Thank you for buying this Pioneer product.
Please read through these operating instructions so you will know how to operate
your model properly. After you have finished reading the instructions, put them away
in a safe place for future reference.
Before You S ar
About this unit 5
About this manual 5
After-sales service for Pioneer products 5
Precautions 5
Use and care of the remote control 6
Installing the battery 6
Using the remote control 6
Protecting your unit from theft 6
Removing the front panel 7
Attaching the front panel 7
Resetting the microprocessor 7
About the XM R ADY mark 7
Wha s Wha
Head unit 9
Remote control 10
Power ON/OFF
Turning the unit on 11
Selecting a source 11
Turning the unit off 11
Tuner
Listening to the radio 12
Introduction of advanced tuner
operation 14
Storing and recalling broadcast
frequencies 14
Tuning in strong signals 15
Storing the strongest broadcast
frequencies 15
Casse e Player
Playing a tape 16
Introduction of advanced cassette player
operation 18
Repeating play 18
Skipping blank tape sections 19
Using Dolby noise reduction 19
Buil -in CD player
Playing a CD 20
Introduction of advanced built-in CD player
operation 22
Repeating play 22
Playing tracks in a random order 23
Scanning tracks of a CD 23
Pausing CD playback 23
Using disc title functions 23
ntering disc titles 24
Displaying disc titles 24
Using CD T XT functions 25
Displaying titles on CD T XT
discs 25
Scrolling titles in the display 25
Mul i-CD Player
Playing a CD 26
Introduction of advanced multi-CD player
operation 28
Repeating play 29
Playing tracks in a random order 29
Scanning CDs and tracks 29
Pausing CD playback 30
Using ITS playlists 30
Creating a playlist with ITS
programming 30
Playback from your ITS playlist 30
rasing a track from your ITS
playlist 31
rasing a CD from your ITS
playlist 31
Using disc title functions 31
ntering disc titles 31
Displaying disc titles 32
Selecting discs from the disc title
list 32
Using CD T XT functions 33
Displaying titles on CD T XT
discs 33
Scrolling titles in the display 33
Contents
En
2

Black plate (3,1)
3 CRD3580 A/N
3 CRD3580-A/N
Using compression and bass emphasis 33
50-disc multi-CD player 34
Audio Adjus men s
Introduction of audio adjustments 35
Using balance adjustment 35
Adjusting loudness 36
Adjusting source levels 36
Digi al Signal Processor
Using the digital signal processor 37
Using the graphic equalizer 38
Recalling equalizer curves 38
Adjusting equalizer curves 38
Adjusting 9-band graphic
equalizer 39
Using sound field control, octaver and BB
sound 39
Recalling sound field programs 39
Adjusting BB sound level 40
Using the position selector 40
Using subwoofer output 41
Adjusting subwoofer settings 41
Using the high pass filter 41
Ini ial Se ings
Adjusting initial settings 42
Setting the time 42
Switching the warning tone 43
Switching the auxiliary setting 43
Switching the dimmer setting 43
Switching the rear output setting 43
Selecting the digital attenuator 44
Adjusting display contrast 44
O her Func ions
Introduction of other functions 45
Using the demonstration 45
Using different entertainment displays 45
Cellular telephone muting 46
Setting the time display on or off 46
Using the AUX source 46
Selecting AUX as the source 46
Setting the AUX title 46
Addi ional Informa ion
Understanding built-in CD player error
messages 48
Cassette tapes 48
Cleaning the playback head 48
Music search and repeat functions during
tape playback 48
CD player and care 49
CD-R/CD-RW discs 49
Specifications 50
Contents
En 3
English

