Multimedia Base
This Multimedia Base can be used for following Philips Monitors:
105S2x,105B2x,107E4x,107T4x,107B4x,107P4x,109S4x and 109B4x
.Powerful 3W Stereo Sound output
.Front firing sound for clear voice reproduction and direct sound
.Bass Boost for extra bass enhancement
.Headphone connector for personal listening
.Microphone connector for recording and videoconferencing
.AC adapter included
Multimedia base
replaces normal base
Optional
USB HUB
PCUH411
6G3B11
6G3B11

Technical Specifications
All data subject to change without notice
Release date: May 2002
www.philips.com
All trademark acknowledged.
Copyright ©2002 Philips Electronics N.V.
Multimedia Base
Compatibility
The Multimedia base is compatible with the following monitor:
• 105S2x
• 105B2x
• 107E4x
• 107T4x
• 107B4x
• 107P4x
• 109S4x
• 109B4x
Amplifier
• RMS power 3W StereoAudio (1.5W/ channel,
RMSx2,140 Hz-20 kHz, 4 ohms,
1%THD)
• Input signal level 340 mV RMS
• Bass boost
Speakers
• Unit diameter 2 inches
• Impedance 4 ohms
• Frequency Response 140 Hz - 20 kHz
Option
USB Hub PCUH411 clip on option
Adapter
• Input (6G3B11/00) 207~253VAC, 50 Hz
(6G3B11/74) 108~132VAC, 60 Hz
• Output 9VDC,600 mA
Regulatory approvals (version dependent)
•UL
• CSA
•CE
Physical specification
• Dim.(excl.swivel)(W x H x D) 239 mm x 54 mm x 208 mm
• Dim.(excl.swivel)(W x H x D) 9.4" x 2.1" x 8.2"
• Additional height for monitor 28 mm / 1.1"
(Multimedia Base-Normal Base)
• Weight 0.7 kg (0.85 kg including swivel)
• Additional weight for monitor 0.5 kg
(Multimedia Base-Normal Base)
• Power consumption 5 watts
Connections and cables
• Headphone connection 3.5 mm jack
• Microphone input 3.5 mm jack
• Microphone output 3.5 mm jack
• Audio cable 1.8 M,3.5 mm jack to 3.5 mm jack
