Philips S100 Series User manual

1
2
4
5
6
7
8
3
1
ENGLISH
Congratulations on your purchase and
welcome to Philips! To fully benet from
the support that Philips oers, register
your product at www.philips.com/
welcome.
General description (Fig. 1)
1 Protection cap
2 Shaving unit
3 Ag+ antibacterial feature (S118, S116,
S111 only)
4 On/o slide
5 Socket for small plug
6 Cleaning brush
7 Supply unit (adapter, type A00390)
8 Small plug
Important safety
information
Read this important information
carefully before you use the appliance
and save it for future reference.
Danger
-Keep the supply unit dry (Fig. 2).
Warning
-To charge the battery, only use
the detachable supply unit (type
A00390) provided with the appliance.
-The supply unit contains a
transformer. Do not cut o the
supply unit to replace it with
another plug, as this causes a
hazardous situation.
-This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning
use of the appliance in a safe
way and understand the hazards
involved. Children shall not play with
the appliance. Cleaning and user
maintenance shall not be made by
children without supervision.
-Always unplug the shaver before
you clean it under the tap.
-Always check the appliance before
you use it. Do not use the appliance
if it is damaged, as this may cause
injury. Always replace a damaged
part with one of the original type.
-Do not open the appliance to
replace the rechargeable battery.
Caution
-Never immerse the cleaning system
or the charging stand in water and
do not rinse it under the tap (Fig. 2).
-Never immerse the shaver in water.
Do not use the shaver in the bath or
in the shower.
-Never use water hotter than 80°C to
rinse the shaver.
-Only use this appliance for its
intended purpose as shown in the
user manual.
-For hygienic reasons, the appliance
should only be used by one person.
-Never use compressed air, scouring
pads, abrasive cleaning agents or
aggressive liquids such as petrol or
acetone to clean the appliance.
-If your shaver comes with a
cleaning system, always use the
original Philips cleaning uid
(cartridge or bottle, depending on
the type of cleaning system).
-Always place the cleaning system
on a stable, level and horizontal
surface to prevent leakage.
-If your cleaning system uses a
cleaning cartridge, always make sure
the cartridge compartment is closed
before you use the cleaning system
to clean or charge the shaver.
-When the cleaning system is ready
for use, do not move it to prevent
leakage of cleaning uid.
-Water may drip from the socket
at the bottom of the shaver when
you rinse it. This is normal and not
dangerous because all electronics
are enclosed in a sealed power unit
inside the shaver.
-Do not use the supply unit in or near
wall sockets that contain an electric
air freshener to prevent irreparable
damage to the supply unit.
Electromagnetic elds (EMF)
-This Philips appliance complies
with all applicable standards and
regulations regarding exposure to
electromagnetic elds.
General
-This shaver can be safely cleaned
under the tap (Fig. 3).
-The appliance is suitable for mains
voltages ranging from 100 to 240 volts.
-The supply unit transforms 100-
240 volts to a safe low voltage of
less than 24 volts.
4222.002.5953.1
www.philips.com
>75% recycled paper
S100
S118, S116, S111, S108,S101
2
5
8
11
3
6
9
12
4
7
10
13
14
17
20
23
1
2
15
18
21
16
19
2
1
22

Note: Do not clean more than
one cutter and guard at a time,
since they are all matching sets.
If you accidentally put a cutter in
the wrong shaving guard, it may
take several weeks before optimal
shaving performance is restored.
5 Remove the guard from the cutter
(Fig. 17).
6 Clean the cutter and guard under
the tap (Fig. 18Fig. 19).
-For additional cleaning you can
also start by using the cleaning
brush to remove hairs.
7 Put the cutter back into the guard
after cleaning (Fig. 20).
8 Put the shaving heads back into the
shaving unit (Fig. 21).
9 Put the retaining frame back into
the shaving unit and turn the
orange wheel clockwise (Fig. 22).
10 Put the shaving unit back onto the
shaver (Fig. 14).
Storage
We advise you to let the shaver dry
before you put the protection cap on it.
1 Switch o the shaver.
2 Put the protection cap on the
shaver after use to prevent damage
and to avoid dirt accumulation in
the shaving heads (Fig. 23).
