Pioneer DVR-A03 User manual
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Allexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2001
c
RRV2423
DVR-A03
1. SAFETY INFORMATION ....................................... 2
2. EXPLODED VIEWS AND PARTS LIST ................. 4
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM 8
4. PCB CONNECTION DIAGRAM ........................... 33
5. PCB PARTS LIST ................................................ 38
6. ADJUSTMENT..................................................... 41
CONTENTS 7. GENERAL INFORMATION .................................. 52
7.1 DIAGNOSIS ................................................... 52
7.1 DISASSEMBLY........................................ 52
7.2 PARTS........................................................... 55
7.2.1 IC .......................................................... 55
8. PANEL FACILITIES AND SPECIFICATIONS....... 81
