Phottix Juno TTL User manual

En INSTRUCTION MANUAL
1
INSTRUCTION MANUAL
說明書
En
Cn Trad
Phottix Juno TTL
Transceiver Flash

2

En INSTRUCTION MANUAL
3
Note: To start immediately using this ash please refer to the Quick-Start guide.
For advanced features please read this manual and be familiar with your camera
manual and operations.
The Phottix Juno TTL Transceiver Flash for Canon is designed to work with
Canon DSLR cameras and features ETTL I/II, Manual, Multi Modes as well as
Wireless (Radio and Optical) triggering.
Warnings
1. Use your ash safely. Do not re the ash into the eyes of people or animals at
short distances – damage and/or blindness can occur.
2. Be careful using the flash in or around cars, buses, motorcycles or other
moving vehicles as accidents can result.
3. Never use the ash near combustible gases (gasoline, solvents, etc.).
4. Do not expose the flash or batteries to dripping/splashing water, or high
humidity.
5. Do not leave the ash or batteries in a hot location (direct sunlight, in a closed
car, etc.).
6. Remove batteries from the ash when not being used for an extended period
of time.
7. Change the batteries when required. Use undamaged batteries in good
condition. Do not mix battery types or new and used batteries.
8. Do not put opaque objects in front of the ash lens when ring the ash. The
energy emitted by the ash may cause objects to burn, or cause damage to the
ash tube or fresnel lens.
9. Use caution in touching the ash head after use. It may be hot and can cause
burns.
10. The flash contains high voltage electronic parts. Do not disassemble or
attempt to repair the ash. Never touch the ash’s internal components.
11. Do not touch the External Power Port contacts with any metal objects – this
can cause electric shock and serious injury.
Table of contents
1. Parts and Function .......................................................................................... 4
2. Flash Set-up ....................................................................................................... 5
3. LCD display ........................................................................................................ 9
4. Functions and Operations ............................................................................14
5. Wireless triggering ..........................................................................................19
6. Other Functions .............................................................................................. 29
7. Custom Function ............................................................................................ 29
8. Technical Specications ............................................................................... 31
9. Appendix ........................................................................................................... 32

4
1. Parts
Back/Left side
1. LCD Display
2. Mode Button
3. Test Button/ Ready Light
4. Locking Lever
5. Function Button 1
6. Function Button 2
7. Function Button 3
8. Function Button 4
9. Power Switch
10. Selection Dial
11. OK Button
12. External Power Port
13. PC Sync Port
14. Micro USB Port
Front/Right side
1. Flash Head Locking Button
2. Battery Compartment
3. Bounce Card
4. Wide Angle Diuser
5. Flash Head
6. Optical Signal Receiver
7. AF Assist Light
8. Hot Shoe

En INSTRUCTION MANUAL
5
2. Flash Set-up
This manual assumes：
1. Both the ash and camera are switched on.
2. The ash and camera are set to the same settings as this manual.
3. Camera menu and ash custom Functions menu are set to default values.
4. The ash is being used with a compatible camera.
Installing Batteries
1. Press the battery cover in while pushing it towards the bottom of the ash.
The battery cover will open and raise.
2. Insert AA batteries as shown by the diagram inside the battery compartment
3. Lower the battery cover and push back towards the top of the ash, locking it
in place.
Please note:
- Please use four standard high-quality batteries of the same brand. Make sure
all batteries are at similar power levels.
- Batteries can get hot when the flash is being used. Use caution when
changing batteries.
- If you do not use the flash for an extended period of time, store with
batteries removed.
- The Juno TTL Flash circuitry is designed to be used with either Alkaline, Ni-
CD or NiMH rechargeable batteries. Do not use Lithium AA batteries.
Battery Level Indicator
The Battery Level Indicator on the LCD (see below) will display an approximate
indication of how much power remains in the batteries in the ash. Use this as
a rough guide as to when a battery change is needed. If ash recycling time has
become very long (30 seconds) change the batteries.
Status LED
Flash-ready indicator. In Quick Flash Mode, the LED will turn green when the
ash has the minimum recycle charge. It will turn red when fully charged.
External Battery Port
The External Battery Port is compatible with the Canon CP-E4 compact battery
packs, or compatible equivalents.

