Philips ReCare 7.0 R User manual

Please read this entire manual carefully
before operating your new recumbent
bike and save it for future use.
User manual
Register your product and get support at
www.philips.com/welcome
PTE7000MR
ReCare
Recumbent bike
7.0 R

Thank you for your recent purchase of the Philips physical
rehabilitation recumbent bike, 7.0 R Philips physical therapy and exer-
cise solutions provide simple, reliable products that oer the most
relevant feedback to caregivers and users to achieve best-in-class
outcomes and empower individuals to build condence in rebuilding
and maintaining healthy lifestyles and keep in touch with their
communities.
Your new product has been manufactured by one of the world’s
leading medical product manufactures. It is backed by one of the
most comprehensive warranties in the industry. Through our dealers,
distributors and manufacturer’s representatives, we will do all we can
to provide many years of successful and prosperous ownership.
Your warranty and service needs will be addressed either through
your regional sales representative or our highly trained service
technicians.
It is their responsibility to provide you with both the technical
knowledge and access to service personnel to make your ownership
experience more informed, and resolve any issues quickly.
Product registration
Register your product and get support at :
www.philips.com/welcome .
This will ensure we have all your details quickly at hand in dealing with
any after sales support. For fastest support visit us online for chat and
self service solution at :
www.philips.com/support .
Philips therapy solutions
Delivering better outcomes

Contents
Important safety instructions 5
Important electrical information
Important operation instructions 10
Application specication 11
Operating principle 13
Signicant physical characteristics 13
8
Signicant performance characteristic
14
Intended user prole 15

42
46
64
69
72
Operating the 7.0 R 17
Features 19
Data transfer software instructions 38
Operation of your new bike 22
Using a heart rate transmitter
Assembly instructions for 7.0 R
Maintenance
Specications
Description of packaging symbols

5
Attention
Read all instructions in this manual before using this device.
Danger
To reduce the risk of electric shock disconnect your from the
electrical outlet prior to cleaning and/or service work.
Warning
• Do not modify this equipment without authorization of the
manufacturer.
• To reduce the risk of burns, re, electric shock, or injury to persons,
install the bike on a at level surface with access to a 90 to
240-volt AC, 50/60 Hz, 15-amp grounded outlet. Do not use an
extension cord unless it is 16awg or larger, with only one outlet on
the end. The bike should be the only appliance in the electrical circuit.
Do not attempt to disable the grounded plug by using improper
adapters, or in any way modify the cord set; a serious shock or re
hazard may result along with computer malfunctions.
• Use this device only for it’s intended use as described in this
manual.
• Keep children away from the bike. There are moving parts, obvious
pinch points and other caution areas that can cause harm.
• Except as instructed for use of the device, keep hands away from all
moving parts.
Important
safety
instructions

6
• Keep the electrical cord away from heated surfaces and out of all
travel lanes and do not operate the bike if the cord or plug is
damaged.
• The pulse sensors are not medical devices. Various factors, including
the user’s movement, may aect the accuracy of heart rate readings.
The pulse sensors are intended only as exercise aids in determining
heart rate trends in general.
• Heart rate monitoring system may be inaccurate. Over exercise may
result in injury or death. If you feel faint stop exercising immediately.
• Ensure there is a minimum space on the sides of the bike of two feet
for proper operation, easy access and to prevent possible injuries to
others standing or walking nearby. There should be a minimum of at
least one foot of free space at the front and rear of the unit.
• Do not use any after market parts on this device, other than those
recommended by Philips.
• Do not attempt any servicing or adjustments other than those
described in this manual. All else must be left to trained service
personnel familiar with electro-mechanical equipment and autho-
rized under the laws of the country in question to carry out mainte-
nance and repair work.
• Installation and assembly of this product should be performed by
trained personnel only.

7
• Hold the handlebar for support when getting on or o the bike.
• To avoid injury please observe all minimum and maximum seat
adjustment settings.
• Never drop or insert any object into any openings.
• Do not use outdoors.
• To disconnect, turn all controls to the o position then remove the
plug from the outlet.
• This device is designed for commercial use and will meet the
demands of orthopedic, sports wellness and general conditioning
programs.
• Do not attempt to use your bike for any purpose other than for the
purpose it is intended.
• Warning: The adjustable crank arms may become entangled in pant
legs if the pant legs are loose tting. To avoid injury roll up the pant
legs or secure the pant legs in some other fashion.
• The ywheel in the bike does not have a freewheel, but is directly
connected to the pedals. The bike is equipped with auto-braking
software that will stop the ywheel when it detects the user is trying
to stop pedaling. In the unlikely event that the electronics fails, or
the Auto-brake function is disabled in the software, a spinning
ywheel can make the bike dicult to stop when pedaling at higher
RPM(Revolutions per minute). There is an emergency brake lever
provided that will stop the ywheel when pressed.