Black plate (4,1)
4 CRD3580-A/N
Selecting fine audio equipment such as the unit you’ve just purchased is only the start of your
musical enjoyment. Now it’s time to consider how you can maximize the fun and excitement your
equipment offers. This manufacturer and the Electronic Industries Association’s Consumer
Electronics Group want you to get the most out of your equipment by playing it at a safe level. One
that lets the sound come through loud and clear without annoying blaring or distortion—and, most
importantly, without affecting your sensitive hearing.
Sound can be deceiving. Over time your hearing “comfort level” adapts to higher volumes of
sound. So what sounds “normal” can actually be loud and harmful to your hearing. Guard against
this by setting your equipment at a safe level BEFORE your hearing adapts.
To establish a safe level:
•Start your volume control at a low setting.
•Slowly increase the sound until you can hear it comfortably and clearly, and without distortion.
Once you have established a comfortable sound level:
•Set the dial and leave it there.
Taking a minute to do this now will help to prevent hearing damage or loss in the future. After
all, we want you listening for a lifetime.
We Want You Listening For A Lifetime
Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment. Since
hearing damage from loud noise is often undetectable until it is too late, this manufacturer and the
Electronic Industries Association’s Consumer Electronics Group recommend you avoid prolonged
exposure to excessive noise. This list of sound levels is included for your protection.
Decibel
Level Example
30 Quiet library, soft whispers
40 Living room, refrigerator, bedroom away from traffic
50 Light traffic, normal conversation, quiet office
60 Air conditioner at 20 feet, sewing machine
70 Vacuum cleaner, hair dryer, noisy restaurant
80 Average city traffic, garbage disposals, alarm clock at two feet.
THE FOLLOWING NOISES CAN BE DANGEROUS UNDER CONSTANT EXPOSURE
90 Subway, motorcycle, truck traffic, lawn mower
100 Garbage truck, chain saw, pneumatic drill
120 Rock band concert in front of speakers, thunderclap
140 Gunshot blast, jet plane
180 Rocket launching pad
Information courtesy of the Deafness Research Foundation.
4En

Black plate (5,1)
5 CRD3580-A/N
About this unit
The tuner frequencies on this unit are allo-
cated for use in North America. Use in other
areas may result in improper receiption.
Impor an
The serial number is located on the top of this
unit. For your own security and convenience, be
sure to record this number on the enclosed
warranty card.
About this manual
This unit features a number of sophisticated
functions ensuring superior reception and op-
eration. All the functions have been designed
for the easiest possible use, but many are not
self-explanatory. This operation manual will
help you benefit fully from this productspo-
tential and to maximize your listening enjoy-
ment.
We recommend that you familiarize yourself
with the functions and their operation by read-
ing through the manual before you begin
using this unit. It is especially important that
you read and observe precautions on this page
and in other sections.
After-sales service for
Pioneer products
Please contact the dealer or distributor from
where you purchased this unit for after-sales
service (including warranty condtions) or any
other information. In case the necessary infor-
mation is not available, please contact the
companies listed below:
Please do not ship your unit to the companies
at the addresses listed below for repair without
advance contact.
U.S.A.
Pioneer lectronics (USA) Inc.
CUSTOM R SUPPORT DIVISION
P.O. Box 1760
Long Beach, CA 90801-1760
800-421-1404
CANADA
Pioneer lectronics of Canada, Inc.
CUSTOM R SATISFACTION D PARTM NT
300 Allstate Parkway
Markham, Ontario L3R OP2
[phone]
1-877-283-5901
For warranty information please see the Lim-
ited Warranty sheet included with this unit.
Precautions
CAUTION:
USE OF CONTRO OR ADJUSTMENT OR
PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN MAY
RESU T IN HAZARDOUS RADIATION
EXPOSURE.
CAUTION:
THE USE OF OPTICA INSTRUMENTS
WITH THIS PRODUCT WI INCREASE EYE
HAZARD.
!Keep this manual handy as a reference for
operating procedures and precautions.
!Always keep the volume low enough so you
can hear sounds outside of the car.
!Protect this product from moisture.
Before You Start 01
En 5
English
Sec ion

Black plate (6,1)
6 CRD3580-A/N
!If the battery is disconnected or discharged,
the preset memory will be erased and must be
reprogrammed.
Use and care of the remote
control
Installing the battery
Slide the tray out on the back of the remote
control and insert the battery with the plus (+)
and minus () poles pointing in the proper di-
rection.
WARNING
Keep the battery out of the reach of children.
Should the battery be swallowed, immediately
consult a doctor.
CAUTION
!Use only one CR2025 (3V) lithium battery.
!Remove the battery if the remote control is
not to be used for a month or longer.
!Do not recharge, disassemble, heat or
dispose of battery in fire.
!Do not handle the battery with metallic tools.
!Do not store the battery with metallic
materials.
!In the event of battery leakage, wipe the
remote control completely clean and install a
new battery.
!When disposing of used batteries, please
comply with governmental regulations or
environmental public institutions rules that
apply in your country/area.
Using the remote control
Point the remote control in the direction of the
front panel to operate.
Impor an
!Do not store the remote control in high
temperatures or direct sunlight.
!The remote control may not function
properly in direct sunlight.
!Do not let the remote control fall onto the
floor, where it may become jammed under the
brake or accelerator pedals.
Protecting your unit from
theft
The front panel can be detached from the
head unit and stored in the protective case
provided to discourage theft.
!If the front panel is not detached from the
head unit within five seconds of turning off
the ignition, a warning tone will sound.
!You can turn off the warning tone. See
Switching the warning tone on page 43.
Impor an
!Never use force or grip the display and the
buttons tightly when removing or attaching.
!Avoid subjecting the front panel to excessive
shocks.
!Keep the front panel out of direct sunlight
and hight temperatures.
Before You Start
01
En
6
Sec ion

