Philips BDL5231V User manual

Philips
LCD monitor
52"
multimedia HDTV monitor
BDL5231V
Impress and capture your audience
with a slim bezel 52" LCD
Deliver your message in the most demanding applications with this stylish 52" LCD
display. Whether used in a network environment, a tiled matrix set-up or as a single public
display, your audience will be astonished.
Optimised for public viewing
• Full HD LCD display, 1920 x 1080p
• Slim bezel design for a stylish look
• Enhanced zoom feature supports tiled matrix applications
• Projects a high brightness picture even in daylight
Operational flexibility for different applications
• Monitor is network controllable for remote management
• Smart insert in the back cover to place a small PC
Lower total cost of ownership
• SmartPower for energy saving
• Brightness automatically adjusts with ambient conditions
• Advanced anti-image sticking function
Sustainable and safe
• Complies with RoHS standards of care for the environment

BDL5231V/00
Highlights
LCD monitor
52" multimedia HDTV monitor
Full HD LCD display 1920 x 1080p
This display has a resolution that is referred to
as Full HD. The state-of-the-art LCD screen
technology has the full high definition
widescreen resolution of 1080 progressive
lines, each with 1920 pixels. This allows the
best possible picture quality for HD input
signals with up to 1080 lines. It produces
brilliant flicker-free progressive scan pictures
with optimum brightness and superb colours.
This vibrant and sharp image will provide you
with an enhanced viewing experience.
Slim bezel
A slim bezel design adds a stylish look to a
public display to blend in nicely in most
environments. Furthermore, this design is ideal
for tiled matrix video walls.
Zoom function for tiled matrix
The internal zoom function enables easy
implementation of a video wall matrix, without
the need for expensive external equipment.
Capable of a vidiwall of 25 displays by dividing
up to 5 displays each horizontally and
vertically.
High brightness
Allows daylight viewing even in large public
environments with high ambient light
conditions.
Network controllability: RS232
Network controllability allows user to control
and adjust monitors remotely through RS232
protocol.
Smart insert
Professional PCs are part of most public
signage installations. Quite often they add
additional depth to the public display and a lot
of cable clutter. This public display contains a
Smart insert in the back cover that will fit many
professional small form factor PCs. In addition,
it offers provisions for efficient cable
management.
SmartPower
The backlight intensity can be controlled and
pre-set by the system to reduce the power
consumption by up to 50%, which saves
substantially on energy costs.
Automatic brightness control
The adjustment of display settings to
correspond with ambient light without user
intervention.
Advanced anti-image sticking
Static images left on-screen for extended
periods of time may leave a "ghost image" or
image sticking effect on LCD displays.
Although image sticking on LCD displays is not
permanent, you want to prevent this
happening, especially in locations where
content is shown 24/7.
Compliant with RoHS standards
Philips designs and produces display products
in compliance with strict Restriction of
Hazardous Substances (RoHS) standards that
restrict lead and other toxic substances that
can harm the environment.
VIDIWALL
P
O
R
T
R
A
I
T
SMARTPOWER

