PHOTONIS PD-PRO-16B User manual

User's Manual
PD-PRO-16B
Night Vision Binocular
Night Vision

Night Vision
p. 2

Safety
• An internal component within the image intensier tube contains toxic materials. During normal
operation, the operator will never come into contact with this component. However, if the tube
is damaged or broken, avoid inhalation or ingestion of the phosphor screen materials, and avoid
contact with open wounds. If the toxic material comes into contact with your skin, wash the aected
area with soap and water. If any material is swallowed, drink large quantities of water, induce
vomiting and seek medical assistance as soon as possible.
• The objective protective cover must always be tted when the night vision goggle is not in use.
Damage to the image intensier can occur if subjected to a strong light source such as daylight for
extended periods, even when power is switched o.
• Never point the PD-PRO-16B towards a bright light source such as the sun. City lights, car lights or
any brightly reecting object will not damage auto-gated tubes.
• Always remove the battery aer use and before repackaging.
• Dry the PD-PRO-16B completely before replacing it in the transit/carrying case.
• Take care when using the ‘‘IR" position ‘3’ of the operation switch an IR light is beaming around,
which can easily be detected by observers and bright light is shining out of the eyepiece, if not
covered.
• For underwater operations, use only the PD-PRO-16B-SUB, which is specially designed to withstand
depths of up to 20m and equipped with Plano-Plano windows.
ENSURE THE LENS IS TIGHTENED FIRMLY BEFORE IMMERSION.
Limited Warranty
The manufacturer of this device has provided a limited warranty to the original purchaser. It was
attached to manufacturer’s terms and conditions of sale.
p. 3

SAFETY.............................................................................................................................................................. 4
Chapter 1 ........................................................................................................................................................... 5
Scope of Manual ............................................................................................................................................. 5
PD-PRO-16B Night Vision binocular ......................................................................................................... 5
General Description.............................................................................................................................. 5
Main Operational Components........................................................................................................ 6
Technical Data ....................................................................................................................................... 9
NVLS-24 Adapter...........................................................................................................................................10
Diver’s Version MINIMUS-BINO-SUB.......................................................................................................10
Cleaning .............................................................................................................................................................11
Optional Accessories .................................................................................................................................... 12
Manual Control Gain (Optional Version)...................................................................................... 12
External Battery Pack (Optional Version).................................................................................... 12
Carrying and storage so case ........................................................................................................ 13
Hard Shell Case .................................................................................................................................... 13
Sacricial Window............................................................................................................................... 13
Demist Shield........................................................................................................................................14
Chapter 2..........................................................................................................................................................15
General ..............................................................................................................................................................15
Safety.................................................................................................................................................................15
Battery Installation........................................................................................................................................15
External battery pack connection (optional)........................................................................................16
Preparation for Use........................................................................................................................................16
Stand Alone Operation.................................................................................................................................16
General Operating Guidelines....................................................................................................................16
Activating the IR light....................................................................................................................................16
Low battery indication .................................................................................................................................. 17
Head-Mounted Operation ........................................................................................................................... 17
Ergonomic Head Mount ..................................................................................................................... 17
Fitting the Head Mount ...................................................................................................................... 17
Attachment of the Helmet Adapter............................................................................................... 17
Head/Helmet-Mounted, PD-PRO-16BOperations....................................................................18
Removing the PD-PRO-16Band Head Mount .............................................................................18
Operation at Low Temperature..................................................................................................................18
Operation at High Temperature.................................................................................................................19
Operation in Humid or Dusty conditions.................................................................................................19
Transportation and Storage........................................................................................................................19
Chapter 3.........................................................................................................................................................20
General .............................................................................................................................................................20
Preventive Maintenance .............................................................................................................................20
Optical Surfaces..................................................................................................................................20
Table of Contents
1.
2.
2.1
2.2
2.3
3.
4.
5.
6.
6.1
6.2
6.3
6.4
6.5
6.6
7.
8.
9.
10.
11.
12.
12.1
12.2
13.
13.1
13.2
13.3
14.4
13.5
13.6
14.
15.
16.
17.
18.
19.
19.1
Night Vision
p. 4

