Pioneer BDP-440 User manual

ORDER NO.
PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION
2011
2011 Printed in Japan
BDP-440
RRV4271
Blu-ray 3DTM PLAYER
BDP-440
BDP-52FD
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
This service manual should be used together with the following manual(s).
For SPECIFICATIONS and PANEL FACILITIES, refer to the operating instructions.
Model Type Power Requirement DVD
Region No.
BD
Region No. Serial No. Remarks
BDP-440 YXCN5 AC 100 V to 240 V 2 B &&&&######YY YY : Europe
BDP-440 VXCN5 AC 100 V to 240 V 2 B &&&&######GB GB : U.K
BDP-52FD UCXCN AC 120 V 1 A &&&&######UC UC :
NORTH AMERICA
Model No. Order No. Remarks
BDP-140/YXCN5 RRV4263
K-ZZZ OCT.

2BDP-440
12 3 4
A
B
C
D
E
F
12 3 4
1. CONTRAST OF MISCELLANEOUS PARTS
CONTRAST TABLE
BDP-140/YXCN5, BDP-440/YXCN5, BDP-440/VXCN5 and BDP-52FD/UCXCN are constructed the same except for the following:
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
56 1
4 7 3
R 5 0
1R 0
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
RN1/4PC F562 x 10
1
5621 5 26 1
Mark No. Symbol and Description BDP-140/YXCN5 BDP-440/YXCN5 BDP-440/VXCN5 BDP-52FD/UCXCN Remarks
PCB ASSEMBLIES
P37-1 MAIN BOARD ASSY 08-BDP140-MA0/Y-TL 08-BDP440-MA0/Y-TL 08-BDP440-MA0/Y-TL 08-BDP440-MA1/U-TL *1
P37-2 POWER BOARD ASSY 08-BDP140-PW0-TL 08-BDP140-PW0-TL 08-BDP140-PW0-TL 08-BDP440-PW2-TL *2
P37-3 FRONT BOARD ASSY 08-BDP140-FV0-TL 08-BDP440-FV0-TL 08-BDP440-FV0-TL 08-BDP440-FV2-TL *3
P37-4 SWITCH BOARD ASSY 08-BDP140-SW0-TL 08-BDP440-SW0-TL 08-BDP440-SW0-TL 08-BDLX55-SW0-TL *4
P37-5 AV BOARD ASSY 08-BDP130-AV0-TL Not used Not used Not used
RS-232C BOARD ASSY Not used Not used Not used 08-BDP440-RS0-TL No.26
PACKING SECTION
P35-1 Remote Control Unit
(RC-2930)
06-RC2930-A000-TL 06-RC2930-A000-TL 06-RC2930-A000-TL Not used
P35-1 Remote Control Unit
(RC-2920)
Not used Not used Not used 06-RC2920-A000-TL
P35-2 Video Audio Cable 41-UH1200-0KK8A-TL 41-UH1500-0KK8A-TL 41-UH1500-0KK8A-TL 41-UH1500-0KK8A-TL
>P35-3 AC Power Cord 51-DC0120-0CRA3-TL 51-DC0120-0CRA3-TL 51-DC0120-0CRD4-TL 51-BC0150-0LSA9-TL
P35-4 Operating Instructions
(En)
72-BDP140-EN0B1-TL 72-BDP140-EN0B1-TL 72-BDP140-EN0B1-TL Not used
P35-5 Operating Instructions
(Fr/De/It/Ni/Es)
72-BDP140-YX0B1-TL 72-BDP140-YX0B1-TL Not used Not used
P35-6 Operating Instructions
(En/Frca)
Not used Not used Not used 72-DP52FD-UC0B1-TL
P35-7 Polyethylene Bag 74-053035-50GB1-TL 74-056045-50HB1-TL 74-056045-50HB1-TL 74-056045-50HB1-TL
P35-9 Packing Case 76-104520-0ATB1-TL 76-106630-0ATB1-TL 76-106630-0ATB5-TL 76-106630-0ATB9-TL
P35-10 Right Card 76-104530-0AP-TL Not used Not used Not used
P35-11 Left Card 76-104540-0AP-TL Not used Not used Not used
P35-13 Pad 76-984950-0AP-TL Not used Not used Not used
EXTERIOR SECTION
P37-7 Top Cover 67-BD14T1-0E0B1-TL 67-BD44T1-0E0B1-TL 67-BD44T1-0E0B1-TL 67-BD44T1-0E0B1-TL
P37-8 Back Plate 67-BD14B1-0E0B1-TL 67-BD44B1-0E0B1-TL 67-BD44B1-0E0B1-TL 67-BD44B1-1E0B1-TL
P37-9 Bottom Cabinet 67-BD14R1-0E0-TL 67-BD14R1-1E0-TL 67-BD14R1-1E0-TL 67-BD14R1-1E0-TL
P37-10 Front Cabinet ASSY 08-BDP140-FA1-TL 08-BDP440-FA1-TL 08-BDP440-FA1-TL 08-BDP440-FA5-TL
P37-11 Rubber Pad 54-907220-000-TL 54-106480-000-TL 54-106480-000-TL 54-106480-000-TL
P37-12 ST Screw B 3.0 x 7 63-B30080-BF4-TL Not used Not used Not used
S/T Screw B 3x8 BF Not used 63-B30080-BF3-TL 63-B30080-BF3-TL 63-B30080-BF3-TL
P37-16 ST Screw B 3 x 6 B 64-B30060-303-TL Not used Not used Not used
Trianglem/C Screw B 3x4 Not used 64-B30040-3H8-TL 64-B30040-3H8-TL 64-B30040-3H8-TL

3
BDP-440
56 7 8
56 7 8
A
B
C
D
E
F
Notes : For PCB ASSEMBLIES, Refer to “2. SCHEMATIC DIAGRAM” and ”3 PCB CONNECTION DIAGRAM ”.
*1 MAIN BOARD ASSY has no service parts.
*2 POWER BOARD ASSY has no service parts.
*3 Although 08-BDP140-FV0-TL and 08-BDP440-FV0-TL are different in part number, they consist of the same service components.
*4 SWITCH BOARD ASSY has no service parts.
EXPLODED VIEWS
PACKING SECTION
P37-21 Cable 6pin 400mm 46-CC040T-06K-TL Not used Not used Not used
P37-21 Cable 6pin 360mm Not used 46-CC036T-06K-TL 46-CC036T-06K-TL 46-CC036T-06K-TL
P37-22 Cable 2pin 140mm 46-FH014T-02P-TL Not used Not used Not used
P37-22 Cable 2pin 100mm Not used 46-FH010T-02P-TL 46-FH010T-02P-TL Not used
P37-22 Cable 3pin 100mm Not used Not used Not used 46-FH010T-03P-TL
P37-23 Cable 9pin 140mm 46-FG022T-09S-TL Not used Not used Not used
P37-23 Cable 11pin 180mm Not used 46-FH022T-11S-TL 46-FH022T-11S-TL 46-FH022T-11S-TL
P37-25 Tray Panel 08-BDP140-DA1-TL 08-BDP440-DA1-TL 08-BDP440-DA1-TL 08-BDP440-DA2-TL
Cable 4pin 60mm Not used Not used Not used 46-FH006T-04SA-TL No.27
Mark No. Symbol and Description BDP-140/YXCN5 BDP-440/YXCN5 BDP-440/VXCN5 BDP-52FD/UCXCN Remarks

4BDP-440
12 3 4
A
B
C
D
E
F
12 3 4
EXTERIOR SECTION
BDP-52FD
FF
AF
BF
CF
EF

5
BDP-440
56 7 8
56 7 8
A
B
C
D
E
F

6BDP-440
12 3 4
A
B
C
D
E
F
12 3 4
2. SCHEMATIC DIAGRAM
2.1 MAIN BOARD ASSY (1/10) : POWER
A1/10F
AC power off RSTI VCORE 1.1V
Internal MCU Use U2
External MCU Use R7
100MA(Max)
close to DC/DC
close to LDO
close to IC
RESET
CIRCUIT
EB
2
2N3904
C
1
VCC R/R to Q3.b
5.000V 0.772V
4.532V 0.700V
3.885V 0.600V
3.237V 0.500V
3
A03407
135MA
1.57A FOR BD
146MA
FOR VFD USE
135MA FOR BD
58MA(BD)
89MA FOR BD
125MA FOR bd
EN
RESET#
OPWRSB
P
VCC
VCC_D
-24V
+12V
1.1V
VCC
VCC
VCC_D
1.1V
+12V
+12V
+12V_D
-24V_D
+12V_D
-24V
VCC 3.3V_STBY
3.3V
VCC 3.3V_STBY
RESET_ 7
POWER_K
7
PCON
7
OPWRSB
7
R302
2.7K
R302
2.7K
R304
NC/33K
R304
NC/33K
R18
3.3K
R18
3.3K
Q206
2N3904
SOT-23
Q206
2N3904
SOT-23
Q207
MOSFET_PGSD
Q207
MOSFET_PGSD
G
DS
Q209
MOSFET_PGSD
Q209
MOSFET_PGSD
G
D
S
C299
0.1uF/25V/Y5V
C299
0.1uF/25V/Y5V
R289
1K
R289
1K
R19
10K
R19
10K
C301
1uF/25V/Y5V
C301
1uF/25V/Y5V
Q150
NPN_3DG3904M
Q150
NPN_3DG3904M
R320
4.7K
R320
4.7K
R305
20K
R305
20K
R25
2.7K
R25
2.7K
R293
10K
R293
10K
R291
20K
R291
20K
-24V-24V
R23 100
C297
1uF/25V/Y5V
C297
1uF/25V/Y5V
Q5
NPN_3DG3904M
Q5
NPN_3DG3904M
R303
3.3K
R303
3.3K
R963 NC/0
Q2
NPN_3DG3904M
Q2
NPN_3DG3904M
TP1TP1
C316
0.1uF/25V/Y5V
C316
0.1uF/25V/Y5V
R15
NC/100K
R15
NC/100K
R297
NC/470
R297
NC/470
C11
2.2uF/10V/Y5V
C11
2.2uF/10V/Y5V
C318
100pF/50V/NP0
C318
100pF/50V/NP0
VCC1VCC1
R20
15K/1%
R20
15K/1%
Q1
NPN_3DG3904M
Q1
NPN_3DG3904M
C25
10uF/10V/Y5V
C25
10uF/10V/Y5V
C321
100pF/50V/NP0
C321
100pF/50V/NP0
C31
0.1uF/25V/Y5V
C31
0.1uF/25V/Y5V
R292 100K
C12
4.7uF/16V/Y5V
C12
4.7uF/16V/Y5V
+12V+12V
R300
15K/1%
R300
15K/1%
U2
G9091-330T11U
SOT-25/SMD
U2
G9091-330T11U
SOT-25/SMD
VIN
1
GND
2
EN
3NC 4
VOUT 5
C26
0.1uF/25V/Y5V
C26
0.1uF/25V/Y5V
R298
NC/470
R298
NC/470
R290
10K
R290
10K
ZD1
BZX79C27
ZD1
BZX79C27
Q6
NPN_3DG3904M
Q6
NPN_3DG3904M
VCCVCC
R962 NC/0
C313
0.1uF/25V/Y5V
C313
0.1uF/25V/Y5V
R296
20K
R296
20K
GND1GND1
Q208
2N3904
SOT-23
Q208
2N3904
SOT-23
C323
0.1uF/25V/Y5V
C323
0.1uF/25V/Y5V
R7 NC/0
XP1
6PIN/2.5mm
XP1
6PIN/2.5mm
11
22
33
44
55
66
R295 100K
C298
100pF/50V/NP0
C298
100pF/50V/NP0
R3
FB36 10/2A
R294
1K
R294
1K
GND2GND2
R301 100
CN503
E

