A
Philips 8000 series
Smart LED TV with
Ambilight Spectra 2 and
Perfect Pixel HD
102 cm (40")
Full HD 3D Max DVB-T2/C
40PFL8606T
Refined living, pure performance
with Ambilight and Smart TV
The thin 8000 series LED TV combines the award-winning Perfect Pixel HD engine,
Ambilight and 3D Max for a truly immersive movie experience. Share and enrich this
experience as Smart TV puts your living room in the centre of the online world.
Intensify your viewing experience
• Ambilight Spectra 2 sided intensifies the experience
• 3D Max for a truly immersive Full HD 3D experience
Breathtaking perfect pictures and Sound
• Full HDTV and Perfect Pixel HD Engine for unrivalled clarity
• Brilliant LED images with incredible contrast
• 800 Hz Perfect Motion Rate (PMR) for superb motion sharpness
• 28 W SoundStage for dynamic powerful sound in an ultra slim TV
Enjoy the online world with Smart TV
• A wealth of online apps, videos to rent and catch-up TV
• Control the TV with your smart phone, tablet or keyboard
• Enjoy photos, music and movies from any device on your TV
• Find, schedule, record and pause TV
• Integrated Wi-Fi to use Net TV apps and SimplyShare wireless

40PFL8606T/12
Highlights
Smart LED TV with Ambilight Spectra 2 and Perfect Pixel HD
102 cm (40") Full HD 3D Max DVB-T2/C
Ambilight Spectra 2
Add a new dimension to your viewing
experience with Ambilight Spectra 2. This
patented Philips technology enlarges the
screen by projecting a glow of light, on the 2
sides of the TV, from the back of the screen
onto the surrounding wall. Ambilight
automatically adjusts the colour and brightness
of the light to match the picture, creating an
immersive viewing experience. The wall-
adaptive function ensures that the colour of
the light always matches the picture, no matter
what the colour of your wall is. Get the bigger
picture with Ambilight.
3D Max
Be enthralled by 3D movies in your own living
room with the 3D Max. The combination of
the fast display and Active shutter glasses bring
real life depth in Full HD resolution. Now all
2D content can be experienced in 3D and you
can even control the depth of the 3D to your
liking. Just add the 3D Max glasses PTA516 and
a 3D compatible BluRay player to make your
TV ready for the 3D Max experience.
Perfect Pixel HD
Experience unrivalled sharpness and clarity
with Perfect Pixel HD Engine. Each pixel of the
picture is enhanced to better match the
surrounding pixels, for a more natural picture.
The result is a unique combination of
sharpness, natural detail, vivid colours,
superior contrast and smooth natural motion
whatever you are watching. Clean and razor
sharp images result from artefact and noise
detection and reduction in all content sources
- from multimedia to standard TV. The Full HD
screen with 1920 x 1080 pixels produces
brilliant flicker-free progressive scan pictures
with superb brightness.
Full HD LED TV
The most advanced LED lighting technology in
this Full HD LED TV combines an eye-catching
minimalistic design with stunning image quality
as well as the lowest power consumption in its
category. On top of that, LED lighting
technology does not contain any hazardous
materials. Thus, with LED backlights you can
enjoy low power consumption, high
brightness, incredible contrast, sharpness and
vibrant colours.
800 Hz Perfect Motion Rate
800 Hz Perfect Motion Rate (PMR) creates
extreme motion sharpness for even clearer
and more vibrant images in fast action movies.
The new Philips PMR standard shows the
combined visible effect of the fastest panel
refresh rate, Perfect Natural Motion and
unique processing formula, for unprecedented
motion sharpness.
28 W RMS SoundStage
Philips SoundStage with 28 W RMS output
power has far more dynamism and power than
anything heard on LCD TVs today. Now, we
can combine an ultra-thin design with powerful
TV sound. The TV stand houses an advanced
speaker system, which combines deep, warm
bass with excellent clarity. And you can also
enjoy the excellent sound experience in the
wall-mount position.
