Instruction manual

HYMN-1-APP / HYMN-5-APP

LED hymn boards with APP control

(2- / 10-line)

™

HYMN-1-APP / HYMN-5-APP —LED hymn boards with APP control (2- / 10-line)

DOC-200224

Phoenix Professional Audio GmbH

Gewerbepark Markfeld 5

83043 Bad Aibling / Germany

Tel.: +49(0)8061-495603-0

Fax: +49(0)8061-495603-1

www.phoenix-pa.com

www.phoenix-pa.com/shop

www.phoenix-pa.com / www.phoenix-pa.com/shop

Phoenix logo is registered with the German Patent and Trademark Ofce (TM)

All trademarks are the property of their respective owners

ENGLISH

LED matrix

APP control

Various colours

2 or 10 lines

Operation with tablet / software

Incl. APP & accessories (full version)

Suitable for tablet & other Android devices

Run through before the church service starts

Excellent readability

High-resolution LED matrix

Input with special characters possible

Colours can be choosen by the user

Suitable for listed buildings (tripod solution)

No WiFi / WLAN required on site

Reading distance available from 35m to 70m

LED indicator off WHITE

Unobtrusive, at design

Maintenance-free - NO additional costs

+DEMO

V 1.0

BOOK

1-2+6

Song

1 u 6

G 805

1+4-7

12345

abcde

Phoenix logo is registered with the German Patent and Trademark Ofce (TM).

All trademarks are the property of their respective owners.

Instruction manual

™

HYMN-1-APP /HYMN-5-APP

- 1 -

IMPORTANT SAFETY INSTRUCTIONS

1. Please note the safety instructions and study these instructions carefully

2. Keep all notices and instructions

3. Only use the device in the manner intended

4. Respect the disposal laws applicable in your country; Please separate plastic and paper or cardboard boxes when

disposing of them

5. If your device does no longer work properly, has been exposed to liquids or has been damaged in any other way, leave

any type of repairs to authorized specialists only

6. Keep the hymn board and all components away from sources of heat and moisture

7. Check all power source connections - DO NOT use defective outlets, cords or connectors

8. Only use the mounting material that we have supplied.

9. If lost, please feel free to contact us; we expressly point out that the use of other fastening materials for wall bra-

ckets or tripod brackets can damage the HYMN-1-APP / HYMN-5-APP. In this case, the warranty claim expires

10. Please check all components for completeness and possible damage immediately after receipt of the delivery

GENERAL INFORMATION

Dear Customer,

We are pleased that you have decided to use our hymn board model „HYMN-1-APP“ or „HYMN-5-APP“ with

APP control.

During development and production, we have set ourselves the goal of being able to provide the user with an

innovative, modern and yet user-friendly display system.

By using the highest quality components, sophisticated assembly techniques and eld-tested tablets, we

guarantee trouble-free, long-term use at the highest level.

Our product was developed according to the strictest quality criteria and meets all common standards.

We hope you enjoy using our product and are happy to answer any questions you may have about the hymn

board.

Phoenix logo is registered with the German Patent and Trademark Ofce (TM).

All trademarks are the property of their respective owners.

Instruction manual

™

- 2 -

HYMN-1-APP /HYMN-5-APP

SCOPE OF DELIVERY

• LED hymn board(s) (according to your order)

• Connection cable for power supply

• Wall mount with mounting kit (tripod mount

optionally available)

• Gateway (radio transmitter) with power cord

• operation manual

• 7“ Android tablet with pre-installed APP

• Original accessories & operating instructions

(for the tablet)

WARRANTY CONDITIONS

The statutory guarantee conditions apply.

Only use the components supplied by us.

Power supplies with incorrect voltage rating can cause damage to the display, for which we do not guarantee

take over. If, contrary to expectations, you have a problem, we will gladly help you quickly. Please contact us

as soon as possible so that we can arrange everything for you. The warranty claim also expires in the event of

improper repairs by non-authorized workshops. Proof of purchase (proper invoice from the seller) is required

to claim warranty services. The guarantee is provided exclusively for the original purchaser.

POST-GUARANTEE SERVICE

Since the HYMN-1-APP / HYMN-5-APP model is our own product, we are still at your disposal for adjustments,

extensions and service years later.

Accessories such as wall brackets, cables, mains adapters or tripods can be purchased separately in the event

of damage or loss.

