Pioneer DEH-P7700MP - In-Dash CD/MP3/WMA/WAV/iTunes AAC Car Stereo... User manual

Operation Manual
Mode demploi
Multi-CD control High power CD/MP3/WMA player
with FM/AM tuner
Syntoniseur FM/AM et lecteur de CD/MP3/WMA,
Puissance éle ée, a ec contrôleur pour lecteur de
CD à chargeur
DEH-P7700MP
English Français

Thank you for buying this Pioneer product.
Please read through these operating instructions so you will know how to operate
your model properly. After you have finished reading the instructions, keep this man-
ual in a safe place for future reference.
Before You Start
Information to User 6
For Canadian model 6
About this unit 6
About this manual 6
After sales service for Pioneer products 7
Product registration 7
Features 7
About W A 8
About AAC 8
About the SAT RADIO READY mark 8
Protecting your unit from theft 8
Removing the front panel 9
Attaching the front panel 9
About the demo mode 9
Reverse mode 9
Feature demo 10
Use and care of the remote control 10
Installing the battery 10
Using the remote control 10
FUNCTION button and AUDIO
button 11
Whats What
Head unit 12
Remote control 12
Basic Operations
Turning the unit on 14
Selecting a source 14
Loading a disc 14
Adjusting the volume 15
Turning the unit off 15
Tuner
Listening to the radio 16
Introduction of advanced tuner
operation 17
Storing and recalling broadcast
frequencies 17
Storing the strongest broadcast
frequencies 17
Selecting stations from the preset channel
list 18
Tuning in strong signals 18
Built-in C Player
Playing a CD 19
Selecting a track directly 19
Introduction of advanced built in CD player
operation 20
Repeating play 20
Playing tracks in a random order 20
Scanning tracks of a CD 21
Pausing CD playback 21
Using compression and B X 21
Selecting the search method 21
Searching every 10 tracks in the current
disc 22
Entering disc titles 22
Entering disc titles 22
Displaying disc titles 23
Using CD TEXT functions 23
Displaying titles on CD TEXT
discs 23
Scrolling titles in the display 23
Selecting tracks from the track title
list 23
MP3/WMA/AAC/WAV Player
Playing P3/W A/AAC/WAV 24
Selecting a track directly in the current
folder 25
Introduction of advanced built in CD player
( P3/W A/AAC/WAV) operation 25
Repeating play 26
Playing tracks in a random order 26
Contents
En
2

Scanning folders and tracks 26
Pausing P3/W A/AAC/WAV playback 27
Using compression and B X 27
Selecting the search method 27
Searching every 10 tracks in the current
disc 27
Displaying text information on P3/W A/
AAC/WAV disc 28
When playing back an P3/W A/
AAC disc 28
When playing back a WAV disc 28
Scrolling text information in the display 28
Selecting tracks from the file name list 28
Multi-C Player
Playing a CD 30
Selecting a track directly 30
50 disc multi CD player 31
Introduction of advanced multi CD player
operation 31
Repeating play 32
Playing tracks in a random order 32
Scanning CDs and tracks 32
Pausing CD playback 33
Using ITS playlists 33
Creating a playlist with ITS
programming 33
Playback from your ITS playlist 33
Erasing a track from your ITS
playlist 34
Erasing a CD from your ITS
playlist 34
Using disc title functions 34
Entering disc titles 34
Displaying disc titles 35
Selecting discs from the disc title
list 35
Using CD TEXT functions 36
Displaying titles on CD TEXT
discs 36
Scrolling titles in the display 36
Selecting tracks from the track title
list 36
Using compression and bass emphasis 36
TV tuner
Watching the television 38
Introduction of advanced TV tuner
operation 39
Storing and recalling broadcast stations 39
Storing the strongest broadcast stations
sequentially 39
Selecting stations from the preset channel
list 40
V Player
Playing a disc 41
Selecting a disc 41
Selecting a folder 41
Introduction of advanced DVD player
operation 42
Repeating play 42
Pausing disc playback 43
Playing tracks in a random order 43
Scanning tracks of a CD/ P3/W A 43
Using ITS playlist and disc title functions 43
Using disc title functions 43
Entering disc titles 44
XM tuner
Listening to the X 45
Introduction of advanced X tuner
operation 46
Switching the X display 46
Storing and recalling broadcast stations 46
Swiching the X channel select setting 46
En 3
English
Contents

