170C4FS/00
http://www.wjel.net

Important Safety Notice
2
FOR PRODUCTS CONTAINING LASER :
Invisible laser radiation when open.
AVOID DIRECT EXPOSURE TO BEAM.
Use of controls or adjustments or
performance of procedures other than
those specified herein may result in
hazardous radiation exposure.
The use of optical instruments with this
product will increase eye hazard.
DANGER-
CAUTION-
CAUTION-
TO ENSURE THE CONTINUED RELIABILITY OF THIS
PRODUCT, USE ONLY ORIGINAL MANUFACTURER'S
REPLACEMENT PARTS, WHICH ARE LISTED WITH THEIR
PART NUMBERS IN THE PARTS LIST SECTION OF THIS
SERVICE MANUAL.
170C4/N4
Proper service and repair is important to the safe, reliable
operation of all Philips Consumer Electronics Company**
Equipment. The service procedures recommended by
Philips and described in this service manual are effective
methods of performing service operations. Some of these
service operations require the use of tools specially designed
for the purpose. The special tools should be used when and
as recommended.
It is important to note that this manual contains various
CAUTIONS and NOTICES which should be carefully read in
order to minimize the risk of personal injury to service
personnel. The possibility exists that improper service
methods may damage the equipment. It is also important to
understand that these CAUTIONS and NOTICES ARE NOT
EXHAUSTIVE. Philips could not possibly know, evaluate and
advise the service trade of all conceivable ways in which
service might be done or of the possible hazardous
consequences of each way. Consequently, Philips has not
undertaken any such broad evaluation. Accordingly, a
servicer who uses a service procedure or tool which is not
recommended by Philips must first satisfy himself thoroughly
that neither his safety nor the safe operation of the equipment
will be jeopardized by the service method selected.
* * Hereafter throughout this manual, Philips Consumer
Electronics Company will be referred to as Philips.
Critical components having special safety characteristics are
identified with a by the Ref. No. in the parts list and
enclosed within a broken line*
(where several critical components are grouped in one area)
along with the safety symbol on the schematics or
exploded views.
Use of substitute replacement parts which do not have the
same specified safety characteristics may create shock, fire,
or other hazards.
Under no circumstances should the original design be
modified or altered without written permission from Philips.
Philips assumes no liability, express or implied, arising out of
any unauthorized modification of design.
Servicer assumes all liability.
WARNING
* Broken Line
Take care during handling the LCD module with backlight
unit
- Must mount the module using mounting holes arranged in four
corners.
- Do not press on the panel, edge of the frame strongly or electric
shock as this will result in damage to the screen.
- Do not scratch or press on the panel with any sharp objects, such
as pencil or pen as this may result in damage to the panel.
- Protect the module from the ESD as it may damage the electronic
circuit (C-MOS).
- Make certain that treatment person’s body are grounded through
wrist band.
- Do not leave the module in high temperature and in areas of high
humidity for a long time.
- Avoid contact with water as it may a short circuit within the module.
- If the surface of panel become dirty, please wipe it off with a soft
material. (Cleaning with a dirty or rough cloth may damage the
panel.)
Go to cover page
http://www.wjel.net