Smart TV
Smart TV for an easier and wireless TV
experience in four areas. Net TV lets you
enjoy a wealth of online apps on your TV:
rent films, watch catch-up TV and enjoy
social media. Stay in Control: change
channels or enter text using your
Smartphone or tablet. Use SimplyShare to
enjoy photos, music and video from your
computer, phone and tablet on your TV.
Watch your favourite Programmes
whenever you want: our programme
guide helps you with Smart USB
recording.
A
Energy Class A
For many years Philips has pro-actively
been working on the reduction of both
on-mode and standby power
consumption of its televisions and as a
result most Philips televisions have
achieved green EU energy labels in 2010.
The greener the label, the lower the on-
mode power consumption and the lower
your energy bill and friendlier to the
environment.
Full HD
LED
Perfect Motion Rate

Issue date 2011-10-20
Version: 7.8.13
12 NC: 8670 000 74661
EAN: 87 12581 59531 9
© 2011 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
40PFL8606T/12
Specifications
Smart LED TV with Ambilight Spectra 2 and Perfect Pixel HD
102 cm (40") Full HD 3D Max DVB-T2/C
Ambilight
• Ambilight Version: 2 sided
• Ambilight Features: Wall colour adaptive, Lounge
light mode
Picture/Display
• Display: edge LED backlight
• Diagonal screen size: 40 inch / 102 cm
• Panel resolution: 1920 x 1080p
• 3D: 3D Max*, 2D to 3D conversion, 3D Depth
adjustment, 2 Player Full Screen Gaming*
• Aspect ratio: 16:9
• Brightness: 450 cd/m²
• Peak Luminance ratio: 65 %
• Dynamic screen contrast: 500,000:1
• Response time (typical): 1 ms
• Picture enhancement: Perfect Pixel HD Engine,
Perfect Natural Motion, ISF image calibration, Active
Control + Light sensor, Wide Colour Gamut
display, Super Resolution, Perfect Colours, Perfect
Contrast, Scanning backlight, 800 Hz Perfect Motion
Rate
Sound
• Output power (RMS): 28 W (2 x 14 W)
• Sound Enhancement: Auto Volume Leveller, Clear
Sound, Incredible Surround, Treble and Bass
Control
• Loudspeaker types: Soundstage stand enclosure
Smart TV Applications
• Control: MyRemote app (iOS & Android), USB
Keyboard and Mouse support
• SimplyShare: DLNA media browser, USB media
browser, Wi-Fi MediaConnect*
• Net TV: Catch-up TV, Online Video shops, Open
Internet browser, Online apps
• Programme: Pause TV, USB recording
Connectivity
• Number of HDMI connections: 4
• HDMI features: 3D, Audio Return Channel
•EasyLink (HDMI-CEC): Remote control pass-
through, System audio control, System standby, Plug
and play add to Homescreen, Auto subtitle shift
(Philips), Pixel Plus link (Philips), One touch play
• Number of components in (YPbPr): 1
• Number of scarts (RGB/CVBS): 1
• Number of USBs: 2
• Other connections: Antenna IEC75, Common
Interface Plus (CI+), Ethernet-LAN RJ-45, SD card
slot (Videostore), Digital audio out (optical), PC-in
VGA + Audio L/R in, Headphone out, Service
connector
• Wireless connections: Wi-Fi Certified
Multimedia Applications
• Video Playback Formats: Codec support:,
Containers: AVI, MKV, H264/MPEG-4 AVC, MPEG-
1, MPEG-2, MPEG-4, WMV9/VC1
• Music Playback Formats: AAC, MP3, WMA (v2 up to
v9.2)
• Picture Playback Formats: JPEG
• Net TV: Included
Supported Display Resolution
• Computer inputs: up to 1920 x 1080 @ 60 Hz
• Video inputs: 24, 25, 30, 50, 60 Hz, up to 1920 x
1080p
Convenience
• PC network link: DLNA 1.5 certified
• Electronic Programme Guide: 8-day Electronic
Programme Guide*
• Ease of Installation: Auto detect Philips devices,
Channel installation wizard, Device connection
wizard, Network installation wizard, Settings
assistant wizard, 2-in-1 Wallmount Stand
• Ease of Use: One-stop Home button, On-screen
User manual, Touch control buttons
• Screen Format Adjustments: Autofill, Autozoom,