Selecting the channel in the channel
category 47
Selecting the X channel directly 47
Display the ID code 47
Channel number select setting 47
Channel category select setting 47
Audio Adjustments
Introduction of audio adjustments 48
Compensating for equalizer curves (EQ
EX) 48
Using balance adjustment 49
Using the equalizer 49
Recalling equalizer curves 49
Adjusting equalizer curves 49
Fine adjusting equalizer curve 50
Adjusting bass and treble 50
Adjusting loudness 51
Using subwoofer output 51
Adjusting subwoofer settings 51
Using nonfading output 52
Adjusting nonfading output level 52
Using the high pass filter 52
Adjusting source levels 52
Using automatic sound levelizer 53
Initial Settings
Adjusting initial settings 54
Setting the clock 54
Switching the warning tone 54
Switching the auxiliary setting 55
Switching the dimmer setting 55
Adjusting the brightness 55
Setting the rear output and subwoofer
controller 55
Switching the telephone muting/
attenuation 56
Switching the feature demo 56
Switching the reverse mode 56
Switching the Ever Scroll 57
Other Functions
Turning the clock display on or off 58
Using the AUX source 58
Selecting AUX as the source 58
Setting the AUX title 58
Using different entertainment displays 59
Using the PG button 59
Additional Information
Understanding built in CD player error
messages 60
CD player and care 60
CD R/CD RW discs 61
P3, W A, AAC and WAV files 61
P3 additional information 62
W A additional information 62
AAC additional information 62
WAV additional information 63
About folders and P3/W A/AAC/WAV
files 63
Terms 65
Specifications 67
Contents
En
4

Selecting fine audio equipment such as the unit you’ve just purchased is only the start of your
musical enjoyment. Now it’s time to consider how you can maximize the fun and excitement your
equipment offers. This manufacturer and the Electronic Industries Association’s Consumer
Electronics Group want you to get the most out of your equipment by playing it at a safe level. One
that lets the sound come through loud and clear without annoying blaring or distortion and, most
importantly, without affecting your sensitive hearing.
Sound can be deceiving. Over time your hearing “comfort level” adapts to higher volumes of
sound. So what sounds “normal” can actually be loud and harmful to your hearing. Guard against
this by setting your equipment at a safe level BEFORE your hearing adapts.
To establish a safe level:
•Start your volume control at a low setting.
•Slowly increase the sound until you can hear it comfortably and clearly, and without distortion.
Once you have established a comfortable sound level:
•Set the dial and leave it there.
Taking a minute to do this now will help to prevent hearing damage or loss in the future. After
all, we want you listening for a lifetime.
We Want You Listening For A Lifetime
Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment. Since
hearing damage from loud noise is often undetectable until it is too late, this manufacturer and the
Electronic Industries Association’s Consumer Electronics Group recommend you avoid prolonged
ex
p
osure to excessive noise. This
l
ist of sound
l
eve
l
s is inc
l
uded for
y
our
p
rotection
.
D
ec
i
bel
Leve
l Exampl
e
30
Quiet
l
i
b
rar
y
, soft whis
p
er
s
4
0
L
ivin
g
room, refri
g
erator,
b
edroom awa
y
from traffi
c
50
L
i
g
ht traffic, norma
l
conversation,
q
uiet office
60 Air conditioner at 20 feet, sewing machine
70 Vacuum cleaner, hair dryer, noisy restaurant
80 Average city traffic, garbage disposals, alarm clock at two feet
THE FOLLOWING NOISES CAN BE DANGEROUS UNDER CONSTANT EXPOSURE
90 Subway, motorcycle, truck traffic, lawn mower
100 Garbage truck, chain saw, pneumatic drill
120 Rock band concert in front of speakers, thunderclap
140 Gunshot blast, jet plane
180 Rocket launching pad
Information courtesy of the Deafness Research Foundation.
En 5
English

