Slim Blu-ray™
BLU FOR OUR NOTEBOOK
The LG Super Multi slim Blu-ray rewriter BT20N for your notebook
features a 6x BD-R write speed with a large 4MB buffer memory
to prevent underrun error. Record up to 128GB of files, photos, or
business documents onto a quad layer BDXL disc. SATA interface
allows for faster performance while M-DISC provides superior
reliability in data storage that is perfect for archiving important
data.
WRITE AND PLA BLU-RA DISCS INCLUDING BDXL
(QUAD LA ER)
M-DISC SUPPORT
SERIAL ATA INTERFACE
CD-R/RW, DVD-R/-RW/-R DL / +R / +RW / +R DL/ RAM
READ AND WRITE COMPATIBLE, CD FAMIL , DVD-ROM,
BD-ROM / R(SL/DL) / RE (SL/DL) READ COMPATIBLE
LARGE BUFFER MEMOR : 4MB WITH EMBEDDED
UNDER-RUN PREVENTION
SUPPORTS BD-R LTH (LOW TO HIGH DISC)
SILENT PLA FUNCTION
ROHS COMPLIANT
8x
DVD±R
MAX WRITE
2x
BD-RE
MAX WRITE
6x
BD-R
MAX READ
6x
BD-ROM (SL/DL)
MAX READ
6x
DVD±R (DL)
MAX WRITE
8x
DVD+RW
MAX WRITE
24x
CD-R
MAX WRITE
24x
CD-RW
MAX WRITE
CD
6x
DVD-RW
MAX WRITE
DVDBLU-RAY DISC
6x
BD-R (SL/DL)
MAX WRITE
Super-Multi Disc ReWriter
with M-DISC™
optical
drive
blu-ray disc rewriter BT20N
specifications
optical
drive
TECHNICAL SPECIFICATIONS
TYPE Super-Multi Slim Blu-ray Disc ReWriter
TRANSFER RATES–WRITE
BD-R (SL/DL) 2x CLV, 4x PCAV, 6x CAV
(Max.)
BDXL 4x
BD-R L TH 2x CLV, 4x PCAV, 6x CAV
BD-RE (SL/DL) 2x CLV, 2x CLV
DVD-R 2x CLV, 4x PCAV, 8x CAV
DVD-R DL 2x CLV, 6x ZCLV
DVD-RW 1x CLV, 2x CLV, 4x ZCLV, 6x ZCLV
DVD-RAM 2x CLV, 3x CLV, 5x PCAV (ver 12x
Media: Not supported)
DVD+R 2.4x CLV, 4x PCAV, 8x CAV
DVD+R DL 2.4x CLV, 6x ZCLV
DVD+RW 2.4x, 3.3x CLV, 4x ZCLV, 8x ZCLV
CD-R 10x CLV, 16x ZCLV, 24x ZCLV
CD-RW 4x CLV, 10x CLV, 16x ZCLV, 24x
ZCLV (High Speed: 10x CLV, Ultra
Speed: 24x ZCLV, Ultra Speed plus: 24x
ZCLV)
TRANSFER RATES - READ
BD-R M (SL/DL) 6x CAV
(Max.)
BD-R (SL/DL) 6x CAV
BD-R (SL LTH) 6x CAV
BD-RE (SL/DL) 6x CAV
BDXL 4x
DVD-R M (SL/DL) 8x / 8x CAV
DVD-R (SL/DL) 8x / 6x CAV
DVD-RW (SL) 8x CAV
DVD+R (SL/DL) 8x CAV
DVD+RW 8x CAV
DVD-RAM(ver.2.2) 5x PCAV
DVD-Video 4x CAV
(CSS Compliant Disc, SL/DL)
CD-R/RW/R M 24x CAV
CD-DA (DAE) 24x CAV
ACCESS TIME (Max.)
BD-R M 120 ms typ.
DVD-R M 170 ms typ.
DVD-RAM(ver.2.2) 190 ms typ.
CD-R M 170 ms typ.
SUSTAINED TRANSFER BD-R M
215.79 Mbps (6x) max.
RATE DVD-R M 11.08 Mbits/s (8x) max
CD-R M
3,600 kB/s (24x) max
BURST TRANSFER RATE
1.5 G bits/s
BUFFER SIZE 4MB (Buffer Under-run prevention function embedded)
HOST INTERFACE
Serial ATA
OPERATING SYSTEMS Windows 7, Windows Vista™, Windows XP
COMPLIANCE RoHS
DIMENSIONS (WxHxD) 5.0" x 0.5" x 5.0" (128 x 12.7 x 127mm)
WEIGHT 0.4 lbs (182g)
technology
THE SUPER MULTI BLUE ADVANTAGE
Multi Blu Compatibility
LG Super Multi Blue optical drives can read and write four
types of disc formats in one convenient package:
1. DVD+R
2. RW DVD-R
3. RW DVD-RAM
4. Blu-Ray Disc
This gives you the option to choose the media best suited for
each task.
M-DISC
Compared to other recordable DVDs on the market today,
M-DISC offers superior reliability in data storage that provides the
permanent optical data storage solution.
S rial ATA T chonology
Serial ATA is a 1.5Gbps evolutionary replacement for the
Parallel ATA physical storage interface used to connect
storage devices, such as hard disks, DVD and CD rewriters to
the PC motherboard. Serial ATA is scalable, enables design
of smaller PCs, and will allow future enhancements to the
computing platform.
BDXL
The BDXL format supports high-capacity blu-ray discs (up to
128GB write-once discs) for users that need to store a large
amount of data.
LGsolutions.com
LG Electronics U.S.A., Inc.
HE B2B Division
2000 Millbrook Drive
Lincolnshire, IL 60069
Custom r S rvic : 888.865.3026
www.LGsolutions.com/support
Contact your LG R gional Sal s R pr s ntativ :
Hospitality: 800.228.1236
Chann l: 800.897.8871
E-mail: info@LGsolutions.com
SPEC_BT20N_041218_PR
Designs, features and specifications are subject to change without notice.
© Copyright 2012 LG Electronics USA, Inc. All Rights Reserved. “LG Life’s Good” is a
registered trademark of LG Corp.
Blu-Ray Disc is a registered trademark of Sony Corporation.Windows and Windows
Vista is either a registered trademark or a trademark of Microsoft Corporation in the
United States and other countries. All other product and brand names are trademarks
or registered trademarks to their respective companies.
Printed in the USA. April 2012
