Philips 5704 series User manual

Quick start guide
Depending on your TV, please see below to determine which QSG you will need to see.
There are two Android OS versions for this model. Please follow below to get started with QSG.
1. On the home menu of your Android TV, select Settings in the upper right corner of the screen,
or press
y(OPTIONS) on the remote.
2. Select About or Device Preferences >About
3. Under Version:
If version is Android O (8.x), please start from next page
If version is Android P (9.x), please start from p.14
Televisions
5704 series
5604 series
5504 series

2
Televisions
Android O (8.x)
C
If you can see below setting menu, please start to read from next page.
If not, please go to P.1 4
Quick start guide
Televisions
5704 series
5604 series
5504 series
1-866-309-5962
http://tinyurl.com/y2e29xsq
9 AM to 9 PM EST Monday – Saturday,
9 AM to 6 PM EST Sunday.
Call us:
Chat with us:
Hours of operation:
Scan to call us:
Scan to chat with us:
Product design and user interface are for illustrative purposes only.
Actual product and user interface may vary.
Quick start guide
1-866-309-5962
9 AM to 9 PM EST Monday – Saturday, 9 AM to 6 PM EST Sunday.
Hours of operation:
Call us: Scan to call us:
http://tinyurl.com/y2e29xsq
Chat with us: Scan to chat with us:

3
1 Using the remote control
How to install the batteries in the remote control
Open the battery cover by firmly sliding down. Insert 2
AAA(1.5V) batteries matching the polarity indicated inside
battery compartment of the remote control.
16 feet (5 m)
30° 30°
23 feet (7 m) 16 feet (5 m)
B(POWER)
Turns the TV on and off of standby.
z(TV GUIDE)
Access to the Electronic Program Guide (EPG).
x(HOME)
Access to your apps, Live TV, input devices, settings, and the Google Play Store.
1(INFO)
Displays input, resolution, and HDR information.
0(Google Assistant)
Activates your personal Google Assistant.
y(OPTIONS)
Displays a list of menu options applicable to the active screen.
TV
Direct access to your installed TV channels.
(This feature is only available for OTA and select cable channels.)
w(INPUTS)
Change input source.
Select and change access to the attached devices such as Blu-ray player, gaming consoles, or cable box.
3(BACK)
Returns to the previous menu screen.

4
2 Best Experience
Google account
Unleash your television's true potential. With a Google® account you can effortlessly expand your
entertainment library via the Google Play Store and Google Play app and also keep apps up-to-date.
You can enjoy this Philips Android TV even without a Google account. For example, you can watch
Live TV programming, streaming applications such as Netflix, VUDU, YouTube and more.
C Note:
Simply login with your Google account.
E Tip:
It is recommended to create a new Google account specifically for your Android TV. A new
account will prevent interference and syncing of your personal account. To create a new Google
account, visit http://accounts.google.com/signup on your smartphone, tablet, or computer.
Network router
Wired Connection:
For the best experience, a wired connection is preferred. Connect an ethernet cable from your
router or modem to the LAN port located on the back of your Philips Android TV.
Wireless Connection:
The Philips 5000 Series Android TV is equipped with Wireless LAN 802.11ac MIMO for wireless
streaming of up-to 4K content.
C Note:
Wireless performance may be affected by various factors, including the distance between the
TV and your Wi-Fi router. To improve wireless performance, we recommend placing your Wi-Fi
router within 15 feet of your TV.
C Note:
The use of open or unencrypted Wi-Fi networks is not recommended, as these networks are
not secured, and your data could be at risk.
E Tip:
If your Wi-Fi Router was set up by your internet service provider (ISP), you may find a sticker on
the bottom of your router indicating your Wi-Fi SSID and password.
Set up Android TV with your Android smartphone or tablet
If you have an Android phone or tablet, you can quickly and easily set up your Android TV from your
Android device. Pairing your Android device will allow you to wirelessly sync your Wi-Fi credentials,
Google account, and Android TV compatible apps. During the initial setup, you will be prompted to
set up your TV with your Android device, select Yes, and follow the on-screen instructions.
C Note:
Be sure to enable pairing mode on your Android device in the beginning.

