Thank you for buying this Pioneer product. Before using the drive, read all warnings, cautions, notices and other
important safety information contained in these Operating Instructions. Please read the entire manual before using
this drive as it contains important information, such as regulatory data, software license agreement(s), product
registration details, service instructions and guidelines.
WARNING
This equipment is not waterproof. To prevent a fire
or shock hazard, do not place any container filled
with liquid near this equipment (such as a vase or
flower pot) or expose it to dripping, splashing, rain
or moisture. D3-4-2-1-3_B_En
Precautions Regarding Use
•
•
•
DANGER – VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN. AVOID DIRECT EXPOSURE TO BEAM.
Pioneer may not be held liable for the loss of any data or any other direct or indirect damage suffered as the
result of the use or breakdown of this product. It is strongly recommended to regularly back up all critical data.
Care must be taken not to infringe copyright restrictions under the laws of each country. If this device is used
to record copyrighted materials, approval must be obtained from the respective copyright holders. The
recording of copyrighted materials without the express approval of the respective copyright holders may result
in legal penalties. Pioneer disclaims any and all responsibility for any legal damages resulting from the use of
this device in the unauthorized copying of copyrighted materials.
All names of corporations, products, and systems listed herein, even when the (™) or (®) symbols are omitted,
are considered the registered trademarks of the respective owners.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
CAUTION:
TO PREVENT THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
IMPORTANT
D3-4-2-1-1_A1_En
WARNING
To prevent a fire hazard, do not place any naked flame
sources (such as a lighted candle) on the equipment.
D3-4-2-1-7a_A1_En
WARNING
This product equipped with a three-wire grounding
(earthed) plug - a plug that has a third (grounding) pin.
This plug only fits a grounding-type power outlet. If you
are unable to insert the plug into an outlet, contact a
licensed electrician to replace the outlet with a properly
grounded one. Do not defeat the safety purpose of the
grounding plug.
D3-4-2-1-6_A1_En
BDR-X12UBK_ORC8299-A.book 2 ページ ２０１９年１１月２７日 水曜日 午後４時３３分

CAUTION : USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
CAUTION : THE USE OF OPTICAL INSTRUMENTS WITH THIS PRODUCT WILL INCREASE EYE HAZARD.
D6-8-2-1_En
For PLUGGABLE EQUIPMENT, the socket-outlet shall be installed near the equipment and shall be easily
accessible.
Operating Environment
Operating environment temperature and humidity:
+5 °C to +35 °C (+41 °F to +95 °F); less than 80 %RH (cooling vents not blocked)
Do not install this unit in a poorly ventilated area, or in locations exposed to high humidity or direct sunlight (or
strong artificial light)
D3-4-2-1-7c*_A1_En
CAUTION
This product is a class 1 laser product, but this
product contains a laser diode higher than Class 1.
To ensure continued safety, do not remove any covers
or attempt to gain access to the inside of the product.
Refer all servicing to qualified personnel.
The following caution label appears on your unit.
CLASS 1
LASER PRODUCT
D3-4-2-1-8*_C_En
ここを開くとクラス 3B の可視レーザ放射及び不可視レーザ
放射が出ます。ビームの目又は皮膚への被ばくは危険！
見たり触れたりしないこと。
Location: Top of built-in drive and rear of outer
mounting case Location: Top of built-in drive
IMPORTANT NOTICE
THE MODEL NUMBER AND SERIAL NUMBER OF THIS EQUIPMENT ARE ON THE REAR OR BOTTOM.
RECORD THESE NUMBERS ON YOUR ENCLOSED WARRANTY CARD AND KEEP IN A SAFE PLACE FOR FUTURE
REFERENCE.
D36-AP9-1_A1_En
BDR-X12UBK_ORC8299-A.book 3 ページ ２０１９年１１月２７日 水曜日 午後４時３３分

