Philips CEM5000 User manual

Register your product and get support at
www.philips.com/welcome
EN User manual
ZH-TWԚʹ˫ 
CEM5000

3
English
EN
Contents
1 Important 4
Safety 4
Notice 4
2 Your car audio system 6
Introduction 6
What’s in the box 6
Overview of the main unit 7
Overview of the remote control 9
3 Get started 11
Install the car audio 11
Install remote control battery 15
Turn on 15
Set clock 15
4 Listen to radio 16
Tune to a radio station 16
Store radio stations in memory 16
Tune to a preset station 16
Play with RDS 16
5 Use bluetooth devices 18
Pairing bluetooth devices 18
Make a call 18
Call transfer 19
Terminate call 19
Play audio files from bluetooth devices 19
6 Play audio files 20
Play a disc 20
Play from USB/SD/SDHC device 20
Control play 21
Search for an MP3/WMA track 21
View play information 21
Intro play 21
Shuffle play 21
Repeat play 22
Connect external sound source 22
7 Adjust sound 23
Adjust volume 23
Mute 23
Turn DBB and subwoofer on/off 23
Select preset equalizer 23
Other sound settings 23
8 Adjust system settings 24
BT mode 24
Language 24
LCD contrast 24
Dimmer 24
Blackout 24
Beep 24
Demo 24
Reset 25
9 Additional information 26
Detach the front panel 26
Replace fuse 26
Remove the unit 26
10 Product information 27
11 Troubleshooting 28
About Bluetooth device 28
12 Glossary 30

4
Notice
The making of unauthorized copies of
copy-protected material, including computer
programs, files, broadcasts and sound
recordings, may be an infringement of
copyrights and constitute a criminal offence.
This equipment should not be used for such
purposes.
This apparatus includes these labels:
Class II equipment symbol
This symbol indicates that the apparatus has a
double insulation system.
Recycling
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
When you see the crossed-out wheel bin
symbol attached to a product, it means the
product is covered by the European Directive
2002/96/EC:
1 Important
Safety
Read and understand all instructions•
before you use your apparatus. If damage
is caused by failure to follow instructions,
the warranty does not apply.
This apparatus is designed for negative•
ground (earth) 12 V DC operation only.
To ensure safe driving, adjust the volume•
to a safe and comfortable level.
Improper fuses can cause damage or•
fire. When you need to change the fuse,
consult a professional.
Use only the supplied mounting hardware•
for a safe and secure installation.
To avoid short circuit, do not expose the•
apparatus, remote control or remote
control batteries to rain or water.
Never insert objects into the ventilation•
slots or other openings on the apparatus.
Clean the apparatus and frame with a•
soft, damp cloth. Never use substances
such as alcohol, chemicals or household
cleaners on the apparatus.
Never place any objects other than discs•
into the apparatus.
Never use solvents such as benzene,•
thinner, cleaners available commercially,
or anti-static sprays intended for discs.
Visible and invisible laser radiation when•
open. Avoid exposure to beam.
Risk of damage to the apparatus screen!•
Never touch, push, rub or strike the
screen with any object.
Caution
Use of controls or adjustments or•
performance of procedures other than herein
may result in hazardous radiation exposure or
other unsafe operation.
EN

5
Specifications are subject to change without
notice. Trademarks are the property of
Koninklijke Philips Electronics N.V. or their
respective owners. Philips reserves the right
to change products at any time without being
obliged to adjust earlier supplies accordingly.
Never dispose of your product with other
household waste. Please inform yourself about
the local rules on the separate collection of
electrical and electronic products. The correct
disposal of your old product helps prevent
potentially negative consequences on the
environment and human health.
Your product contains batteries covered by
the European Directive 2006/66/EC, which
cannot be disposed of with normal household
waste.
Please inform yourself about the local rules on
separate collection of batteries. The correct
disposal of batteries helps prevent potentially
negative consequences on the environment
and human health.
This product complies with the radio
interference requirements of the European
Community.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and
old equipment.
Any changes or modifications made to this
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
2009 © Koninklijke Philips Electronics N.V. All
rights reserved.
English
EN