Black plate (7,1)
7 CRD3580-A/N
Removing the front panel
1 Press DETACH to release the front
panel.
Press DETACH and the left side of the panel is
released from the head unit.
DETACH button
2 Grab the front panel and remove.
Grab the left side of the front panel and pull
away to the right. The front panel will be de-
tached from the head unit.
3 Put the front panel into the
protective case provided for safe keepin .
Attaching the front panel
1 Place the front panel flat a ainst
the head unit.
2 Press the front panel into the face
of the head unit until it is firmly seated.
Resetting the
microprocessor
The microprocessor must be reset under the
following conditions:
!Prior to using this unit for the first time after
installation
!If the unit fails to operate properly
!When strange or incorrect messages appear
on the display
1 Remove the front panel.
See Removing the front panel on this page.
2 Press RESET on the head unit with a
pen tip or other pointed instrument.
RESET button
About the X READY mark
The XM R ADY mark printed on the front pa-
nel indicates that the Pioneer XM tuner (sold
separately) can be controlled by this unit.
Please inquire to your dealer or nearest
authorized Pioneer service station regarding
the XM tuner that can be connected to this
unit. For XM tuner operation, please refer to
the XM tuner owners manual.
No es
!XM Satellite Radio is developing a new band
of radio in the U.S.A.
Before You Start 01
En 7
English
Sec ion

Black plate (8,1)
8 CRD3580-A/N
The system will use direct satellite-to-receiver
broadcasting technology to provide listeners
in their cars and at home with crystal-clear
sound seamlessly from coast to coast. XM will
create and package up to 100 channels of
digital-quality music, news, sports, talk and
childrens programming.
!The XM name and related logos are
trademarks of XM Satellite Radio Inc.
!When this unit is connected to a XM tuner,
only one additional external unit can also be
connected. Please see page 11 for more
information about the external unit.
Before You Start
01
En
8
Sec ion

Black plate (9,1)
9 CRD3580-A/N
1
5
!
7
6
9
0
8
~
3
-
4
=
@
2
Head unit
1DETACH button
Press to remove the front panel from the
head unit.
2FUNCTION button
Press to select functions.
3AUDIO button
Press to select various sound quality con-
trols.
4DSP button
Press to select sound field functions.
5TAPE EJECT button
Press to eject a tape from your cassette
player.
6SOURCE button
This unit is switched on by selecting a
source. Press to cycle through all of the
available sources.
7ENTERTAINMENT button
Press to change to the entertainment dis-
play.
8LOUD button
Press to switch loudness on or off.
9DISPLAY button
Press to select different displays.
a16 buttons
Press for preset tuning and disc number
search when using a multi-CD player.
ba/b/c/dbuttons
Press to do manual seek tuning, fast for-
ward, reverse and track search controls.
Also used for controlling functions.
cCLOCK button
Press to change to the clock display.
dCD EJECT button
Press to eject a CD from your built-in CD
player.
eBAND button
Press to select among three FM and one
AM band and cancel the control mode of
functions.
fVOLUME button
Press to increase or decrease the
volume.
Whats What 02
En 9
English
Sec ion

Black plate (10,1)
10 CRD3580-A/N
2
-
3
%
!
@
^
#
$
Remote control
The supplied remote control enables conveni-
ent remote operation of the head unit. Opera-
tion is the same as when using button on the
head unit.
gCD button
Press to select the built-in or multi-CD
player as source.
hCASSETTE button
Press to select the cassette player as
source.
iTUNER button
Press to select the tuner as source.
jATT button
Press to quickly lower the volume level, by
about 90%. Press once more to return to the
original volume level.
Whats What
02
En
10
Sec ion

