Philips FWM452X/78 User manual

Register your product and get support at
www.philips.com/welcome
EN User manual
FWM452

2EN
English
Contents
1 Important 3
Safety 3
Notice 4
2 Your Mini Hi-Fi System 5
Introduction 5
What’s in the box 5
Overview of the main unit 6
Overview of the remote control 8
3 Get started 9
Connect FM antenna 9
Connect AM antenna 10
Connect speakers 10
Connect power 10
Prepare the remote control 11
Auto install radio stations 11
Set clock 11
Turn on 11
4 Play 12
Play disc 12
Play from USB 12
5 Play options 13
Repeat and random play 13
Program tracks 13
Display play information 13
6 Adjust volume level and sound
effect 14
Adjust volume level 14
Mute sound 14
Boost sound power 14
Select a preset sound effect 14
Enhance bass 14
Incredible surround 14
Customize sound for room acoustics 14
7 Listen to radio 15
Tune to a radio station 15
Program radio stations automatically 15
Program radio stations manually 15
Select a preset radio station 15
Change AM tuning grid 15
8 USB record 16
Record to USB 16
Record CDDA contents to a USB
device with high speed 16
Record CDDA contents to USB at
any playback time 16
Schedule radio-to-USB record 17
9 Other features 18
Set the alarm timer 18
Set the sleep timer 18
Listen to an external device 18
Delete from USB device 19
Karaoke 19
Adjust display brightness 19
10 Product information 19
Specifications 19
USB playability information 20
Supported MP3 disc formats 20
Maintenance 20
11 Troubleshooting 21

3
lUnplug this apparatus during lightning
storms or when unused for long periods
of time.
mRefer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus,
the apparatus has been exposed to rain
or moisture, does not operate normally,
or has been dropped.
nBattery usage CAUTION – To prevent
battery leakage which may result in
bodily injury, property damage, or
damage to the unit:
Install all batteries correctly, + and -•
as marked on the unit.
Do not mix batteries (old and new•
or carbon and alkaline, etc.).
Remove batteries when the unit is•
not used for a long time.
oApparatus shall not be exposed to
dripping or splashing.
pDo not place any sources of danger on
the apparatus (e.g. liquid filled objects,
lighted candles).
qThis product may contain lead and
mercury. Disposal of these materials
may be regulated due to environmental
considerations. For disposal or recycling
information, please contact your local
authorities or the Electronic Industries
Alliance: www.eiae.org.
rWhere the MAINS plug or an appliance
coupler is used as the disconnect device,
the disconnect device shall remain
readily operable.
1 Important
Safety
aRead these instructions.
bKeep these instructions.
cHeed all warnings.
dFollow all instructions.
eDo not use this apparatus near water.
fClean only with dry cloth.
gDo not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
hDo not install near any heat sources
such as radiators, heat registers, stoves,
or other apparatus (including amplifiers)
that produce heat.
iProtect the power cord from being
walked on or pinched, particularly at
plugs, convenience receptacles, and
the point where they exit from the
apparatus.
jOnly use attachments/accessories
specified by the manufacturer.
kUse only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination
to avoid injury from tip-over.
EN
English

4
packaging materials, exhausted batteries and
old equipment.
Windows Media and the Windows logo are
trademarks, or registered trademarks of
Microsoft Corporation in the United States
and/or other countries.
This apparatus includes this label:
Warning
Never remove the casing of this apparatus.•
Never lubricate any part of this apparatus.•
Never place this apparatus on other electrical•
equipment.
Keep this apparatus away from direct sunlight,
•
naked flames or heat.
Never look into the laser beam inside this
•
apparatus.
Ensure that you always have easy access to the
•
power cord, plug or adaptor to disconnect this
apparatus from the power.
Caution
Use of controls or adjustments or•
performance of procedures other than herein
may result in hazardous radiation exposure or
other unsafe operation.
Notice
Any changes or modifications made to this
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
The making of unauthorized copies of
copy-protected material, including computer
programs, files, broadcasts and sound
recordings, may be an infringement of
copyrights and constitute a criminal offence.
This equipment should not be used for such
purposes.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
EN
English

