Philips 150S6FB/27 User manual

TABLE OF CONTENTS
Published by BCU Monitors Printed in Suzhou Copyright reserved Subject to modification S Mar .3. 2005
Description Page
Important Safety Notice -------------------------------2
Technical Data --------------------------------------3~5
Front Control & Connections-----------------------6~7
OSD menu tree ----------------------------------------8
Lock/unlock,Burn in -----------------------------------9
Factory Mode -----------------------------------------10
Pixel Defect Policy -------------------------------11~12
Mechanical Instructions-------------------------13~14
Warning Message ------------------------------------ 16
Trouble Shooting --------------------------------17~18
Wiring Dirgram ---------------------------------------19
Block Diagram ----------------------------------------20
Display Adjustments--------------------------------- 15
Description Page
Scaler Schematic Diagram & C.B.A.----------
Smart Manage----- ------------------------ ------- 90
--21~26
Control Schematic Diagram & C.B.A ----------27~28
Power Schematic Diagram & C.B.A ------------29~42
General Product Specification -----------------43~68
Exploded View ---------------------------------------69
Spare Parts List ---------------------------------70~72
Different Parts List ----------------------------- 73~75
Repair Tips --------------------------------------84~85
Safety test requirements ---------------------------86
Repair Flow Chart -------------------------------87~89
DDC Instruction & Data ------------------------ 76~81
Firmware upgrade for CPU -------------------- 82~83
REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES
CAUTION: USE A SEPARATE ISOLATION TRANSFORMER FOR THIS UNIT WHEN SERVICING.
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING ELECTRONIC
EQUIPMENT CONTAINING HIGH VOLTAGES.
SAFETY NOTICE
GB 3138 106 10448
LCD Colour Monitor
«
Service
Service
Service
150S6FB/00
150S6FB/27
150S6FG/00
150S6FG/27
150S6FS/00
Chassis: SH6 S-Line
170S6FB/00
170S6FB/27
170S6FG/00
170S6FG/27
170S6FS/00
170S6FS/78
190S6FB/00
190S6FB/27
190S6FG/00
190S6FG/93
190S6FS/00
190S6FS/27
190S6FS/96

Important Safety Notice
2
FOR PRODUCTS CONTAINING LASER :
Invisible laser radiation when open.
AVOID DIRECT EXPOSURE TO BEAM.
Use of controls or adjustments or
performance of procedures other than
those specified herein may result in
hazardous radiation exposure.
The use of optical instruments with this
product will increase eye hazard.
DANGER-
CAUTION-
CAUTION-
TO ENSURE THE CONTINUED RELIABILITY OF THIS
PRODUCT, USE ONLY ORIGINAL MANUFACTURER'S
REPLACEMENT PARTS, WHICH ARE LISTED WITH
THEIR PART NUMBERS IN THE PARTS LIST SECTION
OF THIS SERVICE MANUAL.
Proper service and repair is important to the safe,
reliable operation of all Philips Consumer Electronics
Company** Equipment. The service procedures
recommended by Philips and described in this service
manual are effective methods of performing service
operations. Some of these service operations require
the use of tools specially designed for the purpose. The
specialtoolsshouldbeusedwhenandas
recommended.
It is important to note that this manual contains
various CAUTIONS and NOTICES which should be
carefully read in order to minimize the risk of personal
injury to service personnel. The possibility exists that
improper service methods may damage the equipment.
It is also important to understand that these
CAUTIONS and NOTICES ARE NOT EXHAUSTIVE.
Philips could not possibly know, evaluate and advise
the service trade of all conceivable ways in which
service might be done or of the possible hazardous
consequences of each way. Consequently, Philips has
not undertaken any such broad evaluation. Accordingly,
aservicerwhousesaserviceprocedureortoolwhich
is not recommended by Philips must first satisfy
himself thoroughly that neither his safety nor the safe
operationoftheequipmentwillbejeopardizedbythe
service method selected.
* *Hereafter throughout this manual, Philips Consumer
Electronics Company will be referred to as Philips.
WARNING
Critical components having special safety
characteristics are identified with a by the Ref. No.
in the parts list and enclosed within a broken line*
(where several critical components are grouped in one
area)alongwiththesafetysymbol onthe
schematics or exploded views.
Use of substitute replacement parts which do not have
the same specified safety characteristics may create
shock, fire, or other hazards.
Under no circumstances should the original design be
modified or altered without written permission from
Philips. Philips assumes no liability, express or implied,
arising out of any unauthorized modification of design.
Servicer assumes all liability.
*BrokenLine
Take care during handling the LCD module with
Backlight unit
- Must mount the module using mounting holes
arranged in four corners.
-Donotpressonthepanel,edgeoftheframe
strongly or electric shock as this will result in
damage to the screen.
-Donotscratchorpressonthepanelwithanysharp
objects,suchaspencilorpenasthismayresultin
damage to the panel.
- Protect the module from the ESD as it may damage
the electronic circuit (C-MOS).
- Make certain that treatment person s body are
grounded through wrist band.
-Donotleavethemoduleinhightemperatureandin
areasofhighhumidityforalongtime.
-Avoidcontactwithwaterasitmayashortcircuit
within the module.
-Ifthesurfaceofpanelbecomedirty,pleasewipeit
offwithasoftmaterial.(Cleaningwithadirtyor
rough cloth may damage the panel.)

