Phybridge UniPhyer LB-UA2324 User guide

LB-UA2324 - 24 Port UniPhyer
LB-UA2348 - 48 Port UniPhyer
LB-PA111 - PhyAdapter
LB-PA110 - Extended Reach PhyAdapter
Two wire Networ Line Bridge Gateway
System Description
Part Number - 8003-02
Issue 3, May 2009

Contents
Preface 1
Scope 1
Audience........................................................................................................................................ 1
Related Documentation................................................................................................................. 1
Documentation Conventions......................................................................................................... 1
— System Description....................................................................................................2
1.1 General Overview of the UniPhyer LB-UA2348 and LB-UA2324................................... 3
1.1.1 Features ........................................................................................................................... 4
1.1.2 System Application........................................................................................................... 5
1.2 Technical Summary of the UniPhyer LB-UA2324 and LB-UA2348 ................................ 6
1.2.1 Physical Specifications..................................................................................................... 6
1.2.2 Environmental Specifications........................................................................................... 6
1.2.3 Power Specifications........................................................................................................ 6
1.3 Technical Summary of the PhyAdapter LB-PA110 and LB-PA111................................. 7
1.3.1 Physical Specifications..................................................................................................... 7
1.3.2 Environmental Specifications........................................................................................... 7
1.3.3 Power Specifications........................................................................................................ 7
1.3.4 Line Length Specifications ............................................................................................... 7
1.4 Detailed Description of the UniPhyer LB-UA2348..........................................................8
1.4.1 Module Functional Block Diagram ................................................................................... 8
1.4.2 UniPhyer Specifications ................................................................................................... 9
1.4.3 Controls and Indicators .................................................................................................. 14
1.4.4 Cooling System.............................................................................................................. 15
1.4.5 Line Interface Port Power............................................................................................... 15
1.4.6 Over Current protection.................................................................................................. 15
1.4.7 Twisted Pair Wiring Limitations...................................................................................... 15
1-4.7.1 Extended reach with the LB-PA110 PhyAdapter ........................................................... 16
— Software Introduction...............................................................................................17
1.5 General Overview........................................................................................................ 18
1.5.1 Features of Management Interface................................................................................ 19
1.6 Configuration Management.......................................................................................... 20
1.6.1 Factory Default Configuration ........................................................................................ 22

Contents
1.7 Performance management .......................................................................................... 22
1.7.1 RMON Feature............................................................................................................... 25
1.8 Fault Management....................................................................................................... 27
1.9 Loopback Testing........................................................................................................ 29
1.10 Cluster Feature............................................................................................................ 30
Abbreviations .................................................................................................................32

List of Figures
List of Figures
Figure 1-1 UniPhyer LB-UA2348 Front Panel View...................................................................................................3
Figure 1-2 UniPhyer LB-UA2348 system application .................................................................................................5
Figure 1-3 UniPhyer LB-UA2348 Module Functional Block Diagram .......................................................................8
Figure 2-1 Management Software Model...................................................................................................................18
Figure 2-2 Cluster network topology – Daisy Chain..................................................................................................30
Figure 2-3 Cluster network topology – Star ...............................................................................................................31

List of Tables
List of Tables
Table 1-1 UniPhyer LB-UA2348 Controls and Indicators .........................................................................................14
Table 2-1 RMON ETH Statistics variables.................................................................................................................25
Table 2-2 RMON ETH History Control variables......................................................................................................26
Table 2-3 UniPhyer LB-UA2348 Alarm Hierarchy....................................................................................................27