Machine Noise Information Regulation 3.
GPSGV: The highest sound-pressure level is 70 dB(A) or less in accordance EN ISO 7779.
This product was classified under the Safety of laser products, IEC 60825-1:2014
is a trademark of Blu-ray Disc Association.
is a trademark of DVD Format/Logo Licensing Corporation.
Information to User
Alterations or modifications carried out without appropriate authorization may invalidate the user’s right to operate
the equipment. D8-10-2_A1_En
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
D8-10-1-2_A1_En
FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Product Name:
BD/DVD/CD WRITER
Model Number: BDR-X12UBK
Responsible Party Name: PIONEER ELECTRONICS (USA) INC.
Address: 2050 W. 190th Street, Suite 100, Torrance, CA 90504
Phone: [phone]
URL: https://www.pioneerelectronics.com/PUSA/
D8-10-4*_C1_En
CAUTION
This product satisfies FCC regulations when shielded cables (with Ferrite-cores attached) and connectors are used to
connect the unit to other equipment. To prevent electromagnetic interference with electric appliances such as radios
and televisions, use shielded cables (with Ferrite-cores attached) and connectors for connections.
D8-10-3b_A1_En
BDR-X12UBK_ORC8299-A.book 4 ページ ２０１９年１１月２７日 水曜日 午後４時３３分

Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in
accordance with the manufacturer’s
instructions.
Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A
grounding type plug has two blades and a third
grounding prong. The wide blade or the third
prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
Only use attachments/accessories specified by
the manufacturer.
Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
Unplug this apparatus during lightning storms
or when unused for long periods of time.
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
D3-7-13-69_En
11)
12)
13)
14)
BDR-X12UBK_ORC8299-A.book 5 ページ ２０１９年１１月２７日 水曜日 午後４時３３分

6
En
Safety instructions
To ensure your personal safety and to maximize the full operating potential of your unit, read and follow
these safety instructions.
Read & Retain Instructions – Read all operating and user information provided with this drive.
Cleaning – Use a damp cloth to clean the exterior housing. Avoid using any fluids including liquid,
aerosol or alcohol-based cleaning products.
Water or Moisture – Avoid operating or locating this drive near water or other sources of fluid.
Accessories – Do not place this product on an unstable cart, stand, or table. The product may fall and
be seriously damaged.
Operation – Avoid moving, lifting or reorienting this drive while a disc is rotating inside.
Environment – Avoid installing this drive in a location with exposure to large quantities of dust, high
temperatures, high humidity, or subject to excessive vibrations or shocks.
Power Sources – Operate this drive only from the attached power sources.
Power-Cord Protection – When unplugging the unit, pull on the plug – not on the cord. Do not handle
the cord or plug with wet hands; doing so could cause an electric short or shock. Do not allow anything
to pinch or rest on the power cord and do not place in a walkway.
Overloading –Do not overload wall outlets and extension cords. Doing so may result in fire or electric
shock.
Object & Liquid Entry – Never push inappropriate objects into the device. Avoid spilling any liquids into
or on the outside of the drive.
Condensation – Moisture can form in the operating section of the product if the drive is taken from cool
surroundings to a room with a warmer temperature. Let the drive stand for one to two hours in the new
location before turning it ON.
Servicing – Opening or removing the cover exposes you to possible electrical shock or other danger.
Contact a Pioneer authorized service representative for repairing this drive (refer to the enclosed Service
& Support Card).
Damage Requiring Service – Unplug the unit and refer servicing to qualified service personnel in the
following situations:
• When the power cord, plug, or chassis is damaged.
• If liquid has been spilled.
• If the product has been exposed to rain or water.
• If the product does not operate normally when the operating instructions are followed. Adjust only
those controls that are covered by the operating instructions. Improper adjustment of other
controls may result in damage and can require extensive work by a qualified technician to restore
the unit to its normal operation.
• When the product exhibits a distinct change in performance – this indicates a need for service.
BDR-X12UBK_ORC8299-A.book 6 ページ ２０１９年１１月２７日 水曜日 午後４時３３分

