Philips 40PUG6700 User manual

Register your product and get support at 6700 series
www.philips.com/welcome
User Manual
40PUG6700
50PUG6700
55PUG6700

Contents
1 TV Tour 4
1.1 Ultra HD TV 4
1.2 Philips Android TV 4
1.3 Using Apps 4
1.4 Playing Games 4
1.5 Pause TV and Recordings 4
1.6 Smartphones and Tablets 5
1.7 Social Networks 5
1.8 Bluetooth Connection 5
2 Setting Up 6
2.1 Read Safety 6
2.2 TV Stand and Wall Mounting 6
2.3 Tips on Placement 6
2.4 Power Cable 6
2.5 Antenna Cable 6
3 Connect your Android TV 8
3.1 Network and Internet 8
3.2 Google Account 11
3.3 Philips App Gallery 11
4 Connect Devices 13
4.1 About Connections 13
4.2 Receiver - Set-Top Box 15
4.3 Home Theater System - HTS 15
4.4 Smartphones and Tablets 17
4.5 Blu-ray Disc Player 17
4.6 DVD Player 18
4.7 Bluetooth - Speakers and Gamepads 18
4.8 Headphones 19
4.9 Game Consoles 19
4.10 Gamepad 19
4.11 USB Hard Drive 20
4.12 USB Keyboard 21
4.13 USB Flash Drive 21
4.14 Photo Camera 22
4.15 Camcorder 22
4.16 Computer 22
5 Switching On and Off 24
5.1 On or Standby 24
5.2 Philips Logo Brightness 24
5.3 Keys on TV 24
5.4 Sleep Timer 24
5.5 Switch Off Timer 24
6 Remote Control 26
6.1 Key overview 26
6.2 Voice 27
6.3 Keyboard 27
6.4 Pairing the Remote Control 28
6.5 IR Sensor 28
6.6 Batteries 28
6.7 Cleaning 29
7 Channels 30
7.1 Channel Lists 30
7.2 Watching TV Channels 30
7.3 Favorite Channels 32
7.4 Closed captioning (CC) and language 33
7.5 Interactive TV 33
8 TV guide 35
8.1 What You Need 35
8.2 TV Guide Data 35
8.3 Using the TV Guide 35
9 Recording and Pause TV 37
9.1 Recording 37
9.2 Pause TV 38
10 Top Picks 40
10.1 About Top Picks 40
10.2 TV on Demand 40
11 Home Menu 41
11.1 About the Home Menu 41
11.2 Open the Home Menu 41
11.3 Search and Voice Search 41
11.4 Restricted Profile 41
12 TV Menu 42
12.1 About TV Menu 42
12.2 Open TV Menu 42
13 Netflix 43
14 Sources 44
14.1 Switch to a device 44
14.2 Options for TV Input 44
14.3 Device Name and Type 44
14.4 Game or Computer 44
14.5 Rescan Connections 45
15 Apps 46
15.1 About Apps 46
15.2 Google Play 46
15.3 App Gallery 47
15.4 Start or Stop an App 47
15.5 Lock Apps 47
15.6 Manage Apps 48
15.7 Storage 49
16 Games 50
16.1 What You Need 50
16.2 Gamepads 50
16.3 Play a Game 50
17 Internet 51
17.1 Start Internet 51
17.2 Internet Options 51
18 Videos, Photos and Music 52
18.1 From a USB Connection 52
18.2 From a Computer or NAS 52
18.3 From a Cloud Storage Service 52
18.4 Play your Videos 52
18.5 View your Photos 53
18.6 Play your Music 53
19 Smartphones and Tablets 55
19.1 Philips TV Remote App 55
19.2 Google Cast 55
19.3 Miracast 55
19.4 AirPlay 56
19.5 MHL 56
20 Multi View 58
20.1 Text and TV 58
20.2 App Gallery and TV 58
20.3 HDMI and TV 58
21 Settings 59
2

21.1 Picture 59
21.2 Sound 63
21.3 Eco Settings 65
21.4 General Settings 66
21.5 Clock, Region and Language 68
21.6 Universal Access 69
22 Wireless and Networks 71
22.1 Network 71
22.2 Bluetooth 71
23 Android Settings 72
24 Channel Installation 73
24.1 Antenna/Cable Installation 73
24.2 Channel List Copy 73
24.3 Digital Channel Installation 74
25 Software 75
25.1 Update Software 75
25.2 Software Version 75
25.3 Open Source Software 75
25.4 Open Source License 75
25.5 Open Source 76
26 Specifications 109
26.1 Environmental 109
26.2 Power 109
26.3 Operating System 109
26.4 Reception 109
26.5 Display Type 109
26.6 Display Input Resolution 109
26.7 Dimensions and Weights 110
26.8 Connectivity 110
26.9 Sound 110
26.10 Multimedia 110
27 Help and Support 112
27.1 Register your TV 112
27.2 Using Help 112
27.3 Troubleshooting 112
27.4 Online Help 114
27.5 Support and Repair 114
28 Safety and Care 116
28.1 Safety 116
28.2 Screen Care 117
29 Terms of Use 118
29.1 Terms of Use - TV 118
29.2 Terms of Use - Smart TV 118
29.3 Terms of Use - Philips App Gallery 118
30 Copyrights 119
30.1 MHL 119
30.2 Ultra HD 119
30.3 HDMI 119
30.4 Dolby Digital Plus 119
30.5 DTS 2.0+Digital Out ™ 119
30.6 Microsoft 119
30.7 Wi-Fi Alliance 119
30.8 Kensington 120
30.9 Other Trademarks 120
Index 121
3

