Philips XZ5800 User manual

Series S5000
XZ5800, S5230,
S5210, S5095,
S5091, S5090,
S5082, S5081,
S5080, S5079,
S5078, S5077

Series S5000
XZ5800, S5230,
S5210, S5095,
S5091, S5090,
S5082, S5081,
S5080, S5079,
S5078, S5077

5
1
14
13
2
3
4
6
7
8
9
10
12
11
15
16
17
18

English 6
简体中文 31

English
6
Introduction
Congratulations on your purchase and welcome
to Philips! To fully benet from the support that
Philips oers, register your product at
www.philips.com/welcome.
General description
1 Click-on trimmer attachment (S5230/04,
S5210/04, S5082/61, S5081/04, S5079/04,
S5078/04 only)
2 Protection cap for shaving unit
3 Click-on shaving unit
4 Shaving unit release button
5 On/o button
6 Handle
7 Socket for small plug
8 Battery charge indicator with 1 light
9 Unplug for use symbol
10 Travel lock symbol
11 Replacement reminder
(S5210/04, S5230/04 only)
12 Cleaning reminder (S5210/04, S5230/04 only)
13 Click-on cleansing brush attachment
(XZ5800/69, S5095/58, S5091/50,
S5090/58 only)
14 Protection cap for cleansing brush attachment
(XZ5800/69, S5095/58, S5091/50,
S5090/58 only)
15 Protection cap for nose trimmer attachment
(S5091/50, S5082/61 only)
16 Click-on nose trimmer attachment
(S5091/50, S5082/61 only)
17 Supply unit (adapter)
18 Small plug
The accessories supplied may vary for dierent
products. The box shows the accessories that have
been supplied with your appliance.

English 7
Important safety information
Read this important information carefully before
you use the appliance and its accessories and save
it for future reference. The accessories supplied
may vary for dierent products.
Danger
-Keep the supply unit dry.
Warning
-To charge the battery, only use the detachable
supply unit (HQ8505) provided with the
appliance.
-The supply unit contains a transformer. Do not
cut o the supply unit to replace it with another
plug, as this causes a hazardous situation.
-This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
shall not play with the appliance. Cleaning
and user maintenance shall not be made by
children without supervision.
-Always unplug the shaver before you clean it
under the tap.
-Always check the appliance before you use
it. Do not use the appliance if it is damaged,
as this may cause injury. Always replace a
damaged part with one of the original type.

English
8
-Do not open the appliance to replace the
rechargeable battery.
Caution
-Never immerse the cleaning system or the
charging stand in water and do not rinse it
under the tap.
-Never use water hotter than 80°C to rinse the
shaver.
-Only use this appliance for its intended purpose
as shown in the user manual.
-For hygienic reasons, the appliance should only
be used by one person.
-Never use compressed air, scouring pads,
abrasive cleaning agents or aggressive
liquids such as petrol or acetone to clean the
appliance.
-If your shaver comes with a cleaning system,
always use the original Philips cleaning uid
(cartridge or bottle, depending on the type of
cleaning system).
-Always place the cleaning system on a stable,
level and horizontal surface to prevent leakage.
-If your cleaning system uses a cleaning
cartridge, always make sure the cartridge
compartment is closed before you use the
cleaning system to clean or charge the shaver.
-When the cleaning system is ready for use, do
not move it to prevent leakage of cleaning uid.
-Water may drip from the socket at the bottom
of the shaver when you rinse it. This is normal
and not dangerous because all electronics
are enclosed in a sealed power unit inside the
shaver.
-Do not use the supply unit in or near wall
sockets that contain an electric air freshener to
prevent irreparable damage to the supply unit.

English 9
Electromagnetic elds (EMF)
-This Philips appliance complies with all
applicable standards and regulations regarding
exposure to electromagnetic elds.
General
-This shaver is waterproof. It is suitable for use
in the bath or shower and for cleaning under
the tap. For safety reasons, the shaver can
therefore only be used without cord.
-The appliance is suitable for mains voltages
ranging from 100 to 240 volts.
-The supply unit transforms 100-240 volts to a
safe low voltage of less than 24 volts.
The display
Charging
Note: If you press the on/o button during
charging, the 'unplug for use' symbol ashes white
to remind you that you have to disconnect the
appliance from the wall socket.
Battery charge indicator with 1 light
Quick charge (XZ5800, S5230/04, S5210/04,
S5095/58, S5090/58, S5081/04 only): When the
battery is empty and you connect the appliance
to the wall socket, the battery charge indicator
ashes quickly. When the appliance contains
enough energy for one shave, the battery charge
indicator starts ashing slowly.
While the appliance continues to charge, the
battery charge indicator ashes slowly until the
appliance is fully charged.

