Philips FW-R8/17 User manual

Location of printed circuit boards . . . . . . . . . . . . . . . . . . . 1-2
Technical specification . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Measurement setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
RC-5 codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Brief operating instructions. . . . . . . . . . . . . . . . . . . . . . . . 2-4
Warnings & safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Service Testprogram . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Wiring Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Block/Leveldiagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Front Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Tuner Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Audio Frequency Board (AF7) . . . . . . . . . . . . . . . . . . . . . 8
Power Board. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 Disc Changer Module. . . . . . . . . . . . . . . . . . . . . . . . . . 10
CD R/W Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Exploded view of set. . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-1
Partslist of set. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-3
FW-R8/17/21/22
Published by HB 0015 Service Audio Printed in The Netherlands Subject to modification ©3103 785 25040
CDR Mini System
CLASS 1
LASER PRODUCT
©Copyright 2000 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval
system or transmitted, in any form or by any means, electronic, mechanical, photocopying,
or otherwise without the prior permission of Philips.
SERVICING
For servicing FW-R8, the set can be divided into two parts:
1.Except for the CD-R/W module the set has to be repaired on component level.
2.The CD-R/W module will be exchanged completely in case of a failure.
The defective CD-R/W module has to be returned for central repair.
Available circuit descriptions: The Basics of Compact Disc Recordable/Rewritable 4822 725 25242
3rd generation Compact Disc Recording 3104 125 40100
Table of Contents

1-2
Location of Printed Circuit Boards
DESIGN FRONT BOARD
LED BOARD
FRONT BOARD
CDC KEY BOARD
MAINS BOARD
TUNER BOARD
AF7 BOARD
HEADPHONE BOARD
MIC. BOARD
DIG. SWITCH
BOARD
Location of PCB R8 2000 02 14

2-1
General:
Mains voltage : 120 / 240V switchable (for /21)
: 230V (for /22)
: 120V (for /37)
Mains frequency : 50 ~ 60Hz
Power consumption : 155W at 1/8 PRATED
: 350W at max output
:≤15W at Stand by
:≤2W at ECO Stand by
Tuner:
FM
Tuning range : 87.5MHz - 108MHz
Grid : 100kHz
IF : 10.7MHz
Aerial input : 75Ω
Sensitivity Mono : < 7µV (26dB S/N)
d (RF=1mV,∆f=75kHz) : 3% - typ. 2%
IF rejection : > 60dB
Image rejection : > 25dB
-3dB Limiting Point : < 23.5dBf
MW
Tuning range : 531kHz - 1062kHz
Grid : 9kHz
IF : 450kHz ±1kHz
Sensitivity at 26dB S/N : < 4.0mV/m
d (RF=50mV,m=80%) : < 5% - typ. 3%
IF rejection : > 45dB
Image rejection : > 28dB
Amplifier:
Output power : 2 x 100W at 6Ω
Headphone : 3.5mm stereo jack
Frequency response : 20Hz - 20kHz (-3dB) Limit
Equalizer : Digital Sound Control
Input sensitivity
Aux/Line : 500mV ±2dB
Microphone : 2.5mV ±2dB at 1kHz
CDC unit:
Frequency response within : 20Hz - 20kHz at ±3dB
Signal/Noise ratio : > 94dB (A-weighted)
Distortion at 1kHz,0dB : -90dB
Channel unbalance : < 0.3dB
Channel crosstalk at 1kHz : -60dB
De-emphasis : 0 or 15/50 µS
Laser
Output power : ≤500µW
Wave length : 780nm ±20nm
CDR unit:
CD Playback:
Frequency response within : 20Hz - 20kHz at ±3dB
Signal/Noise ratio : > 90dB (A-weighted)
Distortion at 1kHz,0dB : -80dB
Channel unbalance : < 1dB
Channel crosstalk at 1kHz : -60dB
De-emphasis : 0 or 15/50 µS
Analog recording - digital playback:
Frequency response within : 20Hz - 20kHz at ±3dB
Signal/Noise ratio : > 84dB (A-weighted)
Distortion at 1kHz,0dB : -77dB
Channel unbalance : < 1dB
Channel crosstalk at 1kHz : -60dB
De-emphasis : 0 or 15/50 µS
Laser
Output power : ≤1mW during reading
:≤20mW during writing
Laser class 3B
Wave length : 780nm ±20nm
Technical Specification

2-2
Measurement Setup
Bandpass
250Hz-15kHz
e.g. 7122 707 48001 LF Voltmeter
e.g. PM2534
DUT
RF Generator
e.g. PM5326
S/N and distortion meter
e.g. Sound Technology ST1700B
Tuner SW
To avoid atmospheric interference all AM-measurements have to be carried out in a Faraday´s cage.
Use a bandpass filter (or at least a high pass filter with 250Hz) to eliminate hum (50Hz, 100Hz).
Ri=50Ω
Aerial replacement
Capacitor
R=50Ω
Bandpass
250Hz-15kHz
e.g. 7122 707 48001 LF Voltmeter
e.g. PM2534
DUT
S/N and distortion meter
e.g. Sound Technology ST1700B
Frame aerial
e.g. 7122 707 89001
Tuner AM (MW,LW)
To avoid atmospheric interference all AM-measurements have to be carried out in a Faraday´s cage.
RF Generator
e.g. PM5326
Ri=50Ω
Low pass filter 22kHz
L
R
LEVEL METER
e.g. Sennheiser UPM550
with FF-filter
S/N and distortion meter
e.g. Sound Technology ST1700B
DUT
CD
Use Audio Signal Disc SBC429 4822 397 30184 (replaces test disc 3)
L.P.F. = 13 th order filter 4822 395 30204

2-3
RC5 Codes
Remote control key
ALARM
SLEEP
BRIGHTNESS
REPEAT
SHUFFLE
TRACK INCREMENT
VOLUME +
VOLUME -
3
8
w
∑
1
CD, CDR MODE
1 AUX, TUNER MODE
¡ CD, CDR MODE
¡ AUX, TUNER MODE
7
INCREDIBLE SURROUND
PURE
LOUDNESS
BALANCE L
BALANCE R
System Code
16
16
16
20, 26
20, 26
26
16
16
20, 26
20, 26
17,20, 21, 26
17,20, 21, 26
20, 26
17, 21
20, 26
17, 21
20, 26
16
16
16
16
16
Command Code
89
38
71
29
28
114
16
17
53
48
33
32
50
31
52
30
54
64
52
50
27
26
Remote control key
Standby
CD1
CD2
CD3
CDR
Tuner
Aux
1(ABC)
2 (DEF)
3 (GHI)
4 (JKL)
5 (MN)
6 (OPQ)
7 (RST)
8 (UVW)
9 (XYZ)
0 (Space)
YES
NO
EDIT (TEXT)
PROGRAM
PROGRAM
TUNER MODE
MUTE
System Code
17,20, 21, 26
20
20
20
26
17
21
17,20, 21, 26
17,20, 21, 26
17,20, 21, 26
17,20, 21, 26
17,20, 21, 26
17,20, 21, 26
17,20, 21, 26
17,20, 21, 26
17,20, 21, 26
17,20, 21, 26
17,20, 21, 26
17,20, 21, 26
17,20, 21, 26
20, 26
17
16
Command Code
12
55
56
57
63
63
63
01
02
03
04
05
06
07
08
09
00
87
49
82
36
122
13

2-4
Brief Operating Instructions
CONTROLS AND CONNECTIONS
6
1AC MAINS ~ ........................ After all other
connections have been
made
, connect the power
cord to the power outlet.
For optimal performance
use only the original
power cable.
2DIGITAL IN ...........................connect to the coaxial output
of a digital appliance
3DIGITAL OUT........................connect to the coaxial input
of a digital appliance
4SPEAKERS 6 ΩL/R .............connect to the supplied
speakers
5SUBWOOFER OUT ..............connect to the input of a
subwoofer
6AM AERIAL ..........................connect the supplied loop
antenna here
7FM AERIAL 300 Ω...............connect the supplied wire
antenna here
8AUX IN L/R ...........................connect to the analog audio
output of an additional
appliance
9LINE OUT L/R .......................connect to the analog audio
input of an additional
appliance
On the back
English
FMAERIAL
300Ω
AM
AERIAL
R
L
CDCHANGEOPEN/CLOSE
CD REWRITABLECOMPATIBLE • 3 CD CHANGER
DISPLAY
CDR
iR SENSOR
TUNER
DIGITAL/ANALOG
AUX
CDTEXT CLOCK/ TIMER
OPEN/CLOSE
MIC
MIC
LEVEL
12
5670!@#$%^
0&
( ) ¡ £ ≤ ∞ §
89
34
*
CD-TEXTEDITING
STANDBY
ON
CD 1
CD 2
CD 3
RECTYPE
EDIT
COMPILE CD
FINALIZE
ERASE
CD
CD
RECORD
FW-
R8
CD RECORDABLE
MINIHIFISYSTEM
L
ACMAINS
~
SPEAKERS6Ω
DIGITAL
OUT
DIGITAL
IN
L
R
LINE
OUT
AUX
IN
R
SUBWOOFER
OUT
DC
CHANGER
≥
•
º
™
ª
CDRECORDER
CONTROLS AND CONNECTIONS
7
0Source selection
CD 1, CD 2, CD 3 ..................selects the CD changer,
switches to CD 1, CD 2 or
CD 3
CDR........................................selects the CD recorder
TUNER...................................selects the tuner
DIGITAL / ANALOG AUX ....selects the input for an
additional appliance
!...............................................CD changer tray
@OPEN/CLOSE........................opens and closes the
CD changer tray
#CD CHANGE.........................selects the next disc tray
$...............................................display
%CD RECORDER.....................CD recorder tray
^ySTANDBY ON...................switches the unit on and to
standby
&DISPLAY ...............................selects display
information/text
*MIC LEVEL ...........................adjusts the microphone
volume
(MIC........................................microphone jack
)Multiple function control
Rotary control:
íJOG CONTROL ë........CDC, CDR: selects the
previous/next track
TUNER: selects the
previous/next preset tuner
station
Keys to press:
YES ........................................confirms a selection
áSEARCH..........................CDC, CDR: searches forward,
reviews the tracks in a
program, controls the cursor
in different menus
TUNER: tunes to a higher
radio frequency
ÉPLAY/PAUSE..................starts and interrupts
playback/recording
PROG.....................................opens/closes the program
menu
EDIT TEXT.............................enters/exits the text edit
menu
EDIT TRACK .........................enters/exits the track edit
menu
REC LEVEL............................enables the rotary control to
adjust the level for
recordings
ÇSTOP...............................stops CD play/record, closes
program memory
àSEARCH..........................CDC, CDR: searches
backward, reviews the tracks
in a program, controls the
cursor in different menus
TUNER: tunes to a lower
radio frequency
NO..........................................cancels a selection
¡FINALIZE...............................finalizes and unfinalizes
recordings
™REC TYPE..............................enters/exits the recording
menu
£RECORD
CD™CD..................................selects high speed recording
and automatic finalizing of
current CD
COMPILE CD ........................selects high speed recording
and automatic finalizing of
current program
≤ERASE ...................................erases recordings
∞Sound control
MASTER VOLUME ..............adjusts the volume
TREBLE .................................sets the treble level
PURE .....................................switches bass and treble
settings on/off
INCREDIBLE SURR..............creates an incredibly wide
stereo effect
LOUDNESS...........................boosts treble and bass
BASS.....................................sets the bass level
§p...........................................3.5 mm headphone jack
Note: Connecting the headphones will switch off the
speakers.
≥OPEN/CLOSE........................opens and closes the
CD recorder tray
•CD TEXT................................switches through CD text
information
ªCLOCK/TIMER......................selects the clock function,
activates and deactivates the
timer
ºiR SENSOR...........................sensor for the infrared
remote control
Note: You will recognize that various keys will be illuminated
on the unit depending on the different modes or
programs you are in. This is for your guidance in order
to facilitate the finding of the relevant keys for
selection.
On the front
English