6
Please note:
- Batteries must be used in the ash even when an external battery pack is
used.
- Do not use non Canon-compatible battery packs.
Overheating Protection
The Phottix Juno TTL contains an overheating protection circuit that will slow
ash recycle time to avoid overheating-related damage. Approximately 30 full-
power ashes in a short amount of time will trigger this protection. Stop using
the ash and wait 10 minutes for it to cool down.
Sync and USB Ports
1. The PC Sync Port can be used with a PC Sync Cable to trigger the ash – from
a ash trigger or camera. This port is input only – ash signals are not output
from this port.
2. The Micro USB port is used for rmware upgrades. Firmware announcements
and instructions will be made available on Phottix websites.
Attaching the Flash to the camera
1. Turn o both the camera and ash
2. Align the ash hot shoe with the camera hot shoe.
3. Slide the ash into the camera hot shoe until fully inserted.
4. Lock the ash in position by pushing the locking lever to the right until the lock
engages with a click.
5. To Unlock, press the locking release Button on the locking lever and slide to
the left.
Turning the Flash On/ O
1. To power on the ash move the power switch to the on position.
2. To power o the ash move the power switch to the o position.
3. To Lock the ash：Move the power switch to the“LOCK”positios. This “locks”
the Buttons and Dial of the ash, so setting cannot be accidentally changed.
Raising and Rotating the Flash Head
1. The ash head will elevate from -7 to 90 degrees with stops at -7, 0, 45, 60, 75
and 90 degrees.
2. To Adjust: Press the Flash Head Locking Button and gently raise or lower the
ash head into the desired position.

En INSTRUCTION MANUAL
7
3. The ash head will rotate 180 degrees in either direction with stops at 30, 60,
90, 120, 150 and 180 degrees.
4. To Adjust: Press the Flash Head Locking Button and gently rotate the flash
head into the desired position.
5. When the ash head is raised or rotated from the 0 degree standard forward
position the ash zoom will set itself to 50mm. “- -” will be displayed on the LCD.
Flash zoom when the head is raised or rotated can be changed in MZoom Mode
(see below).
6. At -7 degrees the ash zoom will act the same as 0 degree – it will not change
any settings.
Using the Bounce Card or Wide Angle Diuser
The Phottix Juno TTL Flash comes equipped with a White Bounce Card and Wide
Angle Diuser Panel in the ash head.
1. The Wide Angle Diuser Panel will cause the ash to spread light to a 14mm
equivalent.
2. The White Bounce Card can be used when the ash head is in a raised position
to bounce light forward to assist with catch lights in a subject’s eyes.
To use:
1. Gently pull the Diuser Panel and Bounce Card from the Flash Head using
the ridge on the bottom of the Diuser Panel.
2. If using the Diffuser Panel it will drop into position over the Flash Head.
Gently push the Bounce Card back into the Flash Head if not needed.
3. If using the Bounce Card only gently push the Diuser Panel back into the
Flash Head.
Using the Flash Head Diuser
The Phottix Juno TTL Flash comes with an attachable diffuser that can be
added to the front of the ash head when needed. It is good for softening light,
reducing hot spots and shadows and better coverage for macro photography.
Setting ash zoom
There are two ways to control the zoom of the flash while it is on camera：
automatic (Azoom) and manual (Mzoom)。While in automatic zoom, the zoom
on the ash will follow the zoom of the lens to provide the best coverage. When
in manual zoom, the zoom setting on the ash is set by the user.
Setting the ash zoom
1. Press the Function Button underneath or (depending on
the ash Mode)to enter the ash zoom adjustment Mode.

8
2. Use the Selection Dial to set Automatic Zoom Mode (Azoom) or set the
manual zoom value (Mzoom).
3. When nished, press the OK Button to exit.
Please note:
1. When in Azoom and the ash head is raised or rotated from the 0 degree
standard forward position - the ash zoom will set itself to 50mm. “- -” will be
displayed on the LCD. The ash zoom will not change if the head is lowered to
-7 degrees.
2. Azoom will work ONLY when the ash head is set to either 0 or -7 degrees.
3. When using Mzoom and the flash head is raised or rotated from the 0
degree standard forward position - the ash zoom will not be changed from
the previous setting.
4. Flash Zoom can be adjusted when the head is raised or rotated by switching
to Mzoom Mode and making desired adjustments.
Test Button
Pressing the test Button will trigger the ash. This can be used for metering (in
manual Mode only). In Wireless Master Mode pressing the test Button will re
slave ashes on the same channel, group and matching ID being controlled by
the Master ash.
Modeling Flash
1. Pressing the camera depth-of-eld preview Button (if available) will re the
ash continuously for 1 second. This Modeling Flash is useful in seeing lighting
eects and balance on the subject. (Please see your camera manual for more
information on the DOF Button and Button assignment.)
2. Modeling Flash is available in all Modes, TTL, Multi and Manual.
Please note:
1. Overheating and damage can result from excessive use of the Modeling
Flash. Do not use more than 20 times in succession.
2. When overheating the ash will automatically increase charging time until
the ash temperature has decreased.
Autofocus (AF) Assist Light
1. In low light/contrast situations the Phottix Juno TTL built-in Auto Focus Assist
Light will illuminate to assist with AF. The AF Assist Light on the front of the ash
will project a focusing target on the subject.
2. AF Assist Light Functions can be set to on or o (see C.Fn-03 below).
Note:
AF assist light will not work when ash is in Receiver or Slave Mode.