170C4/N4
# Resolution H-Frequency Pixel rate V-Frequency Comment
1 640X350 31.5KHz 25.175 70Hz IBM VGA 10h
2 720X400 31.5KHz 28.322 70Hz IBM VGA 3h
3 640X480 37.5KHz 31.501 75Hz
4 640X480 35.0KHz 30.24 67Hz
5 640X480 31.5KHz 25.175 60Hz
6 800X600 35.2KHz 36 56Hz
7 800X600 46.9KHz 49.498 75Hz
8 800X600 37.9KHz 40 60Hz
9 832X624 49.7KHz 57.28 75Hz MAC
10 1024X768 60.0KHz 78.75 75Hz
11 1024X768 48.4KHz 65 60Hz
12 1152X870 68.7KHz 100 75Hz MAC
13 1152X900 71.8KHz 108 76Hz SUN Mode II
14 1280X1024 64.0KHz 108 60Hz
15 1280X1024 80.0KHz 135 75Hz
16 688X556 31.3KHz 27 50Hz TV-PAL
3
Technical Specifications
Technical Data
Go to cover page
LCD
Type NR. : CLAA170EA03 (CPT.)
Number of Pixels. : 1280 (H) x 1024 (V)
Physical Size. : 358.5(w)296.5(h)17(d) mm
Pixel Pitch. : 0.264 (per one triad) x 0.264 mm
Color pixel arrangement : RGB vertical stripes
Support Color. : 262k colors (RGB 6 bits data)
Display Mode. : Normally White
Backlight. : CCFL edge light system
Active area. (WXH). : 337.92 x 270.336mm (17inch diagonal)
Viewing Angle. : Vertical 140 degree, Horizontal 140 degree
(CR=10)
Contrast ratio. : 450:1
Luminance. : 300 cd/m (Typ)
Type NR. : QD17ER01 (QDI.)
Number of Pixels. : 1280 (H) x 1024 (V)
Physical Size. : 358.5(w)296.5(h)18.8(d) mm
Pixel Pitch. : 0.264 (per one triad) x 0.264 mm
Color pixel arrangement : RGB vertical stripes
Support Color. : 262k colors (RGB 6 bits data)
Display Mode. : Normally White
Backlight. : CCFL edge light system
Active area. (WXH). : 337.92 x 270.3mm (17inch diagonal)
Viewing Angle. : Vertical 140 degree, Horizontal 140 degree
(CR=10)
Contrast ratio. : 400:1
Luminance. : 260 cd/m (Typ)
Type NR. : LS170E01 (LPL.)
Number of Pixels. : 1280 (H) x 1024 (V)
Physical Size. : 358.5(w)296.5(h)17(d) mm
Pixel Pitch. : 0.264 (per one triad) x 0.264 mm
Color pixel arrangement : RGB vertical stripes
Support Color. : 262k colors (RGB 6 bits data)
Display Mode. : Normally White
Backlight. : CCFL edge light system
Active area. (WXH). : 337.920 x 270.3336mm (17inch diagonal)
Viewing Angle. : Vertical 120 degree, Horizontal 140 degree
(CR=10)
Contrast ratio. : 450:1
Luminance. : 250 cd/m (Typ.)
D-sub male with DDC-2B pin assignments.Blue connector thum
B-operated jackscrews .
Pin Assignment:
2
2
2
PIN No. SIGNAL
1 Red video input
2 Green video input /sync on green
3 Blue video input
4 GND
5 GND
6 Red video GND
7 Green video GND
8 Blue video GND
9 DDC +3.3V or +5V
10 Logic GND- Cable detect
11 GND
12 Serial data line (SDA)
13 H-sync / H+V
14 V-sync
15 Data clock line (SCL)
ENERGY STAR is a U.S. registered mark. AS AN ENERGY STAR
PARTNER, DELL Computer Corporation HAS DETERMINED THAT
THIS PRODUCT MEETS THE ENERGY STAR GUIDELINES FOR
ENERGY EFFICIENCY.
Power management
The power consumption and the status indication of the set
with power management function are as follows,
Note : Disconnect DVI signal cable and audio module
According to VESA power saving signal. TCO99 power saving
requirement EPA energy star requirement .
VESA Mode H-sync V-sync Power Used LED color
ON Pulse Pulse < 35 W Green
OFF No Pulse No pulse < 1W Amber
Resolution Factory preset modes (16 modes)
Unit dimension / Weight
Set dimension (incl. pedestal): 399(W) * 398(H) * 197(D) mm
Net weight. : 4.2 kg
Susceptibility of display to external environment
Operating
- Temperature. : 5 to 35 degree C
- Humidity. : 80% max
- Altitude. : 0 to 12,000 feet
Storage
- Temperature. : -20 to 60 degree C
- Humidity. : 100% max (< 40)
- Altitude. : 0 to 30,000 feet
Note: recommend at 5 to 35C, Humidity less than 60 %
http://www.wjel.net

170C4/N4
4Connecting The Monitor
Go to cover page
Connecting to Your PC
Setp 1: Plug the power cord into monitor firmly.
Note: If you use an Apple Macintosh, you need to connect the special
Mac adapter to one end of the monitor signal cable.
Setp 2 :
a) Remove the arm box's top cover ,Press the center of the cap and
open the cap from sides (Do not attempt to open the cap from the
top or the bottom)
b) Fix the cables to the hook
c) Place the cables inside the arm box and lock the cables with grip
on the base.
d) Replace top cover
We recommend you follow intelligent cable management to reduce
the electrical alternating field to low level as not to burden the work
environment with unnecessary factors.
Setp 3: Connect to PC
(A) Turn off your computer and unplug its power cable.
(b) Plug the power cord of your computer and your monitor into a
nearby outlet.
(c) Connect the monitor signal cable to the video connector on the
Back of your computer.
(D) Turn on your computer and monitor. If the monitor displays an
image, installation is complete.
Setp 4: Attach back cover to keep desk clear of unsightly wires.
Setp 5 : To remove back cover
http://www.wjel.net

170C4/N4 5
Front panel and Accessory pack
Go to cover page
Front View Product Description Accessory Pack
1) Audio in Cable (Option only available for Multimedia version)
(color line)
2) Power Cable (socket may differ for different countries)
3) Macintosh Adapter (optional)
4) VGA Signal Cable
5) E-DFU package with Quick Setup Guide and CD-ROM.
6) Screws for wall mounting
UP and DOWN buttons are used when adjusting the
OSD of your monitor .
LEFT and RIGHT buttons, like the UP and DOWN
buttons, are also used in adjusting the OSD of your
Monitor.
BRIGHTNESS hotkey. When the UP and DOWN arrow
buttons are pressed, the adjustment controls for the
BRIGHTNESS will show up.
OK button which when pressed will take you to the OSD
Controls.
POWER button switches your monitor on .
Automatically adjust The horizontal position, vertical
position, Phase and clock setting.
http://www.wjel.net

