Phoenix Mecano Okin OKIMAT 8 User manual

Quick Reference Guide to System
OKIMAT 8 RF 2,40 GHz / DELUXE N RF
OKIMAT 8 RF 2,40 GHz / CLASSIC N RF
06/2011
ID No. 8.00.300.093.00
06/2011
ID No. 8.00.300.093.00
Quick Reference Guide to System
OKIMAT 8 RF 2,40 GHz / DELUXE N RF
OKIMAT 8 RF 2,40 GHz / CLASSIC N RF
1. System overview
OKIMAT 8 / OKIMAT 8+1 / OKIMAT 8+2The system comprises a double drive of the
type with integrated radio receiver enabling trouble-free operation of several drive
systems within the radio system's transmission range.
Front view:
DELUXE N RF
Back view:
CLASSIC N RF
or
Optional:
M4 foot drive
OKIMAT 8
Underbed lighting UBB
Optional:
M3 head drive
M1
back drive
M2
thigh drive
Operating button

Quick Reference Guide to System
OKIMAT 8 RF 2,40 GHz / DELUXE N RF
OKIMAT 8 RF 2,40 GHz / CLASSIC N RF
06/2011
ID No. 8.00.300.093.00
06/2011
ID No. 8.00.300.093.00
3
21
4
56
3
1
5
2
4
6
78
3. Inserting or changing batteries
?
?
?
Insert a coin into the slot in the top of the Turn the coin obliquely and
carefully press the two halves of the housing apart.
Change the battery. Only use batteries of the CR 2032 type.
Press the two halves of the housing back together.
transmitter.
Ensure correct polarity!
2. Button configuration and symbols
DELUXE N RF
CLASSIC N RF
The transmitter is a radio transmitter with a maximum of 8 push-buttons.
The transmitter is a radio transmitter with a maximum of 6 push-
buttons. The number and function of the buttons depends on the equipment and
function of the drive system.
Functions LED
Button Function
1,3,5 Drives UP
2,4,6 Drives DOWN
1 and 2 Underbed lighting
Functions LED
Button Function
1,3,5 Drives UP
2,4,6 Drives DOWN
7,8 Underbed lighting
Coin
CLASSIC N RF
DELUXE N RF
CLASSIC N RF
Symbol Function
Head adjustment
Back adjustment
Thigh adjustment
Foot adjustment
Tilt mattress base of bed
Adjustment of all drives
simultaneously

Quick Reference Guide to System
OKIMAT 8 RF 2,40 GHz / DELUXE N RF
OKIMAT 8 RF 2,40 GHz / CLASSIC N RF
06/2011
ID No. 8.00.300.093.00
06/2011
ID No. 8.00.300.093.00
4. Putting into operation
4.1. Operating button
operating
button
?
?
?
Plug the mains plug into the wall socket.
Wait at least 10s before proceeding with the following steps.
In order to carry out these steps, it will be necessary to actuate the
. By carefully pressing the button, various drive functions can be called up.
Do not dispose of batteries with the normal household waste!
Coin
DELUXE N RF
Operating button

Quick Reference Guide to System
OKIMAT 8 RF 2,40 GHz / DELUXE N RF
OKIMAT 8 RF 2,40 GHz / CLASSIC N RF
06/2011
ID No. 8.00.300.093.00
06/2011
ID No. 8.00.300.093.00
21
Functions LED
34
Put the drive systems into service one after the other. attempt to put several
drive systems into service simultaneously. otherwise the drives will be unable to
assign the or transmitters precisely.
Do not
DELUXE N RF CLASSIC N RF
If the drive does not start up when the button is pressed, briefly release the button and then
press it again If necessary, repeat this procedure.
4.2. Programming the DELUXE N RF / CLASSIC N RF transmitter
operating button drive 2x short press
RF-receiver
buttons 1-2 simultaneously and keep them pressed
DELUXE N RF CLASSIC N RF
DELUXE N RF CLASSIC N RF
In order to put the handset into operation, radio communications with the drive must first
be established.To do this, proceed as follows:
Give the on the in succession. The
underbed lighting comes on, the now switches to the learning mode for
approx. 10s.
Press until the underbed
lighting extinguishes and the function LED glows constantly (programmable process
approx. 10s)). The learning mode of the or
transmitter is completed.
The or transmitter is ready for operation.
?
?
?
4.3. Programming the DELUXE N RF or CLASSIC N RF transmitter onto 2nd drive
DELUXE N RF or CLASSIC N RF
Drive 1:
DELUXE N RF or CLASSIC N RF
Drive 2:
operating button drive 2x short press
RF-receiver
DELUXE N RF or CLASSIC N RF
buttons 3-4 simultaneously
Sequence for programming a to learn 2nd RF
receiver.
Proceed with the as described under section 4.2.
Give the on the second in succession. The
underbed lighting comes on, the now switches to the learning mode for
approx. 10s.
Proceed further with the as described under
section 4.2., now you must press the .
?
?
?

