Philips 109S User manual

19" (18" VIS) Color Monitor
• Larger image in a compact size. Get 30% more viewable screen area
than with a typical 17" monitor for about the same desktop space
• Superior image quality that’s easy on the eyes. Expect crisp
text and realistic color for all of your word processing, spreadsheet, graphics, and
Internet applications. Work comfortably through the day, knowing that the 109S
reduces eye fatigue with our flicker-free display and high refresh rates
• Manage your screen with OSD. You can make quick and easy
onscreen adjustments like picture rotation, geometric symmetry, and screen sizing to
meet your individual needs
• Simple plug-and-play support. Your monitor is automatically
detected to save time and eliminate the aggravation of setup
• A monitor you can rely on.
A 60,000 hour mean-time-between-failure
rating makes it one of the most reliable
monitors on the market, backed by
Philips F1RST CHOICE Program,
with an exceptional 3 years
parts and labor warranty
with 1 year exchange to
protect your investment
Standard Series Monitor
109S

CRT
Size and Deflection 19"/48 cm, 90°
VIS 18.0"
Horizontal Pitch 0.22 mm
Dot Pitch 0.26 mm
Tube Type Flat Square
High Contrast
Invar Shadow Mask
Screen Coating AGAS
46% or 49% Light Transmission
Phosphor P22
Recommended Display Area 14.0" x 10.4"/
355 x 265 mm
Maximum Display Area 14.4" x 10.8"/
365 x 273.5 mm
SCANNING
Horizontal Frequency 30 - 95kHz
Vertical Frequency 50 - 160Hz
VIDEO
Video Dot Rate 203MHz
Input Impedance:
- Video 75Ω
- Sync 2.2 kΩ
Input Signal Levels: .7Vp-p or 1.0Vp-p
- Sync Input Signal Separate Sync
Composite Sync
DISPLAY AND PERFORMANCE
PARAMETERS
White Color Temperature and Chromaticity
CIE Coordinates:
at 9300˚K: x = 0.281
y = 0.311
at 6500˚K: x = 0.313
y = 0.329
RESOLUTION AND PRESET MODES
Maximum Resolution 1600 x 1200 @ 75Hz
10 User Definable Modes
10 Factory Preset Modes:
Resolution Mode H. Freq. V. Freq. Standard
(kHz) (Hz)
640 x 400 31.5 70 VGA
640 x 480 31.5 60 VGA
640 x 480 43.3 85 VESA/85
800 x 600 46.9 75 SVGA®
800x 600 53.7 85 VESA/85
1024 x 768 60.0 75 XGA
1024 x 768 68.7 85 VESA®/85
1280 x 1024 80.0 75 SXGA
1280 x 1024 91.0 85 VESA/85
1600 x 1200 93.8 75 UXGA
PLUG-AND-PLAY COMPATIBILITY
Display Data Channel DDCI/2B (VESA)
POWER MANAGEMENT
Complies with EPA Energy Star and
NUTEX Specifications
Philips 109S consumes less than
5 Watts in Power Off mode
REGULATORY APPROVALS
UL
CSA
FCC-B
CE
SEMKO
TUV/GS
TUV-ERGO
DHHS
LOW-EMISSION CHARACTERISTICS
Complies with MPR-II Specifications
CONTROLS AND CONNECTIONS
Front:
- Power On/Off
- Brightness
- Contrast
- OSD+
- OSD-
- OSD Menu
Rear:
- Power Input Socket
- 15-Pin D-Sub Input Socket
Cables:
- Detachable Power Cord
- Fixed D-Sub Interface Cable
- Switchless Mac Adaptor
OSD Menu Structure:
Size & Position:
- H Size
- H Position
- V Size
- V Position
Geometry:
- Rotation
- Trapezoid
- Parallelogram
- Pincushion
- Unbalanced Pincushion Correction
Color:
- 9300˚K Factory Preset
- 6500˚K Factory Preset
- User Preset 1, Red, Green, Blue Gain
- User Preset 2, Red, Green, Blue Gain
Advanced Controls:
- OSD Position
- Language
- H Moiré
- V Moiré
Others:
- Monitor Status
- Recall (All Levels)
- Degauss
- Exit OSD
- Reset
Display Language:
- Multilingual, User-selectable
PHYSICAL SPECIFICATIONS
Unit Dimensions 17.7"W x 18.2"H x 18.1"D/
452 x 462 x 460 mm
(including pedestal)
Unit Weight 47.3 lbs./21.5 kg.
Carton Dimensions 26.0"W x 24.2"H x 22.3"D/
660 x 614 x 565 mm
Carton Weight 55.0 lbs./25 kg.
UPC Code 0 37849 88487 4
Power Supply 90 - 264 Vac, 50/60Hz
Power Consumption 130 Watts Maximum
Operating Temperature 32°F to 104°F/
0°C to 40°C
Relative Humidity 10% to 90%
Storage Temperature -40°F to 140°F/
-40°C to 60°C
Relative Humidity 5% to 95%
MTBF >60,000 Hours
(excluding CRT)
WARRANTY
3 year parts and labor
Carton contains: 109S Color Monitor, VGA Cable,
Switchless Mac Adaptor, Power Cable, Users Manual, and
Warranty Card.
This monitor fulfills all NUTEK requirements regarding power management as
indicated on the TCO 1992 label.
The EPA ENERGY STAR emblem does not represent EPA endorsement of any
product or service. As an ENERGY STAR Partner, Philips has determined that this
product meets the ENERGY STAR guidelines for energy efficiency.
Mac is a registered trademark of Apple Computer, Inc.
VESA is a registered trademark of the Video Electronics Standards Association.
VGA and SVGA are registered trademarks of International Business Machines Corp.
Windows is a registered trademark of Microsoft Corp.
Printed in the U.S.A.
©1999 Philips Consumer Electronics Co.
A Division of Philips Electronics North America Corp.
601707; Produced by Philips Design Atlanta
FOR MORE INFORMATION
Internet Address: http://www.philipsmonitors.com
FAX INFORMATION SYSTEM: [phone]
TECHNICAL SUPPORT:
toll free [phone] (USA)
[phone] (outside USA)
Literature order form: 19C2502E
PRODUCT NUMBER 19C2502E
TECHNICAL SPECIFICATIONS: Standard Series Monitor
109S
