Philips Cineous 32PF9731D User manual

Turn up your viewing experience
with Pixel Plus 3 HD and Ambilight
Enjoy the ultimate viewing experience of this Philips Cineos Flat TV with Pixel Plus 3 HD,
Ambilight 2 Channel and Clear LCD technology. The Digital Media Reader gives you full
access to multimedia content.
Immersive viewing experience
• High-definition LCD WXGA display, 1366 x 768p
• Integrated Digital Tuner for DVB-T reception
• HD ready for the highest quality display of HDTV signals
• Pixel Plus 3 HD for most vivid and sharp HDTV images
• Clear LCD with 3ms response for extreme motion sharpness
• 2-channel active Ambilight enhances the viewing experience
True beauty lies in the details
• Matching design swivel stand included
Perfect picture quality from your digital photos
• USB Connector for easy, instant multimedia playing
For advanced performance
• Dual HDMI input for full digital High Definition connection
Philips Cineos
digital widescreen flat TV
with Pixel Plus 3 HD and
Ambilight 2 channel
32"
LCD integrated digital
32PF9731D

32PF9731D/10
Digital widescreen flat TV with Pixel Plus 3 HD and Ambilight 2 channel
32" LCD integrated digital
Specifications
Picture/Display
•Aspect ratio: 16:9
•Brightness: 550 cd/m²
•Dynamic screen contrast: 7000:1
•Response time (typical): (BEW equiv.) 3 ms
•Viewing angle: 176º (H) / 176º (V)
•Diagonal screen size: 32 inch / 80 cm
•Display screen type: LCD WXGA Active Matrix
TFT
•Panel resolution: 1366 x 768p
•Picture enhancement: Pixel Plus 3 HD, 3/2 - 2/2
motion pull down, 3D Combfilter, Active Control
+ Light sensor, Clear LCD, Digital Natural
Motion, Dynamic contrast enhancement, Jagged
Line Suppression, Progressive Scan, Pulse Killer
Chip, Widescreen Plus
•Screen enhancement: Anti-Reflection coated
screen
Ambilight
•Ambilight Features: Ambilight 2 Channel, Auto
adaptive to video content, Efficient low energy
lamp
•Colour Settings: Full Multi Colour
•Dimming Function: Manual and via Light Sensor
Supported Display Resolution
Sound
•Output power (RMS): 2x15W
•Sound Enhancement: Digital Signal Processing,
Dynamic Bass Enhancement, Graphic Equaliser
•Sound System: Virtual Dolby Digital
Loudspeakers
•Built-in speakers: 4
•Loudspeaker types: Integrated woofers with
wOOx, Dome tweeter
Multimedia Applications
•Digital Content Management: Digital Media
Reader
•Multimedia connections: USB (streaming video
capable)
•Playback Formats: MP3, Slideshow files (.alb),
JPEG Still pictures, DivX 3.11, DivX 5, MPEG1,
MPEG2, MPEG4, XviD
Tuner/Reception/Transmission
•Aerial Input: 75 ohm coaxial (IEC75)
•TV system: DVB COFDM 2K/8K, PAL, SECAM
•Video Playback: NTSC, SECAM, PAL
•DVB: DVB Terrestrial *
•Tuner bands: Hyperband, S-Channel, UHF, VHF
Connectivity
•Ext 1 Scart: Audio L/R, CVBS in/out, RGB
•Ext 2 Scart: Audio L/R, CVBS in/out, RGB, Y/C
•Ext 3: YPbPr
•Ext 4: HDMI
•Ext 5: HDMI
•Ext 6: VGA PC-in, Audio L/R in
•Front / Side connections: Audio L/R in, CVBS in,
Headphone out, S-video in, USB
•Other connections: Analogue audio Left/Right
out, PC-in VGA + Audio L/R in, S/PDIF in
(coaxial), S/PDIF out (coaxial), Common Interface
Convenience
•Child Protection: Child Lock+Parental Control
•Clock: Smart Clock
•Ease of Installation: Auto Program Naming,
Automatic Channel Install(ACI), Automatic
Tuning System (ATS), Autostore, PLL Digital
Tuning, Plug & Play
•Ease of Use: Auto Volume Leveller (AVL), Delta
Volume per preset, Graphical User Interface, On
Screen Display, Program List, Side Control
•Electronic Program Guide: Now + Next EPG
•Picture in Picture: Text dual screen
•Remote Control: Amp, DVD, Sat, STB (Set-Top
Box), VCR, Multi-functional
•Remote control type: RC4401
•Screen Format Adjustments: 4:3, 6 Widescreen
Modes, Auto Format, Movie expand 14:9, Movie
expand 16:9, Subtitle and Heading Shift, Super
Zoom, Widescreen
•Teletext: 1200 page Hypertext
•Teletext enhancements: Habit Watch, Program
information Line
•VESA Mount: Vesa compliant
Accessories
•Included Accessories: Tabletop swivel stand, RF
antenna cable
•Optional accessories: Floor stand
Dimensions
•Set dimensions (W x H x D):
869 x 625 x 114 mm
•Set dimensions with stand (H x D): 685 x 230 mm
•Weight incl. Packaging: 32 kg
•Product weight: 20.4 kg
•Box dimensions (W x H x D):
1052 x 878 x 263 mm
•Colour cabinet: High Gloss Black
•VESA wall mount compatible: 600 x 200 mm
Power
•Ambient temperature: 5 °C to 40 °C
•Mains power: AC 220 - 240 V +/- 10%
•Power consumption: 163 W
•Standby power consumption: 0.8 W
•
•Computer formats
Resolution Refresh rate
640 x 480 60Hz
800 x 600 60Hz
1024 x 768 60Hz
•Video Formats
Resolution Refresh rate
640 x 480i 1Fh
640 x 480p 2Fh
720 x 576i 1Fh
720 x 576p 2Fh
1280 x 720p 3Fh
1920 x 1080i 2Fh