7
En
English
About DualDisc Playback – DualDisc is a two-sided disc with one side containing DVD video/audio/etc.
content and the opposite side containing non-DVD content such as digital audio material. The non-DVD
audio side is not compliant with the CD Audio Specification; therefore, may not play. The DVD side of
DualDisc media plays in this unit. For more details about the DualDisc specification, please refer to the
disc manufacturer or your retailer.
Note
Some discs may not be playable due to different recording formats or the physical condition of the
disc at the time of recording or playback.
If there are irregularities with the AC adapter or power plug, ask your nearest Pioneer authorized service
center or your dealer to carry out repair work.
• When mounting the AC adapter on a wall outlet, make sure there is no space between the AC adapter
and the wall outlet. Faulty contact or a coin, paper clip or other metal object getting stuck in the space
could cause a short circuit, leading to fire or electric shock.
The supplied AC adapter and power cord are designed specifically for this unit. Do not use them for
another device. A fire or electric shock may occur.
• Avoid touching or scratching the signal surface (shiny side) of the
disc.
• Hold the disc by the edges or by the center hole and one edge.
• Do not affix paper or labels to the disc.
• Discard warped or cracked discs as they may cause damage to
the drive.
• Avoid specially shaped discs such as hearts or polygons.
• Remove dust or lint from the disc with a soft cloth by wiping from
the inside to the outside edge rather than in a circular motion.
• Do not use record-cleaning or anti-static agents as the solutions
may cause damage to a disc.
Always be sure to store your discs in proper disc storage cases
when not in use, and always be sure to check for dirt or dust
on discs (especially on the signal surface) before use.
BDR-X12UBK_ORC8299-A.book 7 ページ ２０１９年１１月２７日 水曜日 午後４時３３分

8
En
Operating environment
The operating environment below is only for reference. It does not guarantee the operation.
During DVD/CD disc writing and reading
• Supported OS: Windows 7, Windows 8, Windows 8.1, Windows 10, Mac OS X 10.11, macOS Sierra
10.12, macOS High Sierra 10.13, macOS Mojave 10.14, Catalina 10.15*1standard loaded model
• CPU: Pentium III 800 MHz or above (Pentium 4, 2.2 GHz or above*2)
• Memory: 128 MB or above (256 MB or above*2)
• Hard disk free space: 2 GB or above (7 GB or above*2)
• Sound card: 16 bit or above
• Graphic: 1024 × 768, 32 bit or above display
• Devices: Arrange for a separate video input device (video cassette recorder and camcorder, etc.) and
capture card.
During Blu-ray disc writing and reading
• Supported OS: Windows 7, Windows 8, Windows 8.1, Windows 10, Mac OS X 10.11, macOS Sierra
10.12, macOS High Sierra 10.13, macOS Mojave 10.14, Catalina 10.15*1standard loaded model
• CPU: Core Duo T2700/Core 2Duo E6300 or above
• Memory: 1 GB or above
• Hard disk free space: During recording 25 GB (50 GB or above*2), during playback 120 MB
• Graphic: During digital output of BD-Video videos, an HDCP-compatible graphic function and monitor
are required.
*1: For the latest OS support information, see the product website.
*2: Recommended operating environment
The required environment varies depending on your OS and applications.
For answers to your queries on the OS and applications, contact the consultation desk of each software
manufacturer.
Blu-ray Disc, BDXL, the Blu-ray Disc and BDXL logos are trademarks of the Blu-ray Disc Association.
Windows is a registered trademark of Microsoft Corporation in the U.S. and other countries.
Mac, Mac logo, Mac OS, OS X and macOS are trademarks of Apple Inc., registered in the U.S. and other
countries.
Other company and product names used herein might be the trademarks or registered trademarks of
their respective companies.
BDR-X12UBK_ORC8299-A.book 8 ページ ２０１９年１１月２７日 水曜日 午後４時３３分