Replacement
For maximum shaving performance, we
advise you to replace the shaving heads
every two years. Replace damaged
shaving heads immediately. Always
replace the shaving heads with original
Philips shaving heads as specied in the
chapter‚ Ordering accessories‘.
For instructions on how to remove the
shaving heads, see chapter‚ Cleaning
and maintenance‘, section‚ Every two
months: shaving heads‘.
Ordering accessories
To buy accessories or spare parts,
visit www.shop.philips.com/service
or go to your Philips dealer. You can
also contact the Philips Consumer
Care Centre in your country (see
the worldwide guarantee leaet for
contact details).
The following accessories and spare
parts are available:
-A00390 adapter
-SH30 Philips shaving heads
-HQ110 Philips shaving head
cleaning spray
Charging
Charging takes approx. 10 hours. A fully
charged shaver has a shaving time of
up to 20 minutes.
-Charge the appliance when the
motor stops or starts running
slower. For optimal performance,
only charge the shaver when the
battery is low.
-Make sure the shaver is switched
o when you start to charge it.
-When you charge the shaver for the
rst time or after a long period of
non-use, let it charge continuously
for 12 hours. Charging normally
takes 10 hours.
Caution: Do not leave the appliance
connected to the power outlet for
more than 24 hours.
Note: You cannot use the appliance
while it is charging.
1 Make sure the appliance is
switched o.
2 Put the supply unit in the wall
socket and put the small plug in the
appliance (Fig. 4).
3 After charging, remove the supply
unit from the wall socket and pull
the small plug out of the appliance.
Using the appliance
Note: This appliance can only be used
without cord (Fig. 5).
Switching the appliance on
and o
-To switch on the appliance, push
the on/o slide upwards (Fig. 6).
-To switch o the appliance, push
the on/o slide downwards (Fig. 6).
Skin adaptation period
Your rst shaves may not bring you the
result you expect and your skin may
even become slightly irritated. This is
normal. Your skin and beard need time
to adapt to any new shaving system.
To allow your skin to adapt to this new
appliance, we advise you to shave
regularly (at least 3 times a week) and
exclusively with this appliance for a
period of 3 weeks.
1 Switch on the appliance.
2 Move the shaving heads over your
skin. Make both straight and circular
movements (Fig. 7).
Recycling
-Do not throw away the product
with the normal household waste
at the end of its life, but hand it in
at an ocial collection point for
recycling. By doing this, you help to
preserve the environment.
-This product contains a built-in
rechargeable battery which shall
not be disposed of with normal
household waste. We strongly
advise you to take your product
to an ocial collection point
or a Philips service centre to
have a professional remove the
rechargeable battery.
-Follow your country’s rules for the
separate collection of electrical
and electronic products and
rechargeable batteries. Correct
disposal helps prevent negative
consequences for the environment
and human health.
Removing the rechargeable
battery
Only remove the rechargeable
battery when you discard the shaver.
Before you remove the battery, make
sure that the shaver is disconnected
from the wall socket and that the
battery is completely empty
Take any necessary safety
precautions when you handle tools
to open the shaver and when you
dispose of the rechargeable battery.
1 Check if there are screws in the
back of the shaver or in the hair
chamber. If so, remove them.
2 Remove the outer panels of the
shaver with a screwdriver or other
tool. If necessary, also remove
additional screws and/or parts until
you see the printed circuit board
with the rechargeable battery.
3 Remove the rechargeable battery.
Warranty and support
If you need information or support,
please visit www.philips.com/support
or read the international warranty
leaet.
Warranty restrictions
The shaving heads (cutters and guards)
are not covered by the terms of the
international warranty because they
are subject to wear.
Note: Shave on a dry face only.
Do not use the shaver in
combination with shaving gel,
shaving foam or water.
3 Clean the appliance after use.
Cleaning and maintenance
Cleaning the shaver under
the tap
Clean the shaver after every shave for
optimal performance.
Caution: Be careful with hot water.
Always check if the water is not too
hot, to prevent burning your hands.
Caution: Never dry the shaving unit
with a towel or tissue, as this may
damage the shaving heads.
1 Switch o the appliance and
disconnect it from the power outlet.
