Philips FW-C500/37 User manual

GB
CLASS 1
LASER PRODUCT
COMPACT
DIGITAL AUDIO
Service Manual
Service
Service
Service
FW-C500/37
TABLE OF CONTENTS
Page
Location of pc boards & Version variations ................1-2
Technical Specifications .............................................1-3
Measurement setup ....................................................1-4
Service Aids, Safety Instruction, etc...........................1-5
Instruction for use ...................................................2-1
Disassembly Instructions & Service positions ...........3-1
Service Test Programs ...............................................3-4
Set Block diagram ......................................................4-1
Set Wiring diagram .....................................................4-2
Front Control Board ....................................................... 5
Front Display Board ....................................................... 6
ECO6 Tuner Board : Systems Non-Cenelec .............. 7A
ETF7 ND Tape Module .................................................. 9
3CDC-LC-MB-DA11 Module........................................ 10
Power 2001 Module (30-70W Version) ....................... 11
AF9 Board .................................................................... 12
Set Mechanical Exploded view & parts list ................. 13
©Copyright 2001 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise
without the prior permission of Philips.
Published by BB 0105 Service Audio Printed in The Netherlands Subject to modification
Mini System
3139 785 22650

1-2
LOCATION OF PRINTED CIRCUIT BOARDS
/37
Aux in /CDR in x
Line Out
Surround Out
Subwoofer Out
Digital Out
Matrix Surround
CD Text
Dolby B
RDS
News
Dolby Pro Logic (DPL)
Incredible Surround x
Karaoke Features
Voltage Selector
ECO Power Standby (Clock Display Off)
ECO6 Tuner Board - Systems Non-Cenelec x
ECO6 Tuner Board - Systems Cenelec
Center/Surround Channel
VERSION VARIATIONS:
Type /Versions: FW-C500
Features &
Board in used:
HEADPHONE
BOARD
ETF7
BOARD
MAINS
BOARD
POWER BOARD
MAINS SOCKET
BOARD
TUNER
BOARD
KEY-CDC BOARD
FRONT
DISPLAY
BOARD
IR-EYE
BOARD
VU
METER
BOARD
FRONT CONTROL
BOARD
AF9
BOARD
CD
BOARD

1-3
SPECIFICATIONS
GENERAL:
Mains voltage : 110-127V/220-240VSwitchable for /21/21M
120V for /37
220V for /33
220-230V for /22/34
230-240V for /30
Mains frequency : 50/60Hz
Power consumption : 10W at Standby
:100W at Active
Clock accuracy : < 4 seconds per day
Dimension centre unit : 265 x 310 x 390mm
TUNER:
FM
Tuning range : 87.5-108MHz
65.81-74MHz for /34 1)
Grid : 50kHz (& 30kHz for /34)
100kHz for /37
IF frequency : 10.7MHz ±25kHz
Aerial input : 75Ωcoaxial
300Ωclick fit for /37
Sensitivity at 26dB S/N : < 7µV
Selectivity at 600kHz bandwidth : > 25dB
Image rejection : > 25dB
Distortion at RF=1mV, dev. 75kHz : < 3%
-3dB Limiting point : < 8µV
Crosstalk at RF=1mV, dev. 40kHz : > 18dB
MW