1
TV Tour
1.1
Ultra HD TV
This TV has an Ultra HD display. Its resolution is
four times higher than normal HD displays. Ultra HD
means 8 million pixels for the most refined and
lifelike picture on a TV.
On top of this, the new Ultra Pixel HD
Engine continuously converts any incoming TV signal
into Ultra HD resolution. So you can enjoy this
stunning picture quality the moment you switch on
the TV. Or you can watch native Ultra HD videos
through an HDMI connection. Ultra HD offers TV
viewing that is crisp and sharp even on a big screen.
1.2
Philips Android TV
This a Philips Android TV™ with UHD.
Android TV offers thousands of movies, shows and
games from Google Play, YouTube and your favorite
apps.*
Voice search and personalized recommendations
mean more time being entertained and less time
hunting for something good. With Google Cast built in,
you can easily cast movies, shows and photos from
your Chromebook or Android device to your TV.**
With the Philips TV Remote App on your
smartphone or tablet, you have your TV channels at
your fingertips. Send a photo to the large TV screen or
follow your favorite cooking show on your tablet in
the kitchen. From now on, your TV is part of your
mobile household.
Connect the TV to your home network and the
Internet.
* The TV must be connected to the
Internet. Subscriptions might be required for certain
content providers.
** Casting optimized for selected services only.
Streaming quality for other content might vary.
Supported operating systems and devices: Android
2.3 and higher, iOS® 7 and higher, Windows® 7 and
higher, Mac OS® 10.7 and higher and Chrome OS
(version 38 or higher).
Android, Google Play and other brands are
trademarks of Google Inc. The Android robot is
reproduced or modified from work created and
shared by Google and used according to terms
described in the Creative Commons 3.0 Attribution
License.
http://creativecommons.org/licenses/by/3.0/legalco
de
1.3
Using Apps
To get you started, some practical Apps are pre-
installed on your TV.
The Apps pages show the collection of Apps
(Applications) on your TV. Like Apps on your
smartphone or tablet, the Apps on your TV offer
specific functions for an enriched TV experience.
Apps like YouTube, Twitter, TV games or weather
forecasts. Or start an Internet Browser App, like
Google Chrome, to surf the Internet.
For more information, in Help, press the color
key  Keywords and look up Apps.
1.4
Playing Games
This TV is your big screen for gaming. Big enough for
two.
You can play a game from a connected Game
Console, a game from an installed App or simply an
online game on a website. You can set the TV to the
ideal settings for gaming, to allow quick and
responsive action. If you play a multi-player game
with split screens, you can set the TV to show each
screen as a full screen simultaneously. Each player
can focus on playing their own game.
1.5
Pause TV and Recordings
If you connect a USB Hard Drive, you can pause and
record a broadcast from a digital TV channel.
Pause your TV and answer that urgent phone call or
simply take a break during a sports match, while the
TV stores the broadcast on the USB Hard Drive. You
can watch it again later.
With a USB Hard Drive connected, you can also
4

record digital broadcasts. You can record while you
are watching a program or schedule a recording of an
upcoming program.
For more information, in Help, press the color
key  Keywords and look up Pause
TV or Recording.
1.6
Smartphones and Tablets
The new Philips TV Remote App is your new TV
buddy.
With the TV Remote App on your smartphone or
tablet, you are the master of the media around you.
Send photos, music or videos to your big TV screen or
watch any of your TV channels live on your tablet or
phone. Open the TV Guide and schedule a recording
for tomorrow. Your TV at home will do the job. With
the TV Remote App you are in control. You can even
lower the TV volume.
Download the Philips TV Remote App from your
favorite app store today.
It's free.
The Philips TV Remote App is available for iOS and
Android.
1.7
Social Networks
No need to get up to check your friend's messages on
your computer.
On this TV, you get the messages from your social
networks on your TV screen. You can send a return
message from your couch.
For more information, in Help, press the color
key  Keywords and look up Apps.
1.8
Bluetooth Connection
Your TV comes with Bluetooth technology.
You can connect extra wireless speakers or a wireless
headphone. Forget connecting cables, pairing your
device with the TV is enough.
For more information, in Help, press the color
key  Keywords and look
up Bluetooth or Wireless Speakers.
5

2
Setting Up
2.1
Read Safety
Read the safety instructions first before you use the
TV.
To read the instructions, in Help, press the color
key  Keywords and look up Safety instructions.
2.2
TV Stand and Wall Mounting
TV Stand
You can find the instructions for mounting the TV
stand in the Quick Start Guide that came with the TV.
In case you lost this guide, you can download it
from www.philips.com.
Use the product type number of the TV to look for
the Quick Start Guide to download.
Wall Mounting
Your TV is also prepared for a VESA-compliant wall
mount bracket (sold separately).
Use the following VESA code when purchasing the
wall mount . . .
• 40PUG6700
VESA MIS-F 200x200, M4
• 50PUG6700, 55PUG6700
VESA MIS-F 400x200, M6
Preparation
First remove the 4 plastic screw caps out of the
threaded insert on the back of the TV.
Make sure that the metal screws to mount the TV to
the VESA-compliant bracket go about 0.4 inches
deep inside the threaded insert.
Caution
Wall mounting the TV requires special skills and
should only be performed by qualified personnel. The
TV wall mounting should meet safety standards
according to the TVs weight. Also read the safety
precautions before positioning the TV.
TP Vision Europe B.V. bears no responsibility for
improper mounting or any mounting that results in
accident or injury.
2.3
Tips on Placement
• Position the TV where light does not shine directly
on the screen.
• Position the TV up to 6 inches away from the wall.
• The ideal distance to watch TV is 3 times its diagonal
screen size. When seated, your eyes should be level
with the center of the screen.
2.4
Power Cable
• Insert the power cable into the POWER connector
on the back of the TV.
• Make sure the power cable is securely inserted in
the connector.
• Make sure that the power plug, in the wall socket, is
accessible at all times.
• When you unplug the power cable, always pull the
plug, never pull the cable.
Although this TV has a very low standby power
consumption, unplug the power cable to save energy
if you do not use the TV for a long period of time.
For more information, in Help, press the color
key  Keywords and look up Switching On for
more information on switching the TV on or off.
6