7
BDP-440
56 7 8
56 7 8
A
B
C
D
E
F
A1/10F
310MA
2A FOR 2D BD
557MA
behind of Caps
behind of Caps
AIM 1.2V: 0.8*(7.87+15)/15=1.22V
DC Current: 4.1A
Saturation Current: 6.4A
DC resistor: 15mOHM
1.1V
POWER
AIM 1.15V: 0.8*(6.65+15)/15=1.155V
Close to DC-DC
1.2A
(pin to pin with G5627) 3.2A
(pin to pin with G5627) 3.2A
EN
OPWRSB
VCC
PCON
1.1V_FB
EN
1.1V_FB
3.3V
VCC
A3.3V
A1.2V
1.2V
1.1V
V_D
VCC
VCC
1.1V
1.5V
3.3VRESET# 6
PCON
7
OPWRSB
7
C324
0.1uF/25V/Y5V
C324
0.1uF/25V/Y5V
C32
0.1uF/25V/Y5V
C32
0.1uF/25V/Y5V
R4
15K/1%
R4
15K/1%
R306 2.2K
R16
10K
R16
10K
R280 NC/1K
R27 0
C3
0.1uF/25V/Y5V
C3
0.1uF/25V/Y5V
R21
15K/1%
R21
15K/1%
R6
1.2K/1%
R6
1.2K/1%
C8
22uF/10V/Y5V
C8
22uF/10V/Y5V
C17
NC/22uF/10V/Y5V
C17
NC/22uF/10V/Y5V
C4
0.1uF/25V/Y5V
C4
0.1uF/25V/Y5V
L1 2.2uH
U3
G5693F11U
U3
G5693F11U
VCC
1
REF 2
GND
3FB 4
EN
5
PGND 6
LX 7
VIN 8
R1 10
C10
0.1uF/25V/Y5V
C10
0.1uF/25V/Y5V
R12
13K/1%
R12
13K/1% C21
0.1uF/25V/Y5V
C21
0.1uF/25V/Y5V
C29
10uF/10V/Y5V
C29
10uF/10V/Y5V
R5
10K
R5
10K
C327
22uF/10V/Y5V
C327
22uF/10V/Y5V
C30
0.1uF/25V/Y5V
C30
0.1uF/25V/Y5V
+
100uF/10V
CE4
+
100uF/10V
CE4
R2
5.6K/1%
R2
5.6K/1%
C19
0.1uF/25V/Y5V
C19
0.1uF/25V/Y5V
+
470uF/6.3V
CE205
+
470uF/6.3V
CE205
R200
6.8K
R200
6.8K
C15 10uF/10V/Y5V
R9
560
R9
560
R41
10K
R41
10K
R13
20K
R13
20K
FB10 10/2A
C14
0.1uF/25V/Y5V
C14
0.1uF/25V/Y5V
C28
0.1uF/25V/Y5V
C28
0.1uF/25V/Y5V
C22
0.1uF/25V/Y5V
C22
0.1uF/25V/Y5V
R26
4.7K/1%
R26
4.7K/1%
U1
G5693
U1
G5693
VCC
1
REF 2
GND
3FB 4
EN
5
PGND 6
LX 7
VIN 8
TP
9
C20
22uF/10V/Y5V
C20
22uF/10V/Y5V
C18
0.1uF/25V/Y5V
C18
0.1uF/25V/Y5V
R81 0
C326
0.1uF/25V/Y5V
C326
0.1uF/25V/Y5V
L2 2.2uH
R3 100
C23
0.1uF/25V/Y5V
C23
0.1uF/25V/Y5V
C325
0.1uF/25V/Y5V
C325
0.1uF/25V/Y5V
U5
G966A-25ADJF11U
U5
G966A-25ADJF11U
POK
1
VEN
2
VIN
3
VPP
4NC 5
VO 6
ADJ 7
GND 8
R14
15K/1%
R14
15K/1%
C5
10uF/10V/Y5V
C5
10uF/10V/Y5V
MAIN BOARD ASSY (1/10)
(BDP-440 : 08-BDP440-MA0/Y-TL)
(BDP-52FD : 08-BDP440-MA1/U-TL)
A1/10F

8BDP-440
12 3 4
A
B
C
D
E
F
12 3 4
2.2 MAIN BOARD ASSY (2/10) : DDR3-1
A2/10F
5558RAEN
AVDD12_MEMPLL
A_WE#
A_RRESET#
A_CKE
A_DQS2
A_DQS1
A_DQS0
A_DQM0
A_DQM1
A_DQM2
A_DQ17
A_DQ19
A_DQ18
A_DQ16
A_DQ1
A_DQ3
A_DQ5
A_DQ2
A_DQ6
A_DQ4
A_DQ7
A_DQ9
A_DQ11
A_DQ12
A_DQ13
A_DQ14
A_DQ15
A_DQ8
A_DQ10
A_DQ0
A_DQ21
A_DQ22
A_DQ20
A_DQ23
A_DQ25
A_DQ27
A_DQ28
A_DQ29
A_DQ30
A_DQ31
A_DQ24
A_DQ26
A_DQ6
A_DQM1
A_DQ4
A_DQ11
A_DQ9
A_DQS1#
A_DQS1
A_DQ15
A_CLK0
A_CLK0#
DDR_VREF
A_DQ14
A_DQM0
A_DQ7
A_DQ5
A_DQS0#
A_DQS0
A_DQ10
A_DQ0
A_DQ1
A_DQ3
A_DQ8
A_DQ2
A_DQ13
A_RRESET#
A_DQ12
AVDD12_MEMPLL
TP_MEMPLL
TN_MEMPLL
A_DQM3
A_DQS0#
A_DQS1#
A_DQS2#
A_DQS3
A_DQS3#
A_ODT
A_RAS#
A_CAS#
A_CS#
A_CLK0#
A_CLK1
A_CLK1#
A_CLK0
A_RA11
A_RA12
A_RA13
A_RA5
A_RA4
A_RA6
A_RA7
A_RA1
A_RA8
A_RA2
A_RA9
A_RA3
A_RA0
A_RA10
A_BA0
A_BA2
A_BA1
1.2V
1.5V
1.5V
DDR_VREF
DDRIC_VREF
DDRIC_VREF
1.5V
1.5V
1.5V
1.5V
1.5V
DDR_VREF
1.5V
1.5V
R35
C65
0.1uF/16V/X7R
C65
0.1uF/16V/X7R
C43
0.1uF/16V/X7R
C43
0.1uF/16V/X7R
C35
0.1uF/25V/Y5V
C35
0.1uF/25V/Y5V
C41
0.1uF/16V/X7R
C41
0.1uF/16V/X7R
C61
0.1uF/16V/X7R
C61
0.1uF/16V/X7R
R31
C173
1000pF/50V/X7R
C173
1000pF/50V/X7R
TP11
TEST POINT SMD0.6 TP11 TEST POINT SMD0.6
C59
0.1uF/16V/X7R
C59
0.1uF/16V/X7R
C39
0.1uF/16V/X7R
C39
0.1uF/16V/X7R
C38
0.1uF/16V/X7R
C38
0.1uF/16V/X7R
C56
0.1uF/16V/X7R
C56
0.1uF/16V/X7R
C48
0.1uF/16V/X7R
C48
0.1uF/16V/X7R
U7A
MT8555_0825_A
U7A
MT8555_0825_A
DVCC18_IO_1
AA25
DVCC18_IO_1
AE10
DVCC18_IO_1
AF14
DVCC18_IO_1
AE17
DVCC18_IO_1
AF20
DVCC18_IO_1
AG26
DVCC18_IO_1
P26
DVCC18_IO_1
V26
DVCC18_IO_1
R25
AVDD12_MEMPLL
AE23
AVSS12_MEMPLL
AD23
TP_MEMPLL
AE24
TN_MEMPLL
AF24
DGND
AA26
DGND
AA12
DGND
L11
DGND
M10
DGND
K10
DGND
N11
DGND
P10
DGND
L13
DGND
R11
DGND
L15
DGND
T10
DGND
U11
DGND
M12
DGND
M13
DGND
M14
DGND
M15
DGND
M17
DGND
AA14
DGND
V10
DGND
N12
DGND
N13
DGND
N14
DGND
N15
DGND
N16
DGND
W11
DGND
P12
DGND
P13
DGND
P14
DGND
P15
DGND
P17
DGND
K12
DGND
R12
DGND
R13
DGND
R14
DGND
R15
DGND
R16
DGND
AA16
DGND
T13
DGND
T15
DGND
T17
DGND
T12
DGND
V12
DGND
U12
DGND
U14
DGND
U16
DGND
U13
DGND
W13
DGND
K14
DGND
T14
DGND
V14
DGND
U15
DGND
W15
DGND
K16
DGND
M16
DGND
P16
DGND
T16
DGND
V16
DGND
L17
DGND
N17
DGND
R17
DGND
U17
DGND
W17
DGND
AF10
DGND
K18
DGND
M18
DGND
P18
DGND
T18
DGND
V18
DGND
L19
DGND
N19
DGND
R19
DGND
U19
DGND
AE20
DGND
V25
DGND
AF17
DGND
AE14
RDQ0 AG17
RDQ1 AF18
RDQ2 AE18
RDQ3 AF19
RDQ4 AC22
RDQ5 AF23
RDQ6 AF22
RDQ7 AG22
RDQ8 AH19
RDQ9 AG19
RDQ10 AC20
RDQ11 AD20
RDQ12 AE22
RDQ13 AH22
RDQ14 AD22
RDQ15 AF21
RDQ16 AG7
RDQ17 AH7
RDQ18 AH8
RDQ19 AG8
RDQ20 AF12
RDQ21 AE12
RDQ22 AC12
RDQ23 AD12
RDQ24 AE8
RDQ25 AF8
RDQ26 AE9
RDQ27 AF9
RDQ28 AH11
RDQ29 AG11
RDQ30 AF11
RDQ31 AE11
RDQM0 AE21
RDQM1 AD21
RDQM2 AD10
RDQM3 AD9
RDQS0 AG20
RDQS0_ AH20
RDQS1 AH21
RDQS1_ AG21
RDQS2 AG9
RDQS2_ AH9
RDQS3 AH10
RDQS3_ AG10
RODT AC14
RCAS_ AD14
RRAS_ AC13
RCS_ AE15
RWE_ AE13
RCKE AG16
RRESET AC16
RBA0 AG14
RBA1 AD19
RBA2 AC15
RA0 AD13
RA1 AE19
RA2 AF16
RA3 AH14
RA4 AD18
RA5 AD15
RA6 AC17
RA7 AE16
RA8 AH16
RA9 AF15
RA10 AH17
RA11 AD17
RA12 AC18
RA13 AD16
RCLK0 AG24
RCLK0_ AH24
RCLK1 AG13
RCLK1_ AH13
RVREF_2 AA20
RVREF_1 AB12
DVCC18_IO_1
AF13
DGND
N25
DGND
AF26
DGND
R26
DGND
M11
DVCC18_IO_1
V21
DVCC18_IO_1
T21
DVCC18_IO_1
AA13
DVCC18_IO_1
AA15
DVCC18_IO_1
AA19
DVCC18_IO_1
AA11
DVCC18_IO_1
Y20
DVCC18_IO_1
AA17
DVCC18_IO_1
P21
DGND
W9
DGND
U9
DVCC18_IO_1
M21
DGND
AB11
DGND
W19
DGND
U21
DGND
N21
DGND
R21
DGND
W21
DGND
L21
DGND
N9
DGND
AA18
C42
0.1uF/16V/X7R
C42
0.1uF/16V/X7R
C37
0.1uF/16V/X7R
C37
0.1uF/16V/X7R
C58
0.1uF/16V/X7R
C58
0.1uF/16V/X7R
C55
0.1uF/16V/X7R
C55
0.1uF/16V/X7R
C68
0.1uF/25V/Y5V
C68
0.1uF/25V/Y5V
C728
100pF/50V/NP0
C728
100pF/50V/NP0
C45
0.1uF/16V/X7R
C45
0.1uF/16V/X7R
C50
0.1uF/16V/X7R
C50
0.1uF/16V/X7R
C67
0.1uF/25V/Y5V
C67
0.1uF/25V/Y5V
C172
1000pF/50V/X7R
C172
1000pF/50V/X7R
C33
NC
C33
NC
C171
100pF/50V/NP0
C171
100pF/50V/NP0
C52
0.1uF/16V/X7R
C52
0.1uF/16V/X7R
C54
0.1uF/16V/X7R
C54
0.1uF/16V/X7R
C34
0.1uF/16V/Y5V
C34
0.1uF/16V/Y5V
R400R400
C47
0.1uF/16V/X7R
C47
0.1uF/16V/X7R
C60
0.1uF/16V/X7R
C60
0.1uF/16V/X7R
TP5
TEST POINT SMD0.6 TP5 TEST POINT SMD0.6
U8
64Mx16
U8
64Mx16
VDD_0
B2
UDQS#
B7
VDDQ_
A1
DQ14
B8
UDM
D3
UDQS
C7
DQ15
A3
VDDQ_
A8
DQ9
C3
VDDQ_
C1
VDDQ_
C9
DQ8
D7
VDDQ_
D2
DQ12
A7 DQ11
C2 DQ10
C8
DQ13
A2
VDD_1
D9
LDQS#
G3
VDDQ_
E9
DQ6
G2
LDM
E7
LDQS
F3
DQ7
H7
VDDQ_
F1
DQ1
F7
VDDQ_
H2
DQ0
E3
VDDQ_
H9
DQ4
H3 DQ3
F8 DQ2
F2
DQ5
H8
VDD_5
N1
VREFD
H1
VDD_2
G7
RESET#
T2
VDD_3
K2
VDD_4
K8
ZQ
L8
VREFCA
M8
VDD_6
N9
VDD_7
R1 VDD_8
R9
C57
0.1uF/16V/X7R
C57
0.1uF/16V/X7R
C53
0.1uF/16V/X7R
C53
0.1uF/16V/X7R
C66
0.1uF/16V/X7R
C66
0.1uF/16V/X7R
C51
0.1uF/16V/X7R
C51
0.1uF/16V/X7R
C148
100pF/50V/NP0
C148
100pF/50V/NP0
C40
0.1uF/16V/X7R
C40
0.1uF/16V/X7R
R29
240
R29
240
C49
0.1uF/16V/X7R
C49
0.1uF/16V/X7R
R280R280
C46
0.1uF/16V/X7R
C46
0.1uF/16V/X7R
C44
0.1uF/16V/X7R
C44
0.1uF/16V/X7R