Black plate (11,1)
11 CRD3580-A/N
Turning the unit on
%Press SOURCE on the head unit, or
press TUNER, CASSETTE or CD on the
remote, to turn the unit on.
When you select a source the unit is turned
on.
Selecting a source
You can select a source you want to listen to.
To switch to the built-in CD player, load a disc
in this unit (refer to page 20). To switch to the
cassette player, load a cassette tape in this
unit (refer to page 16).
%When usin the head unit, press
SOURCE to select a source.
Press SOURCE repeatedly to switch between
the following sources:
Built-in CD playerTelevisionTuner
Cassette playerMulti-CD playerExter-
nal unit 1External unit 2 AUX
%When usin the remote control, press
TUNER, CASSETTE or CD to select a source.
Press each button repeatedly to switch be-
tween the following sources:
TUNER:TelevisionTunerSources off
CASSETTE:Cassette playerAUXSources
off
CD:Built-in CD playerMulti-CD player
Sources off
No es
!In the following cases, the sound source will
not change:
When a product corresponding to each
source is not connected to this unit.
When no disc is set in this unit.
When no cassette is set in this unit.
When no magazine is set in the multi-
CD player.
When the AUX (auxiliary input) is set to
off (refer to page 43).
!xternal unit refers to a Pioneer product
(such as one available in the future) that,
although incompatible as a source, enables
control of basic functions by this unit. Two
external units can be controlled by this unit.
When two external units are connected, the
allocation of them to external unit 1 or
external unit 2 is automatically set by this unit.
!When this units blue/white lead is
connected to the cars auto-antenna relay
control terminal, the cars antenna extends
when this units source is switched on. To
retract the antenna, switch the source off.
Turning the unit off
%Press SOURCE on the head unit and
hold for at least one second to turn the
unit off.
When using the remote control, press TUNER,
CASSETTE or CD repeatedly.
Power ON/OFF 03
En 11
English
Sec ion

Black plate (12,1)
12 CRD3580-A/N
Listening to the radio
1 3
2
5
467
6
8
5
7
These are the basic steps necessary to operate
the radio. More advanced tuner operation is
explained starting on page 14.
1Band indicator
Shows which band the radio is tuned to, AM
or FM.
2Stereo (5) indicator
Shows that the frequency selected is being
broadcast in stereo.
3Frequency indicator
Shows to which frequency the tuner is
tuned.
4SOURCE button
Press to select the tuner as the source.
5BAND button
Press to select among three FM and one
AM band.
6c/dbuttons (Manual or seek tunin )
Press to tune in a radio station.
7VOLUME button
Press to increase or decrease the volume.
8TUNER button
Press to select the tuner as the source.
1 Press SOURCE on the head unit, or
TUNER on the remote, to select the tuner.
Press SOURCE or TUNER until you see Tuner
displayed.
2 Use VOLUME to adjust the sound
level.
When you press VOLUME up/+, the volume is
raised and when pressed down/, the volume
is lowered.
3 Press BAND to select a band.
Press BAND until the desired band is dis-
played, F1,F2,F3 for FM or AM.
4 To perform manual tunin , press c
or dwith quick presses.
The frequencies move up or down step by
step.
5 To perform seek tunin , press and
hold cor dfor about one second and
release.
The tuner will scan the frequencies until a
broadcast strong enough for good reception is
found.
Tuner
04
En
12
Sec ion

Black plate (13,1)
13 CRD3580-A/N
#You can cancel seek tuning by pressing
either cor dwith a quick press.
#If you press and hold cor dyou can skip
broadcasting stations. Seek tuning starts as soon
as you release the buttons.
No e
When the frequency selected is being broadcast
in stereo the stereo (5) indicator will light.
Tuner 04
En 13
English
Sec ion

Black plate (14,1)
14 CRD3580-A/N
Introduction of advanced
tuner operation
2
1
3
5
7
6
4
8
4
7
5
8
1Function display
Shows the function status.
2Preset number indicator
Shows what preset has been selected.
3LOC indicator
Shows when local seek tuning is on.
4FUNCTION button
Press to select an advanced function.
5BAND button
Press to return to the frequency display.
616 buttons (Preset tunin )
Press for one-button selection of radio sta-
tions you have entered into memory. To
store a radio station, press and hold.
7c/dbuttons
Press to choose the item (mode) of the se-
lected function.
8a/bbuttons
Press to select frequencies stored in mem-
ory and turn the selected function on/off.
%Press FUNCTION to display the
function names.
Press FUNCTION repeatedly to switch be-
tween the following functions:
BSM (best station memory)LOCAL (local
seek tuning)
#To return to the frequency display, press
BAND.
No e
If you do not operate the function within about 30
seconds, the display is automatically returned to
the frequency display.
Storing and recalling
broadcast frequencies
If you press any of the preset tuning buttons
16you can easily store up to six broadcast
frequencies for later recall with the touch of a
button.
Tuner
04
En
14
Sec ion