En INSTRUCTION MANUAL
9
3. The LCD Display
TTL Auto Flash Mode：
TTL：TTL Auto
Flash Mode
Flash Exposure
Bracketing
Battery Level
Indicator
Aperture Value
Distance
Indicator display
First Curtain Sync Mode
High Speed Sync Mode
Second Curtain Sync Mode
Flash Exposure
Compensation
(FEC)
Zoom/ Flash
Exposure Bracketing
Selection Button
Wireless Receiving
Mode Selection Button
Flash Exposure
Compensation
Selection Button
Sync Mode
Selection Button
Azoom：Auto Zoom
Mzoom：Manual Zoom
Manual Flash Mode
Power LevelM：Manual Flash
Auto Metering Mode

10
Stroboscopic Flash Mode
Frequency
Flash Count
Power Level
Multi：Stroboscopic Flash
Wireless Flash Selection Menu
Wireless Function off
Optical Mode：
Infrared Transmitter
(Master) Mode
Optical Mode：
Infrared Receiver
Slave Mode
Optical Mode：
Optical Slave
Radio：
Ares II Receiver
Radio: Odin II
Receiver Mode
Radio: Odin II
Transmitter Mode
Radio: SKYPORT
Receiving Mode

En INSTRUCTION MANUAL
11
Wireless Mode：Odin II Transmitter Mixed TTL/M Mode
Master Flash Group Channels
Odin II Transmitter Flash Group
Flash Mode：
Selectable between
TTL/M/OFF
Wireless Radio Mode：Odin II Transmitter Ratio Mode
Flash Ratio
Flash Exposure
Compensation of the Ratio
：Master Flash On
：Master Flash Off
Wireless radio Mode：Odin II Receiver Mode
Wireless Radio Mode：
Odin II Receiver Mode Receiver Group

12
Wireless Radio Mode：Ares II Receiver Mode
Wireless Radio Mode：
Ares II Receiver Mode
Wireless radio Mode：Skyport RX Receiver Mode
Signal Transmit Rate:
Normal/Speed Wireless Radio Mode:
Skyport Receiver Mode
Optical Mode: Infrared Transmitter (Master) Mode
Optical Mode：
Infrared (Master) Mode
TTL Flash Group
: Master Flash On
: Master Flash Off

En INSTRUCTION MANUAL
13
Flash Ratio
Master Flash
Infrared Transmitter Group Flash Power
Optical Mode：Infrared Receiver (Slave) Mode
Optical Mode：
Infrared Receiver
(Slave) Mode Optical Slave Group

14
Optical Mode：Optical Slave Mode
Optical Mode：Optical Slave Mode
4. Functions and Operations
Standard Flash Mode (Wireless OFF)
There are 3 flash Mode available：Auto（TTL）、Manual（M）and
Stroboscopic（Multi).
Changing Flash Mode：
Pressing the“MODE”Button will cycle between Auto（TTL）、Manual（M）
and Stroboscopic（Multi）。The selected Flash Mode will display on the upper
left corner of the LCD.
TTL: Auto Flash
In TTL Mode the ash and camera will work together to calculate the correct
exposure. When the Shutter Button is fully pressed the flash will fire a pre-
ash that the camera will use to calculate exposure and ash power the instant
before the photo is taken.
Flash Exposure Compensation (FEC)
The Juno TTL Flash allows Flash Exposure Compensation (FEC) adjustment from
-3 to +3 in 1/3rd stops. This is useful in situations where ne-tuning of the TTL
system is needed based on the environment.