9
BDP-440
56 7 8
56 7 8
A
B
C
D
E
F
A2/10F
5558RAEN5558RAEN MARDRAENMARDRAEN
DDR_VREF
A_DQM3
A_DQ6
A_DQ17
A_DQM1
A_DQ4
A_DQ11
A_DQ30
A_BA2
A_BA0
A_BA1
A_DQ9
A_DQM2
A_DQ18
A_DQ31
A_DQS1#
A_DQS1
D_CLK0
A_DQ15
A_CLK0
A_CLK0#
A_DQ14
A_DQM0
A_DQ25
A_DQ29
A_DQ7
A_RA5
A_RA4
A_RA2
A_RA3
A_RA10
A_RA6
A_RA1
A_RA11
A_RA7
A_RA9
A_RA13
A_RA8
A_RA0
A_DQS2#
A_DQS2
D_CLK0
D_CLK1
A_CLK1
A_CLK1# D_CLK1#
DDR_VREF
A_DQ5
A_DQS0#
A_DQS0
D_CLK0#
D_CLK1
D_CLK1#
A_DQ10
A_DQ27
A_DQ26
A_DQ0
A_DQ1
A_CKE
A_WE#
A_RAS#
A_ODT
A_CAS#
A_CS#
A_DQ3
A_DQ8
D_CLK0#
A_DQ21
A_DQ20
A_DQ22
A_DQ23
A_DQ16
A_DQ2
A_DQ13
A_RRESET#
A_DQ19
A_DQS3#
A_DQS3
A_DQ24
A_DQ28
A_DQ12
A_WE#_2R
A_BA2_2R
A_RA0_2R
A_RA2_2R
A_RA5_2R
A_RA3_2R
A_BA0_2R
A_CS#_2R
A_CAS#_2R
A_ODT_2R
A_RAS#_2R
A_RA7_2R
A_RA9_2R
A_RRESET#_2R
A_RA13_2R
A_RA10_2R
A_CKE_2R
A_RA12_2R
A_BA1_2R
A_RA1_2R
A_RA4_2R
A_RA6_2R
A_RA11_2R
A_RA8_2R
A_WE#
A_BA2
A_RA0
A_RA2
A_WE#_2R
A_BA2_2R
A_RA0_2R
A_RA2_2R
A_RA5
A_RA3
A_BA0
A_CS#
A_RA5_2R
A_RA3_2R
A_BA0_2R
A_CS#_2R
A_CAS#
A_ODT
A_RAS#
A_CAS#_2R
A_ODT_2R
A_RAS#_2R
A_RA7
A_RA9
A_RRESET#
A_RA13
A_RA7_2R
A_RA9_2R
A_RRESET#_2R
A_RA13_2R
A_CKE
A_RA10
A_BA1
A_RA12
A_CKE_2R
A_RA10_2R
A_BA1_2R
A_RA12_2R
A_RA4
A_RA1
A_RA6
A_RA8
A_RA4_2R
A_RA1_2R
A_RA6_2R
A_RA8_2R
A_RA12
A_RA11_2R
A_RA11
A_DQS1#
A_DQS1
A_DQS0#
A_DQS0
A_DQS3#
A_DQS3
A_DQS2#
A_DQS2
1.5V
DDR_VREF
1.5V 1.5V
DR_VREF
R35 0
R30
240
R30
240
TP3 TEST POINT SMD0.6 TP3 TEST POINT SMD0.6
TP10 TEST POINT SMD0.6 TP10 TEST POINT SMD0.6
R34
100/1%
R34
100/1%
R31 0
RN1
0*4
RN1
0*4
1
2
3
4
6
5
8
7
TP8 TEST POINT SMD0.6 TP8 TEST POINT SMD0.6
TP102 TEST POINT SMD0.6 TP102 TEST POINT SMD0.6
R33
100/1%
R33
100/1%
4*04NR 4*04NR 1
2
3
4
6
5
8
7
4*02NR 4*02NR 1
2
3
4
6
5
8
7
R32 0
C64
0.1uF/25V/Y5V
C64
0.1uF/25V/Y5V
R38
100
R38
100
C36
0.1uF/25V/Y5V
C36
0.1uF/25V/Y5V
4*03NR 4*03NR 1
2
3
4
6
5
8
7
R37
100
R37
100
C68
0.1uF/25V/Y5V
C68
0.1uF/25V/Y5V
C62
0.1uF/25V/Y5V
C62
0.1uF/25V/Y5V
C63
0.1uF/25V/Y5V
C63
0.1uF/25V/Y5V
4*06NR 4*06NR 1
2
3
4
6
5
8
7
TP9 TEST POINT SMD0.6 TP9 TEST POINT SMD0.6
TP4 TEST POINT SMD0.6 TP4 TEST POINT SMD0.6
R420R420
R36 0
U8
64Mx16 DDR3-1333 SDRM
U8
64Mx16 DDR3-1333 SDRM
VDD_0
B2
NC_0 J1
VSS_0 A9
VSSQ_0 B1
UDQS#
B7
VDDQ_0
A1
DQ14
B8
VSSQ_1 B9
UDM
D3
UDQS
C7
VSSQ_2 D1
DQ15
A3
VDDQ_1
A8
DQ9
C3
VDDQ_2
C1
VDDQ_3
C9
DQ8
D7
VDDQ_4
D2
DQ12
A7
VSSQ_3 D8
DQ11
C2 DQ10
C8
VSSQ_4 E2
DQ13
A2
VDD_1
D9
NC_1 J9
VSS_1 B3
VSSQ_5 E8
LDQS#
G3
VDDQ_5
E9
DQ6
G2
VSSQ_6 F9
LDM
E7
LDQS
F3
VSSQ_7 G1
DQ7
H7
VDDQ_6
F1
DQ1
F7
VDDQ_7
H2
DQ0
E3
VDDQ_8
H9
DQ4
H3
VSSQ_8 G9
DQ3
F8 DQ2
F2
BA2 M3
DQ5
H8
VDD_5
N1
VREFDQ
H1
VSS_2 E1
VSS_5 J8
CK J7
VDD_2
G7
CKE K9
WE# L3
RAS# J3
CK# K7
ODT K1
RESET#
T2
BA0 M2
BA1 N8
CAS# K3
CS# L2
A10/AP L7
A1 P7
A2 P3
A0 N3
VDD_3
K2
VSS_3 G8
A3 N2
A5 P2
A6 R8
A4 P8
A7 R2
A9 R3
A11 R7
A8 T8
VSS_4 J2
VDD_4
K8
A12/BC# N7
NC_3 L9
ZQ
L8
NC_2 L1
VREFCA
M8
NC_4 M7
A13 T3
NC_6 T7
VSS_6 M1
VSS_7 M9
VSS_8 P1
VSS_9 P9
VSS_10 T1
VSS_11 T9
VDD_6
N9
VDD_7
R1 VDD_8
R9
TP7 TEST POINT SMD0.6 TP7 TEST POINT SMD0.6
R29
240
R29
240
4*05NR 4*05NR 1
2
3
4
6
5
8
7
TP6 TEST POINT SMD0.6 TP6 TEST POINT SMD0.6
U9
64Mx16 DDR3-1333 SDRM
U9
64Mx16 DDR3-1333 SDRM
VDD_0
B2
NC_0 J1
VSS_0 A9
VSSQ_0 B1
UDQS#
B7
VDDQ_0
A1
DQ14
B8
VSSQ_1 B9
UDM
D3
UDQS
C7
VSSQ_2 D1
DQ15
A3
VDDQ_1
A8
DQ9
C3
VDDQ_2
C1
VDDQ_3
C9
DQ8
D7
VDDQ_4
D2
DQ12
A7
VSSQ_3 D8
DQ11
C2 DQ10
C8
VSSQ_4 E2
DQ13
A2
VDD_1
D9
NC_1 J9
VSS_1 B3
VSSQ_5 E8
LDQS#
G3
VDDQ_5
E9
DQ6
G2
VSSQ_6 F9
LDM
E7
LDQS
F3
VSSQ_7 G1
DQ7
H7
VDDQ_6
F1
DQ1
F7
VDDQ_7
H2
DQ0
E3
VDDQ_8
H9
DQ4
H3
VSSQ_8 G9
DQ3
F8 DQ2
F2
BA2 M3
DQ5
H8
VDD_5
N1
VREFDQ
H1
VSS_2 E1
VSS_5 J8
CK J7
VDD_2
G7
CKE K9
WE# L3
RAS# J3
CK# K7
ODT K1
RESET#
T2
BA0 M2
BA1 N8
CAS# K3
CS# L2
A10/AP L7
A1 P7
A2 P3
A0 N3
VDD_3
K2
VSS_3 G8
A3 N2
A5 P2
A6 R8
A4 P8
A7 R2
A9 R3
A11 R7
A8 T8
VSS_4 J2
VDD_4
K8
A12/BC# N7
NC_3 L9
ZQ
L8
NC_2 L1
VREFCA
M8
NC_4 M7
A13 T3
NC_6 T7
VSS_6 M1
VSS_7 M9
VSS_8 P1
VSS_9 P9
VSS_10 T1
VSS_11 T9
VDD_6
N9
VDD_7
R1 VDD_8
R9
MAIN BOARD ASSY (2/10)
(BDP-440 : 08-BDP440-MA0/Y-TL)
(BDP-52FD : 08-BDP440-MA1/U-TL)
A2/10F

