Philips Ladyshave HP6342 User manual

HP6342, HP6341

2

3
D
G
F
E
H
B
A
C
1

4


 6
 15
 25
 34
 43
 52
 61
 70
 79
 88
 98
 107
 117
 126
 134
 143

6

Congratulations on your purchase and welcome to Philips! To fully benet
from the support that Philips offers, register your product at www.philips.
com/welcome.
With your new Philips Ladyshave you can quickly, easily and comfortably
remove unwanted body hair. You can use the Ladyshave either dry or wet.
If you shave while taking a bath or shower, we advise you to use soap or
shaving foam for the most comfortable shave. After use, you can clean the
Ladyshave under the tap or with the cleaning brush for extra hygiene.

 Shaving unit with shaving foil and pre-trimmer
 Shaving head
 On/off slide
 Battery compartment cover
 Protection cap
 Efciency cap (HP6342 only)
 3mm trimming comb (HP6342 only)
 Cleaning brush
Not shown: Pouch (HP6342 only)

Read this user manual carefully before you use the appliance and save it
for future reference.

- This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
- Children should be supervised to ensure that they do not play with
the appliance.



- Make sure your hands and the appliance are dry when you insert the
batteries.
- Do not clean the Ladyshave with water above shower temperature
(max. 35°C).
- Be careful with hot water. Always check if the water is not too hot, to
prevent your hands from getting burnt.
- Use and store the appliance at a temperature between 15°C and
35°C.
- Do not use the appliance, the shaving unit, the efciency cap (HP6342
only) or the trimming comb (HP6342 only) if it is damaged or
broken, as this may cause injury.
- Never use any accessories or parts from other manufacturers or that
Philips does not specically recommend. If you use such accessories
or parts, your guarantee becomes invalid.
- Do not expose the Ladyshave to direct sunlight.
- This appliance is only intended to be used by women to shave and
trim their body hair. It is not intended for shaving or trimming scalp
hair or for any other purpose.
- Noiselevel: Lc= 65 dB(A)

- The appliance can be safely used in the bath or shower and cleaned
under the tap (Fig. 2).
- To keep the Ladyshave watertight:
1 Make sure that the rubber sealing ring of the battery holder stays
clean and undamaged.
2 Apply some vaseline to the rubber sealing ring from time to time.

- This Philips appliance complies with all standards regarding
electromagnetic elds (EMF). If handled properly and according to the
instructions in this user manual, the appliance is safe to use based on
scientic evidence available today.
 7


The Ladyshave runs on two AA 1.5 volt alkaline batteries. We advise you
to use Philips LR6 PowerLife batteries. They supply sufcient energy for
approx. 40 minutes of shaving.
Note: Make sure that your hands are dry when you insert the batteries.
To avoid damage due to battery leakage:
- Do not expose the appliance to direct sunlight.
- Do not expose the appliance to temperatures higher than 35°C.
- Remove the batteries if you are not going to use the appliance for a
month or more.
- Do not leave empty batteries in the appliance.

1 To remove the battery compartment cover, pull it off the
appliance (Fig. 3).
2 Put the batteries in the battery holder (Fig. 4).
Note: Make sure that the + and - poles of the batteries point in the right
direction.
3 Push the battery compartment cover back onto the appliance
(‘click’) (Fig. 5).

1 To detach the shaving head, press the release buttons on both sides
of the appliance (1) and pull the shaving head (2) (Fig. 6).
2 To attach the shaving head push it onto the appliance.
Note: Do not exert pressure on the shaving foil to avoid damage.

HP6342 comes with the protection cap, the efciency cap and the
trimming comb. HP6340 comes with the protection cap. All attachments
can be attached and detached in the same way.
8

1 To attach a cap or comb, carefully push it onto the appliance. Make
sure the recess of the comb is aligned with the front of the
appliance (Fig. 7).
2 To detach a cap or comb, carefully pull it off the appliance (Fig. 8).
Note: Do not hold the comb by its teeth when you pull it.

The Ladyshave is suitable for:
- Shaving the underarms
- Shaving the legs
- Shaving the bikini line
- Trimming the bikini line (HP6342 only)

You can use the Ladyshave on wet skin, while you have a bath or shower.
To achieve the best result, lather your skin with soap or shaving cream
beforehand.

If you prefer to use the Ladyshave dry, make sure that your skin is clean
and completely dry.
Note: in principle, there is no difference in using the appliance on wet skin
and using it on dry skin. You can simply choose which method you like best.
Note: Do not apply alcohol based-lotions to the skin directly before or after
shaving. If you want, you can apply some talcum powder.
Note: Do not press the shaving head too hard onto the skin, as this has
a negative effect on shaving performance and may cause some skin irritation.


1 Press the on/off slide upwards to switch on the appliance (Fig. 9).
 9

2 Hold the appliance at an angle of approximately 70°. Make sure that
the shaving foil and pre-trimmer are fully in contact with your
skin (Fig. 10).
3 Stretch the skin with your free hand to make the hairs stand
upright.
4 Move the appliance gently over the skin against the direction of hair
growth (Fig. 11).

1 When you shave the underarm area, place one arm behind your
head to stretch the skin (Fig. 12).
2 Move the Ladyshave gently over the skin. To achieve the best result,
move the Ladyshave up and down and from left to right (Fig. 13).

If you are new to shaving, you can use the efciency cap to help you place
the Ladyshave on the skin at the optimum angle. When the efciency cap
is placed at on the skin, the shaving foil and trimmer are fully in contact
with the skin. This helps to get perfect results.

If the hair you want to shave is longer than 10mm, pre-trim the hair with
the trimming comb to a length of 3mm for an optimal shaving
performance.
1 Attach the trimming comb onto the appliance.
2 Press the on/off slide upwards to switch on the appliance (Fig. 9).
3 Move the appliance against the direction of hair growth. Make sure
that the surface of the comb is in full contact with the skin at all
times (Fig. 14).
Note: You will achieve the best result if you trim under dry conditions.
10