2-5
Brief Operating Instructions
INSTALLATION
8
The type plate is located on the rear of the unit.
1Check whether the power voltage as shown on the type
plate corresponds to your local power voltage. If it does
not, consult your dealer or service organization.
2
Make sure all connections have been made before
switching on the power supply.
3Connect the supplied power cable to AC MAINS ~ and to
the power outlet. This switches on the power supply.
For optimal performance use only the original power
cable.
When the unit is switched to standby, it is still consuming
some power. To disconnect the unit from the power
completely, remove the power cable from the power outlet.
To avoid overheating of the unit, a safety circuit has
been built in. Therefore, your unit may disconnect
under extreme conditions. If this happens, switch the
unit off and let it cool down before reusing it.
The speaker connections are click-fit connectors. Use them as
shown below.
1Connect the colored (or marked) wire to the red terminal
and the black (or unmarked) wire to the black terminal.
2Connect:
– Left speaker to L (red and black)
– Right speaker to R (red and black)
AM antenna
The supplied loop antenna is for indoor use only.
1Fit the plug of the loop antenna to AM AERIAL as shown
below.
2Position the antenna as far as possible from a TV, VCR or
other radiation sources.
3Turn the antenna for optimum reception.
FM antenna
The supplied wire antenna can only be used to receive nearby
stations. For better reception we recommend using a cable
antenna system or an outdoor antenna.
1Open the FM AERIAL 300 Ωclick-fits by pushing the lever
down as shown below.
2Insert each wire of the antenna into one hole.
3Close the click-fits using the lever.
4Move the antenna in different positions for optimum
reception.
The unit complies with the FCC-Rules, Part 15 and with
21 CFR 1040.10. Operation is subject to the following
two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received,
including interference that may cause undesired
operation.
FMAERIAL
300
Ω
FMAERIAL
300
Ω
AM
AERIAL
Antenna connections
Speaker connections
Power
English
INSTALLATION
9
AUX IN L/R
It is possible to use an additional appliance, e.g. tape
recorder, TV or VCR, with the unit.
1Insert the red plug of a cinch cable to the red jack AUX IN R
and insert the white plug to the white jack AUX IN L.
2Connect the other end of the cinch cable to the audio
outputs of the additional appliance.
3Press DIGITAL / ANALOG AUX repeatedly to select the
analog input for the appliance.
yAUX Analog is displayed.
4Operate your appliance as usual and adjust volume and
sound with the unit.
Note: It is not possible to connect a turntable directly to
AUX IN L/R. If you wish to use a turntable with the
unit, you have to connect an amplifier to
AUX IN L/R on
the unit. Then connect the turntable to the amplifier.
LINE OUT L/R
You can use these outputs for playback or recording on any
analog audio equipment e.g. amplifier or tape recorder.
•Use a cinch cable to connect the analog audio inputs of the
additional appliance with LINE OUT L/R on the unit and
operate your appliance as usual.
DIGITAL IN
You can use this coaxial input for recordings from any digital
audio equipment with a digital coaxial output e.g. CD player
or DVD player.
1Use a coaxial cable to connect the coaxial output of the
additional appliance with DIGITAL IN on the unit.
2Press DIGITAL / ANALOG AUX repeatedly to select the
digital input for the appliance.
yAUX Digital is displayed.
3Operate your appliance as usual.
DIGITAL OUT
You can use this coaxial output for recordings on any digital
audio equipment with a digital coaxial input e.g. CD recorder.
•Use a coaxial cable to connect the coaxial input of the
additional appliance with DIGITAL OUT on the unit and
operate your appliance as usual.
A subwoofer can be used to enhance the bass performance of
your unit dramatically.
1Use a cinch cable to connect the input of the subwoofer
with SUBWOOFER OUT at the unit.
2Follow the instructions supplied with the subwoofer.
Connecting a subwoofer
Digital audio connectionsAnalog audio connections
English
L
DIGITAL
OUT
DIGITAL
IN
R
LINE
OUT
AUX
IN
L
R
SUBWOOFER
OUT
SPEAKERS 6Ω
SUBWOOFER
TAPE RECORDER
CD RECORDER
CD PLAYER
AM
AERIAL
FM AERIAL
300
Ω
AC MAINS
~
R
L

2-6
Brief Operating Instructions
REMOTE CONTROL
10
2...........................switches the unit to standby
CDR, TUNER, CD1,
CD2, CD3, AUX........selects the sources
Number/alphabet keys
1–0....................keys in numbers for tracks or stations
ABC – XYZ ........keys in letters for text
SPACE ...............keys in a space within the text
EDIT TEXT................enters the text edit menu
-VOLUME.............decreases the volume
+VOLUME.............increases the volume
É...........................starts playback/recording
í..........................CDC, CDR: selects the previous track
TUNER: selects the previous preset tuner
station
ë...........................CDC, CDR: selects the next track
TUNER: selects the next preset tuner
station
Ç...........................stops CD play/recording, closes program
memory
á...........................CDC, CDR: searches forward, reviews the
tracks in a program, controls the cursor in
different menus
TUNER: tunes to a higher radio frequency
à...........................CDC, CDR: searches backward, reviews
the tracks in a program, controls the
cursor in different menus
TUNER: tunes to a lower radio frequency
Å...........................interrupts playback/recording
YES ..........................selects a selection
NO ...........................cancels a selection
PROGRAM ...............opens/closes the program menu
SHUFFLE ..................plays tracks in random order
REPEAT ....................repeats a track, the entire CD(RW) or the
program
TRACK INCR............selects automatic or manual increment of
a track
TIMER ON/OFF........activates and deactivates the timer
SLEEP.......................activates the sleep timer
MUTE.......................mutes the sound
BRIGHTNESS...........controls the brightness of the display
L BALANCE..............adjusts the volume balance to the left
speaker
R BALANCE .............adjusts the volume balance to the right
speaker
LOUDNESS ..............boosts treble and bass
INCREDIBLE
SURROUND .............creates an incredibly wide stereo effect
PURE........................switches bass and treble settings on/off
Note: Always press the source key of the source you wish to
control (e.g.
CD1 ) before selecting the desired function
key (e.g.
SHUFFLE).
Open the battery compartment
of the remote control and insert
2 alkaline batteries, type AA
(R06, UM-3).
Do not use old and new or
different types of batteries in
combination.
Remove batteries if they are dead or if the remote control is
not to be used for a long time.
Batteries contain chemical substances, so they should
be disposed of properly.
Remote control batteries
Remote control buttons
English
CDR
CD3CD1TUNER CD2
TEXT
ABC DEF GHI
JKL MN OPQ
RST UVW XYZ
SPACE
AUX EDIT
VOLUME
NO YES
PROGRAM TRACK INCR.SHUFFLE REPEAT
TIMER ON/OFF SLEEP MUTE
BRIGHTNESS BALANCE
LOUDNESS INCREDIBLE PURE
SURROUND
LR
+
-
É
Ç
ë
0
8
5
2
9
6
3
7
4
1
2
ë
Å

