Philips 8000 LED series
LCD TV with Ambilight
Spectra and Pixel Precise
HD
40"
Full HD 1080p digital TV
40PFL8664H
Enjoy a movie night
with Ambilight and LED
Featuring the Pixel Precise HD engine, this ultra-thin LED TV captures every moment in
stunning detail. Combining a slim frame of only 2.8 cm and Ambilight, you are guaranteed
a larger than life experience.
Immersive viewing experience
• Ambilight Spectra enhances the viewing experience
See precise details in action
• Pixel Precise HD with LED for extreme sharpness and clarity
• 100 Hz LCD, 3 ms performance for superb motion sharpness
• HD Natural Motion for ultra-smooth motion in Full HD movies
• Full HD TV, with 1920 x 1080p resolution
Stylish and elegant design
• Ultra slim and thin TV for perfect fit in your living room
Connect and enjoy the online world
• Net TV for popular online services on your TV
• DLNA PC network link for watching videos from your computer
Enjoy technology while being green
• 40% more energy efficient than conventional Flat TVs

40PFL8664H/12
Highlights
LCD TV with Ambilight Spectra and Pixel Precise HD
40" Full HD 1080p digital TV
Ambilight Spectra
Add a new dimension to your viewing
experience with Ambilight Spectra. This
patented Philips technology enlarges the
screen further by projecting a glow of light
from the back of the screen onto the
surrounding wall. Ambilight automatically
adjusts the colour and brightness of the light
surrounding the TV to match the picture,
creating an immersive viewing experience.
With Ambilight Spectra movies truly come to
life!
Pixel Precise HD
Pixel Precise HD with LED builds on the
award-winning Pixel Plus foundation. It brings
picture quality to the next level with 4 trillion
colours, and HD Natural Motion making all
your movies fluently moving and razor sharp.
You get the fastest 100 Hz LCD in the category
with 3 ms response time. Together with LED
technology it lets you enjoy breathtaking
images of high brightness and extreme motion
sharpness for all your movies and sports.
Ultra slim and thin TV
This 40" TV's state-of-the-art display
technology makes it both ultra-slim and ultra-
thin at the same time. With a frame of only 2.8
cm it fits into compact spaces, giving you more
viewing experience in the same footprint.
Ultra-thin profile of 3.9 cm creates a minimalist
appearance that fits well in any interior.
Wallmounted, or on the elegant stand.
Advanced technology in a breathtaking design.
Net TV
Experience a rich selection of online services
with Net TV. Enjoy movies, pictures,
infotainment and other online content directly
on your TV whenever you like. Simply connect
your home theatre directly to your home
network through the Ethernet connection, and
navigate and select what you want to watch
with the remote control. The Philips menu
gives you access to popular Net TV services
fitted for your TV screen. Additionally, with
the DLNA certified PC network you can watch
videos or access pictures stored on your
computer using your remote control.
100 Hz LCD (3 ms)
100 Hz LCD creates extreme motion
sharpness for clear and vibrant images even
with fast on-screen motion. The Double Frame
Rate Insertion works with a high 100 Hz
refresh rate. It increases the sharpness of
motion reproduction to more than twice that
of conventional LCD, resulting in a
performance with a response time of 3
milliseconds (measured in Perceived Blur-
Edge-Width: BEW). This unique Philips
technology takes motion sharpness of LCD
displays to an unprecedented level.
ECO Flower
Over the last 10 years we
have worked hard to
lower our environmental
impact and will continue to
do so. Our eco-design
process aims to create Philips televisions
that are increasingly eco-friendly and that
have significantly less impact on the
environment. Philips has been awarded
the EU ECO label (the flower) on the
majority of its models because of the
televisions' high energy efficiency, ultra
low standby power (up to 50% less than
the required EU ECO label level), absence
of hazardous substances (e.g. lead) and the
fact that Philips has designed televisions
that can be easily recycled.