6
12
345
67
89
1110
2 Your car audio
system
Congratulations on your purchase, and
welcome to Philips! To fully benefit from the
support that Philips offers, register your product
at www.philips.com/welcome.
Introduction
With the in-car audio system, you can enjoy
your drive while you listen to:
FM or AM (MW) radio•
Audio from CD or MP3 disc•
Audio from your mobile phone•
Audio from a USB drive•
Audio from a SD/SDHC card•
Audio from external devices•
Besides, you can make a call, answer and hang
up a call on the audio system.
What’s in the box
Check and identify the contents of your
package:
aCar audio system
bRemote control
cRubber cushion
dScrew (4 pieces)
eDisassembly tool (2 pieces)
fFront panel
gTrim plate
hCarrying case for front panel
iUser manual
jQuick start guide
kStandard connector
EN

7
d
Select tuner band.•
Select MP3/WMA folder.•
Scroll up menu.•
e/OK/MUTE
Turn the unit on or off.•
Confirm selection.•
Mute or restore the volume.•
Overview of the main unit
aPhone call button with LED indicator
Green button: press to answer•
phone; Press and hold to transfer
call.
Red button: terminate call.•
bMENU
Access system menu.•
cSOURCE
Select audio source.•
SUB-W
de
cg
fhi
j
b
a
ut v
yx
{|
wsrqponmlk
z
SUB-W
de
cg
fhi
j
b
a
ut v
yx
{|
wsrqponmlk
z
English
EN

8
rSEARCH
Store radio stations automatically.•
Search MP3/WMA•
sDBB/SUB-W
Turn on or off Dynamic Bass Boost•
(DBB) sound.
Press and hold to turn on or off•
subwoofer.
t
Tune to a radio station•
Skip track.•
Fast forward playback.•
u
Select tuner band.•
Scroll down menu.•
Select MP3/WMA folder.•
v
Tune to a radio station•
Skip track.•
Fast backward playback.•
wEQ/Audio
Press to select equalizer (EQ) setting.•
Press and hold to access audio•
setting menu.
xPanel power connection
yDisc slot
z
Eject disc.•
{RESET
Restore default settings•
|SD card slot
fRotary encoder knob
Adjust volume.•
Adjust system settings under•
different menus.
g
Return to previous menu.•
hDisplay panel
i
Unlock the panel•
jUSB socket
kMP3 LINK
External device socket•
l5/6
Select preset station 5/6.•
Select preset 5th/6th speed dial•
number.
mSHUF, 4
Set shuffle play mode.•
Select preset station 4.•
Select preset 4th speed dial number.•
n3, REP
Set repeat play mode.•
Select preset station 3.•
Select preset 3rd speed dial number.•
oINTRO, 2
Turn intro play on or off.•
Select preset station 2.•
Select preset 2nd speed dial number.•
p1,
Start play•
Pause or resume play.•
Select preset station 1.•
Select preset 1st speed dial number.•
qDISP/DIM
Display radio frequency, clock and•
radio program type (if available).
Display track, elapsed time, artist,•
alburm, title, folder, file and clock.
Press and hold to access illuminate•
dimmer settings.
EN

9
dNumeric pad
Enter phone number.•
e*/EQ
Input symbol• *.
Select EQ setting.•
f1,
Start play.•
Pause or resume play.•
Select preset station 1.•
Select preset 1st quick dial number.•
gSHUF, 4
Set shuffle play mode.•
Select preset station 4.•
Select preset 4th quick dial number.•
h/OK
Mute or restore volume.•
Confirm selection.•
i/
Select tuner band.•
Scroll up/down menu.•
Select MP3/WMA folder.•
j
Store radio stations automatically.•
Brows files or folders.•
kSOURCE
Select audio source.•
lVOLUME +/-
Adjust volume.•
m
Terminate call•
n/TOP
Return to previous/top menu.•
oMENU
Access system menu.•
pAUDIO
Access audio setting menu.•
qINFO
Display playback information.•
Overview of the remote
control
a/
Tune to a radio station•
Skip track.•
Fast backward/forward playback•
b
Turn the unit on or off.•
c/
Answer phone.•
Dial number.•
Transfer phone call.•
j
k
m
n
o
p
q
r
l
b
c
e
d
i
a
f
g
s
u
t
h
English
EN