2 Rinse the shaving unit under a
warm tap (Fig. 8).
-For additional cleaning you can
also start by using the cleaning
brush to remove hairs (Fig. 9).
3 Pull the shaving unit o the shaver in
a straight upward movement (Fig. 10).
4 Rinse the shaving unit and hair
chamber under a warm tap
(Fig. 11, Fig. 12).
-For additional cleaning you can
also start by using the cleaning
brush to remove hairs.
5 Carefully shake o excess water
and let the shaving unit and hair
chamber dry (Fig. 13).
6 Put the shaving unit back onto the
shaver (Fig. 14).
Every two months: shaving heads
Note: Do not use cleaning agents or
alcohol to clean the shaving heads. Only
use Philips Cleaning Spray (HQ110).
1 Switch o the shaver, remove the
adapter from the wall socket and
pull the small plug out of the shaver.
2 Pull the shaving unit o the shaver in
a straight upward movement (Fig. 10).
3 Turn the orange wheel
anticlockwise and remove the
retaining frame (Fig. 15).
4 Remove and clean one shaving head
at a time. Each shaving head consists
of a cutter and a guard (Fig. 16).
Troubleshooting
This chapter summarizes the most
common problems you could
encounter with the appliance. If you
are unable to solve the problem with
the information below, visit
www.philips.com/support for a
list of frequently asked questions or
contact the Consumer Care Center in
your country.
Prob-
lem
Possible
cause
Solution
The
shaver
does not
shave as
well as it
used to.
The
shaving
heads are
dirty. You
have not
cleaned
the shaver
well
enough
or you
have not
cleaned it
for a long
time.
Clean the
shaving heads
thoroughly
before you
continue
shaving (see
'Cleaning and
maintenance').
Long
hairs
obstruct
the
shaving
heads.
Clean the
cutters and
guards (see
'Every two
months:
shaving
heads').
You
mixed up
the cutters
and
guards
when you
placed
them back
into the
retaining
frame
after
cleaning.
Put each
cutter in the
other guard.
If you do
not switch
the cutters,
it may take
2 to 3 weeks
until optimal
shaving
performance
is restored.
The
shaving
heads are
damaged
or worn.
Replace
the shaving
heads.

-使用前請務必檢查本產品。 若產品受
損請勿使用，以免受傷。 零件如有受
損，請務必以原型號更換之。
-請勿拆開本產品更換充電式電池。
警告
-切勿將清潔系統或充電座浸入水中，
或直接在水龍頭下沖洗 (圖 2)。
-請勿將電鬍刀浸泡在水中。 請勿在泡
澡或淋浴時使用電鬍刀。
-切勿使用超過 80°C 的熱水沖洗電
鬍刀。
-本產品儘限用於本使用手冊所述之相
關用途。
-為保衛生起見，請勿多人共用本產品。
-絕對不可使用壓縮空氣、鋼絲絨、磨蝕
性的清潔劑或侵蝕性的液體 (例如汽油
或丙酮) 清潔本產品。
-如果您的電鬍刀配備清潔系統，請務必
使用飛利浦原廠清潔液 (補充匣或補充
瓶，依清潔系統的類型而定)。
-請務必將清潔系統放置在穩固、平整的
水平面上，以防滲漏。
-如果您的清潔系統使用的是補充匣，
在使用清潔系統清潔電鬍刀或為電鬍
刀充電之前，請務必確定補充匣室已
關閉。
-當清潔系統準備就緒可供使用時，
應避免移動它，以防清潔液漏出。
-在您沖洗時，電鬍刀底部的插孔可能會
滴水。 此為正常現象，並不會造成危
險，因為所有的電子零件都密封於電鬍
刀內的電力裝置中。
-請勿在插入電子空氣清淨機的牆壁插座
內或附近使用電源供應裝置，以免電源
供應裝置發生無法修復的損壞。
電磁波 (EMF)
-本Philips產品符合所有電磁場暴露的相
關適用標準和法規。
一般
-此電鬍刀可在水龍頭下 (圖 3)安全地
清洗。
-本產品適用於 100 到 240 伏特的插座
電壓。
-電源供應裝置可以將 100-240 伏特的電
壓轉換為低於 24 伏特的安全低電壓。
充電
充電時間約需 10 個小時。 完全充電的電
鬍刀可持續刮鬍約 20 分鐘。
-請在馬達停止轉動時或者運轉速度開
始變慢時，為產品充電。 為達到最佳
性能，只有在電力不足時，才需要替電
鬍刀充電。
-開始充電之前，務必將電鬍刀的電源
關閉。
-第一次為電鬍刀充電時，或長期未用後，
請連續充電 12 小時。 正常的充電約
需 10 小時。
The
shaver
does
not work
when
I push
the on/
o slide
upwards.