Phoenix logo is registered with the German Patent and Trademark Ofce (TM).

All trademarks are the property of their respective owners.

Instruction manual

™

- 3 -

HYMN-1-APP /HYMN-5-APP

1. HYMN BOARD / LED PANEL

2. RADIO TRANSMITTER (GATEWAY)

Connect the WLAN transmitter (connection to the hymn board) to the power supply.

PLEASE MAKE SURE THAT THE TABLET IS ALWAYS IN THE RECEPTION RANGE

OF THE WLAN TRANSMITTER (see Appendix A)

3. TABLET

• Mount the Vesa mount in a convenient location where the

hymn board can be seen from all seats.

• Fasten the hymn board with the 4 threaded screws provided.

• Plug the barrel connector of the supplied power pack (12~24V

DC, 5.5/2.1mm) into the socket provided on the back of the

hymn board.

• Now connect the power pack to a power source (socket or

optional battery power pack)

• Please only use the supplied plugs and cables for this purpose.

• When using the tablet for the rst time, please follow the manufacturer‘s original operating instruc-

tions.

• Now use the tablet to dial into the WLAN „Liedanzeige“ (hymn board) (you can nd the procedure for

this in the original operating instructions for the tablet supplied)

• If you do not receive a connection conrmation, please check whether the hymn board and the radio

transmitter are correctly connected to a power source or whether you have used the cables provided

(radio - black). If this is the case, reduce the distance between the radio transmitter and the tablet

(max. 10-15 meters, depending on the structural conditions, shielding, etc.)

INSTALLATION

Phoenix logo is registered with the German Patent and Trademark Ofce (TM).

All trademarks are the property of their respective owners.

Instruction manual

™

- 4 -

HYMN-1-APP /HYMN-5-APP

INSTALLATION

3.1 OPERATING SOFTWARE (APP)

The operating software for the hymn board is already

pre-installed by us and is started via the APP „RemoteXY“

(we put it on page 1). In this app (RemoteXY) you will nd

the icon with the label „Liedanzeige“ (hymn board), which

enables the actual communication with the song display.

It is a fully-edged tablet that you can of course use in all

available applications.

However, please make sure that the APP installed by us

is retained in any case.

If you accidentally delete the app, we are of course happy

to help. We ask for your understanding that this is outside

the scope of the guarantee.

Please press the button „Liedanzeige“ (hymn board) - the display „Connecting“ will now appear briey - che-

cking the connection to the gateway.

The gateway (radio transmitter) serves as a connection from the tablet to the receiver of the hymn boards

and is also mandatory for starting the operating software.

You are now automatically in the entry mode of page 1.

If this is not the case, check possible causes of the error as described in Appendix B.

INPUT SOFTWARE (APP - HYMN BOARD)

Phoenix logo is registered with the German Patent and Trademark Ofce (TM).

All trademarks are the property of their respective owners.

Instruction manual

™

- 5 -

HYMN-1-APP /HYMN-5-APP

1. FUNCTIONAL OVERVIEW

1.1. RECORDING OF DISPLAY TEXTS

A total of 20 memory locations (2 lines each) are available on pages 1 to 4.

The hymn boards HYMN-1-APP and HYMN-5-APP allow you to

use the full character set of the tablet including special charac-

ters, upper and lower case. Each line is limited to 5 digits. Only

the choir boards HYMN-1-40 and 1-70 as well as the main board

HYMN-5-50 cannot distinguish between upper and lower case

due to the smaller letter height. This means that if you use a

HYMN-1-140-APP as the main board for example, you will see the

board displayed exactly as on the tablet, but at the same time only

capital letters displayed on the choir board.

Tapping on the corresponding eld takes you to the input mode

(on-screen keyboard). For further information on using the key-

board, please refer to the tablet‘s original operating instructions.

MEMORY button for ALL entries

Switch to the basic settings menu „CONFIG“

Switch to the COLOR menu

Memory slots

1-5 / page 1 11-15 / page 3

6-10 / page 2 16-20 / page 4

Control button

RED - song no. / verse is currently being displayed

on the LED board

Input elds song number / verse

Quick switch to next song number / verse display

on the LED board

INPUT SOFTWARE (APP - HYMN BOARD)

DEMO

V 1.0

BOOK

1-2+6

Song

1 u 6

G 805

1+4-7

12345

abcde

Phoenix logo is registered with the German Patent and Trademark Ofce (TM).