Information to User
Alteration or modifications carried out without
appropriate authorization may invalidate the
users right to operate the equipment.
For Canadian model
This Class B digital apparatus complies with
Canadian ICES 003.
About this unit
The tuner frequencies on this unit are allo
cated for use in North America. Use in other
areas may result in poor reception.
WARNING:
Handling the cord on this product or cords asso
ciated with accessories sold with the product will
expose you to lead, a chemical known to the
State of California and other governmental enti
ties to cause cancer and birth defects or other re
productive harm. Wash hands after handling.
CAUTIO :
USE OF CO TROL OR ADJUSTME T OR
PERFORMA CE OF PROCEDURES
OTHER THA THOSE SPECIFIED HEREI
MAY RESULT I HAZARDOUS RADIATIO
EXPOSURE.
CAUTIO :
THE USE OF OPTICAL I STRUME TS
WITH THIS PRODUCT WILL I CREASE
EYE HAZARD.
CAUTION
!Do not allow this unit to come into contact
with liquids. Electrical shock could result.
Also, this unit damage, smoke, and overheat
could result from contact with liquids.
!Keep this manual handy as a reference for op
erating procedures and precautions.
!Always keep the volume low enough so that
you can hear sounds from outside the vehicle.
!Protect this unit from moisture.
!If the battery is disconnected or discharged,
the preset memory will be erased and must be
reprogrammed.
Important (Serial number)
The serial number is located on the bottom of
this unit. For your own security and convenience,
be sure to record this number on the enclosed
warranty card.
About this manual
This unit features a number of sophisticated
functions ensuring superior reception and op
eration. All the functions have been designed
for the easiest possible use, but many are not
self explanatory. This operation manual will
help you benefit fully from this units potential
and to maximize your listening enjoyment.
We recommend that you familiarize yourself
with the functions and their operation by read
ing through the manual before you begin
using this unit. It is especially important that
you read and observe WARNINGs and CAU-
TIONs in this manual.
Before You Start
En
6
Section
01

After-sales service for
Pioneer products
Please contact the dealer or distributor from
where you purchased this unit for after sales
service (including warranty conditions) or any
other information. In case the necessary infor
mation is not available, please contact the
companies listed below:
Please do not ship your unit to the companies
at the addresses listed below for repair without
advance contact.
U.S.A.
Pioneer Electronics (USA) Inc.
CUSTO ER SUPPORT DIVISION
P.O. Box 1760
Long Beach, CA 90801 1760
800 421 1404
CANA A
Pioneer Electronics of Canada, Inc.
CUSTO ER SATISFACTION DEPART ENT
300 Allstate Parkway
arkham, Ontario L3R OP2
1 877 283 5901
For warranty information please see the Lim
ited Warranty sheet included with this unit.
Product registration
Visit us at the following site:
1 Register your product. We will keep the details
of your purchase on file to help you refer to
this information in the event of an insurance
claim such as loss or theft.
2 Receive updates on the latest products and
technologies.
3 Download owners manuals, order product
catalogues, research new products, and
much more.
Features
CD playbac
usic CD/CD R/CD RW playback is possible.
MP3 file playbac
You can play back P3 files recorded on CD
RO /CD R/CD RW (ISO9660 Level 1/Level 2
standard recordings).
!Supply of this product only conveys a li
cense for private, non commercial use and
does not convey a license nor imply any
right to use this product in any commercial
(i.e. revenue generating) real time broad
casting (terrestrial, satellite, cable and/or
any other media), broadcasting/streaming
via internet, intranets and/or other net
works or in other electronic content distri
bution systems, such as pay audio or
audio on demand applications. An inde
pendent license for such use is required.
For details, please visit
http://www.mp3licensing.com.
WMA file playbac
You can play back W A files recorded on CD
RO /CD R/CD RW (ISO9660 Level 1/Level 2
standard recordings).
AAC file playbac
You can play back AAC files recorded on CD
RO /CD R/CD RW (ISO9660 Level 1/Level 2
standard recordings).
WAV file playbac
You can play back WAV files recorded on CD
RO /CD R/CD RW (Linear PC (LPC )/ S
ADPC recordings).
Before You Start
En 7
English
Section
01