3
Technical Data - 170S6
LCD PANEL
Type TFT LCD
SCANNING
VIDEO
Input impedance
Optical characteristics
Resolution & Preset Modes
50 user definable modes
Screen size :17" / 43.2 cm diagonal
Pixel Pitch :0.264 x 0.264 mm
:1280 x 1024 pixels
:R.G.B. vertical stripe
:Anti-glare polarizer, hard coated
Effective viewing area :337.9 x 270.3 mm
Display Colors :16.2 M colors
Vertical refresh rate :56 Hz-76 Hz
Horizontal Frequency :30k Hz-83 kHz
Video dot rate :140 Mhz
Video : 750 ohm
Sync :2.2k ohm
Input signal levels :700m Vpp
Separate sync
Sync input signal Composite sync
Sync on green
Sync polarities Positive and negative
Video interface D-Sub (analog)
Contrast ratio 500:1 (typ.)
Brightness 250 cd/m2 (typ.)
Peak contrast angle 6 o'clock
x: 0.283 y: 0.297 (at 9300 K)
White Chromaticity x: 0.313 y: 0.329 (at 6500 K)
x: 0.313 y: 0.329 (at sRGB)
Upper >60 (typ.)
Lower >80 (typ.)
Viewing Angle (C/R>5) Left >80 (typ.)
Right >80 (typ.)
Response time :<12 ms (typ.)
Maximum :1280 x 1024 at 75 Hz
Recommended :1280 x 1024 at 60 Hz
15 factory preset modes:
H. freq (kHz) Resolution V. freq (Hz)
31.5 640*350 70
31.5 720*400 70
31.5 640*480 60
35.0 640*480 67
37.5 640*480 75
35.2 800*600 56
37.9 800*600 60
46.9 800*600 75
49.7 832*624 75
48.4 1024*768 60
60.0 1024*768 75
69.0 1152*870 75
71.8 1152*900 76
63.9 1280*1024 60
80.0 1280*1024 75
LCD Panel type
Power Management Definition
VESA Mode Video H-sync V-sync Power Used LED color
Active ON Yes Yes <30W Green
Sleep OFF No No <1W Amber
Switch Off OFF - - <1W Off
R
R
R
Pin Assignment
The 15-pin D-sub connector (male) of the signal cable:
Pin
No. Assignment Pin No. Assignment
1Red video input 9+5V
2Green video
input/SOG 10 Logic ground
3Blue video input 11 Ground
4Sense (GND) 12 Serial data line (SDA)
5Hot Plug Detect 13 H. Sync / H+V
6Red video ground 14 V. Sync (VCLK for
DDC)
7Green video ground 15 Data clock line (SCL)
8Blue video ground
Physical Specifications
Dimension (WxHxD) 375 x 390 x 200 mm (incl. Pedestal)
Weight 4.2 kg
Tilt -5o~25o
Power supply 100 —240 VAC, 60 - 50 Hz
Power consumption 30 W* (typ.)
Temperature 5oCto40
oC (operating)
-20oCto60
oC (storage)
Relative humidity 20%to 80%
System MTBF 50K hours (including CCFL 40K
hours)
Automatic Power Saving
If you have VESA DPMS compliance display card or software installed in
your PC, the monitor can automatically reduce its power consumption
when not in use. If an input from a keyboard, mouse or other input
device is detected, the monitor will 'wake up' automatically. The
following table shows the power consumption and signaling of this
automatic power saving feature: shows thepower consumption and
signaling of this automatic power saving feature:
This monitor is ENERGY STAR compliant. As an ENERGY
STAR Partner, PHILIPS has determined that this product
meets the ENERGY STAR guidelines for energy efficiency
Lead-free Product
Philips eliminated toxic substances like lead from its displays.
Lead-free display helps protect your health and promotes
environmentally sound recovery and disposal of waste from
electrical and electronic equipment.Philips complies with the
European Community stringent RoHS Directive mandating
restrictions on hazardous substances in electrical and electronic
equipment. With Philips, you can be confident that your display
device does not harm the environment.
3
Technical Data - 170S6
LCD PANEL
Type TFT LCD
SCANNING
VIDEO
Input impedance
Optical characteristics
Resolution & Preset Modes
50 user definable modes
Screen size :17" / 43.2 cm diagonal
Pixel Pitch :0.264 x 0.264 mm
:1280 x 1024 pixels
:R.G.B. vertical stripe
:Anti-glare polarizer, hard coated
Effective viewing area :337.9 x 270.3 mm
Display Colors :16.2 M colors
Vertical refresh rate :56 Hz-76 Hz
Horizontal Frequency :30k Hz-83 kHz
Video dot rate :140 Mhz
Video : 750 ohm
Sync :2.2k ohm
Input signal levels :700m Vpp
Separate sync
Sync input signal Composite sync
Sync on green
Sync polarities Positive and negative
Video interface D-Sub (analog)
Contrast ratio 500:1 (typ.)
Brightness 250 cd/m2 (typ.)
Peak contrast angle 6 o'clock
x: 0.283 y: 0.297 (at 9300 K)
White Chromaticity x: 0.313 y: 0.329 (at 6500 K)
x: 0.313 y: 0.329 (at sRGB)
Upper >60 (typ.)
Lower >80 (typ.)
Viewing Angle (C/R>5) Left >80 (typ.)
Right >80 (typ.)
Response time :<12 ms (typ.)
Maximum :1280 x 1024 at 75 Hz
Recommended :1280 x 1024 at 60 Hz
15 factory preset modes:
H. freq (kHz) Resolution V. freq (Hz)
31.5 640*350 70
31.5 720*400 70
31.5 640*480 60
35.0 640*480 67
37.5 640*480 75
35.2 800*600 56
37.9 800*600 60
46.9 800*600 75
49.7 832*624 75
48.4 1024*768 60
60.0 1024*768 75
69.0 1152*870 75
71.8 1152*900 76
63.9 1280*1024 60
80.0 1280*1024 75
LCD Panel type
Power Management Definition
VESA Mode Video H-sync V-sync Power Used LED color
Active ON Yes Yes <30W Green
Sleep OFF No No <1W Amber
Switch Off OFF - - <1W Off
R
R
R
Pin Assignment
The 15-pin D-sub connector (male) of the signal cable:
Physical Specifications
Dimension (WxHxD) 375 x 390 x 200 mm (incl. Pedestal)
Weight 4.2 kg
Tilt -5o~25o
Power supply 100 —240 VAC, 60 - 50 Hz
Power consumption 30 W* (typ.)
Temperature 5oCto40
oC (operating)
-20oCto60
oC (storage)
Relative humidity 20%to 80%
System MTBF 50K hours (including CCFL 40K
hours)
Automatic Power Saving
If you have VESA DPMS compliance display card or software installed in
your PC, the monitor can automatically reduce its power consumption
when not in use. If an input from a keyboard, mouse or other input
device is detected, the monitor will 'wake up' automatically. The
following table shows the power consumption and signaling of this
automatic power saving feature: shows thepower consumption and
signaling of this automatic power saving feature:
This monitor is ENERGY STAR compliant. As an ENERGY
STAR Partner, PHILIPS has determined that this product
meets the ENERGY STAR guidelines for energy efficiency
Lead-free Product
Philips eliminated toxic substances like lead from its displays.
Lead-free display helps protect your health and promotes
environmentally sound recovery and disposal of waste from
electrical and electronic equipment.Philips complies with the
European Community stringent RoHS Directive mandating
restrictions on hazardous substances in electrical and electronic
equipment. With Philips, you can be confident that your display
device does not harm the environment.