170C4/N4
6On-Screen Display
Go to cover page
When you press the button on the front control of your monitor,
The On-Screen Display (OSD) Main Controls window will pop up and you
can then start making adjustments to your monitor's various features.
Use the or the keys to make your adjustments.
http://www.wjel.net

170C4/N4 7
Go to cover page
OSD Lock/Unlock, Aging & ,
Enable/Disable "warning message"
ATTENTION
OSD MAIN CONTROLS LOCKED
ATTENTION
OSD MAIN CONTROLS UNLOCKED
ATTENTION
ATTENTION SIGNAL OFF
ATTENTION
ATTENTION SIGNAL ON
To Lock/Unlock OSD function (User Mode)
The OSD function can be locked by pressing "OK" button(1) for more
than 10 seconds, the screen shows following windows for 3 seconds.
Everytime when you press "AUTO" or "OK" button, this message
appears on the screen automatically.
To Enable/Disable "Warning message" on screen
(in User Mode)
Unlock OSD function:
Locked OSD function can be released by pressing"OK" button for
more than 10 seconds again.
Step 1: Turn off LCD monitor, and disconnect Interface Cable
between Monitor and PC.
Step 1: Turn on LCD monitor, and disconnect Interface Cable
between Monitor and PC.
Fig. 2
Fig. 3
Bring up
After 15 seconds, bring up :
After 15 seconds, bring up :
:
After 15 seconds, bring up :
----------
----------
repeatly
Connect signal cable again => go back to normal display.
Status 1.: Turn off monitor, then turn on monitor again
=> go back to Windows screen.
=> go back to last display.
Connect signal cable againStatus 2.
Access Aging.. Mode
Step 2 :
[Push AUTO " " & OK " " buttons at the same time and hold
it]+[Press power " " button untill comes out "AGING screen"
] => then release all buttons.
Step 2 :
Push AUTO " " button for more than 10 seconds to disable
"warning message", bring up
Step 3 :
Push AUTO " " button for more than 10 seconds again to enable
"warning message", bring up
AGING...AGING...
AGING...AGI N G ...
Front control panel
Fig. 1
http://www.wjel.net

170C4/N4
8
Go to cover page
Warning message table
Warning message table
Attention Signals Display Time Condition
CANNOT DISPLAY THIS VIDEO
MODE, CHANGE COMPUTER
DISPLAY
INPUT TO 1280x1024 @ 60HZ
30 mins This warning appears when the input signal
from your computer is not in a standard video
mode or is out of the monitor’s scanning
range. After 30 mins, monitor enters sleeping
mode.
NO VIDEO INPUT 30 mins This message appears when there is no
signal input while power on. After 30 mins,
monitor enters sleeping mode.
CHECK CABLE CONNECTION 30 mins This message appears when a signal cable is
disconnected while monitor is working. After
30 mins, monitor enters sleeping mode.
ENTERING SLEEP MODE 3secs This message appears when monitor is about
to enter power saving mode.
WAITING FOR AUTOMATIC
ADJUSTMENT
till auto
adjustment
finished
This message is displayed when the auto
adjustment button is pressed. It disappears
when automatic adjustments are completed.
USE 1280x1024 FOR BEST RESULT On top of OSD
main menu
The message will show up at the top of the
OSD main menu in red color when the input
resolution is not the 1280x1024.
OSD MAIN CONTROLS LOCKED 3 secs / or Till
"OSD MAIN
CONTROLS
UNLOCKED"
appear
This message will appear 3 seconds to
indicate the OSD MAIN CONTROLS status
when to lock or un-lock it by pressing
“MENU(OK)” button for more than 10 seconds
while there is video input from PC. This
function provides the alternative that user can
lock all the OSD main control in case user
don’t want the FOS performance setting to be
changed, for instance, during commercial
exhibition.
OSDMAINCONTROLSUNLOCKED 3secs This message will appear 3 seconds to
indicate the OSD MAIN CONTROLS status
when to un-lock it by pressing “MENU(OK)”
button for more than 10 seconds while there
is video input from PC.
ATTENTION SIGNAL ON
ATTENTION SIGNAL OFF
2secs
3secs
This message will appear 3 seconds to
indicate the attention signals in ON or OFF
status when to switch this function on or off
by pressing the AUTO button for more than
10 seconds while at no video input from PC.
THIS IS 85HZ OVERDRIVE,
CHANGE COMPUTER DISPLAY
INPUT TO 1280x1024@60HZ
10 mins This message will appear 5 seconds in every
60 seconds for 10 minutes when the input of
PC video timing is at 85Hz mode.
Remark: AUTO is still functional in this mode
the window of "OSD MAIN
CONTROLS"
60 secs This message will appear when the “OK”
button is pressed.
the window of "BRIGHTNESS" 60 secs This message will appear when the
BRIGHTNESS button is pressed.
http://www.wjel.net