External Surfaces................................................................................................................................20
Eyepieces Assembly...........................................................................................................................20
Objectives assembly ..........................................................................................................................20
Operation switch.................................................................................................................................20
Cleaning ...........................................................................................................................................................20
External Surfaces................................................................................................................................20
Optical Surfaces................................................................................................................................... 21
Demist Shield........................................................................................................................................ 21
Elements replacement................................................................................................................................. 21
Replace Objective Cover.................................................................................................................... 21
Replace Eye-guard.............................................................................................................................. 22
Replace Battery Cap .......................................................................................................................... 22
Replace Anti-fog / Demist lens ...................................................................................................... 22
Replace Sacricial Lens.................................................................................................................... 22
List of Figures
Figure 1 PD-PRO-16B Dierent Versions ...................................................................................................................6
Figure 2 NVLS-EVO Components Location .............................................................................................................. 6
Figure 3 NVLS-PD-PRO-16B Operating Principle.................................................................................................... 8
Figure 4 NVLS-24 Adapter............................................................................................................................................ 10
Figure 5 Possible NVG Congurations ........................................................................................................................11
Figure 6 Diver Using Possible Congurations ..........................................................................................................12
Figure 7 Typical So Case..............................................................................................................................................13
Figure 8 Typical Hard-Shell Case ................................................................................................................................13
Figure 9 Sacricial Window...........................................................................................................................................13
Figure 10 Demist Shield....................................................................................................................................................14
Figure 11 External Battery Pack Interconnection .....................................................................................................16
Figure 12 Ergonomic Head Mount ................................................................................................................................. 17
Figure 13 Combinations of Universal Head/Helmet Mount..................................................................................18
19.2
19.3
19.4
19.5
20.
20.1
20.2
20.3
21.
21.1
21.2
21.3
21.4
21.5
p. 5

Chapter 1
General Description
1. Scope of Manual
This manual provides description, operating instructions and eld maintenance procedures for the
PD-PRO-16B Night Vision Binocular.
This manual is intended to help you operate and properly maintain the device and promote trouble-free
and ecient operation.
2. PD-PRO-16B Night Vision Binocular
CAUTION
The PD-PRO-16B is a precision electro-optical device. HANDLE IT WITH CARE!
2.1. General Description
The PD-PRO-16B(see Figure 1 and Figure 2) is a lightweight, ruggedized, metallic alloy night vision
BINOCULAR system. It oers a high resolution and clear bright image in a lightweight conguration.
The PD-PRO-16B operation is passive; the light available at the scene is electronically intensied so that
targets can be observed without articial illumination.
The PD-PRO-16B provides a stereoscopic vision to facilitate spatial vision, to drive, measure distances, etc.
The PD-PRO-16B is equipped with a built-in Infra-Red (IR) light, which gives additional close-range
covert illumination.
WARNING
When the IR light is activated, the emitted light can be detected by other image intensifying equipment.
The PD-PRO-16B employs a pair advanced Photonic image intensier tubes characterized by high
resolution and a clear, bright image. 4G auto-gated tubes are the standard conguration.
The PD-PRO-16B is powered by a single “AA” 1.5V, alkaline or lithium battery, or with an external battery
pack with capacity for two alkaline batteries “AA” 1.5V
The system operates under every ambient temperature from -40ºC to +55ºC.
The PD-PRO-16B includes LOW BAT indicator (LED green) in the top of eld of view of right arm, and
IR activation indicator (LED red) in the top of eld of view le arm that providing indications to operator
about state of the system.
The PD-PRO-16B is small and light enough to be hand-held, head mounted or helmet-mounted.
Night Vision
p. 6