10 BDP-440
12 3 4
A
B
C
D
E
F
12 3 4
2.3 MAIN BOARD ASSY (3/10) : DDR3-2
A3/10F
B_DQ10
B_DQ6
B_DQ11
B_DQ15
B_DQ2
B_DQ12
B_DQ5
B_DQ3
B_DQ1
B_DQ8
B_DQ0
B_DQ4
B_DQ9
B_DQ7
B_DQ13
B_DQ14
B_DQ26
B_DQ22
B_DQ27
B_DQ31
B_DQ18
B_DQ28
B_DQ21
B_DQ19
B_DQ17
B_DQ24
B_DQ16
B_DQ20
B_DQ25
B_DQ23
B_DQ29
B_DQ30
B_DQM1
B_DQM0
B_DQM2
B_DQM3
B_DQS0
B_DQS0#
B_DQS1#
B_DQS1
B_DQS2#
B_DQS2
B_DQS3#
B_DQS3
B_RRESET#
B_CAS#
B_RAS#
B_CS#
B_WE#
B_CKE
B_ODT
B_BA1
B_BA0
B_BA2
B_RA1
B_RA0
B_RA13
B_RA3
B_RA7
B_RA6
B_RA4
B_RA2
B_RA5
B_RA8
B_RA9
B_RA11
B_RA10
B_RA12
B_CLK0#
B_CLK0
B_CLK1
B_CLK1#
B_D
B_D
B_D
B_D
B_D
B_D
B_D
B_D
B_D
B_D
B_D
B_D
B_R
B_D
B_D
B_D
B_D
B_D
B_D
B_D
B_D
B_D
B_D
DDRIC_VREF
DDR_VREF
1.5V
1.5V
1.5V
1.5V
1.1V
1.1V
1.1V
1.1V
1.
DDRIC_VREF
DDR_VREF
C118
0.1uF/16V/X7R
C118
0.1uF/16V/X7R
C101
0.1uF/16V/X7R
C101
0.1uF/16V/X7R
C6
100pF/50V/NP0
C6
100pF/50V/NP0
C95
0.1uF/16V/X7R
C95
0.1uF/16V/X7R
C113
0.1uF/16V/X7R
C113
0.1uF/16V/X7R
C82
0.1uF/16V/X7R
C82
0.1uF/16V/X7R
C77
0.1uF/16V/X7R
C77
0.1uF/16V/X7R
C123
0.1uF/16V/X7R
C123
0.1uF/16V/X7R
C16
1000pF/50V/X7R
C16
1000pF/50V/X7R
C84
1000pF/50V/X7R
C84
1000pF/50V/X7R
C73
0.1uF/16V/X7R
C73
0.1uF/16V/X7R
C121
0.1uF/16V/X7R
C121
0.1uF/16V/X7R
C120
0.1uF/16V/X7R
C120
0.1uF/16V/X7R
+
220uF/10V
CE10
+
220uF/10V
CE10
C122
0.1uF/16V/X7R
C122
0.1uF/16V/X7R
C96
0.1uF/16V/X7R
C96
0.1uF/16V/X7R
C102
0.1uF/16V/X7R
C102
0.1uF/16V/X7R
C70
0.1uF/16V/X7R
C70
0.1uF/16V/X7R
C76
0.1uF/16V/X7R
C76
0.1uF/16V/X7R
C78
0.1uF/16V/X7R
C78
0.1uF/16V/X7R
C117
0.1uF/16V/X7R
C117
0.1uF/16V/X7R
C111
0.1uF/16V/X7R
C111
0.1uF/16V/X7R
C83
0.1uF/16V/X7R
C83
0.1uF/16V/X7R
C104
0.1uF/25V/Y5V
C104
0.1uF/25V/Y5V
C2
1000pF/50V/X7R
C2
1000pF/50V/X7R
C9
1000pF/50V/X7R
C9
1000pF/50V/X7R
C85
0.1uF/16V/X7R
C85
0.1uF/16V/X7R
U7B
MT8555_0825_A
U7B
MT8555_0825_A
DVCC10_K
L10
DVCC10_K
W18
DVCC10_K
M9
DVCC10_K
W10
DVCC10_K
P11
DVCC10_K
V9
DVCC10_K
M19
DVCC10_K
N10
DVCC10_K
T11
DVCC10_K
P19
DVCC10_K
R10
DVCC10_K
V11
DVCC10_K
K11
DVCC10_K
L12
DVCC10_K
T19
DVCC10_K
K13
DVCC10_K
V13
DVCC10_K
K15
DVCC10_K
L14
DVCC10_K
U10
DVCC10_K
K17
DVCC10_K
V15
DVCC10_K
L16
DVCC10_K
K19
DVCC10_K
V17
DVCC10_K
V19
DVCC10_K
L18
DVCC10_K
N18
DVCC10_K
R18
DVCC10_K
U18
RDQ0_B T25
RDQ1_B T26
RDQ2_B U26
RDQ3_B U25
RDQ4_B M26
RDQ5_B M25
RDQ6_B N28
RDQ7_B N27
RDQ8_B P23
RDQ9_B T28
RDQ10_B T27
RDQ11_B T23
RDQ12_B N26
RDQ13_B P24
RDQ14_B N23
RDQ15_B N24
RDQ16_B AF25
RDQ17_B AG25
RDQ18_B AH25
RDQ19_B AH26
RDQ20_B AA24
RDQ21_B AB24
RDQ22_B AA23
RDQ23_B AB23
RDQ24_B AD25
RDQ25_B AE25
RDQ26_B AH27
RDQ27_B AH28
RDQ28_B AC25
RDQ29_B AD24
RDQ30_B AC24
RDQ31_B AC23
RDQM0_B P25
RDQM1_B R24
RDQM2_B AD26
RDQM3_B AE26
RDQS0_B R27
RDQS0__B R28
RDQS1_B P28
RDQS1__B P27
RDQS2_B AG27
RDQS2__B AG28
RDQS3_B AF28
RDQS3__B AF27
RODT_B AD27
RCAS__B AC26
RRAS__B AD28
RCS__B AB25
RWE__B AE28
RCKE_B V27
RRESET_B Y26
RBA0_B AB26
RBA1_B T24
RBA2_B W25
RA0_B AE27
RA1_B U24
RA2_B W28
RA3_B AA27
RA4_B V24
RA5_B AA28
RA6_B W24
RA7_B W27
RA8_B Y24
RA9_B W26
RA10_B V28
RA11_B V23
RA12_B U23
RA13_B Y25
RCLK0_B L27
RCLK0__B L28
RCLK1_B AB27
RCLK1__B AB28
RVREF_4 R23
RVREF_3 AA21
DVCC10_K
W12
DVCC10_K
W14
DVCC10_K
W16
C109
0.1uF/16V/X7R
C109
0.1uF/16V/X7R
C72
0.1uF/16V/X7R
C72
0.1uF/16V/X7R
C110
0.1uF/16V/X7R
C110
0.1uF/16V/X7R
C1
100pF/50V/NP0
C1
100pF/50V/NP0
C81
0.1uF/16V/X7R
C81
0.1uF/16V/X7R
C107
0.1uF/16V/X7R
C107
0.1uF/16V/X7R
C13
100pF/50V/NP0
C13
100pF/50V/NP0
C212
0.1uF/16V/X7R
C212
0.1uF/16V/X7R
C176
100pF/50V/NP0
C176
100pF/50V/NP0
C11
0.1u
C11
0.1u
C79
0.1uF/25V/Y5V
C79
0.1uF/25V/Y5V
C74
0.1uF/16V/X7R
C74
0.1uF/16V/X7R
C105
0.1uF/16V/X7R
C105
0.1uF/16V/X7R
C69
0.1uF/16V/X7R
C69
0.1uF/16V/X7R
C119
0.1uF/16V/X7R
C119
0.1uF/16V/X7R
C27
1000pF/50V/X7R
C27
1000pF/50V/X7R
C136
1000pF/50V/X7R
C136
1000pF/50V/X7R
C124
0.1uF/16V/X7R
C124
0.1uF/16V/X7R
C108
0.1uF/16V/X7R
C108
0.1uF/16V/X7R
C75
0.1uF/16V/X7R
C75
0.1uF/16V/X7R
C112
0.1uF/16V/X7R
C112
0.1uF/16V/X7R
C103
0.1uF/25V/Y5V
C103
0.1uF/25V/Y5V
C145
1000pF/50V/X7R
C145
1000pF/50V/X7R
C106
0.1uF/16V/X7R
C106
0.1uF/16V/X7R
R43
240
R43
240

