Philips BDH5011 User manual

• 50”Flat Plasma Display
• High resolution (1366x768 -WXGA)
• Wide viewing angles
• Full motion video capability
• Color and brightness uniformity
• Full screen high brightness
• Remarkable contrast ratios
• Advanced Digital Image Processing
• 3:2 Pull-Down for Film Scan Conversion
• 3D Comb Filter
• Dual HD ComponentVideo Inputs
• Picture-in-Picture (PIP) and splitscreen
• HDTV Signal Compatible
• Digital Zoom Modes
• DVI DigitalVideo Interface with HDCP
• Built-in Internal Amplification & Speakers
• Excellent for Public Spaces & Meetingrooms
• Remote diagnostics and control (RS-232)
50” Plasma Monitor
BDH5011
BDH5011

BDH5011 Plasma Monitor
technical specifications
Connections
• DVI Input DVI-D 24 pin x 1
• RGB Input D-Sub 15-pin x 1
• RGB Output D-Sub 15 pin x 1
• Composite Input RCA-pin x 1
• S-Video Input Mini DIN 4-pin x 1
• ComponentVideo Input RCA-pin x 2
(Y/CB/CR,Y/PB/PR auto detect)
• Audio Input RCA-pin (L/R) x 6
• Audio Output RCA-pin (L/R) x 1
• RemoteTurn On 3.5mm Phono Plug + 12V
• RS-232 D-Sub 9-pin x 1
Features and specifications are subject to change without prior notice.
All trademarks acknowledged
Copyright© 2003 Philips Electronics NV
Specifications subject to change without notice
Philips Business Solutions
Glaslaan 2, building SFH-6 Tel.: [phone]
P.O. Box 80002 Fax: [phone]
5600 JB Eindhoven
The Netherlands www.philips.com
General
•BasicTechnology Plasma
•Visible Screen Diameter 50"
•Active Screen Area 43.56 x 24.49
1107 x 622mm
•Aspect Ratio 16:9
•Native Pixel Resolution 1366 x 768
•Pixel Pitch .81 x .81
•Brightness(cd/m2) 1000
•Contrast Ratio 1000:1
•Viewing Angle H/V(degrees) >160º
•De-interlacing 3:2/2:2 motion adaptive
•Digital Comb Filter 3D
•Displayable Colors 16.7 M,256 RGB levels
•ColorTemperature 3 preset+ User def.
Input Compatability
•Multiscanning VGA - SXGA
•Horizontal Scanning 15.5 - 91 kHz
•Vertical Scanning 50 - 85 Hz
•Max.Resolution 1280x1024 at 50-85Hz
•31 User Definable Modes (VGA,SVGA,XGA,SXGA,WXGA)
Regulations
•Safety UL-1950/6500
•EMC FCC class B, CE
•Display Data Channel DDC 2B (VESA)
The Philips Guarantee
The Philips range of advanced
plasma monitors combines
reliability and unsurpassed
performance with a host of
technological innovations.All of
which ensures that you enjoy an
impressive picture.What else do
you expect from the innovative
world leader in sound and vision
technology.
**The 5 CINCH connector accepts both RGB input
and component input
*** Product is strapped including pallet
**** Light output of a PDP module gradually
decreaes over long-term use.Do not display static
images for prolonged periods: otherwise phosphor
burn might appear on a part of the panel. Phosphor
burn is not covered by the warranty.
The plasma display panel consists of fine pixel
elements (cells).Although Philips produces these
plasma displays with more than 99.99% of their
cells active, there may be some cells that do not
produce light or remain lit after they should have
turned off.
Physical Specifications
•UPC Code BDH5011 0 37849 94263 5
•Unit Dimensions (WxHxD) 49.45" x 31.89" x 11.81" (incl stand)
1256 x 810 x 300 mm
49.45" x 30.0" x 4.23" (excl stand)
1256 x 762 x 107.5 mm
•UnitWeight 108 lbs / 49 kg mm (incl stand)
103.6 lbs / 47 kg mm (excl stand)
•Carton Dimensions (WxHxD) 56.54" x 44.29" x 18.5"
1436 x 1125 x 470 mm
•CartonWeight 132.2 lbs / 60 kg
•Power Supply 100V to 240V +- 10%
•Power Consumption 500W max. (all white pattern)
•Standby & DPMS 5W max.
•Temperature (operating) +0°C to +40°C/ 32°F to 104°F
•Temperature (storage) -20°C to +60°C/ -4°F to 140°F
•Operation Humidity 20% to 80%
•Acoustics (IHF A-weighted 1meter) 40dB Max.
Optional Accessories
•Wall Mount BM02411
Carton contains: BDH5011 Monitor,remote control,power cord,VGA cable
and users manual on CD.
Other Features
•On-screen Status Display Yes
•Side Control Keys Yes
•When the signal received by the Display exceeds the allowed range, a warning
message Signal Out Of Range shall appear on the screen.
•You can confirm the input signal format by selecting the Status page”
from the OSD Menu.
-Video 480p / 60 Hz
720p / 60 Hz
1080i / 60 Hz
No. Resolution Horizontal Vertical Refr.
Horizontal (KHz) Frequency (Hz) Frequency (MHz) Rate (Hz)
1 640x480 (VGA) 31.47 59.94 60
2 640x480 (VGA) 37.86 72.81 72
3 640x480 (VGA) 37.50 75.00 75
4 640x480 (VGA) 43.27 85.01 85
5 800x600 (SVGA) 35.16 56.25 56
6 800x600 (SVGA) 37.88 60.32 60
7 800x600 (SVGA) 48.08 72.19 72
8 800x600 (SVGA) 46.87 75.00 75
9 800x600 (SVGA) 53.67 85.06 85
10 1024x768 (XGA) 48.36 60.00 60
11 1024x768 (XGA) 56.48 70.07 70
12 1024x768 (XGA) 60.02 75.03 75
13 1024x768 (XGA) 68.68 85.00 85
14 1280x1024 (SXGA) 63.98 60.02 60
15* 1280x1024 (SXGA) 79.98 75.02 75
16* 1280x1024 (SXGA) 91.15 85.02 85
18 720x400 (DOS) 31.47 70.09 70
19 640x480 (VGA) 31.47 50.03 50
20* 1280x720p (HDTV) 45.00 60.00 60
21* 1920x1080i (HDTV) 33.75 60.00 60(i)
22 640x350 (VGA) 31.47 70.09 70
23 852x480 (WGA) 31.41 59.83 60
24 640x480 35.00 66.67 67
25 832x624 49.72 74.55 75
26 1152x870 68.68 75.06 75
27 1366x768 47.70 60.00 60
28 1360x768 47.37 59.96 60
29 848x480 29.64 60.00 60
30 1280x960 60.00 60.00 60
31 1280x960 85.94 85.00 85
•RGB loopthrough Yes
•TiltingWall Mount
•Ceiling Mount
•Twin Ceiling mount
Carton contains: BDH5011 Monitor,table-top stand,remote control,
power cord, VGA cable and users manual on CD.
