139 mm (54.8")
Wall mounting instructions
Drill holes on wall at hole positions marked (no accessories provided with this template)
What’s in the supplied mounting kit
1 x wall mount template
What else you’ll need
Electric drill•
2 x screws and dowels•
Screwdriver•
Pencil•
Mount the main unit
Caution
To find a suitable mounting location, make the necessary•
physical and wireless connections.
Mount the main unit and speakers to a solid concrete
•
wall or plaster board wall only!
You can use the supplied bracket to mount the
main unit and speakers to the wall.
140 mm
1 Align the template in the chosen location on
a wall. Use a pencil to mark the drilling posi-
tions.
2Drill holes as marked.
3Secure 2 supplied screws in the holes, but
leave 5mm between the screw head and
the wall.
4 Detach the table stand from the main unit.
5Hook the main unit in place.
139MM
EN
Wall Mounting_98.indd 1Wall Mounting_98.indd 1 2009-3-4 17:26:252009-3-4 17:26:25
安裝套件隨附物品:
1 個壁掛板
您還需要
• 電鑽
• 2 個螺絲和暗榫
螺絲起子•
鉛筆•
掛置主裝置
注意
• 找到合適的架設位置,並完成必要的實體連線和無線連線。
掛置主裝置和揚聲器的牆面必須為堅固的混凝土牆或石膏
•
板牆!
您可使用隨附的支架將主裝置與揚聲器固定到
牆上。
140 mm
1 將壁掛板對準牆上選定的安裝位置。 用鉛
筆標記鑽孔位置。
2在標記的位置上鑽孔。
3將 2 顆隨附的螺絲鎖入孔中,螺絲頭與牆
面之間保留 5 公釐間隙。
4 主裝置的桌面腳架拆下。
5將主裝置掛到牆上。
139MM
139 mm (54.8")
壁掛安裝指示
已此墊紙為樣本在牆上鑚洞 (未隨附任何樣本配件)。
ZH-TW
Wall Mounting_98.indd 2Wall Mounting_98.indd 2 2009-3-4 17:26:282009-3-4 17:26:28