Issue date 2010-08-24
Version: 6.2.3
12 NC: 8670 000 51498
EAN: 87 12581 47680 9
© 2010 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
VGA OUT
VGA INDVI-D IN
HDMI INAC IN YCb/Pb Cr/Pr OUT
IN
IN
S-VIDEO
AC
AC100-240V ~50-60Hz
VIDEO
COMPONENT
OUT
IN
OUT IN3IN2
AUDIO
IN1
L
R
++
--
LR
EXTERNAL SPEAKERS
()()
RS232C
652,5mm / 25,689” 705,5mm / 27,776”
1209,0mm / 47,598” 852,0mm / 33,543”
1156,0mm / 45,512” 200,0mm / 7,874”
174,6mm
6,874” 200,0mm / 7,874”
123,0mm
4,843”
M8
M4
200,0mm / 7,874” 200,0mm / 7,874”
100,0mm
3,937 ”
234,0mm / 9,213” 309,2mm / 12,173”
BDL5231V/00
Specifications
LCD monitor
52" multimedia HDTV monitor
Picture/Display
• Display screen type: LCD Full HD W-UXGA Act.
matrix
• Aspect ratio: 16:9
• Diagonal screen size: 52 inch / 132 cm
• Optimum resolution: 1920 x 1080 @ 60 Hz
• Brightness: 700 cd/m²
• Contrast ratio (typical): 4000:1
• Response time (typical): 8 ms
• Pixel pitch: 0.6 x 0.6 mm
• Display colours: 1.07 Billion colours
• Viewing Angle (H / V): 178 / 178 degree
• Horizontal Scanning Frequency: 31.5 - 91.1 kHz
• Vertical Scanning Frequency: 58 - 85 Hz
• Picture enhancement: 3/2 - 2/2 motion pull down,
3D Combfilter, Motion compens. deinterlacing,
Picture in Picture, Progressive scan, 3D MA
deinterlacing
Supported Display Resolution
•Computer formats
Resolution Refresh rate
640 x 480 60, 75 Hz
800 x 600 60 Hz
1024 x 768 60 Hz
1280 x 768 60 Hz
1360 x 768 60 Hz
1366 x 768 60 Hz
1600 x 1200 60 Hz
1900 x 1200 60 Hz (red. Blanking)
1920 x 1080 60 Hz
•Video formats
Resolution Refresh rate
480i 60 Hz
480p 60 Hz
576i 50 Hz
576p 50 Hz
720p 50, 60 Hz
1080i 50, 60 Hz
1080p 60 Hz
Connectivity
• PC: VGA-in D-Sub 15HD, VGA-out D-Sub 15HD,
DVI-D x 1, RS232 D-Sub9, RS232 D-sub9 output,
3.5 mm PC audio input x 1
• AV input: HDMI x 1, Component (YPbPr) x 1,
Audio (L/R) for YPbPr x 1, Composite (BNC) x 1,
Composite (CVBS) x 1, S-video x 1, Audio (L/R) x
2 for CVBS and S-Vid
• AV output: Audio (L/R) x 1, Composite (BNC) x 1
• Connectivity Enhancements: External Loudspeaker
connector
Convenience
• Network controllable: RS232
• VESA Mount: MIS-F 400 x 400 mm (Set), MIS-D
100 x 100 mm (Smart insert)
• Placement: Portrait, Landscape
• OSD Languages: English, French, German, Italian,
Spanish, Polish, Turkish, Russian, Simplified
Chinese
• Regulatory approvals: CE Mark, RoHS, UL, FCC
Class B, CCC
Sound
• Built-in speakers: 2 x 5 W (8 ohm)
• Detachable speakers: 2 x 7 W (8 ohm)
Power
• Mains power: 90-264 VAC, 50/60 Hz
• Consumption (On mode): 235 W (typical)
• Standby power consumption: < 1 W
Dimensions
•Setdimensions(Wx H x D):
1209 x 705.5 x 123 mm
• Set dimensions in inch (W x H x D):
47.59x 27.77 x 4.85 inch
• Set dimensions with stand (H x D): 751 x 406 mm
•Setdimensionswithstand in inch (H x D):
29.57 x 15.95 inch
• Smart insert (WxHxD): 160 x 300 x 55 mm
• Smart insert in inch (WxHxD): 6.30 x 11.81 x 2.17
inch
•Bezel thickness: 2.6 cm/1.04 inch
• Product weight: 36.5 kg
• Product weight (lb): 81.3
• MTBF: 50,000 hrs
Technical specifications
• Operating temperature range: 0 - 40 °C
• Relative humidity range: 5% - 90%
Accessories
• Included accessories: VGA cable, Remote Control,
Batteries for remote control, User manual on CD-
ROM, AC Power Cord, Quick start guide
• Optional accessories: Table stand BM05211,
Speakers BAL4631S1
Miscellaneous
• Bezel: metallic anthracite
• Warranty: Europe/North America: 3 years
•
