Pico pc Mnho-043 User manual

Intel® Celeron® J1900 4 LAN 3G/4G HD Fanless Firewall Router MNHO-043

MNHO-043

User Manual

Intel® Celeron® J1900 4 LAN 3G/4G HD Fanless Firewall Router MNHO-043

Intel® Celeron® J1900 4 LAN 3G/4G

Fanless Firewall Router

WWW.PONDESK.COM

Intel® Celeron® J1900 4 LAN 3G/4G HD Fanless Firewall Router MNHO-043

The subject matter of this document causes the disclosure of Winston Marriot Ltd

confidential and/or proprietary information. It shall not be disclosed to any person other

than responsible officers and employees of yours who are aware that the same is

commercially confidential and who are bound to treat it as such. It shall not be duplicated,

disclosed or used, in whole or in part for any purpose other than to evaluate the subject

matter of the document. Provided that, if a contract is awarded as a result of, or in

connection with the submission of this information you shall have rights to duplicate,

disclose or use the information as the contract may provide. This restriction does not limit

your right to use this document if it is obtained from another source without restriction.

This document and any copies containing any of this information must be returned to

Winston Marriot Ltd on request.

Winston Marriot Ltd reserves the right to change the contents of the product described in

this manual at any time and without prior notice.

No part of this manual may be reproduced, stored, copied or transmitted in any form or

any storage medium by any means, electronic, photocopying, recording or otherwise,

without the prior written permission of Winston Marriot Ltd.

Trademarks

Registered Names and Trademarks are the copyright and property of their respective

owners.

Products, corporate names and their logos presenting in the manual may or may not be

explanation and identification without intent to infringe.

Disclaimer

All information, specifications and illustrations contained in this manual are based on the

latest information (at the time of publication) and for informational use only with subject to

change at any time without notice. Winston Marriot Ltd takes no liability and responsibility

for any in error that may appear in this manual.

Winston Marriot Ltd will not be responsible and liable for the errors that may contained in

this manual and for incidental or consequential damages (including lost profits) in

connection with the furnishing, performance or use of this material.

Jhumat House | 160 London Road

Barking, Essex IG118BB | United Kingdom

WWW.PONDESK.COM

Intel® Celeron® J1900 4 LAN 3G/4G HD Fanless Firewall Router MNHO-043

CONTENTS

1. INTRODUCTION

1.1 –Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 08

1.2 –Front & Back Side View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 09

1.3 –Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 09

2. SRTUCTURE

2.1 –Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.2 –Opening The Case . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

3. MOTHERBOARD

3.1 –Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

3.2 –Processor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.3 –Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.3.1 –Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.4 –Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

3.4.1 –mSATA SSD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

3.4.2 –2.5” SATA SSD/HDD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

3.5 –Wi-Fi & 3G/4G . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.5.1 –Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.5.2 –3G/4G LTE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.6 –Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

3.6.1 –DC-IN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

3.6.2 –CRT & VGA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

3.6.3 –HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

3.6.4 –LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

3.6.5 –System FAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

3.6.6 –SATA2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

3.6.7 –USB (2.0 & 3.0) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

3.6.8 –BAT1 (CMOS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

3.6.9 –FP1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

4. BIOS

4.1 –Functions & Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

4.2 –Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

4.2.1 –Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4.2.2 –Advanced Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4.2.2.1 –CPU Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

WWW.PONDESK.COM

Intel® Celeron® J1900 4 LAN 3G/4G HD Fanless Firewall Router MNHO-043

4.2.2.2 –PPM Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

4.2.2.3 –IDE Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

4.2.2.4 –RTC Resume Configure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

4.2.2.5 –OS Install Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

4.2.2.6 –CSM Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

4.2.2.7 –USB Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

4.2.3 –Chipset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

4.2.3.1 –North Bridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

4.2.3.2 –South Bridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

4.2.4 –Boot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

4.2.5 –Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

4.2.6 –Save & Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

5. Warranty & RMA

5.1 –Terms and Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

5.2 –Product Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

APPENDIX A (Glossary) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

APPENDIX B (Troubleshooting) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