Tuning range : 531-1602kHz
530-1700kHzfor/21/21M/37
Grid : 9kHz
10kHz for /21/21M/37
IF frequency : 450kHz ±1kHz
Aerial input : Frame aerial
Sensitivity at 26dB S/N : < 4.0mV/M
Selectivity at 18kHz bandwidth : > 18dB
IF rejection : > 45dB
Image rejection : > 28dB
Distortion at RF=50mV, m=80% : < 5%
LW
Tuning range : 153-279kHz /22
Grid : 3kHz
IF frequency : 450kHz ±1kHz
Aerial input : Frame aerial
Sensitivity at 26dB S/N : [< 7.0mV/M]
Selectivity at 18kHz bandwidth : [> 24dB]
IF rejection : [> 30dB]
Image rejection : [> 30dB]
Distortion at RF=50mV, m=80% : [< 5%]
AMPLIFIER:
Output power (6Ω, 60Hz-12.5kHz, 10% THD)
L & R : 2 x 50W FTC
Frequency response within -3dB : 40Hz-20kHz
Incredible Surround : ON/OFF
MAX Sound : ON/OFF
Digital Sound Control (DSC) : Digital, Rock, Pop,
Newage, Classic, Electric
Virtual Ambience Control (VAC) : Hall, Concert, Cinema,
Disco, Arcade, Cyber
Dynamic Bass Boost (DBB) : BEAT, PUNCH, BLAST,
DBB OFF
Input sensitivity
Aux in : 500mV ±3dB at 1kHz
CDR in : 1V ±3dB at 1kHz
Output sensitivity
Headphone output at 32Ω:15mW ±2dB
CASSETTE RECORDER:
Number of track : 2 x 2 stereo
Tape speed : 4.76 cm/sec ±2%
Wow and flutter : < 0.4% DIN
Fast-wind/Rewind time C60 : 130 sec
Bias system : 75kHz ±10kHz
Rec/Pb frequency response within 8dB: 80Hz - 12.5kHz
Signal to Noise Ratio (Type I) : > 48dBA
COMPACT DISC:
Measurement done at output conn. of the CDC module.
Frequency response : < ±1.5dB for 20Hz-20kHz
Output Voltage (in Vrms) : 550mV ±2dB unloaded
Signal to Noise Ratio (A-weighted) : > 80dBA
Distortion at 1kHz : < 0.003%
Channel Unbalance : < ±1dB
Channel Separation (1kHz) : >60dB
De-emphasis : 0 or 15/50 mS (Switched by subcode
on the disc)
[....] Values indicated are for "ECO6 Cenelec Board" only.
1) Default setting is OFF, to switch on please refer page 3-4.

1-4
LF Generator
e.g. PM5110
Recorder
Use Universal Test Cassette CrO2 SBC419 4822 397 30069
LEVEL METER
e.g. Sennheiser UPM550
with FF-filter
S/N and distortion meter
e.g. Sound Technology ST1700B
L
R
DUT
or Universal Test Cassette Fe SBC420 4822 397 30071
LEVEL METER
e.g. Sennheiser UPM550
with FF-filter
S/N and distortion meter
e.g. Sound Technology ST1700B
L
R
DUT
CD
Use Audio Signal Disc
(replaces test disc 3)
SBC429 4822 397 30184
Bandpass
250Hz-15kHz
e.g. 7122 707 48001
LF Voltmeter
e.g. PM2534
DUT
S/N and distortion meter
e.g. Sound Technology ST1700B
Frame aerial
e.g. 7122 707 89001
Tuner AM (MW,LW)
To avoid atmospheric interference all AM-measurements have to be carried out in a Faraday´s cage.
Use a bandpass filter (or at least a high pass filter with 250Hz) to eliminate hum (50Hz, 100Hz).
RF Generator
e.g. PM5326
Ri=50Ω
Bandpass
250Hz-15kHz
e.g. 7122 707 48001
LF Voltmeter
e.g. PM2534
DUT
RF Generator
e.g. PM5326
S/N and distortion meter
e.g. Sound Technology ST1700B
Use a bandpass filter to eliminate hum (50Hz, 100Hz) and disturbance from the pilottone (19kHz, 38kHz).