En INSTRUCTION MANUAL
15
To set FEC:
1. Press “MODE” Button until the ash display TTL on the top left corner of the
LCD.
2. Press Button to enter FEC Adjustment Mode
3. Use the“Selection Dial”to adjust the FEC
4. Press to exit.
Flash Exposure Bracketing – FEB
Flash Exposure Bracketing (FEB) can be used to automatically change flash
power over a series of photos. The camera will record three images with dierent
exposures – one exposed as per camera calculations, one over-exposed and
another under-exposed. Over and under exposure levels can be set by the user.
FEB is useful in run-and-gun situations as well as when shooting scenes with
different lighting conditions to help ensure a properly exposed photo. It can
also be used for HDR photography. Some cameras have ash exposure storage
Function, see your camera user manual for more details.
1. Hold down the Button for 2 seconds. The FEC icon will displayed
in the top right hand corner of the LCD .
2. Use the“Selection Dial”to adjust the exposure bracket amount, once
selected, ash will re in sequence of the selected FEC.
Cancel FEB :
1. Hold Button for 2s, use the“Selection Dial”to set FEB to ±0 .
Please note:
- FEB can be used in conjunction with FEC and Flash Exposure Lock (FEL)
- For best result, set the camera drive Mode to single frame, and before the
second and third picture is taken, make sure the ash is fully recycled.
Flash Exposure Lock–FEL
The Juno TTL is compatible with Flash Exposure Lock (FEL) Functionality. FEL can
be used to lock the ash exposure before a photo is taken. See your camera user
manual for further details on using FEL.
High Speed Sync – HSS
In HSS Mode, the camera/flash maximum sync speed can reach the camera’s
maximum shutter speed. This is useful when using Aperture Priority Mode or
to limit ambient light. HSS may vary with dierent camera models - see your
camera user manual for details.

16
To use HSS Mode:
1. Press Button to cycle through the Sync Mode of the ash.
2. When the icon is displayed, the ash is set at HSS Mode
3. You can now set the camera to use a shutter speed faster than the sync
speed for the camera
Please note:
Check that the HSS icon( ) is displayed in the viewnder
- HSS drastically reduces ash power, battery power and range.
- HSS is not available in Stroboscopic Mode
Second Curtain Sync – SCS
The Phottix Juno TTL Second Curtain Sync Function makes the ash re at the
end of an exposure, not the beginning. This can be useful with slow shutter
speeds for capturing special eect.
To use:
1. Press Button to cycle through the Sync Mode of the ash.
2. When the icon is displayed, the ash is set at SCS Mode
Note:
SCS Function is not available in Stroboscopic Mode
M: Manual Mode
In Manual Mode the ash will re at the power level set on the ash. The Phottix
Juno TTL Flash can be adjusted from 1/1 (full power) to 1/128 – 8 stops of
adjustments in 1/3rd stop increments. Aperture, shutter speed and ISO on the
camera need to be manual adjusted. For best results use camera M-Manual
Mode.
To use:
1. Press “MODE” Button until the ash displays M on the top left corner of the
LCD.

En INSTRUCTION MANUAL
17
2. Press Button to enter Manual Power Adjustment Mode.
3. Use the “Selection Dial” to adjust the Power Level.
4. Press to exit.
Note: Half press the camera Shutter Button will display t he eective manual
ash power range on the Flash LCD.
Auto-Metering Mode
Auto Metering Mode can be used similarly to a light Meter to measure and set
the ash power needed for proper exposure.
To use:
1. While in Manual (M) Mode – press and hold the OK Button for 2 seconds.
2. Auto Metering will be display on the ash LCD
3. When a photo is taken the flash will automatically calculate the manual
power level and display it on the back of the ash.
4. Subsequent photos will be taken at this power level.
5. To re-meter press and hold the OK Button for 2 seconds to re-enter Auto
Metering Mode.
Multi: Stroboscopic Mode
With Multi Stroboscopic Mode a series of rapid ashes will be red. The ash
count, frequency and power of these ashes can be programmed on the Phottix
Juno TTL. Multi Mode is useful for capturing multiple images of a moving
subject in the same photo and other special eects. The frequency of the eect
(in Hz. - number of ashes per second), the total number of ashes and output
levels can be set.

