Philips SP9851 User manual

SP9851, SP9811
SP9851, SP9811
Premium Edition

22
21
23
25 26
24
6
3
1
2
4
5
7
8
9
10
19
20
27
11
12
14
13
15
16
17
18
28
29
30

empty page before TOC

English 6
简体中文 44

English
Introduction
Congratulations on your purchase and welcome to
Philips! To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome.
Please read this user manual, as it contains
information about the features of this shaver as
well as some tips to make shaving easier and more
enjoyable.
General description (Fig. 1)
1 Protection cap for cleansing brush attachment
2 Click-on cleansing brush attachment
3 Click-on massage attachment
4 Click-on fresh eyes attachment (SP9851 only)
5 Attachment base
6 Click-on precision trimmer attachment
7 Click-on shaving unit
8 On/off button
9 Socket for small plug
10 Product stand
11 Exclamation mark
12 Replacement reminder
13 Travel lock symbol
14 Cleaning reminder
15 Charge symbol
16 Battery charge percentage
17 Personal comfort settings bar
18 + and - buttons for personal comfort settings
19 SmartClean system (SP9851 only)
20 Cap of SmartClean system
21 On/off button
22 Replacement symbol
23 Rinsing symbol
24 Drying symbol
25 Ready symbol
26 Charge symbol
6English

27 Cleaning cartridge for SmartClean system
28 Supply unit
29 Small plug
30 Pouch
The accessories supplied may vary for different
products. The box shows the accessories that have
been supplied with your product.
Important safety information
Read this important information carefully before
you use the appliance and its accessories and save
it for future reference. The accessories supplied
may vary for different products.
Danger
- Keep the supply unit dry.
Warning
- To charge the battery, only use the detachable
supply unit (HQ8505) provided with the
appliance.
- The supply unit contains a transformer. Do not
cut off the supply unit to replace it with another
plug, as this causes a hazardous situation.
7
English

- This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
shall not play with the appliance. Cleaning and
user maintenance shall not be made by
children without supervision.
- Always unplug the shaver before you clean it
under the tap.
- Always check the appliance and its attachments
before you use it. Do not use the appliance or
its attachments if it is damaged, as this may
cause injury. Always replace a damaged part
with one of the original type.
- Do not use the click-on fresh eyes attachment if
you have glaucoma, an eye injury, or have had
eye surgery within the last 12 months.
- Do not use the click-on fresh eyes attachment if
you have an allergy to aluminum.
Caution
- Never immerse the cleaning system or the
charging stand in water and do not rinse it
under the tap.
- Never use water hotter than 60°C to rinse the
shaver.
- Only use this appliance for its intended purpose
as shown in the user manual.
- For hygienic reasons, the appliance should only
be used by one person.
- Never use compressed air, scouring pads,
abrasive cleaning agents or aggressive liquids
such as petrol or acetone to clean the
appliance.
8English

- Do not put the appliance or any part in the
dishwasher.
- If your shaver comes with a cleaning system,
always use the original Philips cleaning fluid
(cartridge or bottle, depending on the type of
cleaning system).
- Always place the cleaning system on a stable,
level and horizontal surface to prevent leakage.
- If your cleaning system uses a cleaning
cartridge, always make sure the cartridge
compartment is closed before you use the
cleaning system to clean or charge the shaver.
- When the cleaning system is ready for use, do
not move it to prevent leakage of cleaning fluid.
- Water may drip from the socket at the bottom
of the shaver when you rinse it. This is normal
and not dangerous because all electronics are
enclosed in a sealed power unit inside the
shaver.
- Do not use the supply unit in or near wall
sockets that contain an electric air freshener to
prevent irreparable damage to the supply unit.
- Do not open the appliance to replace the
rechargeable battery.
- Do not use the appliance on chapped skin,
open wounds, healing wounds, skin recovering
from surgery or if you suffer from a skin disease
or skin irritation, such as severe acne, sunburn,
skin infection, skin cancer, inflammation,
eczema, psoriasis, nylon allergy etc.
- Do not use the appliance if you are taking
steroid-based medication.
- If you wear piercings on your face, remove the
piercings before you use the click-on
attachments or make sure that you do not use
the appliance on or near the piercing.
9
English

- Do not use the click-on massage attachment
and click-on fresh eyes attachment with self-
made cleansers, creams, oils or cosmetic
products containing harsh chemicals or rough
particles.
- If you wear jewelry, contact lenses or glasses,
remove them before you use the click-on
attachments, or make sure that you do not use
the appliance on or near jewelry or glasses.
- Only use the click-on fresh eyes attachment at
the lowest personal comfort setting.
- Do not put the click-on fresh eyes attachment
in the freezer/fridge or sun, as this may cause a
hazardous situation for your skin.
- The click-on fresh eyes attachment is intended
for use on the bony area below the eye.
- Please make sure that no loose hair gets
trapped in the click-on massage attachment
during use by wearing a headband, tying your
hair or holding it back with your hands.
- The click-on massage attachment is intended
to massage the cheeks.
- Only use the click-on massage attachment at
the medium or lowest personal comfort setting.
- Do not use the click-on massage attachment
too close to the nostrils.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable
standards and regulations regarding exposure to
electromagnetic fields.
10 English