8
Warning
• Never remove any cover without rst disconnecting AC power. If
voltage varies by 10% or more outside of specied range (90 to 240
V), the performance of your bike may be aected. Such conditions
are not covered under your warranty. If you suspect the voltage is
low, contact your local power company or a licensed electrician for
proper testing.
• Never expose this bike to rain or moisture. This product is not
designed for use outdoors, near a pool or spa, or in any other high
humidity environment.
• The recumbent bike is not protected against the ingress of water or
particulate matter.
• The recumbent bike is not suitable for use in an oxygen rich envi-
ronment.
• If not stated otherwise Philips devices are designed for operation in
normal climatic surroundings (IEC 60601-1):
- Temperature: + 10° ... + 36° C
- Relative humidity: 30 ... 90 % (non condensing)
- Air pressure: 700 ... 1060 mbar
- Maximum operating altitude: approx. 10,000 feet (3000m), with
out pressurization
- Transport and store the devices at a temperature of – 20° ...
+ 50° C.
Important
electrical
information

9
Grounding instructions
• This product must be grounded. In the unlikely event that the
bike’s electrical system should malfunction or breakdown
grounding provides a path of least resistance for electric current,
reducing the risk of electric shock. This product is equipped with
a cord having an equipment-grounding plug. The plug must be
plugged into an appropriate outlet that is properly installed and
grounded in accordance with all local codes and ordinances.
Danger
• Improper connection of the equipment-grounding conductor can
result in a risk of electric shock. Check with a qualied electrician
or serviceman if you are in doubt as to whether the product is
properly grounded. Do not modify the plug provided with the
product if it will not t the outlet; have a proper outlet installed
by a qualied electrician.

10
• Never use your bike during an electrical storm. Surges may occur in
your facility power supply that could damage the bike’s compnents.
• All users should have medical clearance before starting any rigorous
exercise program. This is especially important for persons with a
history of heart disease or other high risk factors.
• The user should adjust the seat to a position that is comfortable
during exercise. The console has a program in the setup menu that
can aid in setting the correct seat position.
• Start at a safe exercise level. Do not allow the user to be over
exerted. Symptoms to watch for, but not limited to, are: shortness of
breath or diculty in breathing, pain or discomfort, feeling faint.
• Make sure the user warms up and cools down properly to avoid over
taxing the cardio vascular system. Allow three to ve minutes of
warm up and cool down during each exercise session.
Important
operation
instructions

11
Medical purpose
• Patient warm up before physical therapy session.
• Have the patient pedal to improve range of motion after
knee/hip/ankle surgery.
• Allow patients to perform cardiovascular exercise.
Intended patient population
• There is no particular restriction on age, gender, height and nationality.
• Maximal patient’s weight is 200kg.
• Patient must be ambulatory.
• Patient should have medical clearance before starting any rigorous
exercise program. This is especially important for person with a history
of heart disease or other high risk factors.
Intended part of the body or type of tissue applied to or
interacted with:
• Contact site: hands, feet, and trunk
• Condition: should not have any trauma
Application
specication

12
Intended conditions of use
• Environment including hygienic requirements
- General: intended for indoors use. This product is not designed
for use outdoors, near a pool or spa, or in any other high humidity
environment.
- Conditions of visibility:
Ambient luminance: standard ambient room lighting is sucient.
Viewing distance: 1 m
Viewing angle: 120°
- Physical
Temperature range: 10°C ~ 36°C
Relative humidity range: 30% R.H. ~ 90% R.H., non condensing
- Hygienic requirements: there is no particular restriction on
hygienic requirements.
• Frequency of use
- Dependent on therapist’s plan.
• Location
- Intended for hospital use, clinic use, home use and research in
academic institutions.
• Mobility
- The product is intended to be xed.
2
3
1
2
1

13
The patient pushes the pedals with their feet. The operator can
increase the workload using the Up and Down Key on the console.
When the workload change is requested an electromagnet is
energized at eld strengths relative to the workload requested. The
magnetic eld generated by the coil is induced into a ywheel
creating eddy currents to ow in the ywheel. The eddy currents then
create an opposing magnetic eld to the electromagnetic eld
creating more or less resistance at the pedal, determined by
workload setting by the operator.
Operating
principle
Please refer to Features of 7.0 R manual.
Signicant
physical
characteristics

