Philips 32PFL7572D - annexe 2 User manual

Philips
digital widescreen flat TV
with Pixel Plus 2 HD
32"
LCD integrated digital
32PFL7572D
Turn up your viewing experience
with Pixel Plus 2HD
Experience the superior picture quality of this excellent Flat TV with the latest LCD
technology. It's packed into a stunning design that will complement your interior.
Immersive viewing experience
• Integrated Digital Tuner for DVB-T reception
• HD ready for the highest quality display of HDTV signals
• Pixel Plus 2 HD improves details in standard TV and HDTV
• Dynamic contrast enhancer delivering rich black details
Better quality images that reveal more detail
• Digital Natural Motion for smooth moving images
Superb sound reproduction
• Virtual Dolby Surround for a cinema-like audio experience
Slim, stylish design to complement your interior
• Compact and slim design that fits in every room
• Matching stand with elegant design included
For advanced performance
• Dual HDMI input for full digital High Definition connection

32PFL7572D/10
Highlights
Digital widescreen flat TV with Pixel Plus 2 HD
32" LCD integrated digital
Integrated Digital DVB-T tuner
The integrated DVB-T tuner lets you receive
Digital Terrestrial TV to watch or record. This
means you do not need an additional set top
box and the additional cables.
HD Ready
Enjoy the exceptional picture quality of a true
High Definition TV signal and be fully prepared
for HD sources like HDTV broadcast, Blu-ray
DVD or HDVD. HD ready is a protected label
that offers picture quality beyond that of
progressive scan. It conforms to strict
standards laid out by EICTA to offer a HD
screen that displays the benefits of resolution
and picture quality of a High Definition TV
signal. It has a universal connection for both
analogue YPbPr and uncompressed Digital
connection of DVI or HDMI, supporting
HDCP. It can display 720p and 1080i signals at
50 and 60Hz.
Pixel Plus 2 HD
Pixel Plus 2 HD offers the unique combination
of ultimate sharpness, natural detail, increased
depth, vivid colours and smooth and natural
motion from standard TV, High Definition
signals and multimedia sources. Each pixel of
the incoming picture is enhanced to better
match the surrounding pixels, resulting in a
more natural picture. Artefacts in compressed
multimedia content are detected and reduced,
ensuring that the picture is clean and razor
sharp. Digital noise reduction ensures that the
picture is perfectly smooth yet razor sharp.
Dynamic contrast enhancer
You want the LCD flat display with the highest
contrast and most vibrant images even at wide
viewing angle. The Philips dynamic contrast
enhancer uses video processing and unique
dimming backlight technology. This delivers
deep rich black levels with increased detail.
The dimming backlight increases the contrast
up to 5 times*, and at the same time improves
the viewing angle. It gives a bright, lifelike
picture with high contrast and vibrant colours
(* factor between 2 and 5, screen type and
picture content dependant).
Digital Natural Motion
Philips invented Digital Natural Motion to
eliminate juddering effects that are visible with
moving picture content. Digital Natural Motion
estimates motion in the picture and corrects
juddering movements in both broadcast and
recorded movie material (such as DVD). The
resulting smooth motion reproduction and
excellent sharpness take the viewing
experience to a higher level.
Virtual Dolby Surround
Virtual Dolby Surround is a processing
technology for enhancing surround sound
effects. It will create the sensation of Dolby
Pro Logic without the necessity of additional
rear speakers. You become totally immersed
in your television experience.
Bypacked tabletop stand
A table-top stand with matching design is
packed with the set.
Dual HDMI input
HDMI makes an uncompressed digital RGB
connection from the source to the screen. By
eliminating conversion to an analogue signal, it
delivers an unblemished image. The non-
degraded signal reduces flicker and leads to a
clearer picture. HDMI intelligently
communicates the highest output resolution
with the source device. The HDMI input is fully
backward compatible with DVI sources but
includes digital audio. HDMI uses HDCP copy
protection. With 2 HDMI inputs you can
connect multiple HD sources, for instance an
HD set top box, and a Blu-ray player. Your TV
is fully prepared for the HD future.