English
10
Battery fully charged
Note: When the battery is full, the display switches
o automatically after 30 minutes.
Note: This appliance can only be used without cord.
Battery charge indicator with 1 light
When the battery is fully charged, the battery
charge indicator lights up white continuously.
Battery low
Battery charge indicator with 1 light
When the battery is almost empty, the battery
charge indicator ashes orange.
’Unplug for use’ reminder
The appliance is equipped with an ‘unplug for
use’ reminder. The ‘unplug for use’ symbol ashes
to remind you that you have to disconnect the
appliance from the supply unit before you can
switch it on.

English 11
Cleaning reminder
Clean the shaver after every shave for optimal
performance. When you switch o the appliance,
the cleaning reminder ashes to remind you to
clean the appliance.
Travel lock
You can lock the appliance when you are going to
travel. The travel lock prevents the appliance from
being switched on by accident.
Activating the travel lock
1 Press the on/o button for 3 seconds to enter
the travel lock mode.
While you activate the travel lock, the travel
lock symbol lights up continuously. When the
travel lock is activated, the travel lock symbol
ashes.
Deactivating the travel lock
1 Press the on/o button for 3 seconds.
The travel lock symbol ashes and then lights
up continuously. The appliance is now ready for
use again.
3 sec.

English
12
Replacement reminder
For maximum shaving performance, we advise
you to replace the shaving heads every two years.
The appliance is equipped with a replacement
reminder which reminds you to replace the shaving
heads. The shaving unit symbol and arrows light
up to indicate that you have to replace the shaving
heads.
Note: After replacing the shaving heads, you need
to reset the replacement reminder by pressing the
on/o button for 7 seconds.
(S5210/04, S5230/04 only)
Charging
Charge the shaver before you use it for the rst
time and when the display indicates that the
battery is almost empty.
Charging takes approx. 1 hour (XZ5800, S5230/04,
S5210/04, S5095/58, S5090/58, S5081/04) or
8 hours (S5091/50, S5082/61, S5080/03,
S5079/04, S5078/04, S5077/04).
Note:You cannot use the appliance while it is
charging.
Charging with the supply unit
1 Make sure the appliance is switched o.
2 Put the supply unit in the wall socket and put
the small plug in the appliance.
3 After charging, remove the supply unit from the
wall socket and pull the small plug out of the
appliance.

English 13
Using the appliance
Note: This appliance can only be used without
cord.
Switching the appliance on and o
1 To switch on the appliance, press the on/o
button once.
2 To switch o the appliance, press the on/o
button once.
Shaving
Skin adaptation period
Your rst shaves may not bring you the result you
expect and your skin may even become slightly
irritated. This is normal. Your skin and beard need
time to adapt to any new shaving system. To allow
your skin to adapt to this new appliance, we advise
you to shave regularly (at least 3 times a week)
and exclusively with this appliance for a period of
3 weeks.
Dry shaving
1 Switch on the appliance.
2 Move the shaving heads over your skin in
circular movements to catch all hairs growing in
dierent directions. Exert gentle pressure for a
close comfortable shave.
Note: Do not press too hard, this can cause skin
irritation.
3 Clean the appliance after use (see 'Cleaning
and maintenance').
Wet shaving
You can also use this appliance on a wet face with
shaving foam or shaving gel.

English
14
To shave with shaving foam or shaving gel,
follow the steps below:
1 Apply some water to your skin.
2 Apply shaving foam or shaving gel to your skin.
3 Rinse the shaving unit under the tap to ensure
that the shaving unit glides smoothly over your
skin.
4 Switch on the appliance.
5 Move the shaving heads over your skin in
circular movements to catch all hairs growing in
dierent directions. Exert gentle pressure for a
close comfortable shave.
Note: Do not press too hard, this can cause skin
irritation.
Note: Rinse the shaving unit regularly to ensure
that it continues to glide smoothly over your
skin.
6 Dry your face.
7 Clean the appliance after use
(see 'Cleaning and maintenance').
Note: Make sure you rinse all foam or shaving
gel o the appliance.

English 15
Using the click-on attachments
Note: The accessories supplied may vary for
dierent products. The box shows the accessories
that have been supplied with your appliance.
Removing or attaching the click-on
attachments
1 Make sure the appliance is switched o.
2 Pull the attachment straight o the appliance.
Note: Do not twist the attachment while you
pull it o the appliance.
3 Insert the lug of the attachment into the slot in
the top of the appliance. Then press down the
attachment to attach it to the appliance (‘click’).
Using the trimmer attachment
You can use the trimmer attachment to groom
your sideburns and moustache.
(S5230/04, S5210/04, S5082/61, S5081/04,
S5079/04, S5078/04 only)
1 Attach the attachment to the appliance ('click').
2 Switch on the appliance.
3 Hold the trimmer attachment perpendicular to
the skin and move the appliance downwards
while you exert gentle pressure.
4 Clean the attachment after use
(see ‚Cleaning and maintenance‘).