DISPLAY
11
The display of the unit is divided into 3 sections, which show
you the following:
Information area
This area is used for feedback of the CD changer, CD recorder,
tuner frequencies, menu options, values and scrolling text
messages.
Status lights and flags
Flags
CD TEXT..........................CD text is available
CD TEXT EDIT ..................text edit menu is active
EDIT TRACK ....................track edit menu is active
REC X..........................record timer is selected
PROG ..............................program menu is active
X................................clock is selected
ALARM X.....................alarm timer is selected
SLEEP .............................sleep timer is selected
REPEAT DISC ...................selected disc is played repeatedly
REPEAT TRACK.................current track is played repeatedly
REPEAT ALL .....................all discs in the CD changer (or the
program) are (is) played repeatedly
SHUFFLE..........................either all tracks of the program or of
the loaded disc(s) in the CD changer or
CD recorder are played in random
order
CD Changer
........................number of disc trays loaded
É........................playback is activated
Å.........................playback is interrupted
CD 1, 2, 3.....................disc tray 1, 2 or 3 is selected and
loaded with a pre-recorded CD,
finalized CDR or CDRW
CD R 1, 2, 3..................disc tray 1, 2 or 3 is selected and
loaded with an unfinalized CDR
CD RW 1, 2, 3...............disc tray 1, 2 or 3 is selected and
loaded with an unfinalized CDRW
CD Recorder
COMPILE CDC .....current program is being recorded with
high speed dubbing and auto finalize
FM TUNER ..........FM station is being recorded
CD=CD ............current disc is being recorded with
high speed dubbing and auto finalize
AUX ...................material from an external source is
being recorded
É.........................playback is activated
Å.........................playback is interrupted
RECORDING IN PROGRESS ..recording in progress
.....status of recording progress is shown
CD..................................pre-recorded CD, finalized CDR or
CDRW inserted
CD R...............................unfinalized CDR inserted
CD RW............................unfinalized CDRW inserted
FINALIZE .........................(un)finalizing will start
MIC ................................microphone input is being used
ALC ................................auto level control is active
Tuner
STEREO ...........................FM station is being received in stereo
AUX
DIGITAL...........................digital input in use for external source
ANALOG..........................analog input in use for external source
Music calendar, sound lights and remote control
INCREDIBLE SURROUND....Incredible Surround is active
LOUDNESS ......................Loudness is active
PURE ..............................bass and treble settings are switched
off
...............................command from remote control is being
received
Music calendar
1–20..........................CDC, CDR: actual track number played,
number of tracks on a disc/program
TUNER: preset number of tuned
station
+................................CDC, CDR: disc or program contains
more than 20 tracks
TUNER: more than 20 radio stations
are stored
......spectrum analyzer
AM
PM
TIME
TRACKPRESET STEP TOTAL TRACK TIME
CD TEXT EDIT TRACK
TUNER
REC
PROG ALARM SLEEP
REPEAT SHUFFLE
DISC TRACK ALL
CD RECORDER
COMPILE CDC
FM TUNER
CD CD AUX
START
FINALIZE
MIC
ALC
FINISH
CD R W
RECORDING IN PROGRESS AUX
STEREO NEWS TA EON
DIGITAL ANALOG
20 4321
+
1098765
1514131211
19181716
CD CHANGER
CD R W
INCREDIBLE
SURROUND
LOUDNESS
PURE
AM
PM
TIME
TRACKTOTAL RECREMPRESET STEP TOTAL TRACK TIME
TUNER
CD RECORDER
COMPILE CDC
FM TUNER
CD CD AUX
START
FINALIZE
MIC
ALC
FINISH
CD R W
RECORDING IN PROGRESS AUX
STEREO
DIGITAL ANALOG
20 4321
+
1098765
1514131211
19181716
CD CHANGER
CD R W
INCREDIBLE
SURROUND
LOUDNESS
PURE
START FINISH
AM
PM
TIME
TRACKPRESET STEP TOTAL TRACK TIME
CD TEXT EDIT TRACK
TUNER
REC
PROG ALARM SLEEP
REPEAT SHUFFLE
DISC TRACK ALL
CD RECORDER
COMPILE CDC
FM TUNER
CD CD AUX
START
FINALIZE
MIC
ALC
FINISH
CD R W
RECORDING IN PROGRESS AUX
STEREO
NEWS TA EON
DIGITAL ANALOG
20 4321
+
1098765
1514131211
19181716
CD CHANGER
CD R W
INCREDIBLE
SURROUND
LOUDNESS
PURE
AM
PM
TIME
TRACKTOTAL RECREMPRESET STEP TOTAL TRACK TIME
TUNER
CD RECORDER
COMPILE CDC
FM TUNER
CD CD AUX
START
FINALIZE
MIC
ALC
FINISH
CD R W
RECORDING IN PROGRESS AUX
STEREO
DIGITAL ANALOG
20 4321
+
1098765
1514131211
19181716
CD CHANGER
CD R W
INCREDIBLE
SURROUND
LOUDNESS
PURE
AM
PM
TIME
TRACKTOTALRECREMPRESET STEP TOTAL TRACK TIME
CD TEXT EDIT TRACK
TUNER
REC
PROG ALARM SLEEP
REPEAT SHUFFLE
DISC TRACK ALL
CD RECORDER
COMPILE CDC
FM TUNER
CD CD AUX
START
FINALIZE
MIC
ALC
FINISH
CD R W
RECORDING IN PROGRESS AUX
STEREO
NEWS TA EON
DIGITAL ANALOG
20 4321
+
1098765
1514131211
19181716
CD CHANGER
CD R W
INCREDIBLE
SURROUND
LOUDNESS
PURE
AM
PM
TIME
TRACKTOTAL RECREMPRESET STEP TOTAL TRACK TIME
TUNER
CD RECORDER
COMPILE CDC
FM TUNER
CD CD AUX
START
FINALIZE
MIC
ALC
FINISH
CD R W
RECORDING IN PROGRESS AUX
STEREO
DIGITAL ANALOG
20 4321
+
1098765
1514131211
19181716
CD CHANGER
CD R W
INCREDIBLE
SURROUND
LOUDNESS
PURE

Display
English

2-7
Brief Operating Instructions
BASIC FUNCTIONS
12
•To switch the unit on press ySTANDBY ON on the unit.
•To switch the unit to standby press ySTANDBY ON
again on the unit (2on the remote control).
Important!
1) This system is designed for regular CD(RW)s.
Therefore, do not use any accessories such as disc
stabilizer rings or CD treatment sheets, etc. as offered
on the market, because they may cause jamming of
the changer mechanism.
2) Do not load more than one disc into one disc tray.
1 CD changer:
Press OPEN/CLOSE on the unit to open the CD changer tray.
yOpen CDC is displayed and the tray is opened.
CD recorder:
Press OPEN/CLOSE on the unit to open the CD recorder tray.
yOpen CDR is displayed and the tray is opened.
2
CD changer:
You can load up to three discs in the CD changer for
continuous playback without interruption.
Insert an
audio disc (printed side up) in the right disc tray.
• You can load another disc in the left disc tray.
• To insert a third audio disc, press CD CHANGE on the unit.
yThe CD carousel will rotate until the empty disc tray
is at the right hand side.
CD recorder:
Insert an audio disc (printed side up) in the tray.
3
CD changer:
Press OPEN/CLOSE on the unit again to close the tray.
yThe tray is closed and Reading is displayed.
yIf an unfinalized disc is inserted, Initializing will
be displayed.
yCD, the disc tray number, the total number of tracks and
the total playing time of the disc in the last selected disc
tray are displayed. The track numbers light up in the music
calendar.
CD recorder:
Press OPEN/CLOSE on the unit again to close the tray.
yThe tray is closed and Reading is displayed.
yIf an unfinalized disc is inserted, Initializing will
be displayed.
yCDR, the total number of tracks and the total playing time
of the disc are displayed. The track numbers light up in the
music calendar.
1Press ÉPLAY/PAUSE (Éon the remote control) to start
playback.
CD changer:
yCD, the disc tray number, the current track number and
elapsed playing time are displayed. The current track
number is also blinking in the music calendar.
CD recorder:
yCDR, the current track number and elapsed playing time
are displayed. The current track number is also blinking
in the music calendar.
• To switch through the following information, repeatedly
press DISPLAY on the unit:
yTrack number, remaining playing time of current track
yTrack number, remaining playing time of disc
yTrack number, actual playing time of current track
2Press ÇSTOP (Çon the remote control) to stop playback.
CD changer:
yCD, the disc tray number, the total number of tracks and
the total playing time of the disc are displayed.
CD recorder:
yCDR, the total number of tracks and the total playing
time of the disc are displayed.
• To switch through the following information, repeatedly
press DISPLAY on the unit:
yTotal number of tracks, total playing time of disc
yCD text is displayed.
•You can interrupt playback by pressing ÉPLAY/PAUSE
(Åon the remote control).
yThe time where playback was interrupted is blinking.
•To resume playback press ÉPLAY/PAUSE (Éon the
remote control) again.
Playing a CD(RW)
Loading the CD changer, CD recorder
Switching on, switching to standby
CD CHANGE OPEN/CLOSE
DISPLAY
CDR
iRSENSOR
TUNER
DIGITAL/ANALOG
AUX
CDTEXTCLOCK/TIMER
OPEN/CLOSE
MIC
MIC
LEVEL
CD-TEXT EDITING
STANDBY
ON
CD 1
CD 2
CD 3
REC TYPE
EDIT
COMPILECD
FINALIZE
ERASE
CD
CD
RECORD
FW-
R8
CDRECORDABLE
MINI HIFI SYSTEM
CD RECORDER
CDREWRITABLECOMPATIBLE•3CDCHANGER
DC
CHANGER
English
BASIC FUNCTIONS
13
Volume adjustment
• Adjust the volume by using MASTER VOLUME
(-VOLUME/+on the remote control).
yThe volume level in dB (decibel) is displayed.
Incredible Surround
Stereo sound is determined by the distance between the front
speakers. Incredible Surround enables you to enjoy an incredibly
wide stereo effect, regardless of the speakers’ distance.
• Press INCREDIBLE SURR. (INCREDIBLE SURROUND on the
remote control) to switch the surround sound effect either
on or off.
y INCREDIBLE SURROUND is shown and Incredible
Surround is displayed if the surround sound effect is on.
Note: The effect of Incredible Surround may vary with different
types of music.
Treble and Bass level adjustment
1Press TREBLE or BASS on the unit.
yThe volume rotary is activated to select the treble/bass
settings.
2Turn the volume rotary to adjust the treble or bass.
yTreble or Bass and the actual value (between –5
and +5) is displayed briefly.
Note: If the volume rotary is not turned for 5 seconds, it will
switch back to volume.
PURE
• Press PURE repeatedly to switch bass and treble settings
either on or off.
yPURE is shown and Pure is displayed if bass and treble
settings are switched off.
yOptimal is displayed if preset bass and treble
settings are switched on.
yPersonal is displayed if personal preset bass and
treble settings are switched on.
LOUDNESS
• Press LOUDNESS to switch loudness either on or off.
yLOUDNESS is shown and Loudness is displayed if
loudness is on.
MUTE
This feature allows you to temporarily switch off the sound
without switching off the unit.
1Press MUTE on the remote control to switch off the sound.
yMute is displayed and playback/recording will be
continued without sound.
2Press MUTE on the remote control again to switch on the
sound again.
Speaker balance
It is possible to adjust the relative volume balance between
the connected front speakers.
• Press L BALANCE or R BALANCE on the remote control to
adjust the relative volume of the left or right front speaker.
yBalance L (or R) and the actual volume of the left
(or right) front speaker are displayed.
yWhen the volume of both speakers is balanced,
Balance L=R is displayed.
The demo mode displays various features of the unit and will
start automatically.
•
If any source key is pressed:
yThe unit switches to the selected source.
If ySTANDBY ON is pressed:
yThe unit switches to standby. After a few seconds, the
demonstration will start again.
Cancelling the demo mode
•Keep ÇSTOP on the unit pressed for at least 3 seconds to
cancel the demo mode.
yThe demo mode is cancelled permanently. The unit
switches to standby. A few seconds later the unit
switches to an economy power save mode.
Demo mode
Sound control
English
RECTYPE
T
COMPILE CD
FINALIZE
ERASE
CD
CD
RECORD