Ri=50Ω
Tuner FM
MEASUREMENT SETUP

SERVICE AIDS
Service Tools:
Universal Torx driver holder .................................. 4822 395 91019
Torx bit T10 150mm ............................................. 4822 395 50456
Torx driver set T6 - T20 ......................................... 4822 395 50145
Torx driver T10 extended ...................................... 4822 395 50423
Cassette:
SBC419 Test cassette CrO2 ................................. 4822 397 30069
SBC420 Test cassette Fe ..................................... 4822 397 30071
MTT150 Dolby level 200nWb/M ............................ 4822 397 30271
Compact Disc:
SBC426/426A Test disc 5 + 5A ............................ 4822 397 30096
SBC442 Audio Burn-in Test disc 1kHz ................. 4822 397 30155
SBC429 Audio Signals disc .................................. 4822 397 30184
Dolby Pro-logic Test Disc ...................................... 4822 395 10216
ESD Equipment:
Anti-static table mat - large 1200x650x1.25mm ... 4822 466 10953
Anti-static table mat - small 600x650x1.25mm ..... 4822 466 10958
Anti-static wristband .............................................. 4822 395 10223
Connector box (1MΩ)............................................ 4822 320 11307
Extension cable
(to connect wristband to conn. box) .................. 4822 320 11305
Connecting cable
(to connect table mat to conn. box) .................. 4822 320 11306
Earth cable (to connect product to mat or box) .... 4822 320 11308
Complete kit ESD3
(combining all above products) ......................... 4822 320 10671
Wristband tester .................................................... 4822 344 13999
1-5
HANDLING CHIP COMPONENTS

GB
WARNING
All ICs and many other semi-conductors are
susceptible to electrostatic discharges (ESD).
Careless handling during repair can reduce life
drastically.
When repairing, make sure that you are
connected with the same potential as the mass
of the set via a wrist wrap with resistance.
Keep components and tools also at this
potential.
F
ATTENTION
Tous les IC et beaucoup d’autres
semi-conducteurs sont sensibles aux
décharges statiques (ESD).
Leur longévité pourrait être considérablement
écourtée par le fait qu’aucune précaution n’est
prise à leur manipulation.
Lors de réparations, s’assurer de bien être relié
au même potentiel que la masse de l’appareil et
enfiler le bracelet serti d’une résistance de
sécurité.
Veiller à ce que les composants ainsi que les
outils que l’on utilise soient également à ce
potentiel.
ESD
D
WARNUNG
Alle ICs und viele andere Halbleiter sind
empfindlich gegenüber elektrostatischen
Entladungen (ESD).
Unsorgfältige Behandlung im Reparaturfall kan
die Lebensdauer drastisch reduzieren.
Veranlassen Sie, dass Sie im Reparaturfall über
ein Pulsarmband mit Widerstand verbunden
sind mit dem gleichen Potential wie die Masse
des Gerätes.
Bauteile und Hilfsmittel auch auf dieses gleiche
Potential halten.
NL
WAARSCHUWING
Alle IC’s en vele andere halfgeleiders zijn
gevoelig voor electrostatische ontladingen
(ESD).
Onzorgvuldig behandelen tijdens reparatie kan
de levensduur drastisch doen verminderen.
Zorg ervoor dat u tijdens reparatie via een
polsband met weerstand verbonden bent met
hetzelfde potentiaal als de massa van het
apparaat.
Houd componenten en hulpmiddelen ook op
ditzelfde potentiaal.
I
AVVERTIMENTO
Tutti IC e parecchi semi-conduttori sono
sensibili alle scariche statiche (ESD).
La loro longevità potrebbe essere fortemente
ridatta in caso di non osservazione della più
grande cauzione alla loro manipolazione.
Durante le riparazioni occorre quindi essere
collegato allo stesso potenziale che quello della
massa dell’apparecchio tramite un braccialetto
a resistenza.
Assicurarsi che i componenti e anche gli utensili
con quali si lavora siano anche a questo
potenziale.
“Pour votre sécurité, ces documents
doivent être utilisés par des spécia-
listes agréés, seuls habilités à réparer
votre appareil en panne”.
GB
Safety regulations require that the set be restored to its original
condition and that parts which are identical with those specified,
be used.
NL
Veiligheidsbepalingen vereisen, dat het apparaat bij reparatie in
zijn oorspronkelijke toestand wordt teruggebracht en dat onderdelen,
identiek aan de gespecificeerde, worden toegepast.
F
Les normes de sécurité exigent que l’appareil soit remis à l’état
d’origine et que soient utiliséés les piéces de rechange identiques
à celles spécifiées.