2.5
Antenna Cable
Insert the antenna plug firmly into
the Antenna socket at the back of the TV.
You can connect your own antenna or an antenna
signal from an antenna distribution system. Use an
IEC Coax 75 Ohm RF antenna connector.
7

3
Connect your
Android TV
3.1
Network and Internet
Home Network
To enjoy the full capabilities of your Philips Android
TV, your TV must be connected to the Internet.
Connect the TV to a home network with a high-speed
Internet connection. You can connect your TV
wirelessly or wired to your network router.
Connect to Network
Wireless Connection
What You Need
To connect the TV to the Internet wirelessly, you need
a Wi-Fi router with a connection to the Internet.
Use a high-speed (broadband) Internet connection.
Make the Connection
Wireless
To make a wireless connection…
1 - Press , select All Settings and press OK.
2 - Select Wireless and Networks and press 
(right) to enter the menu.
3 - Select Wired or Wi-Fi > Connect to
Network and press OK.
4 - Select Wireless and press OK.
5 - In the list of found networks, select your wireless
network. If your network is not in the list because the
network name is hidden (you switched off the router's
SSID broadcast), select Add New Network to enter
the network name yourself.
6 - Depending on the type of router, enter your
encryption key - WEP, WPA or WPA2. If you entered
the encryption key for this network before, you can
select OK to connect immediately.
7 - A message will be shown when the connection is
successful.
Wi-Fi On/Off
Make sure Wi-Fi is switched on before you try to
make the connection…
1 - Press , select All Settings and press OK.
2 - Select Wireless and Networks and
press  (right).
3 - Select Wired or Wi-Fi > Wi-Fi On/Off and
press OK.
4 - If it is switched off, select On and press OK.
WPS
If your router has WPS, you can directly connect to
the router without scanning for networks. If you have
devices in your wireless network that use the WEP
security encryption system, you cannot use WPS.
1 - Press , select All Settings and press OK.
2 - Select Wireless and Networks and
press  (right) to enter the menu.
3 - Select Wired or Wi-Fi > Connect to
Network and press OK.
4 - Select WPS then press OK.
5 - Go to the router, press the WPS button and return
to the TV within 2 minutes.
6 - Select Connect to make the connection.
7 - A message will be shown when the connection is
successful.
WPS with PIN Code
If your router has WPS with a PIN code, you can
directly connect to the router without scanning for
networks. If you have devices in your wireless
network that use the WEP security encryption system,
you cannot use WPS.
1 - Press , select All Settings and press OK.
2 - Select Wireless and Networks and
press  (right) to enter the menu.
3 - Select Wired or Wi-Fi > Connect to
Network and press OK.
4 - Select WPS with PIN code and press OK.
5 - Write down the 8-digit PIN code shown on
screen and enter it in the router software on your PC.
Consult the router manual on where to enter the PIN
code in the router software.
6 - Select Connect to make the connection.
7 - A message will be shown when the connection is
successful.
8

Problems
Wireless network not found or distorted
• Microwave ovens, DECT phones or other Wi-Fi
802.11b/g/n devices in your proximity might disturb
the wireless network.
• Make sure that the firewalls in your network allow
access to the TV's wireless connection.
• If the wireless network does not work properly in
your home, try the wired network installation.
Internet does not work
• If the connection to the router is OK, check the
router connection to the Internet.
The PC and Internet connection are slow
• Look in your wireless router's user manual for
information on indoor range, transfer rate and other
factors of signal quality.
• Use a high-speed (broadband) Internet connection
for your router.
DHCP
• If the connection fails, you can check the DHCP
(Dynamic Host Configuration Protocol) setting of the
router. DHCP should be switched on.
Wired Connection
What You Need
To connect the TV to the Internet, you need a
network router with a connection to the
Internet. Use a high-speed (broadband) connection
to the Internet.
Make the Connection
To make a wired connection…
1 - Connect the router to the TV with a network cable
(Ethernet cable**).
2 - Make sure that the router is turned on.
3 - Press , select All Settings and press OK.
4 - Select Wireless and Networks and
press  (right) to enter the menu.
5 - Select Wired or Wi-Fi > Connect to
Network and press OK.
6 - Select Wired and press OK. The TV constantly
searches for the network connection.
7 - A message will be shown when the connection is
successful.
If the connection fails, you can check the DHCP
setting of the router. DHCP should be switched on.
**To fulfill EMC regulations, use a shielded FTP Cat.
5E Ethernet cable.
Network settings
View Network Settings
You can view all current network settings here. The
IP and MAC address, signal strength, speed,
encryption method, etc.
To view the current network settings…
1 - Press , select All Settings and press OK.
2 - Select Wireless and Networks and
press  (right) to enter the menu.
3 - Select Wired or Wi-Fi > View Network
Settings and press OK.
4 - Press  (left) repeatedly if necessary, to close
the menu.
Network Configuration
If you are an advanced user and want to install your
network with Static IP addressing, set the TV to Static
IP.
To set the TV to Static IP…
1 - Press , select All Settings and press OK.
2 - Select Wireless and Networks and
press  (right) to enter the menu.
3 - Select Wired or Wi-Fi > Network
Configuration and press OK.
4 - Select Static IP and press OK to enable Static
IP Configuration.
5 - Select Static IP Configuration and configure the
connection.
6 - You can set the number for the IP
Address, Netmask, Gateway, DNS 1, or DNS 2.
7 - Press  (left) repeatedly if necessary, to close
the menu.
Switch On with Wi-Fi (WoWLAN)
You can switch this TV on from your smartphone or
tablet if the TV is on Standby. The setting Switch On
with Wi-Fi (WoWLAN) must be switched on.
To switch on WoWLAN…
1 - Press , select All Settings and press OK.
2 - Select Wireless and Networks and
press  (right) to enter the menu.
3 - Select Wired or Wi-Fi > Switch On with Wi-Fi
9