About WMA
The Windows edia"logo printed on the box
indicates that this unit can play back W A
data.
W A is short for Windows edia Audio and
refers to an audio compression technology
that is developed by icrosoft Corporation.
W A data can be encoded by using Windows
edia Player version 7 or later.
icrosoft, Windows edia, and the Windows
logo are trademarks, or registered trademarks
of icrosoft Corporation in the United States
and/or other countries.
Notes
!With some applications used to encode W A
files, this unit may not operate correctly.
!Depending on the version of Windows edia
Player used to encode W A files, album
names and other text information may not be
correctly displayed.
About AAC
AAC is short for Advanced Audio Coding and
refers to an audio compression technology
standard used with PEG 2 and PEG 4.
Several applications can be used to encode
AAC files, but file formats and extensions dif
fer depending on the application, which is
used to encode.
This unit plays back AAC files encoded by
iTunes®version 4.1.1.54.
iTunes®is a trademark of Apple Computer,
Inc., registered in the U.S. and other
countries.
About the SAT RADIO
READY mar
The SAT RADIO READY mark printed on the
front panel indicates that the Satellite Radio
Tuner for Pioneer (aka, X tuner and Sirius sa
tellite tuner which are sold separately) can be
controlled by this unit. Please inquire to your
dealer or nearest authorized Pioneer service
station regarding the satellite radio tuner that
can be connected to this unit. For satellite
radio tuner operation, please refer to the satel
lite radio tuner owners manual.
Notes
!The system will use direct satellite to receiver
broadcasting technology to provide listeners
in their cars and at home with crystal clear
sound seamlessly from coast to coast. Satel
lite radio will create and package over 100
channels of digital quality music, news,
sports, talk and childrens programming.
!SAT Radio, the SAT Radio logo and all re
lated marks are trademarks of Sirius Satellite
Radio inc., and X Satellite Radio Inc.
Protecting your unit from
theft
The front panel can be detached from the
head unit and stored in the protective case
provided to discourage theft.
Before You Start
En
8
Section
01

!If the front panel is not detached from the
head unit within five seconds of turning off
the ignition, a warning tone will sound.
!You can turn off the warning tone. See
Switching the warning tone on page 54.
Important
!Never use force or grip the display and the
buttons too tightly when removing or attach
ing.
!Avoid subjecting the front panel to excessive
shocks.
!Keep the front panel out of direct sunlight and
high temperatures.
Removing the front panel
1 Press OPEN to open the front panel.
2 Grip the left side of the front panel and
pull it gently outward.
Take care not to grip it too tightly or to drop
the front panel and protect it from contact
with water or other fluids to prevent perma
nent damage.
3 Put the front panel into the protective
case provided for safe keeping.
Attaching the front panel
%Replace the front panel by holding it
upright to the unit and clipping it securely
into the ounting hooks.
About the demo mode
This unit features two demonstration modes.
One is the reverse mode, the other is the fea
ture demo mode.
!You cannot cancel a demo mode when the
front panel is open.
Important
The red lead (ACC) of this unit should be con
nected to a terminal coupled with ignition switch
on/off operations. If this is not done, the vehicle
battery may be drained.
Reverse mode
If you do not perform an operation within
about 30 seconds, screen indications start to
reverse, and then continue reversing every 10
seconds. Pressing button 5when power to
this unit is turned off while the ignition switch
is set to ACC or ON cancels the reverse mode.
Press button 5again to start the reverse
mode.
Before You Start
En 9
English
Section
01