D
Bei jeder Reparatur sind die geltenden Sicherheitsvorschriften zu
beachten. Der Original zustand des Geräts darf nicht verändert werden;
für Reparaturen sind Original-Ersatzteile zu verwenden.
I
Le norme di sicurezza esigono che l’apparecchio venga rimesso
nelle condizioni originali e che siano utilizzati i pezzi di ricambio
identici a quelli specificati.
"After servicing and before returning set to customer perform a
leakage current measurement test from all exposed metal parts to
earth ground to assure no shock hazard exist. The leakage current
must not exceed 0.5mA."
CLASS 1
LASER PRODUCT
3122 110 03420
GB
Warning !
Invisible laser radiation when open.
Avoid direct exposure to beam.
S
Varning !
Osynlig laserstrålning när apparaten är öppnad och spärren
är urkopplad. Betrakta ej strålen.
SF
Varoitus !
Avatussa laitteessa ja suojalukituksen ohitettaessa olet alttiina
näkymättömälle laserisäteilylle. Älä katso säteeseen!
DK Advarse !
Usynlig laserstråling ved åbning når sikkerhedsafbrydere er
ude af funktion. Undgå udsaettelse for stråling.
1-6

2-1
3
3
FW-
MINI HIFI SYSTEM
DISC
CHANGE
OPEN• CLOSE
DC
3
CHANGER
ECO POWER
CD 1•2•3 FM•AM
CDR/ DVD
TAPE 1•2
PROG DUBBING REC
CLOCK•
TIMER
AUTO
REPLAY
STANDBY- ON
3
DISC DIRECT PLAY
DISC
3
CD SYNCHRO RECORDING
CD/ CD-R/CD
-RW COMPATIBLE
MUSIC LEVEL
INTERACTIVE VU METER
VOLUME
VOLUME
S
U
R
R
O
U
N
D
V
A
C
D
S
C
D
B
B
•
MAX BASS DYNAMIC AMPLIFICATION
CONTROL (DAC)
•
MAX BASS PORT
TA PE 1 TA PE 2
P
R
E
V
P
R
E
S
E
T
N
E
X
T
DEMO STOP/ CLEAR
PLAY•
PAUSE
S
E
A
R
C
H
•
T
U
N
I
N
G
MAX
SOUND
I
N
C
R
E
D
I
B
L
E
DISC
2
DISC
1
1 2 3
4 56
7 8
9 0 !
$ %
^
& % *
( ) ¡ ™
£
@
S
O
U
N
D
N
A
V
I
G
A
T
I
O
N
-
J
O
G
CD
TUNER
TAP E AUX
SOURCE
DISPLAY
#
7
English
Contents
General Information Environmental Information ................................ 8 Acknowledgement ............................................... 8 Supplied Accessories ........................................... 8 Safety Information ................................................ 8
Preparations Rear Connections .......................................... 9–10 Optional Connection ........................................ 10 Inserting batteries into the remote control .................................................................. 10 Controls Controls on the system and remote control ........................................................... 11–12
Basic Functions Plug and Play ........................................................ 13 Demonstration mode ........................................ 13 Switching the system on ................................... 14 Switching the system to Standby mode ........ 14 Switching the system to Eco Power Standby mode ..................................................... 14 Power Saving Automatic Standby .................... 14 Display mode ....................................................... 14 Volume Control .................................................. 14 Sound Navigation ........................................ 15–16
CD Operation
Discs for Playback .............................................. 17 Loading Discs ...................................................... 17 Disc Playback ....................................................... 18 Programming the disc tracks .................... 18–19 Repeat ................................................................... 19 Shuffle .................................................................... 19
Radio Reception Storing Preset Radio Stations ................... 20–21 Tuning to Preset Radio Stations ...................... 21 Erasing a Preset Radio Station ........................ 21
External Sources Listening to External Sources .......................... 21 Ta pe Operation/Recording
Ta pe Playback ............................................... 22–23 General Information on Recording ................ 23 Preparation for Recording ............................... 24 One Touch Recording ........................................ 24 CD Synchro Recording ..................................... 24 Dubbing Tapes ..................................................... 24 Clock/Timer
View Clock .......................................................... 25 Clock Setting ....................................................... 25 Timer Setting ................................................ 25–26 Sleep Timer Setting ............................................ 26 Specifications
........................................... 27
Maintenance
.............................................. 28
Troubleshooting
............................. 28
–
29

2-2
8
English
General Information
This system complies with the FCC rules, Part 15 and with 21 CFR 1040.10. Operation is subject to the following two conditions: – This device may not cause harmful interference, and – This device must accept any interference received, including interference that may cause undesired operation.