Figure 1- MINIMUS-BINO Dierent Versions
2.2 Main Operational Components
The PD-PRO-16B is composed of the following main operational components (see Figure 2):
• Operation switch
• Objectives cover
• Objectives focus
• Diopters rings
• Eye-guards
• IR LED illuminator
• Battery compartment
• Mounting recess
Options:
• Manual Control Gain
• External Battery Pack
Figure 2 NVLS-EVO Components Location
1. Objective Cover
2. Objective Focus
3. Eyepiece Diopter Ring
4. Eye-guard
5. IR LED
6. Manual Gain Control (OPTIONAL)
7. Operation Switch
8. Battery Cap
9. Mounting Recess
10. External Power Connector (OPTIONAL)
11. External Battery Pack (OPTIONAL)
12. Power Wire (OPTIONAL)
p. 7

2.2.1. Operation Switch
A three-position rotary switch controls the operation of the MINIMUS-BINO.
WARNING
The IR position is very dangerous when used in the eld, since you will be visible to external observers using
image intensied equipment.
Operation switch of the PD-PRO-16B
The Operation switch of the PD-PRO-16B has three dierent positions:
Position 1:“OFF/M”. The device is disconnected and turns ON each arm of the BINOCULAR when
attached to the helmet mount or head mount and each arm is aligned with the eye of the operator.
When the PD-PRO-16B is ipped to side, the equipment disconnects automatically, preventing the
operator from emitting uncontrolled light that can be detected by the enemy. When reattached to the
helmet mount and aligned with the operator’s eye, the equipment restarts automatically, without need
to restart the ON/OFF switch.
WARNING
Before ipping the goggle into the up position, ensure each channel is rotated up to obtain the ultra-low prole
over the helmet.
Position 2: "ON". In this position the device is on when each arm is aligned with the eye of the operator.
This position activates the PD-PRO-16B for the use in manual mode, as observation binocular; the main
magnetic sensor is disabled.
Position 3: "IR”. In this position the system works like 2 position and a short-range IR illuminator
switching on. This position has two modes, instantaneous or continuous, for instantaneous mode turn
the knob to position 3 and keeps it clamped, when you release it, automatically will return to position 2.
To keep the IR illuminator continuous; pull the knob slightly outwards and then turn it to the position 3.
Night Vision
p. 8

WARNING
*IMPORTANT NOTE FOR OPERATOR SAFETY*
The use of the IR illuminator in open spaces makes the operator visible for outside observers with night
vision. We recommend using it only in conned spaces or extreme situations.
2.2.2. Objective Focus
The objective focus allows adjusting the focus from 15 cm to innity by turning the objective lens.
2.2.3. Diopter Ring
The PD-PRO-16B eyepiece enables diopter adjustment to suit dierent user eyesight, by means of the
diopter ring. It is attached to the eyepiece and provides continuous adjustment from -6 to +2 diopters.
2.2.4. IR LED Illuminator
The PD-PRO-16B is equipped with a built-in IR 935 nm diode (almost invisible for Gen 3 IIT), which gives
additional close-range covert illumination. The illuminator is activated by setting the operating switch to
IR position. A red indicator is displayed in the eld of view indicating that the IR illuminator is active.
2.2.5. Battery Compartment
The PD-PRO-16B battery compartment accepts a single “AA” size battery 1.5 alkaline or lithium and
provides inverse polarity protection.
2.2.6. Mounting Recess
The recess is the mounting surface between the PD-PRO-16M and the helmet mount or head mount.
2.2.7. Neck Cord (optional)
The PD-PRO-16B can be provided with a neck cord for user’s convenience. The type of neck cord can be
suited to customer’s requirements.
2.2.8. Operating Principle
The PD-PRO-16B operation principle is depicted in Figure 3 and is the same for boot goggle arms. Light
entering the objective lens is focused onto the image intensier. The image intensier (2) receives the
optical image from the objective lens (1) in the form of light energy, focused onto the photo cathode (4).
The photocathode is a light-sensitive surface, when light hits the surface it emits electrons.
The optical image is transformed into an electronic one, intensied by a micro-channel plate, and
projected onto the phosphor screen at the rear of the image intensier. This can then be seen through
the eyepiece (3).
The PD-PRO-16B uses 4G 16mm high performance tubes with green or white phosphor, characterized
by low weight, high gain, reduced halo and reduced blooming eect, which normally occurs when
viewing a bright light source.
Figure 3 MINUMUS-BINO Operating Principle
p. 9