11
BDP-440
56 7 8
56 7 8
A
B
C
D
E
F
A3/10F
MARDRAEN5558RAENMARDRAEN5558RAEN
B_DQ24
B_DQ15
B_DQS2#
B_DQS2
B_DQ10
B_DQ6
B_DQ26
B_DQ31
B_DQ16
B_DQ18
B_DQ23
B_DQ17
B_DQ25
B_DQ21
B_DQ19
B_DQ13
B_DQ14
B_DQ2
B_DQ3
B_DQ4
B_DQ5
DDR_VREF
B_DQ9
B_DQ0
B_DQ27
B_DQ29
B_CLK0 D_CLK2
B_CLK0# D_CLK2#
B_DQ12
B_CLK1 D_CLK3
B_CLK1# D_CLK3#
B_RRESET#
B_DQS1#
B_DQS1
B_DQS0
B_DQS0#
B_DQM1
B_DQM0
B_BA0
B_BA2
B_BA1
B_RA0
D_CLK2#
D_CLK2
B_CAS#
B_CS#
B_ODT
B_RAS#
B_WE#
B_CKE
B_DQM3
B_DQ22
B_DQ1
B_DQ28
B_DQ11
D_CLK3#
D_CLK3
B_DQS3
B_DQS3#
B_DQM2
B_DQ30
B_DQ20
B_DQ8
B_DQ7
B_RA6
B_RA8
B_RA4
B_RA1
B_BA2_2R
B_RA6_2R
B_RA8_2R
B_WE#_2R
B_RA12_2R
B_BA1_2R
B_RA10_2R
B_RA1_2R
B_RA4_2R
B_RA11_2R
B_CKE_2R
B_RA6_2R
B_CS#_2R
B_CAS#_2R
B_ODT_2R
B_RAS#_2R
B_RA13_2R
B_RA5_2R
B_BA0_2R
B_RA2_2R
B_RA3_2R
B_RA7_2R
B_RA9_2R
B_RRESET#_2R
B_WE#_2R
B_BA2_2R
B_RA0_2R
B_RA8_2R
B_CKE_2R
B_RA10_2R
B_BA1_2R
B_RA12_2R
B_CKE
B_RA10
B_BA1
B_RA12
B_RA4_2R
B_RA1_2R
B_CS#_2R
B_CAS#_2R
B_ODT_2R
B_RAS#_2R
B_CS#
B_CAS#
B_ODT
B_RAS#
B_RA13_2R
B_RA5_2R
B_RA3_2R
B_BA0_2R
B_RA13
B_RA5
B_RA3
B_BA0
B_RRESET#_2R
B_RA9_2R
B_RA7_2R
B_RA2_2R
B_RRESET#
B_RA9
B_RA7
B_RA2
B_RA0_2R
B_RA0
B_BA2
B_WE#
B_RA1
B_RA2
B_RA3
B_RA4
B_RA5
B_RA10
B_RA6
B_RA7
B_RA8
B_RA9
B_RA11
B_RA12
B_RA13
B_RA11 B_RA11_2R
B_DQS1#
B_DQS1
B_DQS0
B_DQS0#
B_DQS3
B_DQS3#
B_DQS2#
B_DQS2
DDR_VREF
1.5V1.5V
DRIC_VREF
R_VREF
R44
240
R44
240
4*07
N
R 4*07
N
R1
2
3
4
6
5
8
7
TP15 TEST POINT SMD0.6 TP15 TEST POINT SMD0.6
R49 0
R45 0
C126
0.1uF/16V/X7R
C126
0.1uF/16V/X7R
4*0202NR 4*0202NR 1
2
3
4
6
5
8
7
C113
0.1uF/16V/X7R
C113
0.1uF/16V/X7R
TP16 TEST POINT SMD0.6 TP16 TEST POINT SMD0.6
4*011NR 4*011NR 1
2
3
4
6
5
8
7
U10
128Mx16 DDR3-1333 SDRM
U10
128Mx16 DDR3-1333 SDRM
VDD_0
B2
NC_0 J1
VSS_0 A9
VSSQ_0 B1
UDQS#
B7
VDDQ_0
A1
DQ14
B8
VSSQ_1 B9
UDM
D3
UDQS
C7
VSSQ_2 D1
DQ15
A3
VDDQ_1
A8
DQ9
C3
VDDQ_2
C1
VDDQ_3
C9
DQ8
D7
VDDQ_4
D2
DQ12
A7
VSSQ_3 D8
DQ11
C2 DQ10
C8
VSSQ_4 E2
DQ13
A2
VDD_1
D9
NC_1 J9
VSS_1 B3
VSSQ_5 E8
LDQS#
G3
VDDQ_5
E9
DQ6
G2
VSSQ_6 F9
LDM
E7
LDQS
F3
VSSQ_7 G1
DQ7
H7
VDDQ_6
F1
DQ1
F7
VDDQ_7
H2
DQ0
E3
VDDQ_8
H9
DQ4
H3
VSSQ_8 G9
DQ3
F8 DQ2
F2
BA2 M3
DQ5
H8
VDD_5
N1
VREFDQ
H1
VSS_2 E1
VSS_5 J8
CK J7
VDD_2
G7
CKE K9
WE# L3
RAS# J3
CK# K7
ODT K1
RESET#
T2
BA0 M2
BA1 N8
CAS# K3
CS# L2
A10/AP L7
A1 P7
A2 P3
A0 N3
VDD_3
K2
VSS_3 G8
A3 N2
A5 P2
A6 R8
A4 P8
A7 R2
A9 R3
A11 R7
A8 T8
VSS_4 J2
VDD_4
K8
A12/BC# N7
NC_3 L9
ZQ
L8
NC_2 L1
VREFCA
M8
NC_4 M7
A13 T3
NC_6 T7
VSS_6 M1
VSS_7 M9
VSS_8 P1
VSS_9 P9
VSS_10 T1
VSS_11 T9
VDD_6
N9
VDD_7
R1 VDD_8
R9
23
uF/16V/X7R
23
uF/16V/X7R
TP17 TEST POINT SMD0.6 TP17 TEST POINT SMD0.6
R47
100/1%
R47
100/1%
6
uF/16V/X7R
6
uF/16V/X7R
TP18 TEST POINT SMD0.6 TP18 TEST POINT SMD0.6
C116
0.1uF/16V/X7R
C116
0.1uF/16V/X7R
TP19 TEST POINT SMD0.6 TP19 TEST POINT SMD0.6
C128
100pF/50V/NP0
C128
100pF/50V/NP0
U11
128Mx16 DDR3-1333 SDRM
U11
128Mx16 DDR3-1333 SDRM
VDD_0
B2
NC_0 J1
VSS_0 A9
VSSQ_0 B1
UDQS#
B7
VDDQ_0
A1
DQ14
B8
VSSQ_1 B9
UDM
D3
UDQS
C7
VSSQ_2 D1
DQ15
A3
VDDQ_1
A8
DQ9
C3
VDDQ_2
C1
VDDQ_3
C9
DQ8
D7
VDDQ_4
D2
DQ12
A7
VSSQ_3 D8
DQ11
C2 DQ10
C8
VSSQ_4 E2
DQ13
A2
VDD_1
D9
NC_1 J9
VSS_1 B3
VSSQ_5 E8
LDQS#
G3
VDDQ_5
E9
DQ6
G2
VSSQ_6 F9
LDM
E7
LDQS
F3
VSSQ_7 G1
DQ7
H7
VDDQ_6
F1
DQ1
F7
VDDQ_7
H2
DQ0
E3
VDDQ_8
H9
DQ4
H3
VSSQ_8 G9
DQ3
F8 DQ2
F2
BA2 M3
DQ5
H8
VDD_5
N1
VREFDQ
H1
VSS_2 E1
VSS_5 J8
CK J7
VDD_2
G7
CKE K9
WE# L3
RAS# J3
CK# K7
ODT K1
RESET#
T2
BA0 M2
BA1 N8
CAS# K3
CS# L2
A10/AP L7
A1 P7
A2 P3
A0 N3
VDD_3
K2
VSS_3 G8
A3 N2
A5 P2
A6 R8
A4 P8
A7 R2
A9 R3
A11 R7
A8 T8
VSS_4 J2
VDD_4
K8
A12/BC# N7
NC_3 L9
ZQ
L8
NC_2 L1
VREFCA
M8
NC_4 M7
A13 T3
NC_6 T7
VSS_6 M1
VSS_7 M9
VSS_8 P1
VSS_9 P9
VSS_10 T1
VSS_11 T9
VDD_6
N9
VDD_7
R1 VDD_8
R9
R48
100/1%
R48
100/1%
TP201 TEST POINT SMD0.6 TP201 TEST POINT SMD0.6
R46 0
C71
100pF/50V/NP0
C71
100pF/50V/NP0
4*021NR 4*021NR 1
2
3
4
6
5
8
7
4*08NR 4*08NR 1
2
3
4
6
5
8
7
C80
0.1uF/25V/Y5V
C80
0.1uF/25V/Y5V
R50 0
C125
0.1uF/16V/X7R
C125
0.1uF/16V/X7R
C114
0.1uF/16V/X7R
C114
0.1uF/16V/X7R
C79
0.1uF/25V/Y5V
C79
0.1uF/25V/Y5V
C24
100pF/50V/NP0
C24
100pF/50V/NP0
R510R510
4*0
0
1N
R4*0 0
1N
R1
2
3
4
6
5
8
7
C124
0.1uF/16V/X7R
C124
0.1uF/16V/X7R
C115
0.1uF/16V/X7R
C115
0.1uF/16V/X7R
TP13 TEST POINT SMD0.6 TP13 TEST POINT SMD0.6
TP14 TEST POINT SMD0.6 TP14 TEST POINT SMD0.6
R43
240
R43
240
MAIN BOARD ASSY (3/10)
(BDP-440 : 08-BDP440-MA0/Y-TL)
(BDP-52FD : 08-BDP440-MA1/U-TL)
A3/10F