2-8
Brief Operating Instructions
BASIC FUNCTIONS
14
• Press either CD 1, CD 2 or CD 3 to select a particular disc.
Selecting a track during playback
• Rotate íJOG CONTROL ë(pressíor ëon the remote
control) to skip to the beginning of the previous or next track
on the selected disc.
yPlayback continues with the selected track.
Selecting a track when playback is stopped
1Rotate íJOG CONTROL ë(pressíor ëon the
remote control) to skip to the required track number.
2PressÉPLAY/PAUSE (Éon the remote control) to start
playback.
yPlayback starts with the selected track.
Note: Instead of using í or ë on the remote control, you can
also directly key in the required track number by using the
numerical keys. For 2-digit numbers, press the keys in
rapid succession.
Searching for a passage during playback
1Keep àSEARCH or áSEARCH (àor áon the remote
control) pressed to find a particular passage in a backward
or forward direction.
ySearching is started and playback continues at a low
volume. After 3 seconds, the search speeds up with
volume muted.
2Release the key at the desired passage.
yNormal playback continues.
Note: During SHUFFLE , while repeating a track or while playing
a program, searching is only possible within the current
track.
Repeating a track, the disc or the program
1Repeatedly press REPEAT on the remote control during
playback to select either:
yREPEAT TRACK: The current track is played repeatedly.
yREPEAT DISC: The entire selected disc is played repeatedly.
yREPEAT ALL: All discs in the CD changer (or the program)
are (is) played repeatedly.
2Playback starts in the chosen mode.
3To return to normal playback, press REPEAT on the remote
control until the display indication disappears.
Note: REPEAT DISC is not possible during SHUFFLE or while
playing a program.
Playing tracks in random order
1Press SHUFFLE on the remote control during playback.
ySHUFFLE is shown and either all tracks of the program or
of the loaded disc(s) in the CD changer or CD recorder
are played in random order.
2To return to normal playback, press SHUFFLE again.
CD text
SHUFFLE and REPEAT
Selecting a track and searching
Selecting a disc on the CD changer
English
PROGRAM
15
You can select tracks and store them either in the CD changer
or CD recorder memory. If you use the program for playback
you can choose one of the two memories, else if you like to
specify tracks for recording, use the CD changer memory only!
You can store any track more than once.
1Load the desired disc(s) in the disc tray(s).
2Press either CD 1, CD 2, CD 3, or CDR to select the disc.
3Press PROG on the unit (PROGRAM on the remote control).
yPROG starts blinking and Program is displayed.
4
If either CD 1, CD 2 or CD 3 is selected:
Rotate íJOG CONTROL ëto select either:
yCD1 (or 2, 3)All: All tracks of CD 1 (or 2, 3) will be
programmed.
yCD1 (or 2, 3) and track number: The track number of
CD 1 (or 2, 3) will be programmed.
If CDR is selected:
Rotate íJOG CONTROL ë(press the numerical keys on
the remote control; for 2-digit numbers, press the keys in
rapid succession) to select a track number.
5Press YES to store your selection in the memory.
yThe number of programmed tracks (STEP), Prog and the
total program time are displayed. The track number
blinks in the music calendar.
6Select and store all desired tracks in this way.
7Press PROG on the unit (PROGRAM on the remote control)
to end programming.
yPROG stays shown and the program is currently
available.
Note: If the maximum number of programmable tracks is
reached, the display shows
Program full.
1If necessary, press ÇSTOP on the unit (Çon the remote
control) to stop playback.
2Press either CD 1, CD 2, CD 3, or CDR to select the desired
memory.
3Press PROG (PROGRAM on the remote control), followed by
àSEARCH or áSEARCH (àor áon the remote
control) to move through the program steps.
yThe track number at the selected step and the total
program time are displayed.
4Press NO to remove the track from the program.
yCleared is displayed briefly.
yThe next programmed track number will move up to this
position and is displayed together with the step number
and the remaining total program time.
1If necessary, press ÇSTOP on the unit (Çon the remote
control) to stop playback.
2Press NO.
yClear Prog? is displayed.
3Press YES to clear the program.
yProg Cleared will be displayed and PROG goes off.
Note: When you open the CD recorder tray or the CD changer
tray the respective program will be cleared.
1Select and store all desired tracks in the CD changer
memory (see “Programming track numbers”).
2Enter the recording menu (see “Internal recording”).
• If the total time of the program is of larger size than the
remaining recording time of the CDR(W):
yNot fitting! will be displayed briefly, followed by
the remaining recording time and Record Prog?
If you nevertheless start recording, only those tracks of the
program that fit onto the CDR(W) will be recorded in
entirety.
•To change the program, press NO.
yEdit Program will be displayed briefly, PROG and
the time of the program start blinking. Now you can
change the program (see “Programming track numbers”,
“Erasing a track from the program” and “Clearing the
program”).
Making a program for recording
Clearing the program
Erasing a track from the program
Programming track numbers
English
MIC
MIC
LEVEL
REC TY
PE
EDIT
COMPILECD
FINALIZE
CD
CD
RECORD

2-9
Brief Operating Instructions
ABOUT RECORDING
16
The CD recorder deck offers you 3 main functions:
– Recording from the internal CD changer and tuner or
from a selected external source
– Finalizing your CDR(W) discs and unfinalizing your
CDRW discs
– Erasing a CDRW disc
The recording procedure is the same for CDR and CDRW
discs.
Make sure the CDR(W) is absolutely free of
scratches and dust particles.
For recordings, the minimum track length is 4 seconds. You can
record up to a maximum of 99 tracks on a disc. The minimum
of recording time left on the disc is 7 seconds. Otherwise
Does not fit is displayed and you cannot enter the
record standby mode.
Copyright protection
The Serial Copy Management System (SCMS) prevents the
making of a digital copy from a digital copy. The system allows
making a digital recording from the original, however in some
countries this may require the authorization of copyright holders.
When you try to record copy protected material from an external
source, Copy Protect will be displayed. No further digital
recording is possible then.
When you try to record copy protected material from the
internal CD changer, no digital recording is possible, however
the CD recorder will automatically switch to analog recording.
Recording CD text
If the original CD has CD Text, this text will be recorded
automatically, provided that the CD text is not copy protected.
In that case, recording of CD text will not be possible and
Text Protect will be displayed.
The CD recorder is equipped with the high-performance Direct
Line Recording technique. It ensures a perfect recording of
the source material, meaning a true “bit for bit” recording.
DLR will always become active when you make normal
recordings in listen mode.
Auto Level Control ensures that the tracks on the recorded
disc have a similar volume level. At all times the already
recorded tracks of the CDR(W) disc will be taken as reference
for the volume level of the following recordings. ALC is active
when ALC is shown.
Auto level control becomes active when:
– COMPILE CD is being used,
– a disc, a track or a track edit is being high speed recorded
and the CDR(W) has recordings on it,
– a program (consisting from more than one disc) from the
CD changer is being high speed recorded, or
– CD™CD is being used and the CDR(W) has recordings on it.
Auto level control will not become active when:
– CD™CD is being used and the CDR(W) has no recordings
on it,
– making recordings from the FM tuner,
– making recordings from an external source, or
– making normal recordings in listen mode.
You can adjust the reference record level. This is also possible
when ALC is active. This feature can be used for fading your
recordings in or out.
1Keep REC LEVEL on the unit pressed to enable the rotary
control to adjust the record level.
2Turn the rotary control to the left to adjust the desired
record level.
yThe actual record level (in dB) will be displayed.
•The record level is reset after the unit has been switched to
standby.
REC LEVEL key
Auto Level Control (ALC)
Direct Line Recording (DLR)
DO NOT FORGET TO FINALIZE!
Finalizing a CDR(W) disc is a simple procedure, necessary to:
– play a recorded CDR on a standard CD player or
– play a recorded CDRW on a CDRW compatible CD player
and CD recorder.
Basic information
English
INTERNAL RECORDING
17
For internal recordings you can record from the internal
CD changer or tuner. You can choose from the following
recording modes:
– High speed recording and automatic finalizing:
Fast and easy! Record and finalize your CDR(W) in one
quick step while the sound is muted. You can record the
current CD or a program from the CD changer.
– High speed recording:
Record your CDR(W) fast while the sound is muted. You can
record an entire CD, a track, a program or a track edit from
the CD changer.
– Normal recording and listening:
Listen to the recording while you are making it. You can
record an entire CD, a track, a program or a track edit
from the CD changer.
– Manual recording:
Start and stop your recording manually while listening to
it. You can do either microphone recordings or radio
recordings from the FM tuner.
High speed recording and automatic finalizing of the
current disc
1Make sure the CDR(W) is absolutely free of scratches and
dust particles.
2Press CD™CD on the unit to enter the recording mode.
yBoth decks will be selected in the display, the arrow starts
blinking. The remaining recording time of the CDR(W), the
total playing time of the source CD and Record CD1
(or 2, 3)?are displayed.
3Press YES to start recording and finalizing.
yThe arrow lights, RECORDING IN PROGRESS is shown, high
speed recording and finalizing start, and the actual
recording time remaining starts to count down.
Note: If a program was already available before pressing
CD™CD , this will be ignored. PROG goes off and the
current disc will be recorded. After finishing the recording,
PROG is shown and the program is available again.
High speed recording and automatic finalizing
(optional) of the current program
1Make sure the CDR(W) is absolutely free of scratches and
dust particles.
2Press COMPILE CD on the unit to enter the record mode.
yBoth decks will be selected in the display, the arrow
starts blinking. The remaining recording time of the
CDR(W), the total playing time of the source CD and
Record Prog? are displayed.
3Press either:
YES to confirm,
or
NO to change the program.
yPROG starts blinking. Now you can change the program
(see “Program”) and return to the record mode by
pressing COMPILE CD.
4Auto Fin? is displayed.
Press either:
YES, if the CDR(W) is to be finalized after recording,
or
NO, if the CDR(W) is not to be finalized after recording.
yThe arrow lights, RECORDING IN PROGRESS is shown, high
speed recording and finalizing (if selected) start and the
actual recording time remaining starts to count down.
Note: If no program is available and you press COMPILE CD ,
you enter immediately into the program menu. Start
your programming and return to the record mode by
pressing
PROGRAM or COMPILE CD.
DO NOT FORGET TO FINALIZE!
Finalizing a CDR(W) disc is a simple procedure, necessary to:
– play a recorded CDR on a standard CD player or
– play a recorded CDRW on a CDRW compatible CD player
and CD recorder.
High speed recording and automatic finalizing
Recording modes
English
RECTYPE
EDIT
COMPILECD
FINALIZE
ERASE
CD
CD
RECORD