9
En
English
Features
WRITE SPEED (MAXIMUM)* READ SPEED (MAXIMUM)*
BD-ROM (SL/DL) – 12X/8X
BD-R (SL/DL) 16X/14X 12X/8X
BD-RE (SL/DL) 2X 10X/6X
BD-R (TL/QL) 8X/6X 6X
BD-RE (TL) 2X 4X
BD-R LTH 8X 8X
M-DISC (BD) SL 4X 12X
M-DISC (BD) DL 8X 8X
M-DISC (BD) TL 6X 6X
DVD-ROM (SL/DL) – 16X/12X
DVD±R (SL) 16X 16X
DVD±R (DL) 8X 12X
DVD-RW 6X 12X
DVD+RW 8X 12X
DVD-RAM 5X 5X
M-DISC (DVD) 4X 16X
CD-ROM – 40X
CD-R 40X 40X
CD-RW 24X 24X
* When using a USB 2.0 port, BD writing/reading speed doesn't achieve 6X or above.
Buffer Memory Size
Interface 4 MBytes USB 3.1 Gen1/3.0/2.0
Disc Format
•BD-ROM(SL/DL)
• BD-R(SL/DL/TL/QL)
• BD-RE(SL/DL/TL)
• M-DISC BD-R (SL/DL/TL)
•DVD-ROM(SL/DL)
• DVD-Video (SL/DL)
• DVD-R (SL/DL)
•DVD-RW
•DVD+R(SL/DL)
•DVD+RW
• DVD-RAM (Non-cartridge), ver2.0&2.1&2.2
•M-DISC(DVD)
• CD-ROM Mode 1&2
• CD-ROM XA Mode 2 (form 1, form 2)
• KODAK Photo CD (Single and Multi-session)
• CD-Extra (CD PLUS)
•CDtext
•CD-R
• CD-RW (HS/US/US+)
•CD-DA
•VideoCD
media is supported only reading.
Note
•A specific application software is necessary to write the formats listed above.
•Supported media required for specific BD, DVD and CD writing speeds.
•Average writing speed may decrease when multiple discs are written during the same session.
•The Pioneer's Drive Utility is needed to configure the Quiet Drive and PureRead features.
https://pioneer.jp/support/download/index-e.html
BDR-X12UBK_ORC8299-A.book 9 ページ ２０１９年１１月２７日 水曜日 午後４時３３分

10
En
Interface
Front view
1 Forced Ejection Hole
Insert a stiff rod into the hole and push to eject the tray when the tray doesn’t open by pressing the Eject
button. During normal operation, the eject button should be used to unload the tray. Make sure the power
to the drive is turned off and wait more than one minute till the disc rotation is stopped when accessing the
eject hole.
2 Disc Tray
Open the tray by pressing the eject button, then place only a BD, DVD or CD disc into the tray with the label
facing up.
Press the eject button to load the tray with the disc.
Do not attempt to pull out the disc tray forcibly.
3 Indicator
Operation status is indicated as follows.
When power off Off
When power on On
When reading Flashing
When writing Flashing
When tray opening/closing On
4 Eject Button ( h )
Opens and closes the disc tray.
* When connected to a Mac computer, this button cannot be used if a disc is inserted.
134
2
BDR-X12UBK_ORC8299-A.book 10 ページ ２０１９年１１月２７日 水曜日 午後４時３３分

11
En
English
Precautions on playing 8 cm (3.15”) Discs
• 8 cm disc adapters cannot be used with this unit.
• When this unit is installed flat, 8 cm discs may be used by placing them in the 8 cm disc depression
in the center of the disc tray.
• When this unit is installed vertically, 8 cm discs cannot be used.
Affixing the insulators (recommended affixing example)
Caution
• When using this product, be sure to use the supplied insulator. If the product is not affixed, there
is a risk of faulty operation or noise due to vibrations.
• When installing the insulator, make sure that it does not run over the protruding part.
• Before installation, wipe off any oil or dirt on the casing.
10 mm
Insulator
10 mm
[When placed vertically]
[When placed horizontally]
Align the product along the
sides and corners where there
is no unevenness and affix it.
BDR-X12UBK_ORC8299-A.book 11 ページ ２０１９年１１月２７日 水曜日 午後４時３３分