1
/ 34
Preface
Scope
This document provides an overview on the UniPhyer LB-UA2348 and UniPhyer LB-UA2324 and the
LB-PA110 and LB-PA111 PhyAdapters. The LB-UA2324 is functionally the same as LB-UA2348 except
it only supports 24 ports and provides a different Power over Ethernet (POE) budget than the LB-UA-2348
UniPhyer. The LB-PA111 has Power Over Ethernet (POE) while the LB-PA110 does not. The document
contains:
Descriptive material about the UniPhyer and PhyAdapter (chapter 1)
Descriptive material about the software of the UniPhyer (chapter 2)
Expansions of abbreviations used in the manual (Abbreviations)
Audience
The guide is intended for system engineers or operating personnel who want to have a basic understanding
of the UniPhyer.
Related Documentation
For information about installing, operating and maintaining, and troubleshooting the UniPhyer system, refer
to the UniPhyer Hardware Installation and User Guide.
For information about how to manage the UniPhyer through Web GUI, refer to the UniPhyer Web
Configuration Tool Guide.
Documentation Conventions
The following conventions are used in this manual to emphasize information that will be of interest to the
reader.
Danger — The described activity or situation might or will cause personal injury.
Warning — The described activity or situation might or will cause equipment damage.
Caution — The described activity or situation might or will cause service interruption.
Note — The information supplements the text or highlights important points.

2 / 32
—
——
— System Description
1.1 General Overview of the UniPhyer LB-UA2348 and LB-UA2324
1.2 Technical Summary of the UniPhyer LB-UA2324 and LB-UA2348
1.3 Technical Summary of the PhyAdapter LB-PA110 and LB-PA111
1.4 Detailed Description of the UniPhyer LB-UA2348
1.5 General Overview
1.6 Configuration Management

1 —System Description
3
/ 34
1.1 General Overview of the UniPhyer LB-UA2348 and LB-UA2324
The UniPhyer LB-UA2324 (24 port) and LB-UA2348 (48 Port) are Line Bridge Gateways within a
rack-mountable 2U high enclosure. The system provides up to 48 Line Bridge ports that when
connected to PhyAdapters can provide an IEEE 802.3af compliant 10/100 Mbps Power over Ethernet
(POE) port with broadband data rates using the two wire intra-office legacy wiring infrastructure. The
UniPhyer LB-UA2348 is capable of delivering very high speed data rates with up to ADSL2+
performance for each of the 48 ports, ideal for Voice over IP network deployments. With advanced
QoS features, the UniPhyer LB-UA2348 also has advanced Quality of Service (QoS) features to further
customize deployment to meet network needs.
The UniPhyer LB-UA2348 provides two uplink trunk ports with both electrical and optical Gigabit
Ethernet (GbE) interfaces..
The UniPhyer LB-UA2348 can act support of 802.3ad link aggression that extends the uplink
bandwidth to 2 Gbps and increases the reliability of uplink by line protection feature of 802.3ad. The
UniPhyer LB-UA2348 also supports stacking configuration that several UniPhyer LB-UA2348s can
stacked up to provide services to more subscribers for one GBE uplink.
Figure 1-1 shows the front panel view of the UniPhyer LB-UA2348.
Figure 0-1 UniPhyer LB-UA2348 Front Panel View
The LB-PA111 PhyAdapter is powered by the UniPhyer and provides IEEE 802.3af compliant 10/100
Mbit Power over Ethernet port. The LB-PA110 PhyAdapter is powered by the UniPhyer and provides
10/100 Mbit Ethernet port.

1—System Description
4 / 32
1.1.1 Features
Highly compact solution that provides 24/48 Line Bridge ports in 2U space and stackable for higher
port density
Provides power for both PhyAdapters and IP devices connected to PhyAdapters over two wire
twisted pair infrastructure on Line Interface.
Equipped with fan, diagnostics and alarm reporting capability
Remote configuration and software upgradeable
Data signalling rates are up to ADSL2+ operation mode
Wide operating temperature range from -10
°
C ~ 50
°
C (for UniPhyer).
Provide two combo GBE trunk interfaces with both electrical (RJ-45) and fiber optical (SFP) ports
Support Link Aggregation in IEEE 802.3ad that allows 2 GBE links to be aggregated together as a
logical link. Support both LACP protocol (dynamic) for load sharing and failover in case of loss of
Ethernet link
User-friendly CLI, web-based GUI, and EMS (NMS) through in-band/out-band channels for
carrying out the OAM&P of the system
Support system software download via FTP for both local and remote terminals
Support database export and import functionality via TFTP for configuration backup and
restoration
Support SNTP to automatically calibrate the time and date of the system
Support on board thermal sensor to detect over temperature conditions with software configurable
thresholds that generate SNMP traps and syslog alarm entries
Provide SSH (Secure Shell) for more secure remote operation
Meet CE requirements