4Technical Data - 150S6
LCD PANEL
Type TFT LCD
SCANNING
VIDEO
Input impedance
Optical characteristics
Resolution & Preset Modes
50 user definable modes
Screen size :15" / 38 cm diagonal
Pixel Pitch :0.297 x 0.297 mm
:1024 x 768 pixels
:R.G.B. vertical stripe
:Anti-glare polarizer, hard coated
Effective viewing area :304.1 x 228.1 mm
Display Colors :16.2 M colors
Vertical refresh rate :56 Hz-76 Hz
Horizontal Frequency :30k Hz-63 kHz
Video dot rate :85 Mhz
Video : 75 ohm
Sync : 2ohm
Input signal levels :700m Vpp
Separate sync
Sync input signal Composite sync
Sync on green
Sync polarities Positive and negative
Video interface D-Sub (analog)
Input Frequency XGA -Hsync 48- 61 kHz, Vsync 60 - 76 Hz (N.I.)
SVGA -Hsync 35- 50 kHz, Vsync 56 - 75 Hz (N.I.)
VGA -Hsync 31- 38 kHz, Vsync 60 - 76 Hz (N.I.)
Contrast ratio 450:1 (typ.)
Brightness 250 cd/m2 (typ.)
Peak contrast angle 6 o'clock
x: 0.283 y: 0.297 (at 9300 K)
White Chromaticity x: 0.313 y: 0.329 (at 6500 K)
x: 0.313 y: 0.329 (at sRGB)
Upper >60 (typ.)
Lower >80 (typ.)
Viewing Angle (C/R>5) Left >80 (typ.)
Right >80 (typ.)
Response time :<16 ms (typ.)
Maximum :1024 x 768 at 75 Hz
Recommended :1024 x 768 at 60 Hz
15 factory preset modes:
H. freq (kHz) Resolution V. freq (Hz)
31.469 640*350 70.086
31.469 720*400 70.087
31.469 640*480 59.940
35.000 640*480 67.000
37.861 640*480 72.809
37.500 640*480 75.000
35.156 800*600 56.250
37.879 800*600 60.317
48.077 800*600 72.188
46.875 800*600 75.000
49.700 832*624 75.000
48.363 1024*768 60.004
56.476 1024*768 70.069
60.023 1024*768 75.029
LCD Panel type
Power Management Definition
VESA Mode Video H-sync V-sync Power Used LED color
Active ON Yes Yes <17W Green
Sleep OFF No No <1W Amber
Switch Off OFF - - <1W Off
R
R
R
Pin Assignment
The 15-pin D-sub connector (male) of the signal cable:
Automatic Power Saving
If you have VESA DPMS compliance display card or software installed in
your PC, the monitor can automatically reduce its power consumption
when not in use. If an input from a keyboard, mouse or other input
device is detected, the monitor will 'wake up' automatically. The
following table shows the power consumption and signaling of this
automatic power saving feature: shows thepower consumption and
signaling of this automatic power saving feature:
This monitor is ENERGY STAR compliant. As an ENERGY
STAR Partner, PHILIPS has determined that this product
meets the ENERGY STAR guidelines for energy efficiency
Lead-free Product
Philips eliminated toxic substances like lead from its displays.
Lead-free display helps protect your health and promotes
environmentally sound recovery and disposal of waste from
electrical and electronic equipment.Philips complies with the
European Community stringent RoHS Directive mandating
restrictions on hazardous substances in electrical and electronic
equipment. With Philips, you can be confident that your display
device does not harm the environment.
Pin
No. Assignment Pin No. Assignment
1Red video input 9+5V
2Green video
input/SOG 10 Logic ground
3Blue video input 11 Ground
4Sense (GND) 12 Serial data line (SDA)
5Hot Plug Detect 13 H. Sync / H+V
6Red video ground 14 V. Sync (VCLK for
DDC)
7Green video ground 15 Data clock line (SCL)
8Blue video ground