12
En
Rear view
5 DC power connector
Connect the AC adapter supplied with the unit.
6 USB connector (Type-B)
Warning
Do not place the unit within the reach of small children.
In the event that a small part is swallowed, seek medical attention immediately.
* Blu-ray, Blu-ray Disc, Blu-ray 3D, and Blu-ray 3D logo are trademarks of Blu-ray Disc Association.
56
BDR-X12UBK_ORC8299-A.book 12 ページ ２０１９年１１月２７日 水曜日 午後４時３３分

13
En
English
Connection
Connecting the power cord
Caution
• Connect the power cord before connecting the unit to a computer.
• About Region codes
– The region code for this drive is set to “1” by default. The region code can only be changed four
(4) times, including the initial setting. Please be aware that the fourth change becomes
PERMANENT. Therefore, avoid changing the region code unless absolutely necessary.
– Region codes are part of the DVD Standard. However, region codes on DVD discs are optional.
DVD discs with no specified region code can be played on all compliant players and/or
application.
AC adapter (accessory)
Power cord (accessory)
BDR-X12UBK_ORC8299-A.book 13 ページ ２０１９年１１月２７日 水曜日 午後４時３３分

14
En
Connecting the USB cable
This is a hot-plug unit. Connect the unit to the supplied USB cable.
1 Confirm that your computer (PC) has available USB port.
2 With your Windows or Mac operating system running, use the supplied USB cable to connect this
unit to the PC.
Caution
• Do not disconnect the USB cable during data transfers.
• Do not disconnect the USB cable during the PC start nor any operation with the unit.
Note
• It is recommended to connect to USB 3.0 port or above, , since when a USB 3.0 cable is connected
to a USB 2.0 port, the connection will be limited to USB 2.0 performance standards.
• This unit can operate with USB 1.1 but will not provide optimum performance.
• Connecting this unit through a USB HUB or using unspecified cables may not guarantee proper
operation.
• The unit will not run on power supplied from the USB connector (bus power). Be sure to use the
unit with the AC adapter supplied with the unit connected.
USB Type-A
(USB 3.0 or higher
is recommended)
USB Type-B
USB cable (accessory)
BDR-X12UBK_ORC8299-A.book 14 ページ ２０１９年１１月２７日 水曜日 午後４時３３分

15
En
English
Forced ejection method in case of
emergency
In a case such as the following, a disc can be removed using the forced ejection hole.
• If the unit fails and the disc cannot be ejected with the eject button or software
1 Check that it has powered off and the disc has stopped rotating after waiting at least one minute.
2 Straighten out a paper clip and insert it straight into the forced ejection hole and push hard.
3 The disc tray comes out about 5 to 10 mm. Pull the tray all the way out and remove the disc.
Caution
• Do not force eject a disc while it is rotating. An injury or disc damage may occur.
• Do not place any object within 12 cm of the front of the unit as it may obstruct the disc ejection
operation.
BDR-X12UBK_ORC8299-A.book 15 ページ ２０１９年１１月２７日 水曜日 午後４時３３分