General
- This shaver is waterproof. It is suitable for use in
the bath or shower and for cleaning under the
tap. For safety reasons, the shaver can
therefore only be used without cord.
- The supply unit is suitable for mains voltages
ranging from 100 to 240 volts.
- The supply unit transforms 100-240 volts to a
safe low voltage of less than 24 volts.
The display
Note: Before you use the shaver for the first time,
remove the protective foil from the display.
Personal comfort settings
The appliance has a feature that allows you to
personalise your settings. You can choose
between three settings depending on your
personal shaving needs (from low to high):
comfort, dynamic or efficiency. When you press the
- or + button, the segment of the personal comfort
settings bar that lights up shows the currently
selected setting. You can press the + or - button to
select a different setting.
Charging
When the shaver is charging, the battery charge
percentage and the battery symbol flash white.
The battery charge is indicated by the battery
charge percentage shown on the display.
11
English

Quick charge: When the battery symbol starts to
flash quickly, the shaver contains enough charge
for one shave.
Battery fully charged
When the battery is fully charged, the battery
charge percentage lights up white continuously.
Note: This appliance can only be used without
cord. When you press the on/off button during or
after charging, you hear a sound to indicate that
the shaver is still connected to the wall socket.
Note: When the battery is full, the display switches
off automatically after 30 minutes.
Battery low
When the battery is almost empty, the battery
charge indicator flashes orange and the shaver
beeps.
Remaining battery charge
The remaining battery charge is indicated by the
battery charge percentage shown on the display.
Cleaning reminder
Clean the shaver after every shave for optimal
performance. When you switch off the appliance,
the cleaning reminder flashes to remind you to
clean the appliance.
Travel lock
You can lock the appliance when you are going to
travel. The travel lock prevents the appliance from
being switched on by accident.
12 English

Activating the travel lock
1Press the on/off button for 3 seconds to enter
the travel lock mode.
While you activate the travel lock, the travel lock
symbol lights up white continuously. When the
travel lock is activated, the appliance produces
a sound and the travel lock symbol flashes.
Deactivating the travel lock
1Press the on/off button for 3 seconds.
The travel lock symbol flashes and then lights
up continuously. The appliance is now ready for
use again.
Note: You can also deactivate the travel lock by
connecting the appliance to the wall socket.
Replacement reminder
For maximum shaving performance, we advise you
to replace the shaving heads every two years.
The appliance is equipped with a replacement
reminder which reminds you to replace the
shaving heads. The shaving unit symbol lights up
white continuously, the arrows flash white and the
appliance beeps to indicate that you have to
replace the shaving heads.
Note: After replacing the shaving heads, you can
reset the replacement reminder by pressing the
on/off button for 7 seconds. If you do not reset the
replacement reminder, the shaver resets
automatically after 9 shaves.
13
English

Exclamation mark
Overheating
If the appliance overheats during charging, the
exclamation mark flashes orange. When this
happens, the shaver switches off automatically.
Charging continues once the temperature of the
appliance has decreased to the normal level.
Blocked shaving heads
If the shaving heads are blocked, the exclamation
mark lights up orange continuously. The
replacement reminder and the cleaning reminder
flash white alternately and you hear a sound. In
this case, the motor cannot run because the
shaving heads are soiled or damaged.
If the shaving heads are soiled, you have to clean
them. If the shaving heads are damaged, you have
to replace them.
Charging
Charge the shaver before you use it for the first
time and when the display indicates that the
battery is almost empty. The battery charge is
indicated by the battery charge percentage shown
on the display.
When you connect the shaver to the wall socket,
you hear a sound.
Charging takes approx. 1 hour. A fully charged
shaver has a shaving time of up to 60 minutes.
Note: You cannot use the appliance while it is
charging.
Charging with the supply unit
1Make sure the appliance is switched off.
14 English

1
2
2Put the small plug in the appliance and put the
supply unit in the wall socket.
3After charging, remove the supply unit from the
wall socket and pull the small plug out of the
appliance.
Charging in the SmartClean system (SP9851 only)
1Put the small plug in the back of the
SmartClean system.
2Put the supply unit in the wall socket.
3Press the top cap to be able to place the shaver
in the holder ('click').
4Hold the shaver upside down above the holder.
Make sure the front of the shaver points
towards the SmartClean system holder.
1
2
3
5Place the shaver in the holder, tilt the shaver
backwards and press down the top cap to
connect the shaver (‘click’).
Note: The battery symbol starts to flash to indicate
that theappliance is charging. When the battery is
fully charged, the battery symbol lights up
continuously.
Using the appliance
Note: This appliance can only be used without
cord.
15
English