5
3 Explore your television
From the Android TV home screen, you can easily access movies, TV shows, music, apps, input
devices, settings, and more.
To go back to the home screen at any time, press x(HOME) on your remote control.
1
5
3 4
2
6
7
8
1Google Assistant
Activates your personal Google Assistant. Type or speak to search for content, control your TV,
manage your smart home devices, and more.
2 Inputs
Toggle inputs between your favorite source devices.
3 e-Help
Online help videos and tutorials
4 Settings
Configure your television settings and connect to wireless devices.
5 Apps
Apps gallery
You must sign in with a Google account to visit and download apps from the Google Play store.
6 How to rearrange channels
Within the row, you want to rearrange, press Jon your remote control.
To rearrange channels, Select arrow (H/I) icon, and press OK. Use HIto move up or down.
Press OK.
To delete channels, Select minus (-) icon, and press OK.
7Install Additional Apps
Select the “+” and click on the Google Play Store to expand your entertainment library.
8 How to move or delete applications
Select the application and long press OK on your remote control.
To move, Select Move in the list, and press OK. Use JKto move left or right. Press OK.
To delete, Select Remove from favorites in the list, and press OK.

6
4 Live TV
The Live TV channels feature on Android TV loads television shows, sports, news, and more from
your participating TV apps or OTA TV tuner so you can watch them all in one place.
To select channels by using HIon your remote control.
Options
Press OK while viewing Live TV to switch between Channels and TV options.
Channels: switches between program guide and channel.
TV options: configure picture and audio preferences.
Program guide
The built-in electronic program guide (EPG) allows you to find channels and content easily.
Pause Live TV
You can pause OTA Live TV programming when a 16GB or larger USB Flash Drive is connected to
your Android TV.
Press oon your remote control to either pause or resume playback of Live TV programming.
E Tip:
Live TV feature is only compatible with antenna and select cable broadcasting. To access
your cable box or other source inputs, you must select w(INPUTS) on your remote control.

7
5 Google Assistant
Activate Google Assistant
E Tip:
To enjoy all of the benefits Google Assistant can provide, an internet connection and a Google
account are required.
How to use the remote control
1. • Activating the Google Assistant on the home screen will launch a Google Query.
• Activating the Google Assistant within an app will allow you to search and find information only
related to a specific app.
2. Speak into the microphone located on the top of your remote control.
Speech examples may be displayed depending on your model.
To learn more about the Google Assistant visit https://assistant.google.com
SafeSearch filter for Google Search
SafeSearch can help you block inappropriate or explicit images from your Google search results.
The SafeSearch filter helps block most adult content from your television. Parental supervision is
strongly recommended.
1. On the Android TV home screen, select Settings in the upper right corner of the screen, and press
OK.
2. Scroll down to Preferences and select Google.
3. Select SafeSearch filter and press OK.

8
6 Connecting your devices
How to use external devices
Connecting antenna or cable / satellite / IPTV set-top box
E Tip:
Connect your external devices to your Android TV before powering on.
If connecting to an antenna via an RF cable If connecting a set-top box via an HDMI cable
DTV programs that are broadcasted in your
area can be received for free through a digital
antenna.
If the TV is connected to a cable or satellite set-
top-box via an HDMI cable, you must select the
correct source by using w(INPUTS) on your
remote control.
ININ
OUTOUT
RF cableRF cableRF cable
AntennaAntenna
CableCable
IN
IN
IN
Set-top boxSet-top box
RF cableRF cable
HDMI cable
HDMI cable
OUTOUT
Changing input to devices that are connected to the TV.
Press w(INPUTS) to switch input device list.
E Tip:
To get the best picture quality for your source device, you may have to adjust the EDID version.
EDID 1.4 is used for legacy devices that can output in 2K or 4K @30Hz.
EDID 2.0 is used for modern devices that can output 4K @ 60Hz and 4K with HDR 10.
1. Press x(HOME) on your remote control and navigate to Settings and select Inputs.
2. Scroll down until you reach HDMI EDID Version.
3. Select the input you want to modify and adjust the EDID.
How to use Chromecast
Casting allows you to mirror your favorite apps on the big screen.
E Tip:
The device you are using to cast to your television must be on the same Wi-Fi network.
1. Open a Chromecast-enabled app.
2. Tap u.
3. Tap the device you would like to cast to.
How to connect to your Bluetooth® devices
To pair your pair Bluetooth® devices, such as a wireless headset, keyboard, game controller,
with your Android TV.
1. On the Android TV home screen, select Settings in the upper right corner of the screen, and press OK.
2. Scroll down to Remote & accessories and select Add accessory.
3. Enable pairing mode on your device.
4. Using your TV remote control, select your device from the list shown on your TV.
5. Your Android TV will pair with your device.
E Tip:
Some devices may require additional steps. Please consult your Bluetooth device manual for
more information.

