30 days.
ENGLISH 5

Charging the appliance
C1Put the appliance plug in the shaver.
2Put the powerplug in the wall socket.
3Remove the powerplug from the wall
socket and pull the appliance plug out of
the shaver when the battery has been fully
charged.
Charging stand
You can also charge the appliance by placing it in
the charging stand, if provided.
C◗Place the shaver properly in the plugged-in
charging stand.
C◗Lift the shaver from the stand without tilting
it.
Removing and inserting the clock
C1Turn the clock anticlockwise (1) ('click')
and pull it out (2).
ENGLISH6

C2Insert the clock (1) and turn it clockwise
(2) ('click').
Setting the time
C◗Set the time by pressing the small button at
the back of the clock.
The time can only be set forward.
Replacing the battery
C1Remove the cap.Then remove the battery
by means of a miniature screwdriver.
C2Insert a new battery and put the cap back
into place.
ENGLISH 7

Using the appliance
Personal Comfort Control
C◗The Personal Comfort Control system allows
you to adapt the shaver to your skin type.
- You can set the shaver to 'Normal' for a fast
and comfortable close shave.
- You can set the shaver to 'Sensitive' for a
comfortable close shave with optimal skin
comfort.
C◗The 'S' position is best suited for sensitive
skin.
C◗The 'N' position is best suited for normal
skin.
◗The in-between positions are suitable for skin
types between normal and sensitive.
Shaving
1Switch the shaver on by pressing the on/off
button once.
C2Move the shaving heads quickly over your
skin, making both straight and circular
movements.
- Shaving on a dry face gives the best results.
- Your skin may need 2 or 3 weeks to get
accustomed to the Philips shaving system.
ENGLISH8

3Switch the shaver off by pressing the on/off
button once.
C4Put the protection cap on the shaver every
time you have used it, to prevent damage.
Trimming
For grooming sideburns and moustache.
C1Open the trimmer by pushing the slide
downwards.
The trimmer can be activated while the motor is
running.
C2Close the trimmer with your index finger.
Cleaning and maintenance
Regular cleaning guarantees better shaving
performance.
The easiest and most hygienic way to clean the
appliance is to rinse the shaving unit and the hair
chamber with hot water every time you have
used the shaver.
Be careful with hot water. Always check if the
water is not too hot, to prevent your hands from
getting burnt.
ENGLISH 9

Every day: shaving unit and hair chamber
1Switch the shaver off, remove the
powerplug from the wall socket and pull
the appliance plug out of the shaver.
C2Press the release button to open the
shaving unit.
C3Clean the shaving unit and the hair
chamber by rinsing them under a hot tap
for some time.
Make sure the inside of the shaving unit and the
hair chamber have been cleaned properly.
C4Rinse the outside of the appliance.
5Close the shaving unit and shake off excess
water.
Never dry the shaving unit with a towel or tissue
as this may damage the shaving heads.
C6Open the shaving unit again and leave it
open to let the appliance dry completely.
You can also clean the hair chamber without
water by using the brush supplied.
ENGLISH10

Every six months: shaving heads
C1Open the shaving unit, turn the lock
anticlockwise (1) and remove the retaining
frame (2).
2Clean the cutters and guards with the
brush supplied.
Do not clean more than one cutter and guard at
a time, since they are all matching sets. If you
accidentally mix up the cutters and guards, it may
take several weeks before optimal shaving
performance is restored.
3Put the shaving heads back into the shaving
unit. Put the retaining frame back into the
shaving unit and turn it clockwise.
4Close the shaving unit.
Trimmer
Clean the trimmer every time you have used it.
1Switch the shaver off, remove the
powerplug from the wall socket and pull
the appliance plug out of the shaver.
C2Clean the trimmer with the brush
supplied.
ENGLISH 11

C3Lubricate the trimmer teeth with a drop
of sewing machine oil every six months.
Charging stand
Never immerse the charging stand in water nor
rinse it under the tap.
You can clean the charging stand with a moist cloth.
Storage
C◗Put the protection cap on the shaver to
prevent damage.
C◗Store the appliance in the luxury pouch or
place the appliance in the stand.
Replacement
Replace the shaving heads every two years for
optimal shaving results.
Replace damaged or worn shaving heads with
HQ9 Philips shaving heads only.
ENGLISH12