!You can also perform the same operation
from Switching the reverse mode on Initial
Settings. For more details, see Switching
the reverse mode on page 56.
Feature demo
The feature demo automatically starts when
power to this unit is turned off while the igni
tion switch is set to ACC or ON. Pressing but
ton 6during feature demo operation cancels
the feature demo mode. Press button 6again
to start the feature mode. Remember that if
the feature demo continues operating when
the car engine is turned off, it may drain bat
tery power.
!You can also perform the same operation
from Switching the feature demo on Initial
Settings. For more details, see Switching
the feature demo on page 56.
Use and care of the remote
control
Installing the battery
Slide the tray out on the back of the remote
control and insert the battery with the plus (+)
and minus () poles pointing in the proper di
rection.
!When using for the first time, pull out the
film protruding from the tray.
WARNING
Keep the battery out of the reach of children.
Should the battery be swallowed, immediately
consult a doctor.
CAUTION
!Use only one CR2025 (3 V) lithium battery.
!Remove the battery if the remote control is not
used for a month or longer.
!Do not recharge, disassemble, heat or dispose
of the battery in fire.
!Do not handle the battery with metallic tools.
!Do not store the battery with metallic materi
als.
!In the event of battery leakage, wipe the re
mote control completely clean and install a
new battery.
!When disposing of used batteries, please
comply with governmental regulations or en
vironmental public institutionsrules that
apply in your country/area.
Using the remote control
Point the remote control in the direction of the
front panel to operate.
!The remote control may not function prop
erly in direct sunlight.
Important
!Do not store the remote control in high tem
peratures or direct sunlight.
!Do not let the remote control fall onto the
floor, where it may become jammed under the
brake or accelerator pedal.
Before You Start
En
10
Section
01

FUNCTION button and AUDIO button
You can also select the desired mode by
FUNCTION button and AUDIO button on the
remote control. But operation of FUNCTION
button and AUDIO button on the remote con
trol differs from the operation of
Multi-Control on the head unit. When operat
ing the remote control, switch through the
modes as described below to select the mode.
FUNCTION button operation
%Press FUNCTION to select the desired
ode (e.g., built-in CD player).
Press FUNCTION repeatedly to switch be
tween the following modes:
Play ode (repeat play)Rando ode
(random play)Scan ode (scan play)
Pause (pause)Co pression (compres
sion and B X)Search ode (search meth
od)TitleInput"A" (disc title input)
Note
Refer to Introduction of advanced built-in CD
player operation on page 20.
AUDIO button operation
%Press AUDIO to select the desired
ode.
Press AUDIO repeatedly to switch between
the following modes:
FAD (balance adjustment)EQ (equalizer
curve adjustment)F80Q1W(equalizer
curve fine adjustment)Bass (bass and treble
level adjustment)Bass (bass and treble fre
quency adjustment)LOUD (loudness)
Sub-W1 (subwoofer on/off setting)/NonFad
(nonfading output on/off setting)Sub-W2
(subwoofer setting)/NonFad (nonfading out
put setting)HPF (high pass filter)SLA
(source level adjustment)ASL (automatic
sound levelizer)
Note
Refer to Introduction of audio adjustments on
page 48.
Before You Start
En 11
English
Section
01

Head unit
1LIST button
Press to display the disc title list, track title
list, folder list, file list or preset channel list
according to the source.
2DISPLAY button
Press to select different displays.
3OPEN button
Press to open the front panel.
4CLOCK button
Press to change to the clock display.
516 buttons
Press for preset tuning and disc number
search when using a multi CD or multi DVD
player.
6SW button
Press to directly select subwoofer setting
menu. See sing subwoofer output on page
51. Press and hold to select EQ EX setting
menu. See Compensating for equalizer
curves (EQ-EX) on page 48.
7Multi-Control
ove to do manual seek tuning, fast for
ward, reverse and track search controls.
Also used for controlling functions.
Turn it to increase or decrease the volume.
8EQ button
Press to select various equalizer curves.
9BAND button
Press to select among three F bands and
one A band and to cancel the control
mode of functions.
aSOURCE button
This unit is turned on by selecting a source.
Press to cycle through all the available
sources.
Remote control
Operation is the same as when using the but
tons on the head unit.
bVOLUME buttons
Press to increase or decrease the volume.
1
2
3
4
5678
9
a
Whats What
En
12
Section
02