Environmental Information All unnecessary packaging has been omitted.We have tried to make the packaging easy to separate into three materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet). Your system consists of materials which can be recycled and reused if disassembled by a specialized company. Please observe the local regulations regarding the disposal of packaging materials, exhausted batteries and old equipment.
Acknowledgement Energy Star As an ENERGY STAR
R
Partner, Philips has determined that this product meets the ENERGY STAR
R
guidelines for energy efficiency (for model FW-C550 only).
Supplied accessories – Remote control – Batteries (two AA size) for remote control –AM loop antenna – FM wire antenna –AC power cord
Safety Information
●Before operating the system, check that the
operating voltage indicated on the typeplate (or the voltage indication beside the voltage selector) of your system is identical with the voltage of your local power supply. If not, please consult your dealer.
●Place the system on a flat, hard and stable
surface.
●Place the system in a location with adequate
ventilation to prevent internal heat build-up in your system. Allow at least 10 cm (4 inches) clearance from the rear and the top of the unit and 5 cm (2 inches) from each side.
●Do not expose the system, batteries or discs to
excessive moisture, rain, sand or heat sources caused by heating equipment or direct sunlight.
●If the system is brought directly from a cold to a
warm location, or is placed in a very damp room, moisture may condense on the lens of the disc unit inside the system. Should this occur, the CD player would not operate normally. Leave the power on for about one hour with no disc in the system until normal playback is possible.
●The mechanical parts of the set contain self-
lubricating bearings and must not be oiled or lubricated.
●When the system is switched to Standby
mode, it is still consuming some power. To disconnect the system from the power supply completely, remove the AC power plug from the wall socket.
9
English
Preparations
Rear Connections The type plate is located at the rear of the system.
A
Power Before connecting the AC power cord to the wall outlet, ensure that all other connections have been made. WARNING! –For optimal performance, use only the original power cable. –Never make or change connections with the power switched on. To avoid overheating of the system, a safety circuit has been built in. Therefore, your system may switch to Standby mode automatically under extreme conditions. If this happens, let the system cool down before reusing it (not available for all versions).
B
Antennas Connection Connect the supplied AM loop antenna and FM antenna to the respective terminals. Adjust the position of the antenna for optimal reception. AM Antenna
AM ANTENNA
Fix the claw to the slot
¶Position the antenna as far as possible from aTV,
VCR or other radiation source.
SPEAKERS 6Ω
R
+
–
L
–
+
AUX/
CDR
IN
AM ANTENNA
FM ANTENNA
AC
MAINS
LR
speaker
(right)
speaker
(left)
AC power cord
FM wire antenna
AM loop
antenna
A
B
C

2-3
10
English
Preparations
FM Antenna
1
2
¶For better FM stereo reception, connect an
outdoor FM antenna to the FM ANTENNA terminal.
C
Speakers Connection Front Speakers Connect the speaker wires to the SPEAKERS (FRONT) terminals, right speaker to "R" and left
speaker to "L", colored (marked) wire to "+" and black (unmarked) wire to "-".
1
¶Clip the stripped portion of the speaker wire as
shown. Notes: –For optimal sound performance, use the supplied speakers. – Do not connect more than one speaker to any one pair of
+
/
-
speaker terminals.
– Do not connect speakers with an impedance lower than the speakers supplied. Please refer to the SPECIFICATIONS section of this manual.
Optional Connection The optional equipment and connecting cords are not supplied. Refer to the operating instructions of the connected equipment for details.