1Switch the shaver off, remove the
powerplug from the wall socket and pull
the appliance plug out of the shaver.
C2Press the release button to open the
shaving unit.
C3Turn the lock anticlockwise (1) and
remove the retaining frame (2).
C4Remove the shaving heads and place new
ones in the shaving unit.
Make sure that the projections of the shaving
heads fit exactly into the recesses.
C5Put the retaining frame back into the
shaving unit (1) and turn the lock
clockwise (2).
6Close the shaving unit.
Accessories
The following accessories are available:
- HQ8500/HQ8000 powerplug.
- HQ9 Philips shaving heads.
- HQ110 Philips shaving head cleaner (shaving
head cleaning spray).
- HQ8010 car cord.
ENGLISH 13

Environment
C◗Do not throw the appliance away with the
normal household waste at the end of its life,
but hand it in at an official collection point for
recycling. By doing this you will help to
preserve the environment.
◗The built-in rechargeable battery contains
substances that may pollute the environment.
Always remove the battery before discarding
the appliance or handing it in at an official
collection point. Dispose of the battery at an
official collection point for batteries. If you
have trouble removing the battery, you can
also take the appliance to a Philips service
centre, which will remove the battery for you
and will dispose of it in an environmentally
safe way.
Disposal of the shaver battery
Only remove the battery if it is completely empty.
1Remove the powerplug from the wall
socket and pull the appliance plug out of
the shaver.
C2Let the shaver run until it stops, undo the
screws and open the shaver.
3Remove the battery.
Do not connect the shaver to the mains again
after the battery has been removed.
ENGLISH14

Guarantee & service
If you need information or if you have a problem,
please visit the Philips website at www.philips.com
or contact the Philips Customer Care Centre in
your country (you will find its phone number in
the worldwide guarantee leaflet). If there is no
Customer Care Centre in your country, turn to
your local Philips dealer or contact the Service
Department of Philips Domestic Appliances and
Personal Care BV.
Troubleshooting
1Reduced shaving performance
BCause 1: the shaving heads are dirty.
The shaver has not been rinsed long enough or
the water used was not hot enough.
◗Clean the shaver thoroughly before you
continue shaving. See chapter 'Cleaning and
maintenance'.
BCause 2: long hairs are obstructing the shaving
heads.
◗Clean the cutters and guards with the brush
supplied. See chapter 'Cleaning and
maintenance', section 'Every six months:
shaving heads'.
ENGLISH 15

BCause 3: the shaving heads are damaged or worn.
◗Replace the shaving heads. See chapter
'Replacement'.
2The shaver does not work when the on/off
button is pressed.
BCause 1: the battery is empty.
◗Recharge the battery. See chapter 'Charging'.
BCause 2: the appliance is not connected to the
mains.
◗Put the powerplug in the wall socket.
C3The shaving unit has come off the shaver.
BCause: the shaving unit has not been placed
correctly.
◗If the shaving unit becomes detached from the
shaver, you can easily reattach it ('click').
ENGLISH16

Penting
Baca arahan penggunaan ini dengan teliti sebelum
menggunakan perkakas dan simpan untuk rujukan
di masa depan.
◗Hanya gunakan plag kuasa yang dibekalkan.
◗Plag kuasa mengubah 100-240 volt kepada
voltan rendah dan selamat tidak melebihi 24
volt.
◗Plag kuasa mengandungi sebuah transformer.
Jangan potong plag kuasa untuk
menggantikannya dengan plag yang lain kerana
ini akan menimbulkan situasi berbahaya.
◗Jangan gunakan plag kuasa yang rosak.
◗Jika plag kuasa rosak, gantikan dengan penggati
jenis tulen untuk mengelakkan daripada
kemudaratan.
◗Pastikan plag kuasa tidak kena basah.
◗Cas dan simpan perkakas pada suhu antara
5cC dan 35cC.
C◗Jangan rendam penegak cas di dalam air atau
membilasnya di bawah pilih air.
◗Jangan mengecas semula pencukur di dalam
pau tertutup.
◗Sentiasa cabut plag daripada pencukur
sebelum membersihkannya di bawah pili air.
C◗Peralatan ini mematuhi peraturan keselamatan
antarabangsa IEC yang diluluskan dan selamat
dibersihkan dengan air paip.
Berhati-hati dengan air panas. Sentiasa periksa
agar air tidak begitu panas, untuk mengelakkan
tangan anda daripada kelecuran.
BAHASA MELAYU 17