5
What’s in the box
Check and identify the contents of your
package:
Main unit x 1•
AC power cable x 1•
Loudspeaker box x 2•
Remote control x 1•
FM wire antenna x 1•
AM loop antenna x 1•
MP3 link cable x 1•
Quick start guide•
User manual•
2 Your Mini Hi-Fi
System
Congratulations on your purchase, and
welcome to Philips!To fully benefit from the
support that Philips offers, register your product
at www.Philips.com/welcome.
Introduction
With this unit, you can enjoy audio from discs,
USB devices, external devices, or radio stations.
For your convenience, you can load up to 3
discs at once.
To enrich sound, this unit offers you these
sound effects:
MAX sound for instant power boost•
Digital Sound Control (DSC)•
Dynamic Bass Boost (DBB)•
Incredible surround (IS)•
Virtual Ambience-based Control (VAC)•
The unit supports the following media formats:
EN
English

6
eSource selection keys
Select a source.•
fCLOCK
Set the clock.•
gSLEEP/TIMER
Set the sleep timer.•
Set the alarm timer.•
Turn on or off sleep/alarm timer.•
hVOLUME
Adjust volume.•
Overview of the main unit
a
b
d
c
e
f
g
h
j
k
i
l
n
m
p
q
o
x
w
v
u
r
s
t
o
r
z
y
aDISC 1/2/3
Select a disc.•
bDISC CHANGE
Change a disc.•
cDisplay panel
Show current status.•
d
Turn on the unit or switch to•
standby mode.
English
EN

7
wMODE
Select repeat play or random play.•
xDISPLAY
Select display information.•
yDisc compartment door
zOPEN/CLOSE
Open or close the disc•
compartment.
i/
Skip to the previous/next track.•
Search within a track/ disc/USB.•
Tune to a radio station.•
Adjust time.•
j
Stop play or erase a program.•
kALBUM/PRESET+/-
Skip to the previous/next album.•
Select a preset radio station.•
Adjust time.•
Select 12 hour or 24 hour format.•
lUSB DELETE
Delete audio files stored on a USB•
device.
mUSB RECORD
Record to a USB device.•
n
Jack for a USB mass storage device.•
oDSC
Select a preset sound equalizer•
setting.
pMP3 LINK
Audio input jack (3.5mm ) for an•
external audio device.
qDBB
Turn on or off dynamic bass•
enhancement.
rMIC VOL
Adjust microphone volume.•
sMAX SOUND
Turn on or off instant power boost•
for sound.
tMicrophone port
Jack for a microphone.•
u
Start or pause play.•
vPROG
Program tracks.•
Program radio stations.•
EN
English

8
dMODE
Select repeat play or random play.•
eUSB DELETE
Delete audio files stored on a USB•
device.
fTITLE+/- /
Skip to the previous/next track.•
Select a preset radio station.•
Adjust time.•
ALBUM +/-/ /
Skip to the previous/next album.•
Search within a track/ disc/USB.•
Tune to a radio station.•
Adjust time.•
Select 12 hour or 24 hour format.•
gDSC
Select a preset sound equalizer•
setting.
hMAX
Turn on or off instant power boost•
for sound.
iVOL +/-
Adjust volume.•
jDBB/IS
Turn on or off dynamic bass•
enhancement.
Turn on or off incredible surround.•
kNumeric keypad
Select a track from a disc directly.•
lPROGRAM
Program tracks.•
Program radio stations.•
mDISPLAY
Select display information.•
n
Stop play or erase a program.•
o
Start or pause play.•
Overview of the remote
control
a
b
e
f
h
g
i
j
k
l
m
o
n
p
r
s
t
q
d
c
a
Turn on the unit, or switch to•
standby mode.
bSource selection keys
Select a source.•
cCLOCK
Set the clock.•
English
EN

9
3 Get started
Caution
Use of controls or adjustments or•
performance of procedures other than herein
may result in hazardous radiation exposure or
other unsafe operation.
Always follow the instructions in this chapter in
sequence.
If you contact Philips, you will be asked for the
model and serial number of this apparatus.The
model number and serial number are on the
back of the apparatus.Write the numbers here:
Model No. __________________________
Serial No. ___________________________
Connect FM antenna
1Connect the supplied FM antenna to the
FM jack on the back of the main unit.
pVAC
Select an ambience-based equaliser•
setting.
qUSB RECORD
Record to a USB device.•
rMUTE
Mute volume.•
sDIM
Select different levels of display•
brightness.
tSLEEP/TIMER
Set the sleep timer.•
Set the alarm timer.•
Turn on or off sleep/alarm timer.•
EN
English