10
r#/SUB-W
Input symbol #. Turn on or off•
subwoofer.
sINTRO, 2
Turn intro play on or off.•
Select preset station 2.•
Enter phone number.•
Select preset 2nd quick dial number.•
t3, REP
Set repeat play mode.•
Select preset station 3.•
Enter phone number.•
Select preset 3rd quick dial number.•
u0+/DBB
Enter phone number.•
Turn on or off Dynamic Bass Boost•
(DBB) sound.
Input symbol• +.
EN

11
Note on the power supply lead (yellow)
When you connect other devices to this•
apparatus, ensure that the rating of the
car circuit is higher than the total fuse
value of all the connected devices.
Notes on speaker connection
Never connect speaker wires to the•
metal body or chassis of the car.
Never connect speaker wires with stripes•
to one another.
Overview of parts
These are the supplied parts needed to
connect and install this unit.
aIn-car audio system and sleeve
bStandard connector
cScrews (4 pieces)
dDisassembly tools
eRubber cushion
fFront panel
gTrim plate
12
34 5
67
3 Get started
Caution
Use the controls only as stated in this user•
manual.
Always follow the instructions in this chapter in
sequence.
If you contact Philips, you will be asked for the
model and serial number of your apparatus.The
model number and serial number are on the
bottom of your apparatus.Write the numbers
here:
Model No. __________________________
Serial No. ___________________________
Install the car audio
These instructions are for a typical installation.
However, if your car has different requirements,
make the corresponding adjustment. If you have
any questions regarding installation kits, consult
your Philips car audio dealer.
Caution
This unit is designed for negative ground•
(earth) 12 V DC operation only.
Always install this unit in the car dashboard.
•
Other locations can be dangerous as the rear
of the unit heats up during use.
To avoid short-circuit: before you connect,
•
ensure that the ignition is off.
Ensure that you connect the yellow and red
•
power supply leads after all other leads are
connected.
Ensure that all loose leads are insulated with
•
electrical tape.
Ensure that the leads do not get caught under
•
screws orin parts that will move (e.g. seat rail).
Ensure that all ground (earth) leads are run to
•
a common ground (earth) point.
Use only the supplied mounting hardware for a
•
safe and secure installation.
Improper fuses can cause damage or fire.
•
When you need to change the fuse, consult a
professional.
English
EN

12
Connect wires: without ISO
connectors
Caution
Ensure that all loose leads are insulated with•
electrical tape.
1Cut off the bigger end of the supplied
standard connector.
2Check the car’s wiring carefully, then
connect them to the standard connector.
ANTENNA
FRONT LINE OUT R
FRONT LINE OUT L
REAR LINE OUT L
REAR LINE OUT R
SUB OUT
Connect wires: ISO connectors
Caution
Ensure that all loose leads are insulated with•
electrical tape.
1Pull out the ISO connectors from the
car dashboard and connect them to
the bigger end of the supplied standard
connector.
2Connect the other end of supplied
standard connector to the unit.
3Do the other connections, if applicable.
EN

13
8 Purple and
purple/
black wires
Right speaker (Rear)
3Connect the supplied standard connector
to the unit.
4Do the other connections, if applicable.
Mount in the dashboard
1If the car does not have an on-board
drive or navigation computer, disconnect
the negative terminal of the car battery.
If you disconnect the car battery in•
a car that has an on-board drive or
navigation computer, the computer
may lose its memory.
ANTENNA
FRONT LINE OUT R
FRONT LINE OUT L
REAR LINE OUT L
REAR LINE OUT R
SUB OUT
Connector Connect to
1BlackwireA metal surface of the car
First connect the black
ground (earth) lead, then
connect the yellow and red
power supply leads.
2 Yellow wire The +12V car battery
which is live at all times.
3 Blue wire Motor/electric antenna
relay control lead/Amplifier
relay control lead
4Redwire The +12V power terminal
which is live in the
accessory (ACC) position
of the ignition switch
If there is no accessory
position, connect to the
+12V car battery terminal
that is always live. Be
sure to connect the black
ground (earth) lead to a
metal surface of the car
first.
5 Green and
green/black
wires
Left speaker (Rear)
6 White and
white/black
wires
Left speaker (Front)
7 Gray and
gray/black
wires
Right speaker (Front)
English
EN