Black plate (15,1)
15 CRD3580-A/N
%When you find a frequency that you
want to store in memory press a preset
tunin button 16 and hold until the preset
number stops flashin .
The number you have pressed will flash in the
preset number indicator and then remain lit.
The selected radio station frequency has been
stored in memory.
The next time you press the same preset tun-
ing button 16the radio station frequency is
recalled from memory.
No es
!Up to 18 FM stations, 6 for each of the three
FM bands, and 6 AM stations can be stored in
memory.
!You can also use aand bto recall radio
station frequencies assigned to preset tuning
buttons 16.
Tuning in strong signals
Local seek tuning lets you tune in only those
radio stations with sufficiently strong signals
for good reception.
1 Press FUNCTION to select LOCAL.
Press FUNCTION until LOCAL appears in the
display.
2 Press ato turn local seek tunin on.
Local seek sensitivity (e.g., LOCAL 2) appears
in the display.
3 Press cor dto set the sensitivity.
There are four levels of sensitivity for FM and
two levels for AM:
FM: LOCAL 1LOCAL 2LOCAL 3
LOCAL 4
AM: LOCAL 1LOCAL 2
The LOCAL 4 setting allows reception of only
the strongest stations, while lower settings let
you receive progressively weaker stations.
4 When you want to return to normal
seek tunin , press bto turn local seek
tunin off.
LOCAL :OFF appears in the display.
Storing the strongest
broadcast frequencies
BSM (best stations memory) lets you automa-
tically store the six strongest broadcast fre-
quencies under preset tuning buttons 16and
once stored there you can tune in to those fre-
quencies with the touch of a button.
1 Press FUNCTION to select BSM.
Press FUNCTION until BSM appears in the
display.
2 Press ato turn BSM on.
BSM begins to flash. While BSM is flashing
the six strongest broadcast frequencies will be
stored under preset tuning buttons 16in or-
der of their signal strength. When finished,
BSM stops flashing.
#To cancel the storage process, press b.
No e
Storing broadcast frequencies with BSM may
replace broadcast frequencies you have saved
using 16.
Tuner 04
En 15
English
Sec ion

Black plate (16,1)
16 CRD3580-A/N
Playing a tape
123
57
68
4
7
9
6
8
These are the basic steps necessary to play a
tape with your cassette player. More advanced
cassette player operation is explained starting
on page 18.
1Tape direction indicator
Shows the direction of the tape transport.
2Play time indicator
Shows the elapsed playing time of the cur-
rent side of the tape.
3MTL indicator
Shows when a metal or chrome tape is in-
serted.
4TAPE EJECT button
Press to eject a tape from your cassette
player.
5SOURCE button
Press to select the cassette player as the
source.
6BAND button
Press to change the direction of the tape
transport and return to playback after fast
forward or rewind.
7c/dbuttons
Press to fast forward or rewind the tape.
8VOLUME button
Press to increase or decrease the volume.
9CASSETTE button
Press to select the cassette player as the
source.
1 Insert a cassette tape into the
cassette loadin slot.
Playback will automatically start.
Cassette loading slot
#You can eject a cassette tape by pressing
TAPE EJECT.
2 After a cassette tape has been
inserted, press SOURCE on the head unit,
or CASSETTE on the remote, to select the
cassette player.
Press SOURCE or CASSETTE until you see
Cassette displayed.
Cassette Player
05
En
16
Sec ion