(WoWLAN) and press OK.
4 - Select On and press OK.
5 - Press  (left) repeatedly if necessary, to close
the menu.
Switch on Wi-Fi Connection
You can switch the Wi-Fi connection on your TV on
or off.
To switch on Wi-Fi…
1 - Press , select All Settings and press OK.
2 - Select Wireless and Networks and
press  (right) to enter the menu.
3 - Select Wired or Wi-Fi > Wi-Fi On/Off and
press OK.
4 - Select On and press OK.
5 - Press  (left) repeatedly if necessary, to close
the menu.
Digital Media Renderer - DMR
If your media files do not play on your TV, make sure
that the Digital Media Renderer is turned on. As a
factory setting, DMR is turned on.
To switch on DMR…
1 - Press , select All Settings and press OK.
2 - Select Wireless and Networks and
press  (right) to enter the menu.
3 - Select Wired or Wi-Fi > Digital Media Renderer
- DMR and press OK.
4 - Select On and press OK.
5 - Press  (left) repeatedly if necessary, to close
the menu.
Switch on Wi-Fi Miracast
Enable Wi-Fi Miracast to share the screen of your
smartphone, tablet, or computer on the TV.
To switch on Miracast…
1 - Press , select All Settings and press OK.
2 - Select Wireless and Networks and
press  (right) to enter the menu.
3 - Select Wired or Wi-Fi > Wi-Fi Miracast and
press OK.
4 - Select On and press OK.
5 - Press  (left) repeatedly if necessary, to close
the menu.
For more information, in Help, press the color
key  Keywords and look up Miracast™, switch
on.
Clear Wi-Fi Miracast Connection
Clear the list of connected and blocked devices that
are used with Miracast.
To clear Miracast connections…
1 - Press , select All Settings and press OK.
2 - Select Wireless and Networks and
press  (right) to enter the menu.
3 - Select Wired or Wi-Fi > Wi-Fi Miracast
Connections and press OK.
4 - Select Clear All and press OK.
5 - Press  (left) repeatedly if necessary, to close
the menu.
Wi-Fi Smart Screen
To watch digital TV channels on your smartphone or
tablet with the Philips TV Remote App, you must
switch on the Wi-Fi Smart Screen. Some scrambled
channels might not be available on your mobile
device.
To switch on the Wi-Fi Smart Screen…
1 - Press , select All Settings and press OK.
2 - Select Wireless and Networks and
press  (right) to enter the menu.
3 - Select Wired or Wi-Fi > Wi-Fi Smart
Screen and press OK.
4 - Select On and press OK.
5 - Press  (left) repeatedly if necessary, to close
the menu.
TV Network Name
If you have more than one TV in your home network,
you can give the TV a unique name.
To change the TV name…
1 - Press , select All Settings and press OK.
2 - Select Wireless and Networks and
press  (right) to enter the menu.
3 - Select Wired or Wi-Fi > TV Network Name and
press OK.
4 - Enter the name with the on-screen keyboard or
the remote control keyboard (if available).
5 - Select  to confirm the change.
6 - Press  (left) repeatedly if necessary, to close
the menu.
Clear Internet Memory
With Clear Internet Memory, you can clear all
Internet files and logins stored on your TV, such as
passwords, cookies, and history.
To clear the Internet memory…
10

1 - Press , select All Settings and press OK.
2 - Select Wireless and Networks and
press  (right) to enter the menu.
3 - Select Wired or Wi-Fi > Clear Internet
Memory and press OK.
4 - Select OK to confirm.
5 - Press  (left) repeatedly if necessary, to close
the menu.
File Sharing
The TV can connect to other devices in your wireless
network, like your computer or smartphone. You can
use a computer with Microsoft Windows or Apple OS
X.
On this TV, you can open photos, music, and videos
stored on your computer. Use any recent DLNA
certified media server software.
Install the media server software on your computer
and set it up to share your media files with the TV.
Read the manual of the media server software for
more information. This software must be running on
your computer to view or play your files on TV.
3.2
Google Account
Sign In
To enjoy the full capabilities of your Philips Android
TV, you can sign in to Google with your Google
Account.
By signing in you'll be able to play your favorite
games across phone, tablet and TV. You'll also get
customized video and music recommendations on
your TV home screen as well as access to YouTube,
Google Play and other apps.
Sign In
Use your existing Google Account to sign in to
Google on your TV. A Google Account consists of an
email address and a password. If you don't have an
Google Account yet, use your computer or tablet to
create one (accounts.google.com). To play games
with Google Play, you need a Google+ profile. If you
did not sign in during the first TV installation, you can
always sign in later.
To sign in after completing the TV installation…
1 - Press , select All Settings and press OK.
2 - Select Android Settings and press OK.
3 - Press  (down) and select Personal > Add
account and press OK.
4 - Select SIGN IN and press OK.
5 - With the remote control keyboard, enter your
email address and press the small OK button to the
right of the keyboard.
6 - Enter your password and press the same
small OK button to sign in.
7 - Press  (left) repeatedly if necessary, to close
the menu.
If you want to sign in with another Google Account,
first sign out, and then sign in with the other account.
Android Settings
You can set or view several Android specific settings
or information. You can find the list of apps installed
on your TV and the storage space they need. You can
set the language you would like to use with Voice
Search. You can configure the on-screen keyboard
or allow apps to use your location. Explore the
different Android settings. You can go
to www.support.google.com/androidtv for more
information on these settings.
To open these settings…
1 - Press , select All Settings and press OK.
2 - Select Android Settings, and press OK.
3 - Explore the different Android settings.
4 - Press  BACK if necessary, to close the menu.
3.3
Philips App Gallery
Philips Apps
Connect the TV to the Internet to enjoy apps selected
by Philips. These apps are made specially for
TVs. The Philips App Gallery offers a wide diversity
of apps. For some countries, you can install apps of a
local Video Store or apps from TV broadcasters in
your country. The latter may offer Catch-Up TV
services.
The Philips App Gallery collection of apps may differ
by country or region.
Some App Gallery apps are pre-installed on your TV.
To install other apps from the App Gallery, you will be
asked to agree to the Terms of Use. You can set the
Privacy Settings according to your preferences.
Terms of Use
To install and use the Philips App Gallery apps, you
must agree to the Terms of Use. If you did not agree
to these terms during the first TV installation, you can
always agree to them later. The moment you agree to
the Terms of Use, some apps will be available
immediately and you can browse the Philips App
11

