Philips DCB2077 User manual

Philips
Micro music system
• Dock for iPod/iPhone/iPad
•DAB+
DCB2077
Sound that fits your home
Obsessed with sound
Dock and listen to your iPod/iPhone/iPad, or turn on the radio and get crystal-clear
DAB+. This Philips DCB2070/10 micro sound system sounds sensational, and offers an
added bonus - it looks great in any home.
Enrich your sound experience
• Bass Reflex Speaker System delivers a powerful, deeper bass
• Digital Sound Control for optimized music style settings
• Dynamic Bass Boost for deep and dramatic sound
• 20W RMS maximum output power
Enjoy your music from multiple sources
• Play and charge your iPod/iPhone/iPad
• DAB and FM compatible for a complete radio experience
• Play MP3/WMA-CD, CD and CD-RW
• USB Direct for MP3/WMA music playback
• MP3 Link for portable music playback
• Radio Data System for station information and data services
Design that blends into your interior
• Wall-mountable option for flexible placement
• Motorized sliding front door adding style and elegance

DCB2077/10
Highlights
Micro music system
Dock for iPod/iPhone/iPad DAB+
Bass Reflex Speaker System
Bass Reflex Speaker System delivers a deep
bass experience from a compact loudspeaker
box system. It differs from a conventional
loudspeaker box system in the addition of a
bass pipe that is acoustically aligned to the
woofer to optimize the low frequency roll-off
of the system. The result is deeper controlled
bass and lower distortion. The system works
by resonating the air mass in the bass pipe to
vibrate like a conventional woofer. Combined
with the response of the woofer, the system
extends the overall low frequency sounds to
create a whole new dimension of deep bass.
Digital Sound Control
Digital Sound Control offers you a choice of
pre-set Jazz, Rock, Pop and Classic controls
you can use to optimise the frequency ranges
for different musical styles. Each mode uses
graphic equalizing technology to automatically
adjust the sound balance and enhance the most
important sound frequencies in your chosen
music style. Ultimately, Digital Sound Control
makes it easy for you get the most out of your
music by precisely adjusting the sound balance
to match the type of music you are playing.
Dynamic Bass Boost
Dynamic Bass Boost maximizes your music
enjoyment by emphasizing the bass content of
the music throughout the range of volume
settings - from low to high – at the touch of a
button! Bottom-end bass frequencies usually
get lost when the volume is set at a low level.
To counteract this, Dynamic Bass Boost can be
switched on to boost bass levels, so you can
enjoy consistent sound even when you turn
down the volume.
Play & charge iPod/iPhone/iPad
Enjoy your favorite MP3 music while charging
your iPod/iPhone/iPad! The dock lets you
connect your portable device directly to the
Philips system so you can listen to your
favorite music in superb sound. It also charges
your iPod/iPhone/iPad while it plays so you can
enjoy your music and not have to worry about
your portable player battery running out. The
system automatically charges your portable
device while it is docked.
DAB and FM compatible
DAB (Digital Audio Broadcasting) digital radio
is, on top of FM analog transmission, a new way
of broadcasting radio via a network of
terrestrial transmitters. It provides listeners
with more choices and information delivered
in clear, crackle-free sound quality. The
technology allows the receiver to lock on to
the strongest signal it can be find. With DAB
digital stations there are no frequencies to
remember, and sets are tuned by station name,
so there is no returning on the move.
USB Direct
With the USB Direct mode, simply plug in your
USB device to the USB port on your Philips
device and your digital music will be played
directly from the Philips device.

Issue date 2013-05-24
Version: 3.1.3
12 NC: 8670 001 00466
EAN: 87 12581 67867 8
© 2013 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
DCB2077/10
Specifications
Micro music system
Dock for iPod/iPhone/iPad DAB+
Sound
• Output power: 2 x 10 W RMS
• Sound enhancement: digital sound control,
Dynamic Bass Boost
• Volume control: up/down
Loudspeakers
• No. of built-in speakers: 2
• Speaker drivers: 2.75" woofer
• Speaker types: bass reflex speaker system
Audio playback
• Disc playback modes: fast forward/backward, next/
previous track search, repeat/shuffle/program
• Playback media: CD, CD-R/RW, MP3-CD, USB
flash drive, WMA-CD
• USB Direct playback modes: fast backward/fast
forward, play/pause, previous/next, repeat, shuffle,
stop
• Docking playback modes: fast forward and
backward, menu, up and down, next and previous
track, play and pause
• Others: ID3-tag support
Tuner/Reception/Transmission
• Tuner bands: FM mono, FM stereo
• Station presets: 20
• RDS: program type, radio text, RDS clock set,
station name
• Tuner enhancement: auto digital tuning, auto scan,
Easy set (plug & play)
• DAB/DAB+: Info display, Menu, Smart scan
Connectivity
• Headphone: 3.5 mm
• MP3 Link: 3.5mm stereo line in
• USB: USB host
Convenience
• Alarms: CD Alarm, Radio Alarm, USB alarm, iPod
Alarm
• Clock: On main display, sleep timer
• Charging device: iPad, iPhone, iPod
• Display type: LCD display
• Loader type: front, motorised
Accessories
• Included accessories: 3.5mm stereo line in cable,
AC-DC Adapter, DAB antenna, Quick Use Guide,
Screws for wall mounting x2
• Remote control: 31-key remote
• User Manual: English, German, French, Dankish,
Norwegian, Italian
Dimensions
•Setdimensions(Wx D): 400 x 98 mm
• Set height (with stand): 235 mm
• Packaging width: 456 mm
• Packaging height: 251 mm
• Packaging depth: 197 mm
•Grossweight:4.2kg
• Net weight: 3.3 kg
Power
• Power supply: 110-240V, 50/60 Hz
iPod compatibility
• Compatible with: iPod nano 7th generation, iPod
touch 5th generation
iPhone compatibility
• Compatible with: iPhone 5
iPad compatibility
• Compatible with: iPad mini
•