170C4/N4 9
Go to cover page
Factory mode
Access Factory Mode
Step 2 :
[Push AUTO " " & OK " " buttons at the same time and hold
it]+[Press power " " button untill comes out "Windows screen"
] => then release all buttons.
How to Get into Factory Mode Menu
Turn off monitor.
Press OK " " button, bring up Factory mode indication as
shown in Fig 2.
Step 1 :
Step 3 :
Basic and simple instruction on the control keys.
When you press the button on the front control of your monitor, the On-
Screen Display (OSD) Main Controls window will pop up and you can
then start making adjustments to your monitor's various features.
Front control panel
Fig. 1
Fig. 2
Contrast adjustment (Sub-Contrast). Use this menu item to
adjust the contrast gain of pre-amp ranges from 0 to 255.
9300KRGB
6500KRGB
Color temperature gain adjustment. Use these menu items to
adjust the RGB gains of pre-amp for different color
temperatures, ranges from 0 to 255.
OFFSET R G B
Sub-Brightness adjustment. Use this menu item to adjust
the brightness level (DC-level) of pre-amp range from 0 to
255.(R/G/B ANALOG DC -level).
GAIN R G B
R/G/B GAIN adjustment. Use this menu item to adjust
the R/G/B (GAIN) of Amp. range from 0 to 255.(R/G/B
ANALOG GAIN Values).
It is for 1024x768/60Hz with special pattern only.
AUTO SUB:
Do not use this function here.
AUTO SUB:
(PS: The OffsetRGB function can be used on reduce or eliminate
snowy noise on the background when the resolution of video signal is
1280 X 1024 vertical 60Hz. Slightly increase or decrease the value
until snowy noise completely disappear.)
Hot key function: by pressing "UP" and "DOWN" key
simultaneously at User mode (or Factory mode).
-
OK
-
SUB CON:SUB CON:
HUDSON3 170C4 V200 2003010
<------Factory mode indicator
BL : Blacklevel value
SUB-BRI : Brightness value range(Min Max)
SUB-CON : Contrast value range(Min Mid Max)
SRGB-B : Brightness of sRGB
SRGB-C : Contrast of sRGB
Gain-m : Minimum value of User Gain
Gain-M : Maximum value of User Gain
AUTO-SUB : To do Auto color function
When push Menu key in white pattern
OSDTIMER : OSD time out control(sec)
VCON : For LG 15inch panel control
IDX : Limit current of inverter
(For 15inch panel control)
SCALER : Read/Write scaler register
NVRAM : Read/Write eeprom address
Panel : AUO (AUO panel)
CPT (CPT panel)
QDI (QDI panel)
LPL (LG.Philips panel)
Factory menu
Cursor can move on gray color area
Fig. 3
http://www.wjel.net

170C4/N4
10 Troubleshooting
Go to cover page
Solving Common Problems
The following table lists possible problems, the possible cause of each problem, and the recommended solutions.
Screen is blank. Power cord is disconnected. Connect the power cord.
Power switch is turned Off. Turn on the power.
Video cable is improperly connected. Connect the video cableproperly.
Screen blanking utility is active. Depress any key on the keyboard or move
The mouse to inactivate the screen blanking
Utility.
Problem Possible Cause Solution
Image appears
blurred, indistinct, or
Too dark.
Image is not
Centered. auto-adjust the screen image.
Press the Menu button to access the
Advanced OSD menu. Select Image
Control/Horizontal Position or Vertical
Position to adjust the horizontal or vertical
position of the image.
Check Video
Cable is displayed
on screen.
(Input Signal Out of
Range) is displayed
on screen.
Restart your computer so that the
new settings take effect.
Brightness and contrast Press the Minus button on
are too low. the monitor front panel to
auto-adjust the screen. If that
Does not work, press the
Menu button to open the
Basic OSD Menu, and
adjust the brightness and
contrast scales as needed.
Position may need When OSD is inactive,press-(minus
Adjustment. button) to
Monitor video cable is Connect the 15-pin monitor video cable
disconnected. to the VGA connector on the computer.
Be sure that the computer
power is off while: connecting the video
Cable.
Video resolution and/or Restart your computer and enter Windows
refresh rate are set Safe Mode by pressing the F6 Function
higher than what your key when the computer starts to boot up.
monitor supports. Change your settings to a supported
setting.
http://www.wjel.net