Gallery to install other apps.
To agree to the Terms of Use after TV installation…
1 - Press  HOME and select Philips Collection >
App Gallery and press OK to open the App Gallery.
2 - Select Terms of Use, then press OK to read.
3 - Select Accept and press OK. You cannot undo
this approval.
4 - Press  BACK to close the menu.
Privacy Settings
You can set some privacy settings for the Philips App
Gallery apps.
• You can allow technical statistics to be send to
Philips.
• You can allow personal recommendations.
• You can allow cookies.
• You can switch on the Child Lock for 18+ rated apps.
To set the Philips App Gallery privacy settings…
1 - Press  HOME and select Philips
Collection > App Gallery and press OK to open
the App Gallery.
2 - Select Privacy Policy, then press OK to read.
3 - Select Accept and press OK. You cannot undo
this approval.
4 - Press  BACK to close the menu.
12

4
Connect Devices
4.1
About Connections
Connectivity Guide
Always connect a device to the TV with the highest
quality connection available. Also, use high quality
cables to ensure good transfer of picture and sound.
When you connect a device, the TV recognizes its
type and gives each device a correct type name. You
can change the type name if you wish. If a correct
type name for a device is set, the TV automatically
switches to the ideal TV settings when you switch to
this device in the Sources menu.
If you need help to connect several devices to the TV,
you can visit the Philips TV connectivity guide. The
guide offers information on how to connect and
which cables to use.
Go to www.connectivityguide.philips.com
Antenna port
If you have a Set-top box (a digital receiver) or
Recorder, connect the antenna cables to run the
antenna signal through the Set-top box and/or
Recorder first before it enters the TV. In this way, the
antenna and the Set-top box can send possible
additional channels to the Recorder to record.
HDMI ports
HDMI Quality
An HDMI connection has the best picture and sound
quality. One HDMI cable combines video and audio
signals. Use an HDMI cable for High Definition (HD) or
Ultra HD (UHD) TV signals.
For best signal quality transfer, use a High speed
HDMI cable and do not use an HDMI cable longer
than 5 m.
Copy protection
HDMI cables support HDCP (High-bandwidth Digital
Content Protection). HDCP is a copy protection signal
that prevents copying content from a DVD disc or Blu-
ray Disc. Also referred to as DRM (Digital Rights
Management).
HDMI ARC
Typically a Home Theater System (HTS) has an HDMI
ARC connection, connect it to HDMI 1 or HDMI 2 on
this TV. With an HDMI ARC connection, you do not
need to connect an extra audio cable that sends the
sound of the TV picture to the HTS. The HDMI ARC
connection combines both signals.
You can use any of HDMI 1 or HDMI 2 connection on
this TV to connect the HTS, but ARC is only available
for 1 device/connection at a time.
HDMI MHL
With HDMI MHL, you can send what you see on your
Android smartphone or tablet to a TV screen.
The HDMI 1 connection on this TV
incorporates MHL 2.0 (Mobile High-Definition Link).
This wired connection offers great stability and
bandwidth, low latency, no wireless interference and
good quality sound reproduction. On top of that, the
MHL connection will charge the battery of your
smartphone or tablet. Although connected, your
mobile device will not be charging when the TV is on
standby.
Inform yourself regarding which passive MHL cable is
suited for your mobile device. In particular, with the
HDMI connector for the TV on one side, the type of
connector you need to connect to your smartphone
or tablet.
MHL, Mobile High-Definition Link and the MHL Logo
are trademarks or registered trademarks of the MHL,
LLC.
13