5
Technical Data - 190S6
LCD PANEL
Type TFT LCD
SCANNING
VIDEO
Input impedance
Optical characteristics
Resolution & Preset Modes
50 user definable modes
Screen size :19" / 48.26 cm diagonal
Pixel Pitch :0.294 x 0.294 mm
:1280 x 1024 pixels
:R.G.B. vertical stripe
:Anti-glare polarizer, hard coated
Effective viewing area :376.32 x 301.06 mm
Display Colors :16.2 M colors
Vertical refresh rate :56 Hz-76 Hz
Horizontal Frequency :30k Hz-83 kHz
Video dot rate :140 Mhz
Video :75 ohm
Sync :2.2k ohm
Input signal levels :0.7 Vpp
Separate sync
Sync input signal Composite sync
Sync on green
Sync polarities Positive and negative
Video interface D-Sub (analog)
Contrast ratio 500:1 (typ.)
Brightness 250 cd/m2 (typ.)
Peak contrast angle 6 o'clock
x: 0.283 y: 0.297 (at 9300 K)
White Chromaticity x: 0.313 y: 0.329 (at 6500 K)
x: 0.313 y: 0.329 (at sRGB)
Upper >80 (typ.)
Lower >80 (typ.)
Viewing Angle (C/R>5) Left >80 (typ.)
Right >80 (typ.)
Response time :<8 ms (typ.)
Maximum :1280 x 1024 at 75 Hz
Recommended :1280 x 1024 at 60 Hz
15 factory preset modes:
H. freq (kHz) Resolution V. freq (Hz)
31.5 640*350 70
31.5 720*400 70
31.5 640*480 60
35.0 640*480 67
37.5 640*480 75
35.2 800*600 56
37.9 800*600 60
46.9 800*600 75
49.7 832*624 75
48.4 1024*768 60
60.0 1024*768 75
69.0 1152*870 75
71.8 1152*900 76
63.9 1280*1024 60
80.0 1280*1024 75
LCD Panel type
Power Management Definition
VESA Mode Video H-sync V-sync Power Used LED color
Active ON Yes Yes <30W Green
Sleep OFF No No <1W Amber
Switch Off OFF - - <1W Off
R
R
R
Pin Assignment
The 15-pin D-sub connector (male) of the signal cable:
Pin
No. Assignment Pin No. Assignment
1Red video input 9+5V
2Green video
input/SOG 10 Logic ground
3Blue video input 11 Ground
4Sense (GND) 12 Serial data line (SDA)
5Hot Plug Detect 13 H. Sync / H+V
6Red video ground 14 V. Sync (VCLK for
DDC)
7Green video ground 15 Data clock line (SCL)
8Blue video ground
Physical Specifications
Dimension (WxHxD) 425 x 419 x235 mm
Weight 5.4 kg
Tilt -5o~25o
Power supply 100 - 240 VAC, 60 - 50 Hz
Power consumption 30 W* (typ.)
Temperature 5oCto40
oC (operating)
-20oCto60
oC (storage)
Relative humidity 20%to 80%
System MTBF 50K hours (including CCFL 40K
hours)
Automatic Power Saving
If you have VESA DPMS compliance display card or software installed in
your PC, the monitor can automatically reduce its power consumption
when not in use. If an input from a keyboard, mouse or other input
device is detected, the monitor will 'wake up' automatically. The
following table shows the power consumption and signaling of this
automatic power saving feature: shows thepower consumption and
signaling of this automatic power saving feature:
This monitor is ENERGY STAR compliant. As an ENERGY
STAR Partner, PHILIPS has determined that this product
meets the ENERGY STAR guidelines for energy efficiency
Lead-free Product
Philips eliminated toxic substances like lead from its displays.
Lead-free display helps protect your health and promotes
environmentally sound recovery and disposal of waste from
electrical and electronic equipment.Philips complies with the
European Community stringent RoHS Directive mandating
restrictions on hazardous substances in electrical and electronic
equipment. With Philips, you can be confident that your display
device does not harm the environment.