Connecting other equipment to your system Connect the audio left and right OUT terminals of a TV,VCR, Laser Disc player, DVD player or CD Recorder to the AUX/CDR IN terminals. Note: – If you are connecting equipment with a monaural output (a single audio out terminal), connect it to the AUX/CDR IN left terminal. Alternatively, you can use a “single to double” cinch cable (still be mono sound).
Inserting batteries into the Remote Control
Insert two batteries (Type R06 or AA) into the remote control with the correct polarity as indicated by the +and -symbols inside the battery compartment.
1
2
CAUTION! – Remove batteries if they are exhausted or not to be used for a long time. – Do not use old and new or different types of batteries in combination. – Batteries contain chemical substances, so dispose of them properly.
11
English
Controls
(main system’s illustration on page 3)
Controls on the system and remote control
1
ECO POWER
– to switch the system on or to Eco Power
Standby mode (for model FW-C550 only).
2
STANDBY ON yy
yy
y
– to switch the system on or to Standby mode.
3
DISPLAY SCREEN
– to view the current status of the system.
4
DISC TRAY
5
DISC CHANGE
– to change disc(s).
6
DISC 1 / DISC 2 / DISC 3 (CD DIRECT)
– to select a disc tray for playback.
7
OPEN•CLOSE
– to open or close the disc tray.
8
INTERACTIVE VU METER
– to show the VU (volume unit) meter in music or
volume mode depending on the display mode selected.
9
VOLUME
– to increase or decrease the volume.
0
Tape Deck Operation AUTO REPLAY
– to select continuous playback in either AUTO
PLAY or ONCE mode only. DUBBING
– to dub a tape.
REC
– to start recording on tape deck 2.
!
SOUND NAVIGATION
–to select the desired sound feature : DSC,VAC,
or DBB.
@
JOG CONTROL
– to select the desired sound effect for the
selected sound feature. DSC .................. DIGITAL, ROCK, POP, NEWAGE,
CLASSIC or ELECTRIC.
VAC .................. HALL, CONCERT, CINEMA,
DISCO, ARCADE or CYBER.
DBB .................. BEAT, PUNCH or BLAST.
#
INCREDIBLE SURROUND (IS)
– to activate or deactivate the surround sound
effect.
$
MAX SOUND (MAX ON/OFF)
– to activate or deactivate the optimal mix of
various sound features.
%
ç
– to open the tape deck door.
^
TAPE DECK 2
&
TAPE DECK 1
*
SOURCE – to select the following: CD / (CD 1•2•3)
– to select disc tray 1, 2 or 3.
TUNER / (FM•AM)
– to select waveband : FM or AM.
TAPE / (TAPE 1• 2)
– to select tape deck 1 or 2.
AUX / (CDR/DVD)
–to select a connected external source :
CDR/DVD or AUX (auxiliary) mode.
(
n
–to connect headphones.
)
Mode Selection PLAY PAUSE ÉÅ for CD ................. to start or interrupt playback. for TAPE .............. to start playback. for PLUG & PLAY…(on the system only) to
initiate and start plug & play mode.
SEARCH•TUNING àá for CD ................. to search backward/forward. for TUNER ......... to tune to a lower or higher radio
frequency.
for TAPE .............. to rewind or fast forward. for CLOCK ....... (on the system only) to set the
hour.
DEMO STOP/CLEAR Ç for CD ................. to stop playback or to clear a
program.
for TUNER ........ to stop programming.
................................. to delete the preset radio
station.
for TAPE .............. to stop playback or recording.
................................. to reset tape counter number.
for DEMO ......... (on the system only) to activate/
deactivate the demonstration.
for CLOCK ....... (on the system only) to exit clock
setting or cancel timer.
for PLUG & PLAY…(on the system only) to exit
plug & play mode.
PREV / PRESET / NEXT íë for CD ................. to skip to the beginning of the
current, previous, or next track.
for TUNER ........ to select a preset radio station. for CLOCK ....... (on the system only) to set the
minute.
¡
DISPLAY
–to select different screen display mode :
NORMAL, MODE 1, MODE 2 or MODE 3.