9
7 Troubleshooting
Category Problem Tip
Performance Remote response is
delayed or sluggish during
initial use.
• Your television is automatically,
downloading and installing the latest
applications, for the best user experience.
• During this time, you may experience
a delayed response from your remote
control. Upon successful installation, your
remote control will operate normally.
Accessibility Television is speaking
prompts out-loud.
• To disable the talkback (text to speech) on
your television, press x(HOME) on your
remote control, navigate to settings icon in
the upper right corner of the home screen
and select accessibility, select talkback,
press OK to toggle between on or off.
Network Slow Data Connection or
buffering.
• Check the settings between your router
and ISP modem or gateway (if applicable).
• Connect to a stable wireless connection
from home wireless or wired network.
• The use of mobile hot spots or public
wireless connections is not recommended.
Sound on
HDMI with
external devices
Television has no sound. • Please check to be sure the device is
connected to the HDMI 2 (ARC) input on
the TV.
Power No power • Ensure that the AC outlet supplies the
proper voltage.Plug another electrical
appliance into the AC outlet to ensure that
the AC outlet operates normally.
• If a power failure occurs, unplug the AC
power cord for 1 minute to allow the unit
to reset itself.
Remote control Remote control buttons
are not functional.
• Re-insert or replace the AAA batteries with
their polarities (+/–) as indicated on the
remote control battery area.
(Google Assistant)
microphone on the remote
control does not work.
• To pair the remote control, refer to the
step “6 Connecting your devices ” in the
previous page and see “How to connect to
your Bluetooth® devices”.
To enable pairing mode, press (Google
Assistant) and vol down (–) button on
your remote control simultaneously for 5
seconds.
7 Troubleshooting

10
7 Troubleshooting
For further assistance, call the customer support service in your country.
- To obtain assistance, contact Philips customer care center;
In the U.S.A., Canada, Puerto Rico, or the U.S. Virgin Islands 1 866 309 5962
Enter below the model and serial numbers located on the left side and the rear of the TV cabinet.
Model :
Serial :
Category Problem Tip
Network Cannot connect the
network.
• Check if your router and/or modem is
properly connected.
• Check if the Ethernet cable connection
between the TV and your router or modem
is properly secured.
• Power cycle the router and/or modem.
• Check your network settings.
Picture Power is on but screen
image is off.
• Check if the connection for your source
device is properly secured.
• Check if the correct input is selected by
pressing w(INPUTS).
• Verify that your HDMI mode, for the input
selected matches the resolution output of
your source device.
Change source input until you have
picture and sound.
Performance Remote response is
delayed or sluggish during
initial use.
• Your television is automatically,
downloading and installing the latest
applications, for the best user experience.
• During this time, you may experience
a delayed response from your remote.
Upon successful installation, your remote
will operate normally.
7 Troubleshooting