Front Control & Connections
6
Front Control
Back View
UP andDOWNbuttonsare usedwhen adjustingthe
OSD ofyourmonitor.
LEFTandRIGHTbuttons, like theUP andDOWN
buttons, are alsousedin adjustingtheOSD ofyour
monitor.
BRIGHTNESS hotkey. When theUP andDOWN
arrow buttonsare pressed, theadjustment controls
for theBRIGHTNESS will show up.
OK button whichwhen pressedwill take youto the
OSD controls.
POWER button switchesyourmonitor on.
Automaticallyadjustthehorizontal position,vertical
position,phaseandclock setting.
1Kensington
anti-thieflock
2VGA input
3ACpower input
Item Description
1) Power Cable (socket may
differ for different countries)
2) Macintosh Adapter (optional)
3) VGA Signal Cable
4) E-DFUpackagewithQuick
Setup GuideandCD-ROM.

7
Connection to PC
Connecting to Your PC
1) Plug thepowercord into monitorfirmly.
Note: If you use an Apple Macintosh, you need
to connect the special Mac adapter to one end
of the monitor signal cable
2) Clipthepowercord andsignal cabletogetherforcable
management
2) Connect to PC
(a) Turn off your computer and unplug its power cable.
Connect the monitor signal cable to the video
connector on the back of your computer.
displays an image, installation is complete.

On Screen Display
8
Description of the On Screen Display
On-Screen Display (OSD) is a feature in all Philips LCD monitors. It allows an end user to adjust screen performance or
select functions of the monitors directly through an on-screen instruction window. A user friendly on screen display
interface is shown as below :
Basic and simple instruction on the control keys.
In the OSD shown above users can press
buttons at the front bezel of the monitor to move the
cursor, to confirm the choice or change, and
t o adjust/select the change
The OSD Tree

9
OSD Lock/Unlock, Aging Mode
Front Control Panel
To Lock/Unlock OSD FUNCTION(User Mode)
The OSD function can be locked by pressing"OK"button(1) for more
than 10 seconds, the screen shows following windows for 3 seconds.
Everytime when you press"AUTO" or "OK" button, this message app-
ears on the screen automatically.
ATTENTION SIGNAL
OSD MAIN CONTROLS UNLOCKED
Unlock OSD function
Locked OSD function can be released by pressing "OK" button for more
than 10 seconds again
ATTENTION SIGNAL
OSD MAIN CONTROLS LOCKED
NO VIDEO INPUT
This screen appears if there is no video signal input. Please check that
the signal is properly connected to the video card of PC and make sure
PC is on
ATTENTION SIGNAL
CHECK CABLE CONNECTION
CANNOT DISPLAY THIS VIDEO MODE..
This screen warns when the input frequency from the computer is not
a standard video mode or out of the monitor's scanning range.
Please change the display mode of the operating software in the com-
puter(i.e.windows) to 1280*1024@60HZ for best display results.
ATTENTION SIGNAL
CANNOT DISPLAY THIS VIDEO
MODE,CHANGE COMPUTER DISPLAY
INPUT TO 1280*1024@60HZI
WAIT FOR AUTOMATIC ADJUSTMENT
This screen appears when you press the "AUTO" buttons at the same
time. It will disappear when the monitor is properly adjusted
ATTENTION SIGNAL
WAITING FOR AUTOMATIC ADJUSTMENT
Access Aging.. Mode
Step1:TurnoffLCDmonitor, and disconnect Interface Cable
between Monitor and PC.
Step 2 : [Push AUTO " " & " " buttons at the same time and
hold it]+[Press power " " button until comes out " AGING screen"
] => then release all buttons.
Bring up:
AGING...
After 15 seconds, bring up:
After 15 seconds, bring up:
AGING...
After 15 seconds, bring up:
----------
----------
repeatly
Connect Signal cable again=> go back to normal display

10 Factory Mode
Hudson 170S6 V008 2004-11-01
Front Control Panel
Access Factory Mode
How to get into Factory Mode Menu
Step1:
Turn off monitor.
Step2:
[Push AUTO " " & OK " " buttons at the same time and hold it]
+[Press power " " button untill comes out "Windows screen" ]
=> then release all buttons
Step3:
Press OK " " button, bring up Factory mode indication as shown
in Fig2.
Factory Mode indicator
Factory Menu
Cursor can move on gray color area
Hot key function: by pressing " up " and " DOWN " key
Simultaneously at User Mode (or Factory Mode)
(PS: The OffsetRGBfunction can be used on reduce or eliminate
snowy noise on the background when the resolution of video signal
is 1280*1024 vertical 60Hz. Slightly increase or decrease the value
until snowy noise completely disappear
HUDSON 170S6 V032 2004/12/16
RUNNING HOUR
SUB-BRI : Brightness value range(Min Max)
SUB-CON : Contrast value range(Min Mid Max)
SRGB-B : Brightness of sRGB
SRGB-C : Contrast of sRGB
Gain-m : Minimum value of User Gain
Gain-M : Maximum value of User Gain
AUTO-SUB :To do Auto color function when push Menu key
in white pattern
IDX : Limit current of inverter
SCALER : Read/Write scaler register
Panel : HS (Hannstar panel)
LG (LG.Philips panel)
AU
QDI(Quanta Display Inc.)
DEFAULT
EXIT : Exit Factory Menu
SAVE : Save the setup values of Factory Menu
RUNNING HOUR : Backlight on time