The
recharge-
able
battery is
empty.
Recharge the
battery (see
'Charging').
My
skin is
irritated
after
shaving.
Your skin
needs
time to
get used
to the
Philips
shaving
system.
Skin irritation
during the rst
2-3 weeks
of use is
possible. After
this period, the
skin irritation
usually
disappears.
The
rotation
speed
of the
shaving
heads is
slower
than
usual.
Too
much
dirt has
collected
in the
shaving
heads.
Clean the
shaving
heads (see
'Cleaning and
maintenance').
The
recharge-
able
battery is
low.
Recharge the
battery (see
'Charging').
Prob-
lem
Possible
cause
Solution
The
appli-
ance
makes a
strange
noise.
Too
much
dirt has
collected
in the
shaving
heads.
Clean the
shaving
heads (see
'Cleaning and
maintenance').
After cleaning,
lubricate the
central point
on the inside
of the guards
with Philips
Cleaning
Spray (HQ110).
The
shaving
heads are
damaged
or worn.
Replace the
shaving heads
(see 'Replace-
ment').
警告： 請勿讓產品連續連接電源插座超
過 24 小時。
注意： 您無法在充電時使用本產品。
1 確定關閉本產品的電源。
2 將電源供應裝置插入牆壁的插座，並將
小插頭插入產品 (圖 4)中。
3 充電完畢請將電源供應裝置拔離電源
插座，並將小插頭從產品上拔除。
使用本產品
注意： 本產品只能以無線 (圖 5)方式使用。
開啟及關閉本產品
-若要開啟本產品電源，請將 on/off
開關往上 (圖 6)推。
-若要關閉本產品電源，請將 on/off
開關往下 (圖 6)推。
皮膚適應期
您第一次刮鬍的結果可能不如您所預期，
皮膚甚至可能稍微刺痛。 這是正常現象。
您的皮膚與鬍鬚需要時間適應新的刮鬍
系統。 建議您用這把電鬍刀定期刮鬍
(每週至少 3 次) 為期 3 週，讓您的肌膚適
應新的電鬍刀。
1 開啟產品電源。
2 讓電鬍刀刀頭在皮膚上移動。 請同時
用直線及畫圓的方式來移動 (圖 7)。
注意： 僅可乾刮。 使用電鬍刀時，
請勿搭配刮鬍凝露、刮鬍泡或水。
3 使用後需清潔本產品。
清潔與維護
將電鬍刀放在水龍頭下沖洗
為達到最佳性能，請於每回刮鬍之後清潔
電鬍刀。
警告： 使用熱水時請小心。 隨時檢查熱
水是否太燙，以避免手部燙傷。
警告： 切勿使用毛巾或紙巾擦乾電鬍刀組，
否則可能會造成電鬍刀刀頭損壞。
1 關閉產品電源，並將產品插頭從插座
拔下。
2 將電鬍刀組以溫水 (圖 8)沖洗。
-如要進行額外的清潔，您可先從使用清
潔刷清除鬍渣 (圖 9)開始。
3 以垂直向上拉起的方式 (圖 10)，將電
鬍刀組自電鬍刀上取下。
4 在 水龍頭 (圖 11圖 12)下以溫水沖洗電
鬍刀組與鬍渣室。
-如要進行額外的清潔，您可先從使用清
潔刷清除鬍渣開始。
5 仔細甩乾多餘的水份之後，讓電鬍刀組
與鬍渣室乾燥 (圖 13)。
6 將電鬍刀組裝回電鬍刀 (圖 14)上。
I con-
nect-
ed the
appli-
ance
to the
mains,
but I was
not able
to (nish
my)
shave.