1 —System Description
5
/ 34
1.1.2 System Application
Figure 0-2 UniPhyer LB-UA2348 system application
The UniPhyer LB-UA2348 leverages the redundant telephone cabling infrastructure to create a parallel
network with Power-over-Ethernet. This is a plug and play solution that can be deployed quickly and
easily with the default configuration.
The UniPhyer provides a permanent point-to-point link between the IP phone jack on the PhyAdapter
and the Phybridge UniPhyer and is thus able to guarantee predictable communication between the two
end points.

1—System Description
6 / 32
1.2 Technical Summary of the UniPhyer LB-UA2324 and LB-UA2348
1.2.1 Physical Specifications
Item Value
Width 431.8 mm (17 in.) not including the mounting
brackets
Height 88.1 mm (3.47 in.) 2U
Depth 381 mm (15 in.)
Weight 5.36 Kg (11.8 pounds)
Rack Standard rack (19”)
1.2.2 Environmental Specifications
Item Value
Operating Temperature -10 ~ 50
°
C
Relative Humidity 10% to 95% (non-condensing) at 35
°
C
1.2.3 Power Specifications
Item Value
Power Supply Interface AC: 100 ~ 240V/50 ~ 60Hz.
Power Consumption: Full load maximum reach with PhyAdapters (no IP
phones)
48 ports: 250 W per system
24 ports: 136 W per system
POE Budget
POE budget includes line loss, maximum 10.6 W per
port
POE Budget 48 port: 390 W
POE Budget 24 port: 255W

1 —System Description
7
/ 34
1.3 Technical Summary of the PhyAdapter LB-PA110 and LB-PA111
1.3.1 Physical Specifications
Item Value
Width 82.8 mm (3.26 in.)
Length 82.8 mm (3.26 in.)
Depth 27.2 (1.07 inch)
Weight 90 Grams (3.17 oz )
1.3.2 Environmental Specifications
Item Value
Operating Temperature 0 to 40
°
C
Relative Humidity 10% to 95% (non-condensing) at 35
°
C
1.3.3 Power Specifications
Item Value
Power Supply Interface Powered from the UniPhyer, 54 V DC maximum
Power Consumption: 2.5 W maximum (not including line or UniPhyer
port power consumption which can add from 0.2 W
to 0.7 W).
POE (LB-PA111 only) RJ45 port provides IEEE 802.3af compliant voltage
on the non signaling pairs, 4-5 and 7-8.
POE Budget (LB-PA111 only) POE budget per PhyAdapter including line loss, is a
maximum 10.6 W per RJ45 Ethernet port.
Class 1, 2 and some Class 3
IEEE 802.3af compliant
devices are supported
1.3.4 Line Length Specifications
Item Value
Wire type Two wire twisted pair, 24 and 26 AWG
LB-PA111 – two wire Up to 1200 feet (with POE)
LB-PA110 – two wire Up to 3000 feet (no POE)

1—System Description
8 / 32
1.4 Detailed Description of the UniPhyer LB-UA2348
1.4.1 Module Functional Block Diagram
Figure 0-3 UniPhyer LB-UA2348 Module Functional Block Diagram
The Power Management and PWS Module provide the power and signaling on the Line Ports for the
PhyAdapters. The ADSL module aggregates 24/48 ports signaling traffic into the network processor
card, the network processor terminates the ATM traffic into Ethernet packets through its SAR
(Segmentation and Reassembly) function. The network processor also provides the Layer-2 Ethernet
functions; it can support the mapping between the ATM VCI and VLAN ID (802.1q) and priority
queues (802.1p). The mapping functionality between ATM PVC and VLAN ID include one PVC to
one VLAN ID and multiple PVCs to one VLAN ID; all of which are configurable.
Through the two GBE uplink interfaces, the system can provide Link Aggregation (802.3ad), VLAN
stacking, and Rapid Spanning Tree (802.1w) as ring protection architecture.