11
Pixel Defect Policy
Philips' Flat Panel Monitors Pixel Defect Policy
Pixels and Subpixels
Types of Pixel Defects
Philips strives to deliver the highest quality products. We use some of
the industry's most advanced manufacturing processes and practice
stringent quality control. However, pixel or subpixel defects on the TFT
LCD panels used in flat panel monitors are sometimes unavoidable.
No manufacturer can guarantee that all panels will be free from pixel
defects, but Philips guarantees that any monitor with an unacceptable
number of defects will be repaired or replaced under warranty.
This notice explains the different types of pixel defects and defines
acceptable defect levels for each type. In order to qualify for repair or
replacement under warranty, the number of pixel defects on a TFT LCD
panel must exceed these acceptable levels.
For example, no more than 0.0004% of the subpixels on a 15" XGA
monitor may be defective. Furthermore, Philips sets even higher quality
standards for certain types or combinations of pixel defects that are
more noticeable than others. This policy is valid worldwide .
A pixel, or picture element, is composed of three subpixels in the
primary colors of red, green and blue. Many pixels together form an
image. When all subpixels of a pixel are lit, the three colored subpixels
together appear as a single white pixel. When all are dark, the three
colored subpixels together appear as a single black pixel.
Other combinations of lit and dark subpixels appear as single pixels of
other colors.
Pixel and subpixel defects appear on the screen in different ways.
There are two categories of pixel defects and several types of subpixel
defects within each category.
Bright Dot Defects Bright dot defects appear as pixels or subpixels that
are always lit or "on".
These are the types of bright dot defects:
One lit red, green or blue subpixel
Two adjacent lit subpixels:
- Red + Blue = Purple
-Red+Green=Yellow
- Green + Blue = Cyan (Light Blue)
Three adjacent lit subpixels
(one white pixel)
Black Dot Defects
Proximity of Pixel Defects
Pixel Defect Tolerances
Black dot defects appear as pixels or subpixels that are always dark or
"off".
These are the types of black dot defects:
One dark subpixel
Two or three adjacent dark subpixels
Because pixel and subpixels defects of the same type that are nearby
one another may be more noticeable, Philips also specifies tolerances
for the proximity of pixel defects.
In order to qualify for repair or replacement due to pixel defects during
the warranty period, a TFT LCD panel in a Philips flat panel monitor
must have pixel or subpixel defects exceeding the tolerances listed in
the following tables.
BRIGHT DOT
DEFECTS ACCEPTABLE LEVEL
MODEL 170S6
1 lit subpixel 4 or fewer
2 adjacent lit subpixels 2 or fewer
3 adjacent lit subpixels
(one white pixel) 0
Distance between two
bright dot defects* 15 mm or more
Total bright dot defects
of all types 4 or fewer
170S6
170S6

12 Pixel Defect Policy
BRIGHT DOT DEFECTS ACCEPTABLE LEVEL
MODEL 150S6
1 lit subpixel 4 or fewer
2 adjacent lit subpixels 2 or fewer
3 adjacent lit subpixels
(one white pixel) 0
Distance between two bright
dot defects* 15 mm or more
Total bright dot defects of all
types 4 or fewer
BLACK DOT DEFECTS ACCEPTABLE LEVEL
MODEL 150S6
1 dark subpixel 4 or fewer
2 adjacent dark subpixels 2 or fewer
3 adjacent dark subpixels 0
Distance between two black
dot defects* 15 mm or more
Total black dot defects of all
types 4 or fewer
TOTAL DOT DEFECTS ACCEPTABLE LEVEL
MODEL 150S6
Total bright or black dot
defects of all types 5 or fewer
BRIGHT DOT DEFECTS ACCEPTAB
LE LEVEL
MODEL 190S6
1 lit subpixel 3 or fewer
2 adjacent lit subpixels 1 or fewer
3 adjacent lit subpixels (one
white pixel) 0
Distance between two bright
dot defects* 25 mm or more
Total bright dot defects of all
types 3 or fewer
BLACK DOT DEFECTS ACCEPTABLE
LEVEL
MODEL 190S6
1 dark subpixel 5 or fewer
2 adjacent dark subpixels 2 or fewer
3 adjacent dark subpixels 0
Distance between two black
dot defects* 15 mm or more
Total black dot defects of all
types 5 or fewer
TOTAL DOT DEFECTS ACCEPTABLE
LEVEL
MODEL 190S6
Total bright or black dot
defects of all types 5 or fewer

13
Mechanical Instructions
Front View
Back View
Step1. Remove the base
-Remove the screws as shown in Fig.3 & Fig.4
Step2. Remove the Front Bezel
-Remove the one screw as shown in Fig.5
-Use the thin " " screw driver to open the clicks as shown
in Fig.6-8
Step3.Remove the Back cover
- Remove the two clicks as shown in Fig.9 ,then remove the Control
board
-Use the thin " " type screw driver to open the clicks as shown in Fig.10
Step4. Remove the Matel frame board
- Remove the two screws as shown in Fig.11
- Remove the matel frame as shown in Fig.12
Fig.1
Fig.2
Fig.4
Fig.5
Fig.6
Fig.9
Fig.10
Fig.11
Fig.3
Fig.8
Fig.7

