Philips FW-P78 User manual

S
O
U
N
D
N
A
V
I
G
A
T
I
O
N
S
O
U
N
D
N
A
V
I
G
A
T
I
O
N
COLOUR
CODED
w
a
k
e
u
p
/
s
l
e
e
p
t
i
m
e
r
KEY
33
KEY
33
FW-P78
Mini DPL Hi-Fi System
3 CD Changer with Dolby® Pro Logic Processor,
Five Loudspeakers,270WattsTotal Power &
Powered subwoofer
• 2 x 75Watts + 40 Watts + 2 x 20 Watts RMS Stereo
• 40Watts Powered Subwoofer
• 6-Speaker Dolby® Pro Logic Surround Sound System
• Sound Navigation and 26 Digital Sound Control modes
• 3-Step Dynamic Bass Boost
• 7-Band Spectrum Analyzer with 3 Display modes
• 3-Way Bass Reflex Speaker System with Detachable Grilles
• Magnetically Shielded (Front and Center Speakers)
• CD-Rewritable Compatible
• 40-Track CD Random Program
• AM/FM Stereo DigitalTuning with 40 Presets
• Dual LogicTape Deck with Auto Reverse
• Digital Recording Ready (digital and line out)
• Subwoofer ready
• Easy set for radio
• Energy Saving Standby mode (<2 watts)
• Bedroom Clock withWake-upAlarm + SleepTimer
• Easy Hook up via Color Coded Cables
• 33-Button Remote Control
• 4-Color Packaging

Sound Enhancement
2 x 75Watts + 40Watts + 2 x 20Watts
Dolby® Pro Logic Output Mode, 40 Watts
Powered Subwoofer
75 Watts L/R front, 40 Watts center, 20 Watts L/R rear
and 40 Watts subwoofer RMS power output power per
channel, at 6 Ohms, from 80Hz-16kHz, with no more
that 10%Total Harmonic distortion (THD).
6-Speaker Dolby® Pro Logic Surround Sound
System
Provides the current industry standard for home theater
sound fromVCR and laserdisc movies.The front left and right
speakers deliver detailed, directional sound as the center
channel speaker "steers" dialogue/vocal sound to where you
see the mouth moving - at the TV screen. Both surround
speakers add a greater sense of depth with special effects
and time delay, making every living room a home theater
with spaceships overhead, aliens behind the couch but no
gum on the floor. The subwoofer enhances this home
theater effect.
Magnetic Shielding
Left front, right front, and center speakers are all
equipped with magnetic shielding to prevent interference
with color television picture tube purity.
3-Way Bass Reflex Speaker System
Equipped with one 6 1/2" woofer for smooth low and mid
range reproduction, one 2 1/2" ferro-fluid cooled tweeter
and one 1" Polydome tweeter for crisp high tones.
Sound Navigation
The JOG SHUTTLE of this feature adds a new
dimensions in fine-tuning the sound settings to suit your
personal taste.
26-step Digital Sound Control
The feature offers 26 different sound settings based on 6
basic settings : (CLASSIC - 1 setting, ROCK - 5 settings,
VOCAL - 5 settings,TECHNO - 5 settings,OPTIMAL - 5
settings,JAZZ - 5 settings)
3-Step Dynamic Bass Boost (Beat,Punch, Blast)
Bass reproduction is essential for deep and rich music. 3
Step DBB offers the optimal level for any kind of music.
AM/FM Stereo DigitalTuner
State-of-the-art precision tuning system insures precise,
accurate station selection every time, along with the
greatest performance and reliability available.
Convenience
3-CD Changer with Motorized Drawer
Multi-disc play capability provides more than three hours
of continuous music.
CD-Rewritable Compatible
The player offers 100% playback guarantee of Cd-
Rewritable CD©s over the entire lifetime of the player.
Even CD-RW audio recordings on computers can be used.
Dual LogicTape Deck
Offer the ability to switch from one function, such as fast
forward,to another function,such as play,by remote control.
Auto Reverse
The feature employs an auto reverse mechanism to
sense the end of the tape and automatically reverse the
direction of tape travel in the PLAY mode providing an
uninterrupted, continuous flow of music without
manually flipping the cassette tape.
33-Button Remote Control
This infrared remote control operates volume +/–,all CD
functions (POWER, NEXT, PREVIOUS, PLAY, STOP,
PAUSE, SHUFFLE, REPEAT, PROGRAM, CD DIRECT 1, 2,
3, SIDE, F and G), AUX select,TUNER select,TAPE
1/2 select, TV select, SLEEP TIMER select and sound
enhancement features including MUTE, Surround,
Dynamic Bass Boost, Digital Sound Control and the
Dolby® Prologic mode select, Test Tone select, Balance
L/R,Center +/- and Rear +/-.