All trademarks are the property of their respective owners.

Instruction manual

™

- 6 -

HYMN-1-APP /HYMN-5-APP

Deletes the input of the corresponding line

You now enter the rst line on page 1, here in the example DEMO

Now do the same for line 2

Both lines do not necessarily have to be captioned at the same time, alternatively you can use only one of the

two lines.

Please be sure to press the SAVE button (top right) after entering the song number.

In order for you to see the entry / entries on the LED board, you must set the desired line to ACTIVE.

To do this, press song number “1”.

The button next to the song number now lights up red

You can now see your input from line 1 on the LED panel

INPUT SOFTWARE (APP - HYMN BOARD)

DEMO

V 1.0

BOOK

1-2+6

BOOK

1-2+6

1 u 6

Song

Enter new value

Cancel Enter

DEMO|

BOOK

1-2+6

1 u 6

Song

BOOK

1-2+6

1 u 6

Song

Enter new value

Cancel Enter

Enter new value

Cancel Enter

V 1.0|

Phoenix logo is registered with the German Patent and Trademark Ofce (TM).

All trademarks are the property of their respective owners.

Instruction manual

™

- 7 -

HYMN-1-APP /HYMN-5-APP

1.2 RECORDING IN MEMORY 1 TO 4

The procedure for recording memories is the same as for individual recording (1.1).

Up to 20 displays are available in the 4 memories.

You can also make the recordings in the parish ofce or at home, but please note that you must take the radio

transmitter with you in any case. This prepares your entries for output on the hymn board and must be in

operation when recording. Otherwise the APP would give you the error message „disconnected“ and not

forward you to the input elds.

1.3 DISPLAY OF SAVED ENTRIES

After recording and SAVING all entries and, if necessary, selecting the color with „F“, you can now send all

data to the displays during the service with just one keystroke. Press „1“ (the red control button lights up);

the rst song number appears on the hymn board. To call up the „2“ and more, you only have to press the

„Next“ button. The red control button now automatically jumps to “2”, etc.

1.4 RUN-THROUGH OF SAVED ENTRIES (PAGE 4)

A very useful option to give the parish the opportunity to prepare hymn books BEFORE the service starts.

2. SETTINGS OF DISPLAY COLORS / MENU F

You have the option of designing EVERY display line separately in countless RGB colors.

To do this, go to the COLOR menu „F“ - as shown in the function overview.

You can choose different colors for the song number and verse.

The song numbers/verses are displayed continuously in the order

entered. The software checks your entries and only outputs occupi-

ed elds. For example, if you have stored data for No. 1 to No. 7, the

run at No. 7 automatically jumps back to No. 1.

It will show No.1 (for 2 seconds) and then song number/verse (for 20

seconds) No. 2 song number/verse etc. The duration of the display is

set like this as standard. An adaptation to your wishes can be made

by us. If, for example, no text was entered in line song 5, i.e. the eld

is empty, the run will always only be displayed from 1 to 4, and then

it will start again from the beginning. It is therefore essential to

avoid empty memory locations between the recorded song numbers.

As soon as the service begins, it is essential to OFF the run-through so that only the current song number/

verse can be released for display by the organist, for example.

INPUT SOFTWARE (APP - HYMN BOARD)

Phoenix logo is registered with the German Patent and Trademark Ofce (TM).

All trademarks are the property of their respective owners.

Instruction manual

™

- 8 -

HYMN-1-APP /HYMN-5-APP

To make a color selection, move the outer ring to the desired color box. The second, inner circle controls the

color intensity of the display (bright/dark). You can see the result of your choice in the inner circle.

These entries can IMMEDIATELY be seen on the LED display.

Proceed in the same way for the line „Verse“. Here, too, every change is IMMEDIATELY visible.

3. BASIC SETTINGS / TIMER / MENU C „CONFIG“

3.1 SETTING THE DISPLAY DURATION (TIMER FUNCTION)

In normal mode, the display of the entered text will be shown on the LED DISPLAY until you make a selec-

tion either by song number or „next“. In addition, the software enables you to generate the display duration

via a timer function.

To do this, use the C button to go to the CONFIGURATION menu

DISPLAY DURATION

Optionally from 1 to 100 seconds.