cAUDIO button
Press to select various sound quality con
trols.
dFUNCTION button
Press to select functions.
eJoystick
ove to do manual seek tuning, fast for
ward, reverse and track search controls.
Also used for controlling functions.
Functions are the same as Multi-Control
except for volume control.
fDIRECT button
Press to directly select the desired track.
gCLEAR button
Press to cancel the input number when
NUMBER are used.
hNUMBER buttons
Press to directly select the desired track,
preset tuning or disc. Buttons 16can oper
ate the preset tuning for the tuner or disc
number search for the multi CD player.
iTUNER button
Press to select the tuner as the source.
jATT button
Press to quickly lower the volume level, by
about 90%. Press once more to return to the
original volume level.
kCD button
Press to select the built in or multi CD
player as the source.
lPGM button
Press to operate the preprogrammed func
tions for each source. (Refer to sing the
PGM button on page 59.)
b
c
d
e
f
g
h
2
i
9
j
k
l
Whats What
En 13
English
Section
02

Turning the unit on
%Press SOURCE to turn the unit on.
When you select a source the unit is turned
on.
Selecting a source
You can select a source you want to listen to.
To switch to the built in CD player, load a disc
in the unit (refer to page 19).
%When using the head unit, press
SOURCE to select a source.
Press SOURCE repeatedly to switch between
the following sources:
XM tunerTunerTelevisionV
player/Multi- V playerBuilt-in C
playerMulti-C playerExternal unit 1
External unit 2AUX
%When using the re ote control, press
TUNER or CD to select a source.
Press each button repeatedly to switch be
tween the following sources:
TUNER:XM tunerTunerTelevision
Sources off
CD:V player/Multi- V playerBuilt-
in C playerMulti-C playerSources
off
Notes
!In the following cases, the sound source will
not change:
When there is no unit corresponding to the
selected source connected to this unit.
When there is no disc in the unit.
When there is no disc in the DVD player.
When there is no magazine in the multi
CD player.
When there is no magazine in the multi
DVD player.
When the AUX (auxiliary input) is set to off
(refer to page 55).
!External unit refers to a Pioneer product (such
as one available in the future) that, although
incompatible as a source, enables control of
basic functions by this unit. Two external units
can be controlled by this unit. When two exter
nal units are connected, the allocation of
them to external unit 1 or external unit 2 is
automatically set by this unit.
!When this units blue/white lead is connected
to the vehicles auto antenna relay control
terminal, the vehicles antenna extends when
this units source is turned on. To retract the
antenna, turn the source off.
Loading a disc
1 Press OPEN to open the front panel.
CD loading slot appears.
#After a CD has been inserted, press SOURCE
to select the built in CD player.
2 Insert a CD into the CD loading slot.
Playback will automatically start.
CD loading slot
EJECT button
#You can eject a CD by pressing EJECT.
#To avoid a malfunction, make sure that no
metal object comes into contact with the term
inals when the front panel is open.
Basic Operations
En
14
Section
03

Notes
!The built in CD player plays one, standard, 12
cm or 8 cm (single) CD at a time. Do not use
an adapter when playing 8 cm CDs.
!Do not insert anything other than a CD into
the CD loading slot.
!There is sometimes a delay between starting
up CD playback and the sound being issued.
When being read in, For at read is dis
played.
!If you cannot insert a disc completely or if
after you insert a disc the disc does not play,
check that the label side of the disc is up.
Press EJECT to eject the disc, and check the
disc for damage before inserting it again.
!If an error message such as ERROR-11 is dis
played, refer to nderstanding built-in CD
player error messages on page 60.
!You can eject the CD by pressing and holding
EJECT with opening the front panel when the
CD loading or ejecting cannot operate proper
ly.
Adjusting the volume
%Use Multi-Control to adjust the sound
level.
With the head unit, rotate Multi-Control to in
crease or decrease the volume.
With the remote control, press VOLUME to in
crease or decrease the volume.
Turning the unit off
%Press SOURCE and hold until the unit
turns off.
Basic Operations
En 15
English
Section
03