170C4/N4 11
Go to cover page
Wiring Diagram
http://www.wjel.net

170C4/N4
12
Go to cover page
Flat Panel Adjust
Optimizing Performance
Installing FPadjust Program
For best performance, ensure that your display settings are set at 1024x768@60Hz (for
14"/15") or 1280x1024, 60Hz (for 17"/18").
Note: You can check the current display settings by pressing the 'OK' button once. Go into the
Product Information.
The current display mode is shown on the item called RESOLUTION.
You can also install the Flat Panel Adjust (FP Adjust) program, a program for getting the best
performance out of your monitor. This included on this CD. Step-by-step instructions are
provided to guide you through the installtion process. Click on the link to know more about this
program.
The FP Adjust program generates alignment patterns which will help you adjust monitor
settings such as CONTRAST, BRIGHTNESS, HORIZONTAL & VERTICAL POSITION, PHASE
and CLOCK.
System requirements:
PC running Windows 95, Windows 98, Windows 2000, Winodws Me, Windows XP or later
To install FPadjust Program:
Click on the link or icon to install FPadjustment Program.
or
Click-and-hold your mouse over the icon. (Win95/98/2000/Me/XP users right-click)
Download FP_setup04.exe
From the menu that appears, choose 'Save Link As...', 'Save Target As...' or 'Download Link to
Disk'.
Choose where you would like to save the file; click 'Save' (if prompted to save as either 'text'
or 'source', choose 'source'). Exit your browser and install the FPadjust Program. Read the
"FP_Readme04.txt" file before installing.
http://www.wjel.net

170C4/N4 13
Go to cover page
Definition of Pixel Defects
LCD Monitor Quality and Pixel Policy
The TFT monitor uses high-precision technology, manufactured according to HP
standards, to guarantee trouble-free performance. Nevertheless, the display
may have cosmetic imperfections that appear as small bright or dark spots. This
is common to all LCD displays used in products supplied by all vendors and is not
specific to the HP LCD. These imperfections are caused by one or more
defective pixels or sub-pixels.
1. A pixel consists of one red, one green, and one blue sub-pixel.
2. A defective whole pixel is always turned on (a bright spot on a dark
background), or it is always off (a dark spot on a bright background). The first
is the more visible of the two.3. A defective sub-pixel (dot defect) is less
3. visible than a defective whole pixel
and is small and only visible on a specific background.
The HP display does not have more than:
4. 3 bright dots.
5. 5 dark dots.
6. 5 total bright and dark dots.
7. No more than two adjacent (less than 2.5 mm edge-to-edge)
defective pixels.
To locate defective pixels, the monitor should be viewed under normal operating
conditions, in normal operating mode at a supported resolution and refresh rate,
from a distance of approximately 50 cm (16 in.).
HP expects that, over time, the industry will continue to improve its ability to
produce LCDs with fewer cosmetic imperfections And HP will adjust guidelines
as improvements are made.
http://www.wjel.net

170C4/N4
14
Go to cover page
Mechanical Instructions
Front view
Fig. 1
Fig. 2 C4 N4
Fig. 3
Step 1. Remove the rear cover as Fig .3
and hinge cover as
Fig. 4.
Step 2. Remove the
four screws as
Fig.5.
Fig. 4
Fig. 8
Step 4. Remove the front bezel as Fig. 8. ~ 11.
Back view
Fig. 9
===>
a. Use thin "I" type screwdriver to open 2 clicks on bottom
side as Fig.8
b. Use thin "I" type screwdriver to open 3 clicks on right
and left side as Fig.9
c. Use thin "I" type screwdriver to open 5 clicks on Top
side as Fig.10
Fig. 10
Fig.11
===>
===>
===>
===>
===>
===>
===>
===>
Hinge cover=====> <=====Hinge cover
Fig.5
Fig.6
Fig. 7
Step 3. Remove the
five screws as
Fig.6.7.
And remove
the
Audio chin
1
=====>
094 823827713371 MULTIEDIA BASE-N4
http://www.wjel.net

170C4/N4 15
Go to cover page
Mechanical Instructions
Step 5. Remove the black cover as Fig. 12. 13.
Fig. 12
Fig. 13
Fig. 14
Step 5. Remove the 8 screws and shift as Fig. 14. ~16.
Fig. 15
Fig. 16
Power board
Scaler board
Fig. 17
Fig. 18
1084 313818876001 FFC 30/90/30 61309
1086 313818875651 FFC 50/90/50 61509
======>
1050 823827712941 LCD PANEL CPT PANEL - 1 (OS)-C4 & N
4
1050 823827713131 LCD PANEL LPL PANEL - 2 (S)-only C4
1050 932219888682 LCD PANEL QDI PANEL – 3 (S)-C4 & N4
1051 313815857151 SB - 1 ASSY (CPT) (OS)-C4
1051 313815857191 SB - 1 ASSY (CPT) (OS)-N4
1051 313815857161 SB - 2 ASSY (LPL) (S)-only C4
1051 313815857171 SB-3 ASSY (QDI) (S)-C4 & N4
***************************************************************************
In warranty, it is not allowed to disassembly the LCD panel, even the
backlight unit defect.
Out of warranty, the replacment of backlight unit is a correct way
when the defect is cused by backlight (CCFL,Lamp).
***************************************************************************
http://www.wjel.net

