Thank you for buying this Pioneer product. Before using the drive, read all warnings, cautions, notices and other
important safety information contained in these Operating Instructions. Please read the entire manual before using
this drive as it contains important information, such as regulatory data, software license agreement(s), product
registration details, service instructions and guidelines.
WARNING
This equipment is not waterproof. To prevent a fire
or shock hazard, do not place any container filled
with liquid near this equipment (such as a vase or
flower pot) or expose it to dripping, splashing, rain
or moisture. D3-4-2-1-3_B_En
WARNING: Handling the cord on this product or
cords associated with accessories sold with the
product may expose you to chemicals listed on
proposition 65 known to the State of California and
other governmental entities to cause cancer and
birth defect or other reproductive harm.
D36-P4_A_En
Wash hands after handling
Precautions Regarding Use
•
•
•
DANGER – VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN. AVOID DIRECT EXPOSURE TO BEAM.
Pioneer may not be held liable for the loss of any data or any other direct or indirect damage suffered as the
result of the use or breakdown of this product. It is strongly recommended to regularly back up all critical data.
Care must be taken not to infringe copyright restrictions under the laws of each country. If this device is used
to record copyrighted materials, approval must be obtained from the respective copyright holders. The
recording of copyrighted materials without the express approval of the respective copyright holders may result
in legal penalties. Pioneer disclaims any and all responsibility for any legal damages resulting from the use of
this device in the unauthorized copying of copyrighted materials.
All names of corporations, products, and systems listed herein, even when the (™) or (®) symbols are omitted,
are considered the registered trademarks of the respective owners.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
CAUTION:
TO PREVENT THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
IMPORTANT
D3-4-2-1-1_A1_En
BDR-XD04_KU_En.fm 2 ページ ２０１１年９月３０日 金曜日 午後３時３２分

CAUTION
This product is a class 1 laser product, but this
product contains a laser diode higher than Class 1.
To ensure continued safety, do not remove any covers
or attempt to gain access to the inside of the product.
Refer all servicing to qualified personnel.
The following caution label appears on your unit.
Location: bottom of the unit
CLASS 1
LASER PRODUCT
D3-4-2-1-8*_C_En
CAUTION : USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
CAUTION : THE USE OF OPTICAL INSTRUMENTS WITH THIS PRODUCT WILL INCREASE EYE HAZARD.
D6-8-2-1_En
For PLUGGABLE EQUIPMENT, the socket-outlet shall be installed near the equipment and shall be easily
accessible.
BDR-XD04
IMPORTANT NOTICE
RECORD THE MODEL NUMBER AND SERIAL NUMBERS OF THIS EQUIPMENT BELOW.
THE NUMBERS ARE ON THE BOTTOM.
MODEL NO.
SERIAL NO.
KEEP THESE NUMBERS FOR FUTURE USE.
D1-4-2-6-2*_A1_En
Operating Environment
Operating environment temperature and humidity:
+5 °C to +35 °C (+41 °F to +95 °F); less than 85 %RH (cooling vents not blocked)
Do not install this unit in a poorly ventilated area, or in locations exposed to high humidity or direct sunlight (or
strong artificial light)
D3-4-2-1-7c*_A1_En
ここを開くとクラス 3B の可視レーザ放射及び不可視レーザ
放射が出ます。ビームの目又は皮膚への被ばくは危険！
見たり触れたりしないこと。
BDR-XD04_KU_En.fm 3 ページ ２０１１年９月３０日 金曜日 午後３時３２分

Machine Noise Information Regulation 3.
GPSGV: The highest sound-pressure level is 70 dB(A) or less in accordance EN ISO 7779.
This product was classified under the Safety of laser products, IEC 60825-1:2007
[Canadian model only]
is a trademark of Blu-ray Disc Association.
is a trademark of DVD Format/Logo Licensing Corporation.
This Class B digital apparatus complies with Canadian ICES-003.
D8-10-1-3_A1_En
Information to User
Alterations or modifications carried out without appropriate authorization may invalidate the user’s right to operate
the equipment. D8-10-2_A1_En
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
D8-10-1-2_A1_En
CAUTION
This product satisfies FCC regulations when shielded cables (with Ferrite-cores attached) and connectors are used to
connect the unit to other equipment. To prevent electromagnetic interference with electric appliances such as radios
and televisions, use shielded cables (with Ferrite-cores attached) and connectors for connections. D8-10-3b_A1_En
FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Product Name:
BD/DVD/CD WRITER
Model Number: BDR-XD04
Responsible Party Name: PIONEER ELECTRONICS (USA) INC.
Address: P.O. BOX 1760, Long Beach, California 90801-1760, U.S.A.
Phone: [phone]
URL: http://www.pioneerelectronics.com/PUSA/
D8-10-4*_C1_En
BDR-XD04_KU_En.fm 4 ページ ２０１１年９月３０日 金曜日 午後３時３２分

5
En
English
Safety instructions
To ensure yourpersonal safety and to maximize the full operating potential of yourunit, read and follow
these safety instructions.
Read & Retain Instructions – Read all operating and userinformation provided with this drive.
Cleaning – Use a dampcloth to clean the exteriorhousing. Avoid using any fluids including liquid,
aerosol oralcohol-based cleaning products.
Water or Moisture – Avoid operating orlocating this drive nearwaterorothersources of fluid.
Accessories – Do not place this product on an unstable cart, stand, ortable. The product may fall and
be seriously damaged.
Ventilation – Slots and openings in the chassis are forcooling and properoperation of the unit. Do NOT
block orcoverthe openings. Do NOT place this unit on a bed, rug, etc. as this can block the openings.
This unit should not be placed in a built-in installation unless properly ventilated.
Operation – Avoid moving, lifting orreorienting this drive while a disc is rotating inside.
Environment – Avoid installing this drive in a location with exposure to large quantities of dust, high
temperatures, high humidity, orsubject to excessive vibrations orshocks.
Power Sources – Operate this drive only from the recommended powersources. If you are unsure of the
powersource, consult an authorized Pioneerrepresentative.
Power-Cord Protection – When unplugging the unit, pull on the plug – not on the cord. Do not handle
the cord orplug with wet hands; doing so could cause an electric short orshock. Do not allow anything
to pinch orrest on the powercord and do not place in a walkway.
Object & Liquid Entry – Neverpush inappropriate objects into the device. Avoid spilling any liquids into
oron the outside of the drive.
Condensation – Moisture can form in the operating section of the product if the drive is taken from cool
surroundings to a room with a warmertemperature. Let the drive stand forone to two hours in the new
location before turning it ON.
Servicing – Opening orremoving the coverexposes you to possible electrical shock orotherdanger.
Contact a Pioneerauthorized service representative forrepairing this drive (referto the enclosed Service
& Support Card).
