PinSound Motion Control User manual

Shaker kit for Stern SAM
KIT CONTENT
x4
ps-mc-shaker-sam
TOOLS
Turn your machine OFF
1 LIFT THE PLAYFIELD
1/4" nut driver
Phillips screwdriver
shaker motor plastic cover SAM shaker board
installation manual
cables x2
x4
x4

X4
Hex head screws x4
INSTALL SHAKER BOARD ON THE
CABINET
5
LOCATE THE 4 PRE-EXISTING T-NUTS
2
Screw the board in pre-drilled
holes on the side of the cabinet
Phillips head screws x4
3 INSTALL THE SHAKER MOTOR
4 INSTALL THE PLASTIC COVER

Installation video
Firmware update
Guide
Q&A
pinsound.org/help
Have fun with your new shaker!
NEED HELP?
ENJOY!8
SHAKER TEST
7
PLUG AND ROUTE CABLES
6
Go to
SERVICE MENU
-> DIAGNOSTICS MENU
-> COIL MENU
-> SINGLE COIL TEST
-> #8 SHAKER MOTOR (OPTIONAL)
