Bus system connector-SACC-MSB-2SC SH PB EX-1457733
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Bus system connector, M12 male connector, PROFIBUS, shielded, B-coded, 2-pos., spring-cage connection,
metal knurl, SPEEDCON fast locking system, suitable for installation in Ex zone 2 potentially explosive areas
Why buy this product
Safe use in the field, thanks to a high degree of protection
Flexible: connectors for on-site assembly
Reliable signal transmission - 360° shielding in environments with electromagnetic interference
Save time, thanks to installation with SPEEDCON fast locking system
Key Commercial Data
Packing unit 1 STK
GTIN
GTIN 4046356627177
Custom tariff number 85366990
Note Made to Order (non-returnable)
Technical data
Dimensions
External diameter 4 mm ... 8 mm
Ambient conditions
Ambient temperature (operation) -30 °C ... 75 °C (Plug / socket)
Degree of protection IP67
General
Rated current at 40°C 2 A
Rated voltage 30 V DC
Number of positions 2
Insulation resistance ≥ 100 MΩ

https://www.phoenixcontact.com/hq/products/1457733
11/13/2016Page2/4
Bus system connector-SACC-MSB-2SC SH PB EX-1457733
Technical data
General
Coding B - inverse
Standards/regulations M12 connector IEC61076-2-101
ATEX Directive 94/9/EC IEC 60079-0 IEC 60079-11 IEC 60079-15
Declaration of conformity QSI 10 ATEX 2018U II 3G Ex nA II Gc
Shock, vibration EN 50155:2001
Status display No
Overvoltage category II
Degree of pollution 3
Connection method Spring-cage connection
Conductor cross section 0.14 mm² ... 0.5 mm²
Conductor cross section AWG 26 ... 20
Assembly instructions AWG 18 wire cross section upon request
Material
Flammability rating according to UL 94 V0
Contact material CuSn
Contact surface material Ni/Au
Contact carrier material PA 66
Material of grip body Zinc die-cast, nickel-plated
Material, knurls Zinc die-cast, nickel-plated
Sealing material NBR
Cable
Standards/specifications M12 connector IEC61076-2-101
ATEX Directive 94/9/EC IEC 60079-0 IEC 60079-11 IEC 60079-15
Declaration of conformity QSI 10 ATEX 2018U II 3G Ex nA II Gc
Shock, vibration EN 50155:2001
Standards and Regulations
Standard designation M12 connector
Standards/regulations IEC61076-2-101
Standard designation ATEX Directive 94/9/EC
Standards/regulations IEC 60079-0
IEC 60079-11
IEC 60079-15
Standard designation Declaration of conformity
Standards/regulations QSI 10 ATEX 2018U
II 3G Ex nA II Gc
Standard designation Shock, vibration
Standards/regulations EN 50155:2001
Connection in acc. with standard CUL
Flammability rating according to UL 94 V0

https://www.phoenixcontact.com/hq/products/1457733
11/13/2016Page3/4
Bus system connector-SACC-MSB-2SC SH PB EX-1457733
Drawings
Schematic diagram
4 3
1 2
5
Pin assignment M12 plug, 5-pos., B-coded
Functional drawing
16
13
3 Nm
16
0,8 Nm
20 mm
0,14 - 0,5 mm²
Ø 4 - 8 mm
33
10
12
Slide the pressure nut and sleeve housing along the cable, strip the cable, shorten the shield,
strip the single wires, connect the wires, in the case of a straight sleeve housing gently twist the
wires together, stick the shielding foil around the shortened shield, in the case of a cable outside
diameter < 6 mm stick an additional shielding foil around the wire pack, screw the sleeve housing
to the plug insert, screw the pressure nut tight.
Dimensional drawing
Ø19
M12
ca. 61
1316
M12 SPEEDCON plug, straight, shielded
Approvals
Approvals
Approvals
UL Recognized / cUL Recognized / cULus Recognized
Ex Approvals
ATEX

https://www.phoenixcontact.com/hq/products/1457733
11/13/2016Page4/4
Bus system connector-SACC-MSB-2SC SH PB EX-1457733
Approvals
Approval details
UL Recognized http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htmFILE E 118976
 
Nominal current IN 4 A
Nominal voltage UN 300 V
cUL Recognized http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htmFILE E 118976
 
Nominal current IN 4 A
Nominal voltage UN 300 V
cULus Recognized http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