2-10
Brief Operating Instructions
INTERNAL RECORDING
18
High speed recording of an entire disc, a track, a
program or a track edit
1Make sure the CDR(W) is absolutely free of scratches and
dust particles.
2Press either CD 1, CD 2 or CD 3 to select the disc from
which you wish to record.
3Press REC TYPE on the unit to enter into the recording menu.
4Rotate íJOG CONTROL ëto select one of the
following high speed recording modes:
If a disc from the CD changer is selected:
yCD Fast?: for high speed recording of an entire disc
• Continue with step 5.
yTrack Fast?: for high speed recording of a track
• Press YES to confirm.
• Rotate íJOG CONTROL ëto select the track.
yRec Tr and the track number is displayed.
• Continue with step 6.
If CD changer program mode is available:
yProg Fast?: for high speed recording of the selected
disc or of the program
If CD changer track edit mode is available:
yA-B Fast?: for high speed recording of the A–B track
5Press YES to confirm your selection.
yBoth decks will be selected in the display, the arrow
starts blinking. The remaining recording time of the
CDR(W), the total recording time of the CDR(W) and
either Record CD1 (or 2, 3)?,Record Prog? or
Record A-B? is displayed.
Note: When the CDR(W) already contains a recording, ALC
will also become active and ALC will be shown.
6Press YES to start high speed recording.
yThe arrow lights, RECORDING IN PROGRESS is shown, high
speed recording starts and the actual recording time
remaining starts to count down.
• To stop recording, press ÇSTOP on the unit.
Normal recording and listening of an entire disc, a
track, a program or a track edit
1Make sure the CDR(W) is absolutely free of scratches and
dust particles.
2Follow steps 2 and 3 of “High speed recording”.
3Rotate íJOG CONTROL ëto select one of the
following normal record options:
If CD changer is selected:
yCD Listen?: for listening to the entire disc during
normal recording
yTrackListen?: for listening to the track during
normal recording
• Press YES to confirm.
• Rotate íJOG CONTROL ëto select the desired
track.
yRec Tr and the track number is displayed.
• Continue with step 6 of “High speed recording”.
If CD changer program mode is available:
yProg Listen?: for listening to the program during
normal recording
If CD changer track edit mode is available:
yA-B Listen?: for listening to the A–B track during
normal recording
4Follow steps 5 and 6 of “High speed recording”.
• To stop recording, press ÇSTOP on the unit.
DO NOT FORGET TO FINALIZE!
Finalizing a CDR(W) disc is a simple procedure, necessary to:
– play a recorded CDR on a standard CD player or
– play a recorded CDRW on a CDRW compatible CD player
and CD recorder.
Normal recording and listening
High speed recording
English
DISPLAY
CDR
iRSENSOR
TUNER
DIGITAL/ANALOG
AUX
CD TEXT CLOCK/TI
M
OPEN/CLOSE
MIC
MIC
LEVEL
CD-TEXTEDITING
STANDBY
ON
CD 1
CD 2
CD 3
RECTYPE
EDIT
COMPILECD
FINALIZE
ERASE
CD
CD
RECORD
FW-
R8
CDRECORDABLE
MINIHIFISYSTEM
CDRECORDER
INTERNAL RECORDING
19
Manual recording from the FM tuner
1Make sure the CDR(W) is absolutely free of scratches and
dust particles.
2Press TUNER repeatedly to select the FM tuner. Then select
the desired radio station (see “Tuning to radio stations”).
3Press REC TYPE on the unit to enter the recording menu.
yFM Tuner? is displayed.
4Press YES to confirm.
yWait and Record? are displayed.
5Press YES to start recording.
yThe arrow lights, RECORDING IN PROGRESS is shown,
manual recording starts and the actual recording time
remaining starts to count down.
6Press ÇSTOP to stop recording.
Manual microphone recording
1Make sure the CDR(W) is absolutely free of scratches and
dust particles.
2Set MIC LEVEL to the minimum level to prevent acoustic
feedback (e.g. a loud howling sound) before you connect
the microphone.
3Connect a microphone to MIC.
4Press CD 1, CD 2 or CD 3 to select the disc with which you
wish to mix the microphone.
5Press REC TYPE on the unit to enter the recording menu.
6Rotate íJOG CONTROL ëto select the manual recording
mode for the microphone:
yCD Mix Mic is displayed.
7Press YES to confirm.
yWait and Record? are displayed.
8Press YES to start recording.
9Rotate íJOG CONTROL ëto select the desired track.
yThe disc tray number, the current track number and
playing time of the track are displayed.
10 Press ÉPLAY/PAUSE to start playback.
yThe selected source is mixed with the microphone.
11 Press ÇSTOP to stop recording.
• To perform microphone recording only, see “Manual
recording” in chapter “External recording”.
DO NOT FORGET TO FINALIZE!
Finalizing a CDR(W) disc is a simple procedure, necessary to:
– play a recorded CDR on a standard CD player or
– play a recorded CDRW on a CDRW compatible CD player
and CD recorder.
Manual recording
English
DISPLAY
CDR
iRSENSOR
TUNER
DIGITAL/ANALOG
AUX
CD TEXT CLOCK/TI
M
OPEN/CLOSE
MIC
MIC
LEVEL
CD-TEXTEDITING
STANDBY
ON
CD 1
CD 2
CD 3
RECTYPE
EDIT
COMPILECD
FINALIZE
ERASE
CD
CD
RECORD
FW-
R8
CDRECORDABLE
MINIHIFISYSTEM
CDRECORDER

2-11
Brief Operating Instructions
EXTERNAL RECORDING
20
When making recordings from an external source, we
recommend to do analog recording only if digital recording is
not possible. Digital recording will usually result in better
sound quality.
Recording of an entire disc or a track with automatic
start
1Make sure the CDR(W) is absolutely free of scratches and
dust particles.
2Repeatedly press DIGITAL / ANALOG AUX to select the
input for the external source from which you want to record.
yAUX Digital is displayed if the digital input is
selected.
yAUX Analog is displayed if the analog input is selected.
3Press REC TYPE on the unit to enter the recording menu.
4Rotate íJOG CONTROL ëto select either:
yAUX CD?: for recording with synchronized start of an
entire disc
yAUX Track?: for recording with synchronized start of
a track
5Press YES to confirm your selection.
yStart Source,AUX and the remaining recording
time of the CDR(W) are displayed.
6Start playback on the selected source.
yThe CD recorder starts to record simultaneously and
RECORDING IN PROGRESS is shown. The remaining
recording time on the CDR(W) is displayed.
Note: If you start playback on the selected source within a
track, recording starts at the beginning of the next track
or after 2.7 seconds of silence in analog recordings.
7 If a digital source is selected:
After the recording process, the CD recorder stops
automatically.
Note: Recordings from DAT or DCC will automatically stop
after 20 seconds of silence.
If an analog source is selected:
At the end of the recording process, the CD recorder stops
after a silence of 20 seconds on the source material.
• To stop recording manually, press ÇSTOP on the unit.
yRECORDING IN PROGRESS goes off.
DO NOT FORGET TO FINALIZE!
Finalizing a CDR(W) disc is a simple procedure, necessary to:
– play a recorded CDR on a standard CD player or
– play a recorded CDRW on a CDRW compatible CD player
and CD recorder.
Recording with automatic start
Analog or digital recording?
English
DISPLAY
CDR
iRSENSOR
TUNER
DIGITAL/ANALOG
AUX
CD TEXT CLOCK/TIMER
OPEN/CLOSE
MIC
MIC
LEVEL
CD-TEXTEDITING
STANDBY
ON
CD 1
CD 2
CD 3
RECTYPE
EDIT
COMPILECD
FINALIZE
ERASE
CD
CD
RECORD
FW-
R8
CDRECORDABLE
MINIHIFISYSTEM
CDRECORDER
EXTERNAL RECORDING
21
Manual recording from an external source
1Make sure the CDR(W) is absolutely free of scratches and
dust particles.
2Repeatedly press DIGITAL / ANALOG AUX to select the
input for the external source from which you want to record.
yAUX Digital is displayed if the digital input is
selected.
yAUX Analog is displayed if the analog input is selected.
3Press REC TYPE on the unit to enter the recording menu.
4Rotate íJOG CONTROL ëto select the type of recording.
yAUX Manual?: for manual start of recording
5Press YES to confirm your selection.
yWait is displayed.
yRecord?,AUX and the remaining recording time of
the CDR(W) are displayed.
6Start playback on the external source in order to set the
optimal recording level on the CD recorder (see
“REC LEVEL key”).
7Stop playback on the external source.
8Go to the beginning of the desired track.
9Press YES on the unit and simultaneously start playback on
the external source.
yThe CD recorder starts to record and RECORDING IN
PROGRESS is shown. The remaining recording time of the
CDR(W) is displayed.
Note: If Check Input is flashing, check the digital
connection.
10 Press ÇSTOP on the unit to stop recording.
yUpdate is displayed and RECORDING IN PROGRESS goes off.
Manual microphone recording
1Make sure the CDR(W) is absolutely free of scratches and
dust particles.
2Set MIC LEVEL to the minimum level to prevent acoustic
feedback (e.g. a loud howling sound) before you connect
the microphone.
3Connect a microphone to MIC.
4Repeatedly press DIGITAL / ANALOG AUX to select the
input for the external source with which you wish to mix
the microphone.
yAUX Digital is displayed if the digital input is
selected.
yAUX Analog is displayed if the analog input is selected.
5Press REC TYPE on the unit to enter the recording menu.
6Rotate íJOG CONTROL ëto select the type of recording:
yAUX Mix Mic: the microphone is mixed with the
external source.
yMic Only: only the microphone is recorded.
7Press YES to confirm your selection.
yWait is displayed.
yRecord?,AUX and the remaining recording time of
the CDR(W) are displayed.
8Set the optimal recording level on the CD recorder (see
“REC LEVEL key”).
• In addition, you can also set the optimal recording level
of the microphone by turning MIC LEVEL.
9
If AUX Mix Mic is selected:
Press YES on the unit and simultaneously start playback on
the external source.
yThe CD recorder starts to record and RECORDING IN
PROGRESS is shown. The remaining recording time of the
CDR(W) is displayed.
If Mic Only is selected:
Press YES on the unit to start recording.
yThe CD recorder starts to record and RECORDING IN
PROGRESS is shown. The remaining recording time of the
CDR(W) is displayed.
10 Press ÇSTOP on the unit to stop recording.
yUpdate is displayed and RECORDING IN PROGRESS goes off.
DO NOT FORGET TO FINALIZE!
Finalizing a CDR(W) disc is a simple procedure, necessary to:
– play a recorded CDR on a standard CD player or
– play a recorded CDRW on a CDRW compatible CD player
and CD recorder.
Manual recording
English

