Phoenix Gold RX112D User manual

Subwoofer Manual
Manuel de subwoofer
Features Caractéristiques
Models: RX110, RX110d, RX112, RX112d
Phoenix Gold • www.phoenixgold.com
• One Piece Polypropylene Dustcap
• High Temperature 2 Inch OFC Voice Coils
• Long Throw Rubber Surround
• Optimized for Sealed or Vented Enclosures
• Rigid Powder Coated Steel Frame
• Nickel Plated 12 Gauge Speaker Terminals
• High Excursion Motor Design
• Pare-poussière monopièce
• Bobines acoustiques en cuivre exempt d’oxygène à haute température
• Enceinte d’ambiance avec contour en caoutchouc de longue portée
• Optimisé pour les boîtiers étanches ou porté
• Panier rigide en acier
• Bornes d’enceinte nickelées de calibre 12
• Modèle de moteur à grand battement

Phoenix Gold • www.phoenixgold.com
Subwoofer Owner’s Manual
Enclosures
Enclosure recommendations
ENCLOSURE INFORMATION
Phoenix Gold subwoofers are overbuilt in virtually every way conceivable. It is important that the subwoofer’s enclosure is built to these same exacting
standards. The enclosure must be constructed of at least .75 inch MDF. Screws or air staples are excellent construction fasteners when used with a strong
bonding “yellow” wood working glue that can fill joint gaps. Be sure that the enclosure’s panels are airtight at all joining seams. Lining the walls with a polyester
matting 1 to 3 inches thick is sufficient.
Your PG dealer has extensive knowledge, tools and the experience needed for the design and construction necessary for your subwoofer application. We also
recommend you consult with your dealer for specific technical assistance related to your installation. The charts provided should be used as a reference when
building an enclosure for your subwoofer. The charts contain several enclosure types. The Sound Quality enclosure provides deeper, tighter, and more musical
output to truly reproduce the original source material. The SPL enclosure fits the “basshead’s” need for maximum output while sacrificing some sound quality.
The normal enclosure is a balance between SPL and SQ.
INFORMATIONS SUR L’ENCEINTE
Les caissons d’extrêmes graves sont fabriqués en fonction de normes rigoureuses afin de fournir des années de plaisir acoustique. Il est important que
l’enceinte du caisson des extrêmes graves soit construite en fonction de ces mêmes normes rigoureuses. L’enceinte doit comprendre au moins un RP d’au
moins 3/4” de pouces. Les vis ou agrafeuses pneumatiques constituent d’excellentes pièces de fixation lorsqu’elles sont utilisées avec une colle forte de
couleur «jaune » pour le travail du bois qui peut combler les écarts de jointures. Assurez-vous que les panneaux de l’enceinte soient étanches au niveau de
toutes les piqûres de liaison. Le revêtement des murs à l’aide d’une natte en polyester épaisse de 1 à 3 pouces suffit.
Votre concessionnaire PG dispose de grandes connaissances, d’outils et d’expérience requise pour la conception et la constructions de votre application
de caisson d’extrêmes graves. Nous recommandons également de consulter votre concessionnaire afin d’obtenir une assistance technique spécifique se
rapportant à votre installation. Les tableaux fournis devraient être utilisés comme référence au moment de construire une enceinte pour votre caisson aux
extrêmes graves PG. Les tableaux présentent plusieurs types d’enceinte. L’enceinte de Qualité du son offre une sortie de musique qui est plus profonde, plus
serrée et davantage de sortie sonore afin de reproduire véritablement le matériau source d’origine. L’enceinte SPL satisfait le besoin en «basshead» pour une
sortie maximale tout en sacrifiant un peu de la qualité du son.
SEALED
VOLUME(cu.ft.)
RX110
RX110d
RX112
RX112d
SPL 0.3 0.75
Normal 0.6 1.1
SQ 0.8 1.5
VENTED - SQ RX110
RX110d
RX112
RX112d
Volume(cu.ft.) 2.0 2.25
Vent Opening(in.) 2 x 10 2 x 10
Vent Length(in.) 23 23
Tuning Freq 34Hz 32Hz
- For vented enclosures a subsonic filter set at 30Hz to 40Hz is highly
recommended.
- Sealed enclosure volumes INCLUDE THE DISPLACEMENT of the
subwoofer.
- Vented enclosure volumes INCLUDE THE DISPLACEMENT of the
subwoofer. But DO NOT include displacement of the vent.
- In many cases, a 4 inch round vent/port can be used instead of a
rectangle/slot vent. This can reduce the vent length and simply the
enclosure construction. However, in some rare cases at high power a
small amount of port noise maybe audible. The provided slot/rectangle
ports will provide maximum performance and the most predictable
results. Contact technical support for additional enclosure options.
VENTED - Normal RX110
RX110d
RX112
RX112d
Volume(cu.ft.) 1.5 1.75
Vent Opening(in.) 2 x 10 2 x 10
Vent Length (in.) 25.5 24.75
Tuning Freq 38Hz 36Hz
VENTED - SPL RX110
RX110d
RX112
RX112d
Volume(cu.ft.) 1.25 1.5
Vent Opening(in.) 2 x 10 2 x 10
Vent Length(in.) 25.25 22.5
Tuning Freq 42Hz 40Hz