12 BDP-440
12 3 4
A
B
C
D
E
F
12 3 4
2.4 MAIN BOARD ASSY (4/10) : HDMI
A4/10F
For PLL testing
3.3V Analog Power
PLL
Reserved hardware trap
VCXO Circuit
AVDD12_27MPLL
AVDD33_VDAC_R
AVDD33_VDAC_X
AVDD33_VDAC_BG
AVDD33_XTAL
AVDD12_DMPLL
AVDD12_APLL
AVDD12_27MPLL
AOSDATA3
AOSDATA1
AOMCLK
AOSDATA0
AOBCK
AOSDATA2
AOLRCK
AVDD12_DMPLL
AVDD33_XTAL
AVDD12_APLL
FS
CVBS
AMUTE
AVDD33_HDMI_TX
EXT_RES
HDMISCK
HDMISD
CEC_M
HDPLG
AVDD12_HDMI_TX
TX0+
TX1+
TX0-
TX1-
TX2+
TX2-
TXC-
TXC+
NS_XTALO
AOSDATA2
AOSDATA1
AOSDATA0
AOLRCK
NS_XTALI
AVDD33_VDAC_R
AVDD33_VDAC_X
AVDD33_VDAC_BG
VCXO_PWM
VCXO_PWM
VCXO_1.65V
VCXO_1.65V_CTL
3.3V
3.3V
3.3V
3.3V_STBY
1.2V
1.2V
1.2V
3.3V_STBY
3.3V_STBY
3.3V_STBY
AOM
AOB
AOL
AOS
AOSDATA
AOSDATA
AOSDATA
VCXO_1.65V_CTL
7
R7910K R7910K
Q26
PNP_3CG3906M
Q26
PNP_3CG3906M
R357 10K
R60
10/NC
R60
10/NC
C127
0.1uF/16V/X7R
C127
0.1uF/16V/X7R
R358
20K/1%
R358
20K/1%
C140 NC
U7C
MT8555_0825_A
U7C
MT8555_0825_A
AVDD33_VDAC_R
F18
AVSS33_VDAC_R
G17
AVDD33_VDAC_X
E19
AVSS33_VDAC_X
F19
AVDD33_VDAC_BG
D19
AVSS33_VDAC_BG
E18
AVDD33_XTAL
C15
AVSS33_XTAL
D15
AVDD12_DMPLL
F15
AVSS12_DMPLL
F14
AVDD12_APLL
G15
AVSS12_APLL
G14
AVDD12_27MPLL
E15
AVSS12_27MPLL
E14
TP_PLLG
C14
TN_PLLG
D14
NS_XTALI
A13
NS_XTALO
B13
AOMCLK C12
AOBCK A12
AOLRCK B12
AOSDATA0 C11
AOSDATA1 D11
AOSDATA2 D12
AOSDATA3 E10
AOSDATA4 F10
SPDIF E13
MCIN E12
AMUTE D10
VDACX_OUT C19
VDACR_OUT C18
VDACG_OUT A19
VDACB_OUT B19
FS D18
AVDD12_HDMI_TX E16
AVSS12_HDMI_TX G16
AVDD12_HDMI_TX D16
AVSS12_HDMI_TX F16
AVDD33_HDMI_TX C17
AVSS33_HDMI_TX E17
AVDD33_HDMI_TX D17
AVSS33_HDMI_TX F17
CH0_M A16
CH0_P B16
CH1_M A15
CH1_P B15
CH2_M A14
CH2_P B14
CLK_M A17
CLK_P B17
HTPLG D25
CEC C24
HDMISD D24
HDMISCK C25
EXT_CAP A18
EXT_RES B18
SPBCK G11
SPDATA F13
SPLRCK F12
SPMCLK F11
R55 560/1%
R62 NC
C130
0.1uF/16V/X7R
C130
0.1uF/16V/X7R
C129
0.1uF/16V/X7R
C129
0.1uF/16V/X7R
FB4 1000/200mA
Y4
VCXO 27M
Y4
VCXO 27M
Vc
1VDD
4
C332
2.2uF
C332
2.2uF
C328
33pF/50V/NP0
C328
33pF/50V/NP0
R64
2.49K/1%
R64
2.49K/1%
C330
2.2uF
C330
2.2uF
C329
1000pF/50V/NP0
C329
1000pF/50V/NP0
R364
20K/1%
R364
20K/1%
C141
0.1uF/16V/X7R
C141
0.1uF/16V/X7R
R360
10K
R360
10K
C142
0.1uF/16V/X7R
C142
0.1uF/16V/X7R
R7810K R7810K
C139
0.1uF/16V/X7R
C139
0.1uF/16V/X7R
R8110K R8110K
C138
NC
C138
NC
R361
100K
R361
100K
R8010K R8010K
R363
20K/1%
R363
20K/1%
C135
NC
C135
NC
C131
NC
C131
NC
C133
0.1uF/16V/X7R
C133
0.1uF/16V/X7R
C134
0.1uF/16V/X7R
C134
0.1uF/16V/X7R
+
220uF/10V
CE7
+
220uF/10V
CE7
C132
1000pF/50V/X7R
C132
1000pF/50V/X7R
C143
0.1uF/16V/X7R
C143
0.1uF/16V/X7R
R359
20K/1%
R359
20K/1%
C331
1000pF/50V/X7R
C331
1000pF/50V/X7R
R362 1K Q212
NPN_3DG3904M
Q212
NPN_3DG3904M

13
BDP-440
56 7 8
56 7 8
A
B
C
D
E
F
A4/10F
100 ohm - Impedance
No Through Hole !
Differential Signal !
HDMI Port
HDMI TX
350mA
HDMI
DDC
CEC
Place TOP layer
38MA
O Circuit
HDMI-CECT
AOSDATA3
AOSDATA1
AOMCLK
AOSDATA0
AOBCK
AOSDATA2
AOLRCK
FS
CVBS
AMUTE
DD33_HDMI_TX
T_RES
MISCK
MISD
C_M
PLG
AVDD12_HDMI_TX
0+
1+
0-
1-
2+
2-
C-
C+
HDMI_VCC
CEC HDMI-CECT
SPDIF
HDMISD
HDMISCK
HDMI_SDA
HDMI_SCL
F_TX2-
F_TX1+
F_TX1-
F_TXC+
F_TXC-
F_TX0-
F_TX0+
HDMI_SCL
HDMI_SDA
CEC_M
HDPLG
F_TX2+
TX2+
TX2-
TX1+
TX1-
TXC-
TXC+
TX0-
TX0+
HDMI_VCC
NS_XTALI
VCXO_PWM
1.2V
3.3V
VCC
VCC
VCC
3.3V_STBY
HDMI_VCC
CVBS 8
AMUTE 8
SPDIF 8
AOMCLK 8
AOBCK 8
AOLRCK 8
AOSDATA0
CEC 7
AOSDATA1
AOSDATA2
AOSDATA3 8
F1
PTC/9V/0.2A/SMD
F1
PTC/9V/0.2A/SMD
ESD307
LVSL10180Z020/18V/2pF
ESD307
LVSL10180Z020/18V/2pF
2 1
R6633R6633
R7433R7433
C7
15pF/50V/NP0
C7
15pF/50V/NP0
D303
LL4148
D303
LL4148
C312
10uF/10V/Y5V
C312
10uF/10V/Y5V
C140 NC
C137
100pF/50V/NP0
C137
100pF/50V/NP0
R55 560/1%
R62 NC
R61
27K
R61
27K
C130
0.1uF/16V/X7R
C130
0.1uF/16V/X7R
R312
1.8K
R312
1.8K
C333
12pF/50V/NP0/NC
C333
12pF/50V/NP0/NC
ESD302
LVSL10180Z020/18V/2pF
ESD302
LVSL10180Z020/18V/2pF
2 1
Y4
VCXO 27M
Y4
VCXO 27M
Vc
1GND 2
OUT 3
VDD
4
C332
2.2uF
C332
2.2uF
C328
33pF/50V/NP0
C328
33pF/50V/NP0
ESD301
LVSL10180Z020/18V/2pF
ESD301
LVSL10180Z020/18V/2pF
2 1
R64
2.49K/1%
R64
2.49K/1%
R323 0
J1
HDMI JACK
HDMI JACK
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
2221
20 23
R315 22
F/50V/NP0F/50V/NP0
TVS Arrays
D306
PESD_TPD4S010B/NC
TVS Arrays
D306
PESD_TPD4S010B/NC
1
1
2
2
GND
3
4
4
5
566
77
GND 8
99
10 10
R6733R6733
TVS Arrays
D305
PESD_TPD4S010B/NC
TVS Arrays
D305
PESD_TPD4S010B/NC
1
1
2
2
GND
3
4
4
5
566
77
GND 8
99
10 10
C144
1000pF/50V/X7R
C144
1000pF/50V/X7R
ESD304
LVSL10180Z020/18V/2pF
ESD304
LVSL10180Z020/18V/2pF
21
C135
NC
C135
NC
C131
NC
C131
NC
C134
0.1uF/16V/X7R
C134
0.1uF/16V/X7R
C132
1000pF/50V/X7R
C132
1000pF/50V/X7R
R313
1.8K
R313
1.8K
R63 33
MAIN BOARD ASSY (4/10)
(BDP-440 : 08-BDP440-MA0/Y-TL)
(BDP-52FD : 08-BDP440-MA1/U-TL)
A4/10F
HDMI
J1

14 BDP-440
12 3 4
A
B
C
D
E
F
12 3 4
2.5 MAIN BOARD ASSY (5/10) : FLASH
A5/10F
PCB TOP U
ETHERNET PHY
PCB BTMP
TXVN_0
TXVP_0
ET_REXT
TXVN_1
TXVP_1
AVDD33_LD
AVDD33_REC
AVDD12_COM
USB_1P_VRT
USB_2P_VRT
USBP0
USBP1
USBM1
USBP2
USBM0
USBM2
AVDD12_USB_2P_1A
AVDD12_USB_1P_1
AVDD33_SATA
SREXT
AVDD33_USB_1P_1
AVDD33_USB_2P_2
SFDO
SFCK
SFCS
NFD6
NFCEN2
NFRBN
NFD7
NFD1
NFALE
NFD4
NFCEN
NFD3
NFD0
NFREN
NFWEN
GPIO4
GPIO3
GPIO1
GPIO2
GPIO0
SDA
SCL
TDO
TMS
TRST_
TCK
TDI
EFPWRQ
AVDD12_REC
TDO
TRST_
TDI
TCK
TMS
NFD5
NFCLE
NFD2
SFDI
NFRBN2
AVDD12_SATA1
USB
USB
USB
USB
USB
USB
USB
USB
USB
AVSS12_SATA1
TXVP_0
TXVN_1
TD-
TD+
RD+
RD-
TXVP_1
TXVN_0
NFRBN
NFCLE
NFCEN
NFWEN
NFALENFALE_R
NFRENNFREN_
AVDD33_COM
3.3V
3.3V
1.2V
1.2V
3.3V
1.2V
3.3V
3.3V
LAN_GND
3.3V
3.3V
3.3V
3.3V
1.2V
SCL 7
SDA 7
C98
0.1uF/16V/X7R
C98
0.1uF/16V/X7R
C97
0.1uF/16V/X7R
C97
0.1uF/16V/X7R
C157
0.1uF/25V/Y5V
C157
0.1uF/25V/Y5V
C91
0.1uF/16V/X7R
C91
0.1uF/16V/X7R
R402 0
C158
0.1uF/16V/X7R
C158
0.1uF/16V/X7R
C86
0.1uF/16V/X7R
C86
0.1uF/16V/X7R
C156
0.1uF/16V/X7R
C156
0.1uF/16V/X7R
C146
0.1uF/16V/X7R
C146
0.1uF/16V/X7R
C179
0.1uF/25V/Y5V
C179
0.1uF/25V/Y5V
R1150 R1150
C149
4.7uF/10V/Y5V
C149
4.7uF/10V/Y5V
R98 0
C164
0.1uF/16V/X7R
C164
0.1uF/16V/X7R
C87
0.1uF/16V/X
C87
0.1uF/16V/X
R100 0
C162
0.1uF/16V/X7R
C162
0.1uF/16V/X7R
R103 5.1K/1%
R133
75/1%
R133
75/1%
C550NC/100pF/2000VC550NC/100pF/2000V
C935
0.1uF/25V/Y5V
C935
0.1uF/25V/Y5V
R583 75/1% R583 75/1%
R9710K R9710K
C168
0.1uF/16V/X7R
C168
0.1uF/16V/X7R
C155
4.7uF/10V/Y5V
C155
4.7uF/10V/Y5V
C161
4.7uF/10V/Y5V
C161
4.7uF/10V/Y5V
C160
0.1uF/16V/X7R
C160
0.1uF/16V/X7R
C180
0.1uF/25V/Y5V
C180
0.1uF/25V/Y5V
C147
4.7uF/10V/Y5V
C147
4.7uF/10V/Y5V
C163
4.7uF/10V/Y5V
C163
4.7uF/10V/Y5V
C153
4.7uF/10V/Y5V
C153
4.7uF/10V/Y5V
C154
0.1uF/16V/X7R
C154
0.1uF/16V/X7R
C92
0.1uF/16V/X
C92
0.1uF/16V/X
R125
24K/1%
R125
24K/1%
R407 0
C159
4.7uF/10V/Y5V
C159
4.7uF/10V/Y5V
U7E
MT8555_0825_A
U7E
MT8555_0825_A
DVCC33_IO_5
J13
DVCC33_IO_2
Y8
DVCC33_IO_2
AA8
SFCS
AH5
SFCK
AF5
SFDI
AG5
SFDO
AH4
NFALE
AF4
NFCEN
AH2
NFCLE
AG3
NFRBN
AE3
NFREN
AD4
NFWEN
AG4
NFCEN2
AD5
NFRBN2
AE4
NFD0
AG2
NFD1
AH1
NFD2
AF3
NFD3
AG1
NFD4
AF2
NFD5
AF1
NFD6
AE2
NFD7
AE1
GPIO0
F9
GPIO1
E9
GPIO2
G9
GPIO3
D9
GPIO4
AD6
GPIO5
AE6
GPIO6
AE5
GPIO7
AC7
SCL
B10
SDA
C10
TDO
AF6
TRST_
AF7
TDI
AD8
TMS
AE7
TCK
AD7
EFPWRQ
AC9
AVDD33_USB_1P_1 AA3
AVDD33_USB_2P_2 AA4
AVSS33_USB_1P_1 AA6
AVSS33_USB_2P_2 AA5
AVDD12_USB_1P_1 AB3
AVDD12_USB_2P_1A AC4
AVSS12_USB_1P_1 AB6
AVSS12_USB_2P_1A AB5
USB_1P_DP AB2
USB_1P_DM AB1
USB_2P_DP1 AC2
USB_2P_DM1 AC1
USB_2P_DP0 AD2
USB_2P_DM0 AD1
USB_1P_VRT AC3
USB_2P_VRT AD3
AVDD12_COM E5
AVDD12_REC E6
AVSS12_COM F7
AVSS12_REC G7
AVDD33_COM C5
AVDD33_REC F5
AVDD33_LD D4
AVSS33_COM D5
AVSS33_LD C4
AVSS33_REC F6
TXVN_0 B3
TXVP_0 A2
TXVN_1 A4
TXVP_1 B4
TANA_0 A5
TANA_1 B5
REXT D6
DVCC33_IO_5
J14 STXN W2
STXP W1
SRXP Y2
SRXN Y1
SREXT Y4
AVDD33_SATA Y5
AVDD12_SATA1 Y3
AVSS12_SATA1 W6
DVCC33_IO
N8
DVCC33_IO
P8
DVCC33_IO
T8
DVCC33_IO_3
J18
DVCC33_IO_3
J19
R101 0
R102 5.1K/1%
C88
0.1uF/16V/X7R
C88
0.1uF/16V/X7R
C167
4.7uF/10V/Y5V
C167
4.7uF/10V/Y5V
P2
RJ8-45
P2
RJ8-45
TX+
1
TX-
2
RX+
3
N/C
4
N/C
5
RX-
6
N/C
7
N/C
8GND 9
GND 10
R94 453 R94 453
R579
75/1%
R579
75/1%
U14
LFE8634
U14
LFE8634
RD+
6
RD-
8
TDCT
4
TD-
3
RXCT
5
TD+
1
RX- 9
RXCT 12
RX+ 11
TX- 14
TXCT 13
TX+ 16
R580
75/1%
R580
75/1%
C166
0.1uF/16V/X7R
C166
0.1uF/16V/X7R
C174
0.1uF/25V/Y5V
C174
0.1uF/25V/Y5V
R9010K R9010K
R400 0
C89
0.1uF/16V/X
C89
0.1uF/16V/X
C165
4.7uF/10V/Y5V
C165
4.7uF/10V/Y5V
C169
4.7uF/10V/Y5V
C169
4.7uF/10V/Y5V
R134
75/1%
R134
75/1%
C152
0.1uF/16V/X7R
C152
0.1uF/16V/X7R
C402
0.1uF/16V/Y5V
C402
0.1uF/16V/Y5V
MAIN BOARD ASSY (5/10)
(BDP-440 : 08-BDP440-MA0/Y-TL)
(BDP-52FD : 08-BDP440-MA1/U-TL)
A5/10F