Issue date 2010-09-03
Version: 8.6.4
12 NC: 8670 000 56456
EAN: 87 12581 50553 0
© 2010 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
40PFL8664H/12
Specifications
LCD TV with Ambilight Spectra and Pixel Precise HD
40" Full HD 1080p digital TV
Picture/Display
• Aspect ratio: Widescreen
• Brightness: 500 cd/m²
• Dynamic screen contrast: 500,000:1
• Response time (typical): 3 (BEW) ms
• Viewing angle: 176º (H)/176º (V)
• Diagonal screen size: 40 inch / 102 cm
• Panel resolution: 1920 x 1080p
• Picture enhancement: Pixel precise HD, 3/2 - 2/2
motion pull down, 3D Combfilter, Active Control
+ Light sensor, Digital Noise Reduction, Dynamic
contrast enhancement, Luminance Transient
Improver, Progressive scan, 2D/3D noise
reduction, 100 Hz LCD, 1080p 24/25/30 Hz
processing, 1080p 50/60 Hz processing, HD
Natural Motion, LED backlight Display
• Screen enhancement: Anti-Reflection coated
screen
• Colour processing: 4 trillion colours (14-bit RGB)
Ambilight
• Ambilight Features: Ambilight Spectra, Lounge light
mode
• Dimming Function: Manual and via Light Sensor
• Ambilight light system: LED-wide colour
Supported Display Resolution
•Computer formats
Resolution Refresh rate
640 x 480 60 Hz
800 x 600 60 Hz
1024 x 768 60 Hz
1280 x 1024 60 Hz
1360 x 768 60 Hz
1600 x 1200 60 Hz
1920 x 1080 60 Hz
•Video formats
Resolution Refresh rate
480i 60 Hz
480p 60 Hz
576i 50 Hz
576p 50 Hz
720p 50, 60 Hz
1080i 50, 60 Hz
1080p 24, 25, 30, 50, 60 Hz
Sound
• Output power (RMS): 2 x 10 W
• Sound Enhancement: Auto Volume Leveller,
Incredible Surround, Treble and Bass Control
• Sound System: Nicam Stereo
Loudspeakers
• Built-in speakers: 2
• Loudspeaker types: Full range speakers
Convenience
• Child Protection: Child Lock+Parental Control
• Clock: Sleep Timer
• Ease of Installation: Auto Programme Naming,
Automatic Channel Install (ACI), Automatic
Tuning System (ATS), Autostore, Fine Tuning, PLL
Digital Tuning, Plug and Play
• Ease of Use: Auto Volume Leveller (AVL), Delta
Volume per preset, Programme List, Settings
assistant Wizard, Side Control, On-screen User
manual, One-stop Home button, Favourite
programme selection
• Electronic Programme Guide: Now + Next EPG,
8-day Electronic Programme Guide*
• Remote control type: RC PF04E09B
• Screen Format Adjustments: Auto Format, Movie
expand 16:9, Super Zoom, Widescreen, unscaled
(1080p dot by dot)
• Teletext: 1000-page Smart Text
• Teletext enhancements: 4 favourite pages
• Firmware upgradeable: Firmware auto upgrade
wizard, Firmware upgradeable via USB
• Multimedia: USB autobreak-in, DLNA media
Browser, Internet browser, Net TV services, USB
media browser
• Smart mode: Game, Cinema, Personal, Power
saver, Standard, Vivid
Multimedia Applications
• Multimedia connections: Ethernet-UTP5, USB
• Playback Formats: MP3, WMA v2 up to v9.2,
Slideshow files (.alb), JPEG Still pictures, MPEG1,
MPEG2, MPEG4, AVI, H.264/MPEG-4 AVC, MPEG-
Programme-stream PAL, WMV9/VC1
Tuner/Reception/Transmission
• Aerial Input: 75 ohm coaxial (IEC75)
• TV system: DVB COFDM 2K/8K
• Video Playback: NTSC, SECAM, PAL
• Digital TV: DVB-T MPEG4*, DVB-C MPEG4*
• Tuner bands: Hyperband, S-Channel, UHF, VHF
Connectivity
• Ext 1 Scart: Audio L/R, CVBS in, RGB
• Ext 2 Scart: Audio L/R, CVBS in, RGB
• Ext 3: YPbPr, Audio L/R in
• Front/Side connections: USB
• PC network link: DLNA 1.0 certified
• Other connections: A/V Audio L/R in (value),
Analogue audio Left/Right out, S-Video in,
Composite video (CVBS) input, HDMI, Headphone
out, S/PDIF out (coaxial), Common Interface Plus
(CI+)
•HDMI1:HDMIv1.3a
•HDMI2:HDMIv1.3a
•HDMI3:HDMIv1.3a
• EasyLink (HDMI-CEC): One touch play, Remote
control pass-through, System audio control,
System standby
Power
• Ambient temperature: 5°C to 35°C
• Mains power: 220 - 240 V, 50/60 Hz
• Power consumption (typical): 104 W
• Standby power consumption: < 0.15 W
Dimensions
•Setdimensions(Wx H x D): 958 x 580 x 39 mm
• Set dimensions with stand (W x H x D):
958 x 628 x 220 mm
• Weight incl. Packaging: 24.0 kg
• Product weight: 15 kg
• Product weight (+stand): 18 kg
•Boxdimensions(Wx H x D):
1200 x 698 x 200 mm
• Colour cabinet: High gloss black deco front with
black cabinet
• VESA wall mount compatible: 300 x 300 mm
Accessories
• Included accessories: Tabletop stand, Power cord,
Quick start guide, Warranty certificate, Remote
Control, Batteries for remote control, Safety/legal
instructions
• Optional accessories: Smart level wallmount
SQM6175, DVB-S module PFS0001*
•
* DVB-T MPEG4 only for: France, Spain, Denmark, Norway, Finland,
Sweden. DVB-C MPEG4 only for selected providers: Denmark,
Norway, Finland, Sweden. The most up-to-date information is
available on the type plate of the TV, or via www.philips.com/support
under the specific type number.
* Net TV, service offering is dependent on country and subject to
terms of use.
* Optional Philips DVB-S module required (part no. PFS0001, only
available in Germany, Austria and Switzerland)
VGA
SERVICE UART
NETWORK
AUDIO
OUT
SPDIF
OUT
AUDIO IN
LEFT/RIGHT
HDMI 1 / DVI
HDMI 2 / DVI
HDMI 3 / DVI
VGA
3
2 1
SIDE