1 —System Description
9
/ 34
1.4.2 UniPhyer and PhyAdapter Specifications
Description Specification
Trunk Interface Support both RJ45 and optical mini-GBIC (SFP) connectors
for each uplink port (total 2 ports per box).
For electrical interface:
Support IEEE 802.3 10/100/1000 Base-T auto-sensing GBE.
And the selection of speed for each port is independent.
Support auto-adaptive between full-duplex and half-duplex
operation modes for 10 and 100 Mbps
operation speed on a per
trunk port basis. The system only supports full-
duplex mode for
1000 Mbps.
For optical interface:
Support 1000 Base-TX/SX/LX/EX/ZX/LHX fiber interfaces
(defined in IEEE 802.3z) depending on plug-in SFP transceiver
Support Ethernet frame that complies with IEEE 802.3z
Line Interface Each of the 24 or 48 ports are supplied power for the
PhyAdapter and POE enabled device attached to PhyAdapter.
On the same port pair data signaling is provided by ADSL2+
operation that comply with G.992.5 Annex M (extended
upstream bandwidth)
Supported signaling data rate:
- up to 25 Mbit/s downstream
- up to 1.4 Mbit/s upstream
Support rate adaptation modes defined in ITU-T G.992.5 and
G.997.1 including Manual, Rate Adaptive At Init, and
Dynamic Rate Adaptation modes
Support Seamless Rate Adaptation (SRA) to on-line
reconfigure the total data rate according to the line condition
The subscriber interface is able to support Fast Channel or
Interleaved Channel independently for each ADSL port.
Support loop diagnostic function specified in ITU-T G.992.5
for each ADSL port independently (support DELT loop
diagnostics).
Supported PhyAdapters Each port on the Line Interface can be plugged into either
LB-PA111 or LB-PA110 PhyAdapter models. The
PhyAdapter is powered by the UniPhyer.

1—System Description
10 / 32
POE PhyAdapter– LB-PA111 The UniPhyer
supplies up to 10.6W per line to the PhyAdapter
for POE. The LB-PA111 PhyAdapter functions as a PSE,
providing POE to IEEE 802.3af compliant IP Phones.
Resettable Fuse on RJ45 POE port for maximum 200 mA draw.
Non POE, Extended reach
PhyAdapter – LB-PA110
The UniPhyer powers the PhyAdapter. The RJ45 port does not
provide power to the IP device an independent power supply is
required for the IP device. This adapter can be used beyond
Management Interface In-band management: provide all system OAM&P functions:
software updates, configurations import/export, and
management system interaction through Ethernet trunk port.
Out-band management: Using the MGMT port, a 100 Base-T
auto-sensing Ethernet Interface.
OAM&P Configuration Management
Performance Management
Fault Management
Status Monitoring.

1 —System Description
11
/ 34
Ethernet/IP Functionality General Bridging Function
–Support IPv4 packet
–
Support IEEE802.1d Ethernet bridge function between
trunk Ether port and ATM VCs
–Support Rapid Spanning Tree Protocol (RSTP) for the
trunk interfaces per IEEE 802.1w
–Support static source MAC table provisioning,
automatic source MAC learning and block duplicate
ones
–The system is able to maintain 4K entries in its own
static MAC address table and to provision up to a
maximum of 128 MAC entries per line port
VLAN
–Support IEEE 802.1q Port-based VLAN and
Protocol-based VLAN
–Support 512 non-stacked VLAN-ID simultaneously
ranging from 1 to 4095
–Support VLAN stacking and VLAN cross-connect
–Support IP Spoofing prevention
–Support MAC anti-Spoofing
–Support port isolation functionality. When port
isolation is enabled, no Layer-2 bridging between
different ports (or subscriber lines) is supported in a
VLAN
–Support static VLAN group and membership
provisioning
Multicast
–Support IP multicast forwarding and the multicast
works well for RFC2684 bridged payload
encapsulation mode
–Support up to 256 multicast groups and 256 copies
simultaneously
–Support profile-based Multicast Access Control (up to
48 profiles) and assign any profile to a subscriber
interface (the number of multicast channels within a
profile is 256)
–Support to limit maximum number of IGMP groups
joined per bridge port
–Support IGMP snooping/proxy per IGMP v1, v2, and
v3
–Support selection between IGMP proxy and IGMP
snooping
ACL/Filtering
–Support Layer-2 frame filtering based on
source/destination MAC addresses and EtherType
–Support Layer-3 filtering based on IP
header including