Movie expand 16:9, Super Zoom, Unscaled,
Widescreen
• Signal strength indication
• Teletext: 1200-page Hypertext
• Firmware upgradeable: Firmware auto upgrade
wizard, Firmware upgradeable via USB, Online
firmware upgrade
Tuner/Reception/Transmission
• Digital TV: DVB-C MPEG2*, DVB-C MPEG4*, DVB-
T MPEG2*, DVB-T MPEG4*, DVB-T2, Freeview HD
• Video Playback: NTSC, PAL, SECAM
Power
• Mains power: AC 220 - 240 V 50/60 Hz
• Ambient temperature: 5°C to 35°C
• Energy Label Class: A
• EU Energy Label power: 66 W
• Annual energy consumption: 91 kW·h
• Standby power consumption: < 0.1 W
• Power Saving Features: 0 Watt Power-off switch,
Auto switch-off timer, Eco mode, Eco settings menu,
Light sensor, Picture mute (for radio)
• Presence of lead: Yes*
• Off mode power consumption: < 0.01 W
Dimensions
• Set dimensions (W x H x D): 950 x 582 x 32 mm
• Set dimensions with stand (W x H x D):
950 x 636 x 244 mm
• Product weight: 17 kg
• Product weight (+stand): 20 kg
• Compatible wall mount: adjustable 300 x 200 mm
Accessories
• Included accessories: Power cord, Remote Control,
2 x AAA Batteries, Tabletop swivel stand, Quick
start guide, Legal and safety brochure, Wall
mounting bracket, Smart TV Quick Guide, Wi-Fi
MediaConnect voucher
• Optional accessories: 3DMax Glasses PTA516
(Active)
•
* 3D TV requires Accessory PTA516 (Active shutter glasses), a 3D
compatible source device and 3D source material.
* 3D Max two player gaming is only supported by 3D Max TVs with
the following set types: 58pfl9956, 46pfl9706, 37pfl9606, 52pfl9606,
46pfl8686, 40pfl8606, 46pfl8606
* Net TV: Visit www.philips.com/smarttv to discover the services
available in your country.
* Wi-Fi Media connect: The playback of video can be affected by your
PC speed and Wi-Fi bandwidth. For minimum and recommended
system requirements go to www.philips.com/wifimediaconnect.
Displays content with a delay of some seconds. Small differences
between image and sound can occur.
* Parents should monitor their children during 3D viewing and ensure
they do not experience any discomfort as mentioned above.
Watching 3D is not recommended for children under 6 years of age
as their visual system is not fully developed yet.
* The TV supports DVB reception for 'Free to air' broadcast. Specific
DVB operators may not be supported. An up to date list can be
found in the FAQ section of the Philips support website. For some
operators Conditional Access and subscription are required.
Contact your operator for more information.
* 8 days EPG, service not available in all countries
* USB pause and record requires an empty USB Hard Disk of at least
32 GB, although 250 GB is recommended (not supplied). This
function is only available for DVB-T C and S channels, not on
analogue broadcast or external inputs.
* USB recording is only possible for digital channels covered by the TV
IP bases Electronic Programme Guide (country and channel
restrictions may apply); recordings may be limited by broadcast copy
protection (CI+). An Internet connection is required.
* Annual energy consumption is calculated using the typical power
consumption of 4 hours per day, 365 days per year.
* This television contains lead only in certain parts or components
where no technology alternatives exist in accordance with existing
exemption clauses under the RoHS Directive.
* ISF and IMAGING SCIENCE FOUNDATION are Trade Marks
owned by Isf Research Labs Llc Limited Liability Company
* For 2D games only.
* Ensure that the game console is connected to the HDMI connector
of the TV.
Connections
Side Back
HDMI SideUSB USB
COMMON INTERFACE
SD CARD
HDMI 1
ARC
HDMI 2 HDMI 3 SCART NETWORK
AUDIO OUT ANTENNA
VGA AUDIO IN
DVI / VGAOPTICAL
Y Pb Pr - L R
