Philips 32PFL3506 User manual

Register your product and get support at
www.philips.com/support
32PFL3506
MODEL NUMBER SERIAL NUMBER
EN User Manual
FR Manuel d’Utilisation
ES Manual del Usuario
EN: For further assistance, call the customer support service in your country.
• To obtain assistance in the U.S.A., Canada, Puerto Rico, or the U.S.Virgin Islands, contact Philips
Customer Care Center at 1-866-309-0841
• To obtain assistance in Mexico, contact Philips Customer Care Center at 01 800 504 62 00
Enter below the model and serial numbers located on the back and right side of theTV cabinet.
FR: Pour obtenir de l’aide supplémentaire, communiquez avec le centre de service à la clientèle de
votre pays.
• Pour obtenir de l’aide aux États-Unis, au Canada, à Puerto Rico ou aux Îles Vierges américaines,
communiquez avec le centre de service à la clientèle Philips au : 1-866-309-0841
• Pour obtenir l’aide au Mexique, entrez en contact avec le centre de soin de client de Philips à
01 800 504 62 00
Entrer ci dessous le modèle et le numéro de série situés dérrière à droite sur le dos du téléviseur.
ES: Para obtener más información, llame al servicio de soporte al cliente de su país.
• Para obtener asistencia en los Estados Unidos, en Canadá, Puerto Rico o en las Islas
Vírgenes de los Estados Unidos, comuníquese con Centro de atención al cliente de Philips al
1-866-309-0841
• Solo para Mexico CENTRO DE ATENCIÓN A CLIENTES LADA. 01 800 504 62 00 Solo
Para México.
Escriba a continuación el modelo y número de serie que estan localizados en lado derecho y parte
posterior de el gabinete de el televisor.
Lea esta manual antes de usar el producto

1
English
EN
Contents
1 Notice 4
2 Important 5
Product information 5
Screen care 5
Environmental care 5
Regulatory notices 5
3 Your TV 6
Side controls and indicators 6
Remote control 6
4 Get started 8
Supplied accessories 8
Mounting stand ontoTV 8
Positioning the TV 8
Installing the remote control batteries 8
Connecting the antenna or cable 9
Managing cables 10
Plugging in the AC power cord 10
Switching on and initial setup 11
5 Use your TV 12
Switching on yourTV and putting it in standby mode 12
Switching channels 12
Adjusting volume 13
Still mode 13
Watching channels from a set-top box 13
Watching connected devices 13
Watching a Blu-ray disc 14
Switching audio mode 14
6 Use more of your TV 15
Changing picture and sound settings 15
Sleeptimer 18
Child and rating locks 18
Closed caption 20
EasyLink 21
ECO 21
Set your location to home 21
Viewing photos and watching videos
on a USB storage device 22
7 Install channels 24
Selecting your menu language 24
Autoprogram 24
Channel list 25
Add channels 25
Optimizing the signal quality from your antenna 25
8 Upgrade your TV software 26
Checking your current software version 26
Preparing for the software upgrade 26
Upgrading software 26
9 Connect devices 27
Connection overview 27
Selecting your connection quality 28
Connecting your devices 29
10 Troubleshooting 31
Downloading an electronic copy 31
Contact us 31
11 Notes for the use of USB devices 32
12 Specifications 32
13 Warranty 33
14 Index 34

2
EN
Registering your model with Philips makes you eligible for all of the valuable benefits listed below, so don't miss out. Complete
and return your Product Registration Card at once, or register online at www.philips.com/support to ensure:
Visit our World Wide Web Site at http://www.philips.com/support
Know these
safetysymbols
CAUTION
This “bolt of lightning” indicates uninsulated material
within your unit may cause an electrical shock. For the
safety of everyone in your household, please do not
remove product covering.
The “exclamation point” calls attention to features for
which you should read the enclosed literature closely to
prevent operating and maintenance problems.
WARNING: To reduce the risk of fire or electric shock, this apparatus should not be exposed to rain or moisture and objects filled
with liquids, such as vases, should not be placed on this apparatus.
CAUTION: To prevent electric shock, match wide blade of plug to wide slot, fully insert.
ATTENTION: Pour éviter les choc électriques, introduire la lame la plus large de la fiche dans la borne correspondante de la prise et
pousser jusqu’au fond.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
*Product Safety Notification *Additional Benefits
By registering your product, you'll receive notification
- directly from the manufacturer - in the rare case of
a product recall or safety defect.
Registering your product guarantees that you'll
receive all of the privileges to which you're
entitled, including special money-saving offers.
Return your Product Registration Card or register online at
www.philips.com/support today to get the very most from your purchase.

3
EN
English