Phoenix Gold • www.phoenixgold.com
Subwoofer Owner’s Manual
system diagrams
+
-
+
-
+
-
+
-
+
+
-
-
All voice coils are wired in parallel for 2 ohm load.
RX250.1 makes maximum power into 2 ohm load.
RX112d SINGLE SUBWOOFER SYSTEM
RX250.1 + (1) RX112d
Dual 4 ohm Subwoofer (wired in parallel)
Single 4 ohm Subwoofers (wired in parallel)
Single 4 ohm Subwoofer
RX400.4 makes maximum power into a 4 ohm bridged load.
RX112 DUAL SUBWOOFER SYSTEM
RX500.1 + (2) RX112
All voice coils are wired in parallel for 2 ohm load.
RX500.1 makes maximum power into 2 ohm load.
RX112 FOUR CHANNEL SYSTEM
RX400.4 + R65CX 4 ohms stereo front
and RX112 4 ohms bridged rear
Toutes les bobines mobiles sont câblées en parallèle de 2 Ohms.
RX250.1 faire puissance maximale en 2 Ohms.
RX400.4 faire puissance maximale en 4 ohm charge comblé.
Toutes les bobines mobiles sont câblées en parallèle pour
2 Ohms. RX500.1 rend la puissance maximale de charge
en 2 ohm.
-
RX250.1 Speaker Terminal
RX500.1 Speaker Terminal
+
-
RX400.4 Speaker Terminal

© 2013 Phoenix Gold • www.phoenixgold.com
Phoenix Gold
A Division of AAMP of America™
13190 56th Court
Clearwater, Florida 33760
P: 866-788-4237
[email protected]
www.phoenixgold.com
© 2013 AAMP of Florida, Inc
Designed and Engineered in the USA
LIMITED WARRANTY
Phoenix Gold warrants this product to be free of defects in materials and workmanship for a period of one (1) year from the original date of purchase. This
warranty is not transferable and applies only to the original purchaser from an authorized Phoenix Gold dealer in the United States of America only. Should
service be necessary under this warranty for any reason due to manufacturing defect or malfunction, Phoenix Gold will (at its discretion), repair or replace the
defective product with new or remanufactured product at no charge. Damage caused by the following is not covered under warranty: accident, misuse, abuse,
product modification or neglect, failure to follow installation instructions, unauthorized repair attempts, misrepresentations by the seller. This warranty does not
cover incidental or consequential damages and does not cover the cost of removing or reinstalling the unit(s). Cosmetic damage due to accident or normal wear
and tear is not covered under warranty.
INTERNATIONAL WARRANTIES:
Products purchased outside the United States of America are covered only by that country’s Authorized Phoenix Gold reseller and not by Phoenix Gold.
Consumers needing service or warranty information for these products must contact that country’s reseller for information.
Specifications
T/S Parameters: RX110 RX110d RX112 RX112d
Re (Dcr) 3.4 1.7 3.5 1.7
FS (Hz) 33.8 32.9 28.5 28.0
Sd (SqM) .035 .035 .05 .05
BL TM 12.3 8.3 13.3 8.4
Qms 4.2 4.03 3.7 3.5
Qes .553 .568 .601 .667
Qts .49 .5 .52 .56
Vas (liters) 32.6 35.8 62.63 70.60
Cms (uM/N) 191.39 210.35 183.04 206.34
Mms (gms) 116.09 111.32 169.88 156.11
SPL 90dB 90dB 90dB 90dB
Impedance Single 4 Dual 4 Single 4 Dual 4
Specifications: RX110
RX110d
RX112
RX112d
RMS Power Handling 200 watts 200 watts
Xmax (Peak to Peak) 25mm 25mm
Mounting Diameter 9 1/4in - 235mm 11 1/8in - 282mm
Mounting Depth 5 1/4in - 133mm 5 3/4in - 145mm
*Specifications subject to change
