Issue date 2014-02-13
Version: 7.1.7
12 NC: 8670 000 59878
EAN: 87 12581 52486 9
© 2014 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
32PFL5615D/78
Specifications
LCD TV with Pixel Plus HD
81 cm (32") Full HD 1080p, digital TV
Picture/Display
• Aspect ratio: Widescreen
• Brightness: 450 cd/m²
• Response time (typical): 2 ms
• Viewing angle: 176º (H) / 176º (V)
• Diagonal screen size: 32 inch / 81 cm
• Display: LCD Full HD, direct LED backlight
• Panel resolution: 1920x1080p
• Picture enhancement: Pixel Plus HD, Active
Control + Light sensor, Color Enhancement,
Digital Noise Reduction, Dynamic contrast
enhancement, Luminance Transient Improver,
MPEG artifact reduction, 120Hz Clear LCD, HD
Natural Motion
• Screen enhancement: Anti-Reflection coated
screen
• Color cabinet: High gloss black deco front with
black cabinet
Supported Display Resolution
• Computer inputs: up to 1920x1080 @ 60Hz
• Video inputs: up to 1920x1080p, 24, 25, 30, 50, 60
Hz
Sound
• Output power (RMS): 20W
• Sound Enhancement: Auto Volume Leveller,
Dynamic Bass Enhancement, Incredible Surround,
Treble and Bass Control, Clear Sound
• Sound System: Mono, Stereo, SAP
Convenience
• Child Protection: Child Lock+Parental Control
• Clock: Sleep Timer
• Ease of Installation: Channel installation wizard,
Network installation wizard, Settings assistant
wizard, Device connection wizard, Auto detect
Philips devices, Auto Program Naming, Autoinstall,
Program Name, Sorting
• Ease of Use: Smart Picture, Smart Sound, Closed
Captioning Full Text, Onscreen Usermanual,
EasyLink, Favorite program selection, Mozaïc
channel grid, One-stop experience button, One-
stop Home button
• Electronic Program Guide: Now + Next EPG, 7
day Electronic Program Guide
• On-Screen Display languages: English, Portuguese,
Spanish
• Remote Control: TV
• Screen Format Adjustments: Autofill (no black
bars), Autozoom (original format), Super Zoom,
Movie expand 16:9, Widescreen, unscaled (1080p
dot by dot), 16:9 stretch
• Signal strength indication
• Firmware upgradeable: Firmware auto upgrade
wizard, Firmware upgradeable via USB, Online
firmware upgrade
• Multimedia: USB autobreak-in, DLNA media
Browser, USB media browser, Online services
Multimedia Applications
• Multimedia connections: USB memory class device
• Picture Playback Formats: JPEG
• Music Playback Formats: MP3, WMA (v2 up to
v9.2), AAC
•Video Playback Formats: Codec support:, H264/
MPEG-4 AVC, MPEG-1, MPEG-2, MPEG-4,
WMV9/VC1, Containers: AVI, MKV
• Online services: Included
Tuner/Reception/Transmission
• Aerial Input: 75 ohm F-type
• TV system: NTSC M, PAL N, PAL M
• Video Playback: NTSC, PAL (all versions)
• Digital TV: SBTVD
• Tuner bands: Hyperband, S-Channel, UHF, VHF
•InteractiveTV:DTVi
Connectivity
• AV 1: Audio L/R in, YPbPr
• AV 2: Audio L/R in, YPbPr
• AV 3: Audio L/R in, CVBS in
• VGA-in: PC input, D-sub 15
•HDMI1:HDMIv1.4(AudioReturn Ch.)
•HDMI2:HDMIv1.3
•Front/Sideconnections: HDMI v1.3, USB
•Other connections: S/PDIF out (coaxial), Ethernet-
LAN RJ-45
• EasyLink (HDMI-CEC): One touch play, EasyLink,
Pixel Plus link (Philips), Remote control pass-
through, System audio control, System standby
• PC network link: DLNA 1.5 certified
• Summary: 3x HDMI, 1x USB, 2x YPbPr, 1x
Ethernet, Wi-Fi ready
Power
• Ambient temperature: 5 °C to 35 °C
• Mains power: 110-240V, 50/60Hz
• Power consumption (typical): 100 W
• Standby power consumption: < 0.15 W
• Power Saving Features: 0 Watt Power-off switch,
Light sensor, Eco mode, Picture mute (for radio)
Dimensions
• Compatible wall mount: 200 x 200mm
•Setdimensions(Wx H x D):
790 x 501.3 x 92 mm
• Set dimensions with stand (W x H x D):
790 x 542.4 x 221.4 mm
• Weight incl. Packaging: 13.5 kg
• Product weight: 10 kg
• Product weight (+stand): 11.7 kg
•Boxdimensions(Wx H x D):
967x 583.5 x 197 mm
Accessories
• Included accessories: Table top stand, Quick start
guide, User Manual, Remote Control, 2 x AAA
Batteries, Safety/legal instructions
• Optional accessories: Wireless USB adaptor
(PTA01)
•User Manual: Portuguese
•
* Avoid extensive use of the set in a volume higher than 85 decibel
because this may damage your hearing.
* Wi-Fi Media connect: The playback of video can be affected by your
PC speed and Wi-Fi bandwidth. For minimum and recommended
system requirements go to www.philips.com/wifimediaconnect.
Displays content with a delay of some seconds. Small differences of
image and sound can occur.
* The Ginga brand and logo are registered marks of Pontifical Catholic
University of Rio de Janeiro (PUC-Rio) and the Federal University of
Paraíba (UFPB).
* Online services: Visit www.philips.com/tv to discover the services
offering in your country
REAR CONNECTORS
BOTTOM REAR CONNECTORS
SIDE CONNECTORS