11
Child and rating lock
Block individuals from using specific apps or games.
You can prevent people from using specific apps or games on your Android TV by setting up a
restricted profile.
If you are using a restricted profile, you cannot:
• Access or make purchases in the Google Play Store app
How to set up a restricted profile ( )
1. On the Android TV home screen, select Settings in the upper right corner of the screen, and press
OK.
2. Scroll down to Personal and select Security & restrictions > Create restricted profile.
3. Set a PIN.
4.
Choose which apps the restricted profile can or cannot use by selecting Not allowed or Allowed for
each app.
5. Press 3(BACK).
6. Select Enter restricted profile and press OK.
How to exit the restricted profile ( )
1. On the Android TV home screen, select Restricted Profile in the upper of the screen, and press
OK.
2. Select Exit restricted profile and press OK.
3. Enter PIN.
Parental controls
You can restrict your children from watching certain programs or channels, by setting parental
controls using a rating lock.
How to set up a Parental controls
1. On the Android TV home screen, select Settings in the upper right corner of the screen, and press
OK.
2. Scroll down to Device and select Channel > Parental controls.
3. Set a PIN > Program restrictions > Ratings.
4. Select Ratings as described in the table below and press OK.
 Rating types and restriction levels
United States United States (Film ratings)
TV-Y TV-Y7 TV-G TV-PG TV-14 TV-MA G PG PG-13 R NC-17 X
High restrictions
Content suitable for
children
  
Medium restrictions
Content suitable for
older children
 
Low restrictions
Content suitable for
teens
   
8 Parental Control and Restricted Prole

12
Specications
Model # 55PFL5704, 55PFL5604 50PFL5704, 50PFL5604
Type UHD (Ultra HD) (3840 x 2160 pixels 60Hz)
Diagonal screen size / Aspect ratio 54.6”/ 16:9 49.5”/ 16:9
Viewing angles 178° (V) by 178° (H)
Built-in digital / analog tuner ATSC (digital) / NTSC (analog)
Sound
Mono / Stereo
Mono, Stereo
Power output (RMS watts) 10W x 2
Equalizer 5 band
Ease of use
Picture format
SD (4:3 source) 4:3 / Wide screen
HD (16:9 source) 4:3 / Wide screen
UHD Full
Channel
Channel coverage
Over-the-Air DTV
(ATSC)
VHF: 2~13
UHF: 14~69 (Each channel may have e.g. 2.1~2.9, 3.1~3.9, etc)
Over-the-Air Analog
(NTSC)
VHF: 2~13
UHF: 14~69
CATV (Analog NTSC) 2~13, A~W
W+1~W+94 (Analog W+1~W+84), A-5~A-1, 5A
Tuning system Channel frequency synthesized tuning system
Channel access Direct access number keyboard, Programmable scan and
Channel + (up) / - (down)
Connectivity
Composite video input 1
HDMI input
3 (selectable HDMI modes)
Supporting HDMI video signals : 480i/p, 720p, 1080i @60Hz, 1080p,
2160p @24/30/60Hz
Supporting HDMI digital audio signals : LPCM, AC3, DD+
Supporting PC-input video signal up to 4096 x 2160
Analog audio L/R input 1 (L Audio / R Audio)
PC input Via HDMI and HDMI-DVI + Analog audio L/R
USB 1
Wireless LAN Wireless LAN Supporting wireless standards : IEEE 802.11a/b/g/n/ac
(2.4GHz/5GHz)
Ethernet port 1
Digital audio output 1
Supporting Dolby Digital
Headphone output 1
1/8 inch (3.5 mm)
Power
Power requirements 120 V~/ 10%, 60 Hz / 0.5%
Temperature
Operating temperature 41 °F (5 °C) to 104 °F (40 °C)
* Specifications are subject to change without prior notice.

For complete instructions, please visit
www.philips.com/support to download the
full version of the User manual.
This product has been manufactured by
and is sold under the responsibility of Funai
Corporation, Inc., and Funai Corporation, Inc. is
the warrantor in relation to this product.
The Philips trademark and the Philips shield
emblem are registered trademarks of Koninklijke
Philips N.V. used under license.