14
Step 5. Remove the sclar and power board.
- Disconnect the 1505,1502,1413 and 4 backlight cables
as shown in Fig.13
- Remove the scaler and power board as shown in Fig.14
**************************************************************************************
***************************************************************************************
In warranty, it is not allowed to disassembly the LCD panel, even the
backlight unit defect.
Out of warranty, the replacement of backlight units is a correct way
when the defect is caused by backlight (CCFL, Lamp).
Fig.15
Mechanical Instruction
Fig.12
Fig.13
Fig.14
Panel

15
Display Adjustment
Alignment procedure
1. Turn on the LCD monitor.
2.Turn on the Timing/pattern generator. See Fig.1
Resolution :1280x1024(Use the best resolution)
Timing : H= 31.47KHz V=60Hz
3. Preset LCD color Analyzer CA-110
-Remove the lens protective cover of probe CA-A30.
-Set measuring/viewing selector to measuring position for reset
analyzer.(zero calibration) as Fig.2
- Turn on the color analyzer (CA-110)
-Press 0-CAL button to starting reset analyzer. See Fig.3
Fig. 1
Fig. 2
Cover (black)Cover (black)
Measurement viewing selectorMeasurement viewing selector
Note: after alignment,please reset OSD to user s mode for normal
operation. Otherwise,the monitor won t entering power saving mode
and showing full white picture all the time as no video signal supplied.
To leave factory mode by restart the monitor.
5.Adjust OSD menu to lower position of screen (i.g. adjust V-position to
value "0"at submenu of OSD Setting.
6. Setting Brightness and Contrast
-Adjust Brightness to value "90".
-Adjust Contrast to value "80".
7. Switch light probe to Viewing position.
8. Move the Lens barrel forward or backward to get clear image as
showninFig.4
9. Switch light probe to Measuring position. It should be able to indicate
Clear imageClear image
Measurement/viewing selectorMeasurement/viewing selector
Alignment hits: 1. R for x value,Gfor y value,Bfor Yvalue on the
colour analyzer.
2. If the colour analyzer has been calibrated and preset
colour temperature in it. Please switch to correct
setting in accordance with colour settings.
Factory Mode indicator
HUDSON 170S6 V032 2004/12/16
4. Access Factory Mode
How to get into Factory Mode Menu
Step1:
Turn off monitor.
Step2:
[Push AUTO" "&OK""buttons at the same time and hold it]
+[Press power ""button untill comes out "Windows screen"]
=> then release all buttons
Step3:
Press OK""button,bring up Factory mode indication as shown
in Fig3.
Fig. 3
10. Setting pattern to full white picture
11. Press button,then select factory mode indicator by"" ""
button
12. Press""button to bring up submenu windows as below:
13. Press ""or ""button to select R GB. Change the value by
""or ""key until the X,Y co-ordinates as below
sRGB
x(center) 0.313 ±0.008
y(center) 0.329 ±0.008
Ynits 180 ±10
9300°K 6500°K
Fig.4
15.EEPROMpresetting(B)
After finishing all the adjustment,set:
Brightness control to 100%
Contrast control to 50%
OSD position at middle of screen
COLORadjusts to 6500K color.

16 Warning Message Table
Warning message table
Item AttentionSignals DisplayTime ConditionAttentionoff
1CANNOT DISPLAY
THIS VIDEO MODE,
CHANGE COMPUTER
DISPLAY
INPUT TO 1024X768
@ 60HZ
30 mins This warning appears when theinput signal fromyour
computer is notinastandardvideomodeorisoutof the
monitor’sscanning range.After 30 mins,monitor enters
sleeping mode.
No
2NO VIDEO INPUT 30 mins This message appears when there is nosignal inputbutwith
cable while AC orDC while power on.After 30 mins,monitor
enters sleeping mode.
Yes
Show floating
menu
ATTENTION
SIGNAL OFF
3CHECK CABLE
CONNECTION
30 mins This message appears when a signal cable is disconnected
while monitorisworking.After 30 mins,monitor enters
sleeping mode.
Yes
Show floating
menu
ATTENTION
SIGNAL OFF
4ENTERING SLEEP
MODE
3secsThis message appears when monitorisabouttoenter power
saving mode.
No
5WAITING FOR
AUTOMATIC
ADJUSTMENT
till auto
adjustment
finished
This message is displayedwhen theautoadjustment button
is pressed. Itdisappears when automaticadjustments are
completed.
No
6USE 1024 X 768 FOR
BEST RESULT
Ontop of OSD
main menu
The message will show up at thetop of theOSD main menu
in redcolorwhen theinputresolutionisnotthe1024x768.
Yes
7OSD MAIN
CONTROLS LOCKED
3secs/orTill
OSD MAIN
CONTROLS
UNLOCKED
appear
This message will appear 3secondstoindicate theOSD
MAIN CONTROLS statuswhen tolock orun-lock it by
pressing MENU(OK) buttonformore than 10 secondswhile
there is videoinputfromPC. This functionprovides the
alternativethat user can lock all theOSD main controlin
case user don’twant theFOS performance setting tobe
changed, forinstance,during commercial exhibition.
No functionwhen
push10secs(If
OSD lock then
attentionoff, not
anymessage and
onlyattentionon)
8OSD MAIN
CONTROLS
UNLOCKED
3secsThis message will appear 3secondstoindicate theOSD
MAIN CONTROLS statuswhen toun-lock it bypressing
MENU(OK) buttonformore than 10 secondswhile there is
videoinputfromPC.
No functionwhen
push10secs
9ATTENTION SIGNAL
ON
ATTENTION SIGNAL
OFF
3secs
3secs
This message will appear 3secondstoindicate the attention
signals in ON orOFF statuswhen toswitch this functionon
oroff bypressing theAUTO buttonformore than 10 seconds
while at novideoinputfromPC.
Yes
10 THIS IS 85HZ
OVERSCAN, CHANGE
COMPUTER DISPLAY
INPUT TO
1024X768@60HZ
10 mins This message will appear 5secondsinevery60secondsfor
10 minutes when theinputof PC videotiming is at 85Hz
mode.
Remark: AUTO is still functional in this mode
No
11 thewindow of OSD
MAIN CONTROLS
60 secsThis message will appear when theOK buttonispressed. Yes