Listening to the radio
1
2
3
4
6
5
These are the basic steps necessary to operate
the radio. ore advanced tuner operation is
explained starting on the next page.
1Band indicator
Shows which band the radio is tuned to, A
or F .
2LOC indicator
Shows when local seek tuning is on.
3Stereo (5) indicator
Shows that the frequency selected is being
broadcast in stereo.
4Preset nu ber indicator
Shows which preset has been selected.
5Signal level indicator
Shows the radio wave strength.
6Frequency indicator
Shows to which frequency the tuner is
tuned.
1 Press SOURCE to select the tuner.
Press SOURCE until you see Tuner displayed.
2 Press BAND to select a band.
Press BAND until the desired band is dis
played, FM-1,FM-2,FM-3 for F or AM.
3 To perfor anual tuning, push
Multi-Control left or right.
The frequencies move up or down step by
step.
4 To perfor seek tuning, push and hold
Multi-Control left or right for about one
second and release.
The tuner will scan the frequencies until a
broadcast strong enough for good reception is
found.
#You can cancel seek tuning by pushing
Multi-Control left or right.
#If you push and hold Multi-Control left or
right you can skip stations. Seek tuning starts as
soon as you release Multi-Control.
Tuner
En
16
Section
04

Introduction of advanced
tuner operation
1
1Function display
Shows the function status.
1 Press Multi-Control to display the ain
enu.
FUNCTION,AUDIO and ENTERTAINMENT
appear on the display.
2 Use Multi-Control to select FUNCTION.
Turn to change the menu option; press to se
lect.
The function name appears on the display.
3 Turn Multi-Control to select the func-
tion.
Turn Multi-Control clockwise to switch be
tween the functions in the following order:
BSM (best stations memory)Local (local
seek tuning)
#You can also switch between the functions in
the reverse order by turning Multi-Control coun
terclockwise.
#To return to the frequency display, press
BAND.
Note
If you do not operate the function within about 30
seconds, the display is automatically returned to
the frequency display.
Storing and recalling
broadcast frequencies
If you press any of the preset tuning buttons
16you can easily store up to six broadcast
frequencies for later recall with the touch of a
button.
%When you find a frequency that you
want to store in e ory press one of pre-
set tuning buttons 16 and hold until the
preset nu ber stops flashing.
The number you have pressed will flash in the
preset number indicator and then remain lit.
The selected radio station frequency has been
stored in memory.
The next time you press the same preset tun
ing button the radio station frequency is re
called from memory.
Notes
!Up to 18 F stations, six for each of the three
F bands, and six A stations can be stored
in memory.
!You can also recall radio station frequencies
assigned to preset tuning buttons 16by
pushing Multi-Control up or down.
Storing the strongest
broadcast frequencies
BS (best stations memory) lets you automa
tically store the six strongest broadcast fre
quencies under preset tuning buttons 16and
once stored there you can tune in to those fre
quencies with the touch of a button.
1 Use Multi-Control to select BSM.
BSM appears in the display.
Tuner
En 17
English
Section
04

2 Press Multi-Control to turn BSM on.
Searching is displayed. While Searching is
displayed, the six strongest broadcast frequen
cies will be stored under preset tuning num
bers 16in the order of their signal strength.
When finished, the preset channel list ap
pears.
#To cancel the storage process, press
Multi-Control.
3 Use Multi-Control to select the desired
station.
Turn to change the station; press to select.
#You can also change the station by pushing
Multi-Control up or down.
Note
Storing broadcast frequencies with BS may re
place broadcast frequencies you have saved
using buttons 16.
Selecting stations from the
preset channel list
The preset channel list lets you see the list of
preset stations and select one of them to re
ceive.
1 Press LIST to switch to the preset chan-
nel list ode during the frequency display.
2 Use Multi-Control to select the desired
station.
Turn to change the station; press to select.
#You can also change the station by pushing
Multi-Control up or down.
#If you do not operate the list within about 8
seconds, the preset channel list mode is can
celled automatically.
Tuning in strong signals
Local seek tuning lets you tune in only those
radio stations with sufficiently strong signals
for good reception.
1 Use Multi-Control to select Local.
Local appears in the display.
2 Press Multi-Control to turn local seek
tuning on.
Local seek sensitivity (e.g., Level 2) appears in
the display.
#To turn local seek tuning off, press
Multi-Control again.
3 Push Multi-Control left or right to set
the sensitivity.
There are four levels of sensitivity for F and
two levels for A :
F : Level 1Level 2Level 3Level 4
A : Level 1Level 2
The Level 4 setting allows reception of only
the strongest stations, while lower settings let
you receive progressively weaker stations.
Tuner
En
18
Section
04