2-12
Brief Operating Instructions
EXTERNAL RECORDING (UN)FINALIZING, ERASING
22
In recording mode, tracks will be incremented automatically so
that the track numbers are in the same position as the original.
•To switch the automatic track increment function on, press
as often as necessary TRACK INCR. on the remote control
during stop when CDR is selected.
yAuto Tr ON is displayed and the function is on. Track
increments are now automatically detected from digital
source material. In analog source material, a silence of
2.7 seconds or more is detected as a track increment.
•To switch the automatic track increment function off, press
as often as necessary TRACK INCR. on the remote control
during stop when CDR is selected.
yAuto Tr OFF is displayed and the function is off.
Track numbers can now be incremented manually by
pressing TRACK INCR. on the remote control during
recording. The minimum track length is 4 seconds.
Notes: – Track numbers cannot be changed after recording.
– The automatic track increment only works with
consumer sources with a digital output signal
according to the IEC 958 (consumer part) audio
standard. DAT, DVD and DCC do not deliver this
signal.
Finalizing a CDR(W) disc is a simple procedure, necessary to:
– play a recorded CDR on a standard CD player,
– play a recorded CDRW on a CDRW compatible CD player
and CD recorder,
– avoid further unwanted recordings on a disc, or
– avoid erasure of tracks on a CDRW.
Notes: – Finalizing will take about 2–4 minutes.
– After finalization of the CDR(W),
CDR(W) changes to
CD on the display.
– During finalization no other operating commands
can be executed.
Auto finalizing
When using either CD™CD or COMPILE CD, your recordings
will be finalized automatically (see “High speed recording and
automatic finalizing”).
Manual finalizing when recording is in progress
1Press FINALIZE on the unit during recording.
yAuto Final? is displayed.
2Press YES to confirm.
yFINALIZE is shown. The finalization will start after recording
and the actual finalizing time left will start to count down.
Manual finalizing when recording is stopped
1Insert the CDR(W) you want to finalize in the CD recorder tray.
2Press CDR to select the CD recorder.
3Press FINALIZE on the unit.
yFinalize? is displayed.
4Press YES to start finalizing.
yFINALIZE is shown, Final is displayed and the actual
finalizing time left starts to count down.
Finalizing CDR(W) discs
Automatic track increment
English
RECTYPE
EDIT
COMPILECD
FINALIZE
ERASE
CD
CD
RECORD
(UN)FINALIZING, ERASING
23
If you want to record (or erase) on (from) a finalized CDRW,
you have to unfinalize it first.
Notes: – Unfinalizing will take approximately 2 minutes.
– After unfinalizing of the CDRW,
CD changes to CDRW
on the display.
– When unfinalizing a CDRW with CD text on it
available, this text will be transferred to the
CD recorder memory. In case the memory is full, you
have to erase text (see
“ Erasing from the memory ”)
or to finalize another disc first in order to obtain
memory space.
1Insert the CDRW you want to unfinalize in the CD recorder
tray.
2Press CDR to select the CD recorder.
3Press FINALIZE on the unit.
yUnfinalize? is displayed.
4Press YES to start unfinalizing.
yUnfinal is displayed and the operation time remaining
starts to count down.
It is possible to erase one or more tracks (starting from the
end of the last track) or the entire CDRW.
Erasing an entire CDRW
1Insert the CDRW you want to erase in the CD recorder tray.
2Press CDR to select the CD recorder.
3Press ERASE to enter the erasing menu.
4Rotate íJOG CONTROL ëto select:
yErase Disc?: for erasing the entire disc
5Press YES to confirm your selection.
yErase?, the total playing time and the total number of
tracks to be erased are displayed. All track numbers will
blink in the music calendar.
6Press YES to start erasing.
yErase is displayed and the operation time remaining
starts to count down. The track number of the actual
erased track will go off in the music calendar.
Erasing one or more tracks
1Insert the CDRW from which you want to erase tracks in
the CD recorder tray.
2Press CDR to select the CD recorder.
3Press ERASE to enter the erasing menu.
4Rotate íJOG CONTROL ëto select the track number(s)
you wish to erase.
yErase and the track number (e.g. 10+)?are displayed.
•To select more tracks to be erased, repeat step 4.
Note: When erasing more tracks, the tracks to be erased
must be selected in sequence, starting from the last
recorded track. Example: The CDRW has 5 tracks
recorded on it. Now, you can erase tracks 5 and 4. You
can also erase tracks 5, 4 and 3, but you cannot erase
tracks 5 and 3!
yAll track numbers selected for erasing will blink in the
music calendar. The remaining track numbers light up.
5Press YES to confirm your selection.
yErase? is displayed.
6Press YES to start erasing.
yErase is displayed and the operation time remaining
starts to count down. The track number of the currently
erased track will go off in the music calendar.
Erasing from a CDRW disc
Unfinalizing CDRW discs
English
RECTYPE
EDIT
COMPILECD
FINALIZE
ERASE
CD
CD
RECORD

2-13
Brief Operating Instructions
FEATURES
24
Storing text during stop mode
After you have recorded your CDR(W) you can enter text, e.g.
names to discs and tracks. The text will be displayed during
playback. You can enter up to 60 characters per text field.
Only use an unfinalized CDR or CDRW (finalized CDRW must
be unfinalized first).
1If necessary, press ÇSTOP on the unit (Çon the remote
control) to stop playback.
2Press CDR to select the CD recorder.
3Press EDIT TEXT on the unit to enter the text edit menu.
yCD TEXT EDIT is blinking, Text Edit is displayed.
4Press YES to confirm.
5Rotate íJOG CONTROL ëto select either:
yAlbum Artist: for editing the CD artist.
yAlbum Title: for editing the CD title.
yArtist Tr 1 or (2,3,…): for editing the artist of
track 1 or (2, 3,…).
yTitle Tr 1 or (2,3,…): for editing the title of track 1
or (2, 3,…).
6Press YES to confirm the selection.
7Rotate íJOG CONTROL ë(press the alphabet keys on
the remote control) to select a character.
8Press YES to confirm the selection.
yThe cursor moves to the next character space.
9Repeat steps 7 and 8 for adding further characters.
10 Press EDIT TEXT to save the characters that have been
selected and to exit to the last position in the text editing
menu.
yUpdate is displayed.
Storing text during recording
You can store and edit text even while recording a single
track or single CD, or when recording from an external source
or tuner. Editing text during finalizing is not possible. Make
sure, when using high speed recording and automatic
finalizing, to enter the text before finalizing starts, otherwise
automatic finalizing will be cancelled.
•Follow steps 3–10 of “Storing text during stop mode”.
Note: Editing text is not possible when a copy protected track
is analog recorded. Editing is stopped,
CDText
Saved
is displayed and your text is saved for later
editing.
Auto copied text
When an artist’s name has been stored for a track, it will be
copied automatically into the next track.
•Press either:
EDIT TEXT to confirm the copied text,
or
NO to delete the copied text and enter new text.
Inserting a space
1Press àSEARCH or áSEARCH (àor áon the remote
control) to move to the position where the space is to be
inserted.
yThe position starts blinking.
2Press YES to confirm the position of the insert character.
yA space will be inserted, text will move to the right.
Deleting and substituting a character
1Press àSEARCH or áSEARCH (àor áon the remote
control) to move to the character’s position to be deleted or
substituted.
yThe character starts blinking.
2
If you want to delete the character:
Press NO.
yThe character is deleted and the text is shifted one
position to the left.
If you want to substitute the character:
Rotate íJOG CONTROL ë(press the alphabet keys on
the remote control) to select a new character.
Press YES to confirm the selection.
• To change another character, press àSEARCH or
áSEARCH (àor áon the remote control).
EDIT TEXT (on CD recorder only)
English
MIC
MIC
LEVEL
REC TY
PE
EDIT
COMPILECD
FINALIZE
CD
CD
RECORD
FEATURES
25
Erasing text
1Press EDIT TEXT to enter the text edit menu.
yCD TEXT EDIT is blinking, Text Edit is displayed.
2Rotate íJOG CONTROL ëto select the text erase menu.
yText Erase is displayed.
3Press YES to confirm.
4Rotate íJOG CONTROL ëto select one of the following:
yAll Text: All text of the selected disc is chosen to
be erased in one step.
yAlbum Artist: CD artist’s name is chosen to be
erased.
yAlbum Title: CD title is chosen to be erased.
yArtist Tr 1 or (2,3,…): artist’s name of track 1 or
(2, 3,…) is chosen to be erased.
yTitle Tr 1 or (2,3,…): title of track 1 or (2, 3,…)
is chosen to be erased.
5Press YES to confirm your selection.
yErase? or Erase All? is displayed.
6Press YES to start erasing.
yUpdate is displayed and the chosen text is erased.
Erasing from the memory
When the text memory of your CD recorder is full, the messages
Memory Full and Finalize Disc will be displayed. If
you still want to add a new disc to the text memory, you either
have to erase another disc from the memory or you have to
finalize another disc.
1Press EDIT TEXT to enter the text edit menu.
yCD TEXT EDIT is blinking, Text Edit is displayed.
2Rotate íJOG CONTROL ëto select the memory view
menu.
yText Memory is displayed.
3Press YES to confirm.
4Rotate íJOG CONTROL ëto select the disc you wish to
erase from the text memory.
5Press YES to confirm.
yErase Memory is displayed.
6Press YES to confirm the text erasure of that particular disc.
Note: If there are no discs stored in the text memory,
Memory Empty will be displayed.
You can create a “track” by marking a passage of music within
one track on the current disc. This new “track” can be used for
recording or playing. The minimum track length is 4 seconds.
1Press EDIT TRACK on the unit.
yEDIT TRACK starts blinking, Track and the current track
number ?are displayed. The current track number also
blinks in the music calendar.
2Rotate íJOG CONTROL ëuntil the desired track
number is displayed.
3Press YES to confirm the selected track.
yThe marker position Aand the track time will be
displayed. The first 4 seconds of the track will be played
continuously.
4Press ÉPLAY/PAUSE on the unit to play to the desired
start position of your new “track” (The initial position of
marker Ais always the start of the chosen track).
• To fast forward to the desired start position, press
àSEARCH or áSEARCH on the unit.
• To fine tune the position, first press ÉPLAY/PAUSE on the
unit, then rotate íJOG CONTROL ë.
5Press YES to confirm the position of marker A.
yThe marker position Band the new “track” time will be
displayed. The first 4 seconds before marker position B
until marker position Bwill be played continuously.
6Press ÉPLAY/PAUSE on the unit to play to the stop position
of your new “track” (the initial position of marker Bis always
the position of marker Aplus 4 seconds).
7Press YES to confirm the marked passage.
yEDIT TRACK is shown, A-B and the track edit time are
displayed.
Note: If you open the CD changer tray, the edit is deleted.
Clearing the track edit
1Press NO during stop.
yClear A-B? is displayed.
2Press YES to clear the markers.
yThe markers A-B are cleared.
Track editing (on CD changer only)
English