HDMI CEC - EasyLink
EasyLink
An HDMI connection has the best picture and sound
quality. One HDMI cable combines video and audio
signals. Use an HDMI cable for High Definition (HD) or
Ultra HD (UHD) TV signals. For best signal quality
transfer, use a High speed HDMI cable and do not use
an HDMI cable longer than 5 m.
EasyLink HDMI CEC
If your devices are connected with HDMI and have
EasyLink, you can operate them with the TV remote
control. EasyLink HDMI CEC must be switched On on
the TV and the connected device.
With EasyLink you can operate a connected device
with the TV remote control. EasyLink uses HDMI CEC
(Consumer Electronics Control) to communicate with
the connected devices. Devices must support HDMI
CEC and must be connected with an HDMI
connection.
EasyLink setup
The TV comes with EasyLink switched on. Make sure
that all HDMI CEC settings are properly set up on the
connected EasyLink devices. EasyLink might not work
with devices from other brands.
HDMI CEC on other brands
The HDMI CEC functionality has different names on
different brands. Some examples are: Anynet, Aquos
Link, Bravia Theater Sync, Kuro Link, Simplink and
Viera Link. Not all brands are fully compatible with
EasyLink.
Example HDMI CEC branding names are property of
their respective owners.
Operate Devices
To operate a device connected to HDMI and set up
with EasyLink, select the device - or its activity - in
the list of TV connections. Press  SOURCES , select
a device connected to an HDMI connection and
press OK.
Once the device is selected, the TV remote control
can control the device. However the
keys  HOME and  OPTIONS and some other
TV keys are not forwarded to the device.
If the key you need is not on the TV remote control,
you can select the key in the Options menu.
Press  OPTIONS and select Controls in the
menu bar. On the screen, select the device key you
need and press OK.
Some very specific device keys might not be available
in the Controls menu.
Only devices that support EasyLink Remote
Control function will respond to the TV remote
control.
EasyLink On or Off
You can switch EasyLink on or off. The TV comes with
the EasyLink settings switched on.
To switch off EasyLink completely…
1 - Press , select All Settings and press OK.
2 - Select General Settings and press  (right) to
enter the menu.
3 - Select EasyLink, press  (right) and
select EasyLink one step further.
4 - Select Off.
5 - Press  (left) repeatedly if necessary, to close
the menu.
EasyLink Remote Control
If you want devices to communicate but you don't
want to operate them with the TV remote control, you
can switch off EasyLink Remote Control separately.
To switch EasyLink Remote Control on or off…
1 - Press , select All Settings and press OK.
2 - Select General Settings and press  (right) to
enter the menu.
3 - Select EasyLink > EasyLink Remote
Control and press OK.
4 - Select On or Off and press OK.
5 - Press  (left) repeatedly if necessary, to close
the menu.
DVI to HDMI
If you still own a device that only has a DVI
connection, you can connect the device to any of
the HDMI connections with a DVI to HDMI adapter.
Use a DVI to HDMI adapter if your device only has a
DVI connection. Use one of the HDMI connections
and add an Audio L/R cable (mini-jack 3.5mm) to
Audio In for sound, on the back of the TV.
14

Copy protection
DVI and HDMI cables support HDCP (High-bandwidth
Digital Content Protection). HDCP is a copy protection
signal that prevents copying content from a DVD disc
or Blu-ray Disc. Also referred to as DRM (Digital
Rights Management).
CVBS - Composite
Next to the CVBS signals add the Audio Left and Right
signals for sound.
Use an Audio L/R cinch cable if your device also has
sound.
.
Audio Out - Optical
Audio Out - Optical is a high quality sound
connection.
This optical connection can carry 5.1 audio channels.
If your device, typically a Home Theater System
(HTS), has no HDMI ARC connection, you can use this
connection with the Audio In - Optical connection on
the HTS. The Audio Out - Optical connection sends
the sound from the TV to the HTS.
You can set the type of the audio out signal to fit the
audio capabilities of your Home Theater System.
For more information, in Help, press the color
key  Keywords and look up Audio Out Settings.
If the sound does not match the video on screen, you
can adjust the audio to video synchronization.
For more information, in Help, press the color
key  Keywords and look up Audio to Video
Sync.
4.2
Receiver - Set-Top Box
Use 2 antenna cables to connect the antenna to the
Set-top box (a digital receiver) and the TV.
Next to the antenna connections, add an HDMI cable
to connect the Set-top box to the TV.
Switch Off Timer
Switch off this automatic timer, if you only use the
remote control of the Set-top box. Switch this timer
off to prevent the TV from switching off automatically
after a preset time without a key press on the remote
control of the TV.
For more information, in Help, press the color
key  Keywords and look up Switch Off
Timer for more information.
15

4.3
Home Theater System - HTS
Connect with HDMI ARC
Use an HDMI cable to connect a Home Theater
System (HTS) to the TV. You can connect a Philips
Soundbar or an HTS with a built-in disc player.
HDMI ARC
If your Home Theater System has an HDMI ARC
connection, you can use any HDMI connection on the
TV to connect. With HDMI ARC, you do not need to
connect the extra audio cable. The HDMI ARC
connection combines both signals.
All HDMI connections on the TV can offer the Audio
Return Channel (ARC) signal, but once you have
connected the Home Theater System, the TV can
only send the ARC signal to this HDMI connection.
Audio to video synchronization (sync)
If the sound does not match the video on screen, you
can set a delay on most Home Theater Systems with
a disc player to match the sound with the video.
For more information, in Help, press the color
key  Keywords and look up Audio to Video
Sync.
Connect with HDMI
Use an HDMI cable to connect a Home Theater
System (HTS) to the TV. You can connect a Philips
Soundbar or an HTS with a built-in disc player.
If the Home Theater System has no HDMI ARC
connection, add an optical audio cable to send the
sound of the TV picture to the Home Theater System.
Audio to video synchronization (sync)
If the sound does not match the video on screen, you
can set a delay on most Home Theater Systems with
a disc player to match the sound with the video.
For more information, in Help, press the color
key  Keywords and look up Audio to Video
Sync.
Audio Out Settings
Audio Out Delay
With a Home Theater System (HTS) connected to the
TV, the picture on the TV and the sound from the HTS
should be synchronized.
Automatic audio to video sync
With recent Philips Home Theater Systems, the audio
to video sync is done automatically and always
correct.
Audio sync delay
For some Home Theater Systems you may need to
adjust the audio sync delay to synchronize the audio
to the video. On the HTS, increase the delay value
until there is a match between picture and sound. A
delay value of 180ms may be required. Read the user
manual of the HTS. With a delay value set up on the
HTS, you need to switch off Audio Out delay on the
TV.
To switch off Audio Out Delay…
1 - Press , select All Settings and press OK.
2 - Select Sound and press  (right) to enter the
menu.
3 - Select Advanced > Audio Out Delay and
press OK.
4 - Select Off.
5 - Press  (left) repeatedly if necessary, to close
the menu.
Audio Out Offset
If you cannot set a delay on the Home Theater
System, you can set the TV to sync the sound. You
can set an offset that compensates for the time
necessary for the Home Theater System to process
the sound of the TV picture. You can set the value in
steps of 5ms. Maximum setting is -60ms.
The Audio Out Delay setting should be switched on.
To synchronize the sound on the TV…
1 - Press , select All Settings and press OK.
2 - Select Sound and press  (right) to enter the
menu.
3 - Select Advanced > Audio Out Offset and
16