Switching the appliance on and off
- To switch on the appliance, press the on/off
button once.
The display lights up for a few seconds.
- To switch off the appliance, press the on/off
button once.
The display lights up for a few seconds and
shows the remaining battery charge.
Shaving
Skin adaptation period
Your first shaves may not bring you the result you
expect and your skin may even become slightly
irritated. This is normal. Your skin and beard need
time to adapt to any new shaving system. To allow
your skin to adapt to this new appliance, we advise
you to shave regularly (at least 3 times a week) and
exclusively with this appliance for a period of 3
weeks.
Shaving tips
- Selectyour personal comfort settings (see ‘The
display’).
- For the best results on skin comfort, pre-trim
your beard if you have not shaved for 3 days or
longer.
Dry shaving
1Switch on the appliance.
The display lights up for a few seconds.
2Move the shaving heads over your skin in
circular movements to catch all hairs growing in
different directions. Make sure each shaving
head is fully in contact with the skin. Exert
gentle pressure for a close, comfortable shave.
16 English

Note: Do not press too hard, this can cause skin
irritation.
3Clean the appliance after use.
Wet shaving
For a more comfortable shave, you can also use
this appliance on a wet face with shaving foam or
shaving gel.
To shave with shaving foam or shaving gel, follow
the steps below:
1Apply some water to your skin.
2Apply shaving foam or shaving gel to your skin.
3Rinse the shaving unit under the tap to ensure
that the shaving unit glides smoothly over your
skin.
4Switch on the appliance.
5Move the shaving heads over your skin in
circular movements to catch all hairs growing in
different directions. Make sure each shaving
head is fully in contact with the skin. Exert
gentle pressure for a close, comfortable shave.
Note: Rinse the shaving unit regularly to ensure
that it continues to glide smoothly over your
skin.
17
English

6Dry your face.
7Clean the appliance after use.
Note: Make sure you rinse all foam or shaving
gel off the appliance.
Using click-on attachments
Note: The accessories supplied may vary for
different products. The box shows the accessories
that have been supplied with your product.
It is recommended not to use the click-on
cleansing brush attachment, the massage
attachment or fresh eyes attachment directly after
shaving to prevent skin irritation.
Removing or attaching the click-on
attachments
Note: Attach the click-on massage attachment,
cleansing brush attachment and fresh eyes
attachment on the attachment base first, before
placing it on the appliance.
1Pull the click-on attachment straight off the
attachment base.
2Place the click-on attachment onto the
attachment base until it locks into position with
a click.
3Make sure the appliance is switched off.
18 English

4Pull the attachment straight off the appliance.
Note: Do not twist the attachment while you
pull it off the appliance.
5Insert the lug of the attachment into the slot in
the top of the appliance. Then press down the
attachment to attach it to the appliance (‘click’).
Using the trimmer attachment
You can use the precision trimmer attachment to
touch up your beard, sideburns and moustache.
1Attach the attachment to the appliance (‘click’).
2Switch on the appliance.
The display lights up for a few seconds.
3Hold the trimmer attachment perpendicular to
the skin and move the appliance downwards
while you exert gentle pressure.
4Clean the attachment after use (see 'Cleaning
and maintenance').
Using the cleansing brush attachment
After approx. 20 seconds, move the appliance to
your forehead and start cleansing this part of your
face. Gently move the brush head from left to
right.Note: For better shaving results, use the click-
on cleansing brush attachment before shaving.
Use the rotating cleansing brush with your daily
cleansing cream. The cleansing brush removes oil
and dirt, contributing to a healthy and oil-free skin.
We advise you to use it no more than twice a day.
Start with the lowest personal comfort setting to
familiarize yourself with the attachment.
19
English

Do not use the appliance on damaged or irritated
skin or on wounds.
1Place the attachment on the attachment holder
(see 'Removing or attaching the click-on
attachments').
2Attach the attachment to the appliance (‘click’).
3Moisten the attachment with water.
Note: Do not use the appliance with a dry
cleansing brush attachment, as this can irritate
the skin.
4Moisten your face with water and apply a
cleanser to your face.
5Place the attachment on your cheek.
6Switch on the appliance.
20 sec.
7Gently move the attachment across your skin
from the nose towards the ear. Do not push the
attachment too hard onto the skin to make sure
that the treatment remains comfortable.
Note: Do not cleanse the sensitive area around
your eyes.
20 sec.
8After approx. 20 seconds, move the appliance
to your other cheek and start cleansing this part
of your face.
20 English