10
1Insert the wire completely.
Insert the right speaker wire to “• R”,
and left speaker wire to “L”.
Connect power
Caution
Risk of product damage! Ensure that the•
power supply voltage corresponds to the
voltage set on the voltage selector on the back
of the unit.
Before connecting the AC power cord, ensure
•
you have completed all other connections.
Note
The type plate is located on the back of the•
main unit.
1If your power supply voltage is 110V-127V,
adjust the voltage selector to 110V-127V.
2Connect the AC power cable to:
the main unit.•
the wall socket.•
Connect AM antenna
1Assemble the AM loop antenna.
2Connect the AM loop antenna to the AM
jack on the back of the main unit.
Connect speakers
Note
For optimal sound, use the supplied speakers•
only.
Connect only speakers with impedance that is
•
the same or higher than the supplied speakers.
Refer to the Specifications section of this
manual.
English
EN

11
The unit automatically stores radio»
stations with sufficient signal strength.
When all the available radio stations»
are stored, the first preset radio station
is broadcast automatically.
Set clock
1In the standby mode, press CLOCK to
activate the clock setting mode.
The 12 hour or 24 hour format is»
displayed.
2Press ALBUM +/- / repeatedly to
select 12 hour or 24 hour format.
3Press CLOCK to confirm.
The clock digits are displayed and»
begin to blink.
4Press ALBUM +/- / to set the hour.
5Press TITLE+/- / to set the minute.
6Press CLOCK to confirm.
Tip
To view the clock during play, press• CLOCK.
Turn on
1Press .
The unit switches to the last selected»
source.
Switch to standby
1Press to switch the unit to standby
mode.
The backlight on the display panel is»
dimmed.
The clock (if set) appears on the»
display panel.
Prepare the remote control
Note
Risk of explosion! Keep batteries away from heat,•
sunshine or fire. Never discard batteries in fire.
To replace the remote control battery:
1Open the battery compartment.
2Insert two AAA batteries (not supplied)
with correct polarity (+/-) as indicated.
3Close the battery compartment.
Note
If you are not going to use the remote control•
for a long time, remove the batteries.
Do not use old and new or different types of
•
batteries in combination.
Batteries contain chemical substances, so they
•
should be disposed of properly.
Auto install radio stations
When you connect power and no radio
stations are stored, the unit automatically begins
to store radio stations.
1Connect the unit to the power supply.
[AUTO INSTALL - PRESS PLAY] (auto»
install - press the PLAY button) is
displayed.
2Press on the main unit to start
installation.
[AUTO] (auto) is displayed.»
3
1
2
EN
English

12
Play from USB
Note
• Ensure that the USB device contains playable
audio contents for supported formats. (see
‘USB playability information’ on page 20)
1Plug the USB device into the socket of
this unit.
2Press USB to select the USB source.
3Press ALBUM +/- /to select a folder.
4Press TITLE+/- /to select an audio file.
5If the USB device doesn’t play, press .
To pause/resume play, press• .
To stop play, press• .
To search within an audio file, press•
and hold ALBUM +/- / , then
release to resume normal play.
4 Play
Play disc
1Press CD 1/2/3 to select the disc source.
2Press OPEN/CLOSE on the main unit to
open the disc compartment.
3Load up to two discs on the disc trays,
with the printed side facing up.
To load the third disc, press• DISC
CHANGE on the main unit to rotate
to the disc tray.
4Press OPEN/CLOSE on the main unit to
close the disc compartment.
Play starts automatically.»
To select a disc, press• DISC 1/2/3.
To pause/resume play, press• .
To stop play, press• .
To select another track, press• /
or press a numeric button.
To select an album, press• ALB/
PRESET+/-.
To search within a track, press and•
hold / , then release to resume
normal play.
2
2
1
1
English
EN

13
Display play information
1During play, press DISPLAY repeatedly to
select different play information.
5 Play options
Repeat and random play
1Press MODE repeatedly to select:
• : the current track is played repeatedly.
• : all tracks are played repeatedly.
• : all tracks are played
randomly and repeatedly.
• : all tracks are played randomly.
2To return to normal play, press MODE
repeatedly until play mode is no longer
displayed.
Tip
Shuffle play cannot be selected when you play•
programmed tracks.
Program tracks
You can program a maximum of 40 tracks.
1At CD/USB mode, in the stop position,
press PROGRAM to activate the
program mode.
[PROG] (program) is displayed.»
2For MP3/WMA tracks, press ALBUM
+/- /to select an album.
3Press TITLE+/- / to select a track
number, then press PROGRAM to
confirm.
4Repeat steps 2 to 3 to select and store all
tracks to program.
5Press to play the programmed tracks.
During play, [PROG] (program) is»
displayed.
To erase the program, in the stop•
position, press .
EN
English