14
5Install the sleeve into the dashboard and
bend the tabs outward to fix the sleeve.
Note
Skip this step if the unit is not fixed by sleeve•
but by supplied screws.
6Place the supplied rubber cushion over
the end of the mounting bolt.
7Slide the unit into the dashboard until you
hear a click sound.
8Reconnect the negative terminal of the
car battery.
Attach the front panel
1Attach the trim plate to the main unit.
2Insert the right side of the panel in the
chassis until it is correctly engaged.
3Push the left side of the panel and point
the left hole at the left pillar.
4Release the panel to engage the left side.
5mm
If the car battery is not disconnected,•
to avoid short-circuit, ensure that
bare wires do not touch each other.
2Remove the two screws on the top of the
unit.
3Remove the mounting sleeve with the
supplied disassembly tools.
4Ensure that car dashboard opening is
within these measurements:
183 mm
53mm
5mm
EN

15
Turn on
1Press to turn on the unit.
To turn off the unit, press• for 3
seconds.
Set clock
1Press MENU repeatedly until [TIME
FORMAT] (time format)displays.
2Use rotary encoder knob to toggle the
settings:
•[TIME FORMAT 12H]
•[TIME FORMAT 24H]
3Press or repeatedly until [CLOCK
SET] (clock set) displays.
Hour digits blinks»
4Set hour with rotary encoder knob.
5Press OK/MUTE to confirm.
Minute digits blinks»
6Set minute with rotary encoder knob.
7Press to confirm clock set and exit the
menu.
5Push the front side of the panel backward
to the main unit a “click” is heard.
Install remote control battery
Caution
Risk of explosion! Keep batteries away from•
heat, sunshine or fire. Never discard batteries
in fire.
Risk of decreased battery life! Never mix
•
different brands or types of batteries.
Risk of product damage! When the remote
•
control is not used for long periods, remove
the batteries.
Perchlorate Material - special handling may
•
apply. See www.dtsc.ca.gov/hazardouswaste/
perchlorate.
For first-time use:
1Remove the protective tab to activate the
remote control battery.
To replace the remote control battery:
1Open the battery compartment.
2Insert 1 CR2025 battery with correct
polarity (+/-) as indicated.
3Close the battery compartment.
English
EN

16
Store staions automatically
1Press SEARCH on the main unit.
The six strongest stations of the»
selected band are saved in preset
channels 1-6 automatically.
Store staions manually
1Tune to a station that you want to store.
2Press one of the numbered buttons 1to
6for 3 seconds.
The station is saved in the selected»
channel.
Tune to a preset station
1Press or to select band.
2Press the number button 1to 6to select
the preset station.
Play with RDS
The RDS (Radio Data System) function
operates only in areas with FM stations
broadcasting RDS signals. If you tune to an RDS
station, an RDS icon and information about the
presenter, station or program is displayed.
Turn on RDS
Note
By default, the RDS function is off.•
To adjust the RDS function, the unit must be•
under Radio playback mode.
1Press MENU for 3 seconds.
2Rotate encoder knob to select [RDS
ON]:
To turn off the RDS function, repeat•
steps above and choose [RDS OFF].
4 Listen to radio
Tune to a radio station
1Press SOURCE repeatedly to select
[Radio].
2Press or to select band: [FM1],
[FM2],[FM3],[AM1], or [AM2] .
3Press or to tune to a radio station
manually.
The radio station is broadcast.»
Select tuner area
You can select the suitable country area of the
radio.
1Under Radio mode, press MENU
repeatedly to select [AREA].
2Rotate encoder knob to select:
•[USA]
•[LATIN]
•[EUROPE]
•[RUSSIA]
Select tuner sensitivity
You can adjust the tuner sensitivity if you want
to receive more radio stations or only stations
with strong signal.
1Press MENU repeatedly to select
[LOCAL SEEK].
2Rotate encoder knob to select a setting:
•[LOCAL SEEK ON]: Only stations
with strong signal can be broadcast.
•[LOCAL SEEK OFF]: Stations with
strong and weak signals can be
broadcast.
Store radio stations in
memory
You can store up to 6 stations in each band.
EN