17
Trouble Shooting
Common Problems
Having this problem? Check these items
No Picture
(power LED not lit)
·Make sure the power cord is plugged into the power outlet
and into the back of the monitor.
·First, ensure that the power button on the front of the monitor is in
the OFF position, then press it to the ON position
No Picture
(Power LED is amber or yellow)
·Make sure the computer is turned on.
·Make sure the signal cable is properly connected to your computer.
·Check to see if the monitor cable has bent pins.
·The Energy Saving feature may be activated
Screen says ·Make sure the monitor cable properly connected to your computer.
(Also refer to the Quick Set-Up Guide).
·Check to see if the monitor cable has bent pins,
·Make sure the computer is turned on.
Screen says ·Make sure the vertical sync of input signal is within the range of
56--75Hz.
·Change the refresh rate to 56--75Hz within 10 minutes.
·Re-power on monitor to start over again if you failed to change the
refreshratewithin10minutes.
AUTO button not working properly ·The Auto Function is designed for use on standard Macintosh or
IBM-compatible PCs running Microsoft Windows.
·It may not work properly if using nonstandard PC or video card.
·The AUTO adjustment does not function when digital input is used
for display

18 Trouble Shooting
The following table lists possible Image problems, and the recommended resolutions.
Image Problems
Having this problem?Checkthese items
Displayposition is incorrect ·Press the AUTObutton
·Adjust the image position using the Horizontal Position
and/or Vertical Position in OSD Main Controls.
Image vibrates on the screen ·Checkthat the signal cable is properlyconnected to the
graphics board or PC.
Vertical flicker appears ·Press the AUTObutton
·Eliminate the vertical bars using the ClockAdjustment of
VIDEO NOISE in OSD Main Controls.
Horizontal flicker appears ·Press the AUTObutton
·Eliminate the horizontal bars using the Phase
Adjustment of VIDEO NOISE in OSD Main Controls.
The screen is too bright or too dark
·Adjust the contrast and brightness on OSD Main Controls.
Anafter-image appears ·If an image remains on the screen for an extended period of time,
it maybe imprinted in the screen and leaveanafter-image. This
usuallydisappears after a few hours.
Anafter-image remains after the power has
been turned off.
·This is characteristic of liquid crystal and is not caused bya
malfunction or deterioration of the liquid crystal. The after-image
will disappear after a period of time.
Green, red, blue, and white dots remains ·The remaining dots are normal characteristic of the liquid crystal
used in todays technology.

19
Wiring Message

20 Block Diagram
SCALER
NT68521A
EEPROM
M24C16
DDCSDA DDCSCL
R/G/B
CLK and R/G/B
DATA
(LVDS interface)
MCU (64K)
NT68F633
CLK: 12MHz
IICSDA
IICSCL
HS/VS
Connector to
Control
Board
Connector to Panel
VIDEO
Input
LVDS
Tx
Panel_PWR 5V/12V
D-SUB
Connector to
Inverter
BL_CTRL
Brightness
Buy
Buy-
-In
In
AC
AC-
-DC Power supply
DC Power supply
Inverter and
Inverter and
DC
DC-
-DC converter
DC converter
(150mm x 135mm)
(150mm x 135mm)
Scalar(LVDS interface)
Scalar(LVDS interface)
Analog Input
Analog Input
(94mm x 74mm)
(94mm x 74mm)
AC
input
Connector
Connector
30 pin wafer
Connector Connector 30 Pin FFC Cable
Connector
11P-Connector
D_SUB
7P-Connector
CONTROL BD
Scaler IC
(NT68521A)
11-Pin
Power Input
connector
LVDS Interface Connector
MCU
NT68F633L
7-Pin Control
Output
Connector
EEPROM
D_SUB
12MHz
XTAL
System Block Diagram
System Block Diagram
Scaler
Scaler Board Layout
Board Layout
Scaler
Scaler Board Block Diagram Board Block Diagram