Mengecas
Pastikan peralatan dimatikan sebelum dicas.
Mengecas alat pencukur biasanya mengambil masa
lebih kurang 1 jam.
Anda juga dapat bercukur tanpa mengecas,
dengan menyambung pencukur kepada punca
kuasa utama.
Arahan cas
Mengecas
C◗Apabila pencukur sedang dicas, penunjuk plag
terus menyala.
Bateri yang sudah dicas sepenuhnya.
C◗Apabila bateri telah dicas sepenuhnya,
penunjuk bateri mula berkelip.
Masa pencukuran tanpa kord
Pencukur yang sudah dicas sepenuhnya
mempunyai masa mencukur tanpa kord selama 30
hari.
BAHASA MELAYU18

Mengecas perkakas
C1Pasangkan plag peralatan pada alat
pencukur.
2Pasangkan plag kuasa ke soket dinding.
3Cabut palam wayar dari soket dan cabut
palam alat dari pencukur apabila bateri
telah dicas penuh.
Penegak cas
Anda boleh juga mengecas perkakas dengan
meletakkannya di dalam penegak cas, jika
disediakan.
C◗Letakkan pencukur dengan baik di dalam
penegak cas yang sudah diplag.
C◗Angkat pencukur dari penegak tanpa
memiringkannya.
Menanggalkan dan memasukkan jam
C1Pusingkan jam ke arah lawan jam (1) ('klik')
dan tariknya keluar (2).
BAHASA MELAYU 19

C2Masukkan jam (1) dan pusingkannya ke
arah jam (2) ('klik').
Mengeset masa
C◗Mengeset masa dengan menekan butang kecil
di bahagian belakang jam.
Masa hanya boleh diset ke hadapan.
Menggantikan bateri
C1Tanggalkan tukup. Kemudian keluarkan
bateri dengan menggunakan pemutar skru
kecil.
C2Masukkan bateri baru dan pasang kembali
tukup ke tempat asalnya.
BAHASA MELAYU20

Menggunakan perkakas
Kawalan Keselesaan Peribadi
C◗Sistem Kawalan Keselesaan Peribadi
menyesuaikan pencukur dengan jenis kulit
anda.
- Anda boleh tetapkan pencukur kepada
'Normal' untuk cukuran yang cepat dan selesa.
- Anda boleh tetapkan pencukur kepada
'Sensitive' untuk cukuran selesa dengan
keselesaan kulit yang optimum.
C◗Kedudukan 'S' adalah sesuai sekali untuk kulit
sensitif.
C◗Kedudukan 'N' adalah sesuai sekali untuk kulit
biasa.
◗Kedudukan di antaranya adalah sesuai untuk
jenis kulit antara biasa dan sensitif.
Pencukuran
1Hidupkan alat pencukur dengan menekan
butang hidup/mati sekali.
C2Gerakkan kepala pencukur denagn gerakan
lurus dan membulat di atas permukaan
kulit dengan pantas.
- Hasil pencukuran yang terbaik akan terhasil jika
muka anda kering.
- Kulit anda mungkin memerlukan 2 atau 3
minggu untuk membiasakan diri dengan sistem
pencukuran Philips.
BAHASA MELAYU 21

3Matikan pencukur dengan menekan butang
hidup/mati sekali.
C4Pasang semula penutup pelindung pada
pencukur selepas setiap penggunaan untuk
mengelakkan kerosakan.
Perapian
Untuk merapikan jambang dan kumis kemas.
C1Buka perapi dengan menolak gelangsar ke
bawah.
Perapi dapat dihidupkan semasa motor berjalan.
C2Tutup perapi dengan jari telunjuk anda.
Pembersihan dan penyenggaraan
Membersih alat pencukur dengan kerapkali
menjamin prestasi pencukuran terbaik.
Cara yang senang dan bersih untuk mencuci
peralatan adalah membilas unit mencukur dan
ruangan menyimpan rambut dengan air panas
setiap kali setelah anda menggunakan alat
pencukur tersebut.
BAHASA MELAYU22