The
recharge-
able
battery is
empty.
The shaver
does not
run from the
mains. When
the battery
is empty,
you have to
recharge the
battery and
then unplug
the shaver
before you
can use the
shaver again.
繁體中文
感謝您購買本產品。歡迎來到飛利浦的世
界！ 為充分享受飛利浦為您提供的好處，
請至下列位址註冊產品：www.philips.com/
welcome。
一般說明 (圖 1)
1 保護蓋
2 除毛刀頭組
3 銀離子抗菌功能 (僅限 S118、S116、
S111)
4 On/Off 滑動開關
5 小插頭插座
6 清潔刷
7 電源供應裝置 (電源轉換器，
型號 A00390)
8 小插頭
重要安全資訊
使用本產品前，請先仔細閱讀此重要資訊，
並保留說明以供日後參考。
危險
-電源供應裝置請保持乾燥 (圖 2)。
警示
-如需為電池充電，僅可使用裝置隨附的
可拆式電源供應裝置 (型號：A00390)。
-電源供應裝置內含一個變壓器。 請勿
切斷電源供應裝置而以其他的插頭取
代，否則會造成危險。
-本產品可供 8 歲以上兒童、身體官能
或心智能力退化者，或是經驗與使用知
識缺乏者使用，但需有人從旁監督或指
示如何安全使用本產品，且使用者需了
解使用本產品的潛在危險。 請勿讓小
孩把玩本產品。 若無人監督，請勿讓
兒童進行清潔和使用者維護。
-在水龍頭下沖洗電鬍刀之前，請先拔掉
電鬍刀的插頭。
每兩個月： 電鬍刀刀頭
注意： 請勿使用清潔劑或酒精清潔電鬍
刀刀頭， 務必使用飛利浦噴霧清潔劑
(HQ110)。
1 關閉電鬍刀電源，將轉換器從電源插座
拔下，並將小插頭自電鬍刀上拔下。
2 以垂直向上拉起的方式 (圖 10)，將電
鬍刀組自電鬍刀上取下。
3 以逆時針方向轉動橘色轉盤，將固定架
(圖 15)拆下。
4 一次取下並清洗一個刀頭。 每個電鬍刀
刀頭都是由刀具和刀網 (圖 16)組成。
注意： 刀具及刀網是成對組合，請勿
一次清潔超過一組。 如果您不小心將
刀片放進錯誤的電鬍刀刀網中，可能
要花幾週的時間才能恢復最理想的刮
鬍效果。
5 取下刀具 (圖 17)的刀網。
6 將刀片及刀網放在水龍頭 (圖 18圖 19)
下清洗。
-如要進行額外的清潔，您可先從使用清
潔刷清除鬍渣開始。
7 清潔 (圖 20)後，將刀具放回刀網中。
8 將電鬍刀刀頭裝回電鬍刀組 (圖 21)。
9 將固定架裝回電鬍刀組，並以順時針方
向 (圖 22)轉動橘色轉盤。
10 將電鬍刀組裝回電鬍刀 (圖 14)上。
存放
我們建議您先將電鬍刀晾乾，再蓋上保
護蓋。
1 請關閉電鬍刀電源。
2 使用後請為電鬍刀蓋上保護蓋以防損
壞，並避免污垢累積在電鬍刀刀頭
(圖 23)中。
更換
為達到最佳刮鬍性能，我們建議您每兩年
更換一次電鬍刀刀頭。 刀頭若受損，請立
即更換。 更換電鬍刀刀頭時，請一律使用
「訂購配件」單元中所指明的原廠飛利浦
電鬍刀刀頭。
有關如何取下電鬍刀刀頭的說明，請參閱
「清潔與維護」單元之「每兩個月： 電鬍
刀刀頭」一節。
訂購配件
若要購買配件或備用零件，請造訪
www.shop.philips.com/service，或洽詢您
的飛利浦經銷商。 您也可以聯絡您所在國
家/地區的飛利浦客戶服務中心 (詳細聯絡