Black plate (17,1)
17 CRD3580-A/N
3 Use VOLUME to adjust the sound
level.
When you press VOLUME up/+, the volume is
raised and when pressed down/, the volume
is lowered.
4 To perform fast forward or rewind,
press cor d.
FF or REW appears in the display.
#To cancel fast forward or rewind and return
to playback, press BAND.
#You can cancel fast forward or rewind by
pressing cor din the same direction twice.
5 To perform forward or rewind music
search, press cor dtwice.
F-MS (forward music search) or R-MS (rewind
music search) appears in the display. The cas-
sette player will fast forward or rewind to the
next or previous blank spot on the tape and be-
gin to play.
#To cancel music search and return to play-
back, press BAND.
#You can cancel music search by pressing c
or din the same direction again.
6 To chan e the direction of the tape
transport, press BAND.
No es
!Do not insert anything other than a cassette
tape into the cassette loading slot.
!Play time indicator starts from 0000 in the
following cases:
When a tape is inserted
When the tape direction is changed
When you rewind the tape to the begin-
ning
!Play time indicator is halted when fast
forward, rewind or music search is
operating.
Cassette Player 05
En 17
English
Sec ion

Black plate (18,1)
18 CRD3580-A/N
Introduction of advanced
cassette player operation
1
342
57
6
5
6
7
1Function display
Shows the function status.
22B indicator
Shows when Dolby B NR is turned on.
3B.SKIP indicator
Shows when blank skip is turned on.
4RPT indicator
Shows when repeat play is turned on.
5FUNCTION button
Press to select an advanced function.
6BAND button
Press to return to the playback display.
7a/bbuttons
Press to turn the selected function on/off.
%Press FUNCTION to display the
function names.
Press FUNCTION repeatedly to switch be-
tween the following functions:
REPEAT (repeat play)B.SKIP (blank skip)
NR (Dolby B NR)
#To return to the playback display, press
BAND.
No e
If you do not operate the function within about 30
seconds, the display is automatically returned to
the playback display.
Repeating play
Repeat play lets you hear the same track over
again.
1 Press FUNCTION to select REPEAT.
Press FUNCTION until REPEAT appears in the
display.
2 Press ato turn repeat play on.
REPEAT :ON appears in the display. The track
presently playing will play and then repeat.
3 Press bto turn repeat play off.
REPEAT :OFF appears in the display. The track
presently playing will continue to play and
then play the next track.
Cassette Player
05
En
18
Sec ion

Black plate (19,1)
19 CRD3580-A/N
Skipping blank tape
sections
Blank skip automatically fast forwards to the
next song if there is a long period of silence
(12 seconds or longer) between songs.
1 Press FUNCTION to select B.SKIP.
Press FUNCTION until B.SKIP appears in the
display.
2 Press ato turn blank skip on.
B.SKIP :ON appears in the display. Long peri-
ods of silence between songs will be skipped.
3 Press bto turn blank skip off.
B.SKIP :OFF appears in the display. The com-
plete cassette tape will play.
Using Dolby noise
reduction
When you listen to tapes that have been re-
corded with Dolby B NR, turn Dolby B NR on.
1 Press FUNCTION to select NR.
Press FUNCTION until NR appears in the dis-
play.
2 Press ato turn Dolby B NR on.
B NR :ON appears in the display. The tape will
play with Dolby B NR on.
3 Press bto turn Dolby B NR off.
NR :OFF appears in the display. The tape will
play without Dolby B NR.
No e
Manufactured under license from Dolby
Laboratories. Dolbyand the double-D symbol
are trademarks of Dolby Laboratories.
Cassette Player 05
En 19
English
Sec ion

Black plate (20,1)
20 CRD3580-A/N
Playing a CD
1 2
45
3
6
5
7
6
These are the basic steps necessary to play a
CD with your built-in CD player. More ad-
vanced CD operation is explained starting on
page 22.
1Track number indicator
Shows the track currently playing.
2Play time indicator
Shows the elapsed playing time of the cur-
rent track.
3CD EJECT button
Press to eject a CD from your built-in CD
player.
4SOURCE button
Press to select the built-in CD player as the
source.
5c/dbuttons (Track search and FF/
REV)
Press to select a track from the current CD
and for fast forward and reverse.
6VOLUME button
Press to increase or decrease the volume.
7CD button
Press to select the built-in CD player as the
source.
1 Insert a CD into the CD loadin slot.
Playback will automatically start.
CD loading slot
#You can eject a CD by pressing CD EJECT.
2 After a CD has been inserted, press
SOURCE on the head unit, or CD on the
remote, to select the built-in CD player.
Press SOURCE or CD until you see
CompactDisc displayed.
3 Use VOLUME to adjust the sound
level.
When you press VOLUME up/+, the volume is
raised and when pressed down/, the volume
is lowered.
Built-in CD player
06
En
20
Sec ion
