PHOTONIS PD-PRO-Q User manual

Quick Start Guide
PD-PRO-Q
Panoramic Night Vision Device
Photonis Defense, Inc.
1000 New Holland Avenue
Lancaster, PA 17601
PD-PRO-Q-QSG Rev: 48/20
Download the full maintenance manual
using the QR Code provided above.
Maintenance of the
PD-PRO-Q
Cleaning Instructions:
1. Remove any dust and dirt using a
cleaning brush or air pressure.
2. If available, apply a light coat of demist
compound to the lenses and wipe o
with a clean annel cloth.
NVG Inspection:
1. Inspect NVG lenses for cracks,
scratches or chips. Check that
the range focus rings rotates freely in
both directions.
2. Check that the threads (for sacricial
windows) on the objective and
eyepiece housing are not damaged.
3. Inspect NVG exterior surfaces for
damage and loose parts or screws.
4. Check that the daylight covers are
properly seated and secure.
5. Inspect function switch for
completeness and security (ensure in
the OFF position).
6. Check that the function switch can be
moved to all four positions. Must pull
the switch out before setting to ON-V
or ON-IR.
7. Check the battery cap and compartment
are complete and free of corrosion.
8. Inspect NVG mounting recess for damage.
9. Inspect eyecup for damage and perforations.
Inspect the Sacricial Windows:
1. The sacricial windows are also the antifog windows for your device.
2. Remove any dust and dirt using a cleaning brush or air pressure.
3. Remove the Sacricial/Antifog windows from the device by turning them counterclockwise direction.
4. Wash lenses with clean, fresh water soaked into a so cotton cloth.
5. Apply a light coat of anti-fog compound to the lenses and wipe o with a clean so cotton cloth in a
circular motion from the center of the lens moving outward.
6. Replace the Sacricial/Anti-Fog windows onto NVG by turning them in a clockwise direction.
Night Vision
Quick Start Guide
PD-PRO-Q
Panoramic Night Vision Device
Night Vision
Field of View Remarks/ Corrective Action
GPNVG positioned too low.
Correct height adjustment.
GPNVG positioned too high.
Correct height adjustment.
IPD too narrow. Correct IPD
adjustment.
IPD too wide. Correct IPD
adjustment.
IPD too narrow AND eye
relief too long. Correct IPD
adjustment and fore and a
adjustment.
Eye relief too long. Correct fore
and a adjustment.
Eye relief too short. Correct
fore and a adjustment.
Field of View Interpupillary Adjustments

Operating Instructions
WARNING:
Your NVGs are a precision electro-optical instrument; handle them with care.
Do not remove the daylight covers from the objective lenses at any time until you are ready to
use them in a dark and/or nighttime environment and especially do not remove in bright sunlight.
Damage to the image intensier tube may result from exposure to sunlight and will invalidate your
warranty. The Bright Spot Protection capability built into your PD-PRO is designed for bright lights at
night such as headlights or streetlights and will not suciently protect the system from the intense
rays of the sun. Do not touch or scratch the external lens surfaces. Clean NVGs and dry thoroughly
and clean lenses with lens paper prior to storage. For detailed instructions see the User’s Manual
by using the QR code provided on the back page of this guide.
Warning:
1. Internal components within the image intensier tube contain toxic materials.
2. If the image intensier tube is damaged or broken, avoid inhalation or ingestion of the phosphor
screen material, and avoid contact with open wounds.
3. If the toxic material comes in contact with your skin, wash the aected area with soap and water immediately.
4. If any material is swallowed, drink large quantities of water, induce vomiting and seek medical
assistance as soon as possible.
Fit to Helmet/Harness Mount:
1. Slide the NVG mount onto the helmet/harness attachment until it rmly seats.
2. Additional counterweights are supplied and can be tted in case the external counterbalance battery
pack itself is not sucient.