14
Please refer to “Unique uses for the 7.0 R” in Operating
the 7.0 R.
Signicant
performance
characteristic

15
Intended
user
prole
Intended operator
• There is no particular restriction on age, gender, height, weight,
ability and culture.
• Education: University or above
• Knowledge: The operator should read the User’s Manual before use.
• Discipline: The operator should receive training from the manufac-
turer before use.
• Experience: The operator must have experience in physical therapy.
• Background: The operator must be a major in physical therapy.
• Professional competence: The operator should have the physical
therapist license.
Intended installer
• There is no particular restriction on age, gender, height, weight,
ability and culture.
• Education: High School or above
• Knowledge: The installer shall be able to manipulate this product
properly.
• Discipline: The installer shall be given a specic training by manu-
facturer.
• Experience: The installer must have experience in product assembly
and disassembly.
• Background: The installer must be electro-mechanically trained.
• Professional competence: Normal vision ability required.

16

17
The recumbent bike is intended to be used in aiding in the physical
rehabilitation process for patients with orthopedic and neurological
problems. Also used in sports medicine, wellness and general
conditioning programs.
Typical applications for this type of product are:
• Patient warm up before physical therapy session.
• Have the patient pedal to improve range of motion after knee/hip/
ankle surgery.
• Allow patients to perform cardiovascular exercise
Unique uses for the 7.0 R
• Adjustable crank allows patients to pedal in smaller range of knee
motion, from 15 degrees to full range.
• Symmetry program measures distance between left and right step
lengths. Graphical Bio-feedback display motivates patients to main-
tain even step symmetry between left and right legs.
Operating
the 7.0 R

18
Other features of the 7.0 R
• Work range up to 750 watts (60 RPM) when level settings are at 15
watts per level
(see Setup under Console section for Level settings).
• Indexed seat positioning accommodates users from 147 cm to 200 cm
(4’ 10” to 6’ 7”).
• Heart Rate monitoring using the optional heart rate chest-strap.
Heart rate measurements are not for medical use
The heart rate function on this product is not a medical device and
should not be relied on when accurate readings are necessary. Some
people, including those in a cardiac rehab program, may benet from
using an alternate heart rate monitoring system like a chest or wrist
strap. Various factors, including movement of the user, may aect the
accuracy of your heart rate reading. The heart rate reading is intended
only as an exercise aid for measuring heart rate trends in general.

19
7.0 U – Upright bike
Parts and adjustments
1. Electronic console
2. Mechanical brake
3. Pedal adjustment
4. A.C. Power input
5. Seat swivel adjustment
6. Hand pulse sensors
7. Seat back angle adjustment
8. Leveling glide
9. Seat angle adjustment
Optional parts (not shown)
2.1 Neurological pedal set
Features
1
2
3
4
5
9
6
8
7

20
The 7.0 R is an easy product to set up and use, from the adjustments to
the intuitive interface. This section explains how to set up, adjust and
operate your 7.0 R.
Leveling the 7.0 R
Once the 7.0 R is assembled, and placed on a at level oor, it may
be necessary to adjust the leveling glides on the bottom of the unit
to ensure proper stability of the 7.0 R. Use a 1/2” wrench to loosen
the top nut of the leveler. Adjust the levelers by hand as necessary to
remove any wobble in the unit. Then tighten the top nut against the
bottom of the stabilizer tube. Make sure the bottom nut remains
cinched against the leveling foot.
Connecting to A.C. power
The 7.0 R has a built-in universal power supply. You can plug the 7.0
R into any A.C. power source from 90 to 240 volts, 50 to 60 Hz. The
A.C. input is located in the front of the unit. The input module has an
input connector for the line cord, a power switch and a 5 amp fuse.
Turn the power switch to o when the 7.0 R is not in use.
Adjusting the seat fore/aft position
Squeeze the brake handle located on the left side handle bar. Move
the seat slightly until the seat lock clicks in place. There is anumbered
scale located on the aluminum seat slide tube for repeatable set-
tings. Seatposition is indicated by the front of the seat carriage lining
up with the number on the scale.
Adjusting the seat back angle
The seat back angle can be adjusted for comfort, but also may be
adjusted to change the hip angle for patients. To adjust the seat back
angle, squeeze the brake handle located on the left side handle bar
and move the seat back to the desired position. There is a numbered
scale located just below the seat back cushion for repeatable set-
tings.
Rotating the swivel seat
Lift the handle behind the seat to disengage the latch. Rotate the
seat to the desired position; lower the handle when approaching
position to activate latch. The seat will latch into place every 45
degrees