2-14
Brief Operating Instructions
TUNER
26
1Press TUNER to select the tuner.
yTuner is scrolled.
2Press TUNER again to select the desired waveband.
yThe selected waveband is displayed.
3Keep àSEARCH or áSEARCH (àor áon the remote
control) pressed for more than a half second.
yThe selected waveband and Searching are displayed.
The radio tunes to a station with sufficient signal strength.
4Repeat searching until you find the desired station.
• To tune to a weak station, briefly press àSEARCH or
áSEARCH (àor áon the remote control) as often as
necessary for optimum reception.
It is possible to store up to 40 radio stations. Stations can be
selected and programmed automatically or you can do that
yourself. Programming will overwrite your former presets
starting from the last active preset station. After programming
the last stored preset station will be tuned.
Automatic programming
If no preset is tuned, automatic programming starts at preset
number one.
1Follow steps 1 and 2 of “Tuning to radio stations”.
2Keep PROG (PROGRAM on the remote control) pressed for
more than 2 seconds.
yAutoprogram is displayed, PROG and the current
preset number in the music calendar start blinking.
yAll available radio stations for the selected waveband are
stored automatically. PROG goes off, the preset number,
the waveband and the frequency of the last preset station
are displayed briefly.
• To store radio stations for another waveband, repeat steps
1–2. Make sure to select the next available preset number
first before proceeding, otherwise already programmed
radio stations may be erased.
• To exit the automatic programming, press PROG (PROGRAM
on the remote control).
Note: Strong stations will always automatically be programmed
first, followed by the weak stations.
Manual programming
1Follow steps 1 and 2 of “Tuning to radio stations”.
2Keep PROG (PROGRAM on the remote control) pressed for
less than 2 seconds.
yPROG and the current preset number in the music
calendar start flashing.
3Press àSEARCH or áSEARCH (àor áon the remote
control) to tune to the desired radio station.
• To allocate the radio station to another preset number,
rotate íJOG CONTROL ë(pressíor ëon the
remote control).
4Press YES to confirm the setting.
yPROG goes off, the preset number, the waveband and
the frequency of the preset station are displayed.
• To exit manual programming, press PROG (PROGRAM on
the remote control).
• Use íJOG CONTROL ë(íor ëon the remote control)
until the preset number of the desired station is displayed.
Tuning to preset stations
Storing radio stations
Tuning to radio stations
English
DISPLAY
CDR
iRSENSOR
TUNER
DIGITAL/ANALOG
AUX
CD TEXT CLOCK/TI
M
OPEN/CLOSE
MIC
MIC
LEVEL
CD-TEXTEDITING
STANDBY
ON
CD 1
CD 2
CD 3
RECTYPE
EDIT
COMPILECD
FINALIZE
ERASE
CD
CD
RECORD
FW-
R8
CDRECORDABLE
MINIHIFISYSTEM
CDRECORDER
CLOCK/TIMER
27
Manual clock setting
1Press ySTANDBY ON as often as necessary on the unit to
switch the unit to standby.
2Press CLOCK/TIMER on the unit.
3Rotate íJOG CONTROL ëto select the clock.
yClock is displayed and Xstarts blinking.
4Press YES to confirm the selection.
yThe day of the week digit blinks.
5Rotate íJOG CONTROL ëto set the day.
6Use àSEARCH or áSEARCH on the unit to move from
day of the week to hour.
7Rotate íJOG CONTROL ëto set the hour.
8Repeat steps 6 and 7 to set the minutes.
9Press YES to confirm the settings.
Clock setting
English
DISPLAY
CDR
iRSENSOR
TUNER
DIGITAL/ANALOG
AUX
CD TEXT CLOCK/TIMER
OPEN/CLOSE
MIC
MIC
LEVEL
CD-TEXTEDITING
STANDBY
ON
CD 1
CD 2
CD 3
RECTYPE
EDIT
COMPILECD
FINALIZE
ERASE
CD
CD
RECORD
FW-
R8
CDRECORDABLE
MINIHIFISYSTEM
CDRECORDER

2-15
Brief Operating Instructions
CLOCK/TIMER
28
You can select different timer functions which will be activated
at a chosen time. Make sure the clock is set before using one
of these features.
Alarm timer setting
The unit can be used as an alarm clock, whereby the tuner,
CD recorder or CD changer starts playback automatically at a
preset time.
1Press ySTANDBY ON as often as necessary on the unit to
switch the unit to standby.
2Press CLOCK/TIMER on the unit.
3Rotate íJOG CONTROL ëto select the alarm timer.
yAlarm is displayed, ALARM is blinking.
4Press YES to confirm the selection.
yThe hour digit is blinking.
5Rotate íJOG CONTROL ëto set the hour.
6Use àSEARCH or áSEARCH on the unit to move from
hour to minutes.
7Rotate íJOG CONTROL ëto set the minutes.
8Press YES to confirm the time settings.
9Rotate íJOG CONTROL ëto select the source you want
to be woken up with.
10 Press YES on the unit to confirm the source selection.
• To stop the alarm, press ySTANDBY ON on the unit.
Record timer setting
The unit can do recordings automatically from an external
source or from a preset radio station at a preset time.
1Follow steps 1 and 2 of “Alarm timer setting”.
2Rotate íJOG CONTROL ëto select the record timer.
yRec Timer is displayed, REC is shown and Xstarts
blinking.
3Press YES on the unit to confirm the selection.
yThe hour digit for the start of recording blinks.
4Rotate íJOG CONTROL ëto set the hour of start of
recording.
5Use àSEARCH or áSEARCH on the unit to move from
hour to minutes of start of recording.
6Rotate íJOG CONTROL ëto set the minutes of start of
recording.
7Continue this procedure by using àSEARCH or
áSEARCH to move on to hour and minutes of end of
recording and to the day of the week. After each move,
always rotate íJOG CONTROL ëto do the settings.
8Press YES to confirm the settings.
9Rotate íJOG CONTROL ëto select from which you
want to record.
If you have chosen the tuner as source:
Rotate íJOG CONTROL ëagain to select a preset radio
station and confirm this selected station by pressing YES.
10 Press YES on the unit to confirm the source selection.
• To stop the recording press ÇSTOP on the unit.
• Press TIMER ON/OFF on the remote control repeatedly to
switch the alarm and/or record timer on or off:
yALARM is shown and Alarm ON is displayed when the
alarm timer is on.
yREC is shown and REC Timer ON is displayed when
the record timer is on.
yALARM and REC are shown, REC+Alarm ON is
displayed when the alarm and record timer are on.
yALARM and REC go off, REC+AlarmOFF is displayed
when the alarm and record timer are off.
You can set a certain period of time before the unit switches off.
1Press SLEEP on the remote control until the desired sleeper
time is displayed.
ySLEEP is shown and Sleep 60 min, 45 min, 30
min,15 min is displayed or, Sleep OFF is displayed.
2As soon as the desired time is displayed, do not press
SLEEP again.
yAfter the chosen time has elapsed, the unit switches to
standby.
• To deactivate the sleep timer, press SLEEP on the remote
control until Sleep OFF is displayed.
Sleep timer
Switching the alarm and record timer on/off
Record timer
Alarm timer
English
TECHNICAL DATA
29
Subject to modification without notice.
General
AC Power..............................................................120 V / 60 Hz
Power consumption
Active.........................................................................148 W
Standby.....................................................................< 30 W
Economy power save mode .......................................< 2 W
Dimensions, w ×h ×d ...........................10.4 ×12.2 ×15.6 in.
Weight (without speakers) ................................................11 kg
Amplifier
Output power................2 ×100 W FTC, 6 Ω, 1 kHz, THD 10%
Frequency response ................60–12,500 Hz FTC, +0.5/-1.5 dB
S/N ratio..............................................................≥80 dBA (IEC)
Input sensitivity
AUX IN L/R...............................................................800 mV
MIC...............................................................................1 mV
DIGITAL IN ..............................500 mVpp (75 Ω)/12–56 kHz
Output
Impedance speakers...................................................≥6 Ω
Impedance headphones..................................32 Ω–600 Ω
LINE OUT L/R ...........................................................500 mV
DIGITAL OUT ..............................500 mVpp (75 Ω)/44.1 kHz
SUBWOOFER OUT...........................................................1 V
CD changer
Number of programmable tracks............................................40
Frequency range ...................................................20–20,000 Hz
S/N ratio......................................................................≥92 dBA
Cross talk..........................................................≤-65 dB (1 kHz)
Total harmonic distortion..................................≤-94 dB (1 kHz)
CD recorder
Number of programmable tracks............................................99
CD playback
Frequency range.............................................20–20,000 Hz
S/N ratio playback................................................≥92 dBA
Cross talk....................................................≤-65 dB (1 kHz)
Total harmonic distortion ...........................≤-84 dB (1 kHz)
Analog recording, digital playback
Frequency range.............................................20–20,000 Hz
S/N ratio playback................................................≥86 dBA
Cross talk....................................................≤-65 dB (1 kHz)
Total harmonic distortion ...........................≤-81 dB (1 kHz)
Laser (CD recorder)
Type ..............................................Semiconductor laser GaAIAs
Wave length...........................................775–795 nm (at 25° C)
Output power............................2.5 mW (Read), 35 mW (Write)
Beam divergence........................................................60 degree
Tuner
Wave range
FM..............................................................87.5–108.0 MHz
AM................................................................530–1,700 kHz
Speakers
System............................................................3 way bass reflex
Impedance............................................................................6 Ω
Woofer ...........................................................................1 ×6.5"
Tweeter ...........................................1 ×2.5", Ferro fluid cooled
Tweeter ..........................................................1 ×1", Polydome
Dimensions, h ×w ×d .............................12.2 ×9.4 ×12.7 in.
Weight .....................................................................4.6 kg/each
English