APPENDIX C (Abbreviations) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

WWW.PONDESK.COM

Intel® Celeron® J1900 4 LAN 3G/4G HD Fanless Firewall Router MNHO-043

Chapter 1

Introduction

Intel® Celeron® J1900 4 LAN 3G/4G HD Fanless Firewall Router MNHO-043

The PICO PC 4 LAN fanless firewall router security gateway appliance, featuring the quad-

core Intel® Celeron® Processor J1900 with Intel® HD graphics. It can be used as a security

gateway to act as a virtual private network and network firewalls. You can add multiple

LAN's or multiple WLAN's to your network, each segmented for maximum security and

configurability.

High performance & perfect for edge policy stations, network servers, LAN or WAN router,

VPN appliance, DHCP Server, DNS Server and can be configured as a firewall either open-

source or commercial, for example; pfSense, Untangle, Endian, Smoothwall, ClearOS,

m0n0wall etc. This appliance also supports windows 7/8/10. It combines a robust

industrial-grade performance and the advantages of network security management, can

be widely used in virtual private networks, traffic control, network firewalls or other network

applications.

4x intel GbE LAN, USB2.0 & USB 3.0 and dual display including HDMI and VGA powered by

Intel® HD Graphics. Support 802.11 b/g/n WiFi and WWAN 3G & 4G LTE (optional).

Compatible with windows 7/8/10, Linux & firewalls etc. Support up to 8GB SODIMM DDR3L

1.35 low voltage memory and dual storage drives including mSATA SSD and 2.5" SATA

SSD/HDD.

Compact size, durable, low cost, high reliability universal performance and ultra-low power

10W~15W consumption helps user getting much better computing experience. Stylish sleek

design, industrial standard aluminum alloy case makes it perfect and provide stable

performance.

Best for small and medium sized business networks, offices, service providers, MSP/MSSP

etc.

For details: https://www.pondesk.com/product/MNHO-043

WWW.PONDESK.COM

Intel® Celeron® J1900 4 LAN 3G/4G HD Fanless Firewall Router MNHO-043

1.1 SPECIFICATIONS

Processor

Intel® Celeron® J1900

2M Cache, 2.42 GHz

4 Cores, 4 Threads

Memory

Support up to 8 GB

Types: SODIMM DDR3L 1.35V low voltage

memory

Slots: 1 x SODIMM

Storage

Support 1 x mSATA SSD

Support 1 x 2.5" 7mm SATA SSD/HDD

Graphics

Integrated Intel® HD Graphics

688 MHz Base Frequency

854 GHz Max Dynamic Frequency

Intel® Quick Sync Video

Advanced Technologies

Intel® Virtualization Technology (VT-x)

Intel® 64

Enhanced Intel SpeedStep® Technology

Expansion Slot

1 x Mini-PCIE Slot (For WIFI, 3G/4G)

1 x mSATA Slot (For SSD)

I/O Specifications

4 x Intel® I211-AT Gigabit LAN

1 x VGA

1 x HDMI

1 x USB 2.0

1 x USB 3.0

2 x Wi-Fi Antenna Interface

1 x Restart Switch

1 x I/O Switch

2 x LED Signal indicator (power & hard

drive indicator)

Onboard I/O

1 x SYS FAN (1*3pin)

1 x DT-126RP-02P Terminal Block

1 x CTR1 (2*5pin)

1 x SATA2.0

1 x BAT1 (1*2pin) CMOS battery connector

1 x 6pin SIM interface

Support Windows 7, 8, 10 etc.

Support pfSense, Untangle, Debian,

Smoothwall, ClearOS, m0n0wall etc.