14
Quick start guide
Televisions
5604 series
1-866-309-5962
http://tinyurl.com/y2e29xsq
9 AM to 9 PM EST Monday – Saturday,
9 AM to 6 PM EST Sunday.
Call us:
Chat with us:
Hours of operation:
Scan to call us:
Scan to chat with us:
Product design and user interface are for illustrative purposes only.
Actual product and user interface may vary.
Televisions
Android P (9.x)
C
If you can see below setting menu, please start to read from next page.
If not, please go to P.2
Product design and user interface are for illustrative purposes only.
Actual product and user interface may vary.
Quick start guide
1-866-309-5962
9 AM to 9 PM EST Monday – Saturday, 9 AM to 6 PM EST Sunday.
Hours of operation:
Call us: Scan to call us:
http://tinyurl.com/y2e29xsq
Chat with us: Scan to chat with us:

15
1 Using the remote
How to install the batteries in the remote
Open the battery cover by firmly sliding down.
Insert 2 AAA (1.5 V) batteries matching the polarity indicated
inside battery compartment of the remote.
16 feet (5 m)
40° 40°
23 feet (7 m) 16 feet (5 m)
a c
AAA (1.5 V) x 2
b
1 (POWER)
Turns the TV on and off of standby.
2 z(TV GUIDE)
Access to the Electronic Program Guide (EPG).
3 The Google Assistant
Press the Assistant button on your remote to talk to your
Google Assistant.
4 3(BACK)
Returns to the previous menu screen.
5 w(INPUT)
Change input source.
Select and change access to the attached devices such
as Blu-ray player, gaming consoles, or cable box.
6 1(INFO)
Displays input and resolution information.
7 y(OPTIONS)
Displays a list of menu options applicable to the active
screen.
8 (CURSOR as H I J K) and OK
Moves to select an item and to determine on the various
menu.
9 x(HOME)
Access to your apps, Live TV, input devices, settings, and
the Google Play Store.
10 PREV.CH
Direct access to the Live TV channels.
Displays the last selected terminal or channel.
1
3
10
7
9
2
6
4
5
8
Microphone

16
2 Best Experience
Google account
Unleash your television's true potential. With a Google® account you can effortlessly expand your
entertainment library via the Google Play Store and Google Play app and also keep apps up-to-date.
While you can enjoy this Philips Android TV™ without a Google Account via the preinstalled
selection of applications, we recommend a Google account to download additional apps from the
Google Play Store or use the Google Assistant.
C Note:
Simply login with your Google account.
E Tip:
It is recommended to create a new Google account specifically for your Android TV. A new
account will prevent interference and syncing of your personal account. To create a new Google
account, visit http://accounts.google.com/signup on your smartphone, tablet, or computer.
Network router
Wired Connection:
For the best experience, a wired connection is preferred. Connect an ethernet cable from your
router or modem to the LAN port located on the back of your Philips Android TV.
Wireless Connection:
The Philips 5000 Series Android TV is equipped with Wireless LAN 802.11ac MIMO for wireless
streaming of up-to 4K content.
C Note:
Wireless performance may be affected by various factors, including the distance between the
TV and your Wi-Fi router. To improve wireless performance, we recommend placing your Wi-Fi
router within 15 feet of your TV.
C Note:
The use of open or unencrypted Wi-Fi networks is not recommended, as these networks are
not secured, and your data could be at risk.
E Tip:
If your Wi-Fi Router was set up by your internet service provider (ISP), you may find a sticker on
the bottom of your router indicating your Wi-Fi SSID and password.
Set up Android TV with your Android smartphone or tablet
If you have an Android phone or tablet, you can quickly and easily set up your Android TV from your
Android device. Pairing your Android device will allow you to wirelessly sync your Wi-Fi credentials,
Google account, and Android TV compatible apps. During the initial setup, you will be prompted to
set up your TV with your Android device, select Yes, and follow the on-screen instructions.
C Note:
Be sure to enable pairing mode on your Android device in the beginning.

17
3 Explore your television
From the Android TV home screen, you can easily access movies, TV shows, music, apps, input
devices, settings, and more.
To go back to the home screen at any time, press x(HOME) on your remote.
1
5
3 4
2
6
7
8
1The Google Assistant
With the Google Assistant, quickly access entertainment, control smart devices, get answers on
screen, and more using your voice.
2 Inputs
Toggle inputs between your favorite source devices.
3 Network condition
Display the network status and open network settings if selected.
4 Settings
Configure your television settings and connect to wireless devices.
5 Apps
Apps gallery
You must sign in with a Google account to visit and download apps from the Google Play store.
6 How to rearrange channels
Within the row, you want to rearrange, press Jon your remote.
To rearrange channels, Select arrow (H/I) icon, and press OK. Use HIto move up or down.
Press OK.
To delete channels, Select minus (-) icon, and press OK.
7Install Additional Apps
Select the “+” and click on the Google Play Store to expand your entertainment library.
8 How to move or delete applications
Select the application and long press OK on your remote.
To move, Select Move in the list, and press OK. Use JKto move left or right. Press OK.
To delete, Select Remove from favorites in the list, and press OK.