18
To Use:
1. Press “MODE” Button until the ash displays Multi on the top left corner of
the LCD.
2. Press Button to enter Power Adjustment Mode, use the Selection
Dial to adjust the ash power
4. Press Button to cycle through Number of Flashes (X) and frequency
(Hz), and use the Selection Dial to adjust these settings.
Please note:
1. Overheating and damage can result from excessive use of the Multi
Stroboscopic Mode. Do not use more than 20 times in succession.
2. When overheated the ash will automatically increase recycling time until
the ash temperature has decreased.
Stroboscopic Mode and Shutter Speeds
To determine the proper camera shutter speed to be used with various
Stroboscopic Mode variables, use the following formula: Number of flashes /
Frequency = Shutter Speed
Example: 5x (number of ashes) / 10 Hz (Frequency) = .5 second shutter speed.
This is a rough guideline: You may need to increase or decrease the shutter
speed to get the desired result.
Multi Stroboscopic Mode Output Chart
1/4
1/8
1/16
1/32
1/64
1/128
7
14
30
60
90
100
6
14
30
60
90
100
5
12
30
60
90
100
4
10
20
50
80
100
4
8
20
50
80
100
3
6
20
40
70
90
3
5
10
30
60
80
2
4
8
20
50
70
2
4
8
20
40
70
2
4
8
20
40
60
2
4
8
18
35
50
2
4
8
16
30
40
2
4
8
12
20
40
1 2 3 4 5 6-7 8-9 10 11 12-
14
15-
19
20-
50
60-
199
HZ
Flash
Output
If the number of ashes is displayed as “N---”, the maximum number of ashes
will be as shown by the table below regardless of the ring frequency.
Flash output 1/4 1/8 1/16 1/32 1/64 1/128
Flash count 2 4 8 12 20 40

En INSTRUCTION MANUAL
19
5. Wireless Triggering Modes
The Phottix Juno TTL Flash is equipped with several wireless transmitter and
receiver Modes. It oers built-in compatibility with the Phottix Odin II TTL Trigger
system, Phottix Odin Lite, Phottix Ares II and Elinchrom Skyport. Compatibility
for Canon’s native optical master/slave triggering system is also included. For
information on these systems please consult the respective product manuals.
Selecting Wireless Triggering Mode
To set the wireless triggering Modes on the Juno TTL
1. Press the Function Button to enter the Wireless Triggering Mode
Selection screen
2. Use the Selection Dial to select the desired Wireless Triggering Mode and
press the OK Button to select.
3. Set the parameters for the selected Wireless Triggering Mode (e,g: Channels
and groups).
Wireless Triggering Mode available on Juno TTL:
Odin II Tx(Transmitter)
Allows full adjustments to local and remote TTL and Manual ash power and
zoom on other Juno TTL flashes (in Odin II Rx Mode) or compatible flashes
equipped with Phottix Odin II receivers. Flashes or studio lights with Strato II or
Ares II receivers can be triggered in manual Mode by the Juno TTL ash in Odin
II Tx Mode.
Note: Odin Z OS require on Odin II receiver
Odin II Rx(Receiver)
The Juno TTL flash in Odin II Rx Wireless Mode can be triggered by another
Juno TTL ash in Odin II Tx Mode or by a Phottix Odin II Transmitter. If using an
Odin II Tranmitter (for any brand) the Juno TTL in Odin II Rx Wireless Mode will
automatically switch to Canon, Nikon, Sony and Pentax compatibility.
Note: Odin II Canon, Nikon and Sony requires Odin Z OS

20
Ares II Rx(Receiver)
The Juno TTL in Ares II Rx Wireless Mode can be triggered by Phottix Ares II
Transmitters, Phottix Odin II Transmitters and Phottix Juno TTL ash in Odin II Tx
Mode.
Skyport RX(Receiver)
In Skyport Rx Mode, the Juno TTL flash can be triggered by Elinchrom EL
Skyport Transmitter Plus, Elinchrom EL Skyport Transmitter Plus HS, Elinchrom
EL Skyport transmitter Pro.
OP Tx(Master)— Using Canon Infrared triggering system
Using pulses of light, the Juno TTL ash on camera can adjust and re remote
ashes in OP Rx Mode .
OP Rx (Slave)—Using Canon Infrared triggering system
Remote Juno TTL (Canon) in OP Rx Mode are controlled and red by on-camera
ashes in OP Tx Master Mode.
Note: Both OP Tx and OP Rx ash needs to be Juno TTL for Canon.
S1 Rx (Slave)— Optical Slave
In S1 Rx Mode other nearby ashes will trigger the Juno TTL in manual Mode
only when they are red.
Please note: The Juno TTL cannot be triggered by Phottix Strato, Odin I TCU or
Ares .
In the wireless triggering Mode Selection screen, if the OK Button is not pressed,
after 12 seconds the ash will enter the current selected Wireless Mode.
OdinII Tx (Transmitter Mode)
Using the Juno TTL Flash in Odin II Tx Mode allows for a ash to be used on-
camera in TTL or Manual Mode as well as control three groups (A, B, C) –
adjusting TTL and manual power levels as well as ash head zoom on Juno TTL
ashes set in Odin II Rx Mode or other compatible ashes mounted on Phottix
Odin II receivers. In ash groups under manual Mode can also set ‘auto metering’
feature to assist it setting the desired power.