14
Enhance bass
The best DBB (Dynamic Bass Enhancement)
setting is generated automatically for each
DSC selection.You can manually select the
DBB setting that best suits your listening
environment.
1During play, press DBB/IS repeatedly to
select:
DBB 1•
DBB 2•
DBB 3•
DBB off•
If DBB is activated,»DBB is displayed.
Incredible surround
You can enhance audio with a virtual surround
sound effect.
1Press and hold DBB/IS to turn on or off
the incredible surround.
If the incredible surround is activated,»
[INC SURR] (incredible surround) is
displayed.
Customize sound for room
acoustics
1During play, press VAC repeatedly to
select a type of listening environment:
[HALL] (hall)•
[CONCERT] (concert)•
[CINEMA] (cinema)•
6 Adjust volume
level and sound
effect
Note
MAX sound and DSC (Digital Sound Control)•
cannot be activated at the same time.
Adjust volume level
1During play, press VOL +/- to increase/
decrease the volume level.
Mute sound
1During play, press MUTE to mute/unmute
sound.
Boost sound power
MAX gives an instant boost to the sound
power .
1Press MAX to turn on or off the instant
power boost.
Select a preset sound effect
The DSC (Digital Sound Control) enables you
to enjoy special sound effects.
1During play, press DSC repeatedly to
select:
[JAZZ] (jazz)•
[POP] (pop)•
[TECHNO] (techno)•
[OPTIMAL] (optimal)•
English
EN

15
3Press TITLE+/- / to allocate a
number to this radio station, then press
PROGRAM to confirm.
4Repeat the above steps to program other
stations.
Tip
To overwrite a programmed station, store•
another station in its place.
Select a preset radio station
1In tuner mode, press TITLE+/- /to
select a preset number.
Tip
Position the antenna as far as possible from•
TV, VCR or other radiation source.
For optimal reception, fully extend and adjust
•
the position of the antenna.
Change AM tuning grid
In some countries, the AM radio frequency step
between adjacent channels is 10 kHz (9 kHz in
some areas).
1Select the tuner source.
2Press and hold on the main unit for
more than 5 seconds.
The frequency step is changed to 9»
kHz or 10 kHz.
All preset stations are erased and need»
to be re-programmed.
7 Listen to radio
Tune to a radio station
1Press TUNER repeatedly to select FM or
AM.
2Press and hold ALBUM +/- /for
more than 2 seconds.
[SEARCH] (search) is displayed.»
The radio tunes to a station with»
strong reception automatically.
3Repeat step 2 to tune to more stations.
To tune to a weak station, press•
ALBUM +/- / repeatedly until
you find optimal reception.
Program radio stations
automatically
You can program a maximum of 40 (FM + AM)
preset radio stations.
1In the tuner mode, press and hold
PROGRAM more than 2 seconds to
activate automatic program mode.
[AUTO] (auto) is displayed.»
All available stations are programmed»
in the order of waveband reception
strength.
The first programmed radio station is»
broadcast automatically.
Program radio stations manually
You can program a maximum of 40 (FM + AM)
preset radio stations.
1Tune to a radio station.
2Press PROGRAM to activate program
mode.
[PROG] (program) is displayed.»
EN
English