16
En
Specifications
Orientation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . This device supports both vertical installation and horizontal.
Disc Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.72 inch (12 cm) / 3.15 inch (8 cm) *
* 3.15 inch (8 cm) discs cannot be used with upright position.
(Drive does not support non-standard shapes such as business cards, diamond, etc.)
(Drive does not support 8 cm adapter.)
Data Transfer Rate * Media that is dirty or damaged can affect the transfer rate.
Data Read (sustained) BD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Max. 54.0 MBytes/sec.
DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Max. 21.6 MBytes/sec.
CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Max. 6.0 MBytes/sec.
Data Write (sustained) BD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Max. 72.0 MBytes/sec. (16X BD-R)
DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Max. 21.6 MBytes/sec. (16X DVD-R)
CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Max. 6.0 MBytes/sec. (40X CD-R)
Access Time/Seek Time (Random Averages)
Access Time BD-ROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .180 ms
DVD-ROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .170 ms
CD-ROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .160 ms
Seek Time BD-ROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .160 ms
DVD-ROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .150 ms
CD-ROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .140 ms
AC Input Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AC 120 V, 60 Hz
Power consumption (Rating). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 W
No load power consumption. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.3 W
Physical Information
Dimensions (excluding foot pad) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.30 inch (W) x 8.66 inch (D) x 1.97 inch (H)
160 mm (W) x 220 mm (D) x 50 mm (H)
Weight (Drive only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.4 lbs/1.1 kg (Typ.)
Operation Temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +41 °F to +95 °F (+5 °C to +35 °C)
Operation Humidity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 % to 80 % (no condensation)
[AC Adapter]
Dimensions (Body only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.54 inch (W) x 1.49 inch (D) x 1.06 inch (H)
89.8 mm (W) x 37.8 mm (D) x 27.0 mm (H)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0.33 lbs / 0.15 kg (Typ.)
Accessories
Instruction manual (This document)
USB Type-A to USB Type-B (1 m). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Insulators for horizontal placement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Insulators for vertical placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
AC adapter (OWR8003-) (1.2m) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Power cord (0.5 m) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Warranty Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
BDR-X12UBK_ORC8299-A.book 16 ページ ２０１９年１１月２７日 水曜日 午後４時３３分

17
En
English
Pioneer Drive Utility and USB High Speed Driver
To download the Pioneer Drive Utility and USB High Speed Driver, visit:
https://pioneer.jp/device_e/product-e/ibs/device_e/dev00001r_e.html
• The Pioneer Drive Utility is needed to configure the Quiet Drive and PureRead features.
• When the USB High Speed Driver is not installed, it may not be up to 16x writing speed on BD-R.
Note
Specifications and designs are subject to possible modifications without notice, due to improvements.
© 2019 PIONEER CORPORATION.
All rights reserved.
BDR-X12UBK_ORC8299-A.book 17 ページ ２０１９年１１月２７日 水曜日 午後４時３３分