17
24 JAZZ Jazz Music
25 COUNTRY Country Music
26 NATION M National Music
27 OLDIES Oldies Music
28 FOLK M Folk Music
29 DOCUMENT Documentary
30 TEST Alarm Test
31 ALARM Alarm
Select alternate frequencies
If the radio signal come from the current
station is poor, you can turn on the AF
(Alternate Frequency) function to let the
unit searches for another station with
stronger signal but with the same program
identification as the current station
automatically.
1Press MENU until [AF] displays.
2Rotate encoder knob to select a setting.
•[AF ON]: Turn on the AF mode.
•[AF OFF]: Turn off the AF mode.
Receive traffic announcement
If you do not want to miss traffic
announcement during enjoying music, you
can turn on the TA (Traffic Announcement)
function.
1Press MENU until [TA] displays.
2Rotate encoder knob to select a setting:
•[TA ON]: When there is traffic
announcement, the unit switches
to the tuner mode (regardless of
the current mode) and begins to
broadcast the announcement on
traffic conditions. When the traffic
announcement is over, it returns to
the previous mode.
•[TA OFF]: Traffic announcement
does not cut in.
Select program type
Before tuning to RDS stations, you can select
program type and let the unit search only for
programs of the selected category.
1Press MENU until [PTY RDS] displays.
2Press OK/MUTE/ to confirm.
3Rotate encoder knob to select a type,
then press OK/MUTE/ to confirm.
Item Program type Description
1NEWS News services
2AFFAIRS Politics and
current affairs
3INFO Special
information
programs
4SPORT Sports
5EDUCATE Education
and advanced
training
6DRAMA Radio plays and
literature
7CULTURE Culture, religion
and society
8SCIENCE Science
9VARIED Entertainment
programs
10 POP M Pop music
11 ROCK M Rock music
12 EASY M Light music
13 LIGHT M Light classical
music
14 CLASSICS Classical music
15 OTHER M Special music
programs
16 WEATHER Weather
17 FINANCE Finance
18 CHILDREN Children’s
programs
19 SOCIAL Social Affairs
20 RELIGION Religion
21 PHONE IN Phone In
22 TRAVEL Travel
23 LEISURE Leisure
English
EN

18
»[Connect Ok!] displays if re-
connection is successful.
»[Connect Fail!] displays if re-
connection is failed.
Make a call
Note
To make an outgoing call on this unit, the•
bluetooth connection between the unit and
the phone must be active.
You can dial number through your mobile
phone or the remote control.
To make call through the remote control.
1Press until [NUM DIAL] displays.
2Press 0-9 to enter phone number.
Press• to delete entered
numbers.
3Press to dial.
To redial number:
1Press .
2Press or to choose [REDIAL].
3Press again.
»[Calling] displays and the unit starts
dialing the number dialed last time.
To quick dial preset number:
1Press .
2Press or to choose [QUICK DIAL].
3Press 1to 6numeric keys to choose
preset numbers.
Preset phone number displays.»
4Press again.
»[Calling] displays and the unit starts
dialing the selected number.
5 Use bluetooth
devices
With this car audio system, you can listen
to audio files from a player or make a call
if bluetooth connection is available on your
phone or player.
Pairing bluetooth devices
You can pair your bluetooth device with the
unit as follows:
Note
For pairing operation, make sure to switch on•
the [BT MODE] on the unit.
1Turn on bluetooth function on your
device.
2Search for other bluetooth devices that
can pair with your device.
3Select “Philips” in the pairing list.
4Enter default password “0000”.
»[Paired Ok!] displays on the panel if
pairing is successful.
The paired device connect to the car»
audio system automatically.
To disconnect the bluetooth
1Press MENU.
»[BT DIS-CONNECT] displays.
2Press OK/MUTE.
»[Dis Connect Ok!] displays if
disconnection is successful.
To re-connect the bluetooth
1Press MENU.
»[BT RE-CONNECT] displays.
2Press OK/MUTE.
»[Waiting] displays.
EN