16
Record CDDA contents to a
USB device with high speed
To record the CDDA content into a USB
storage device with high speed,
1Plug the USB device into the socket of
this unit.
2Press DISC to select the disc source.
3Load a CDDA disk.
4Press to stop play.
5Press and hold USB RECORD until
[HIGH SPEED RECORDING] is
displayed.
Press• USB RECORD repeatedly to
select:
A [REC ONE] (record one): the first/
current track is recorded.
B[REC ALL] (record all): all tracks/the
remaining tracks are recorded.
The recording starts.»
To stop recording, press• .
Tip
• If the USB device does not have enough
memory to store the audio files, a message
about a full memory is displayed.
During high speed recording, speaker will be
•
no sound output.
Record CDDA contents to
USB at any playback time
Note
Make sure that the USB storage device is•
connected to the main unit.
To record the CDDA content into a USB
storage device at any playback time:
1Press USB RECORD during CDDA
playback.
The recording starts.»
8 USB record
Audio CD tracks, MP3 files, radio and audio
from external devices are recorded in .mp3
format, and WMA files are recorded in .wma
format.
The first time you record to USB, a folder
called ‘PHILIPS’ is automatically created in the
USB device. Each time you record to USB, the
recorded files are stored in a sub-folder in the
‘PHILIPS’ folder. Files and sub-folders are named
numerically in the order in which they are
created.
Record to USB
1Plug the USB device into the socket of
this unit.
2Prepare the source to record from.
Disc - Select the disc source and load•
a disc. You can select a track from
which a recording starts.
Radio - Tune to a radio station.•
MP3 LINK/AUX - Select the MP3•
link/AUX source, then connect and
start to play an external device.
3Press USB RECORD to start recording.
For discs, press• USB RECORD
repeatedly to select:
A[REC ONE] (record one): the first/
current track is recorded.
B[REC ALL] (record all): all tracks/the
remaining tracks are recorded.
Disc play starts automatically from the»
beginning of the disc/the selected track,
and the recording starts.
To stop recording, press».
Tip
If the USB device does not have enough•
memory to store the audio files, a message
about a full memory is displayed.
English
EN

17
13 Press SLEEP/TIMER to confirm.
»is displayed.
At the scheduled times, the recording»
begins and ends automatically.
When the recording ends, the unit»
switches to standby mode.
To deactivate or re-activate a record timer
1In the standby mode, press SLEEP/TIMER
repeatedly.
If the timer is activated,»is displayed.
If the timer is deactivated,»
disappears.
2Press to stop recording.
Tip
• If the USB storage device does not have
enough memory to store the audio files, a
message about a full memory is displayed.
Anytime recording is not available for CD-MP3•
and CD-WMA discs.
Anytime recording is not available for•
High speed recording.
Schedule radio-to-USB record
Schedule radio recordings in advance and you
can listen to your favorite programs at your
convenience.
Note
A recording is activated only in the standby mode.•
The maximum length of a recording is 12 hours.•
1Ensure that you set the clock correctly.
2Plug the USB device into the socket of
this unit.
3Tune to a radio station.
4Press to switch to standby mode.
5Press and hold SLEEP/TIMER for more
than 2 seconds.
A prompt to select the source is displayed.»
6Press TUNER repeatedly to select FM or AM.
7Press USB RECORD.
The start timer digits are displayed and»
begin to blink.
8Press ALBUM +/- / to set the hour.
9Press TITLE+/- / to set the minute.
10 Press SLEEP/TIMER to confirm.
The end timer digits are displayed and»
begin to blink.
11 Press ALBUM +/- / to set the hour.
12 Press TITLE+/- / to set the minute.
EN
English

18
Set the sleep timer
This unit can switch to standby automatically
after a set period of time.
1When the unit is turned on, press SLEEP/
TIMER repeatedly to select a set period
of time (in minutes).
When sleep timer is activated,»is
displayed.
To deactivate sleep timer
1Press SLEEP/TIMER repeatedly until
[OFF] (off) is displayed.
When sleep timer is deactivated,»
disappears on the display.
Listen to an external device
You can listen to an external audio device
through this unit.
For audio players with headphone sockets
1Press MP3 LINK/AUX repeatedly to
select the MP3 link source.
2Connect the supplied MP3 link cable to:
the• MP3 LINK jack (3.5mm) on the
unit.
the headphone jack on an external•
device.
3Start to play the device (refer to the
device’s user manual).
For audio players with red/white audio output
sockets
1Press MP3 LINK/AUX repeatedly to
select the AUX source.
2Connect the audio cables (white/red
jacks, not supplied) to:
the• AUX IN jacks on the back of the
unit.
the AUDIO OUT jacks on an•
external device.
3Start to play the device (refer to the
device’s user manual).
9 Other features
Set the alarm timer
This unit can be used as an alarm clock.The
disc, radio or USB is activated to play at a
preset time.
Note
If you have set a record timer and an alarm•
timer, only the latest timer is activated.
1Ensure that you have set the clock correctly.
2Press to switch to standby mode.
3Press and hold SLEEP/TIMER for more
than 2 seconds.
A prompt to select the source is»
displayed.
4Press CD 1/2/3, or TUNER or USB to
select a source.
5Press SLEEP/TIMER to confirm.
The clock digits are displayed and»
begin to blink.
6Press ALBUM +/- / to set the hour.
7Press TITLE+/- / to set the minute.
8Press SLEEP/TIMER to confirm.
The timer is set and activated.»
To deactivate or re-activate an alarm timer
1In the standby mode, press SLEEP/TIMER
repeatedly.
If the timer is activated,»is displayed.
If the timer is deactivated,»disappears.
Tip
In MP3 link or AUX mode, the alarm timer•
cannot be set.
If disc or USB source is selected but no
•
audio file can be played, radio is activated
automatically.
English
EN