The tube also contains Automatic Brightness Control (ABC) and Bright Source Protection (BSP) and
Auto Gated power supply, that gives a steady state of screen brightness under varying light conditions
and high resolution, including conditions normally too bright for a night vision device.
2.3. Technical Data
2.3.1. Physical Characteristics
a. Length: 100 mm
b. Width: 100-170 mm
c. Height: 60-80 mm
d. Weight: < 440 g
2.3.2. Performance
a. Magnication: x1 ± 3%
b. Field of View: > 40º
c. Image Intensier Tube: 4G
d. Phosophor Green or White
2.3.3. Objective Lens
a. Focal Length: 22.7 mm
b. F Number: 1.03
c. Focusing Range: 15 cm to innity
2.3.4. Eyepiece
a. Focal Length: 22.7 mm
b. Eye Relief: 25 mm
c. Diopter Adjustment: -6 to +4 diopter
d. Distortion Lower than 2%
2.3.5. Electrical Data
a. Power Source: Single 1.5V “AA” size battery
b. Reverse Polarity Protection: Yes
c. Minimum Operating Time:
AA 1.5V battery:
> 10 hours (al 21ºC)
External Battery Pack
(x2 AA) >30 hours
d. Auto-gating
When using auto-gated tubes there will be no shut down of the tubes, even at high light levels
of 5000 lux. The center resolution stays at not less than 55 lp/mm under these conditions,
allowing a normal operation at dynamic light levels conditions.
Night Vision
p. 10

Figure 4 NVLS-24 Adapter
3. NVLS-24 Adapter
The NVLS-24 adapter enables head-mounted use of the
PD-PRO-16B (using helmet mounts for helmet and Skull
Crusher, diver’s masks, etc.). The adapter is composed of
the following (see Figure 4):
1. Quick Release: Separate for a strong hold and put
together to make a quick separation system.
2. Height Control: Move to the right in order to release
the mounting, setting the proper height and
then turn to the le to secure the position.
3. Release the Adapter: Press to release the NVLS-24
adapter.
4. Flip-Up: Press and move up to separate night vision
system from eld of view.
5. Proximity Control: Press the two buttons at the same
time and move forward and backward, release the
buttons and the system will be xed.
6. Release Mono/Bino Bridge: Press to release the
Mono/Bino Bridge system.
7. Tilt Control: Turn CW or CCW to adjust the angle of vision.
4. Diver’s Version PD-PRO-16B SUB
(Only for submersible version)
The optional diver’s face mask enables positioning of a single PD-PRO-16B SUB in front of the diver's
eye without using his hands, while wearing a diver's mask. The PD-PRO-16B SUB in this conguration is
water-tight, eliminating the need for additional sealing of the PD-PRO-16B SUB before entering the water
and enabling immediate re-use of the PD-PRO-16B SUB when out of the water.
Figure 5 Possible NVG Congurations
p. 11

CAUTION
Typically, the PD-PRO-16B is not designed for under-water operations.
Use only the PD-PRO-16B SUB, which is specially designed to withstand depths of up to 20m and
equipped with Plano-Plano windows.
CAUTION
FIRMLY TIGHTEN THE LENS BEFORE IMMERSION.
Figure 6 Diver Using Possible Congurations
5. Cleaning
CAUTION
The goggles are a precision electro-optical instrument and must be handled carefully.
Do not scratch the external lens surfaces or touch them with your ngers.
Wiping demist shields with lens paper while wet or with wet lens paper can damage the coating.
Clean goggles with water if necessary and dry completely. Clean lenses with lens paper (and water if
necessary, except for demist shields). Demist shields must be dry before being cleaned with dry lens paper.
6. Optional Accessories
The PD-PRO-16B may be supplied with one or more of the optional accessories described in the
following paragraphs.
6.1. Manual Control Gain (Optional Version)
You can modify the system gain by turning the manual gain control. Note that manual gain control will
remain disabled when the Auto-gating system is activated and the Auto-gating system is automatically
activated in high-light conditions
6.2. External Battery Pack (Optional Version)
WARNING
Never use external and internal batteries together.
An external battery pack with two alkaline batteries size “AA” must be connected to power the system. If
system is powered with the external battery pack, make sure that the internal battery is not installed.
NOTE
Never connect the external battery pack while there is a battery installed in the goggle’s battery holder.
Night Vision
p. 12