18
4 Live TV/Antenna
The Live TV channels feature on Android TV loads television shows, sports, news, and more from
your participating TV apps or Antenna / OTA TV tuner so you can watch them all in one place.
To select channels, use CH + / – on your remote. For installation of TV channels using a set-top
box, go to “ 6 Connecting your devices ”.
Add channels
To add for the first time or additional channels, please follow the steps below:
1. On the Home menu, go to the Apps row and select How to…
2. Select Live TV to open channel installation page. Once open, select Setup and press OK.
3. Select your signal type Antenna / Cable to start the channel installation.
Channel list
Press OK while viewing Live TV to open channel list. Based on the type of channels installed,
select with the yellow color key Broadcast (conventional TV channels) or Network (internet TV
channels).
Program guide
To view the latest TV program schedule, press z(TV GUIDE) on your remote.
E Tip:
Live TV feature is only compatible with antenna and select cable broadcasting. To access
your cable box or other source inputs, you must press w(INPUT) on your remote.

19
5 The Google Assistant
Activate the Google Assistant
E Tip:
To enjoy all of the benefits the Google Assistant can provide, an internet connection and a
Google account are required.
How to use the remote
Press your Assistant button on your remote to talk to the Google Assistant. To learn more about the Google
Assistant visit https://assistant.google.com
SafeSearch filter for Google search
SafeSearch can help you block inappropriate or explicit images from your Google search results.
The SafeSearch filter helps block most adult content from your television. Parental supervision is
strongly recommended.
1. On the Android TV home screen, select Settings in the upper right corner of the screen, and press OK.
2. Select Device Preferences and press OK.
3. Select the Google Assistant and press OK.
4. Select SafeSearch filter and press OK.

20
6 Connecting your devices
How to use external devices
Connecting antenna or cable / satellite / IPTV set-top box
E Tip:
Connect your external devices to your Android TV before powering on.
If connecting to an antenna via an RF cable If connecting a set-top box via an HDMI cable
DTV programs that are broadcasted in your
area can be received for free through a digital
antenna.
If the TV is connected to a cable or satellite
set-top-box via an HDMI cable, you must select
the correct source by using w(INPUT) on your
remote.
ININ
OUTOUT
RF cableRF cableRF cable
AntennaAntenna
CableCable
IN
IN
IN
Set-top boxSet-top box
RF cableRF cable
HDMI cable
HDMI cable
OUTOUT
Changing input to devices that are connected to the TV
Press w(INPUT) to switch input device list.
E Tip:
To get the best picture quality for your source device, you may have to adjust the EDID version.
EDID 1.4 is used for legacy devices that can output in 2K or 4K @ 30Hz.
EDID 2.0 is used for modern devices that can output 4K @ 60Hz and 4K with HDR 10.
1. Press y(OPTIONS) on your remote and navigate to Settings and press OK.
2. Select Device Preferences and press OK.
3. Select Inputs and press OK.
4. Select HDMI EDID Version and press OK.
How to use Chromecast built-in
Casting allows you to mirror your favorite apps on the big screen.
E Tip:
The device you are using to cast to your television must be on the same Wi-Fi network.
1. Open a Chromecast built-in enabled app.
2. Tap u.
3. Tap the device you would like to cast to.
How to connect to your Bluetooth® devices
To pair your pair Bluetooth® devices, such as a wireless headset, keyboard, game controller, with your Android TV.
1. On the Android TV home screen, select Settings in the upper right corner of the screen, and press OK.
2. Select Remote &Accessories and press OK.
3. Enable pairing mode on your device.
4. Using your TV remote, select your device from the list shown on your TV.
5. Your Android TV will pair with your device.
E Tip:
Some devices may require additional steps. Please consult your Bluetooth device manual for more information.