Quick Reference Guide to System
OKIMAT 8 RF 2,40 GHz / DELUXE N RF
OKIMAT 8 RF 2,40 GHz / CLASSIC N RF
06/2011
ID No. 8.00.300.093.00
06/2011
ID No. 8.00.300.093.00
(2)
(1)
(3)
4.5. Attaching or removing the fastening clip
(1) (3)
DELUXE N RF CLASSIC N RF
carefully (3)
?
?
To attach, press the fastening clip into the two notches on the underside (2)
of the or transmitter. The fastening clip snaps into
place.
To remove, prize the fastening clip out of the two notches .
4.4. Deactivating the DELUXE N RF / CLASSIC N RF transmitter
operating button drive 4x short press
operating button 1x
DELUXE N RF CLASSIC N RF
If the learning procedure for an RF transmitter has been unsuccessful or the transmitter
is taken out of service, you can interrupt communications between the transmitter and
the drive as follows:
Give the on the in succession. The
underbed lighting comes on. Now actuate the . The underbed
lighting extinguishes and the or transmitter is
deactivated.
?

Quick Reference Guide to System
OKIMAT 8 RF 2,40 GHz / DELUXE N RF
OKIMAT 8 RF 2,40 GHz / CLASSIC N RF
06/2011
ID No. 8.00.300.093.00
06/2011
ID No. 8.00.300.093.00
Underbed lighting
UBB
5.4 Resetting
5.5. Resetting in the event of a power failure
not
The resetting function allows the mattress base of the bed to be moved to the sleeping
position in the event of a power or hand transmitter failure (e.g. batteries depleted).
Power is supplied to the OKIMAT 8 via two 9V-block batteries. In order to prevent the block
batteries from discharging prematurely, these are connected at the factory. Only at the
time of the emergency should the batteries be connected to achieve resetting. Movement of
the drive is limited to a one-time emergency manual operation. Afterwards, the block
batteries must be replaced in order to ensure resetting for the next emergency situation. The
drives can be moved to the home position by pressing the operating button.
5. Operation
5.1. Basic adjustment functions
5.2. Operating the underbed lighting (UBB) DELUXE N RF
button 7 or 8
button 7 or 8
5.3. Operating the underbed lighting (UBB) CLASSIC N RF
button 1 - 2 simultaneously
button 1 - 2 simultaneously
After having been put into operation in accordance with section 4., the drive system is
ready for use.
By actuating buttons 1 - 6 (see section 2, availability and function depending on the
drive system) the drive can be operated.
Press (symbol , see section 2), the LED of the UBB lights up.
Press (symbol ) again, the UBB extinguishes.
Press (see section 2), the LED of the UBB lights up.
Press again, the UBB extinguishes.
?
?
?
?

Quick Reference Guide to System
OKIMAT 8 RF 2,40 GHz / DELUXE N RF
OKIMAT 8 RF 2,40 GHz / CLASSIC N RF
06/2011
ID No. 8.00.300.093.00
06/2011
ID No. 8.00.300.093.00
Battery clip
Battery
5.6 Emergency lowering on failure of the DELUXE N RF or CLASSIC N RF
transmitter
The drives can be moved to the home position by pressing the operating button.
6. Table of faults/errors
Should a fault/error occur that is not listed in this table, please contact your supplier.
- Check that batteries are poled correctly.
- Change the batteries.
- Check the mains connection of the drive,
if necessary restore it.
- Check whether the transmitter has under
gone the learning procedure. If this is the
case, then the control system is defective.
- Reduce the distance to the drive system
(receiver)
- Ensure that no other transmitter is operated
simultaneously, e.g. garage door opener, car
key etc.
- Check whether the transmitter has
undergone the learning procedure.
- Check the mains power and if necessary,
restore it
- Repeat the learning procedure
- Contact your dealer
Relearn the transmitter-
LED in the
or does not
light up
Receiver does not respond
Despite programming, no
function
Several receivers react
simultaneously
DELUXE N RF
CLASSIC N RF
Problem Solution