Nous vous remercions pour cet achat de ce produit Pioneer. Avant d’utiliser ce lecteur, veuillez lire et comprendre
toutes les mises en garde, avis et avertissements, ainsi que tous les renseignements importants sur la securite qui
apparaissent dans ce manuel d’utilisation. De plus, lisez tout le manuel avant d’utiliser ce produit, car il contient
des renseignements importants, tels que les donnees de reglementation, les licences d’utilisation des logiciels,
l’enregistrement des produits, le service et le fonctionnement.
AVERTISSEMENT
Cet appareil n’est pas étanche. Pour éviter les
risques d’incendie et de décharge électrique, ne
placez près de lui un récipient rempli d’eau, tel
qu’un vase ou un pot de fleurs, et ne l’exposez pas
à des gouttes d’eau, des éclaboussures, de la pluie
ou de l’humidité. rF_A_3-1-2-4-3D
Précautions relatives à l’utilisation
Pioneer n’est responsable d’aucune perte de donnée ni d’aucun autre dommage direct ou indirect que ce soit
•découlant de l’utilisation ou de la défaillance de ce produit. Il est fortement recommandé que vous fassiez
régulièrement des copies de secours de vos données importantes.
Assurez-vous de ne contrevenir à aucune restriction de droit d’auteur imposée par les lois de tout pays que ce
•soit. Si ce dispositif est utilisé pour enregistrer du matériel protégé par des droits d’auteur, vous devez d’abord
obtenir l’approbation des titulaires respectifs de tels droits. L’enregistrement du matériel protégé par des
droits d’auteur sans l’approbation expresse préalable des titulaires respectifs de tels droits peut entraîner des
sanctions judiciaires. Pioneer rejette toute responsabilité en cas de dommages légaux découlant de l’utilisation
de ce dispositif pour faire des copies non autorisées de tout matériel protégé par des droits d’auteur que ce
soit.
Tous les noms de corporations, de produits et de systèmes indiqués dans les présentes, même lorsque les
•symboles (™) ou (®) sont omis, doivent être considérés comme des propriétés commerciales de leur titulaire
respectif.
Ce point d’exclamation, placé dans un
triangle équilatéral, a pour but d’attirer
l’attention de l’utilisateur sur la présence,
dans les documents qui accompagnent
l’appareil, d’explications importantes du
point de vue de l’exploitation ou de
l’entretien.
Ce symbole de l’éclair, placé dans un
triangle équilatéral, a pour but d’attirer
l’attention de l’utilisateur sur la présence, à
l’intérieur du coffret de l’appareil, de
“tensions dangereuses” non isolées d’une
grandeur suffisante pour représenter un
risque d’électrocution pour les êtres
humains.
ATTENTION :
POUR ÉVITER TOUT RISQUE
D’ÉLECTROCUTION, NE PAS ENLEVER LE
COUVERCLE (NI LE PANNEAU ARRIÈRE).
AUCUNE PIÈCE RÉPARABLE PAR
L’UTILISATEUR NE SE TROUVE À
L’INTÉRIEUR. CONFIER TOUT ENTRETIEN À
UN PERSONNEL QUALIFIÉ UNIQUEMENT.
ATTENTION
DANGER D´ELECTROCUTION
NE PAS OUVRIR
IMPORTANT
D3-4-2-1-1_A1_Fr
AVERTISSEMENT
Cet appareil est muni d’une fiche de mise à la terre
(masse) à trois fils. Comme la fiche présente une
troisième broche (de terre), elle ne peut se brancher
que sur une prise de courant, prévue pour une mise à
la terre. Si vous n’arrivez pas à insérer la fiche dans la
prise de courant, contactez un électricien qualifié pour
faire remplacer la prise par une qui soit mise à la terre.
N’annulez pas la fonction de sécurité que procure cette
fiche de mise à la terre.
D3-4-2-1-6_A1_Fr
AVERTISSEMENT
Pour éviter les risques d’incendie, ne placez aucune
flamme nue (telle qu’une bougie allumée) sur l’appareil.
D3-4-2-1-7a_A1_Fr
BDR-X12UBK_ORC8299-A.book 2 ページ ２０１９年１１月２７日 水曜日 午後４時３３分

ATTENTION
Cet appareil est un produit laser de Classe 1, mais la
diode laser qu’il renferme est supérieure à la Classe 1.
Pour garantir une sécurité constante, ne retirez aucun
des couvercles et n’essayez pas d’avoir accès à
l’intérieur de l’appareil.
Confiez toute réparation à un personnel qualifié.
L’étiquette suivante se trouve sur votre appareil.
D3-4-2-1-8*_C_Fr
APPAREIL Á LASER
DE CLASSE 1
Pour un ÉQUIPEMENT ENFICHABLE, la prise de courant sera installée près de l’équipement et elle sera
facilement accessible.
Réglementation 3 d’information sur bruits de machine,
Cet appareil est classé selon la norme de Sécurité des produits laser IEC 60825-1:2014.
GPSGV: Le niveau de pression sonore mazimum est de 70 dB(A) ou moins, conformemént à EN ISO 7779.
Milieu de fonctionnement
Température et humidité du milieu de fonctionnement :
De +5 °C à +35 °C (de +41 °F à +95 °F) ; Humidité relative inférieure à 80 % (orifices de ventilation non obstrués)
N’installez pas l’appareil dans un endroit mal ventilé ou un lieu soumis à une forte humidité ou en plein soleil (ou à
une forte lumière artificielle). D3-4-2-1-7c*_A1_Fr
ここを開くとクラス 3B の可視レーザ放射及び不可視レーザ
放射が出ます。ビームの目又は皮膚への被ばくは危険！
見たり触れたりしないこと。
Emplacement : Dessus du lecteur incorporé
Emplacement : Dessus du lecteur incorporé et arrière
du boîtier de montage extérieur
est une marque de commerce de DVD Format/Logo Licensing Corporation.
est une marque commerciale de Blu-ray Disc Association.
BDR-X12UBK_ORC8299-A.book 3 ページ ２０１９年１１月２７日 水曜日 午後４時３３分