6.3. Carrying and storage so case
The so case (gure 8) is a user congurable system used for carrying the PD-PRO-16B under eld
conditions or for storing it inside the hard case. The so case provides protection from eld damages.
The system consists of three counterweight elements, with an individual weight of 187 gram that can be
tted according to the operator’s preference.
Figure 7 Typical So Case
6.4. Hard Shell Case
The hard-shell case (Figure 9) is used for storing the so case with PD-PRO-16B and its accessories
under eld conditions. The case is water and air-tight and its interior is prepared to accommodate the
so case.
Figure 10 Typical Hard-Shell Case
6.5. Sacricial Window
The PD-PRO-16B is provided with sacricial windows (see Figure 10) to protect the objectives and the
eyepieces lens from scratches caused by blowing sand or other abrasive conditions. In order to install
them on the PD-PRO-16B the sacricial windows should be screwed over the objectives or eyepieces lens.
NOTE
The sacricial window can be installed only in PD-PRO-16B units that have an objective or eyepiece with
a thread.
p. 13

Figure 11 Sacricial Window
6.6. Demist Shield
The demist shield (see Figure 11) prevents the eyepiece from fogging over when the PD-PRO-16B is cold
or being used in cold and humid conditions. It is made of plastic and is installed between the eye-guard
and the eyepiece. The demist shield must be handled by the edge only. Special attention shall be paid
to cleaning and handling of the shield (see paragraph 3.2.1).
Figure 12 Demist Shield
Night Vision
p. 14

Chapter 2
Operation
8. General
This chapter provides operating instructions for the PD-PRO-16B.
CAUTION
The PD-PRO-16B is a precision electro-optical device - handle it with care!
9. Safety
An internal component within the image intensier tube contains toxic materials. During normal
operation, the operator will never come into contact with this component. However, if the tube is
damaged or broken, avoid inhalation or ingestion of the phosphor screen materials, and avoid contact
with open wounds.
a. If the toxic material comes into contact with your skin, wash the aected area with
soap and water. If any material is swallowed, drink large quantities of water, induce
vomiting and seek medical assistance as soon as possible.
b. The objective protective cover must be tted at all times when the night vision goggle is
not in use. Damage to the image intensier can occur if it is pointed to a strong
light source such as daylight for extended periods, even when power is switched o.
c. Never point the night vision goggle towards the sun, even when shut o and with an
objective cover with pinhole. The center of the photocathode can be damaged. When
training at daylight a totally shuttered objective cover or a neutral density lter must be
used. A searchlight, a camera ash or any brightly reecting object, at distances of
more than 5 meter will not damage auto-gated tubes. Never point a visible or IR laser
towards eyepiece or objective as the tube will be damaged permanently.
d. Always remove the battery aer using and before repackaging, to avoid acid leakage due
to defective battery and permanent damage to the electronic board of NVLS EVO.
e. Rinse thoroughly in tap water aer immersion in sea water to prevent drying of salt deposits.
f. Dry the night vision goggle completely before replacing it in the tactical bag or hard-shell case.
g. Take care when using the V and IR positions of the operation switch. In V position bright
light is shining out of the eyepiece, if not covered. In IR position IR light is beaming
around, which can easily be detected by enemy forces and bright light is shining out of
the eyepiece, if not covered.
10. Battery Installation
CAUTION
The PD-PRO-16B is powered by a single 1.5V "AA" size alkaline or lithium battery. Do not use any other
type of battery. Batteries with a higher voltage will damage the MINIMUS-BINO.
a. Turn the battery cap counterclockwise to remove it from the battery compartment.
b. Make sure the battery compartment is clean and dry.
c. Make a note of the polarity indicated on the side of the PD-PRO-16B and install a battery.
d. Put the battery cap in position at the battery compartment.
e. Turn the battery cap clockwise until the battery cap is tightly closed and gives a good seal against
the “O”-ring.
p. 15