Playing a CD
1
2
These are the basic steps necessary to play a
CD with your built in CD player. ore ad
vanced CD operation is explained starting on
the next page.
1Track nu ber indicator
Shows the track currently playing.
2Play ti e indicator
Shows the elapsed playing time of the cur
rent track.
1 Press SOURCE to select the built-in CD
player.
Press SOURCE until you see Co pact Disc
displayed.
#If no disc is loaded in the unit, you cannot se
lect Co pact Disc (built in CD player). Insert a
disc in the unit. (Refer to page 14.)
2 To perfor fast forward or reverse,
push and hold Multi-Control left or right.
#If you select Rough search, pushing and hold
ing Multi-Control left or right enables you to
search every 10 tracks in the current disc. (Refer
to Selecting the search method on page 21.)
3 To skip back or forward to another
track, push Multi-Control left or right.
Pushing Multi-Control right skips to the start
of the next track. Pushing Multi-Control left
once skips to the start of the current track.
Pushing again will skip to the previous track.
Note
When a CD TEXT disc is inserted, the disc title
automatically begin to scroll in the display.
When Ever Scroll is set to ON at the initial setting,
the disc title scroll continuously. About Ever
Scroll, refer to Switching the Ever Scroll on page
57.
Selecting a trac directly
When using the remote control, you can select
a track directly by entering the desired track
number.
!You cannot operate this mode from func
tion display.
1 Press DIRECT.
Track number input display appears.
2 Press NUMBER buttons to enter the de-
sired track nu ber.
#You can cancel the input number by pressing
CLEAR.
3 Press DIRECT.
The track of entered number will play.
Note
After entering the number input mode, if you do
not perform an operation within about 30 sec
onds, the mode is automatically canceled.
Built-in CD Player
En 19
English
Section
05

Introduction of advanced
built-in CD player operation
1
1Function display
Shows the function status.
1 Press Multi-Control to display the ain
enu.
FUNCTION,AUDIO and ENTERTAINMENT
appear on the display.
2 Use Multi-Control to select FUNCTION.
Turn to change the menu option; press to se
lect.
The function name appears on the display.
3 Turn Multi-Control to select the func-
tion.
Turn Multi-Control clockwise to switch be
tween the functions in the following order:
Play ode (repeat play)Rando ode
(random play)Scan ode (scan play)
Pause (pause)Co pression (compres
sion and B X)Search ode (search meth
od)TitleInput"A" (disc title input)
#You can also switch between the functions in
the reverse order by turning Multi-Control coun
terclockwise.
#To return to the playback display, press BAND.
Note
If you do not operate the function within about 30
seconds, the display is automatically returned to
the playback display.
Repeating play
There are two repeat play ranges for the built
in CD player: Disc repeat (disc repeat) and
Track repeat (one track repeat).
1 Use Multi-Control to select Play ode.
Play ode appears in the display.
2 Press Multi-Control to select the repeat
range.
Press Multi-Control repeatedly until the de
sired repeat range appears in the display.
!Disc repeat Repeat the current disc
!Track repeat Repeat just the current
track
Note
If you perform track search or fast forward/re
verse during Track repeat, the repeat play range
changes to Disc repeat.
Playing trac s in a random
order
Random play lets you play back tracks on the
CD in a random order.
1 Use Multi-Control to select
Rando ode.
Rando ode appears in the display.
2 Press Multi-Control to turn rando
play on.
Tracks will play in a random order.
#To turn random play off, press Multi-Control
again.
Built-in CD Player
En
20
Section
05