Power & Working Environment

Power Input: 12V

Type: External Adapter

Socket: 12V DC Power Jack

Consumption: 10W~15W

Power Adapter: 60W 12V/5A

Operating Temperature: -10°C ~ 60°C

Storage Temperature: -20°C ~ 70°C

Relative Humidity: 0% - 90% (non-

condensing)

Others

BIOS: AMI

Type: Fanless

Structure: Aluminum Alloy Metal Structure

Size: 126mm x 134mm x 40.6mm (L*W*H)

Weight: approx. 0.5 KG

WWW.PONDESK.COM

Intel® Celeron® J1900 4 LAN 3G/4G HD Fanless Firewall Router MNHO-043

1.2 FRONT & BACK SIDE VIEW

1.3 PACKAGE

1 x Firewall Router 1 x Power Adapter

1 x Power Cord 2 x WiFi Antenna

WWW.PONDESK.COM

Intel® Celeron® J1900 4 LAN 3G/4G HD Fanless Firewall Router MNHO-043

Chapter 2

Structure

Intel® Celeron® J1900 4 LAN 3G/4G HD Fanless Firewall Router MNHO-043

Small and slim fanless aluminum alloy chassis smaller than A4 paper, with excellent

ventilation and heat dissipation. Compact, lightweight, stylish and durable. Just 5.3 inches

by 4.9 inches by 1.6 inches. Support 2.5" 7mm SATA SSD/HDD.

2.1 INTERFACES

4 x Gigabit LAN 1 x HDD & Power Indicator

1 x USB3.0 & 1 x USB2.0 1 x 12V Power Connector

1 x HDMI 1 x I/O Switch

1 x VGA 1 x Restart Switch

WWW.PONDESK.COM

Intel® Celeron® J1900 4 LAN 3G/4G HD Fanless Firewall Router MNHO-043

WWW.PONDESK.COM

Intel® Celeron® J1900 4 LAN 3G/4G HD Fanless Firewall Router MNHO-043

2.2 OPENING THE CASE

There are 4 screws (2 screws on each sides) for holding the case cover. By unscrewing

these screws, you can remove the case cover to add or remove SSD, memory etc.

Please follow the below image to unscrew the cover. Please don’t over-tighten the screws,

it causes damage the screw holes.

WWW.PONDESK.COM

Intel® Celeron® J1900 4 LAN 3G/4G HD Fanless Firewall Router MNHO-043

Chapter 3

Motherboard

Intel® Celeron® J1900 4 LAN 3G/4G HD Fanless Firewall Router MNHO-043

PONDESK PICO PC 4 LAN Firewall router equipped with low power Nano-ITX (12*12 cm)

industrial motherboard with Onboard Baytrail series quad-core J1900 processor.

The following figure shows the top interfaces of the motherboard. In the process of

installation of the device must be careful for some part, if not properly installed, it will not

work properly.

01. Restart Switch 08. Mini PCIe (WiFi/3G Module)

02. VGA 09. mSATA (SSD)

03. HDMI 10. Power Input 12V

04. USB 2.0 & 3.0 11. LED Indicator

05. Power Switch 12. RJ45 NICs

06. SODIMM Memory Slot 13. SATAIII (2.5” SSD/HDD)

07. 3G/4G SIM Slot

WWW.PONDESK.COM

Intel® Celeron® J1900 4 LAN 3G/4G HD Fanless Firewall Router MNHO-043

3.1 LAYOUT

WWW.PONDESK.COM

Intel® Celeron® J1900 4 LAN 3G/4G HD Fanless Firewall Router MNHO-043

3.2 PROCESSOR

The system is equipped with onboard Intel® Celeron® Processor

J1900 (2M Cache, 2.42 GHz) processor powered by the Intel® Bay

Trail series chipset. Features Intel® HD graphics.

(Detail specifications: https://ark.intel.com/products/78867)

3.3 MEMORY

There is one SO-DIMM slot, which supports up to 8GB of DDR3L SODIMM 204Pins 1.35V low

voltage memory.