170C4/N4
16 Electrical Instructions
Go to cover page
1.
2.
General points
Input signal
1.1 During the test and measuring, supply a distortion free AC
mains voltage to the apparatus via an isolated transformer
with low internal resistance.
1.2 All measurements mentioned hereafter are carried out at a
normal mains voltage (90 - 132 VAC for USA version,
195 -264 VAC for EUROPEAN version, or 90 - 264 VAC for
the model with full range power supply, unless otherwise
stated.)
1.3 All voltages are to be measured or applied with respect to
ground, unless otherwise stated. Note: don't use heat-sink
as ground.
1.4 The test has to be done on a complete set including LCD
panel after 30 minutes warm-up at least in a room with
temperature of 25 +/- 5 degree C.
1.5 All values mentioned in these test instruction are only
applicable of a well aligned apparatus, with correct signal.
1.6 The letters symbols (B) and (S) placed behind the test
instruction denotes
(B): carried out 100% inspection at assembly line
(S): carried out test by sampling
1.7 The white balance (color temperature) has to be tested in
subdued lighted room.
1.8 Repetitive power on / off cycle are allowed except it should
be avoided within 6 sec.
2.1 Signal type
2.1.1 Video signal input
Signal source: pattern generator format as attachment.
(Table 1 to 34) Reference generator: QuantumData 802G
The input signals can be applied in two different modes:
1). VESA Analog
The video input consists of red, green, and blue signals.
The video signals are analog levels,where 0V corresponds
to black and 700mV is the maximum signal amplitude.
Input impedance of video pins is 75 ohm +- 1%.
2.1.2 Sync signal input
The capability of sync signal inputs shall include separate
sync, composite sync and sync on green. Input
impedance: 2k2 ohms The signals are defined as follow:
Separate sync TTL level, Positive/Negative
Composite sync TTL level, Positive/Negative
Sync on green H-sync TTL level, Positive/Negative
Signal source: pattern generator format as attachment
(Table 1 to 34) Reference generator: QuantumData 802G
2.2 Input signal mode
Pre-set 34 modes
PRESETVIDEO RESOLUTION
# Resolution H-
Frequency
Pixel rate V-
Frequency
Comment
1 640X350 31.5K 25.175 70Hz IBM VGA 10h
2 720X400 31.5K 28.322 70Hz IBM VGA 3h
3 640X480 31.5K 25.175 60Hz
4 640X480 35.0K 30.24 67Hz
5 640X480 37.9K 31.5 72Hz
6 640X480 37.5K 31.501 75Hz
7 640X480 43.3K 36 85Hz
8 800X600 35.2K 36 56Hz
9 800X600 37.9K 40 60Hz
10 800X600 48.1K 50 72Hz
11 800X600 46.9K 49.498 75Hz
12 800X600 53.7K 56.251 85Hz
13 832X624 49.7K 57.28 75Hz MAC
14 1024X768 48.4K 65 60Hz
15 1024X768 56.5K 75 70Hz
16 1024X768 60.0K 78.75 75Hz
17 1024X768 61.1K 83.096 76Hz IBM XGA-2
18 1024X768 68.7K 94.5 85Hz
19 1152X864 54.0K 79.9 60Hz non-VESA
20 1152X864 67.5K 108 75Hz
21 1152X864 63.9K 94.5 70Hz non-VESA
22 1152X870 68.7K 100 75Hz MAC
23 1152X900 61.8K 92.94 66Hz SUN Mode IV
24 1152X900 71.8K 108 76Hz SUN Mode II
25 1280X960 60.0K 108 60Hz
26 1280X960 75.0K 129.895 75Hz non-VESA
27 1280X102
4
64.0K 108 60Hz
28 1280X102
4
71.7K 117 67Hz SUN Mode V
29 1280X102
4
76.0K 130.223 72Hz DOS/V
30 1280X102
4
80.0K 135 75Hz
31 1280X102
4
81.1K 135.008 76Hz SUN Mode I
32 688X556 31.3K 27 50Hz TV-PAL
33 960X720 44.76K 57.58 60Hz
34 960X720 56.4K 72.42 75Hz
http://www.wjel.net

