Philips 22PFS4232/12 User manual

Published by Amy/SC 1746 Quality Subject to modification 3122 785 20342
2017-Nov-15
2017 © TP Vision Netherlands B.V.
All rights reserved. Specifications are subject to change without notice. Trademarks are the
property of Koninklijke Philips Electronics N.V. or their respective owners.
TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust
earlier supplies accordingly.
PHILIPS and the PHILIPS’ Shield Emblem are used under license from Koninklijke Philips Electronics N.V.
Chassis name
Platform
Model name
Model name
TPN17.1E LA NT72461
22PFS4232/12 43PFT4112/05
22PFT4232/12 43PFT4112/12
32PFS4132/12 24PFS4032/12
32PFT4132/05 24PFT4032/12
32PFT4132/12 24PFT4032/60
32PFT4132/60 24PHS4032/12
32PHS4132/12 24PHT4032/05
32PHT4132/05 24PHT4032/12
32PHT4132/12 24PHT4032/60
32PHT4132/60 32PHS4032/12
43PFS4132/12 32PHT4032/05
43PFT4132/05 32PHT4032/12
43PFT4132/12 32PHT4032/60
43PFT4132/60 22PFS4022/12
49PFS4132/12 22PFT4022/05
49PFT4132/12 22PFT4022/12
32PHS4112/12 22PFT4022/60
32PHT4112/05 24PFS4022/12
32PHT4112/12 24PFT4022/12
39PHS4112/12 24PFT4022/60
39PHT4112/05 24PHS4022/12
39PHT4112/12 24PHT4022/05
43PFS4112/12 24PHT4022/12
TPN17.1E
EU

Published by Amy/SC 1746 Quality Subject to modification 3122 785 20342
2017-Nov-15
2017 © TP Vision Netherlands B.V.
All rights reserved. Specifications are subject to change without notice. Trademarks are the
property of Koninklijke Philips Electronics N.V. or their respective owners.
TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust
earlier supplies accordingly.
PHILIPS and the PHILIPS’ Shield Emblem are used under license from Koninklijke Philips Electronics N.V.
1. Product Information………………….……………………………………………………………………. 3
2. Connections Overview……………….……………………………………………………………………. 4
3. Mechanical Instruction ……………….……………………………………………………………………. 5
Cable dressing (22" 4232 series)……………………………………………………………………………5
Cable dressing (32" 4032/4132 series)………………………………………………………………………5
Cable dressing (43" 4132 series)……………………………………………………………………………6
Cable dressing (49" 4132 series)………………………………………………………………….………...6
Cable dressing (32" 4112 series)……………………………………………………………………………7
Cable dressing (39" 4112 series)……………………………………………………………………………7
Cable dressing (43" 4112 series)……………………………………………………………………………8
Cable dressing (24” 4022 series)……………………………………………………………………………8
Assembly/Panel Removal ……………………………………………………………………………………9
4. Service Modes………….……………….………………….…………………………………………….….16
5. Software upgrading, Error Code and Panel Code……...…………………………………………….. 20
6. Circuit Descriptions…..…………………….………………………………………………………………26
7. IC Data Sheet ……...…………………………………………………………………………………….…..36
8. Circuit Diagrams ……………...…………………………………………………………………………….39
8.1 715G8732 PSU………………………………………………………………………..…………………39
8.2 715G8697 PSU………………………………………………………………………..…………………41
8.3 715G7735 PSU………………………………………………………………………..…………………42
8.4 715G7734 PSU ……………………………………………………………………..……………………43
8.5 715G7574 PSU ………………………………………………………………………..…………………45
8.6 715G9216 C+P………………………………………………………..…………………………………47
8.7 715G9040 C+P………………………………………………………..…………………………………61
8.8 715G8991 C+P………………………………………………………..…………………………………75
8.9 715G8659 SSB………………………………………………………..…………………………………90
8.10 715G8791 IR/LED Panel………………………………………………………………………………..105
8.11 715G8576 IR/LED Panel………………………………………………………………………………..106
8.12 715G8767 IR/LED Panel………………………………………………………………………………..107
8.13 715G8623 IR/LED Panel………………………………………………..………………………………108
8.14 715G7088 Keyboard control pane…………………………………..…………………………………109
8.15 715G8728 Connection Panel………………………………………………..…………………………110
9. Styling Sheet……………….………………….……………………………………………………………..111
4232 series 22"……………………………………………………………..…………………………………111
4132&4032 series 32"………………………………………………………..………………………………112
4132 series 43"……………………………………………………………..…………………………………113
4132 series 49"……………………………………………………………..…………………………………114
4112 series 32"……………………………………………………………..…………………………………115
4112 series 39"……………………………………………………………..…………………………………116
4112 series 43"……………………………………………………………..…………………………………117
4032 series 24" & 4022 series 22/24"…………………………………..…………………………………118