3. Attach the NVG dovetail adapter (#5) to the swivel mechanism mate (audible “click” will sound).
4. Move NVG until eyecup touches the face in front of the eye and adjust the mount for eye separation distance.
5. See the User’s Manual for details about the NVG mount and its component parts.
Caution: New devices and mounts will be tight. Do not force the dovetail into the mount – use gentle
pressure to secure the NVG to the mount.
External Battery Attachment:
1. The PD-PRO-Q can ONLY be operated in conjunction with the provided external battery pack.
2. Install batteries in the battery pack. The external battery back is designed as a counterbalance.
Additional counterweights have been provided if needed.
3. With the NVG in the OFF position attach the external battery pack to either a helmet or harness and
ensure it is secure. Attach the battery cable to the battery pack and then connect the cable to the
NVG at the power receptacle port located near the dovetail mounting attachment (#6).
4. The external battery pack has two (2) position switches, le and right, to activate the battery cell
on each side of the battery pack. Switch one of the cells to the ON position. The other cell should be
activated by turning it to the ON position aer the depletion of the rst cell.
Operation Check:
1. The function switch has four (4) positions: (1) OFF; (2) ON; (3) IR; (4) IR Continuous.
2. Check the function switch to ensure it is in the OFF position (1) and the daylight covers are in place
(Never remove the daylight covers except for low-light level use).
3. Switch the function switch (#1) to the ON position 2; ensure the NVG is operating by looking through
the diopters to see an image of the surrounding environment.
4. Switch the function switch to IR position 4 (you must pull the switch out before setting) and check
that the red LED is visible on the NVG screen.
5. Return the function switch to the OFF position. The system is now operational and is ready to be
adjusted for visual acuity to suit the individual user – see optical adjustments below.
Optical Adjustments:
1. Your PD-PRO panoramic goggle has two optical adjustments to rene the clarity of system’s image.
2. The diopter (#3) is adjustable using Snap-on lenses to adjust for a user’s individual eyesight
requirements. Your system comes with individual Snap-on lenses from +2 to -6 range.
3. Once the diopters have been installed the Objective Lenses (#4) can be focused by twisting them
clockwise and counterclockwise to ne tune the image.
4. Using the Interpupillary Distance adjusters (IPD) (#2), adjust the interpupillary interval to meet
individual requirements (See the See the Field of View Interpupillary Adjustment chart in this guide
to adjust the eld of view for the individual user.
Helmet/NVG Magnetic ON/OFF Function Check:
1. With the NVG attached to the mount and in the operational position in front of the eyes turn the
Function Switch to the ON position 2 with the daylight covers in place.
2. Rotate the swivel mechanism on the mount into the up position and ensure the NVG switches OFF
by observing the NVG screen image has turned black. Move the mechanism into the down position
to ensure the device turns ON and an image is visible in the view screen.
Operating in Adverse Conditions
Operating in Dusty/Sandy Environment:
1. Sand and dust can pit/scratch the optical elements and damage the mechanical components if
precautions are not taken.
2. Ensure the sacricial windows (#7) protecting the objectives are in place.
3. Avoid pointing the device into the wind unless necessary.
4. Keep the carrying case closed.
5. Ensure the NVG and case are cleaned aer use.
Operating in Wet/Humid Environment:
Warning: The PD-PRO-Q has parts made from magnesium and can be damaged by salt water. Clean
thoroughly with fresh water aer exposure to salt water.
1. PD-PRO-Q is water resistant to 10-meters (33-feet) but is not intended for use in diving operations.
2. Wet/Humid conditions can cause corrosion and deterioration of the NVG without precautions.
3. Ensure the sacricial windows are in place.
4. Keep the carrying case closed.
5. Dry the NVG, mount, and accessories aer exposure prior to storage.
Warning: Do not store NVG in a wet carrying case or storage case as severe damage may result.
1
3
Function Switch
IPD Adjusters
Diopter
Objective Lens/
Range Focus Adj.
Power Receptacle
Mount Adapter
2
6
4
5
Sacricial Window
7