32PFL7572D/10
Specifications
Digital widescreen flat TV with Pixel Plus 2 HD
32" LCD integrated digital
Picture/Display
• Aspect ratio: 16:9
• Brightness: 500 cd/m²
• Dynamic screen contrast: 7500:1
• Response time (typical): 8 ms
• Viewing angle: 176º (H) / 176º (V)
• Diagonal screen size: 32 inch / 80 cm
• Display screen type: LCD WXGA Active Matrix
TFT
• Panel resolution: 1366 x 768p
• Picture enhancement: Pixel Plus 2 HD, Digital
Natural Motion, Dynamic contrast enhancement,
3/2 - 2/2 motion pull down, 3D Combfilter, Active
Control + Light sensor, Active Control, Jagged
Line Suppression, Progressive Scan, Widescreen
Plus
• Screen enhancement: Anti-Reflection coated
screen
Supported Display Resolution
•Computer formats
Resolution Refresh rate
640 x 480 60Hz
800 x 600 60Hz
1024 x 768 60Hz
•Video Formats
Resolution Refresh rate
640 x 480i 1Fh
640 x 480p 2Fh
720 x 576i 1Fh
720 x 576p 2Fh
1280 x 720p 3Fh
1920 x 1080i 2Fh
Sound
• Output power (RMS): 2x10W
• Sound Enhancement: Digital Signal Processing,
Dynamic Bass Enhancement, Graphic Equaliser
• Sound System: Virtual Dolby Digital
Loudspeakers
• Built-in speakers: 4
• Loudspeaker types: Dome tweeter
Convenience
• Child Protection: Child Lock+Parental Control
• Clock: Smart Clock
• Ease of Installation: Auto Program Naming,
Automatic Channel Install(ACI), Automatic Tuning
System (ATS), Autostore, PLL Digital Tuning, Plug
& Play
• Ease of Use: 4 favourite lists, Auto Volume Leveller
(AVL), Delta Volume per preset, Graphical User
Interface, On Screen Display, Program List, Side
Control
• Electronic Program Guide: Now + Next EPG
• Remote Control: TV
• Remote control type: RACER RC
• Screen Format Adjustments: 4:3, 6 Widescreen
Modes, Auto Format, Movie expand 14:9, Movie
expand 16:9, Subtitle and Heading Shift, Super
Zoom, Widescreen
• Picture in Picture: Text dual screen
• Teletext: 1200 page Hypertext
• Teletext enhancements: Habit Watch, Program
information Line
• VESA Mount: Vesa compliant
Multimedia Applications
• Multimedia connections: USB (streaming video
capable)
• Playback Formats: MP3, Slideshow files (.alb), JPEG
Still pictures, MPEG2
Tuner/Reception/Transmission
• Aerial Input: 75 ohm coaxial (IEC75)
• TV system: DVB COFDM 2K/8K
• Video Playback: NTSC, SECAM, PAL
• DVB: DVB Terrestrial *
• Tuner bands: Hyperband, S-Channel, UHF, VHF
Connectivity
• Ext 1 Scart: Audio L/R, CVBS in/out, RGB
• Ext 2 Scart: Audio L/R, CVBS in/out, RGB, S-video
in
• Ext 3: YPbPr
• Ext 4: HDMI
• Ext 5: HDMI
• Front / Side connections: Audio L/R in, CVBS in,
Headphone out, S-video in, USB
• Other connections: Analogue audio Left/Right out,
S/PDIF in (coaxial), S/PDIF out (coaxial)
Power
• Ambient temperature: 5 °C to 40 °C
• Mains power: AC 220 - 240 V +/- 10%
• Power consumption: 128 W
• Standby power consumption: <1W
Accessories
• Included Accessories: Table top stand, Power
cord, User Manual, Registration card, Warranty
certificate, Remote Control, Batteries for remote
control
• Optional accessories: Floor stand
Dimensions
• Colour cabinet: Black glass deco front, silver frost
front cabinet, Black microfoil speakers
•Setdimensions(Wx H x D):
804.9 x 546.5 x 117.6 mm
• Set dimensions with stand (W x H x D):
804.9 x 609 x 210 mm
• Product weight: 14.4 kg
• Product weight (+stand): 22.6 kg
•Boxdimensions(Wx H x D):
877x 641 x 267 mm
• Weight incl. Packaging: 22.6 kg
• VESA wall mount compatible: 200 x 100 mm
•
Issue date 2009-08-14
Version: 5.0.8
12 NC: 8670 000 25332
EAN: 87 12581 30199 6
© 2009 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