11. External battery pack connection (optional)
WARNING
Never use external and internal batteries together.
An external battery pack can be connected to power the system.
a. If the system is powered with the external battery pack, make sure that the internal battery is
not installed.
b. Remove the two battery caps in the external battery pack.
c. Make sure the two compartments of the batteries are clean and dry.
d. Make a note of the polarity indicated on the side of the battery pack and install a battery in
each compartment.
e. Put the two-battery caps back into position at the batterie compartments.
f. Connect the battery pack to the PD-PRO-16B using the proper wire.
Figure 11 External Battery Pack Interconnection
Make sure that there is not battery installed on the goggle when powering the system using the external
battery pack.
Never connect the external battery pack while there is a battery installed in the goggle battery holder
12. Preparation for Use
a. Remove the PD-PRO-16B from the carrying case, or pouch.
b. Examine the PD-PRO-16B for damage. If damage is found return the PD-PRO-16B to a
suitable maintenance facility.
c. Make sure that the operation switch is set to OFF.
d. Make sure that all lenses are clean.
e. Install a battery (see paragraph 2.3) or connect the external battery pack (see paragraph 2.4).
f. With the objective protective covers on, turn the operation switch to ON position to check function.
13. Stand Alone Operation
(Without Head mount or Helmet Mount)
a. When the PD-PRO-16B is removed from the head mount or helmet mount and the main
switch are at position ‘OFF/M’, the magnetic switch automatically turns the unit o.
b. To operate the PD-PRO-16B as a stand-alone device, turn the operation switch to the “ON” position.
Night Vision
p. 16

14. General Operating Guidelines
14.1. Activating the IR light
WARNING
When the IR light is activated, the emitted light can be detected by other image intensifying equipment.
NOTES
- The Infra-red (IR) light is not visible to the naked eye.
- The use of a 935 nm IR diode will make it hardly visible for user’s whit tubes Gen III
- To activate the IR light, proceed as follows:
a. Turn the operation switch to IR position.
b. Make sure that a red LED illuminates in the eld of view in the le arm, this indicates that the
IR light is active.
14.2. Low battery indication
If a green LED light illuminates in the eld of view of the right arm, indicate that the battery is near to be
empty, in this condition, the battery must be replaced as soon as possible.
NOTE
-The battery in this condition will allow approximately 30 minutes of operation.
15. Head-Mounted Operation
Head mounted operation refers to using of the PD-PRO-16B along with a head mount (option), helmet
mount (option) or diver’s mask (option).
15.1. Ergonomic Head Mount
The new ergonomic head mount allows the use of the same BINOCULAR helmet adapter.
Figure 12 Ergonomic Head Mount
p. 17