Easy Set
Press Standby `ON' for 5 secs to automatically program
40 tuner presets.
40-Random Channel Presets
Random memory presets allow pre-programming of up to
40AM and FM station frequencies into the tuner memory.
Auto Store
Automatically stores up to 40 preset FM orAM stations.
40-Track CD Random Program
Store up to 40 of your favorite CD track selections, from
one or multiple discs, to be played back in the order in
which they are programmed anytime you like.
AUX/Video Input
For connection of audio accessory pieces such as a LD or
DVD player,television,or external cassette deck.
Demo Mode
Functions always. Press "STOP" for 5 secs to interrupt
demo mode.
Direct Play Button
Allows you to select and play any CD in the carousel by
touching only one button.
ChangeWhile Play
Flexiblility of changing 2 discs while still listening to the
third disc being played.
One-Touch CD Synchro Recording
One button allows the cassette deck and CD player to
communicate with one another to synchronize the start
of a recording on an analog audio cassette deck with the
start of a CD or a CD program.
Repeat track
Repeat your favorite track.
Shuffle One/All Discs
Plays all selections on a particular disc or multiple discs in
multi-disc players in random order,ignoring the sequential
order in which they were originally recorded.
Next/Previous Skip
This two button feature offers you the opportunity to skip back
to the previous track or skip up to the next track instantly.
High-Speed Dubbing
High-speed dubbing makes it possible to create good
quality recordings (dubs) from one tape to another at
twice the normal speed in RECORD mode.
Easy Hook up with Color Coded Cables
Center - Blue/Black
Front - Red/Black
Rear - Grey/White
3 Dim Display modes (including nite mode)
2 different display options showing different amounts of
display activity can be selected and 1 nite mode display which
shows minimal display activity and turns most of the lights off.
UPC Code:0 37849 89359 3
Product Dimensions:
10.4"W x .12.2" H x 15.4" D (electronics)
9.4"W x 12.2" H x 12.4" D (speakers)
10.4"W x 5.5" H x 9.4" D (center speakers)
9.2" W x 4.1" H x 8.8" D (surround speakers)
7.9"W x 12.2" H x 14.6" D (subwoofer)
Package Dimensions:
39.3"W x 28.2" H x 14.3" D
Product weight: 61.7 lbs.
Carton contains: 3CD Changer Mini System, Subwoofer, Multi-Function
Remote Control,Batteries, Operating instructions,Warranty information
Printed in Singapore
Date printed : Oct 1999
©1999 Royal Philips Electronics N.V.
A Division of Philips Electronics North America Corp.
Specifications subject to change without notice.
Dolby® and Dolby® Pro Logic are trademarks of Dolby Laboratories
As an ENERGY STAR® Partner, Philips has determined that this product meets the
ENERGY STAR® guidelines for energy efficiency.
Clock/Timer and Sleeptimer
Set the alarm portion of a built-in digital clock to wake
you to music from your favorite CD or an AM/FM radio
station at any desired time of the day. Sleeptimer settings
of 60,45,30 or 15 minutes.
Stereo Headphone Jack
Design
Design Concept
The attractive and shelf appealing emphasis on the sound
control panel dominates and determines this range©s
character. The sound sontrol panel emphasis which
supports the entire sound story is reinforced by 2
distinctive rotaries (sound jog and volume) that builds
itself logically up the range with features, finishing, colours
and product design detail differentiation.
Uninterrupted display and cassette window lens set on a
strong underlying profile gives strong rational while the
use of appropriate backlighting, lightstrips and rings
coupled with choice colours evokes the emotional appeal.
Oversized,MultiColor,Digital FTD Display
This large display is easy to read at any distance with no
distortion or distraction and the multi-color format
makes it easy to recognize different functions at a glance.
Detachable Cloth Speaker Grilles
Detachable cloth covered grilles protect delicate speaker
components with rich, high-tech styling.
2
21 3
TAPE 1/2 AUXTUNERCD
TV
SLEEP TIMERDBB
PROGRAMREPEAT SHUFFLE
MUTE PAUSE TEST TONE
CD DIRECT
VOLUME
LDPL
BALANCE
CENTER REAR
á
à
ë
í
É
Ç
R
Å
DSC
-+-+
FW-P78
Mini DPL Hi-Fi System
