Enjoy the benefits of
Digital technology at home!
• Digital Picture and Sound quality - D-VHS enhances the Picture and Sound
quality of your recordings to a level never seen before.
• Up to 21 hours Widescreen TV-recording – Enjoy the possibility to have up
to 21 hours of recording on one tape (DF-420) with D-VHS.
• Digital Camcorder recording - D-VHS is the best archiving medium for
your Digital Camcorder videos.You can make perfect digital copies (DV to D-VHS)
with up to 7 hours of recordings on one D-VHS cassette (DF-420).
Naturally D-VHS is also the perfect digital storage medium for your
analogue camcorder recordings.
• MPEG Encoder/Decoder – The encoder makes a perfect digital picture out of
your analogue signals.The decoder turns the digital signals in an analogue
signal, so you can enjoy perfect picture and sound quality on your normalTV.
• 100% backwards compatibility - We made sure that with a D-VHS recorder
you can still use existing VHS and S-VHS tapes for recording and playback.
By this means, D-VHS manages a smooth transition into the digital future.
8 head Digital VCR
VR20D

8 head Digital VCR
VR20D
Reception
Tuner
Tuning
Tuning/Install Features
Sound System Off Air
Full (UHF + VHF + Hyperband) Tuner
FST, CH entry, 99 presets
Guide Channel Mapping, Manual Search/Store, Plug & Play
German Stereo, NICAM, Mono
User Interface
OSD Menu Languages
Time/Date Download
Picture Improvement System:
Additional Playback Standard
Audio Recording System
Audio Recording Level
Audio Dubbing
Insert
TV-Related Functions
TV-Related Control Functions
Remote Control RT597/101
English, German, Dutch, France, Italian, Spanish, Swedish, Norwegian, Finish, Danish
PDC, Text (Time/Date)
Advanced Studio Picture Control, Not applicable (Digital Image)
SMART Picture, Digital Noise Reduction,
Digital Time Base Corrector
NTSC no
FM Audio, Linear MPEG1 Layer 1 or 2
Automatic
no
no
16:9 (pin 8), Direct Record
NexTView Link (pin 10)
Backlit,TV Multicode,VCR1/2
Programming
Number of Events
Programming Mode
Record Control & Transmitter Identification
Automatic Sat. Recording
Record Speed
8/year
Remote
PDC,VPS
SCART 2
Long Play (LP), Standard Play (SP) Long Play (LS3), Standard Play (STD)
Tape Deck
Number of (S-)VHS Video/D-VHS/FM Audio/Flying Erase Heads
Play:
Additional Playback Features
Index Related Functions
Tape Length Recognition
Tape Counter
Automatic Functions at Tape End
Winding/Rewinding Time
Head Cleaning Mode
4/2/2/0
+1, -1, Repeat +1, Repeat
Still, Fast Search Speed
Next/Previous index search
Automatic
Linear relative, Linear time left
Rewind after Play - Eject after Record
100 sec (E180) 170 sec (DF420)
Automatic
Color
Front, side panels
Cover
Silver
Gray
Connectors Rear
EXT1 (AV1)
EXT2 (AV2)
EXT3 (S-IN)
EXT4 (S-OUT)
Audio Conn. Rear
Terrestrial Antenna In & Out
Mains Connector
Synchro edit
LANC edit
I.LINK (DV camcorder)
Black, Euro CVBS in/out,Y/C in/out, switchableY/C out or CVBS out
Black, Euro CVBS in/out, Euro Decoder
S-VHS in
S-VHS out
Cinch stereo in/out
75 Ohms (IECtype)
Standard (IECtype)
Mini-Jack 3,5mm
Yes no
no IEEE1394 in
Connectors Front
Audio/Video Conn. Front Cinch CVBS in, Cinch stereo in, S-VHS in
General
Voltage
Frequency
Backup Presets & Timer Events
Backup Clock & Calendar
Power Cons. in Play / Std-By
Equipment Supplied
Weight incl./excl. package in kg
Set Size -W x D x H (mm)
Packaging -W x D x H (mm)
220-240V
50Hz-60Hz
1yr
60 minutes
50W / 9W
Arial cable, Mains cord, Scart cable, S-VHS cable, Remote Control, Batteries
12 Kg/10 Kg
476 x 366 x 145
560 x 500 x 261
Comparison
Chroma bandwidth
Resolution
S/N sound
Maximum Recoding Time in Standard/Long Play Mode
S-VHS D-VHS
0.5 MHz 3.375 MHz
400 lines 540 lines
80 dB 110 dB
4 hours/8 hours (E240 tape) 7 hours/21 hours (DF420 tape)
Preliminary specifications
S-VHS/VHS D-VHS
Still, Fast Search Speed,Variable Slow Motion Speed