2-16
Brief Operating Instructions
TROUBLESHOOTING
30
English
PROBLEM POSSIBLE CAUSE SOLUTION
No sound, Volume is not correctly adjusted. Adjust the volume.
no power Headphones are connected. Disconnect headphones.
Speakers are wrongly or not connected. Make sure speakers are properly connected.
Power cable is not securely connected. Connect power cable properly.
No reaction to Electrostatic discharge Disconnect the unit from power supply, then
controls reconnect after a few seconds.
Poor radio reception Weak radio signal Direct the antenna for optimum reception.
Antenna is positioned near a radiation source Change the position of the interfering unit or
such as a TV, VCR, computer, etc. try to switch it off.
Poor bass sound Speakers are not in phase. Connect the colored (or marked) wires to the
colored terminals and the black (or unmarked)
wires to the black terminals.
Bad sound Badly matched setting for the given type of Correct the sound settings on the unit.
music or sound.
Remote control does not Batteries are inserted incorrectly. Insert batteries correctly.
function properly Batteries are flat. Insert new batteries.
Distance to the unit is too large. Reduce distance.
Insert Disc indication The CD(RW) is scratched badly or dirty. Replace or clean the disc.
No CD(RW) inserted or inserted upside down. Insert a CD(RW), with label facing upwards.
The laser lens is steamed up. Wait until the lens has cleared.
Wrong Disc indication, No digital audio disc is inserted. Insert a digital audio disc marked with “Digital
Use Audio CD indication Audio” and the special logo.
Disc Recover indication Power loss Wait a few minutes. The disc is being repaired.
Disc Error indication Disc Recover was not able The disc can still be played, but not recorded
to repair the disc. or finalized further.
Check Input indication Wrong input is chosen. Select the correct input.
No correct digital source is detected after Make sure the connection cable is properly
starting recording. connected.
Does not record CDR(W) is scratched or dirty. Make sure the CDR(W) is absolutely free of
scratches and dust particles.
The inserted disc is not recordable. Insert a digital CDR(W) and make sure it is
unfinalized.
Recording process is interrupted (power Start recording again.
loss, mechanical shock).
Recorded disc does not The inserted CDR(W) is not finalized. Finalize the CDR(W).
play in another standard The CDRW is inserted in a non-CDRW Insert the CDRW in a CDRW compatible
CD player compatible CD player. CD player.
WARNING
Under no circumstances should you try to repair the
unit yourself as this will invalidate the guarantee. Do
not open the unit as there is a risk of electric shock.
If a fault occurs, first check the points listed, before taking
the unit for repair.
If you are unable to solve a problem by following these hints,
consult your dealer or service center.
LASER SAFETY
This unit employs a laser. Only a qualified service
person should remove the cover or attempt to service
this device, due to possible eye injury.

3-1
© WARNING
All ICs and many other semiconductors are susceptible to
electrostatic discharges (ESD). Careless handling during
repair can reduce life drastically.
When repairing, make sure that you are connected with the
same potential as the mass of the set via a wristband with
resistance. Keep components and tools at this potential.
f ATTENTION
Tous les IC et beaucoup d´autres semi-conducteurs sont
sensibles aux décharges statiques (ESD). Leur longévite
pourrait être considérablement écourtée par le fait qu´aucune
précaution nést prise à leur manipulation.
Lors de réparations, s´assurer de bien être relié au même
potentiel que la masse de l´appareil et enfileer le bracelet
serti d´une résistance de sécurité.
Veiller à ce que les composants ainsi que les outils que l´on
utilise soient également à ce potentiel.
d WARNUNG
Alle ICs und viele andere Halbleiter sind empfindlich
gegenüber elektrostatischen Entladungen (ESD).
Unsorgfältige Behandlung im Reparaturfall kann die
Lebensdauer drastisch reduzieren.
Sorgen Sie dafür, daß Sie im Reparaturfall über ein Puls-
armband mit Widerstand mit dem Massepotential des
Gerätes verbunden sind.
Halten Sie Bauteile und Hilfsmittel ebenfalls auf diesem
Potential.
ñ WAARSCHUWING
Alle IC´s en vele andere halfgeleiders zijn gevoelig voor
electrostatische ontladingen (ESD).
Onzorgvuldig behandelen tijdens reparatie kan de levensduur
drastisch doen vermindern. Zorg ervoor dat u tijdens reparatie
via een polsband met weerstand verbonden bent met hetzelfde
potentiaal als de massa van het apparaat.
Houd componenten en hulpmiddelen ook op ditzelfde potentiaal.
i AVVERTIMENTO
Tutti IC e parecchi semi-conduttori sono sensibili alle scariche
statiche (ESD).
La loro longevità potrebbe essere fortemente ridatta in caso di
non osservazione della più grande cauzione alla loro
manipolazione. Durante le riparationi occorre quindi essere
collegato allo stesso potenziale che quello della massa
delápparecchio tramite un braccialetto a resistenza.
Assicurarsi che i componenti e anche gli utensili con quali si
lavora siano anche a questo potenziale.
©
Safety regulations require that the set be restored to its
original condition and that parts which are identical with
those specified be used.
Safety components are marked by the symbol
i
Le norme di sicurezza estigono che l´apparecchio venga
rimesso nelle condizioni originali e che siano utilizzati i
pezzi di ricambiago identici a quelli specificati.
Componenty di sicurezza sono marcati con
ñ
Veiligheidsbepalingen vereisen, dat het apparaat in zijn
oorspronkeliijke toestand wordt teruggebracht en dat
onderdelen, identiek aan de gespecificeerde, worden toegepast.
De Veiligheidsonderdelen zijn aangeduid met het symbool
sVarning !
Osynlig laserstrålning när apparaten är öppnad och
spärren är urkopplad. Betrakta ej strålen.
∂Advarsel !
Usynlig laserstråling ved åbning når sikkerhedsafbrydere
er ude af funktion. Undgå udsaettelse for stråling.
ßVaroitus !
Avatussa laitteessa ja suojalukituksen ohitettaessa olet alttiina
näkymättömälle laserisäteilylle. Älä katso säteeseen !
f
"Pour votre sécurite, ces documents doivent être utilisés par
des spécialistes agréés, seuls habilités à réparer votre
appareil en panne".
ESD
SAFETY
d
Bei jeder Reparatur sind die geltenden Sicherheitsvor-
schriften zu beachten. Der Originalzustand des Gerätes
darf nicht verändert werden. Für Reparaturen sind Original-
ersatzteile zu verwenden.
Sicherheitsbauteile sind durch das Symbol markiert.
f
Les normes de sécurité exigent que l`appareil soit remis
à l`état d`origine et que soient utilisées les pièces de
rechange identiques à celles spécifiées.
Les composants de sécurité sont marqués
CLASS 1
LASER PRODUCT
© DANGER: Invisible laser radiation when open.
©
After servicing and before returning the set to customer
perform a leakage current measurement test from all
exposed metal parts to earth ground, to assure no
shock hazard exists.
The leakage current must not exceed 0.5mA.
AVOID DIRECT EXPOSURE TO BEAM.
© AVAILABLE ESD PROTECTION EQUIPMENT :
anti-static table mat large 1200x650x1.25mm 4822 466 10953
small 600x650x1.25mm 4822 466 10958
anti-static wristband 4822 395 10223
connection box (3 press stud connections, 1MΩ) 4822 320 11307
extendible cable (2m, 2MΩ, to connect wristband to connection box) 4822 320 11305
connecting cable (3m, 2MΩ, to connect table mat to connection box) 4822 320 11306
earth cable (1MΩ, to connect any product to mat or to connection box) 4822 320 11308
KIT ESD3 (combining all 6 prior products - small table mat) 4822 310 10671
wristband tester 4822 344 13999
Warnings & Safety

TORX T10 screwdriver with shaftlength 150mm ......................................4822 395 50423
TORX screwdriver set SBC 163..............................................................4822 295 50145
Audio signal disc SBC 429......................................................................4822 397 30184
Playability test disc SBC444...................................................................4822 397 30245
Test disc 5 (disc without errors) +
Test disc 5A (disc with dropout errors, black spots and fingerprints)
SBC 426/426A ....................................................................4822 397 30096
Burn in test disc (65 min. 1kHz signal at -30dB level without "pause")...4822 397 30155
3-2
Service Tools
Handling Chip Components
