Photinus aron User manual

INSTALLATION AND
OPERATING INSTRUCTIONS
V.1|2017
aron |aron duo
aron duo aron

3
www.photinus.at | Installation and operating instruction aron V.1 |2017
SAFETY INSTRUCTIONS
AND WARNINGS
This LED solar street and parking lot light meets the prescribed safety regulations.
Improper use may cause damage to persons or property. Read this manual prior
to installation.
INTENDED USE
Only use this solar lamp outdoors to illuminate streets, paths, parking lots, or similar
areas. Other applications are potentially dangerous. Photinus is not liable for damages
caused by improper use or incorrect operation.
TECHNICAL SAFETY
Check the solar lamp for visible damage prior to installation. Do not install or operate
a damaged solar lamp.
Faulty components must only be replaced with Photinus original spare parts. Only
when these parts are used can Photinus ensure that they are in complete compliance
with safety requirements.
Improper repairs can result in unforeseeable danger to users, for which Photinus ac-
cepts no responsibility. Repairs may only be performed by authorized Photinus techni-
cians, otherwise subsequent damage will not be covered by the warranty.
Do not make any modifications to the aron lamp that are not expressly approved by
Photinus.
1

4
www.photinus.at | Installation and operating instruction aron V.1 |2017
INTENDED USE
Only install your aron lamp in the recommended foundations. Photinus recommends
either a pipe foundation or a screw foundation. If in doubt, contact your dealer.
OPTIMAL PLACEMENT
In order for the solar lamp to perform optimally, it needs to be installed in a location
with direct sunlight and not shaded buildings or trees.
PHOTINUS CANNOT BE HELD RESPONSIBLE FOR DAMAGES RESULTING FROM FAILU-
RE TO COMPLY WITH SAFETY INSTRUCTIONS AND WARNINGS.

5
www.photinus.at | Installation and operating instruction aron V.1 |2017
2
INCLUDED PARTS
1aron power unit
1aron lamp unit
1aron lamp pole
6 M8 screws
1Installation and user guide
TOOLS REQUIRED
1Allen wrench 4mm
1Allen wrench 5mm

6
www.photinus.at | Installation and operating instruction aron V.1 |2017
INSTALLATION
NOTE
When scheduling the installation, make sure that the outside temperature does not
drop below freezing on the day of installation or on the next three days after installa-
tion. On the first few days, the system will record the new environmental conditions,
such as hours of daylight. During this period, the battery may initially be discharged
completely. This in combination with very low temperatures can cause damage to the
battery.
STEP 1
MOUNTING THE POWER UNIT TO THE LAMP UNIT
Unpack the power unit carefully and check it for shipping damage. Remove the trans-
port safety mounting (4 pieces) from the bottom of the power unit using the 5mm
Allen wrench.
3
ATTENTION
Do not press on the solar panels!
Unpack the lamp unit and check it for shipping damage. Connect the yellow plug on
the power unit with the yellow plug on the lamp unit (pay attention to the white mar-
kings!). Then connect the black plug on the power unit with the black plug on the lamp
unit (pay attention to the white markings once again!).

7
www.photinus.at | Installation and operating instruction aron V.1 |2017
STEP 2
PREPARATION LAMP POLE
Unpack the lamp pole and check it for shipping damage.
All cables must then be stowed in the holding tube of the light housing. Take the
screws from the transport safety mounting and secure the lamp unit to the power
unit.
PLEASE SELECT THE CORRECT END OF THE LAMP POST WHEN MOUNTING! THE UPPER
END HAS A TOTAL OF 6 DRILL HOLES!
UPPER END
LOWER END

8
www.photinus.at | Installation and operating instruction aron V.1 |2017
FIGURE 3 FIGURE 4
STEP 3
MOUNTING THE POWER UNIT LAMP TO THE LAMP POLE
Attach the 6 M8 threaded pins to the lamp post with two to three turns.
Then slide the power unit/lamp onto the lamp post to the stop (see figure 3).
Now you can fix and center the lamp post by tightening the 6 M8 threaded pins
(see figure 4).
ATTENTION
Tightening torque 8 Nm minimum – 12Nm maximum.

9
www.photinus.at | Installation and operating instruction aron V.1 |2017
STEP 4
LAMP UNIT ANGLE ADJUSTMENT
Remove the fitted coverings on the side of the lamp unit and loosen the 4
screws. The desired angle of the lamp unit can now be selected and then
fixed by retightening the screws.
BY LOOSENING THE SCREWS ON
THE SIDE OF THE LAMP UNIT,
THE ANGLE CAN BE ADJUSTED.
STEP 5
INSTALLING THE LAMP POLE
Mount the lamp pole in either a screw foundation or a pipe foundation as
is described in the following pages. When standing up the lamp pole, it is
necessary to use mechanical aid.

10
www.photinus.at | Installation and operating instruction aron V.1 |2017
STEP 5 - FOUNDATION
MOUNTING POSSIBILITY 1 - PIPE FOUNDATION
SOIL
CONCRETE PIPE Ø30cm
GRAVEL/SAND
DRAINAGE (GRAVEL)
CONCRETE RING 10cm
POLE DIAMETER 89
1000
800
CA DN 300