15
BDP-440
56 7 8
56 7 8
A
B
C
D
E
F
A5/10F
NAND Flash
BE
ICE
PCB TOP USB TESET POINT
Hardware trap
To Front USB
TO WiFi
PCB BTMP USB TESET POINT
NFD2
NFD5
NFWEN_R
NFCEN_R
NFALE_R
NFWP#
NFD4
NFD7
NFD1
NFREN_R
NFD6
NFCLE_R
NFRBN_R
3.3VRESET#
TDO
TRST_
TDI
TCK
TMS
SFCKSD_DAT3
SFCSSD_DAT2
SFDISD_DAT1
SFDOSD_DAT0
DMC_DS2NBRFN 2NBRFN
NFCEN2SD_CLK
USBM0
USB_VCC3
USBP2
USBM2
USB_VCC1
USBP0
USB_VCC2
USBP1
USBM1
3.3VRESET#
NFWEN_R
NFCLE_R
NFREN_R
NFCEN_R
NFALE_R
NFCEN2
USB_EN2#
USB_OC2#
USBP2
USBM2
USB_OC0#
USB_VCC3
USB_VCC2
USB_VCC1
USB_VCC3
NFRBN_RNFRBN
NFCLE_R
NFCLE
NFCEN_RNFCEN
NFWEN_RNFWEN
NFALENFALE_R
NFRENNFREN_R
NFD0
NFD3
USB_VCC2
USBM0
USBP0
USB_VCC1
USBP1
USBM1
USB_EN2#
USB_OC2#
GPIO2
GPIO4
GPIO1
GPIO3
GPIO0 USB_EN0#
USB_OC0#
TGPIO4
USB_EN0#
3.3V
3.3V
VCC_D
VCC
3.3V
3.3V
3.3V
3.3V
3.3V
HDMI_VCC
VCC
SD_DAT29
SD_DAT39
SD_CLK9
SD_DAT09
SD_DAT19
SD_CMD9
3.3VRESET#2
WiFi_EN#
9
C98
0.1uF/16V/X7R
C98
0.1uF/16V/X7R
C150
0.1uF/16V/X7R
C150
0.1uF/16V/X7R
TP32TP32
C97
0.1uF/16V/X7R
C97
0.1uF/16V/X7R
R442 33
R118 10K
R9650R9650
C349
NC
C349
NC
R8710K R8710K
C91
0.1uF/16V/X7R
C91
0.1uF/16V/X7R
J2
8PIN/1.0mm
J2
8PIN/1.0mm
1
12
23
34
45
56
67
78
8
R894.7K R894.7K
+
100uF/16V
CE11
+
100uF/16V
CE11
C86
0.1uF/16V/X7R
C86
0.1uF/16V/X7R
R127
NC/10K
R127
NC/10K
R11110K R11110K
C94
0.1uF/16V/X7R
C94
0.1uF/16V/X7R
R116 10K
TP29TP29
R126
NC/10K
R126
NC/10K
C350
NC
C350
NC
C87
0.1uF/16V/X7R
C87
0.1uF/16V/X7R
Q210
NC/2N3904
SOT-23
Q210
NC/2N3904
SOT-23
R441 33
TP30TP30
C351
NC
C351
NC
C100
0.1uF/16V/X7R
C100
0.1uF/16V/X7R
C353
NC
C353
NC
CB402
0.1uF/16V/Y5V
CB402
0.1uF/16V/Y5V
R9110K R9110K
R106
10K
R106
10K
C90
0.1uF/16V/X7R
C90
0.1uF/16V/X7R
R964NC/4.7KR964NC/4.7K
TP33TP33
R447 33
R9710K R9710K
XP3
NC/4PIN/2.0mm
XP3
NC/4PIN/2.0mm
1
12
23
34
4
TP91TP91
C352
NC
C352
NC
C178
NC/0.1uF/25V/Y5V
C178
NC/0.1uF/25V/Y5V
R11410K R11410K
R130NC/510R130NC/510
R119 10K
FB18 10/2A
R990R990
C93
0.1uF/16V/X7R
C93
0.1uF/16V/X7R
TP31TP31
U13
G556B1
SO8
U13
G556B1
SO8
IN
7
/EN1
1
/OC1
2
/OC2
3
/EN2
4
OUT2 5
OUT1 8
GND 6
CB403
NC/0.1uF/16V/Y5V
CB403
NC/0.1uF/16V/Y5V
R9210K R9210K
U12
NAND 256MB
U12
NAND 256MB
VCC 12
NC 11
CE2 10
CE1 9
RE 8
R/B1 7
R/B2 6
NC 5
NC 23
NC 4
NC 3
NC 2
VSS 13
NC 14
NC 15
ALE 17
WE 18
WP 19
NC 20
NC 21
NC 24
NC 22
NC 1
CLE 16
NC
48
NC
47
NC
46
NC
45
DQ7
44
DQ6
43
DQ5
42
DQ4
41
NC
40
NC
39
PRE
38
VCC
37
VSS
36
NC
35
NC
34
NC
33
DQ3
32
DQ2
31
DQ1
30
DQ0
29
NC
28
NC
27
NC
26
NC
25
C92
0.1uF/16V/X7R
C92
0.1uF/16V/X7R
TP28TP28
XP6
4PIN/2.0mm
XP6
4PIN/2.0mm
1
12
23
34
4
R9310K R9310K
R11010K R11010K
TP34TP34
R968
NC/180
R968
NC/180
R120 0/NC
R86NC/0 R86NC/0R10910K R10910K
C151 0.1uF/16V/X7R
1:GND
2:D+
3:D-
4:VCC
4
2
3
1
P503
USB TYPEA
1:GND
2:D+
3:D-
4:VCC
4
2
3
1
P503
USB TYPEA
2
3
4
1
56
R117 10K
C88
0.1uF/16V/X7R
C88
0.1uF/16V/X7R
C372
0.1uF/25V/Y5V
C372
0.1uF/25V/Y5V
C354
NC
C354
NC
R966
NC/180
R966
NC/180
R445 33
Q211
NC/PNP_PBSS5320T
Q211
NC/PNP_PBSS5320T
C99
0.1uF/16V/X7R
C99
0.1uF/16V/X7R
CB1
0.1uF/16V/Y5V
CB1
0.1uF/16V/Y5V
R854.7K R854.7K
R11210K R11210K
R448 NC/33
TP26TP26
R9010K R9010K
TP27TP27
C89
0.1uF/16V/X7R
C89
0.1uF/16V/X7R
XS221
BF

16 BDP-440
12 3 4
A
B
C
D
E
F
12 3 4
2.6 MAIN BOARD ASSY (6/10) : VFD/IR
A6/10F
{LCDRD, ETTXEN} = 0 , Normal mode
{LCDRD, ETTXEN} = 1 , RST by SVO mode
{LCDRD, ETTXEN} = 2 , Monitor mode
{LCDRD, ETTXEN} = 3 , Test scan mode
RS232C JACK FOR CONTROL BOX
IR
VCLK
VSTB
DVCC33_IO_STB
OPWRSB
GPIO8_AO2LRCK
AVDD33_LDO
AVDD33_LDO
ETTXEN_VOUTD14
UARXD
UATXD
DVCC33_IO_STB
VDATA
AVDD10_LDO
LCDRD
ETTXER_AO2SDATA0
RESET_
LCDRD
ETTXEN_VOUTD14
OPEN_K
POWER_K
OPEN_K
POWER_K
Play_K
Play_K
2ndrs232TX
2ndrs232RX
VCXO_1.65V_CTL
2ndrs232TX
2ndrs232RX
VFD_PW_CTL
3.3V_STBY
3.3V_STBY
3.3V_STBY
3.3V_STBY
VCC
RESET_ 2
OPWRSB 2
POWER_K 2
VCXO_1.65V_CTL 5
VFD_PW_CTL 5
R151
10K
R151
10K
CON3
4PIN/2.0mm4PIN/2.0mm
11
22
33
44
C
4
C
4
U7D
MT8555_0825_A
U7D
MT8555_0825_A
DVCC33_IO_STB
J21
DVCC33_IO_STB
H21
AVDD33_LDO
J24
AVDD10_LDO
K21
AVSS33_LDO
H22
GPIO8 H24
ETCOL J27
ETCRS F26
ETMDC J28
ETMDIO J26
ETRXCLK G26
ETRXD0 F25
ETRXD1 G27
ETRXD2 G28
ETRXD3 G25
ETRXDV E25
ETRXER E26
ETTXCLK G24
ETTXD0 G23
ETTXD1 H23
ETTXD2 J23
ETTXD3 H26
ETTXEN H25
ETTXER F24
UARXD J25
UATXD K26
VSTB L25
VDATA M23
VCLK M24
LCDRD L26
IR K25
RESET_ K23
OPWRSB K24
C509
100pF/50V/NP0
C509
100pF/50V/NP0
C187
NC
C187
NC
R141 4.7K
R152
10K
R152
10K
C192
0.1uF/16V/X7R
C192
0.1uF/16V/X7R
C514
100pF/50V/NP0/NC
C514
100pF/50V/NP0/NC
R153
10K
R153
10K
TP41TP41
TP35TP35
R150
10K
R150
10K
R14610K R14610K
C191
NC
C191
NC
C511
100pF/50V/NP0/NC
C511
100pF/50V/NP0/NC
C504
0.1uF/16V/X7R
C504
0.1uF/16V/X7R
C188
NC
C188
NC
C507
0.1uF/16V/X7R
C507
0.1uF/16V/X7R
XS1
FF