The song number/verse disappears automatically after the entered time has elapsed.

SAVE input

Back to page 1,2,3 or 4

Control display of the selected color

COLOR selection ring

Color intensity light/dark

INPUT SOFTWARE (APP - HYMN BOARD)

Phoenix logo is registered with the German Patent and Trademark Ofce (TM).

All trademarks are the property of their respective owners.

Instruction manual

™

- 9 -

HYMN-1-APP /HYMN-5-APP

INPUT SOFTWARE (APP - HYMN BOARD)

3.2 BRIGHTNESS

Your LED display is equipped with a sensor and automatic brightness adjustment, which regulates itself depen-

ding on the incidence of light on the display. In automatic mode, EACH of the displays may adjust itself separate-

ly; as soon as you switch to manual brightness control, your entry applies to ALL mounted hymn boards SAME.

An individual adjustment to the ambient light is only possible via the automatic function.

Manual setting

To do this, switch the automatic to OFF and move the slider to the RIGHT to make it brighter, to the LEFT to

make it weaker.

To reactivate the internal brightness sensor of the LED displays, switch the automatic function to ON.

Selection via slider

Left 0 ………… Right 100

ON / OFF

Here, too, your entry is only permanently recorded when

you press the „Save“ button.

Slider for manual adjustment

RIGHT brighter LEFT weaker

Brightness control

ON / OFF

Phoenix logo is registered with the German Patent and Trademark Ofce (TM).

All trademarks are the property of their respective owners.

Instruction manual

™

- 10 -

HYMN-1-APP /HYMN-5-APP

HYMN BOARD / LED MATRIX („HYMN-1“ / „HYMN-5“)

HYMN BOARD GATEWAY (RADIO TRANSMITTER) MATRIX

WiFi IEEE 802.11 b/g/n 2.4GHz (reception from input device)

Radio transmitter/receiver Frequency 868 MHz (For hymn board)

Wireless range free eld About 200m

Power supply 5V/500mA (plug power supply / USB)

Current consumption / mean value 100mA/5V

Dimension 85 x 65 x 28 mm (W x H x D)

Weight about 0.1 kg

TECHNICAL SPECIFICATIONS

Radio transmitter / receiver Frequency 868MHz

Wireless range free eld about 200m

Power supply 12~24V DC / 1400….700mA

Plug-in power supply 220-240 VAC (operation with 115 VAC possible on request)

Power consumption / mean value 1000mA/12VDC

Dimension Depending on the version ordered

Weight Depending on the version ordered

Character height Depending on the version ordered

Dot matrix Depending on the version ordered

Depiction 2 lines (HYMN-1-APP) or 10 lines (HYMN-5-APP) /

5 characters per line

Display type Colored design in RGB colors individually adjustable per line via soft-

ware; Alphanumeric in the full character set of the tablet keyboard

Reading distance Depending on the version ordered

Brightness control Manually via software or automatically via the built-in sensor

Timer function Display duration adjustable via software

Phoenix logo is registered with the German Patent and Trademark Ofce (TM).

All trademarks are the property of their respective owners.

Instruction manual

™

- 11 -

HYMN-1-APP /HYMN-5-APP

TABLET (SAMPLE CONFIGURATION - SUBJECT TO AVAILABILITY)

TECHNICAL SPECIFICATIONS

Brand Lenovo

Model/series TAB3 A7-10

Item weight 299 g

Product dimensions 19 x 1 x 11.3 cm

Colour black, blue

Form factor tablet

Screen size 7 inch

Screen resolution 1024x600 pixels

Processor speed 1.3GHz

Processor cores 4

RAM size 1GB

Storage technology LPDDR3 SDRAM

Storage Art DDR4 SDRAM

Random access memory 1GB

Size of hard disk 8GB

Permanent storage Flash

Audio output 3.5mm

Chipset manufacturer ARM

Connectivity type WIRELESS INTERNET ACCESS

WiFi type 802.11B, 802.11G, 802.11n

Operating system Android

Battery type Lithium Ion (Li Ion)

Average battery life 10 hours

Lithium battery capacity 50 watt hours

Phoenix logo is registered with the German Patent and Trademark Ofce (TM).

All trademarks are the property of their respective owners.