19
Note
Some mobile phone supports auto playback,•
no need to start play manually.
Some mobile phone needs to open the Media
•
Players for audio files wireless playback.
To pause, press 1,• again.
To track up/down, press•/ .
Note
If no preset quick dial number is stored,•
[Empty] displays.
Preset quick dial numbers
You can preset and store up to 6 quick dial
numbers.
1Press .
2Enter the desired dial number directly.
3After completed the number input, within
20 seconds time out, press and hold the
1to 6numeric keys more than 3 seconds
to store the entered phone number.
The set numeric icon blinks.»
»[Store OK!] displays.
Call transfer
You can transfer voice from loudspeaker to
mobile phones during call.
1Press and hold until [MUTE] displays.
Voice transfers from loudspeaker to»
mobile phone.
Terminate call
1Press to terminate call.
Play audio files from
bluetooth devices
You can listen to audio from a bluetooth device
and control playback with the unit.
1Press SOURCE repeatedly to select [BT
Audio].
To start play, press•1, .
English
EN

20
Play from USB/SD/SDHC
device
Note
Ensure that the USB or SD/SDHC device•
contains playable music.
Insert the USB device
1Open the cover marked on the front
panel.
2Insert the USB device into the USB
socket.
The unit starts playing from the USB»
device automatically.
Remove the USB device
1Press and hold to turn off the unit.
2Remove the USB device.
Insert a card
Note
This unit supports SD and SDHC cards.•
1Press to release the panel.
6 Play audio files
Note
Ensure that the disc or device contains playable•
files.
Play a disc
Note
You cannot play CDs encoded with copyright•
protection technologies.
You can play commercially available audio CDs
and these discs:
CD-Recordables (CD-R)•
CD-Re-writables (CD-RW)•
MP3 CDs•
WMA CDs•
Note
Ensure that the disc contains playable content.•
1Press on the front panel to release the
panel.
2Insert a CD with the printed side facing
up.
3Close the panel.
Play starts automatically.»
To pause CD play, press•.
To resume CD play, press•again.
To remove the CD
1Press .
2Press beside the disc slot.
Tip
If the disc is blocked in the disc compartment,•
press and hold until the disc comes out.
EN

21
3Press OK/MUTE to access into the folder.
Or press and hold• OK/MUTE to play
the first file in the folder.
4Rotate encoder knob to select a file in
the folder
5Press OK/MUTE to play the selected file.
Tip
To go back to upper level of a folder, press•.
View play information
1During play MP3/WMA files, press
DISP/DIM repeatedly to view:
•[FOLDER]
•[FILE]
•[ALBUM]
•[TITLE]
•[ARTIST]
Intro play
You can play the first 10 seconds of each track.
1During play, press INTRO, 2 to select:
•[INTRO On]: After the first 10
seconds of each track have been
played, play stops.
•[INTRO Off]: Cancel intro play and
start normal play.
Shuffle play
You can play the tracks in random order.
1During play, press SHUF, 4 to select:
•[SHUFFLE On]: start shuffle play for
all tracks.
•[SHUFFLE Off]: cancel shuffle play.
2Insert the card into the card slot.
The unit starts playing from the card»
automatically.
Remove the card
1Press to turn off the unit.
2Press the card until you hear a click
sound.
The card is now disengaged.»
3Remove the card.
Control play
To select a folder, press• or .
To skip to the previous/next track, press•
or .
To search backward/forward rapidly•
within the current track, press or
for 3 seconds.
To pause, press• 1,.
To resume play, press•1,again.
Search for an MP3/WMA
track
1Press SEARCH.
»[Browse] displays.
2Rotate encoder knob to navigate trough
all folders on the disc/USB/SD card.
Folder names displays.»
English
EN