press OK.
4 - Use the slider bar to set the sound offset and
press OK.
5 - Press  (left) repeatedly if necessary, to close
the menu.
Audio Out Format
If you have a Home Theater System (HTS)
with multichannel sound processing capabilities like
Dolby Digital, DTS® or similar, set the Audio Out
Format to Multichannel. With Multichannel, the TV
can send the compressed multichannel sound signal
from a TV channel or connected player to the Home
Theater System. If you have a Home Theater System
without multichannel sound processing, select Stereo.
To set Audio Out Format…
1 - Press , select All Settings and press OK.
2 - Select Sound and press  (right) to enter the
menu.
3 - Select Advanced > Audio Out Format and
press OK.
4 - Select Multichannel or Stereo (uncompressed),
then press OK.
5 - Press  (left) repeatedly if necessary, to close
the menu.
Audio Out Leveling
Use the Audio Out Leveling setting to level the
volume (loudness) of the TV and the Home Theater
System when you switch over from one to another.
Volume differences can be caused by differences in
sound processing.
To level the difference in volume…
1 - Press , select All Settings and press OK.
2 - Select Sound and press  (right) to enter the
menu.
3 - Select Advanced > Audio Out Leveling and
press OK.
4 - Select More, Medium, or Less, then press OK.
5 - If the volume difference is large, select More. If
the volume difference is small, select Less.
6 - Press  (left) repeatedly if necessary, to close
the menu.
Audio Out Leveling affects both the Audio Out -
Optical and HDMI ARC sound signals.
Problems with HTS sound
Sound with loud noise
If you watch a video from a plugged in USB flash drive
or connected computer, the sound from your Home
Theater System might be distorted. This noise is heard
when the audio or video file has DTS sound but the
Home Theater System has no DTS sound processing.
You can fix this by setting the Audio Out Format of
the TV to Stereo.
Press  for All
settings > Sound > advanced > Audio Out
Format.
No sound
If you cannot hear the sound from the TV on your
Home Theater System, check if you connected the
HDMI cable to an HDMI ARC connection on the
Home Theater System. All HDMI connections on the
TV are HDMI ARC connections.
4.4
Smartphones and Tablets
To connect a smartphone or tablet to the TV, you can
use a wireless or wired connection.
Wireless
For a wireless connection on your smartphone or
tablet, download the Philips TV Remote App from
your favorite app store.
Wired
For a wired connection, use the HDMI 1 MHL
connection on the back of the TV. In Help, press the
color key  Keywords and look up HDMI
MHL for more information.
4.5
Blu-ray Disc Player
Use a High speed HDMI cable to connect the Blu-
ray Disc player to the TV.
If the Blu-ray Disc player has EasyLink HDMI CEC,
you can operate the player with the TV remote
17

control.
4.6
DVD Player
Use an HDMI cable to connect the DVD player to the
TV.
If the DVD player is connected with HDMI and has
EasyLink CEC, you can operate the player with the TV
remote control.
For more information on EasyLink, in Help, press the
color key  Keywords and look up EasyLink
HDMI CEC.
4.7
Bluetooth - Speakers and
Gamepads
What You Need
You can connect a wireless device with Bluetooth® to
this TV: a wireless speaker, a subwoofer, a sound bar,
or headphones. You can also connect a wireless
gamepad with Bluetooth LE.
To play the TV sound through a wireless speaker, you
must pair the wireless speaker with the TV. You can
pair up to 4 wireless speakers, but you can only play
the sound through one wireless audio speaker at a
time. If you connect a subwoofer, the sound is
played through the TV and the subwoofer. If you
connect a sound bar, the sound is played through the
sound bar only.
Attention: Audio to Video syncronization
Many Bluetooth speaker systems have a high, so
called, "latency." High latency means that the audio
lags behind the video, causing unsynchronized "lip
sync." Before you purchase a wireless Bluetooth
speaker system, learn about the newest models and
look for a device with a low latency rating. Ask your
dealer for advice.
For more information on how to pair a wireless
speaker, in Help, press the color key  Keywords
and look up Bluetooth, Pairing.
Pairing a Device
Position the wireless speaker within a distance of
about 16 feet from the TV. Read the user manual of
the device for specific information on pairing and on
wireless range. Make sure the TV's Bluetooth setting is
switched on.
Once a wireless gamepad is paired, you can use it.
When a wireless speaker is paired, you can select it to
play the TV sound. When a device is paired, you do
not need to pair it again unless you remove the
device.
To pair a wireless speaker with the TV
1 - Switch on the wireless speaker and place it within
range of the TV.
2 - Press , select All Settings and press OK.
3 - Select Wireless and Networks and
press  (right) to enter the menu.
4 - Select Bluetooth > Search Bluetooth Device,
and press OK.
5 - Select Search and press OK. Follow the
instructions on screen. You will pair the device with
the TV and the TV will store the connection.
6 - Select the type of device (headphones,
subwoofer, …), select Next and press OK.
7 - Press  (left) repeatedly if necessary, to close
the menu.
For more information on how to select the wireless
speaker, in Help, press the color
key  Keywords and look up Speakers, Select.
For more information on the Bluetooth On or Off
setting, in Help, press the color
key  Keywords and look up Bluetooth, On or
Off.
Select a Device
Once a wireless Bluetooth speaker is paired, you can
select it to play the TV sound.
To select a speaker to play the TV sound…
1 - Press , select Speakers and press OK.
2 - Select the speaker system you want and
press OK.
3 - Press  (left) repeatedly if necessary, to close
the menu.
18