Product Information

2. Connections Overview
Figure 2-1 (24” 4022 series)
Figure 2-2 (32” 4112 series)
Remarks: Figure 2-1 apply to the 24PFS4022/12, but will be similar for other series models except for 4112 series.
Figure 2-2 apply to the 32PHS4112/12, but will be similar for other 4112 series models.
C
I
USB
Headphone
YPBPR
SERV.U
AUDIO OUT
HDMI
TUNER
SAT
C
I
USB
Headphone
AUDIO IN
HDMI
AUDIO OUT
SERV.U
TUNER
SAT
SCART
(RGB/CVBS)
VGA

3. Mechanical Instructions
Notes: Figures below can deviate slightly from the actual situation due to the different set executions.
3.1 Cable Dressing
Figure 3-1 Cable dressing (22" 4232 series)
Figure 3-2 Cable dressing (32" 4032/4132 series)
IR MODUEAL(1056)
ECN408
ECN401
MAIN POWER SUPPLY
(
1055
)
A
SSB
(10
53
)
B
ECN701
ECN804
ECN401
ECN701
ECN401
ECN408
ECN601
ECN601
ECN401
CN8601
CN9101
J
SSB(1053)

Figure 3-3 Cable dressing (43" 4132 series)
Figure 3-4 Cable dressing (49" 4132 series)
ECN601
ECN408
ECN601
ECN701
ECN401
ECN408
ECN601
ECN601
ECN401
ECN701
CN601
CN401

Figure 3-5 Cable dressing (32" 4112 series)
Figure 3-6 Cable dressing (39" 4112 series)
ECN401
ECN407
ECN601
ECN601
ECN401
ECN408
ECN601
ECN601
CN8604
CN601
CN601
CN401 CN8604
CN408

Figure 3-7 Cable dressing (43" 4112 series)
Figure 3-8 Cable dressing (24” 4022 series)
ECN401
ECN408
ECN601
ECN601
ECN401
ECN408
ECN701
CN408
CN601
CN8604
CN401

3.2 Assembly/Panel Removal
3.2.1 Stand removal
Notes: Refer to Figure 3-9 and Figure 3-10 for details. But Figures below can deviate slightly from the actual situation due to the different set executions.
1. Remove the fixation screws [1] that secure the stand
2. Take the stand bracket out from the set.
Figure 3-9
Figure 3-10 (For 4022 series)
3.2.2 Rear Cover
Warning: Disconnect the mains power cord before removing the rear cover.
1. Remove fixation screws [2] and [3] that secure the Back cover assy. Refer to Figure 3-11 for details.
Remove fixation screws [2] and [3] that secure the Back cover assy. Refer to Figure 3-12 for details.
At the indicated areas [4] the cover is secured by clips. Be very careful with releasing those. Refer to Figure 3-13 for details.
2. Gently lift the rear cover from the TV. Make sure that wires and cables are not damaged while lifting the rear cover from the set.

Figure 3-11 (For 4232/4132/4032 series)
Figure 3-12 (For 4112 series)

Figure 3-13 (For 4022 series)
3.2.3 Keyboard Control Unit
1. Release the connector from the SSB Board.
Caution: Be careful, the Keyboard is catch on the Back cover, please be careful to avoid damage the fragile connectors!
2. Remove all the fixation screws [1] from the keyboard control panel and take it out from the Back cover
When defective, replace the whole unit.
Figure 3-14

3.2.4 Small Signal Board (SSB)
Caution: it is mandatory to remount all different screws at their original position during re-assembly. Failure to do so may result in damaging the SSB.
1. Release the clips from the connector that connect with the SSB[1].
Caution: be careful, as these are very fragile connectors!
2. Unplug all other connectors [2] .
3. Remove all the fixation screws [3] from the SSB or M+P BOARD. Refer to Figure 3-15 or Figure 3-16 for details.
4. The SSB / M+P BOARD can now be shifted from side connector cover, then lifted and taken out of the I/O bracket.
Figure 3-15 SSB
Figure 3-16 M+P BOARD (For 4112 Series)
3.2.5 Power Supply Unit (PSU)
Caution: it is mandatory to remount all different screws at their original position during re-assembly. Failure to do so may result in damaging the PSU.
1. Gently unplug all connectors from the PSU.
2. Remove all fixation screws from the PSU.
3. The PSU can be taken out of the set now.
3.2.6 IR board Control Unit
3
3
3
3
3