NOTE: The system doesn’t support ECC & 1.5V DDR3 memory, always use non-ECC 1.35V DDR3L memory.

3.3.1 Installation

Step 1: Turn off the system before installing and removing the memory.

Step 2: Align the notch and insert the memory module into the socket at a slight 30-40°

angle relative to the memory slot.

Step 3: Push down the memory until it slips down and properly seated into the socket.

WWW.PONDESK.COM

Intel® Celeron® J1900 4 LAN 3G/4G HD Fanless Firewall Router MNHO-043

3.4 STORAGE

The system supports dual storage drives including 1 x mSATA SSD & 1 x 2.5" 7mm SATA

SSD/HDD.

3.4.1 mSATA SSD

Turn off the machine and remove the chassis cover.

Locate mSATA socket (refer to the image on page 15) on the motherboard and align the

notches of the SSD with mSATA socket and insert it.

After that screw it according to the below illustrations.

WWW.PONDESK.COM

Intel® Celeron® J1900 4 LAN 3G/4G HD Fanless Firewall Router MNHO-043

3.4.2 2.5” SATA SSD/HDD

PICO PC also support 1 x 2.5” SATA SSD OR 2.5” SATA HDD (7mm) secondary storage.

To add 2.5” SSD in the machine, first remove the case cover and locate the SSD/HDD holes.

(please refer to page # 12 & 13)

First attach SSD/HDD with the case cover by the 4 screws and then connect the SATA data

& power cable with the machine. As shown in below image.

WWW.PONDESK.COM

Intel® Celeron® J1900 4 LAN 3G/4G HD Fanless Firewall Router MNHO-043

3.5 Wi-Fi & 3G/4G

The system supports wireless or 3G/4G LTE networks.

There is one mini PCIe slot for WiFi or 3G/4G LTE module.

3.5.1 Wi-Fi

PICO PC comes with 802.11 b/g/n 2.4GHz half mini PCI-E

wireless card. (Up to 150Mbps)

3.5.2 3G/4G LTE

System support 3G/4G LTE networks. There is 6pin SIM interface for WWAN connectivity.

Please follow below the useful links to find the list of 3G (UMTS) and 4G (LTE) networks

around the world, grouped by their frequency bands. Helps to find the right module as per

your country/Territory.

3G (UMTS): https://en.wikipedia.org/wiki/List_of_UMTS_networks

4G (LTE): https://en.wikipedia.org/wiki/List_of_LTE_networks

WWW.PONDESK.COM

Table of contents

Other PICO PC Network Router manuals

PICO PC

PICO PC MNHO-113 User manual

PICO PC

PICO PC MNHO-048 User manual

Popular Network Router manuals by other brands

SHURflo

SHURflo LCB - GO installation manual

D-Link

D-Link DFL-300 - Security Appliance user manual

QOLSYSYS

QOLSYSYS IQ PANEL user manual

Airlinkplus

Airlinkplus UG-ASW116-1103 user guide

Asus

Asus RT-AC86U quick start guide

Philips

Philips SNB5600/00 quick start guide

Verizon

Verizon 4G LTE user manual

Ruijie

Ruijie RSR30-X-SPU10 Hardware installation and reference guide

Hootoo

Hootoo HT-TM05 TripMate user guide

NetComm

NetComm NB6PLUS4WN user guide

Billion

Billion BiPAC 7202 quick start guide

HP FlexFabric 5930 Series Security configuration guide

Niveo Professional

Niveo Professional NR-10 user manual

Tropos Networks

Tropos Networks 5210 installation guide

D-Link

D-Link DIR-853 user manual

Linksys

Linksys BEFVP41 - EtherFast Cable/DSL VPN Router user guide

BEC

BEC 6200WZL user manual

D-Link

D-Link DIR-605L user manual

PICO PC MNHO-043 User manual

Popular Network Router manuals by other brands