Remove a Device
You can connect or disconnect a wireless Bluetooth
device. When a Bluetooth device is connected, you
can use the gamepad or hear the TV sound through
the wireless speaker. You can also remove a wireless
Bluetooth device. If you remove a Bluetooth device,
the device will be unpaired.
To remove or disconnect a wireless device…
1 - Press , select All Settings and press OK.
2 - Select Wireless and Networks and press OK.
3 - Select Bluetooth > Remove Device and
press OK.
4 - In the list, select the wireless device and
press OK.
5 - Select Disconnect or Remove and press OK.
6 - Select OK and press OK to confirm.
7 - Press  (left) repeatedly if necessary, to close
the menu.
4.8
Headphones
You can connect a set of headphones to
the  connection on the back of the TV. The
connection is a mini-jack 3.5mm. You can adjust the
volume of the headphones separately.
To adjust the volume…
1 - Press , select Headphone Volume and
press OK.
2 - Press the arrows  (up) or  (down) to adjust
the value.
3 - Press  (left) repeatedly if necessary, to close
the menu.
4.9
Game Consoles
HDMI
For best quality, connect the game console with a
high-speed HDMI cable to the TV.
Video-Audio L/R
Connect the game console to the TV with a
composite cable (CVBS) and an audio L/R cable to
the TV.
Best Setting
Before you start playing a game from a connected
game console, we advise you to set the TV in the
ideal setting Game.
When you finish playing a game and start watching
TV again, remember to switch the Game or Computer
setting back to Off.
To set the TV to the ideal setting…
1 - Press , select All Settings and press OK.
2 - Select Picture > Advanced and select Game or
Computer.
3 - Select Off, Game or Computer.
4 - Press  (left) repeatedly if necessary, to close
the menu.
19

4.10
Gamepad
Connect a Gamepad
To play games from the Internet on this TV, you can
connect a selected range of wireless gamepads. You
can use gamepads with a USB nano receiver or
gamepads with Bluetooth.
To connect a gamepad with a USB nano receiver…
1 - Plug the small nano receiver into one of the USB
connections on the side of the TV. The wireless nano
receiver comes with the gamepad.
2 - If the gamepad is switched on, you can use the
gamepad.
You can connect a second gamepad in the second
USB connection on the side of the TV.
Bluetooth
To connect a wireless gamepad with Bluetooth,
in Help, press the color key  Keywords and look
up Bluetooth, Pairing.
Suitable gamepads
A selected range of wireless gamepads are suited and
tested for use on this TV. Other gamepads might not
be fully compatible.
The suited gamepads are…
• Logitech F710
• Logitech F510
• Xbox 360 Wireless Controller for Windows
• Speedlink Strike FX Wireless Gamepad
• Sony Play Station wired
• Mad Catz C.T.R.L. Mobile Gamepad for Android
• Ipega, PG-9023
• Ipega, PG-9025
• PhoneJoy gamepad
Problems
To solve possible interference with other wireless
devices on TV…
• Use a USB extension cord and move the nano
receiver about 3 feet away from the TV.
• Alternatively, you can use a powered USB hub
connected to the TV and plug the nano receivers into
the USB hub.
4.11
USB Hard Drive
What You Need
If you connect a USB Hard Drive, you can pause or
record a TV broadcast. The TV broadcast must be a
digital broadcast (DVB broadcast or similar).
To Pause
To pause a broadcast, you need a USB 2.0
compatible Hard Drive with a minimum of 4GB of disk
space.
To Record
To pause and record a broadcast, you need a
minimum of 250GB disk space. If you want to record
a broadcast with TV guide data from the Internet, you
need to have the Internet connection installed on
your TV before you install the USB Hard Drive.
For more information on how to install a USB Hard
Drive, in Help, press the color
key  Keywords and look up USB Hard Drive,
installation.
Installation
Before you can pause or record a broadcast, you
must connect and format a USB Hard Drive.
Formatting removes all files from the USB Hard Drive.
1 - Connect the USB Hard Drive to one of
the USB connections on the TV. Do not connect
another USB device to the other USB ports when
formatting.
2 - Switch on the USB Hard Drive and the TV.
3 - When the TV is tuned to a digital TV channel,
press  (Pause). Trying to pause will start the
formatting.
Follow the instructions on screen.
When the USB Hard Drive is formatted, leave it
connected permanently.
Warning
The USB Hard Drive is formatted exclusively for this
TV, you cannot use the stored recordings on another
TV or PC. Do not copy or change recording files on
20