170C4/N4
sRGB
x (center) 0.313 ±0.020
y (center) 0.329 ±0.020
Ynits 210 ±10
17
Electrical Instructions
Go to cover page
2.3 Allowed 85 Hz overscan signal mode specified
Once the signal input of PC is 85Hz, this monitor is able to
display at least for 10 minutes. An attention signal
appears and shows This is 85Hz overscan for 5 seconds,
Change computer display input to 1024*768 @ 60 Hz.
Dot rate (MHz) H. Freq (KHz) Mode Resolution V. Freq (Hz)
36.000 43.269 VESA 640 * 480 85.008
56.250 53.674 VESA 800 * 600 85.061
94.500 68.677 VESA 1024 * 768 84.997
3. POWER SUPPLY
4. Display Adjustment
3.1 Setup the AC I/P at 90VAC, add 2.6A loading to C2116,
C2117 and DC O/P voltage is 12V +/- 1.2V; 1A loading to
C2119 and DC O/P voltage is 3.3V +/- 0.165V (B).
4.1 Access to factory mode (RS232) in auto-alignment system
The communication protocol switch to RS232 .
4.2 Auto color adjustment (B)
Apply a 48.36kHz/60Hz signal with white pattern, set
brightness control at 100%, and contrast control at 50%.
Adjust the R. G. B offset, and gain to calibrate the color
smoothly and 64-gray level distinguishable.
Check all pre-setting 34 modes.
4.3 Adjustment of WHITE-D (B)
Apply a 1024*768 / 60Hz signal with white pattern, set
brightness control at 100%, and contrast control at 50%.
Adjust the R, G, B Sub-Gain, for the screen center, the
1931 CIE chromaticity (X, Y) co-ordinates shall be;
Use Minolta CA-110 for color coordinates and luminance check.
Luminance is > 200 Nits in the center of the screen when
brightness at 100% and
contrast set to 100% with original color.
4.4 Adjustment of sRGB
Apply a 1024*768 / 60Hz signal with white pattern, set
brightness control at 100%, and contrast control at 50%.
Adjust the R, G, B Sub-Gain, for the screen center, the
1931 CIE chromaticity (X, Y) co-ordinates shall be;
4.5 EEPROM presetting (B)
After finishing all the adjustment, set:
Brightness control to 100%
Contrast control to 50%
OSD position at middle of screen
COLOR ADJUST to 6500K color.
4.6 When adjustment is finished, monitor should be set to
6500K.
9300°K 6500°K
x (center) 0.283 ±0.020 0.313 ±0.020
y (center) 0.297 ±0.020 0.329 ±0.020
http://www.wjel.net

18 170C4/N4
Go to cover page
Safety Test Requirements
All units that are returned for service or repair must pass the
original manufactures safety tests. Safety testing requires both
and testing.Hipot Ground Continuity
HI-POT TEST INSTRUCTION
1. Application requirements
2. Test method
1.1 All mains operated products must pass the Hi-Pot test as
described in this instruction.
1.2 This test must be performed again after the covers have
been refitted following the repair, inspection or modification
of the product.
2.1 Connecting conditions
2.1.1 The test specified must be applied between the parallel-
blade plug of the mainscord and all accessible metal
parts of the product.
2.1.2 Before carrying out the test, reliable conductive
connections must be ensured and thereafter be
maintained throughout the test period.
2.1.3 The mains switch(es) must be in the "ON" position.
2.2 Test Requirements
All products should be HiPot and Ground Continuity tested as
follows:
Test 2820VDC 1700VDC Test current:
voltage (2000VAC) (1200VAC) 25A,AC
Test time:
Test time 3 seconds 1 second 3 seconds(min.)
(min.) Resistance
required:
Trip set at 100 uA 5 mA <=0.09+R ohm,
current for Max. R is the
(Tester) limitation; set resistance of
at 0.1 uA for the mains cord.
Min. limitation
Ramp set at 2
time seconds
Condition HiPot Test for HiPot Test for Ground Continuity
products where products where Test requirement
the mains input the mains input is
range is Full 110V AC(USA
range(or 220V type)
AC)
2.2.1 The test with AC voltage is only for production purpose,
2.2.2 The minimum test duration for Quality Control Inspector
must be 1 minute. No breakdown during the test.
2.2.3 The test voltage must be maintained within the specified
voltage + 5%.
2.2.4 The grounding blade or pin of mains plug must be
conducted with accessible metal parts.
Service center shall use DC voltage.
3. Equipments and Connection
4. Recording
3.1. Equipments
For example :
- ChenHwa 9032 PROGRAMMABLE AUTO SAFETY
TESTER
- ChenHwa 510B Digital Grounding Continuity Tester
- ChenHwa 901 (AC Hi-pot test), 902 (AC, DC Hi-pot test)
Withstanding Tester
3.2. Connection
Hipot and Ground Continuity testing records have to be kept for
a period of 10 years.
* Turn on the power switch of monitor before Hipot and
Ground Continuity testing.
Connect the "video cable"
or "grounding screw"
to the CLIP on your tester.
Video cable
(Rear view of monitor)
Connect the power cord
to the monitor.
Grounding screw
Power outlet
(ChenHwa 9032 tester)
Clip
Clip
http://www.wjel.net