2-4
12
English
Controls
≤ *
6 ! ¡ ∞
9 ) §
º
ª • ) 9
™ ≥
$
#
™
PROG (PROGRAM) for CD ................. to program disc tracks. for TUNER ........ to program preset radio stations. for CLOCK ....... (on the system only) to select 12-
or 24-hour clock mode.
£
CLOCK•TIMER
– to view the clock, set the clock or set the timer.
≤
MUTE
– to interrupt or resume sound reproduction.
∞
SLEEP
– to activate, deactivate or set the sleep timer.
§
REPEAT
– to playback track(s)/disc(s)/program repeatedly.
≥
SHUFFLE
– to playback all available discs and their tracks/
program in random order.
•
TIMER ON/OFF
– to activate or deactivate the timer.
ª
CLOCK
– to view the clock display.
º
B
– to switch the system to Standby mode. – to switch the system to Eco Power Standby
mode (for model FW-C550 only). Notes for remote control: – First, select the source you wish to control by pressing one of the source select keys on the remote control (CD 123 or TUNER, for example). –Then select the desired function (
É
,
í
,
ë
, for example).
13
English
Basic Functions
IMPORTANT! Before you operate the system, complete the preparation procedures. Plug and Play Plug and Play allows you to store all available radio stations automatically. If Plug and Play has not been installed
1
When you turn on the system, "AUTO INSTALL - PRESS PLAY" will be displayed.
2
Press PLAYÉon the system to start installation. ➜"INSTALL" will be displayed and followed by
"TUNER" and then "AUTO". ➜
PROG
will start flashing.
➜The system will search for all radio stations on the FM band, then the AM band. ➜All available radio stations with sufficient signal strength will be stored automatically. ➜The system will stop searching when all the available radio stations are stored or when the memory for 40 preset radio stations is used. ➜The last preset radio station will play when Plug and Play is completed. To reinstall Plug and Play
1
In Standby or Demonstration mode, press and hold PLAYÉon the system until "AUTO INSTALL - PRESS PLAY" is displayed.
2
Press PLAYÉagain to start installation. ➜All previously stored radio stations will be replaced.
To exit without storing the Plug and Play
●Press Çon the system.
Notes: – When the power is turned on, the disc tray may open and close to initialize the system. –If you do not complete Plug and Play installation, Plug and Play will be reinitiated the next time you turn on the power. – If no stereo frequency is detected during Plug and Play, "
CHECK ANTENNA
" will be
displayed. – During Plug and Play, if no button is pressed within 15 seconds, the system will exit Plug and Play mode automatically.
Demonstration mode The system has a demonstration mode that shows the various features offered by the system. To activate the demonstration
●In Standby mode, press and hold DEMO
STOPÇon the system until "DEMO ON" is displayed. ➜The demonstration will begin. To deactivate the demonstration
●Press and hold DEMO STOP Çon the system
until "DEMO OFF" is displayed. ➜The system will switch to Standby mode. Note: – Even if you remove the AC power cord and reconnect it to the wall socket, the demonstration will remain off until you activate it again.
FW-
MINI HIFI SYSTEM
ECO POWER
CD 1•2•3 FM•AM
CDR/ DVD
TAPE 1•2
PROG DUBBING REC
CLOCK•
TIMER
AUTO
REPLAY
STANDBY-ON
MUSIC LEVEL
INTERACTIVE VU METER
VOLUME
VOLUME
S
U
R
R
O
U
N
D
V
A
C
D
S
C
D
B
B
•MAX BASS DYNAMIC AMPLIFICATION
CONTROL (DAC)
•MAX BASS PORT
P
R
E
V
P
R
E
S
E
T
N
E
X
T
DEMO STOP/ CLEAR
PLAY•
PAUSE
S
E
A
R
C
H
•
T
U
N
I
N
G
MAX
SOUND
I
N
C
R
E
D
I
B
L
E
S
O
U
N
D
N
A
V
I
G
A
T
I
O
N
-
J
O
G
CD
TUNER
TAP E AUX
DISPLAY
SOURCE