1—System Description
12 / 32
source/destination IP address, protocol ID, and
TCP/UDP destination port number
Relay Functionality
–Support DHCP forward and DHCP relay agent
option-82 functionality. The value within Circuit ID
and Remote ID sub-options is configurable.
–Support PPPoE relay
QoS
–The system is able to control the bandwidth occupied
by broadcast, multicast, and unknown unicast
(flooding) traffic respectively on a per VLAN basis.
–Support rate-limit profile binding per bridge port
–Support Three Color Marking (TCM) policer
–Support Ethernet rate limit per bridge port
–Support ToS (type of service) /DiffServ (differentiated
services) stripping and priority queuing
–Support DSCP mapping to 802.1p
–
Support selectable adopted priority queue mechanisms
according to Strict Priority Queue (SPQ) and Weighted
Fair Queue (WFQ)
–
Support configurable mapping function between ATM
PVC and 802.1p priority queue
–Support IP CoS technology
ICMP
Support ICMP (Internet Control Message Protocol)
function; can send/respond the ICMP request message to/
from other system
Support IPSec/L2TP/PPTP VPN pass-through function
ATM and Interworking
Function (IWF) Support 8 PVCs per line; VPI range is from 0 to 255 and VCI range from 32 to 65535 (ATM Forum UNI 3.1/4.0, PVCs
only). The VPI and VCI value can be created and deleted via
CLI, Web-GUI, and EMS.
Support multi-protocol encapsulation over ATM per RFC 2
684
/ RFC 1483 for bridged mode and routed mode (IPoA).
Comply with ITU-T I.361 UNI cell format and support AAL5
per ITU-T I.363.5.
Support line-level fault management ITU-T Rec. I
.610 OA&M
F5 loopback on DSL ports including both origination and
reception/return of F5 loopback cells.
Commit the supported ATM service categories in the
increasing order of UBR, nrt-VBR, rt -
VBR, and CBR on a per
port basis.
Provide PCR (peak cell rate) configurable parameter for UBR
and CBR service; PCR and SCR (sustainable cell rate)

1 —System Description
13
/ 34
configurable parameters for rt-VBR and nrt-VBR.
Support upstream and downstream
traffic shaping and policing
on per PVC basis.
Support profile-based ATM traffic management (up to 252
profiles with one default and 251 user-configurable profiles)
and the downstream/upstream ATM profile assignments are
independent
Support PPPoE transparent forwarding and PPPoE
intermediate agent
Support PPPoE/PPPoA interworking as defined in section
3.5.4 of TR-101.

1—System Description
14 / 32
1.4.3 UniPhyer Controls and Indicators
Table 0-1 UniPhyer LB-UA2348 Controls and Indicators
Front View of UniPhyer LB-UA2348
LED Description
SYS To indicate the system operation status
ALM To indicate the system alarm status
GBE1 To indicate the optical trunk port status
GBE2 To indicate the optical trunk port status
Port Status To indicate the Signaling status for each PhyAdapter port.
GBE1-
Speed
GBE2- Speed
(LED on RJ-45)
To indicate the trunk port transmission speed
(orange color LED on the Ethernet port)
GBE1- Link/Act
GBE2-Link/Act
(LED on RJ-45)
To indicate the trunk port data activity status
(green color LED on the Ethernet port)
MGMT- Speed
(LED on RJ-45)
To indicate the transmission speed of the Ethernet management port
(green color LED on the Ethernet port)
MGMT- Link/Act
(LED on RJ-45)
To indicate the link status of the Ethernet management port
(orange color LED on the Ethernet port)
Interface Description
GBE1 Gigabit Ethernet electrical trunk port 1
SFP1 Gigabit Ethernet SFP trunk port 1
GBE2 Gigabit Ethernet electrical trunk port 2
SFP2 Gigabit Ethernet SFP trunk port 2