Instruction manual

™

- 12 -

HYMN-1-APP /HYMN-5-APP

APPENDIX A / FUNCTIONAL SCHEME – RADIO TRANSMISSION

Phoenix logo is registered with the German Patent and Trademark Ofce (TM).

All trademarks are the property of their respective owners.

Instruction manual

™

- 13 -

HYMN-1-APP /HYMN-5-APP

APPENDIX B / ERRORS AND FIXES

TABLET DOES NOT START THE APP

Possible causes

A) No WLAN connection to the gateway

Under SETTINGS on your tablet, check whether the WLAN connection with „Liedanzeige“ (hymn board) is

available. If this is not the case, check whether the gateway is correctly connected to a power source or whe-

ther you are within the recommended reception range of the gateway (see Appendix A).

If the range has not been exceeded, carry out a RESET on the gateway.

To do this, use a pen or something similar to press the small button to the right of the LED control light for

around 10 seconds. Now restart the tablet and establish the connection via the ICONS RemoteXY and hymn

board.

B) After starting RemoteXY, there is no shortcut „Liedanzeige“ or the software has been updated

Delete and regenerate link.

To regenerate the link to „Liedanzeige“ in the APP RemoteXY, proceed as described below

1: Click on „+“ at the top right

2: Select „Wi-Fi Point“

3: In the Wlan-ssid window, select „Liedanzeige“. If „Liedanzeige“ is not available for selection

switch on the tablet‘s WLAN, click on the round double arrow at the top right. It should now all

available WLANs are listed. Select „Liedanzeige“.

4: Now the program should be started

5: The color or parameters of the created icon/shortcut can be changed by long pressing on it

Icon/Shortcut “Liedanzeige” can be changed

NO PRESENTATION ON THE HYMN BOARD

Possible causes

A ) The hymn board is not properly connected to a power source.

B ) The supplied power supply unit was not used - ATTENTION !! In this case, the electronics of your hymn

board may have been damaged - WARRANTY LOST!!

C ) The reception between gateway and hymn display is disturbed

Through reections, reinforced concrete, niches, etc. reception may be disrupted.

Bring the gateway closer to the hymn board and reboot the system.

With larger distances and several hymn boards, it may be necessary to use an additional repeater. In this

case, please contact us.

Phoenix logo is registered with the German Patent and Trademark Ofce (TM).

All trademarks are the property of their respective owners.

Instruction manual

™

- 14 -

HYMN-1-APP /HYMN-5-APP

HYMN-5-110 HYMN-5-70 HYMN-5-50

Type Main display Main display Main display

Reading distance up to 35-45 m up to 20-25 m up to 12-15 m

Dimensions (WHD) 39 x 102 x 3.5 cm 32 x 96 x 3.5 cm 26 x 53 x 3 cm

Number of LEDs 24,500 12,288 8,000

Digit height 110 mm 70 mm 50 mm

Lines 10 10 10

HYMN-1-180 HYMN-1-140 HYMN-1-100 HYMN-1-70

Type Main display Main display Main display Choir display

Reading distance up to 60-70 m up to 50-55 m up to 35-40 m up to 15-20 m

Dimensions (WHD) 60 x 45 x 3 cm 48 x 32 x 3 cm 40 x 30 x 3 cm 32 x 16 x 3 cm

Number of LEDs 6,100 6,100 6,100 3,050

Digit height 180 mm 140 mm 100 mm 70 mm

Lines 2 2 2 2

• 2 lines

• 2-fold display

• 5 characters

per line

HYMN-1 SERIES

MODELS

• 10 lines

• 5-fold display

• 5 characters

per line

HYMN-5 SERIES

Instruction manual

™

- 15 -

HYMN-1-APP /HYMN-5-APP

Disclaimer

The author points out that the representations, explanations, calculations and the like contained in the guideline are only of an exemplary nature. They

reect the current state of knowledge and the current legal situation, but do not claim to be complete.

In view of the complexity of construction projects, the development of individual solutions related to the respective project is essential.

Liability for all descriptions, applications, references and transfers of parts of the guideline or individual information is hereby expressly excluded.

Important instructions

The following applies to all pages of this description:

Subject to technical changes and printing errors.

The illustrations are similar, subject to color deviations.

Phoenix logo is registered with the DE Patent and Trademark Ofce (TM)

All trademarks are the property of their respective owners.
