SECTIO TITLE PAGE
1.0 GE ERAL RULES 10
1.1 SI GLE FLUE WAY OR CHIM EY 11
1.2 SOOT I SPECTIO 11
1.3 CHIM EY STACK 12
1.4 FRESH AIR I TAKE 13
1.5 I STALLATIO E VIRO ME T 13
1.6 LOAD CAPACITY OF THE FLOOR 14
1.7 HEATI G CAPACITY 14
1.8 MI IMUM SAFETY DISTA CES 15
1.9 FLUE WAY 15
1.10 CO ECTI G TO A CO VE TIO AL CHIM EY 17
1.11 USI G A EXTER AL FLUE 18
1.12 PREVE TIO OF DOMESTIC FIRES 18
2.0 TECH ICAL CHARACTERISTICS A D SPECIFICATIO S 19
2.1 DESCRIPTIO OF THE APPLIA CE 19
2.2 TECH ICAL DATA 20
2.3 FEATURES 21
2.4 ACCESSORIES A D EQUIPME T 21
2.5 PRODUCT IDE TIFICATIO DATA 21
2.6 DIME SIO S P963 THERMO 22
2.7 WIRI G DIAGRAM 23
3.0 FUEL 24
4.0 PREPARI G FOR THE I STALLATIO 25
5.0 I STALLATIO 26
5.1 WATER CO ECTIO S 26
5.2 WATER PIPE CO ECTIO S 27
5.3 ELECTRICAL CO ECTIO S A D CO TROLS 28
5.4 ROOM THERMOSTAT I STALLATIO 28
5.5 I STALLI G THE AUX THERMOSTAT 29
5.6 FILLI G THE SYSTEM 29
6.0 USE 30
6.1 LOADI G THE PELLETS 30
6.2 REMOTE CO TROL 30
6.3 LIGHTI G FOR THE FIRST TIME 31
6.4 START-UP A D ORMAL OPERATIO 32
6.5 TROUBLESHOOTI G 35
6.6 CO TROL PA EL 38
6.7 SETTI G THE LA GUAGE 38
6.8 PROGRAMMI G 39
6.9 PROGRAMMI G THE CLOCK 40
6.10 TIMER 41
6.11 E ERGY SAVI G 45
6.12 PARAMETER ME U 47
6.13 E ABLE AUDIO SIG AL 49
6.14 PARAMETER ME UE 49
6.15 MODIFYI G THE TRA SMISSIO U IT 50
6.16 SAFETY DEVICES 50
6.17 FROST PROTECTIO MODE 53
6.18 OPE I G THE DOOR 53
6.19 DISPOSAL OF ASHES 53
7.0 MAI TE A CE 54
7.1 CLEA I G THE GRATE A D GRATE SUPPORT 54
7.2 CLEA I G THE ASH GUARD 54
7.3 CLEA I G THE FIREBOX A D BAFFLE PLATE 55
7.4 CLEA I G THE SMOKE CHAMBER A D BOILER 55
7.5 CLEA I G THE FLUE SYSTEM 57
7.6 CLEA I G THE CERAMIC CLADDI G 57
7.7 CLEA I G THE E AMELLED METAL PARTS 58
7.8 CLEA I G THE GLASS ( DAILY ) 58
7.9 REPLACI G THE GLASS 58
7.10 REPLACI G THE REMOTE CO TROL BATTERY 58
7.11 WHE OT I USE 59
7.12 SHECDULED MAI TE A CE 59
8.0 TROUBLESHOOTI G 60
8.1 REPLACI G THE FUSES 63
CERTIFICATE OF CO FORMITY 64
SCHEMATICS 67
CLADDI G 71
DIME SIO S 72
EXPLODED VIEW 73
PREPARATIO S FOR I STALLATIO 73
I STALLATIO 74