15.2. Fitting the Head Mount
a. Loosen all straps and unclick the chin support
b. Place the head mount on your head. When necessary loosen also the rotary adjustment
wheels to get a comfortable feeling.
c. Close the chinstrap, tighten the straps and nish by adjusting the three rotary wheels until the
head mount sits rmly and in the correct, cantered position of your head and face.
d. Attach the head/helmet adapter with the NVLS-24 adapter by inserting it into the
NVLS-24 receptacle.
e. Adjust the BINOCULAR to get a comfortable and circular vision, centered in front of your eye.
When necessary readjust head mount and BINOCULAR.
f. The PD-PRO-16B allows the individual ip to side of each arm and the binocular ip-up.
15.3. Attachment of the Helmet Adapter
a. Insert the head/helmet adapter on the NVLS-24 adapter and then click the assembly into the
helmet NVLS-24 shroud, starting the insertion on the top side of the NVLS-24 shroud and
pushing rmly the bottom until the interface plate is completely inserted and locked. Adjust
the height if needed by releasing the locking lever.
b. Position the clutch adapter in the fully forward position.
c. When using a single PD-PRO-16B, it should be rst placed in front of the required eye and
then adjusted.
d. Moving of the PD-PRO-16B from eye to eye is done by releasing the central locking screw,
pushing the arm slightly away from the face until it is released from the dent, moving towards
the other eye until it engages the second dent and locking again the central screw.
e. Fine adjustment of the PD-PRO-16B in front of the eye is done by means of the height
adjustment and the rotation of the BINOCULAR aer pressing rmly the clutch.
f. When using binocular conguration proceed in the same way as with BINOCULAR
conguration for each system.
Figure 13 Combinations of Universal Head/Helmet Mount
Night Vision
p. 18

15.4. Head/Helmet-Mounted, PD-PRO-16B Operations
a. Take o the objective protective cover (in low light conditions only) and position it under the
PD-PRO-16B. Opposite side of the electronic housing.
b. Set the operation switch to OFF for magnetic switch-controlled operation.
c. Adjust the diopter ring to achieve the clearest screen resolution (sharp spots on the
eyepiece). Does not focus on an object yet; put your palm over the objective front lens, to
only allow a small amount of light into the PD-PRO-16B. Once set for your eye, it should
not require further adjustment during operation.
d. Adjust the objective focus ring to obtain a clear image of a desired object. Readjust eyepiece
and objective if necessary.
NOTE
The mounting adapter incorporates a magnetic switch that automatically turns o the PD-PRO-16B
when it is moved to the side away from the eye, switched between eyes or removed from the head mount.
15.5. Removing the PD-PRO-16B and Head Mount
a. Set the PD-PRO-16B operation switch to OFF.
b. Disconnect the neck cord from the anchor point on clothing or webbing.
c. Make sure that the objective protective cover is in position.
d. Press and hold the NVLS-24 release button on the mounting adapter.
e. Pull the PD-PRO-16B o the dovetail of the adapter assembly.
f. Loosen all straps and unbuckle the chin support.
g. Remove the head mount over your head.
h. Remove the battery from the PD-PRO-16B.
16. Operation at Low Temperature
At very low temperature (below zero) it can require more eort to operate the PD-PRO-16B controls
than in warmer conditions. This is normal. Do not attempt to force the movement of controls as this can
damage the working parts.
The capacity of the battery is reduced at low temperatures. This reduction in battery life is normal and
battery depletion will increase as the temperature decreases.
17. Operation at High Temperature
The PD-PRO-16B can be operated up to 55˚C, but wherever possible protect the battery from excessive heat.
The PD-PRO-16B can be subjected to sudden changes in temperature. But if the PD-PRO-16B is
moved from a cold area (A/C acclimatized) into an area with a much higher temperature and humidity,
condensation can occur on the optical surfaces.
18. Operation in Humid or Dusty Conditions
In humid or dusty conditions, extra care must be taken to keep all surfaces (particularly the optical
surfaces) clean at all times.
When using for diving the sacricial at-at lenses must be rmly attached to objective and eyepiece.
Adjust eyepiece diopter and focusing ring at 1-meter depth.
Aer immersion in salt water, all elements of the goggle must be cleaned with fresh water for
dissolving salts and dried completely with a clean cloth. Salt will corrode any material over a
medium or long-term duration. This will particularly impact the Magnesium variant of the PD-PRO-16B.
p. 19

19. Transportation and Storage
When the equipment is to be transported or stored for long periods, proceed as follows:
a. Remove the battery.
b. Make sure that the objective protective cover is in position.
c. Carry out a visual inspection of the PD-PRO-16B and the accessories.
d. Clean and dry the PD-PRO-16B and accessories.
e. Place the PD-PRO-16B in the tactical bags and the accessories in the hard-shell case.
Night Vision
p. 20