4
Fr
Instructions de sécurité
Pour garantir votre sécurité personnelle et obtenir le maximum de votre lecteur, lire et suivre ces
consignes de sécurité.
Lire les instructions – Lire toutes les instructions de sécurité et d’utilisation avant d’actionner le lecteur.
Nettoyage – NE PAS utiliser de liquides, de détachants en aérosol ou de l’alcool. N’utiliser qu’un
chiffon humide pour nettoyer les surfaces extérieures du boîtier.
Eau et humidite – NE PAS utiliser ce produit à proximité d’eau.
Accessoires – Ne pas placer ce produit sur un chariot, un support ou une table instable. Le produit peut
tomber et être sérieusement endommagé.
Fonctionnement – Evitez de déplacer, de soulever ou de changer l’orientation de ce lecteur pendant
qu’un disque tourne à l’intérieur.
Environnement – Ne pas utiliser cet appareil dans des endroits avec beaucoup de poussière, une
température ou une humidité élevée. Utiliser l’appareil à un endroit ou il n’est pas soumis à des
vibrations ou des chocs.
Sources d’alimentation – Utiliser ce produit uniquement à partir des sources d’alimentation connectées.
Protection du cordon d’alimentation – Débrancher l’appareil en tirant sur la fiche et non sur le
cordon. Ne pas manipuler le cordon ou la fiche avec les mains mouillées; cela pourrait provoquer un
court-circuit ou un choc électrique. Faire attention que rien ne puisse pincer ou être posé sur le cordon
d’alimentation et ne pas le placer sur un passage.
Surcharge – NE PAS surcharger les prises murales et les cordons rallonges. Cette pratique peut
entraîner un incendie ou une secousse électrique.
Penetration d’objets et de liquides – No jamais enfoncer d’objet d’aucune sorte dans ce produit. Le
contact avec des points de tension dangereux peut provoquer un court-circuit, entraînant un incendie
ou une secousse électrique. Ne pas verser de liquide d’aucune sorte sur ce produit.
Condensation – De l’humidité se forme sur la section de fonctionnement du produit entraînant une
baisse de performances s’il est amené d’un endroit trais vers un environnement
plus chaud. En cas de
déplacement de l’appareil vers un endroit ayant une température plus chaude,
laisser le produit perdant 1
à 2 heures dans le nouvel endroit avant de le remettre sous tension.
Entretien – Ne pas essayer de réparer soi-même ce produit. L’ouverture ou le retrait des capots peut
vous exposer à une tension dangereuse ou d’autres dangers. Pour tout entretien, demander à un
personnel d’entretien qualifie. (Se reporter à la carte d’entretien et de support jointe.)
Problèmes nécessitant une intervention – Débranchez l’appareil et confiez le service à un personnel
d’entretien qualifié dans les cas suivants :
• Si le cordon d’alimentation, la fiche et/ou le châssis est endommagé.
• Si du liquide a été renversé.
• Si l’appareil a été mouillé par de l’eau ou de la pluie.
•
Si l’appareil ne fonctionne pas normalement alors que les instructions du mode d’emploi ont été
respectées. Agissez uniquement sur les commandes tel qu’expliqué dans le mode d’emploi.
Des
réglages inappropriés d’autres commandes peuvent provoquer des dégâts et entraîner des travaux
coûteux par un technicien qualifié pour rendre à l’appareil son fonctionnement normal.
BDR-X12UBK_ORC8299-A.book 4 ページ ２０１９年１１月２７日 水曜日 午後４時３３分
