Pico Macom PFAD900CS User manual

PFAD900CS
The Pico Macom PFAD900CS is a frequency agile professional re-broadcast
grade, microprocessor controlled CATV demodulator. Its phase-locked-loop fre-
quency control, envelope signal detection, and superior SAW filtering minimize
adjacent channel interference and assure accurate and spurious free perform-
ance.The unit accepts any NTSC television signal in the 54-806MHz frequency
range converting it to baseband video and audio, while maintaining over 60dB
S/N ratio. IRC or HRC offsets can be activated via push-button switches on the
front panel.The unit’s PLL circuitry in conjunction with the non-volatile memory
contained in the microprocessor ensures easy and reliable channel selection and
restoration.The PFAD900CS provides three additional outputs: (1) an IF output
to monitor tuner status and use in encoder, ghost cancelling, and video override
applications; (2) a 4.5MHz sub-carrier output; and (3) a broadband multiplex
(MPX) output for high quality BTSC stereo.The PFAD900CS demodulator is
shipped with all internal adjustments preset. Pico Macom backs up this product
with its industry leading 5-year limited warranty.
PFAD900CS
806MHz Agile CATV A/V Demodulator
125-Channel Range 54-806MHz
(CATV 2-125, TV 2-69)
Re-broadcast-quality specifications for
unparalleled picture quality
Keyed AGC system provides excellent
picture stability
>60 dB signal-to-noise ratio for crisp,
sharp picture
Quadrature single-tuned audio detec-
tion guarantees superior audio quality
Separate video and audio outputs
provide maximum flexibility
Separate 4.5 MHz sub-carrier and MPX
outputs for BTSC stereo applications
Microprocessor control with push-but-
ton channel selection provides ease of
installation, configuration, and servicing
Digital display provides quick channel
identification
State-of-the-art digital phase-locked
loop (PLL) design guarantees precise
frequency locking for solid drift-free
operation
SAW filtered for precise adjacent
channel rejection
Envelope detection ensures exceptional
differential gain and phase
45.75 MHz composite IF output allows
tuner monitoring, encoder, ghost can-
celing, and video override applications
806MHz Agile CATV A/V Demodulator
www.picomacom.com
Headend & Electronics
355 Parkside Drive San Fernando, CA 91340
Ph: 818-493-4300 Toll Free: 800-421-6511 Fax: [phone]
A-25
Rev. 08/03

PFAD900CS
Channels: 125 Channels
(CATV 2 – 125, TV 2-69)
HRC/IRC offsets
Input Level:
Single channel +40 dBmV max.
60 channels +20 dBmV max.
Image Rejection:
(@ -47 dBmV input) VHF = 70 dB, UHF = 60 dB
(@ -17 dBmV input) VHF = 60 dB, UHF = 50 dB
Noise Figure: VHF = 8 dB, UHF = 8 dB
Output Level: 0.5 to 1 V p-p
Impedance: 75 Ohms
Bandwidth: DC to 4.2 MHz
Frequency Response: ±1.5 dB
Differential Gain: <5% (10 to 90% APL)
Differential Phase: <5° (10 to 90% APL)
Detector Type: Envelope
Signal to Noise Ratio: >60dB minimum
Power Input: 117 VAC 60 Hz
Operating Temperature: -10° C to +50° C
Dimensions: 19˝(L) x 3˝(D) x 13/4˝(H)
Weight: 3.8 lbs.
Output Level: 800 mV min. deemphasized
Output Impedance: 600 Ohms
Frequency Response: 20 Hz to 15 kHz
Detection Type: Quadrature FM
4.5 MHz Sub-Carrier Output Level: 35 dBmV
MPX output level: 800 mV unbalanced @
600 Ohms
RF Video
Audio General
Product Specifications
806MHz Agile CATV A/V Demodulator
RF IN
VIDEO OUT IF OUT 4.5MHzOUT AUDIO OUTMPX OUT
600W MAX
120 VAC
60Hz 16W
Front View
Rear View
Ordering Information
PFAD-900CS
www.picomacom.com
A-26
Rev. 08/03 355 Parkside Drive San Fernando, CA 91340
Ph: 818-493-4300 Toll Free: 800-421-6511 Fax: [phone]
Specifications Subject to Change © Copyright 2003 Pico Macom, Inc.