English
16
Using the cleansing brush attachment
Use the rotating cleansing brush attachment with
your daily cleansing cream. The cleansing brush
attachment removes oil and dirt, contributing to a
healthy and oil-free skin.
(XZ5800/69, S5095/58, S5091/50,
S5090/58 only)
1 Attach the attachment to the appliance ('click').
2 Moisten the attachment with water.
Note: Do not use the appliance with a dry brush
attachment, as this can irritate the skin.
3 Moisten your face with water and apply a
cleanser to your face.
4 Place the attachment on your cheek.
5 Switch on the appliance.
6 Gently move the attachment across your skin
from the nose towards the ear. Do not push the
attachment too hard onto the skin to make sure
the treatment remains comfortable.
Note: Do not cleanse the sensitive area around
your eyes.
20 sec.

English 17
7 After approx. 20 seconds move the appliance
to your other cheek and start cleansing this part
of your face.
8 After approx. 20 seconds move the appliance
to your forehead and start cleansing this part of
your face. Gently move the brush head from left
to right.
Note: We advise you to not overdo the
cleansing and to not cleanse any zone longer
than 20 seconds.
9 After the treatment, rinse and dry your face.
Your face is now ready for the next step of your
daily skincare routine.
10 Clean the attachment after use
(see 'Cleaning and maintenance').
Using the nose trimmer attachment
You can use the nose trimmer attachment to trim
your nose and/or ear hair.
(S5091/50, S5082/61 only)
Trimming nose hair
When trimming nose hair, make sure your nostrils
are clean.
1 Attach the attachment to the appliance ('click').
2 Switch on the appliance.
3 Carefully insert the attachment into one of your
nostrils.
Do not insert the attachment more than 0.5cm
into your nostrils.
20 sec.
20 sec.

English
18
4 Slowly move the attachment around to remove
all unwanted hairs in your nostrils.
5 Clean the attachment after use
(see 'Cleaning and maintenance').
Trimming ear hair
When trimming ear hair, make sure your outer ear
channels are clean and free from wax.
1 Attach the attachment to the appliance ('click').
2 Switch on the appliance.
3 Slowly move the attachment along the rim of
the ear to remove hairs that stick out beyond
the rim.
4 Insert the attachment into the outer ear
channel.
Do not insert the attachment more than 0.5cm
into your ear channel, as this could damage the
eardrum.
5 Slowly turn the attachment around to remove
all unwanted hairs from your outer ear channel.
6 Clean the attachment after use
(see 'Cleaning and maintenance').
Cleaning and maintenance
Note: The accessories supplied may vary for
dierent products. The box shows the accessories
that have been supplied with your appliance.
Cleaning the shaver under the tap
Clean the shaver after every shave for optimal
performance.
Caution: Be careful with hot water. Always check
if the water is not too hot, to prevent burning
your hands.

English 19
Never dry the shaving unit with a towel or tissue,
as this may damage the shaving heads.
1 Switch on the appliance.
2 Rinse the shaving unit under a warm tap.
3 Switch o the appliance. Press the release
button to open the shaving unit.
4 Rinse the hair chamber under the tap.
5 Rinse the shaving head holder under a warm
tap.
6 Carefully shake o excess water and let the
shaving head holder dry.
7 Close the shaving head holder ('click').

English
20
Cleaning the click-on attachments
Never dry trimmer or beard styler attachments with
a towel or tissue, as this may damage the trimming
teeth.
The accessories supplied may vary for dierent
products. The box shows the accessories that have
been supplied with your appliance.
Cleaning the trimmer attachment
Clean the trimmer attachment every time you have
used it.
(S5230/04, S5210/04, S5082/61, S5081/04,
S5079/04, S5078/04 only)
1 Switch on the appliance with the trimmer
attachment attached.
2 Rinse the attachment under a warm tap.
3 After cleaning, switch o the appliance.
4 Carefully shake o excess water and let the
attachment dry.
Tip: For optimal performance, lubricate the teeth of
the attachment with a drop of sewing machine oil
every six months.
Cleaning the cleansing brush attachment
Clean the cleansing brush attachment every time
you have used it.
(XZ5800/69, S5095/58, S5091/50, S5090/58 only)
1 Switch o the appliance.
2 Detach the brush head from the brush base.
3 Clean the parts thoroughly with warm water
and soap.
4 Dry the cleansing brush attachment with a
towel.