19
10 Product
information
Note
Product information is subject to change•
without prior notice.
Specifications
Amplifier
Total output power 200W RMS
Frequency response 60 - 16kHz
Signal-to- noise ratio >67dB A (IEC)
Aux input 1500mV/2000mV
Disc
Laser type Semiconductor
Disc diameter 12cm/8cm
Support disc CD-DA, CD-R,
CD-RW, MP3-CD,
WMA-CD
Audio DAC 24Bits / 44.1kHz
Total harmonic
distortion
<1%
Frequency response 60Hz -16kHz
(44.1kHz)
S/N ratio >75dBA
Delete from USB device
1During USB play, press TITLE+/- /to
select an audio file.
To delete an audio folder, in the stop•
position, press ALBUM +/- /to
select an audio folder.
2Press USB DELETE.
A confirmation message is displayed.»
3While the message is displayed, press
USB DELETE again to confirm.
To cancel, press• .
Karaoke
You can connect a microphone and sing along
with a music source.
1Turn MIC VOL to the minimum level.
2Connect a microphone to the
microphone port on the unit.
3Press CD 1/2/3, or TUNER, or USB, or
MP3 LINK/AUX to select the source, and
start play.
4Sing through the microphone.
To adjust the volume of the source,•
press VOL +/-.
To adjust the volume of the•
microphone, turn MIC VOL.
Adjust display brightness
1Press DIM repeatedly to select different
levels of display brightness.
EN
English

20
Supported formats:
USB or memory file format FAT12,•
FAT16, FAT32 (sector size: 512 bytes)
MP3 bit rate (data rate): 32-320 Kbps and•
variable bit rate
WMA v9 or earlier•
Directory nesting up to a maximum of 8 levels•
Number of albums/ folders: maximum 99•
Number of tracks/titles: maximum 999•
ID3 tag v2.0 or later•
File name in Unicode UTF8 (maximum•
length: 128 bytes)
Unsupported formats:
Empty albums: an empty album is an•
album that does not contain MP3/WMA
files, and is not be shown in the display.
Unsupported file formats are skipped. For•
example, Word documents (.doc) or MP3
files with extension .dlf are ignored and
not played.
AAC, WAV, PCM audio files•
DRM protected WMA files (.wav, .m4a,•
.m4p, .mp4, .aac)
WMA files in Lossless format•
Supported MP3 disc formats
ISO9660, Joliet•
Maximum title number: 999 (depending•
on file name length)
Maximum album number: 99•
Supported sampling frequencies: 32 kHz,•
44.1kHz, 48 kHz
Supported Bit-rates: 32-320 (kbps),•
variable bit rates
ID3 tag v2.0 or later•
Directory nesting up to a maximum of 8•
levels
Maintenance
Clean the cabinet
Use a soft cloth slightly moistened with•
a mild detergent solution. Do not use
Tuner
Tuning range FM: 87.5 - 108MHz;
AM: 531 - 1602kHz
(9KHz); 530 - 1700KHz
(10KHz)
Tuning grid 100KHz (FM);
9KHz/10KHz (AM)
Number of presets 40 (FM + AM)
FM 75ohm wire
AM loop antenna
Speakers
Speaker Impedance 6ohm
Woofer 2 x 5.25”
Tweeter 2 x 1.75”
Dimensions
(W x H x D)
209 x 310 x 242 mm
Weight 3.58kg each
General information-Specs
AC power 110 - 127/220 - 240V,
50/60Hz
Operation power
consumption
110W
Standby power
consumption
<15W
USB direct Version 2.0/1.1
Dimensions
Main Unit
(W x H x D)
269 x 310 x 390 mm
Weight (without
speakers)
6.09kg
USB playability information
Compatible USB devices:
USB flash memory (USB 2.0 or USB 1.1)•
USB flash players (USB 2.0 or USB 1.1)•
memory cards (requires an additional•
card reader to work with this unit)
English
EN