17
BDP-440
56 7 8
56 7 8
A
B
C
D
E
F
A6/10F
BE RS232 SW Debug JACK
bdx3200 46-35199W-06X
pcb TOP VFD/IR Port TESET point
TO VFD BOARD
UARXD
UATXD
VCLK
VDATA
VSTB
IR_OUTIR
POWER_K
PCON
VCLK
VDATA
VSTB
+12V_D
VFD_EN
-24V_D
OPEN_K
SCL
-24V_D
Play_K
VFD_ENVFD_PW_CTL
3.3V_STBY
3.3V_STBY
_STBY
VCC_D
+12V_D
-24V_D
VCC
3.3V_STBY
VCC
3.3V
CEC 5
SCL 6
SDA 6
PCON
2
5
C5120.1uF/50V/X7R C5120.1uF/50V/X7R C19627pF/50V/NP0 C19627pF/50V/NP0
R143 33 R143 33
R151
10K
R151
10K
C19727pF/50V/NP0 C19727pF/50V/NP0
VSTB1VSTB1
CON1
4PIN/2.0mm
CON1
4PIN/2.0mm
11
22
33
44
VDATA1VDATA1
R76
10K
R76
10K
C19327pF/50V/NP0 C19327pF/50V/NP0
R152
10K
R152
10K
R75 33/NC
C19527pF/50V/NP0 C19527pF/50V/NP0
TM31TM31
C20027pF/50V/NP0 C20027pF/50V/NP0
R153
10K
R153
10K
TM34TM34
R73
NC/4.7K
R73
NC/4.7K
XP4
CON_12P_0GNDD
CON_12P_0GNDD
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
R69 NC/33
C513
0.1uF/16V/X7R
C513
0.1uF/16V/X7R
R68 4.7K
C186
0.1uF/16V/X7R
C186
0.1uF/16V/X7R
R72 NC/33
R150
10K
R150
10K
C19927pF/50V/NP0 C19927pF/50V/NP0
R685 0/NC
TM14TM14
R142 NC/33 R142 NC/33
R682
10K
R682
10K
C19827pF/50V/NP0 C19827pF/50V/NP0
TM33TM33
VCLK1VCLK1
R145 33 R145 33
R679 NC/0
C194NC/27pF/50V/NP0 C194NC/27pF/50V/NP0
R13810K R13810K
R70 NC/0
R678
10K
R678
10K
R77
10K
R77
10K
R144 33 R144 33
R684 0
R71 0
R13910K R13910K
MAIN BOARD ASSY (6/10)
(BDP-440 : 08-BDP440-MA0/Y-TL)
(BDP-52FD : 08-BDP440-MA1/U-TL)
A6/10F
XS135
BF
XP4

18 BDP-440
12 3 4
A
B
C
D
E
F
12 3 4
2.7 MAIN BOARD ASSY (7/10) : AUDIO DAC
A7/10F
59MA?
50MA?
AOLRCK
AOBCK
AOMCLK
<CONSTRAINT_CLASS>
AOSDATA3
ROUT1
ETUMA ETUMA
LOUT1
CVBS0
MUTE
AMUTE
GND
GND
GND
3.3V
GND
GND
GND
GND
3.3V
GND
GND
VCC_D
AMUTE
5
AOSDATA3 5
CVBS 5
+
470uF/16V/NC
CE607
+
470uF/16V/NC
CE607
C356560pF/50V/X7R C356560pF/50V/X7R
C303
10uF/10V/Y5V C303 10uF/10V/Y5V
+
47uF/10V CE23
+
47uF/10V CE23
C304
0.1uF/25V/Y5V
C304
0.1uF/25V/Y5V
R619
100K
R619
100K
C305
1uF/10V/Y5V C305 1uF/10V/Y5V
C309
2.2uF/10V/Y5V
C309
2.2uF/10V/Y5V
Q50
NPN_3DG3904M
Q50
NPN_3DG3904M
R620 1KR620 1K
C308560pF/50V/X7R C308560pF/50V/X7R
R618
75/1%
R618
75/1%
R310 470R310 470
FB25 120/200mA FB25 120/200mA
R283 10KR283 10K
C623
47pF/50V/NP0
C623
47pF/50V/NP0
R626 2.2KR626 2.2K
Q218
PNP_3CG3906M
Q218
PNP_3CG3906M
C510560pF/50V/X7R C510560pF/50V/X7R
R285 4.7KR285 4.7K
C307
560pF/50V/X7R
C307
560pF/50V/X7R
R617 0R617 0
C306
1uF/10V/Y5V C306 1uF/10V/Y5V
R311 470R311 470
U15
AK4430ET
TSSOP16
U15
AK4430ET
TSSOP16
CN 1
CP 2
SMUTE
3
MCLK
4
BICK
5
SDTI
6LRCK
7
DIF
8
AOUTR 9
AOUTL 10
VDD
11
VSS1
12 VREFH 13
CVDD
14
VSS2
15
VEE 16
FB26 120/200mA FB26 120/200mA
D608
LVSL10180Z020/18V/2pF
D608
LVSL10180Z020/18V/2pF
2 1
L453 1.8uH/50mAL453 1.8uH/50mA
C3020.1uF/25V/Y5V C3020.1uF/25V/Y5V
C622
47pF/50V/NP0
C622
47pF/50V/NP0
R284 NC/4.7KR284 NC/4.7K

19
BDP-440
56 7 8
56 7 8
A
B
C
D
E
F
A7/10F
Left (White)
Right (Red)
CVBS (Yellow)
AOMCLK
AOBCK
AOSDATA0
AOLRCK
ROUT1
LOUT1
SPDIF
VCC_D
LOUT1
ROUT1
MUTE
MUTE
CVBS0
SPDIF
AOMCLK 5
AOBCK 5
AOSDATA0 5
AOLRCK 5
LOUT1
ROUT1
SPDIF 5
C628
100pF/50V/NP0
C628
100pF/50V/NP0
FB6
500/200mA
FB6
500/200mA
C629
100pF/50V/NP0
C629
100pF/50V/NP0
C614
0.1uF/25V/Y5V
C614
0.1uF/25V/Y5V
R609 180/1%R609 180/1%
R625 2.2KR625 2.2K
+
CE608
10uF/16V
+
CE608
10uF/16V
Q48
NPN_3DG3904M
Q48
NPN_3DG3904M
R624 2.2KR624 2.2K Q49
NPN_3DG3904M
Q49
NPN_3DG3904M
R611 100/1%R611 100/1%
RCA
P3
RCA+OPTICAL
RCA
P3
RCA+OPTICAL
RCA+OPTICAL
1
2
3
4
5
6
7
MAIN BOARD ASSY (7/10)
(BDP-440 : 08-BDP440-MA0/Y-TL)
(BDP-52FD : 08-BDP440-MA1/U-TL)
A7/10F

20 BDP-440
12 3 4
A
B
C
D
E
F
12 3 4
2.8 MAIN BOARD ASSY (8/10) : VIDEO/SD OUTPUT
A8/10F
VDIN30
VDIN28
VDIN29
VDIN31
AVDD33_HDMI_RX
AVDD12_HDMI_RX
VOUT_CR1VDIN3
SD_PWR_CTRL
SD_WP
VDIN10 WiFi_EN#
CARD_PROTECTCARD_PROTECT
SD_PWR_CTRL
SD_WP
SD_DAT1
SD_DAT0
SD_DAT3
SD_CMD
SD_DAT2
SD_CLK
CARD_DETECT
1.2V
3.3V
3.3V
CARD_3V3
SD_CLK 6
SD_DAT0 6
SD_DAT1 6
SD_DAT2 6
SD_DAT3 6
SD_CMD 6
WiFi_EN# 6
R194 0R194 0
R666 0R666 0
C218
NC
C218
NC C219
0.1uF/16V/X7R
C219
0.1uF/16V/X7R
R277
10K
R277
10K
TP68 TEST POINT SMD1.0 TP68 TEST POINT SMD1.0
C656
NC
C656
NC
TP69 TEST POINT SMD1.0 TP69 TEST POINT SMD1.0
R279
510
R279
510
U7G
MT8555_0825_A
U7G
MT8555_0825_A
RX0
B8 RX0B
A8
RX1
B7 RX1B
A7
RX2
B6 RX2B
A6
RXCK
B9 RXCKB
A9
VDD12_HDMI_RX
D7
VSS33_HDMI_RX
E8
VDD33_HDMI_RX
C7 VDD33_HDMI_RX
C8
VSS33_HDMI_RX
F8
VDIN0 E27
VDIN1 D28
VDIN2 D27
VDIN3 C28
VDIN4 C27
VDIN5 B28
VDIN6 D26
VDIN7 A28
VDIN8 B27
VDIN9 A27
VDIN10 C26
VDIN11 A26
VDIN12 B26
VDIN13 A25
VDIN14 B25
VDIN15 A24
VDIN16 B24
VDIN17 D23
VDIN18 C23
VDIN19 D22
VDIN20 C22
VDIN21 E23
VDIN22 E22
VDIN23 F22
VDIN24 A22
VDIN25 B22
VDIN26 A21
VDIN27 B21
VDIN28 E20
VDIN29 C20
VDIN30 D21
VDIN31 C21
VDIN32 E21
VDIN33 D20
VDIN34 F21
VDIN35 G20
VDINHSYNC E28
VDINVSYNC F27
VDINCLK F28
VDD12_HDMI_RX
D8
Q15
P_AO3401/NC
Q15
P_AO3401/NC
G
DS
LED_BLED_B
R967 NC/0R967 NC/0
C296
0.1uF/25V/Y5V
C296
0.1uF/25V/Y5V
R275 33R275 33
LED_ALED_A
R274 10KR274 10K
C295
10uF/10V/Y5V
C295
10uF/10V/Y5V
R276 1KR276 1K
R191 33R191 33
C220
0.1uF/16V/X7R
C220
0.1uF/16V/X7R