1. Unplug the connector from the SSB.
Caution: be careful, as these are very fragile connectors!
2. Remove all the fixation screws and connector from the IR board control unit.
3. Remove the IR lens, IR board from the DECO_REAR_COVER.
When defective, replace the whole unit.
Figure 3-17 (For 32" 4132 series)
Figure 3-18 (For 43" 4132 series)
Figure 3-19 (For 32” 4112 series)

1. Unplug the connector from the SSB.
Caution: Be careful, as these are very fragile connectors!
2. Remove the IR hold, IR board from the DECO_REAR_COVER.
When defective, replace the whole unit.
Figure 3-20 (For 22" 4232 series)
3.2.7 Speakers
1. Gently release the tapes that secure the speaker cables.
2. Unplug the speaker connector from the SSB.
3. Take the speakers out.
When defective, replace the both units.
Notes: For 24” 4022 & 32/39/43” 4112 series, the speaker is catch on the Back cover. Please be careful to avoid damage the fragile connectors when
assembly! Refer to Figure 3-21 and Figure 3-22 for details.

Figure 3-21 (For 24” 4022 series)
Figure 3-22(For 32” 4112 series)
3.2.8 WIFI module
1. Unplug the connector from the SSB..
2. Remove fixation screw that secure the WIFI module,
When defective, replace the whole unit.
3.2.9 LCD Panel
Remove the SSB as described earlier.
Remove the keyboard control panel as described earlier.
Remove the stand bracket as described earlier.
Remove the IR/LED as described earlier.
Remove the fixations screws that fix the metal clamps to the front bezel. Take out those clamps.
Remove all other metal parts not belonging to the panel.
Lift the LCD Panel from the bezel.
When defective, replace the whole unit.

4. Service Modes
4.1 Service Modes
The Service Mode feature is split into following parts:
Service Alignment Mode (SAM).
Factory Mode.
Customer Service Mode (CSM).SAM and the Factory mode offer features, which can be used by the Service engineer to repair/align a TV set.
SAM and the Factory mode offer features, which can be used by the Service engineer to repair/align a TV set. Some features are:
Make alignments (e.g. White Tone), reset the error buffer(SAM and Factory Mode).
Display information (“SAM” indication in upper right corner of screen, error buffer, software version, operating hours,options and option codes, sub menus).
The CSM is a Service Mode that can be enabled by the consumer. The CSM displays diagnosis information, which the customer can forward to the dealer
or call centre. In CSM mode, “CSM”, is displayed in the top right corner of the screen. The information provided in CSM and the purpose of CSM is to:
Increase the home repair hit rate.
Decrease the number of nuisance calls.
Solved customers’ problem without home visit.
Note: For the new model range, a new remote control (RC) is used with some renamed buttons. This has an impact on the activation of the Service modes.
For instance the old “MENU” button is now called “HOME” (or is indicated by a “house” icon).
4.2 Service Alignment Mode (SAM)
Purpose
To modify the NVM.
To display/clear the error code buffer.
To perform alignments.
Specifications
Operation hours counter (maximum five digits displayed).
Software version, error codes, and option settings display.
Error buffer clearing.
Option settings.
Software alignments (White Tone).
NVM Editor.
Set screen mode to full screen (all content is visible).
How to Activate SAM
To activate SAM, use one of the following methods:
Press the following key sequence on the remote control transmitter: “062596”, directly followed by the “INFO/OK” button. Do not allow the display to time
out between entries while keying the sequence.
Or via ComPair.
After entering SAM, the following items are displayed,
with “SAM” in the upper right corner of the screen to indicate that the television is in Service Alignment Mode.
How to Navigate
In the SAM menu, select menu items with the UP/DOWN keys on the remote control transmitter. The selected item will be indicated. When not all menu
items fit on the screen, use the UP/DOWN keys to display the next/previous menu items.
With the “LEFT/RIGHT” keys, it is possible to:
(De) activate the selected menu item.
(De) activate the selected sub menu.
Change the value of the selected menu item.