資料請參閱全球保證書)。
備有下列配件及備用零件可供另外選購：
-A00390 變壓器
-SH30 飛利浦電鬍刀頭
-HQ110 飛利浦電鬍刀刀頭噴霧清潔劑

我已將本
產品連接
電源，
但無法
(完成) 刮
鬍。
充電式電
池沒電。
電鬍刀無法插
電運轉。 電池
電力耗盡時，
您必須先讓電
池充電，然後
拔掉電鬍刀的
插頭，才能
再度使用電鬍
刀。
長鬍鬚卡
住電鬍刀
刀頭。
清潔刀具
及刀網
後，將其
放回固定
架時，把
刀具及刀
網混在一
起。
把每一片刀具
放入另一個刀
網。 如果您沒
有調換刀具，
可能要花 2 到
3 週的時間才
能恢復最理想
的刮鬍效果。
把每一片
刀具放入
另一個刀
網。 如
果您沒
有調換刀
具，可能
要花 2 到
3 週的時
間才能恢
復最理想
的刮鬍效
果。
電鬍刀刀
頭毀壞或
磨損。
更換刀頭。
將 On/Off
滑動開關
往上推，
但電鬍刀
無法運
作。
充電式電
池沒電。
將電池 (見
'充電')重新充
電。
刮鬍之
後，皮
膚感到刺
痛。
您的皮膚
需要一些
時間才能
適應飛利
浦電鬍刀
系統。
開始使用的第
2 到 3 週，皮
膚可能會有過
敏現象。 過了
這段時間，皮
膚過敏的症狀
通常會消失。
刀頭的旋
轉速度比
平常緩
慢。
過多污垢
累積在電
鬍刀刀頭
中。
清潔刀頭
(見 '清潔與維
護')。
充電式電
池電力不
足。
將電池 (見 '
充電')重新充
電。
產品發出
奇怪的噪
音。
過多污垢
累積在電
鬍刀刀頭
中。
清潔刀頭 (見
'清潔與維
護')。 清潔
後，請使用飛
利浦噴霧清潔
劑 (HQ110) 潤
滑刀網內側的
中心點。
電鬍刀刀
頭毀壞或
磨損。
更換刀頭 (見
'更換')。
回收
-本產品使用壽命結束時請勿與一般家
庭廢棄物一併丟棄。請將該產品放置於
政府指定的回收站， 此舉能為環保盡
一份心力。
-本產品包含內建充電式電池，不得與
一般家用廢棄物一併丟棄。 強烈建
議您將產品攜至政府指定的回收站或
Philips 服務中心，由專業人員取出充
電式電池。
-請按照您所在國家/地區的規定，分類
與回收電子電器產品及充電式電池。
正確處理廢棄產品有助於避免對環境和
人類健康帶來負面影響。
取出充電式電池
請僅在棄置電鬍刀前取出充電式電池。
取出電池前，請確認電鬍刀已從牆上插
座拔出，且電池電力已完全耗盡
使用工具打開電鬍刀或棄置充電式電池
時，請採取任何必要的安全預防措施。
1 檢查電鬍刀背面或鬍渣室是否有螺絲。
如有的話請拆下。
2 使用螺絲起子或其他工具拆除電鬍刀外
部面板。 必要時，也可拆下其他螺絲
和/或零件，直到清楚看見印刷電路板
與充電式電池為止。
3 取出充電式電池。
保固與支援
如需資訊或支援，請造訪：www.philips.com/
support，或另行參閱全球保證書。
保固限制
電鬍刀刀頭 (刀具和刀網) 由於其耗損性，
因此不在全球保固範圍內。
疑難排解
本章概述了使用本產品最常遇到的問題。
如果無法利用以下資訊解決遇到的問題，
請造訪 www.philips.com/support 瀏覽常
見問題清單，或聯絡您所在國家/地區的飛
利浦客戶服務中心。
問題 可能原因 解決方法
電鬍刀
不像平
常一樣運
作。
電鬍刀刀
頭髒污。
電鬍刀清
潔不夠徹
底或是太
久沒有清
潔。
在您繼續刮鬍
(見 '清潔與維
護')之前，請徹
底清潔刀頭。
問題 長鬍鬚卡
住電鬍刀
刀頭。
清潔刀片及刀
網 (見 '每兩個
月： 電鬍刀刀
頭')。