32PF9731D/10
Digital widescreen flat TV with Pixel Plus 3 HD and Ambilight 2 channel
32" LCD integrated digital
Product highlights
Issue date 2009-01-22
Version: 5.0.16
12 NC: 8670 000 23306
EAN: 87 10895 92047 6
© 2009 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
LCD WXGA display, 1366 x 768p
This WXGA display with state-of-the-art LCD screen
technology gives you widescreen HD resolution of 1366
x 768p pixels. It produces brilliant flicker-free progressive
scan pictures with optimum brightness and superb
colours. This vibrant and sharp image will provide you
with an enhanced viewing experience.
Integrated Digital DVB-T tuner
The integrated DVB-T tuner lets you receive Digital
Terrestrial TV to watch or record. This means you do not
need an additional set top box and also the additional
cables.
HD Ready
Enjoy the exceptional picture quality of a true High
Definition TV signal and be fully prepared for HD sources
like HDTV broadcast, Blu-ray DVD or HD-DVD. HD
ready is a protected label that offers picture quality
beyond that of progressive scan. It conforms to strict
standards laid out by EICTA to offer a HD screen that
displays the benefits of resolution and picture quality of a
High Defin ition TV s ignal. It has a unive rsal connection for
both analogue YPbPr and uncompressed Digital
connection of DVI or HDMI, supporting HDCP. It can
display 720p and 1080i signals at 50 and 60Hz.
Pixel Plus 3 HD
Pixel Plus 3 HD offers the unique combination of ultimate
sharpness, natural detail, vivid colours and smooth
natural motion on all qualities of HD, standard TV signals
and multimedia content for high definition displays. Each
pixel of the incoming picture is enhanced to better match
the surrounding pixels, resulting in a more natural
picture. Artefacts and noise in all sources, from
multimedia to standard TV and also in highly compressed
HD, are detected and reduced ensuring that the picture
is clean and razor sharp.
Clear LCD with 3 ms response
Clear LCD creates extreme motion sharpness for clear
and vibrant images even with fast on-screen motion. The
high refresh rates of the scanning backlight technology
increases the sharpness of motion reproduction down to
an effective response time of 3 milliseconds (measured in
Perceived Blur-Edge-Width; BEW). On top it creates a
higher dynamic contrast and an increased viewing angle.
The unique Philips technology brings motion sharpness of
LCD displays to an unprecedented level, better than any
other Flat display technology.
Ambilight 2 channel
Ambilight makes an impressive contribution to the overall
viewing experience by producing ambient light to
complement the colours and light intensity of the on-
screen image. It adds a new dimension to the viewing
experience, completely immersing you into the content
you are watching. It creates ambience, stimulates more
relaxed viewing and improves perceived picture detail,
contrast and colour. Ambilight instantly adapts its colour
and light intensity according to the changing content on
the screen.
Bypacked swivel stand
For maximum freedom of placement, this high-quality
stand is designed specifically for this TV and allows easy
placement of your Flat TV without drilling holes in the
wall. Enjoy the best viewing angle with the convenience of
the 40 degrees of swivel (20 degrees each side). Invisible
cable management is included in the back. This stand fits
seamlessly on the matching accessory floorstand.
* DVB-T, supported in selected countries only