When you press the MENU button once while in top level SAM, the set will switch to the normal user menu (with the SAM mode still active in the
background).
How to Store SAM Settings
To store the settings changed in SAM mode (except the RGB Align settings), leave the top level SAM menu by using the POWER button on the remote
control transmitter or the television set. The mentioned exceptions must be stored separately via the STORE button.
How to Exit SAM
Use one of the following methods:
Switch the set to STANDBY by pressing the mains button on the remote control transmitter or the television set.
Via a standard RC-transmitter, key in “00” sequence.
Note: When the TV is switched “off” by a power interrupt while in SAM, the TV will show up in “normal operation mode” as soon as the power is supplied
again. The error buffer will not be cleared.
SAM mode overview
4.3 Factory mode:
Purpose
To perform extended alignments.
Specifications
Displaying and or changing Panel ID information.
Displaying and or changing Tuner ID information.
Error buffer clearing.
Various software alignment settings.
Testpattern displaying.
Public Broadcasting Service password Reset.
etc.
How to Activate the Factory mode
To activate the Factory mode, use the following method:
Press the following key sequence on the remote control transmitter: from the “menu/home” press “1999”, directly followed by the “Back/Return” button.
Do not allow the display to time out between entries while keying the sequence.
After entering the Factory mode, we can see many items displayed, use the UP/DOWN keys to display the next/previous menu items

Factory mode overview
How to Exit the Factory mode
Use one of the following methods:
Select EXIT_FACTORY from the menu and press the “OK” button.
Note: When the TV is switched “off” by a power interrupt, or normal switch to “stand-by” while in the factory mode, the TV will show up in “normal operation
mode” as soon as the power is supplied again. The error buffer will not be cleared.
4.4 Customer Service Mode (CSM)
Purpose
The Customer Service Mode shows error codes and information on the TVs operation settings.The call centre can instruct the customer (by telephone) to
enter CSM in order to identify the status of the set.This helps the call centre to diagnose problems and failures in the TV set before making a service call.
The CSM is a read-only mode; therefore, modifications are not possible in this mode.
Specifications
Ignore “Service unfriendly modes”.
Line number for every
line (to make CSM language independent).
Set the screen mode to full
screen (all contents on screen is visible).
After leaving the Customer Service Mode, the original settings are restored.
Possibility to use “CH+” or “CH-” for channel surfing, or enter the specific channel number on the RC.
How to Activate CSM
To activate CSM, press the following key sequence on a standard remote control transmitter: “123654” (do not allow the display to time out between entries
while keying the sequence). After entering the Customer Service Mode, the following items are displayed. use the Right/Left keys to display the
next/previous menu items
Note: Activation of the CSM is only possible if there is no (user) menu on the screen!

CSM Overview
How to Navigate
By means of the “CURSOR-DOWN/UP” knob (or the scroll wheel) on the RC-transmitter, can be navigated through the menus.
How to Exit CSM
To exit CSM, use one of the following methods.
Press the MENU/HOME button on the remote control transmitter.
Press the POWER button on the remote control transmitter.
Press the POWER button on the television set.

5. Software Upgrading, Error code and Panel Code
5.1 Software Upgrading
5.1.1. The following update is for .pkg file.
1. Rename the file to “upgrade_loader.pkg”
2. Prepare a USB memory.
3. Copy the software to USB flash disk(root directory).
4. Switch off the TV and Insert the USB memory stick that contains the software update files in one of the TV’s USB 2.0 ports.
Note: It contains USB3.0 port, if connect on it, the software may can’t be detected.
5. Switch on the TV. The TV will detect the USB memory s tick automatically. Then a window jumps out as below
6. When the TV software is updated, the TV will turn on again automatically. Remove your USB flash drive.
7. We can enter in CSM or Factory mode to check the current software version.
5.1.2. The following update is for .upg file.
Step 1: Ready for F/W Upgrade
1. Prepare a USB memory.
2. Copy the software to USB flash disk(root directory).
Note the version of this F/W before you change the software file name.
Step 2: F/W Upgrade
1. Plug the USB memory on the USB port on the side I/O port of TV (Please connect to USB 2.0 port, not recommend USB3.0 port)
2. AC on (Power plug)
3. TV will show message as below image, Press [Start] to detect the software automatically