19
170C4/N4
Display Adjustment
2.6 Switch light probe to Viewing position.
2.7 Move the Lens barrel forward or backward to get clear image as
shown in Fig. 4
2.8 Switch light probe to Measuring position. It should be able to
indicate colour value on the CA-110.
Measurement/viewing selectorMeasurement/viewing selector
Fig. 4
Clear image
2.9 Press buttons to select RGBof9300 and 6500.
Increase / decrease value by press or buttons until the
1931 CIE chromaticity ( x, y ) as below.
Menu
Up Down
Alignment hits:
1. R for x value , G for y value, B for Y value on the colour analyzer.
2. Must to select 9300 in user mode, then 9300 is available in factory
mode.
3. Must to select 6500 in user mode, then 6500 is available in factory
Mode.
3. NVRAM(24C16) Default Values:
Sub_Bri: 0 255
Sub_Con: 98 128 158
VCOM: 160
4. Factory Reset:
After finishing all the adjustment, select Factory Reset function to
Recall:
To leave factory mode by restart the monitor.
Display Adjustment:
Press and button simultaneously while power ON.
Adjust OSD menu to lower position of screen (i.g. adjust OSD H-
Position and OSD V-Position to 0 at OSD setup sub-menu. Then
press or button to move the cursor to
item ( see red circle on table 1). Press button to access to
factory mode (see table2.). Check CPU version if it is not right
version, then ISP new one (7301). After pre-check, aging 1 hour
at least. Programming Analog DDC data into Monitor. Check #
serial number to meet bar code label.
Menu Auto
Down Up Factory Entrance
Menu
Table 2. The content of Factory setting.see table 2.
Cursor can move on gray color area
1. Auto color adjustment:
Apply a 48.36kHz/60Hz signal with white pattern. Set brightness
at 100% and contrast at 50%. Move the cursor by pressing or
button to ( see red circle on table 2 ), press OK
button to do auto color, scaler would calibrate offset1,offset2 and
gain itself then display OK. Check the 64-gray level is
distinguishable.
Up
Down AutoColor
Table 1.
2. Color temperature adjustment:
Apply a 48.36kHz / 60Hz signal with white pattern.Set brightness
control at 100% and contrast control at 50%. Adjust the R.G.B
gain to reach special color temperature on center of screen.
Keep one color fixed gain to maximum at least.
2.1 Aim the probe CA-A30 at the center of screen as Fig. 1
2.2 Remove the lens protective cover of probe CA-A30.
2.3 Set Measuring/viewing selector to Measuring position for reset
analyzer. (Zero calibration) as Fig. 2
2.4 Turn on the colour analyzer (CA-110).
2.5 Press 0-CAL button to start reset analyzer. See Fig.3
HUDSON3 170C4 V200 2003010
<------Factory mode indicator
Table 2.
Measurement/viewing selectorMeasurement/viewing selector
cover (black)cover (black)
Fig. 1 Fig. 2
Fig. 3
0-CAL
9300°K 6500°K
x (center) 0.283 ±0.020 0.313 ±0.020
y (center) 0.297 ±0.020 0.329 ±0.020
5. EEPROM Presetting:
After finishing all the adjustment,Set:
Brightness control to 100%
Contrast control to 50%
OSD position at middle of screen.
Color Adjust to 6500K color.
When adjustment is finished,monitor should be set to 6500K.
Go to cover page
http://www.wjel.net

Go to cover page
X
20
170C4/N4
DDC Instructions
General
Pin assignment
Assignment Assignment
Pin No. Pin No.
Ground
Cable Detect
Ground
Bin
2
7
6
8
4
5
3
19
12
11
14
13
15
10
Red video ground
Blue video ground
Green video ground
DDC +5V or +3.3V
Ground-
Data clock line(SCL)
V.Sync
H.Sync / H=V
Serial data line(SDA)
G in , Syne. on green
Rin
A. 15-pin D-Sub Connector
DDC Data Re-programming
Analog DDC IC, & EEPROM
Additional information
In case the DDC data memory IC or main EEPROM which storage all
factory settings were replaced due to a defect, the serial numbers have
to be re-programmed" ".
It is advised to re-soldered DDC IC and main EEPROM from the old
board onto the new board if circuit board have been replaced, in this
case the DDC data does not need to be re-programmed.
Additional information about DDC (Display Data Channel) may be
obtained from Video Electronics Standards Association (VESA).
Extended Display Identification Data(EDID) information may be also
obtained from VESA.
1. An i486 (or above) personal computer or compatible.
2. Microsoft operation system Windows 95/98 .
Y o Install the EDID_PORT_Tool under Win2000/XP . As
Fig. 1 .
A. Cody the "UserPort.sys" to C:\WINNT\system32\drivers(win2000)
C:\WINDOWS\system32\drivers(winXP)
B. Running " io.exe" everytime, Before you start to programming
edid data .
4. A/D Alignment kits (3138 106 10079):
inclusion : a. Alignment box x1 (as Fig. 2)
b. Printer cable x1
c. (D-Sub) to (D-Sub) cable x1
Note: The EDID45.EXE is a windows-based program, which cannot
be run in MS-DOS.
System and equipment requirements
ou have t
3. EDID45.EXE program .
Note: The alignment box has already build-in a batteries socket for
using as power source. Pull out the socket by
remove four screws at the rear of box. Please do not forget that
remove batteries after programming. The energy of batteries can
only drive circuits for a short period of time.
batteries (5V)
Fig. 2Fig. 2
Fig. 1Fig. 1
1
5
6
10
11
15
To Monitor
D-sub cable
DC 5V
To Printer port
Power
indicator
Fig. 3Fig. 3
Ground
http://www.wjel.net
